Man & Machine HotTooth User Manual
H
H
H
o
o
o
t
t
t
T
T
T
o
o
o
o
o
o
t
t
t
h
h
h
K
K
K
e
e
e
y
y
y
b
b
b
o
o
o
a
a
a
r
r
r
d
d
d
The HotTooth is a Bluetooth wireless keyboard with full tactile feedback. The
keyboard is easy to use and clean. It saves valuable desk space and is flexible so
it can be loosely rolled and carried (Carrying pouch included). HotTooth is based
on the wireless Bluetooth HID profile. It can be used with PCs, Laptops, Tablet
PCs, PDAs and Smartphones with built in Bluetooth HID profile, or via USB
Bluetooth bridge with appropriate driver (Bridge with driver sold separately).
KEYBOARD MUST BE CHARGED AT LEAST TWO HOURS BEFORE 1ST USE
Weight:
153 g (0.34 lb.)
Dimensions:
330 x114 x 13 mm
(13.0” x 4.5” x 0.5”)
Number of keys:
87 keys US layout
Power:
Rechargeable Lithium-ion battery.
Charging Cable included.
3 volts (5 volts to charge)
System requirements:
Built in Bluetooth HID profile or
USB interface for wireless bridge
with appropriate driver.
Operating Frequency:
2.4 GHz
Warranty period:
One-year limited warranty
DO NOT FOLD OR TIGHTLY ROLL AS THIS MAY DAMAGE KEYBOARD
Pairing the HotTooth Keyboard:
For Built in Bluetooth HID PCs, Laptops, Tablet PCs and PDAs:
11.
. Turn on the keyboard by pressing the ON/OFF Button (See the picture on
the right). Green light indicates keyboard is on.
22.
. Press the Pairing Button on the keyboard to enable keyboard pairing
mode. Blue light blinks when the keyboard is in pairing mode.
33.
. Open the Bluetooth manager on your PC, Laptop or PDA and follow the
instruction for the software to pair the keyboard.
44.
. When pairing is complete the blue light stops blinking and it becomes
solid green. The keyboard is now ready for use.
Using a USB Bluetooth Bridge: (Bridge with driver sold separately)
11.
. Turn on the keyboard by pressing the ON/OFF Button (See the picture on
the right). Green light indicates keyboard is on.
22.
. Press the Pairing Button on the keyboard to enable keyboard pairing
mode. Blue light blinks when the keyboard is in pairing mode.
33.
. Connect your USB Bluetooth bridge to the USB port on your PC.
44.
. Open the Bluetooth manager software for the bridge and follow the
instruction for the software to pair the keyboard.
55.
. When pairing is complete the blue light stops blinking and it becomes
solid green. The keyboard is now ready for use.
Battery status light:
• Red light indicates charging.
• Yellow light indicates low battery power.
• Blinking blue light indicates pairing mode.
• Green light indicates 20% or more battery power.
Cleaning Instructions for HotTooth Keyboard:
• Clean the keyboard surface by wiping or brushing. Use only rags, sponges
or soft bristle brushes.
DO NOT SUBMEREGE THE KEYBOARD DIRECTLY INTO CLEANING FLUID
• The rubber of HotTooth can be cleaned with water, soap, alcohol, 10%
bleach solutions, and a variety of chemical disinfectants.
DO NOT use Petroleum based cleaners, Acetone, Over 10% bleach
solutions, Temperature or pressure sterilization, buffing pads or
scrubbing pads
Charging the HotTooth Keyboard:
• Use the Mini USB cable (included) to charge the keyboard. Plug the USB
“A” end to your PC and the mini USB “B” end to the USB Charging port
connector on the keyboard shown below.
• It takes approximately 2 hours to fully charge the battery.
THESE INSTRUCTIONS AND RECOMMENDATIONS HAVE BEEN PREPARED TO ADVISE THE
PROPER METHODS FOR CLEANING YOUR PRODUCT. MAN & MACHINE, INC. OR THE LOCAL
DISTRIBUTOR CANNOT ASSUME ANY RESPONSIBILITY FOR THE APPLICATION OF THEM. IF
THERE ARE ANY QUESTIONS, PLEASE CONTACT PLACE OF PURCHASE OR MMI PRIOR TO
CLEANING. MAN & MACHINE DOES NOT CONSIDER THE HOTTOOTH KEYBOARD TO BE A
MEDICAL KEYBOARD FOR INFECTION CONTROL PURPOSES DUE TO THE INABILITY TO
MECHANICALLY CLEAN ALL SURFACES AND AREAS ON THE KEYBOARD. ALL SPECIFICATIONS
SUBJECT TO CHANGE WITHOUT NOTICE.
You can email us at: info@mmimd.com
or call us at: (301) 341-4900
In Europe, contact +31-23-5450185
www.man-machine.com
Copyright Man & Machine, Inc. 2008
