UnderCounter Model
Ice Machines
Installation, Use & Care Manual
This manual is updated as new information and models are released.
Visit our website for the latest manual. www.manitowocfsg.com
America’s #1 Selling Ice Machine
Part Number 000001774 07/08
QM45
Safety Notices
As you work on Manitowoc equipment, be sure to pay
close attention to the safety notices in this manual.
Disregarding the notices may lead to serious injury and/
or damage to the equipment.
Throughout this manual, you will see the following types
of safety notices:
Warning
!
Text in a Warning box alerts you to a potential
personal injury situation. Be sure to read the
Warning statement before proceeding, and work
carefully.
Caution
!
Text in a Caution box alerts you to a situation in
which you could damage the equipment. Be sure to
read the Caution statement before proc eeding, and
work carefully.
Procedural Notices
As you work on Manitowoc equipment, be sure to read
the procedural notices in this manual. These notices
supply helpful information which may assist you as you
work.
Throughout this manual, you will see the following types
of procedural notices:
Read These Before Proceeding:
Caution
!
Proper installation, care and maintenance are
essential for maximum performance and troublefree operation of your Manitow oc equipment. Read
and understand this manual. It contains valuable
care and maintenance information. If you encounter
problems not covered by this manual, do not
proceed, contact Manitowoc Foodservice Group.
We will be happy to provide assistance.
Important
Routine adjustments and maintenance procedures
outlined in this manual are not covered by the
warranty.
Warning
!
PERSONAL INJURY POTENTIAL
Do not operate equipment that has been misused,
abused, neglected, damaged, or altered/modified
from that of original manufactured specifications.
NOTE: SAVE THESE INSTRUCTIONS.
Important
Text in an Important box provides you with
information that may help you perform a procedure
more efficiently. Disregarding this information will
not cause damage or injury, but it may slow you
down as you work.
NOTE: Text set off as a Note provides you with simple,
but useful, extra information about th e pr oce dur e yo u
are performing.
We reserve the right to make product improvements at any time.
Specifications and design are subject to change without notice.
Section 1
General Information
Model Numbers. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-1
Accessories. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-1
Model/Serial Number Location . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-2
Owner Warranty Registration Card. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-3
Section 2
Installation Instructions
General . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-1
Ice Machine Dimensions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-1
Location of Ice Machine. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-2
Ice Machine Heat of Rejection . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-2
Leveling the Ice Machine . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-2
Electrical Service . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-3
Water Service/Drains . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-4
Installation Checklist . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-6
Before Starting the Ice Machine . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-6
Table of Contents
Tri-liminator Water Filter System . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-1
Manitowoc Cleaner and Sanitizer . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-1
General . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-3
Commercial Warranty Coverage . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-3
Residential Warranty Coverage . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-4
Voltage . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-3
Fuse/circuit breaker . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-3
electrical Rating . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-3
Water Supply . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-4
Drain Connections . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-4
Water Supply and Drain Line Sizing/Connections. . . . . . . . . . . . . . . . . . . . 2-4
Section 3
Operation
Component Identification . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-1
Ice Making Sequence of Operation. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-2
Initial Start-up Or Start-up After Automatic Shut-off . . . . . . . . . . . . . . . . . . 3-2
Freeze Sequence . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-2
Harvest Sequence . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-2
Automatic Shut-off . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-2
Part Number 000001774 07/08 i
Section 4
Maintenance
Table of Contents (continued)
Energized Parts Chart. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-3
Operational Checks. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-4
General . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-4
Siphon System . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-4
Siphon System Check . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-4
water Float Valve Check . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-4
Water Level Check . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-5
Ice Bridge Thickness Check . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-5
Interior Cleaning and Sanitizing . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-1
General . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-1
Cleaning And Sanitizing Procedure . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-1
Ice Machine Inspection . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-8
Exterior Cleaning . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-8
Cleaning the Condenser . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-8
Removal From Service Winterization . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-8
Section 5
Before Calling for Service
Checklist . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-1
Safety Limit Feature . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-2
Safety Limits . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-3
ii Part Number 000001774 07/08
Section 1
General Information
Model Numbers
This manual covers the following models:
Self-Contained
Air-Cooled
QM45A 115/60/1
QM45A 230/50/1
Self-Contained
Water-Cooled
Accessories
Contact your Manitowoc distributor for these optional
accessories:
TRI-LIMINATOR WATER FILTER SYSTEM
Engineered specifically for Manitowoc ice machines, TriLiminator water filters are an efficient, dependable, and
affordable method of inhibiting scale formation, filtering
sediment, and removing chlorine taste and odor.
MANITOWOC CLEANER AND SANITIZER
Manitowoc Ice Machine Cleaner and Sanitizer are
available in convenient 16 oz. (473 ml) and 1 g al (3.7 8 l)
bottles. These are the only cleaner and sanitizer
approved for use with Manitowoc products.
Cleaner Part Number Sanitizer Part number
16oz 94-0456-3 16oz 94-0565-3
1 Gallon 94-0580-3 1 Gallon 94-0581-3
Part Number 000001774 07/08 1-1
General Information Section 1
Model/Serial Number Location
Record the model and serial number of your ice machine
in the space provided below. These numbers are
required
when requesting information from your local
Manitowoc distributor, service represen tative, or
Manitowoc Ice, Inc.
The model and serial number are listed on the OWNER
WARRANTY REGISTRATION CARD. They are also
listed on the MODEL/SERIAL NUMBER DECAL affixed
to the ice machine.
MODEL/SERIAL
PLATE LOCATION
Ice Machine
Model Number
Serial Number
MODEL/SERIAL
PLATE LOCATION
Model/Serial Number Location
1-2 Part Number 000001774 07/08
Section 1 General Information
Owner Warranty Registration Card
General
The packet containing this manual also includes
warranty information. Warranty coverage beg ins the day
your new ice machine is installed.
Important
Complete and mail the OWNER WARRANTY
REGISTRATION CARD as soon as possible to
validate the installation date.
If you do not return your OWNER WARRANTY
REGISTRATION CARD, Manitowoc will use the date of
sale to the Manitowoc Distributor as the first day of
warranty coverage for your new ice machine.
