Mannatech serenity Operation Manual

HOME DIFFUSER

OPERATION MANUAL

English 2

Español 8

Chinese 14

Languages

Overview

Mannatech’s Serenity Home Diffuser functions as a humidier, atomizer and

aroma diffuser in one simple-to-use product. By using ultrasonic high-frequency

oscillation, the Serenity Home Diffuser converts any mixture of essential oils and
water into millions of micro particles, disperses them into the air and releases the

aromas found in Mannatech 100% Essential Oils™ line. It’s custom designed with
a built-in safety system that automatically shuts-off when the diffuser runs out of

liquid. It also provides soothing ambient light, making it effective for enjoying a
spa-like atmosphere anywhere in your home at any time.

Specications and Contents

Power Supply : (Input) AC100-240V 50/60Hz

(Output) 18V 500mA

Power : 9W

Product Size : 19x19x20cm

Product Weight :about 550g (with adaptor)

Type : Ultrasonic
Recommended

Water Level :

600ml (MAX)

Suitable Area :10-15 m

2

Accessories :

Adaptor, measuring
cup,manual

Materials : ABS, PP

Water : Tap water only

2

Read Before Use for Safety

1. This product can be only used in the house.

2. Please make sure that the manual is saved.

3. The unit should be used out of the reach of children.

4. Unplug Diffuser from outlet when not in use and before cleaning

.

3

Diagram

Measuring Cup

Mist Nozzle

Ultrasonic

Nebulizer Plate

Water Level Sensor

LED Light

LED Indicator

LED Button

Mist Button

AC Supply

DC Supply

DC Plug Base

Air Outlet

Base

Cover

Water Reservoir

Operating Instructions

1. Please insert the DC supply plug
into the plug base of the product.

2. Position the unit on a flat and hard surface.
Remove the upper cover from the base.

6. Place the upper cover on the base.
Please make sure it fits perfectly.

6. Plug in and turn on the appliance
using the mist button.

3. Fill the tank with water

up to the max level of 600ml.

5. Add 5-8 drops of essential oils into the water.

Always fill in water before you add essential oil.

4

Functionality

Light Button

Indicator

Light

Button

Mist

Button

Mist Button

1st press: 3 LED lights (warm yellow) on

2nd press: 3 LED lights (warm yellow) off

1st press: mist level is set to be high—Two LED indicator lights on at the same time (blue).
2nd press: will change to low mist level—Top LED indicator light on (blue).

3rd press: stop the mist—Indicator lights off

This button controls the LED lights.

This button controls the mist level.

The unit stops spraying when
the water is almost depleted:

To Resume: Simply switch off

and rell the water tank with

tap water and add drops of

essential oils. Place the cover
back on the main base. Switch
back on to start the diffuser’s

function.

To power off: Unplug the unit
when not in use and before
cleaning. Pour out the water

remaining in the tank. Wipe the

diffuser with a soft damp cloth
and buff with a dry cloth.

Safety and Care

Please read and follow these safety guidelines closely to ensure safe
operation of the diffuser.

1. Unplug the diffuser immediately and discontinue use in the event of smoke
or a burning smell.

2. Use room-temperature tap or spring water. Do not use distilled or

puried water.

3. Never wrap the adaptor with cloth, paper, etc. Such actions may result in
damage to the diffuser or re.

4. Never touch the adaptor with wet hands; electric shock or injury may occur.

5. Do not disassemble or attempt to repair the diffuser; this will void the
warranty.

5

6. Never immerse the diffuser in water.

7. Unplug the adaptor when relling, cleaning or moving the diffuser.

8. Keep the diffuser out of reach of children.

9. Do not remove or place objects in the water reservoir during operation.

10. Do not place your ngers in the water during operation; this may result in

injury.

11. Do not place acidic or alkaline chemicals in the water reservoir.

12. Use only the included power adaptor provided in the packaging or by
Mannatech.

13. Do not shake the diffuser.

14. Any damage caused by the user does not qualify for replacement by
Mannatech.

15. Never use the product for purposes other than those listed in this manual.

16. Clean the unit before switching to different essential oils.

17. The water reservoir level should not exceed the MAX ll level of 600 ml.

18. When unplugging the power adaptor, pull from the adaptor plug instead of
pulling the wire.

19. Avoid placing the product under direct sunlight, close to a refrigerator or

fan or in a hot environment.

Cleaning and Maintenance

1. Always turn off and unplug the diffuser prior to cleaning.

2. To ensure proper performance, clean the ultrasonic plate after each

use. Never use a corrosive detergent to clean the ultrasonic plate or

damage will occur.

3. You can use one of two ways to clean the ultrasonic plate:

a. Pour a small amount of rubbing alcohol on a Q-tip and wipe the

plate.

b. Mix ¼ cup vinegar and 1 ¼ cups of water, pour in diffuser and let

run until it stops, then dump out the excess.

DO NOT USE ANY OTHER TYPES OF CLEANSERS OR METAL!

4. Periodically check under the diffuser to keep the fan intake free of
debris. Debris can be removed by blowing on the fan intake opening
or wiping with a clean, dry cloth. (Do not use aerosol sprays, solvents
or abrasives to clean the plastic housing.)

5. When not in use, clean the diffuser and store dry.

6

U.S. Shipping

600 S. Royal Ln., Ste. 200, Coppell, TX 75019 USA

Mannatech.com

Troubleshooting

1. If the mist of the Diffuser has noticeably decreased, the Diffuser

and Ultrasonic plate need to be cleaned (see #3 in Cleaning and
Maintenance).

2. If the water (EO mixture) in the Diffuser has evaporated, Diffuser

and Ultrasonic plate must be cleaned (see #3 in Cleaning and
Maintenance).

3. Blinking lights mean the water level is too low for operation.

Add water if continued use is desired and reset by turning off or
unplugging the Diffuser.

Warranty

• This Diffuser comes with a one year manufacturer’s warranty from
date of purchase against mechanical/electrical malfunction due to the
manufacturing process.

• Noncompliance with instructions listed in this manual and/or abuse

are not covered.

• Please contact Mannatech customer service if you feel your Diffuser
falls under the manufacturer’s warranty.

• Proof of purchase dates are required for warranty issues.

• Shipping and Handling are not covered.

7

Item # 1416501

Job # 19407.0116

© 2016 Mannatech, Incorporated. All Rights Reserved.

Mannatech, Stylized M Design, Transform Your Life,
and Mannatech 100% Essential Oils are trademarks of
Mannatech, Incorporated.
