QM45 Series
Ice Machines
Installation, Use, Care,
and Service Manual
Thank you for selecting a Manitowoc Ice Machine, the dependability leader in ice making equipment and
related products. With proper care and maintenance, your new Manitowoc Ice Machine will provide you with
many years of reliable and economical performance.
We reserve the right to make product improvements at any time.
Specifications and design are subject to change without notice.
Part Number 000001774
10/06
Safety Notices
Procedural Notices
When using or servicing these Ice Machines, be sure
to pay close attention to the safety notices in this
manual. Disregarding the notices may lead to serious
injury and/or damage to the ice machine.
Throughout this manual, you will see the following
types of safety notices:
WARNING
Text in a Warning box alerts you to a potential
personal injury situation. Be sure to read the
Warning statement, and then proceed carefully.
CAUTION
Text in a Caution box alerts you to a situation in
which you could damage the ice machine. Be sure
to read the Caution statement, and then proceed
carefully.
CAUTION
Proper care and maintenance are essential for
maximum ice production and trouble-free operation
of your Manitowoc Ice Machine.
Read and understand this manual. It contains
valuable care and maintenance information. If you
encounter problems not covered by this manual,
feel free to contact Manitowoc Ice, Inc. We will be
happy to provide assistance.
When using or servicing these Ice Machines, be sure
to read the procedural notices in this manual. These
notices supply helpful and important information.
Throughout this manual, you will see the following
types of procedural notices:
Important
Important boxes serve two functions.
They call the operator’s attention to important
information.
They also provide the service technician with
information that may help perform a procedure
more efficiently. Disregarding this information may
slow down the work.
NOTE: Text set off as a Note provides you with
simple, but useful, extra information.
This manual covers the following model numbers:
Self-Contained Air-Cooled:
QM45A
QM45AE
Table of Contents
Table of Contents
Section 1 - General Information
Model Numbers................................................................................................................................................1-1
Accessories........................................................................................................................................................1-1
Model/Serial Number Location......................................................................................................................1-2
Owner Warranty Registration Card..............................................................................................................1-3
Warranty Coverage.........................................................................................................................................1-3
Section 2 - Installation Instructions
General..............................................................................................................................................................2-1
Ice Machine Dimensions..................................................................................................................................2-1
Location of Ice Machine..................................................................................................................................2-2
Ice Machine Heat of Rejection........................................................................................................................2-2
Leveling the Ice Machine.................................................................................................................................2-3
Electrical Service..............................................................................................................................................2-5
Water Service/Drains.......................................................................................................................................2-6
Installation Checklist.......................................................................................................................................2-8
Before Starting the Ice Machine.....................................................................................................................2-8
Section 3 - Ice Machine Operation
Component Identification ...............................................................................................................................3-1
Ice Making Sequence of Operation................................................................................................................3-2
Ice Making Sequence of Operation Energized Parts Chart.........................................................................3-3
Operational Checks
Siphon System ........................................................................................................................................... 3-4
Water Level Check ................................................................................................................................... 3-4
Ice Bridge Thickness................................................................................................................................. 3-5
i
Table of Contents
Table of Contents (cont.)
Section 4 - Maintenance
General..............................................................................................................................................................4-1
Cleaning and Sanitizing Procedure................................................................................................................4-1
Exterior Cleaning.............................................................................................................................................4-7
Cleaning the Condenser ..................................................................................................................................4-7
Removal from Service/Winterization.............................................................................................................4-8
Section 5 - Before Calling for Service
Checklist............................................................................................................................................................5-1
Safety Limit Feature........................................................................................................................................5-2
Safety Limits.....................................................................................................................................................5-3
ii
Section 1 General Information
Section 1
General Information
Model Numbers
This manual covers the following models:
Self-Contained
Air-Cooled
QM45A 115/60/1
QM45AE 230/50/1
Voltage
Accessories
Contact your Manitowoc distributor for these
optional accessories:
ARCTICPURE WATER FILTER SYSTEM
Engineered specifically for Manitowoc ice machines,
ArcticPure water filters are an efficient, dependable,
and affordable method of inhibiting scale formation,
filtering sediment, and removing chlorine taste and
odor.
MANITOWOC CLEANER AND SANITIZER
Manitowoc Ice Machine Cleaner and Sanitizer are
available in convenient 16 oz. (473 ml) and 1 gal
(3.78 l) bottles. These are the only cleaner and
sanitizer approved for use with Manitowoc products.
Cleaner Part Number Sanitizer Part number
16oz 94-0456-3 16oz 94-0565-3
1 Gallon 94-0580-3 1 Gallon 94-0581-3
Warning
PERSONAL INJURY POTENTIAL
Do not operate equipment that has been,
misused, abused, neglected, damaged,
or altered/modified from that of original
manufactured specifications.
1-1
General Information
Model/Serial Number Location
Section 1
Record the model and serial number of your ice
machine in the space provided below. These numbers
are required when requesting information from your
local Manitowoc distributor, service representative,
or Manitowoc Ice, Inc.
The model and serial number are listed on the
OWNER WARRANTY REGISTRATION CARD.
They are also listed on the MODEL/SERIAL
NUMBER DECAL affixed to the ice machine.
MODEL/SERIAL
NUMBER PLATE
Ice Machine
Model Number
Serial Number
1-2
MODEL/SERIAL
NUMBER PLATE
Model/Serial Number Location
SV1732
Section 1 General Information
Owner Warranty Registration Card
GENERAL
The packet containing this manual also includes
warranty information. Warranty coverage begins the
day your new ice machine is installed.
Important
Complete and mail the OWNER WARRANTY
REGISTRATION CARD as soon as possible to
validate the installation date.
If you do not return your OWNER WARRANTY
REGISTRATION CARD, Manitowoc will use the
date of sale to the Manitowoc Distributor as the first
day of warranty coverage for your new ice machine.
Commercial Warranty Coverage
GENERAL
The following Warranty outline is provided for your
convenience. For a detailed explanation, read the
warranty bond shipped with each product.
Contact your local Manitowoc representative or
Manitowoc Ice, Inc. if you need further warranty
information.
PARTS
1. Manitowoc warrants the ice machine against
defects in materials and workmanship, under
normal use and service for three (3) years from
the date of original installation.
LABOR
1. Labor required to repair or replace defective
components is covered for three (3) years from
the date of original installation.
