U s e r ’ s M a n u a l
SG300BT Wireless Handheld Linear
Imager Bar code Scanner
Table of contents
Table of contents ..................................... 3
INTRODUCTION .......................................... 1
CHAPTER 1 PRODUCT SAFETY ............................. 2
1.1 Safety & Caution ......................... 2
1.2 FCC Warning .............................. 3
CHAPTER 2 GENERAL DESCRIPTION ........................ 4
2.1 Use of the SG300BT ....................... 4
CHAPTER 3 INSTALLATION OF THE SG300BT ................ 5
3.1 SG300BT Unpacking ........................ 5
3.2 SG300BT Cradle Installation .............. 6
3.3 SG300BT Setup Bluetooth Communication .... 7
3.3.1 Pairing .................................... 7
3.3.2 Setup SPP Master Mode Communication ........ 7
3.3.3 Setup SPP Slave Mode Communication ......... 9
3.3.4 Setup HID Slave Mode Communication ......... 9
3.3.5 Sleep Mode ................................. 9
3.3.6 Batch Mode ................................ 10
3.3.7 Out of Range .............................. 10
CHAPTER 4 CONFIGURING THE SG300BT ................... 11
4.1 Preface ................................. 11
4.1.1 Changing Scanner Settings with Programming
Codes .......................................... 11
4.1.2 Programming Flow Chart .................... 12
4.2 Set All Default Parameter ............... 13
4.3 General Process ......................... 13
4.3.1 Abort Configuration ...................... 14
4.3.2 Recall ................................... 14
4.3.3 Version Information ...................... 14
4.4 Cradle Interface Selection ............... 14
4.4.1 Interface ................................ 14
4.5 Bluetooth Scanner Setup .................. 15
4.5.1 Preface .................................. 15
4.5.2 Scanner Mode ............................. 15
4.5.3 *** Batch Mode (“***” means “Quick Setting
Label”, The function can be executed directly by
scanning barcode instead of doing the general
process.) ......................................... 16
4.5.4 Out of Range ............................. 16
4.5.5 Sleep Mode ............................... 16
4.5.6 Scanner Pincode Mode ...... 錯誤
4.5.7 Scanner Pincode Setup ..... 錯誤
4.6 Bluetooth Cradle Setup .... 錯誤
4.6.1 Cradle Pincode Mode ....... 錯誤
錯誤! 尚未定義書籤
錯誤錯誤
錯誤! 尚未定義書籤
錯誤錯誤
錯誤! 尚未定義書籤
錯誤錯誤
錯誤! 尚未定義書籤
錯誤錯誤
尚未定義書籤。。。。
尚未定義書籤尚未定義書籤
尚未定義書籤。。。。
尚未定義書籤尚未定義書籤
尚未定義書籤。。。。
尚未定義書籤尚未定義書籤
尚未定義書籤。。。。
尚未定義書籤尚未定義書籤
4.6.2 Cradle Pincode Setup ...... 錯誤
4.7 Scanner Operation ........................ 17
4.7.1 Reading Mode ............................. 17
4.7.2 Beeper Option ............................ 17
4.7.3 Reading Level ............................ 18
4.7.4 Accuracy Scan ............................ 18
4.7.5 Sensitivity of Continuous Reading ........ 18
4.7.6 Reverse Output Characters ................ 19
4.8 RS232 Mode Parameters .................... 20
4.8.1 Baud Rate ................................ 20
4.8.2 Data/Stop Bits ........................... 21
錯誤! 尚未定義書籤
錯誤錯誤
尚未定義書籤。。。。
尚未定義書籤尚未定義書籤
4.8.3 Parity .................................... 21
4.8.4 Handshaking ............................... 22
4.9 Keyboard Wedge Mode Parameters .......... 23
4.9.1 Terminal Type ............................. 23
4.9.2 Country/Language .......................... 24
4.9.3 Upper/Lower Case .......................... 25
4.9.4 Capslock Detection ........................ 25
4.9.5 Character by ALT Method ................... 26
4.9.6 Select Numerical Pad ...................... 26
4.9.7 Interscan Code Delay ...................... 26
4.10 Output Characters ....................... 27
4.10.1 Select Terminator ......................... 27
4.11 Code Type ............................... 28
4.11.1 Barcode Selection ......................... 28
4.12 UPC/EAN/JAN Parameters .................. 31
4.12.1 Reading Type .............................. 31
4.12.2 Supplemental Setup ........................ 33
4.12.3 Check Digit Transmission .................. 33
4.13 Code 39 Parameters ...................... 34
4.13.1 Type of Code .............................. 34
4.13.2 Check Digit Transmission .................. 34
4.13.3 Output Start/Stop Character ............... 35
4.13.4 Decode Asterisk ........................... 35
4.13.5 Setup Code Length ......................... 35
4.14 Code 128 Parameters ..................... 37
4.14.1 Reading Type .............................. 37
4.14.2 Check Digit Transmission .................. 38
4.14.3 Append FNC2 ............................... 38
4.14.4 Setup Code Length ........................ 38
4.15 Interleave 2 of 5 Parameters ............. 40
4.15.1 Check Digit Transmission ................. 40
4.15.2 Setup Number of Character ................ 40
4.15.3 Brazilian Banking Code ................... 40
4.15.4 Setup Code Length ........................ 41
4.16 Industrial 2 of 5 Parameters ............. 42
4.16.1 Reading Type ............................. 42
4.16.2 Check Digit Transmission ................. 42
4.16.3 Setup Code Length ........................ 43
4.17 Matrix 2 of 5 Parameters ................. 44
4.17.1 Check Digit Transmission ................. 44
4.17.2 Setup Code Length ........................ 45
4.18 CODABAR/NW7 Parameters ................... 46
4.18.1 Setup Start/Stop Characters upon
Transmission ...................................... 46
4.18.2 Transmission Type of Start/Stop .......... 46
4.18.3 Setup Code Length ........................ 47
4.19 Code 93 Parameters ....................... 49
4.19.1 Check Digit Transmission ................. 49
4.19.2 Setup Code Length ........................ 49
4.20 Code 11 Parameters ....................... 51
4.20.1 Check Digit Transmission ................. 51