COMMERCIAL WARRANTY COVERAGE
General
The following Warranty outline is provided for your
convenience. For a detailed explanation , re ad the
warranty bond shipped with each product.
Contact your local Manitowoc representative or
Manitowoc Ice, Inc. if you need further warranty
information.
Parts
Manitowoc warrants the ice machine against defects in
materials and workmanship, under normal use and
service for three (3) years from the date of original
installation.
Labor
Labor required to repair or replace defective
components is covered for three (3) years from the date
of original installation.
Exclusions
The following items are not included in the ice machine’s
warranty coverage:
1. Normal maintenance, adjustments and cleaning as
outlined in this manual.
2. Repairs due to unauthorized modifications to the ice
machine or use of non-standard parts without prior
written approval from Manitowoc Ice, Inc.
3. Damage caused by improper installation of the ice
machine, electrical supply , water supp ly or drainage,
or damage caused by floods, storms, or other acts of
God.
4. Premium labor rates due to holidays, overtime, etc.;
travel time; flat rate service call charges; mileag e
and miscellaneous tools and material charges not
listed on the payment schedule. Additional labor
charges resulting from the inaccessibility of
equipment are also excluded.
5. Parts or assemblies subjected to misuse, abuse,
neglect or accidents.
6. Damage or problems caused by installation,
cleaning and/or maintenance procedures
inconsistent with the technical instructions provided
in this manual.
Authorized Warranty Service
To comply with the provisions of the warranty, a
refrigeration service company, qualified and authorized
by your Manitowoc distributor, or a Contracted Service
Representative must perform the warranty repair.
NOTE: If the dealer you purchased the ice machine from
is not authorized to perform warranty service, contact
your Manitowoc distributor or Manitowoc Ice, Inc. for the
name of the nearest authorized service representative.
Service Calls
Normal maintenance, adjustments and cleaning as
outlined in this manual are not covered by the warranty.
If you have followed the procedures listed in this manual,
and the ice machine still does not perform properly, call
your authorized service company.
Part Number 000001774 07/08 1-3
General Information Section 1
RESIDENTIAL WARRANTY COVERAGE
WHAT DOES THIS LIMITED WARRANTY COVER?
Subject to the exclusions and limitations below,
Manitowoc Ice, Inc. (“Manitowoc”) warrants to the
original consumer that any new ice machine
manufactured by Manitowoc (the “Product” ) shall be free
of defects in material or workmanship for the warranty
period outlined below under normal use and
maintenance, and upon proper installation and start-up
in accordance with the instruction manual supplied with
the Product.
HOW LONG DOES THIS LIMITED WARRANTY
LAST?
Ice Machine - Twelve (12) months from the sale date
WHO IS COVERED BY THIS LIMITED WARRANTY?
This limited warranty only applies to the original
consumer of the Product and is not transferable.
WHAT ARE MANITOWOC ICE’S OBLIGATIONS
UNDER THIS LIMITED WARRANTY?
If a defect arises and Manitowoc receives a valid
warranty claim prior to the expiration of the warranty
period, Manitowoc shall, at its option: (1) repair the
Product at Manitowoc’s cost, including standard straight
time labor charges, (2) replace the Product with one that
is new or at least as functionally equivalent as the
original, or (3) refund the purchase price for the Pr oduct.
Replacement parts are warranted for 90 days or the
balance of the original warranty period, whiche ve r is
longer. The foregoing constitutes Manitowoc’s sole
obligation and the consumer’s exclusive remedy for any
breach of this limited warranty. Manitowoc’s liability
under this limited warranty is limited to the purchase
price of Product. Additional expenses including, without
limitation, service travel time, overtime or premium labor
charges, accessing or removing the Product, or shipping
are the responsibility of the consumer.
HOW TO OBTAIN WARRANTY SERVICE
To obt a in wa rr anty ser v ice or in form ation re gard ing yo ur
Product, please contact us at:
MANITOWOC ICE, INC.
2110 So. 26
th
St.,
P.O. Box 1720,
Manitowoc, WI 54221-1720
Telephone: 920-682-0161 Fax: 920-683-7585
www.manitowocice.com
WHAT IS NOT COVERED?
This limited warranty does not cover, and you are solely
responsible for the costs of: (1) periodic or routine
maintenance, (2) repair or replacement of the Product or
parts due to normal wear and tear, (3) defects or
damage to the Product or parts resulting from misuse,
abuse, neglect, or accidents, (4) defects or damage to
the Product or parts resulting from improper or
unauthorized alterations, modifications, or changes; and
(5) defects or damage to any Product that has not been
installed and/or maintained in accordance with the
instruction manual or technical instructions provided by
Manitowoc. To the extent that warranty exclusions are
not permitted under some state laws, these exclusions
may not apply to you.
EXCEPT AS STATED IN THE FOLLOWING
SENTENCE, THIS LIMITED WARRANTY IS THE SOLE
AND EXCLUSIVE WARRANTY OF MANITOWOC
WITH REGARD TO THE PRODUCT. ALL IMPLIED
WARRANTIES ARE STRICTLY LIMITED TO THE
DURATION OF THE LIMITED WARRANTY
APPLICABLE TO THE PRODUCTS AS STATED
ABOVE, INCLUDING BUT NOT LIMITED TO, ANY
WARRANTY OF MERCHANT ABILITY OR OF FITNESS
FOR A PARTICULAR PURPOSE. Some states do not
allow limitations on how long an implied warranty lasts,
so the above limitation may not apply to you.
IN NO EVENT SHALL MANITOWOC OR ANY OF ITS
AFFILIATES BE LIABLE TO THE CONSUMER OR ANY
OTHER PERSON FOR ANY INCIDENTAL,
CONSEQUENTIAL OR SPECIAL DAMAGES OF ANY
KIND (INCLUDING, WITHOUT LIMITATION, LOSS OF
PROFITS, REVENUE OR BUSINESS) ARISING FROM
OR IN ANY MANNER CONNECTED WITH THE
PRODUCT, ANY BREACH OF THIS LIMITED
WARRANTY, OR ANY OTHER CAUSE WHA TSOEVER,
WHETHER BASED ON CONTRACT, TORT OR ANY
OTHER THEORY OF LIABILITY. Some states do not
allow the exclusion or limitation of incidental or
consequential damages, so the above limitation or
exclusion may not apply to you.