EXCLUSIONS
The following items are not included in the ice
machine’s warranty coverage:
1. Normal maintenance, adjustments and cleaning as
outlined in this manual.
2. Repairs due to unauthorized modifications to the
ice machine or use of non-standard parts without
prior written approval from Manitowoc Ice, Inc.
3. Damage caused by improper installation of the
ice machine, electrical supply, water supply or
drainage, or damage caused by floods, storms, or
other acts of God.
4. Premium labor rates due to holidays, overtime,
etc.; travel time; flat rate service call charges;
mileage and miscellaneous tools and material
charges not listed on the payment schedule.
Additional labor charges resulting from the
inaccessibility of equipment are also excluded.
5. Parts or assemblies subjected to misuse, abuse,
neglect or accidents.
6. Damage or problems caused by installation,
cleaning and/or maintenance procedures
inconsistent with the technical instructions
provided in this manual.
AUTHORIZED WARRANTY SERVICE
To comply with the provisions of the warranty, a
refrigeration service company qualified and
authorized by your Manitowoc distributor, or a
Contracted Service Representative must perform the
warranty repair.
NOTE: If the dealer you purchased the ice machine
from is not authorized to perform warranty service,
contact your Manitowoc distributor or Manitowoc
Ice, Inc. for the name of the nearest authorized
service representative.
SERVICE CALLS
Normal maintenance, adjustments and cleaning as
outlined in this manual are not covered by the
warranty. If you have followed the procedures listed
on page 5-1 of this manual, and the ice machine still
does not perform properly, call your authorized
service company.
1-3
General Information Section 1
Residential Warranty Coverage
WHAT DOES THIS LIMITED WARRANTY COVER
Subject to the exclusions and limitations below, Manitowoc
Ice, Inc. (“Manitowoc”) warrants to the original consumer that
any new ice machine manufactured by Manitowoc (the
“Product”) shall be free of defects in material or workmanship
for the warranty period outlined below under normal use and
maintenance, and upon proper installation and start-up in
accordance with the instruction manual supplied with the
Product.
HOW LONG DOES THIS LIMITED WARRANTY
LAST?
Ice Machine - Twelve (12) months from the sale date
WHO IS COVERED BY THIS LIMITED WARRANTY
This limited warranty only applies to the original consumer of
the Product and is not transferable.
WHAT ARE MANITOWOC ICE’S OBLIGATIONS
UNDER THIS LIMITED WARRANTY?
If a defect arises and Manitowoc receives a valid warranty
claim prior to the expiration of the warranty period,
Manitowoc shall, at its option: (1) repair the Product at
Manitowoc’s cost, including standard straight time labor
charges, (2) replace the Product with one that is new or at least
as functionally equivalent as the original, or (3) refund the
purchase price for the Product. Replacement parts are
warranted for 90 days or the balance of the original warranty
period, whichever is longer. The foregoing constitutes
Manitowoc’s sole obligation and the consumer’s exclusive
remedy for any breach of this limited warranty. Manitowoc’s
liability under this limited warranty is limited to the purchase
price of Product. Additional expenses including, without
limitation, service travel time, overtime or premium labor
charges, accessing or removing the Product, or shipping are
the responsibility of the consumer.
HOW TO OBTAIN WARRANTY SERVICE
To obtain warranty service or information regarding your
Product, please contact us at:
MANITOWOC ICE, INC.
2110 So. 26
P.O. Box 1720,
Manitowoc, WI 54221-1720
Telephone: 920-682-0161 Fax: 920-683-7585
www.manitowocice.com
th
St.,
?
?
WHAT IS NOT COVERED
This limited warranty does not cover, and you are solely
responsible for the costs of: (1) periodic or routine
maintenance, (2) repair or replacement of the Product or parts
due to normal wear and tear, (3) defects or damage to the
Product or parts resulting from misuse, abuse, neglect, or
accidents, (4) defects or damage to the Product or parts
resulting from improper or unauthorized alterations,
modifications, or changes; and (5) defects or damage to any
Product that has not been installed and/or maintained in
accordance with the instruction manual or technical
instructions provided by Manitowoc. To the extent that
warranty exclusions are not permitted under some state laws,
these exclusions may not apply to you.
EXCEPT AS STATED IN THE FOLLOWING SENTENCE,
THIS LIMITED WARRANTY IS THE SOLE AND
EXCLUSIVE WARRANTY OF MANITOWOC WITH
REGARD TO THE PRODUCT. ALL IMPLIED
WARRANTIES ARE STRICTLY LIMITED TO THE
DURATION OF THE LIMITED WARRANTY
APPLICABLE TO THE PRODUCTS AS STATED ABOVE,
INCLUDING BUT NOT LIMITED TO, ANY WARRANTY
OF MERCHANTABILITY OR OF FITNESS FOR A
PARTICULAR PURPOSE. Some states do not allow
limitations on how long an implied warranty lasts, so the
above limitation may not apply to you.
IN NO EVENT SHALL MANITOWOC OR ANY OF ITS
AFFILIATES BE LIABLE TO THE CONSUMER OR ANY
OTHER PERSON FOR ANY INCIDENTAL,
CONSEQUENTIAL OR SPECIAL DAMAGES OF ANY
KIND (INCLUDING, WITHOUT LIMITATION, LOSS OF
PROFITS, REVENUE OR BUSINESS) ARISING FROM OR
IN ANY MANNER CONNECTED WITH THE PRODUCT,
ANY BREACH OF THIS LIMITED WARRANTY, OR ANY
OTHER CAUSE WHATSOEVER, WHETHER BASED ON
CONTRACT, TORT OR ANY OTHER THEORY OF
LIABILITY. Some states do not allow the exclusion or
limitation of incidental or consequential damages, so the
above limitation or exclusion may not apply to you.
HOW STATE LAW APPLIES
This limited warranty gives you specific legal rights, and you
may also have rights that vary from state to state or from one
jurisdiction to another.
REGISTRATION CARD
To secure prompt and continuing warranty service, this
warranty registration card must be completed and sent to
Manitowoc within thirty (30) days from the sale date.
Complete the following registration card and send it to
Manitowoc at the address shown.
?
1-4
Section 2 Installation Instructions
Section 2
Installation Instructions
General
These instructions are provided to assist the qualified
installer. Check your local Yellow Pages for the
name of the nearest Manitowoc distributor, or call
Manitowoc Ice, Inc. for information regarding startup services.
