Page 1
Item # _____________________________________
Quantity ___________________________________
C.S.I. Section 11400
DGC5 SERIES GAS
701 S Ridge Avenue, Troy, OH 45374
1-888-4HOBART • www.hobartcorp.com
STANDARD FEATURES
■ Stainless Steel Front, Sides, Top and Back
■ Painted Legs
■ Solid Stainless Steel Doors
■ 44,000 BTU/hr. Burner per Section
■ Electronic Spark Ignition
■ 1⁄2 H.P. Two Speed Oven Blower Motors.
115/60/1 with 6' Cord and Plug, 9 Amps.
■ Side Mounted Solid State Temperature Controls
Adjust from 150° to 500°F
■ 60 Minute Timer with Audible Alarm per Section
■ Oven Cool Switch for Rapid Cool Down
■ Porcelain Enamel on Steel Oven Interior
■ Five Nickel Plated Oven Racks with Eleven Rack
Positions per Section
■ 3⁄4" Rear Gas Connection with Gas Pressure
Regulator and Manual Shut-Off Valve
CONVECTION OVENS
MODELS
❑ DGC501 – Single Deck Gas Convection Oven
❑ DGC502 – Double Deck Gas Convection Oven
❑ DGC504 – Single Deck Gas Convection Oven
with Open Stand
ACCESSORIES
❑ Extra Oven Rack(s)
❑ Stainless Steel Drip Pan
❑ Down Draft Flue Diverter for Direct Vent
Connection
❑ Stacking Kit (DGC501 only)
Specifications, Details and Dimensions on Inside and Back.
DGC5 SERIES GAS CONVECTION OVENS
OPTIONS
❑ Stainless Steel Legs
❑ Stainless Steel Doors with Windows
❑ Cook & Hold Control
❑ Casters
F-39821 – DGC5 Series Gas Convection Ovens Page 1 of 4
Page 2
DGC5 SERIES GAS
CONVECTION OVENS
IMPORTANT
1. A gas pressure regulator sized for this unit is included.
Natural gas 3.5" W.C., propane gas 10.0" W.C.
2. An adequate ventilation system is required for
commercial cooking equipment. Information may be
obtained by writing to the National Fire Protection
Association, Batterymarch Park, Quincy, MA 02289.
When writing, refer to NFPA No. 96.
3. These units are manufactured for installation in
accordance with ANSZ223.1A (latest edition), National
Fuel Gas Code. Copies may be obtained from the
American Gas Association, 1515 Wilson Blvd.,
Arlington, VA 22209.
4. Clearances: Combustible Non-combustible
Rear 6" 0"
Sides 6" 0"
5. This appliance is manufactured for commercial
installation only and is not intended for home use.
701 S Ridge Avenue, Troy, OH 45374
1-888-4HOBART • www.hobartcorp.com
DEPTH
(INCLUDES
MODEL NO. WIDTH
DGC501 40" 411⁄2" 563⁄4" 44,000 44,000 115/60/1 483
DGC502 40" 411⁄2" 70" 44,000 88,000 115/60/1 1,180
HANDLES) HEIGHT
BTU/HR.
PER OVEN
TOTAL
BTU/HR. ELECTRICAL
APPROX.
SHP. WT.
LBS.
Page 2 of 4 F-39821 – DGC5 Series Gas Convection Ovens
Page 3
DGC5 SERIES GAS
701 S Ridge Avenue, Troy, OH 45374
1-888-4HOBART • www.hobartcorp.com
DETAILS AND DIMENSIONS
CONVECTION OVENS
F-39821 – DGC5 Series Gas Convection Ovens Page 3 of 4
Page 4
Printed On Recycled Paper
DGC5 SERIES GAS
CONVECTION OVENS
SPECIFICATIONS
General: Gas convection oven. Basic section
(DGC5) is without legs; may be ordered separately
for replacement, for stacking 2-high or for mounting
on legs. DGC501 single basic section on 253⁄4" legs.
DGC502 two basic DGC5 sections on 8" legs.
Construction: Stainless steel front, sides and top,
painted legs. Porcelain enamel on steel oven
interior. Independently operated solid stainless steel
doors open a full 180 degrees. Two interior oven
lights per section. Non-sag insulation applied to the
top, rear and sides, bottom and doors.
Oven interior measures 29" w x 221⁄8" d x 20"h. Five
nickel plated oven racks per section measure 281⁄4" x
201⁄2". Eleven position nickel plated rack guides with
positive rack stops per section.
701 S Ridge Avenue, Troy, OH 45374
1-888-4HOBART • www.hobartcorp.com
Controls: Side mounted solid state temperature
controls adjust from 150° to 500°F. 60-minute timer
with audible alarm. Oven cool switch for rapid cool
down.
Gas: One 44,000 BTU/hr. burner per section. 88,000
BTU/hr. for Model DGC502. Electronic spark igniter.
Electrical: Two-speed 1⁄2 H.P. oven blower motor per
section. 115/60/1 power supply required. 6 foot cord
and plug. 9 amps total draw.
IMPORTANT
WHEN ORDERING: The following must be specified:
1) The type of gas
2) The altitude when above 2,000 ft.
As continued product improvement is a policy of Hobart, specifications are subject to change without notice.
Page 4 of 4 F-39821 – DGC5 Series Gas Convection Ovens
F-39821 (REV. 05/07) LITHO IN U.S.A. (H-01)