HOW STATE LAW APPLIES
This limited warranty gives you specific legal rights, and
you may also have rights that vary from state to state or
from one jurisdiction to another.
REGISTRATION CARD
To secure prompt and continuing warranty service, this
warranty registration card must be completed and sent
to Manitowoc within thirty (30) days from the sale date.
Complete the following registration card and send it to
Manitowoc at the address shown.
1-4 Part Number 000001774 07/08
Section 2
Installation Instructions
General
These instructions are provided to assist the qualified
installer.
Dimensions
50.00cm
57.00cm
79.00cm
1.90cm±0.63cm
Part Number 000001774 07/08 2-1
Installation Instructions Section 2
Location of Ice Machine
The location selected for the ice machine must meet the
following criteria. If any of these criteria are not met,
select another location.
• The location must be indoors.
• The location must be free of airborne and other
contaminants.
• The air temperature must be at least 1.6° C (35°F),
but must not exceed 43.4°C (110°F).
• The location must not be near heat-generating
equipment or in direct sunlight.
• The location must be capable of supporting the
weight of the ice machine and a full bin of ice.
• The location must allow enough clearance for water,
drain and electrical connections in the rear of the ic e
machine.
• The location must not obstruct airflow through or
around the ice machine (condenser airflow is in and
out the front). Refer to the chart below for clearance
requirements.
Ice machines, like other refrigeration equipment, reject
heat through the condenser. It is helpful to know the
amount of heat rejected by the ice machine when sizing
air conditioning equipment where self-contained aircooled ice machines are installed.
Leveling the Ice Machine
After moving the ice machine into the installation
location, it must be leveled for proper operation. Follow
these steps to level the ice machine:
1. Check the level of the ice machine from front to back
and from side to side.
Self-Contained Air-Cooled
Top/Sides 5” (127 mm)*
Back 5” (127 mm)*
NOTE: The ice machine may be built into a cabinet.
There is no minimum clearance requirement for the top
or left and right sides of the ice machine. The listed
values are recommended for efficient operation and
servicing only.
Caution
!
The ice machine must be protected if it will be
subjected to temperatures below 32°F (0°C).
Failure caused by exposure to freezing
temperatures is not covered by the warranty. See
“Removal from Service/Winterization” Section 4.
Ice Machine Heat of Rejection
Series
Ice Machine
QM45 1750 2600
Air Conditioning** Peak
Heat of Rejection*
Checking for Level
2. If the ice machine is not level, adjust the leveling
glides on each corner of the base of the ice machine
as necessary.
Leveling Glide
3. Check the level of the ice machine after each
adjustment of the leveling glides.
*B.T.U./Hour
**Because the heat of rejection varies during the ice making
cycle, the figure shown is an average.
2-2 Part Number 000001774 07/08
4. Repeat steps 2 and 3 until the ice machine is level
from front to back and from side to side.
Section 2 Installation Instructions
Electrical Service
!
Warning
All wiring must conform to local, state and national
codes.
Voltage Phase Total Amps
Never use an extension cord. If an outlet is not
within reach of the ice machine’s power cord, have
a proper amperage outlet wired closer to the ice
machine.
!
Warning
230/50/1 2.6
115/60/1 5.2
VOLTAGE
The maximum allowable voltage variation is ± 10% of
the rated voltage on the ice machine model/serial
number plate at start-up (when the electrical load is
highest).
!
Warning
The ice machine must be grounded in accordance
with national and local electrical codes.
FUSE/CIRCUIT BREAKER
A separate fuse/circuit breaker must be provided for
each ice machine.
NOTE: A disconnect means must be provided for field
wiring.
ELECTRICAL RATING
The electrical rating is used to help select the wire size
of the electrical supply. The wire size (or gauge) also
depends on location, materials used, length of run, etc.,
so it must be determined by a qualified electrician.
Part Number 000001774 07/08 2-3
Installation Instructions Section 2
Water Service/Drains
WATER SUPPLY
Local water conditions may require treatment of the
water to inhibit scale formation, filter sediment, remove
chlorine, and improve taste and clarity.
Important
If you are installing a Manitowoc Tri-Liminator
water filter system, refer to the Installation
Instructions supplied with the filter system for ice
making water inlet connections.
• Install a water shut-off valve for both the ice making
and condenser water lines (if applicable).
•
Insulate water lines to prevent condensation.
Important
The water inlet line is connected to the water
valve. This valve is located just behind the front
panel of the ice machine.
Follow these guidelines to install water inlet lines:
• Connect to potable water supply only.
• Do not connect the ice machine to a hot water
supply. Be sure all hot water restrictors installed for
other equipment are working. (Check valves on sink
faucets, dishwashers, etc.)
• If water pressure exceeds the maximum
recommended pressure, obtain a water pressure
regulator from your Manitowoc distributor.
WATER SUPPLY AND DRAIN LINE SIZING/CONNECTIONS
Caution
!
Plumbing must conform to state and local codes.
DRAIN CONNECTIONS
Follow these guidelines when installing drain lines to
prevent drain water from flowing back into the ice
machine and storage bin:
• Drain lines must have a 2.5 cm (1 inch) drop per 1
meter (40 inches) of run, and must not create traps.
• The floor drain must be large enough to
accommodate drainage from all drains.
• Insulate the bin drain line to prevent condensation.
Water
Pressure
1
2
Ice Making
Water Inlet
Water
Temperature
0.6°C (33° F)
32.2°C (90° F)Max.
Min.
1
137.9 kPA (20 psi)Min.
2
551.5 kPA (80 psi)Max.
Ice Making/
Bin Water
—— ——
Drain
1
Min. = Minimum
2
Max. = Maximum
2-4 Part Number 000001774 07/08
Ice Machine
Fitting
3/8” male hose
connection
1.59 cm (5/8”)
diameter flexible
hose
inside
T u bin g Size Up to Ice
Machine Fitting
0.95 cm (3/8”)
minimum inside
diameter
1.59 cm (5/8”)
minimum inside
diameter
Section 2 Installation Instructions
ICE MAKING WATER
INLET TUBING 3/8”
MIN.I.D.