Ice Machine Dimensions
QM-45 ICE MACHINES
Important
Failure to follow these installation guidelines may
affect warranty coverage.
6.00”
15.24 CM
SV1679B
2.88”
22.34”
56.74 CM
7.3 CM
6.19”
15.7 CM
8.6 CM
9.8 CM
5.94”
15.1 CM
3.35”
3.85”
19.69”
50.1 CM
SV1733
76.2 CM
30”
ICE MAKING
WATER/BIN DRAIN
3.75”
9.5 CM
ICE MAKING
WATER INLET
SV1678E
ELECTRICAL
INLET
SV1735A
2-1
Installation Instructions Section 2
Location of Ice Machine
Ice Machine Heat of Rejection
The location selected for the ice machine must meet
the following criteria. If any of these criteria are not
met, select another location.
• The location must be indoors.
• The location must be free of airborne and other
contaminants.
• The air temperature must be at least 35°F (1.6°C),
but must not exceed 110°F (43.4°C).
• The location must not be near heat-generating
equipment or in direct sunlight.
• The location must be capable of supporting the
weight of the ice machine and a full bin of ice.
• The location must allow enough clearance for
water, drain and electrical connections in the rear
of the ice machine.
• The location must not obstruct airflow through or
around the ice machine. Refer to the chart below
for clearance requirements.
Self-Contained
Air-Cooled
Top/Sides 5” (203 mm)* 5” (127 mm)*
Back 5” (127 mm)* 5” (127 mm)*
Self-Contained
Water-Cooled
Series Heat of Rejection*
Ice Machine Air Conditioning** Peak
QM-45 1750 2600
* B.T.U./Hour
** Because the heat of rejection varies during the ice making
cycle, the figure shown is an average.
Ice machines, like other refrigeration equipment,
reject heat through the condenser. It is helpful to
know the amount of heat rejected by the ice machine
when sizing air conditioning equipment where selfcontained air-cooled ice machines are installed.
NOTE: The ice machine may be built into a cabinet.
There is no minimum clearance requirement for the
top or left and right sides of the ice machine. The
listed values are recommended for efficient operation
and servicing only.
CAUTION
The ice machine must be protected if it will be
subjected to temperatures below 32°F (0°C).
Failure caused by exposure to freezing
temperatures is not covered by the warranty.
See “Removal from Service/Winterization” on page
4-10.
2-2
Section 2 Installation Instructions
Leveling the Ice Machine
1. Screw the leveling legs onto the bottom of the ice
machine.
2. Screw the foot of each leg in as far as possible.
Level the ice machine from front to back and side
Important
to side
CAUTION
The legs must be screwed in tightly to prevent them
from bending.
3. Move the ice machine into its final position.
4. Level the ice machine to assure that the siphon
system functions correctly. Use a level on top of
the ice machine. Turn each foot as necessary to
level the ice machine from front to back and side
to side.
THREAD
LEVELING LEG
INTO BASE OF
CABINET
THREAD “FOOT”
IN AS FAR AS
POSSIBLE
Leveling Leg and Foot
SV1606
SV1704
Checking Ice Machine Level
2-3
Installation Instructions Section 2
THIS PAGE INTENTIONALLY LEFT BLANK
2-4
Electrical Service
GENERAL
WARNING
All wiring must conform to local, state and national
codes.
VOLTAGE
The maximum allowable voltage variation is ± 10%
of the rated voltage on the ice machine model/serial
number nameplate at start-up (when the electrical
load is highest).
Installation InstructionsSection 2
FUSE/CIRCUIT BREAKER
A separate fuse/circuit breaker must be provided for
each ice machine. Circuit breakers must be
H.A.C.R. rated (does not apply in Canada).
TOTAL CIRCUIT AMPACITY
The total circuit ampacity is used to help select the
wire size of the electrical supply.
The wire size (or gauge) is also dependent upon
location, materials used, length of run, etc., so it
must be determined by a qualified electrician.
WARNING
The ice machine must be grounded in accordance
with national and local electrical codes.
Never use an extension cord. If an outlet is not
within reach of the ice machine’s power cord, have
a proper amperage outlet wired closer to the ice
machine.
The 115/1/60 ice machines are factory pre-wired
with a 6’ power cord, and NEMA 5-20P-plug
configuration.
The 230/50/1 ice machines are factory pre-wired
with a 6’ power cord only, no plug is supplied.
QM-45 ICE MACHINE
Voltage Air-Cooled
Ice Machine Phase
Cycle
QM-45 115/1/60 15 5.2
230/1/50 15 2.6
Maximum
Fuse/Circuit
Breaker
Total Amps
WARNING
For United Kingdom Only
As the colours of the wires in the mains lead of the appliance may not correspond with
the coloured markings identifying the terminals in your plug, proceed as follows:
• The wire which is coloured green and yellow must be connected to the terminal in the
plug which is marked with the letter E or by the earth ground symbol or coloured
green or green and yellow.
• The wire coloured blue must be connected to the terminal which is marked with the
letter N or coloured black.
• The wire coloured brown
letter L or coloured red.
must be connected to the terminal which is marked with the
2-5
Installation Instructions Section 2
Water Service/Drains
WATER SUPPLY
Local water conditions may require treatment of the
water to inhibit scale formation, filter sediment,
remove chlorine, and improve taste and clarity.
Important
If you are installing a Manitowoc Tri-Liminator
water filter system, refer to the Installation
Instructions supplied with the filter system for ice
making water inlet connections.
WATER INLET LINES
Follow these guidelines to install water inlet lines:
• Do not connect the ice machine to a hot water
supply. Be sure all hot water restrictors installed
for other equipment are working. (Check valves
on sink faucets, dishwashers, etc.)
• If water pressure exceeds the maximum
recommended pressure (80 psig), obtain a water
pressure regulator from your Manitowoc
distributor.
• Install a water shut-off valve for the ice making
water line.
• Insulate water inlet line to prevent condensation.
DRAIN CONNECTIONS
Follow these guidelines when installing drain lines to
prevent drain water from flowing back into the ice
machine and storage bin:
• The ice machine comes equipped with a vinyl
drain hose for use with floor drains.
• The floor drain must be large enough to
accommodate drainage from all drains.
• Insulate the bin drain to prevent condensation.
• Drain lines must have a 1″ (2.5 cm) drop per 40″
(1 meter) of run, and must not create traps.
