Manitowoc Ice AC-0370 User Manual
Specifications and Main Features
- Model: AC-0370 Ice Vender
- Dimensions (with “400” Series Cuber):
- Height: 20-5/16”
- Width: 30”
- Depth: 23-9/16”
- Approximate Shipping Weight: 232 lbs (for ADO0402A), 233 lbs (for ADO0403W)
- Ice Production Specifications:
- Incoming Room Temperature Categories:
70°F Water Temp: 380 lbs/24 hours
59°F Water Temp: 340 lbs/24 hours
90°F Water Temp: 300 lbs/24 hours
- Ice Making Section Electrical Characteristics:
- Voltage: 115 VAC
- Frequency: 60 Hertz
- Phase: Single
- Minimum Ampacity: 18 Amps
- Coin Mechanism:
- Accepts: Quarters, Dimes, Nickels
- Gives change in Nickels only
- Price setting maximum: 75¢
- Timer:
- 2-minute timer that governs dispensing turns.
- 60-minute turn for making ice.
- Weight Control System:
- Compensates to limit the quantity of ice that is ejected.
- Warranty:
- Parts and Material: (for a period of only 1 year)
- Compressor: (for a period of only 5 years)
Frequently Asked Questions
Q: What coins do the AC-0370 Ice Vender accept?
A: The AC-0370 accepts quarters, dimes, and nickels, change is dispensed in nickels only.
Q: How to adjust the vend price for the Ice vender?
A: Disconnect the power supply, take out the coin accepter, and alter the price through using the slide switches attached to the printed circuit board to adjust the vend price.
Q: What happens when the two minute duration of vend is overstepped?
A: An empty light will light up and vend will try to accept further coins till the ice gets replenished.
Q: What are the methods to determine if the vending unit is in working condition?
A: Power measurement at the terminal is recommended and try switching those on in switches. If there is no power still, then check the door and weight control switch.
Q: Ice delivery isn’t working at needed speed, what do I do?
A: In case there are no barriers preventing the augur check for ice canting, also ensure the ice cubers are appropriately working.
Q: How frequently should I be able to maintain the bin and mechanisms?
A: In order to prevent any malfunctioning cleaning the storage bin, the auger and the coin maintenance should be done practically on a regularly basis.