ICE MAKING WATER/BIN
DRAIN 5/8” MIN.I.D.
WATER
SHUTOFF
Typical Water Supply and Drain Line Sizing and Connections
Part Number 000001774 07/08 2-5
Installation Instructions Section 2
Installation Checklist Before Starting the Ice Machine
All Manitowoc ice machines are factory-operated and
Is the ice machine level?
Has all of the internal packing been removed?
Have all of the electrical and water connection s
been made?
Has the supply voltage been tested and
checked against the rating on the nameplate?
adjusted before shipment. Normally, new installations do
not require any adjustment.
To ensure proper oper at i on , follo w th e Oper ational
Checks on page 3-4 of this manual. Starting the ice
machine and completing the Operational Checks are the
responsibilities of the owner/operator.
NOTE: Adjustments and maintenance procedures
outlined in this manual are not covered by the warranty.
Is there proper clearance around the ice
machine for air circulation?
Has the ice machine been installed where
ambient temperatures will remain in the range
of 35° – 110°F (1.7° – 43.3°C)?
Has the ice machine been installed where the
incoming water temperature will remain in the
range of 33° – 90°F (0.6° – 32.2°C)?
Are all electrical leads free from contact with
refrigeration lines and moving equipment?
Has the owner/operator been instructed
regarding maintenance and the use of
Manitowoc Cleaner and Sanitizer?
Has the owner/operator complete d the warranty
registration card?
Has the ice machine and bin been sanitized?
!
Warning
PERSONAL INJURY POTENTIAL
Do not operate equipment that has been misused,
abused, neglected, damaged, or altered/modified
from that of original manufactured specifications.
Has this manual been given to the owner/
operator?
2-6 Part Number 000001774 07/08
Component Identification
ICE THICKNESS PROBE
WATER DISTRIBUTION
Section 3
Operation
FLOAT VALVE ASSEMBLY
WATER TROUGH
CONDENSER AIR FILTER
ICE DAMPER
BIN SWITCH MAGNET
WATER PUMP
ON/OFF/WASH TOGGLE SWITCH
Part Number 000001774 07/08 3-1
Operation Section 3
Ice Making Sequence of Operation
INITIAL START-UP OR START-UP AFTER AUTOMATIC SHUT-OFF
1. Pressure Equalization
Before the compressor starts the hot gas valve is
energized for 15 seconds to equalize pressures during
the initial refrigeration system start-up.
2. Refrigeration System Start-Up
The compressor starts after the 15-second pressure
equalization, and remains on throughout the entire
Freeze and Harvest Sequences. The hot gas valve
remains on for 5 seconds during initial compressor startup and then shuts off.
At the same time the compressor starts, the condenser
fan motor (air-cooled models) is supplied with power
throughout the entire Freeze and Harvest Sequences.
The fan motor is wired through a fan cycle pressure
control, therefore it may cycle on and off. (The
compressor and condenser fan motor are wired through
the relay . As a result, any time the relay coil is energized,
the compressor and fan motor are supplied with power.)
FREEZE SEQUENCE
3. Prechill
The compressor is on for 30 seconds prior to water flow
to Prechill the evaporator.
4. Freeze
The water pump starts after the 30-second Prechill. An
even flow of water is directed across the evaporator and
into each cube cell, where it freezes.
When sufficient ice has formed, the water flow (not the
ice) contacts the ice thickness probe. After
approximately 7 seconds of continual water contact, the
Harvest Sequence is initiated. The ice machine cannot
initiate a Harvest Sequence until a 6-minute freeze time
has been surpassed.
HARVEST SEQUENCE
5. Harvest
The water pump de-energizes stopping flow over the
evaporator. The rising level of water in the sump trough
diverts water out of the overflow tube, purging excess
minerals from the sump trough. The hot gas valv e also
opens to divert hot refrigerant gas into the evaporator.
The refrigerant gas warms the evaporator causing the
cubes to slide, as a sheet, off the evaporator an d into the
storage bin. The sliding sheet of cubes contacts the ice
damper, opening the bin switch.
The momentary opening and re-closing of the bin switch
terminates the Harvest Sequence and returns the ice
machine to the Freeze Sequence (steps 3 - 4).
AUTOMATIC SHUT-OFF
6. Automatic Shut-Off
When the storage bin is full at the end of a Harvest
Sequence, the sheet of cubes fails to clear the ice
damper and will hold it down. After the ice damper is
held open for 7 seconds, the ice machine shuts off. The
ice machine remains off for 3 minutes before it can
automatically restart.
The ice machine remains off until enough ice has been
removed from the storage bin to allow the ice to fall clear
of the damper. As the ice damper swings back to the
operating position, the bin switch re-closes and the ice
machine restarts (steps 1 - 2), provided the 3-minute
delay period is complete.
3-2 Part Number 000001774 07/08
Section 3 Operation
Energized Parts Chart
CONTROL BOARD RELAYS RELAY
12 3 3A 3BLENGTH
WATER
PUMP
INITIAL START-UP/
START UP AFTER
AUTO SHUT-OFF:
1. Pressure
Equalization
2. Refrigeration
System Start-up
FREEZE
SEQUENCE:
3. Pre-Chill
4. Freeze ON OFF ON ON ON
OFF ON OFF OFF OFF
OFF ON ON ON ON
OFF OFF ON ON ON
HOT GAS
VALVE
RELAY
COIL
COMPRESSOR
CONDENSER ∗
FAN MOTOR
of “ON” TIME
15
Seconds
5
Seconds
30
Seconds
Until 7 sec.
water contact
with ice
thickness
probe
HARVEST
SEQUENCE:
5. Harvest
AUTOMAT IC SHUT-
OFF:
6. Auto Shut-Off
* Condenser Fan Motor: The fan motor is wired through a fan cycle pressure control, therefore, it may cycle on and off.
OFF ON ON ON ON
OFF OFF OFF OFF OFF
Bin switch
activation
Until
bin switch
re-closes
Part Number 000001774 07/08 3-3
Operation Section 3
Operational Checks
GENERAL
Your Manitowoc ice machine was factory-operated and
adjusted before shipment. Normally , a newly inst alled ice
machine does not require any adjustment.