Important
The Commonwealth of Massachusetts requires that
all water-cooled models must be connected only to
a closed loop, cooling tower system.
2-6
Section 2 Installation Instructions
WATER SUPPLY AND DRAIN LINE SIZING/CONNECTIONS
CAUTION
Plumbing must conform to state and local codes.
Location
Ice Making
Water Inlet
Bin Drain
Water
Temperature
33°F (0.6°C) Min.
90°F (32.2°C) Max.
20 psi (137.9 kPA) Min.
80 psi (551.5 kPA) Max.
--- ---
Water
Pressure
Ice Machine
Fitting
3/8” Female Pipe
Thread
3/4” (19.1 mm)
Vinyl Tubing
Tubing Size Up to Ice
Machine Fitting
3/8” (9.5 mm)
minimum inside
diameter
N/A
Typical Water Supply Drain Installation
ICE MAKING WATER
INLET TUBING
3/8″ MIN. I.D. (.95CM)
WATER SHUTOFF
VALVE
SV1735
ICE MAKING
WATER/BIN DRAIN
5/8″ I.D. (1.59CM)
2-7
Installation Instructions Section 2
Installation Checklist
Before Starting the Ice Machine
Is the ice machine level?
Has all of the internal packing been removed?
Have all of the electrical and water connections
been made?
Has the supply voltage been tested and checked
against the rating on the nameplate?
Is there proper clearance around the ice
machine for air circulation?
Has the ice machine been installed where
ambient temperatures will remain in the range
of 35° - 110°F (1.7° - 43.3°C)?
Has the ice machine been installed where the
incoming water temperature will remain in the
range of 33° - 90°F (0.6° - 32.2°C)?
Are all electrical leads free from contact with
refrigeration lines and moving equipment?
Has the owner/operator been instructed
regarding maintenance and the use of
Manitowoc Cleaner and Sanitizer?
All Manitowoc ice machines are factory-operated
and adjusted before shipment. Normally, new
installations do not require any adjustment.
To ensure proper operation, follow the Operational
Checks on page 3-4 of this manual. Starting the ice
machine and completing the Operational Checks are
the responsibilities of the owner/operator.
Adjustments and maintenance
procedures outlined in this manual
are not covered by the warranty.
WARNING
PERSONAL INJURY POTENTIAL
Do not operate equipment that has been misused,
abused, neglected, damaged, or altered/modified
from that of original manufactured specifications.
Has the owner/operator completed the warranty
registration card?
Has the ice machine and bin been sanitized?
Has this manual been given to the
owner/operator?
2-8
Section 3 Ice Machine Operation
Ice Machine Operation
Component Identification
ICE THICKNESS PROBE
FLOAT VALVE ASSEMBLY
WATER DISTRIBUTION TUBE
SIPHON CAP
EVAPORATOR
BIN SWITCH MAGNET
ICE DAMPER
WATER PUMP
WATER TROUGH
SV1731A
CONDENSER AIR FILTER
COMPRESSOR COMPARTMENT
ON/OFF/WASH
TOGGLE SWITCH
ACCESS SCREWS
SV1733
3-1
Ice Machine Operation Section 3
Ice Making Sequence of Operation
INITIAL START-UP OR START-UP AFTER
AUTOMATIC SHUT-OFF
1. Pressure Equalization
Before the compressor starts the hot gas valve is
energized for 15 seconds to equalize pressures during
the initial refrigeration system start-up.
2. Refrigeration System Start-Up
The compressor starts after the 15-second pressure
equalization, and remains on throughout the entire
Freeze and Harvest Sequences. The hot gas valve
remains on for 5 seconds during initial compressor
start-up and then shuts off.
At the same time the compressor starts, the condenser
fan motor (air-cooled models) is supplied with power
throughout the entire Freeze and Harvest Sequences.
The fan motor is wired through a fan cycle pressure
control, therefore it may cycle on and off. (The
compressor and condenser fan motor are wired
through a relay. As a result, any time the relay coil is
energized, the compressor and fan motor are supplied
with power.)
FREEZE SEQUENCE
3. Prechill
The compressor is on for 30 seconds prior to water
flow to Prechill the evaporator.
4. Freeze
The water pump starts after the 30-second Prechill.
An even flow of water is directed across the
evaporator and into each cube cell, where it freezes.
HARVEST SEQUENCE
5. Harvest
The water pump de-energizes stopping flow over the
evaporator. The rising level of water in the sump
trough diverts water out of the over flow tube,
purging excess minerals from the sump trough. The
hot gas valve also opens to divert hot refrigerant gas
into the evaporator.
The refrigerant gas warms the evaporator causing the
cubes to slide, as a sheet, off the evaporator and into
the storage bin. The sliding sheet of cubes contacts
the ice damper, opening the bin switch.
The momentary opening and re-closing of the bin
switch terminates the Harvest sequence and returns
the ice machine to the Freeze Sequence (steps 3 - 4).
AUTOMATIC SHUT-OFF
7. Automatic Shut-Off
When the storage bin is full at the end of a Harvest
sequence, the sheet of cubes fails to clear the ice
damper and will hold it down. After the ice damper is
held open for 7 seconds, the ice machine shuts off.
The ice machine will remain off for 3 minutes before
it can automatically restart.
The ice machine remains off until enough ice has
been removed from the storage bin to allow the ice to
fall clear of the damper. As the ice damper swings
back to the operating position, the bin switch recloses and the ice machine restarts (steps 1 - 2),
provided the 3-minute delay period is complete.
When sufficient ice has formed, the water flow (not
the ice) contacts the ice thickness probe. After
approximately 7 seconds of continual water contact,
the Harvest Sequence is initiated. The ice machine
cannot initiate a Harvest sequence until a 6-minute
freeze lock has been surpassed.
