Page 1
For more Parts Information:
https://manitowocfsg.sysonline.com/Default.aspx
Page 2
TABLE OF CONTENTS
Manitowoc Foodservice [Updated: Sep. 30, 2013]
Manitowoc - Ice & Related
Parts Catalog
Ice Machine
A Series
A0100
A0100 - All Components 1
i
Page 3
A0100
A0100 - ALL COMPONENTS
A0100_2.PDF
1
Page 4
A0100
A0100 - ALL COMPONENTS
# PART # DESCRIPTION QTY Note
The following parts are the only available parts for this model.
All other parts are no longer available.
Components for Tecumseh Compressor:
8504753 Tecumseh AE9422EXA B/M AE172AT-900-A4Y
8505203 Tecumseh AE4448Y B/M AE660AT-734-A4D
2416021 Condenser Fan Blade
1165061 Water Condenser up to SN 860861874
8930259 Drier
CONTROL GROUP
2406239 Omnetics Timer SIN 23188 to 23687
6082014 Timer Insulating Paper
2404071 Solenoid Valve
2404111 Solenoid Valve Coil [1]
2404203 Sporlan coil only after SN AA0100
8367179 Expansion Valve
2355011 High Pressure Cut-out [2]
2355193 Low Pressure Cut-in
155711 Control Box Cover
2300849 Main Toggle Switch
155521 Water Distribution Tube - A100
4408209 End Stopper
4420333 Tubing, Clear Vinyl 1/2 ID
7627383 Water Pump - 115V/60 Hz
8369049 Float Valve Assembly
5000013 Thumbscrew - #8-32 x 0.375" [3]
1260033 Water Strainer
4420333 Tubing, Clear Vinyl 1/2 ID
8390053 Union Connector [4]
8485033 Water Pump Seal -- Gorman Rupp Pump Only
8485053 Water Pump Seal -- Hartell Pump Only
5000013 Thumbscrew - #8-32 x 0.375"
Components for Tecumseh AE234JL725A4:
1502881 Relay For Tecumseh AE234JT603
2406239 Omnetics Timer SIN 23188 to 23687
2404071 Solenoid Valve
2404293 Hot Gas Solenoid Valve Assembly
FOR 220V 60 Hz MODELS ONLY
8503723 Start Capacitor - 208-230V/50-60 Hz/1 Ph
8505523 Tecumseh AE4448Y B/M AE660ET-734-A4D
PART NOTES:
[1] - (For 2404071 valve)
[2] - Starting with SN AF0100
A0100_2.PDF
2
Page 5
A0100
A0100 - ALL COMPONENTS
# PART # DESCRIPTION QTY Note
PART NOTES:
[3] - Mounting float bracket
[4] - Nylon on water pump
A0100_2.PDF
3