To ensure proper operation, always follow these
Operational Checks when starting the ice machine:
• for the first time
• after a prolonged out of service period
• after cleaning and sanitizing
Routine adjustments and maintenance procedures
outlined in this manual are not covered by the warranty.
SIPHON SYSTEM
To reduce mineral build-up and cleaning frequency, the
water in the sump trough must be purged during each
harvest cycle.
When the water pump de-energizes the level in the
water trough rises above the standpipe st artin g a siphon
action. The siphon action stops when the water level in
the sump trough drops. When the siphon action stops,
the float valve refills the water trough to the correct level.
WATER FLOAT VALVE CHECK
Before water will flow into the water trough the float
valve shut-off must be in the OPEN position.
PRESS TO
OPEN
PRESS TO
CLOSE
Water Level
Siphon System Check
Follow steps 1 through 6 under water level check.
SIPHON
CAP
WATER
LEVEL
STANDPIPE
DRAIN
3-4 Part Number 000001774 07/08
Section 3 Operation
WATER LEVEL CHECK
Check the water level while the ice machine is in the ice
mode and the water pump is running. The correct water
level is 1/4”(6.3mm) to 3/8” (9.5mm) below the top of the
standpipe a line in the water trough indica tes the correct
level.
SIPHON CAP
SET THE WA TER LEVEL
TO THE LINE IN THE
WATER TROUGH
Water Level
The float valve is factory-set for the proper water level. If
adjustments are necessary:
1. Verify the ice machine is level (see page 2-4).
ICE BRIDGE THICKNESS CHECK
The ice thickness probe is factory-set to maintain th e ice
bridge thickness at 1/8” (3.2 mm).
1. Inspect the bridge connecting the cubes. It should
be about 1/8” (3.2 mm) thick.
2. If adjustment is necessary, turn the ice thickness
probe adjustment screw clockwise to increase
bridge thickness, or counterclockwise to decrease
bridge thickness.
NOTE: Turning the adjustment 1/3 of a turn will change
the ice thickness about 1/16” (1.5 mm).
ADJUSTING SCREW
1/8” ICE BRIDGE THICKNESS
2. Remove the siphon cap from the standpipe.
3. Place the main ON/OFF/ WASH toggle switch to the
ON position, and wait until the float valve stops
adding water.
4. Adjust the water level to (1/4" to 3/8"
5. (6.3 to 9.5 mm) below the standpipe) the line in
6. the water trough:
7. Loosen the two screws on the float valve bracket.
8. Raise or lower the floa t valve assembly as
necessary, then tighten the screws.
9. Move the main ON/OFF/ WASH toggle switch to the
OFF position. The water level in the trough will rise
above the standpipe and run down the drain.
10. Replace the siphon cap on the standpipe, and verify
water level and siphon action by repeating steps 3
through 5.
Ice Thickness Check
Make sure the ice thickness probe wire and the brac ket
do not restrict movement of the probe.
Part Number 000001774 07/08 3-5
Operation Section 3
THIS PA GE INTENTIO NALLY LEFT BLANK
3-6 Part Number 000001774 07/08
Section 4
Maintenance
Interior Cleaning and Sanitizing
GENERAL
Clean and sanitize the ice machine every six months for
efficient operation. If the ice machine requires more
frequent cleaning and sanitizing, consult a qualified
service company to test the water quality and
recommend appropriate water treatment.
The ice machine must be taken apart for cleaning and
sanitizing.
Caution
!
Use only Manitowoc approved Ice Machine Cleaner
(part number 94-0546-3) and Sanitizer (part
number 94-0565-3). It is a violation of Federal law
to use these solutions in a manner inconsistent with
their labeling. Read and understand all labels
printed on bottles before use.
CLEANING AND SANITIZING PROCEDURE
Caution
!
Do not mix Ice Machine Cleaner and Sanitizer
solutions together. It is a violation of Federal law to
use these solutions in a manner inconsistent with
their labeling.
Warning
!
Wear rubber gloves and safety goggles (and/or face
shield) when handling Ice Machine Cleaner or
Sanitizer.
Step 3 T o st art a cleaning cycle, move the toggle switch
to the WASH position.
Step 4 Add the proper amount of Manitowoc Ice
Machine Cleaner to the water trough.
Model Amount of Cleaner
QM45 1.5 ounces (45 ml)
Step 5 Wait until the clean cycle is complete
(approximately 22 minutes) then place the toggle switch
in the OFF position, disconnect power and water
supplies to the ice machine.
!
Warning
Disconnect electric power to the ice machine at the
electric switch box before proceeding.
Step 6 Remove parts for cleaning.
A. Remove the Vinyl Hose
• Disconnect the water hose from the
distribution tube and water pump.
B. Remove Water Pump
• Disconnect the water pump power cord.
DO NOT SOAK
WATER PUMP MOTOR IN
CLEANER OR SANITIZER
SOLUTIONS
Ice machine cleaner is used to remove lime scale and
mineral deposits. Ice machine sanitizer disinfects and
removes algae and slime.
Step 1 Set the toggle switch to the OFF position after
ice falls from the evaporator at the end of a Harvest
cycle. Or, set the switch to the OFF position and allow
the ice to melt off the evaporator.
Caution
!
Never use anything to force ice from the evaporator.
Damage may result.
Step 2 Remove all ice from the bin.
Part Number 000001774 07/08 4-1
• Loosen the screws securing the pump-
• Lift the pump and bracket assembly off the
Water Pump Removal
mounting bracket to the bulkhead.
mounting screws.
Maintenance Section 4
C. Remove the Ice Thickness Probe
• Compress the side of the ice thickness
probe near the top hinge pin and remove it
from the bracket.
ICE THICKNESS
PROBE
COMPRESS SIDES OF ICE
THICKNESS PROBE
Ice Thickness Probe Removal
NOTE: At this point, the ice thickness probe can easily
be cleaned. If complete removal is desired follow the ice
thickness probe wire to the bulkhead grommet (exit
point) in the back wall. Pop the bulkhead grommet out of
the back wall by inserting fingernails or a flat object
between the back wall and the grommet and prying
forward. Pull the bulkhead grommet and wire forward
until the connector is accessible, then disconnect the
wire lead from the connector.