3-2
Section 3 Ice Machine Operation
QM45 SELF-CONTAINED AIR COOLED MODELS
ICE MAKING SEQUENCE OF OPERATION
1 2 3 3A 3B * LENGTH
INITIAL
START-UP/or
START UP
AFTER
AUTO SHUTOFF:
1. Pressure
Equalization
2. Refrigeration
System Start-up
FREEZE
SEQUENCE:
3. Pre-Chill
4. Freeze
HARVEST
SEQUENCE:
5. Harvest
CONTROL BOARD RELAYS RELAY
WATER PUMP HOT GAS
VALVE
OFF
OFF
OFF
ON
OFF
ON
ON
OFF
OFF
ON
RELAY COIL COMPRESSOR CONDENSER
FAN MOTOR
OFF
ON
ON
ON
ON
OFF
ON
ON
ON
ON
OFF
ON
ON
ON
ON
of “ON” TIME
15
Seconds
5
Seconds
30
Seconds
Until 7 sec.
water contact
with ice
thickness
probe
Bin switch
activation
6. AUTO SHUTOFF
Condenser Fan Motor: The fan motor is wired through a fan cycle pressure control, therefore, it may cycle on and off.
OFF
OFF
OFF
OFF
OFF
Until
bin switch
re-closes
3-3
Ice Machine Operation Section 3
Operational Checks
GENERAL
Your Manitowoc ice machine was factory-operated
and adjusted before shipment. Normally, a newly
installed ice machine does not require any
adjustment.
To ensure proper operation, always follow these
Operational Checks when starting the ice machine:
• for the first time
• after a prolonged out of service period
• after cleaning and sanitizing
Routine adjustments and maintenance procedures
outlined in this manual are not covered by the
warranty.
SIPHON SYSTEM
To reduce mineral build-up and cleaning frequency,
the water in the sump trough must be purged during
each harvest cycle.
When the water pump de-energizes the level in the
water trough rises above the standpipe starting a
siphon action. The siphon action stops when the
water level in the sump trough drops below the
siphon cap. When the siphon action stops, the float
valve refills the water trough to the correct level.
Siphon System Check
WATER LEVEL CHECK
Check the water level while the ice machine is in the
clean mode and the water pump is running. The
correct water level is 1/4" (6.3mm) to 3/8″ (9.5mm)
below the top of the standpipe.
1/4” TO 3/8″(6.3 TO 9.5 MM) BELOW TOP OF
STANDPIPE
SIPHON CAP
SV1689-2
Water Level
The float valve is factory-set for the proper water
level. If adjustments are necessary:
1. Verify the ice machine is level (see page 2-3).
2. Remove the siphon cap from the standpipe.
3. Place the main ICE/OFF/WASH toggle switch to
the WASH position, and wait until the float valve
stops adding water.
Follow steps 1 through 6 under water level check.
SIPHON
WATER LEVEL
CAP
STANDPIPE
DRAIN
SV1689-2
4. Adjust the water level to 1/4" (6.3mm) to 3/8"
(9.5mm) below the standpipe:
A Loosen the two screws on the float valve
bracket.
B Raise or lower the float valve assembly as
necessary, then tighten the screws.
5. Move the main ICE/OFF/ WASH toggle switch
to the OFF position. The water level in the trough
will rise above the standpipe and run down the
drain.
6. Replace the siphon cap on the standpipe, and
verify water level and siphon action by repeating
steps 3 through 5.
3-4
Section 3 Ice Machine Operation
ICE THICKNESS CHECK
The ice thickness probe is factory-set to maintain
the ice bridge thickness at 1/8” (3.2 mm).
1. Inspect the bridge connecting the cubes. It
should be about 1/8” (3.2 mm) thick.
2. If adjustment is necessary, turn the ice thickness
probe adjustment screw clockwise to increase
bridge thickness, or counterclockwise to
decrease bridge thickness.
NOTE: Turning the adjustment 1/3 of a turn will
change the ice thickness about 1/16” (1.5 mm).
ADJUSTING
SCREW
1/8” (3.2MM)
ICE BRIDGE
THICKNESS
SV1208
Ice Thickness Check
Make sure the ice thickness probe wire and the
bracket do not restrict movement of the probe.
3-5
Ice Machine Operation Section 3
THIS PAGE INTENTIONALLY LEFT BLANK
3-6
Section 4 Maintenance
Section 4
Maintenance
Interior Cleaning and Sanitizing
GENERAL
Clean and sanitize the ice machine every six months
for efficient operation. If the ice machine requires
more frequent cleaning and sanitizing, consult a
qualified service company to test the water quality
and recommend appropriate water treatment.
The ice machine must be taken apart for cleaning and
sanitizing.
CAUTION
Use only Manitowoc approved Ice Machine Cleaner (part
number 94-0546-3) and Sanitizer (part number 94-05 65-3). It
is a violation of Federal law to use these solutions in a manner
inconsistent with their labeling. Read and understand all
labels printed on bottles before use.
CLEANING AND SANITIZING PROCEDURE
CAUTION
Do not mix Ice Machine Cleaner and Sanitizer solutions
together. It is a violation of Federal law to use these solutions
in a manner inconsistent with their labeling.
WARNING
Wear rubber gloves and safety goggles (and/or face shield)
when handling Ice Machine Cleaner or Sanitizer.
Ice machine cleaner is used to remove lime scale and
mineral deposits. Ice machine sanitizer disinfects and
removes algae and slime.
Step 1: Set the toggle switch to the OFF position
after ice falls from the evaporator at the end of a
Harvest cycle. Or, set the switch to the OFF position
and allow the ice to melt off the evaporator.
CAUTION
Never use anything to force ice from the evaporator.
Damage ma y r esult.
Step 2: Remove all ice from the bin.
Step 3: To start a cleaning cycle, move the toggle
switch to the WASH position.
Step 4 Add the proper amount of Manitowoc Ice
Machine Cleaner to the water trough.
Model Amount of Cleaner
QM45 1.5 ounces (45 ml)
Step 5 Wait until the clean cycle is complete
(approximately 22 minutes) then place the toggle
switch in the OFF position, disconnect power and
water supplies to the ice machine.
4-1
Maintenance Section 4
WARNING
Disconnect electric power to the ice machine at the electric
switch box before proceeding.
Step 6: Remove parts for cleaning.
C. Remove the Ice Thickness Probe
• Compress the side of the ice thickness probe near
the top hinge pin and remove it from the bracket.
ICE
THICKNESS
PROBE
A. Remove the Vinyl Hose
• Disconnect the water hose from the distribution
tube and water pump.
B. Remove Water Pump
• Disconnect the water pump power cord
DO NOT SOAK WATER
PUMP MOTOR IN
CLEANER OR
SANITIZER
SOLUTIONS
SV1694-1
Water Pump Removal
• Loosen the screws securing the pump-mounting
bracket to the bulkhead.
• Lift the pump and bracket assembly off the
mounting screws.