Ice Thickness Probe Cleaning
• Mix a solution of Manitowoc ice machine cleaner and
water (2 ounces of cleaner to 16 ounces of water) in
a container.
• Soak the ice thickness probe a minimum of 10
minutes.
Clean all ice thickness probe surfaces and verify the ice
thickness probe cavity is clean. Rinse thoroughly with
clean water , then dry completely. Incomplete rinsing and
drying of the ice thickness probe can cause prema tur e
harvest.
D. Remove the Water Distribution Tube
1. LIFT UP
2. SLIDE BACK
3. SLIDE TO RIGHT
DISTRIBUTION
TUBE
3
THUMBSCREW
2
1
THUMBSCREW
LOCATING
PIN
Water Distribution Tube Removal
• Loosen the two thumbscrews, which secure the
distribution tube.
• Lift the right side of the distribution tube up off the
locating pin, then slide it back and to the right.
Caution
!
Do not force this removal. Be sure the locating pin is
clear of the hole before sliding the distribution tube
out.
Disassembly
• Twist both of the inner tube ends until the tabs line up
with the keyways.
• Pull the inner tube ends outward.
INNER TUBE
INNER TUBE
KEYWAY
TAB
Water Distribution Tube Disassembly
4-2 Part Number 000001774 07/08
Section 4 Maintenance
E. Remove the Float Valve
• Turn the splash shield counterclockwise one or two
turns.
FLOAT VALVE
BRACKET
COMPRESSION
FITTING
SHUT-OFF VALVE
SPLASH SHIELD
CAP AND
FILTER SCREEN
FLOAT
Float Valve Removal
F. Remove the Water Trough
• Apply downward pressure on the siphon tube and
remove from the bottom of the water trough.
• Remove the upper thumbscrew.
• While supporting the water trough remove the two
thumbscrews from beneath the water trough.
• Remove the water trough from the bin area.
UPPER
THUMBSCREW
LOWER
THUMBSCREWS
REMOVE
SIPHON TUBE
• Pull the float valve forward and off the mounting
bracket.
• Disconnect the water inlet tube from the float valve at
the compression fitting.
• Remove the cap and filter screen for cleaning.
Part Number 000001774 07/08 4-3
Maintenance Section 4
G. Remove the ice damper.
• Grasp ice damper and apply pressure to ward the lef t
hand mounting bracket.
• Apply pressure to the right hand mounting bracket
with thumb.
• Pull ice damper forward when the right hand ice
damper pin disengages.
Installation
• Place ice damper pin in left hand mounting bracket
and apply pressure toward the left hand mounting
bracket.
H. Remove the Bin Door
• Grasp the rear of the bin door and pull bin door
forward approximately 5”.
• Slide bin door to the rear while applying upward
pressure (The rear door pins will ride up into the track
slot and slide backward to the stop tab).
• While applying pressure against the bin door pull
down on the rear of each bin door track until th e door
pins clear the stop tabs.
• Slide the rear door pins off the end and then below
the door track. Slide bin door forward allowing the
back of the door to lower into the bin. Continue
forward with the bin door until the front pins bottom
out in the track.
• Lift right side of door until the front pins clear the
track, then remove door from bin.
PRESS DOWN
TO RELEASE
DOOR
STOP TAB
TRACK SLOT
SLIDE DOOR
FORWARD
• Apply pressure to the right hand mounting bracket
with thumb.
• Push ice damper toward evaporator until right hand
damper pin engages.
4-4 Part Number 000001774 07/08
Section 4 Maintenance
Step 7 Mix a solution of cleaner and warm water.
Depending on the amount of mineral buildup, a larger
quantity of solution may be required. Use the ratio in the
table below to mix enough solution to thoroughly clean
all parts.
Solution Type Water Mixed with
Cleaner 1 gal. (4 l) 16 oz (500 ml) cleaner
Step 8 Use ½ of the cleaner/water solution to clean all
components. The cleaner solution will foam when it
contacts lime scale and mineral deposits; once the
foaming stops use a soft bristle brush, sponge or cloth
(not a wire brush) to carefully clean the parts. Soak the
parts for 5 minutes (15 – 20 minutes for heavily scaled
parts). Rinse all components with clean water.
Step 9 While components are soaking, use ½ of the
cleaner/water solution to clean all foodzone surfaces of
the ice machine and bin. Use a nylon brush or cloth to
thoroughly clean the following ice machine areas:
• Evaporator plastic parts – including top, bottom and
sides
• Bin bottom, sides and top
Rinse all areas thoroughly with clean water.
Step 10 Mix a solution of sanitizer and warm water.
Step 15 Add the proper amount of Manitowoc Ice
Machine Sanitizer to the water trough.
Model Amount of Sanitizer
QM45 1.5 ounces (45 ml)
Step 16 Wait until the sanitize cycle is complete
(approximately 22 minutes) then place the toggle switch
in the OFF position, disconnect power and water
supplies to the ice machine.
!
Warning
Disconnect electric power to the ice machine at the
electric switch box before proceeding.
Step 17 Repeat step 6 to remove parts for hand
sanitizing.
Step 18 Mix a solution of sanitizer and warm water.
Solution Type Water Mixed With
Sanitizer 6 gal. (23 l) 4 oz (120 ml) sanitizer
Step 19 Use 1/2 of the sanitizer/water solution to
sanitize all removed components. Use a cloth or sponge
to liberally apply the solution to all surfaces of the
removed parts or soak the removed parts in the
sanitizer/water solution. Do not rinse parts after
sanitizing.
Solution Type Water Mixed With
Sanitizer 6 gal. (23 l) 4 oz (120 ml) sani t ize r
Step 11 Use 1/2 of the sa nit izer /wa te r so lut ion to
sanitize all removed components. Use a cloth or sponge
to liberally apply the solution to all surfaces of the
removed parts or soak the removed parts in the
sanitizer/water solution. Do not rinse parts after
sanitizing.
Step 12 Use 1/2 of the sanitizer/water solution to
sanitize all foodzone surfaces of the ice machine and
bin. Use a cloth or sponge to liberally apply th e solu tion.
When sanitizing, pay particular attention to the f ollowing
areas:
• Evaporator plastic parts - including top, bottom and
sides
• Bin bottom, sides and top
Do not rinse the sanitized areas.
Step 13 Replace all removed components.
Step 14 Reapply power and water to the ice machine
and place the toggle switch in the WASH position.
Step 20 Use 1/2 of the sanitizer/water solution to
sanitize all foodzone surfaces of the ice machine and
bin. Use a cloth or sponge to liberally apply the solutio n.
When sanitizing, pay particular attention to the following
areas:
• Evaporator plastic parts - including top, bottom and
sides
• Bin bottom, sides and top
Do not rinse the sanitized areas.
Step 21 Replace all removed components.
Step 22 Reapply power and water to the ice machine
and place the toggle switch in the ICE position.
Part Number 000001774 07/08 4-5
Maintenance Section 4
Ice Machine Inspection
Check all water fittings and lines for leaks. Also, make
sure the refrigeration tubing is not rubbing or vibrating
against other tubing, panels, etc.
Do not put anything (boxes, etc.) in front of the ice
machine. There must be adequate airflow through and
around the ice machine to maximize ice pr od u ctio n an d
ensure long component life.
Exterior Cleaning
Clean the area around the ice machine as often as
necessary to maintain cleanliness and efficient
operation.
Sponge any dust and dirt off the outside of the ice
machine with mild soap and water. Wipe dry with a
clean, soft cloth.
A commercial grade stainless steel cleaner/polish can
be used as necessary.
Cleaning the Condenser
!
Warning
Disconnect electric power to the ice machine at
the electric service switch before cleaning the
condenser.
4. Use a commercial condenser coil cleaner. Follow
the directions and cautions supplied with the
cleaner.
5. Straighten any bent condenser fins with a fin comb.
6. Carefu lly wi pe off the fan blades an d m otor with a
soft cloth. Do not bend the fan blades. If the fan
blades are excessively dirty, wash with warm, soapy
water and rinse thoroughly.
Caution
!
If you are cleaning the condenser fan blades with
water, cover the fan motor to prevent water
damage.
Removal From Service Winterization
Special precautions must be taken if the ice machine is
to be removed from service for an extended period of
time or exposed to ambient temperatures of 32°F (0°C)
or below.
Caution
!
If water is allowed to remain in the ice machine in
freezing temperatures, severe damage to some
components could result. Damage of this nature i s
not covered by the warranty.
A dirty condenser restricts airflow, resulting in
excessively high operating temperatures. This reduces
ice production and shortens component life. Clean the
condenser at least every six months. Follow the steps
below.
!
Warning
The condenser fins are sharp. Use care when
cleaning them.
1. The washable aluminum filter on self-contained ice
machines is designed to catch dust, dirt, lint and
grease. This helps keep the condenser clean. Clean
the filter with a mild soap and water solution.
2. Clean the outside of the condenser with a soft brush
or a vacuum with a brush attachment. Clean from
top to bottom, not side to side. Be careful not to
bend the condenser fins.
3. Shin e a flash ligh t th ro ug h th e co nd en se r to check
for dirt between the fins. If dirt remains: Blow
compressed air through the condenser fins from the
inside. Be careful not to bend the fan blades.
Follow the applicable procedure below.
1. Disconnect the electric power at the circuit breaker
or the electric service switch.
2. Turn off the water supply.
3. Remove the water from the water trough.
4. Disconnect and drain the incoming ice-making water
line at the rear of the ice machine.
5. Blow compressed air in both the incoming water and
the drain openings in the rear of the ice machine
until no more water comes out of the inlet water lines
or the drain.
6. Make sure water is not trapped in any of the water
lines, drain lines, distribution tubes, etc.
4-6 Part Number 000001774 07/08
Section 5
Before Calling for Service
Checklist
If a problem arises during operation of your ice machine, follow the checklist below before calling service. Routine
adjustments and maintenance procedures are not covered by the warranty.
Problem Possible Cause To Correct
Ice machine does not operate. No electrical power to the ice machine. Replace the fuse/reset the breaker/turn on
the main switch/plug power cord into
receptacle.
Ice machine stops, and can be
restarted by moving the toggle
switch to OFF and back to ICE.
Ice machine does not release ice or
is slow to harvest.
Ice machine does not cycle into
harvest mode.
Ice quality is poor
(soft or not clear).
ON/OFF/ WASH toggle switch set
improperly.
Damper in open position (down). Damper must be in upright position and
Safety limit feature stopping the ice machi ne. Refer to “Safety Limit Feature” on the next
Ice machine is dirty. Clean and sanitize the ice machine.
Ice machine is not level. Level the ice machine.
Low air temperature around ice machine. Air temperature must be at least 35°F
The six-minute freeze time lock-in has not
expired yet.
Ice thickness probe is dirty. Clean and sanitize the ice machine.
Ice thickness probe wire is disconnected. Connect the wire.
Ice thickness probe is out of adjustment. Adjust the ice thickness probe.
Uneven ice fill (thin at top of evaporator). See “Shallow or Incomplete Cubes” on the
Poor incoming water quality. Contact a qualified service company to
Water filtration is poor. Replace the filter.
Ice machine is dirty. Clean and sanitize the ice machine.
Water siphon is not working. Check the water siphon system.
Water softener is working improperly
(if applicable).
Move the toggle switch to the ON position.
capable of swinging freely.
page.
(1.7°C).
Wait for freeze lock-in to expire.
next page.
test the quality of the incoming water and
make appropriate filter recommendations.
Repair the water softener.
Continued on next page...
Part Number 000001774 07/08 5-1
Before Calling for Service Section 5
Problem Possible Cause To Correct
Ice machine produces shallow or
incomplete cubes, or the ice
fill pattern on the evaporator is
incomplete.
Low ice capacity. Water float valve filter screen is dirty. Remove and clean the filter screen.
Ice thickness probe is out of adjustment. Adjust the ice thickness probe.
Water trough level is to high or too low. Check the water level.
Water float valve filter screen is dirty. Remove and clean the filter screen.
Water filtration is poor. Replace the filter.
Hot incoming water. Connect the ice machine to a cold water
supply.
Water float valve is not working. Remove the water float valve and clean it.
Incorrect incoming water pressure. Water pressure must be 20-80 psi (137.9 -
551.5 kPA).