COMPRESS SIDES OF
ICE THICKNESS PROBE
SV1138A
Ice Thickness Probe Removal
NOTE: At this point, the ice thickness probe can
easily be cleaned. If complete removal is desired
follow the ice thickness probe wire to the bulkhead
grommet (exit point) in the back wall. Pop the
bulkhead grommet out of the back wall by inserting
fingernails or a flat object between the back wall and
the grommet and prying forward. Pull the bulkhead
grommet and wire forward until the connector is
accessible, then disconnect the wire lead from the
connector.
Ice Thickness Probe Cleaning
• Mix a solution of Manitowoc ice machine cleaner
and water (2 ounces of cleaner to 16 ounces of
water) in a container.
• Soak the ice thickness probe a minimum of 10
minutes.
Clean all ice thickness probe surfaces and verify the
ice thickness probe cavity is clean. Rinse thoroughly
with clean water, then dry completely. Incomplete
rinsing and drying of the ice thickness probe can
cause premature harvest.
4-2
Section 4 Maintenance
D. Remove the Water Distribution Tube
E. Remove the Float Valve
DISTRIBUTION
TUBE
THUMBSCREW
1. LIFT UP
2. SLIDE BACK
3. SLIDE TO RIGHT
2
3
1
THUMBSCREW
LOCATING PIN
SV127
Water Distribution Tube Removal
• Loosen the two thumbscrews, which secure the
distribution tube.
• Lift the right side of the distribution tube up off
the locating pin, then slide it back and to the
right.
• Turn the splash shield counterclockwise one or
two turns.
FLOAT VALVE
BRACKET
COMPRESSION
FITTING
SHUT-OFF
VALVE
CAP AND FILTER
SCREEN
SPLASH SHIELD
FLOAT
CAUTION
Do not force this removal. Be sure the locating pin is clear of
the hole before sliding the distribution tube out.
Disassembly
• Twist both of the inner tube ends until the tabs
line up with the keyways.
• Pull the inner tube ends outward.
INNER
TUBE
KEYWAY
INNER
TUBE
TAB
Water Distribution Tube Disassembly
SV1695-2
Float Valve Removal
• Pull the float valve forward and off the mounting
bracket.
• Disconnect the water inlet tube from the float
valve at the compression fitting.
• Remove the cap and filter screen for cleaning.
SV1211
4-3
Maintenance Section 4
F. Remove the Water Trough
G. Remove the Ice Damper
• Apply downward pressure on the siphon tube and
remove from the bottom of the water trough.
• Remove the upper thumbscrew.
• While supporting the water trough remove the
two thumbscrews from beneath the water trough.
• Remove the water trough from the bin area
UPPER
THUMBSCREW
SV1689-1
LOWER
THUMBSCREWS
REMOVE SIPHON
TUBE
• Grasp ice damper and apply pressure toward the
left hand mounting bracket.
• Apply pressure to the right hand mounting
bracket with thumb.
• Pull ice damper forward when the right hand ice
damper pin disengages.
Installation
• Place ice damper pin in left hand mounting
bracket and apply pressure toward the left hand
mounting bracket.
• Apply pressure to the right hand mounting
bracket with thumb.
4-4
• Push ice damper toward evaporator until right
hand damper pin engages.
Section 4 Maintenance
H. Remove the Bin Door
• Grasp the rear of the bin door and pull bin door
forward approximately 5”.
•
Slide bin door to the rear while applying upward
Step 7 Mix a solution of cleaner and warm water.
Depending on the amount of mineral buildup, a larger
quantity of solution may be required. Use the ratio in
the table below to mix enough solution to thoroughly
clean all parts.
pressure (The rear door pins will ride up into the
track slot and slide backward to the stop tab).
•
While applying pressure against the bin door pull
down on the rear of each bin door track until the
door pins clear the stop tabs.
•
Slide the rear door pins off the end and then
below the door track. Slide bin door forward
allowing the back of the door to lower into the
bin. Continue forward with the bin door until the
front pins bottom out in the track.
Solution Type Water Mixed with
Cleaner 1 gal. (4 l) 16 oz (500 ml) cleaner
Step 8 Use ½ of the cleaner/water solution to clean
all components. The cleaner solution will foam when
it contacts lime scale and mineral deposits; once the
foaming stops use a soft bristle brush, sponge or cloth
(not a wire brush) to carefully clean the parts. Soak
the parts for 5 minutes (15 – 20 minutes for heavily
scaled parts). Rinse all components with clean water.
•
Lift right side of door until the front pins clear the
track, then remove door from bin.
Step 9 While components are soaking, use ½ of the
cleaner/water solution to clean all foodzone surfaces
PRESS DOWN
TO RELEASE
DOOR
of the ice machine and bin. Use a nylon brush or
cloth to thoroughly clean the following ice machine
areas:
TRACK
SLOT
STOP TAB
SLIDE
DOOR
FORWARD
• Evaporator plastic parts – including top, bottom
and sides
• Bin bottom, sides and top
Rinse all areas thoroughly with clean water.
Step 10 Mix a solution of sanitizer and warm water.
Solution Type Water Mixed With
Sanitizer 6 gal. (23 l) 4 oz (120 ml) sanitizer
Step 11 Use 1/2 of the sanitizer/water solution to sanitize all
removed components. Use a cloth or sponge to liberally apply
the solution to all surfaces of the removed parts or soak the
removed parts in the sanitizer/water solution. Do not rinse parts
after sanitizing.
4-5
Maintenance Section 4
Step 12 Use 1/2 of the sanitizer/water solution to
sanitize all foodzone surfaces of the ice machine and
bin. Use a cloth or sponge to liberally apply the
solution. When sanitizing, pay particular attention to
the following areas:
• Evaporator plastic parts - including top, bottom
and sides
Step 18 Mix a solution of sanitizer and warm water.
Solution Type Water Mixed With
Sanitizer 6 gal. (23 l) 4 oz (120 ml) sanitizer
Step 19 Use 1/2 of the sanitizer/water solution to
sanitize all removed components. Use a cloth or
sponge to liberally apply the solution to all surfaces
of the removed parts or soak the removed parts in the
• Bin bottom, sides and top
Do not rinse the sanitized areas.
sanitizer/water solution. Do not rinse parts after
sanitizing.
Step 13 Replace all removed components.
Step 14 Reapply power and water to the ice machine
and place the toggle switch in the WASH position.
Step 15 Add the proper amount of Manitowoc Ice
Machine Sanitizer to the water trough.
Model Amount of Sanitizer
QM45 1.5 ounces (45 ml)
Step16 Wait until the sanitize cycle is complete
(approximately 22 minutes) then place the toggle
switch in the OFF position, disconnect power and
water supplies to the ice machine.
WARNING
Disconnect electric power to the ice machine at the electric
switch box before proceeding.
Step 17 Repeat step 6 to remove parts for hand
sanitizing.
Step 20 Use 1/2 of the sanitizer/water solution to
sanitize all foodzone surfaces of the ice machine and
bin. Use a cloth or sponge to liberally apply the
solution. When sanitizing, pay particular attention to
the following areas:
• Evaporator plastic parts - including top, bottom
and sides
• Bin bottom, sides and top
Do not rinse the sanitized areas.
Step 21 Replace all removed components.
Step 22 Reapply power and water to the ice machine
and place the toggle switch in the ICE position.
.
4-6
Section 4 Maintenance
ICE MACHINE INSPECTION
Check all water fittings and lines for leaks. Also,
make sure the refrigeration tubing is not rubbing or
vibrating against other tubing, panels, etc.
Do not put anything (boxes, etc.) in front of the ice
machine. There must be adequate airflow through
and around the ice machine to maximize ice
production and ensure long component life.
3. Shine a flashlight through the condenser to check
for dirt between the fins. If dirt remains: Blow
compressed air through the condenser fins from
the inside. Be careful not to bend the fan blades.
4. Use a commercial condenser coil cleaner. Follow
the directions and cautions supplied with the
cleaner.
EXTERIOR CLEANING
Clean the area around the ice machine as often as
necessary to maintain cleanliness and efficient
operation.
Sponge any dust and dirt off the outside of the ice
machine with mild soap and water. Wipe dry with a
clean, soft cloth.
A commercial grade stainless steel cleaner/polish can
be used as necessary.
CLEANING THE CONDENSER
WARNING
Disconnect electric power to the ice machine at the electric
service switch before cleaning the condenser.
Air-Cooled Condenser
A dirty condenser restricts airflow, resulting in
excessively high operating temperatures. This
reduces ice production and shortens component life.
Clean the condenser at least every six months. Follow
the steps below.
5. Straighten any bent condenser fins with a fin
comb.
6. Carefully wipe off the fan blades and motor with
a soft cloth. Do not bend the fan blades. If the fan
blades are excessively dirty, wash with warm,
soapy water and rinse thoroughly.
CAUTION
If you are cleaning the condenser fan blades with water, cover
the fan motor to prevent water damage.
WARNING
The condenser fins are sharp. Use care when cleaning them.
1. The washable aluminum filter on self-contained
ice machines is designed to catch dust, dirt, lint
and grease. This helps keep the condenser clean.
Clean the filter with a mild soap and water
solution.
2. Clean the outside of the condenser with a soft
brush or a vacuum with a brush attachment. Clean
from top to bottom, not side to side. Be careful
not to bend the condenser fins.
4-7
Maintenance Section 4
REMOVAL FROM SERVICE
WINTERIZATION
Special precautions must be taken if the ice machine
is to be removed from service for an extended period
of time or exposed to ambient temperatures of 32°F
(0°C) or below.
CAUTION
If water is allowed to remain in the ice machine in
freezing temperatures, severe damage to some
components could result. Damage of this nature is
not covered by the warranty.
Follow the applicable procedure below.
SELF-CONTAINED AIR-COOLED ICE
MACHINES
1. Disconnect the electric power at the circuit
breaker or the electric service switch.
2. Turn off the water supply.
3. Remove the water from the water trough.
4. Disconnect and drain the incoming ice-making
water line at the rear of the ice machine.
5. Blow compressed air in both the incoming water
and the drain openings in the rear of the ice
machine until no more water comes out of the
inlet water lines or the drain.
6. Make sure water is not trapped in any of the
water lines, drain lines, distribution tubes, etc.
4-8
Section 5 Before Calling for Service
Section 5
Before Calling for Service
Checklist
If a problem arises during operation of your ice machine, follow the checklist below before calling for service.
Routine adjustments and maintenance procedures are not covered by the warranty.
Problem Possible Cause To Correct
Ice machine does not operate.
ON/OFF/ WASH toggle switch set
Damper in open position (down). Damper must be capable of
Ice machine stops, and can be
restarted by moving the toggle
switch to OFF and back to ICE.
Ice machine does not release
ice or is slow to harvest.
Ice machine is not level. Level the ice machine.
Low air temperature around ice
Water regulating valve leaks in harvest
Ice machine does not cycle
into harvest mode.
Ice thickness probe is dirty. Clean and sanitize the ice machine.
Ice thickness probe wire is
Ice thickness probe is out of
Uneven ice fill (thin at top of
Ice quality is poor (soft or not
clear).
Water filtration is poor. Replace the filter.
Ice machine is dirty. Clean and sanitize the ice machine.
Water siphon is not working. Check the water siphon system.
Water softener is working improperly (if
No electrical power to the ice
machine.
improperly.
Safety limit feature stopping the ice
machine.
Ice machine is dirty. Clean and sanitize the ice machine.
machine (air-cooled models).
mode (water-cooled models).
The six-minute freeze time lock-in has
not expired yet.
disconnected.
adjustment.
evaporator).
Poor incoming water quality. Contact a qualified service company
applicable).
Replace the fuse/reset the
breaker/turn on the main switch/plug
power cord into receptacle.
Move the toggle switch to the ON
position.
swinging freely. See page 6-2.
Refer to “Safety Limit Feature” on the
next page.
See pages 4-3 and 4-4.
See page 2-3.
Air temperature must be at least 35°F
(1.6°C).
Replace water-regulating valve.
Wait for freeze lock-in to expire.
See pages 4-3 and 4-4.
Connect the wire.
Adjust the ice thickness probe. See
page 3-5.
See “Shallow or Incomplete Cubes”
on the next page.
to test the quality of the incoming
water and make appropriate filter
recommendations.
See pages 4-3 and 4-4.
See page 3-4.
Repair the water softener.
Continued on next page...
5-1
Before Calling for Service Section 5
Problem Possible Cause To Correct
Ice machine produces shallow
or incomplete cubes, or the ice
fill pattern on the evaporator is
incomplete.