Ice machine is not level. Level the ice machine.
Incoming water supply is shut off. Open the water service valve.
Water float valve stuck open or leaking. Remove the water float valve and clean it.
The condenser is dirty. Clean the condenser.
High air temperature around ice machine. Air temperature must not exceed 1 10 °F
(43.3°C).
Inadequate clearance around the ice
machine.
Objects stacked around ice machine,
blocking airflow to condenser.
Provide adequate clearance.
Remove items blocking airflow.
Safety Limit Feature
In addition to the standard safety controls, your
Manitowoc ice machine features built-in safety limits that
will stop the ice machine if conditions arise which could
cause a major component failure.
Before calling for service, re-start the ice machine using
the following procedure:
1. Move the ON/OFF/ WASH switch to OFF and then
back to ON.
A. If the safety limit feature has stopped the ice
machine, it will restart after a short delay.
Proceed to step 2.
B. If the ice machine does not restart, see “Ice
machine does not operate” on the previous
page.
2. Allow the ice machine to run to determine if the
condition is reoccurring.
A. If the ice machine stops again, the condition has
reoccurred. Call for service.
B. If the ice machine continues to run, the condition
has corrected itself. Allow the ice machine to
continue running.
5-2 Part Number 000001774 07/08
Section 5 Before Calling for Service
SAFETY LIMITS
General
In addition to standard safety controls, the control board
has two built in safety limit controls which protect the ice
machine from major component failures.
Safety Limit #1: If the freeze time reaches 60 minutes,
the control board automatically initiates a harvest cycle.
If three consecutive 60-minute freeze cyc les oc cu r, the
ice machine stops.
Safety Limit #2: If the harvest time reaches 3.5
minutes, the control board automatically returns the ice
machine to the freeze cycle. If three consecutive 3.5
minute harvest cycles occur, the ice machine stops.
Safety Limit Stand-By Mode:
The first time a safety limit shut down occurs, the ice
machine turns off for 60 minutes (Stand-by Mode). The
ice machine will then automatically restart to see if the
problem reoccurs. During the Stand-By Mode the
harvest light will be flashing continuously and a safety
limit indication can be viewed. If the same safety limit is
reached a second time (the problem has reoccurred) the
ice machine will initiate a safety limit shut down and
remain off until it is manually restarted. During a safety
limit shut down the harvest light will be flashing
continuously.
Determining Which Safety Limit
Stopped The Ice Machine
When a safety limit condition causes the ice machine to
stop, the harvest light on the control board continually
flashes on and off. Use the following procedures to
determine which safety limit has stopped the ice
machine.
1. Move the toggle switch to OFF.
2. Move th e tog g le switc h ba ck to ON.
3. Watch the harvest light. It will flash one or two times,
corresponding to safety limits 1 and 2, to indicate
which safety limit stopped the ice machine.
After safety limit indication, the ice machine will restart
and run until a safety limit is exceeded again.
Safety Limit Notes
• A safety limit indication is completed before the water
pump starts. Water contacting the ice thickness
probe in the freeze cycle will cause the harvest light
to flash. Do not mistake a harvest light flashing in the
freeze cycle with a safety limit indication.
• A continuous run of 100 harvests automatically
erases the safety limit code.
• The control board will store and indicate only one
safety limit – the last one exceeded.
• If the toggle switch is moved to the OFF position and
then back to the ON position prior to reaching the
100-harvest point, the last safety limit exceeded will
be indicated.
• If the harvest light did not flash prior to the ice
machine restarting, then the ice machine di d not stop
because it exceeded a safety limit.
Part Number 000001774 07/08 5-3
Before Calling for Service Section 5
Safety Limit #1
Freeze time exceeds 60 minutes for 3 consecutive freeze cycles.
Possible Cause Check/Correct
Improper installation See “Installation Instructions” Section 2 of this manual
Water system Low water pressure (20 psi minimum.)
High water pressure (80 psi maximum.)
High water temperature (90°F/32.2°C maximum.)
Clogged water distribution tube
Dirty/defective water float valve
Loss of water from sump area
Defective water pump
Electrical system Ice thickness probe out of adjustment
Harvest cycle not initiated electrically
Compressor relay not energizing
Compressor electrically non-operational
Restricted condenser air flow High inlet air temperature (110°F/43.3°C maximum.)
Condenser discharge air recirculation
Dirty condenser filter
Dirty condenser fins
Defective fan cycling control
Defective fan motor
Refrigeration system Non-Manitowoc components
Improper refrigerant charge
Defective hot gas valve
Defective compressor
TXV starving or flooding (check insulation and bulb mounting)
Non-condensables in refrigeration system
Plugged or restricted high side refrigerant lines or component
Because there are many possible external problems,do not limit your diagnosis to only the items listed in
these charts.
5-4 Part Number 000001774 07/08
Section 5 Before Calling for Service
Safety Limit #2
Harvest time exceeds 3.5 minutes for 3 consecutive harvest cycles.
Possible Cause Check/Correct
Improper installation See “Installation Instructions” Section 2 of this manual
Water system Water area (evaporator) dirty
Water freezing behind evaporator
Low water pressure (20 psi minimum.)
Loss of water from sump area
Clogged water distribution tube
Dirty/defective water float valve
Defective water pump
Electrical system Ice thickness probe out of adjustment
Ice thickness probe dirty
Bin switch defective
Premature harvest
Refrigeration system Non-Manitowoc components
Improper refrigerant charge
Defective hot gas valve
TXV flooding (check insulation and bulb mounting)
Defective fan cycling control
Because there are many possible external problems,do not limit your diagnosis to only the items listed in
these charts.
Part Number 000001774 07/08 5-5
Before Calling for Service Section 5
THIS PA GE INTENTIO NALLY LEFT BLANK
5-6 Part Number 000001774 07/08
© 2007 Manitowoc
Continuing product improvements
may necessitate change of
specifications without notice.
Part Number 000001774 07/08
Manitowoc Foodservice Group
2110 South 26th Street, P.O. Box 1720
Manitowoc, WI 54221-1720, USA
Ph: 920-682-0161 Fax: 920-683-7589
Visit us online at: www.manitowocfsg.com