Water float valve filter screen is dirty. Remove and clean the filter screen.
Water filtration is poor. Replace the filter.
Hot incoming water. Connect the ice machine to a cold
Water float valve is not working. Remove the water float valve and
Incorrect incoming water pressure. Water pressure must be 20-80 psi
Ice machine is not level. Level the ice machine.
Low ice capacity. Water float valve filter screen is dirty. Remove and clean the filter screen.
Incoming water supply is shut off. Open the water supply valve.
Water float valve stuck open or
The condenser is dirty. Clean the condenser. See page 4-1.
High air temperature around ice
Inadequate clearance in front of the
Objects stacked around ice machine,
Ice thickness probe is out of
adjustment.
Water tro ugh level is to high or too low. Check the water level. See page 3- 4.
leaking.
machine (air-cooled models).
ice machine.
blocking airflow to condenser (aircooled models).
Adjust the ice thickness probe. See
page 3-5.
See page 4-1.
water supply. See page 2-6.
clean it. See page 4-7.
(137.9 - 551.5 kPA).
See page 2-3.
See page 4-1.
Remove the water float valve and
clean it. See page 4-7.
Air temperature must not exceed
110°F (43.3°C).
Provide adequate clearance.
See page 2-2.
Remove items blocking airflow.
Safety Limit Feature
In addition to the standard safety controls, your
Manitowoc ice machine features built-in safety limits
that will stop the ice machine if conditions arise
which could cause a major component failure.
Before calling for service, re-start the ice machine
using the following procedure:
1. Move the ON/OFF/ WASH switch to OFF and
then back to ON.
A. If the safety limit feature has stopped the ice
machine, it will restart after a short delay.
Proceed to step 2.
B. If the ice machine does not restart, see “Ice
machine does not operate” on the previous
page.
2. Allow the ice machine to run to determine if the
condition is reoccurring.
A. If the ice machine stops again, the condition
has reoccurred. Call for service.
B. If the ice machine continues to run, the
condition has corrected itself. Allow the ice
machine to continue running.
5-2
SAFETY LIMITS
General
In addition to standard safety controls, the control
board has two built in safety limit controls which
protect the ice machine from major component
failures.
Safety Limit #1: If the freeze time reaches 60
minutes, the control board automatically initiates a
harvest cycle. If three consecutive 60-minute freeze
cycles occur, the ice machine stops.
Safety Limit #2: If the harvest time reaches 3.5
minutes, the control board automatically returns the
ice machine to the freeze cycle. If three consecutive
3.5 minute harvest cycles occur, the ice machine
stops.
Safety Limit Stand-By Mode:
The first time a safety limit shut down occurs, the ice
machine turns off for 60 minutes (Stand-by Mode).
The ice machine will then automatically restart to see
if the problem reoccurs. During the Stand-By Mode
the harvest light will be flashing continuously and a
safety limit indication can be viewed. If the same
safety limit is reached a second time (the problem has
re-occurred) the ice machine will initiate a safety
limit shut down and remain off until it is manually
restarted. During a safety limit shut down the harvest
light will be flashing continuously.
Before Calling for ServiceSection 5
Determining Which Safety Limit
Stopped The Ice Machine
When a safety limit condition causes the ice machine
to stop, the harvest light on the control board
continually flashes on and off. Use the following
procedures to determine which safety limit has
stopped the ice machine.
1. Move the toggle switch to OFF.
2. Move the toggle switch back to ON.
3. Watch the harvest light. It will flash one or two
times, corresponding to safety limits 1 and 2, to
indicate which safety limit stopped the ice
machine.
After safety limit indication, the ice machine will
restart and run until a safety limit is exceeded again.
Safety Limit Notes
• A safety limit indication is completed before the
water pump starts. Water contacting the ice
thickness probe in the freeze cycle will cause the
harvest light to flash. Do not mistake a harvest
light flashing in the freeze cycle with a safety
limit indication.
• A continuous run of 100 harvests automatically
erases the safety limit code.
• The control board will store and indicate only one
safety limit – the last one exceeded.
• If the toggle switch is moved to the OFF position
and then back to the ICE position prior to
reaching the 100-harvest point, the last safety
limit exceeded will be indicated.
• If the harvest light did not flash prior to the ice
machine restarting, then the ice machine did not
stop because it exceeded a safety limit.
5-3
Before Calling for Service Section 5
Safety Limit #1
Freeze time exceeds 60 minutes for 3 consecutive freeze cycles.
Possible Cause Check/Correct
Improper installation • See “Installation Instructions” Section two of this manual
Water system • Low water pressure (20 psi minimum.)
• High water pressure (80 psi maximum.)
• High water temperatur e (90°F/32.2°C maximum.)
• Clogged water distribution tube
• Dirty/defective water float valve
• Loss of water from sump area
• Defective water pump
Electrical system • Ice thickness probe out of adjustment
• Harvest cycle not initiated electrically
• Relay not energizi ng
• Compressor electrically non-operational
Restricted condenser air flow
(air-cooled models)
Refrigeration system • Non-Manitowoc components
• High inlet air temperature (110°F/43.3°C maximum.)
• Condenser discharge air recirculation
• Dirty condenser filter
• Dirty condenser fins
• Defective fan cycling control
• Defective fan motor
• Improper refrigerant charge
• Defective hot gas valve
• Defective compressor
• TXV starving or flooding (check insulation and bulb mounting)
• Non-condensables in refrigeration system
• Plugged or restricted high side refrigerant lines or component
Safety Limit #2
Harvest time exceeds 3.5 minutes for 3 consecutive harvest cycles.
Possible Cause Check/Correct
Improper installation • See “Installation Instructions” Section two of this manual
Water system • Water area (evaporator) dirty
• Water freezing behind evaporator
• Low water pressure (20 psi min.)
• Loss of water from sump area
• Clogged water distribution tube
• Dirty/defective water float valve
• Defective water pump
Electrical system • Ice thickn ess probe out of adjustment
• Ice thic kness probe dirty
• Bin switch defective
• Premature harvest
Refrigeration system • Non-Manitowoc components
• Improper refrigerant charge
• Defective hot gas valve
• TXV flooding (check insulation and bulb mounting)
• Defective fan cycling control
Because there are many possible external problems,
do not limit your diagnosis to only the items listed in these charts.
5-4