4.20.2 Setup Code Length ........................ 51
4.21 MSI/Plessey Code Parameters .............. 53
4.21.1 Check Digit Transmission ................. 53
4.21.2 Setup Code Length ........................ 53
4.22 Telepen Parameters ....................... 55
4.22.1 Type of Code ............................. 55
4.22.2 Check Digit Transmission .................. 55
4.22.3 Setup Code Length ......................... 55
4.23 GS1 Databar Omnidirectional Parameters .. 57
4.23.1 Check Digit Transmission .................. 57
4.23.2 Application ID ............................ 57
4.23.3 Symbology ID .............................. 57
4.24 GS1 Databar Limited Parameters .......... 58
4.24.1 Check Digit Transmission .................. 58
4.24.2 Application ID ............................ 58
4.24.3 Symbology ID .............................. 58
4.25 GS1 Databar Expanded Parameters ......... 59
4.25.1 Symbology ID .............................. 59
CHAPTER 5 MISCELLANEOUS PARAMETERS .................. 60
5.1 Bar Code ID ............................. 60
5.1.1 Default Barcode ID ........................ 60
5.1.2 User Define Code ID ....................... 61
5.2 Preamble and Postamble Insertion ........ 63
5.2.1 Setup Insertion ........................... 63
5.2.2 Insertion Set Number ...................... 64
5.2.3 Code Type for Insertion ................... 65
5.2.4 Position to Be Inserted ................... 67
5.2.5 Characters to Be Inserted ................. 67
5.3 Character Deletion ...................... 67
5.3.1 Deletion Set Number ....................... 69
5.3.2 Code Type for Deletion .................... 69
5.3.3 Position to Be Deleted .................... 71
5.3.4 Number of Characters to Be Deleted ........ 71
APPENDIXES ............................................ 72
A. Decimal Value Table ...................... 72
B. ASCII Value Table ......................... 73
C. ASCII Table .............................. 74
D. Function Key Table ....................... 80
E. Technical Specifications ................. 81
F. Scan Map ................................. 83
G. LED Indicator Status ..................... 84
H. Test Symbologies ......................... 85
Quick Configuration ........................... 87
INTRODUCTION
SG300BT
designed specifically for retail market. To the brand
new series of SG300BT, we add on more user-friendly
functions with detachable interface cable that makes it
easier to be operated by the customers.
Speaking of the performance, this scanner supports
middle to long range mode.SG300BT which supports the
reading depth up to 50 centimeters, and the scan speed
is up to 500 scans per second.
In short, SG300BT is absolutely a high performance guntype scanner which provides the customer with the most
cost-effective solution in the market. It is perfectly
suitable and definitely the best choice for any
retailers using POS environment.
The SG300BT is available in various interface types,
RS232, Keyboard Wedge, USB HID or Virtual comport
interface, so there is always a solution to connect the
SG300BT to your POS system.
is a gun-type barcode scanner which is
1
CHAPTER 1 PRODUCT SAFETY
1.1 Safety & Caution
1. Please read the following safety statement carefully.
2. Please preserve this user’s manual for reference
sometime.
3. Before cleaning the SG300BT, the users must cut off
all AC power. Do not use liquid or spray type of
detersive to clean the SG300BT. Please use dampish
cotton cloth to clean the SG300BT.
4. The outlet must set nearby the SG300BT for connecting
power easily.
5. Keep the SG300BT dry to avoid short circuit.
6. During installation you must fix the equipment at
solid table to avoid damage caused by falling.
7. Before inserting power please ensure the voltage is
healthy to the equipment.
8. For safety please tie wire well and don’t put
anything on the wire.
9. If you don’t use this equipment for long time, please
cut off the power to avoid damage from surge power.
10. Don’t spray any liquid on this scanner because it may
cause a fire or short circuit.
11. Please do not open the equipment. For safety only the
qualified serviceman can open the equipment.
12. If there are the following situations please contact
the qualified serviceman to check this equipment.
(a) The damage of wire or pin of power supply.
(b) Some Liquid infiltrate into the equipment.
(c) The equipment has been exposed to wet
environment.
(d) The equipment can’t work well.
(e) The equipment has any obvious damage, making the
SG300BT working abnormally.
13. Don’t store the SG300BT at the temperature lower than
-20°C (-4°F) or higher than +70°C (158°F) to avoid
any damage.
2
1.2 FCC Warning
This equipment complies with the requirements in Part
15 of FCC.
Any operation must comply with the conditions below:
(a) The equipment will not cause any severe interference.
(b) The equipment can avoid any interference from
environment.
Statement:
This product is classified as B class product.
In environment this product may cause some
interference. In this situation the user may
do something to avoid interference.
3
CHAPTER 2 GENERAL DESCRIPTION
2.1 Use of the SG300BT
The SG300BT is very ergonomic and modern designed and
very user friendly. It can be connected to your POS or
Host system trough a RS232, Keyboard Wedge or USB cable.
To read a bar code, simply press the red trigger button
and aim the beam to the bar code. It needs to position
the beam to fall across all bars in the 1D barcodes. You
will hear one beep and the green LED indicator will light
on after scan successfully.
The programming of the SG300BT is very easy. You can
setup the SG300BT by scan all necessary programming codes
that meet applications. Thanks to the powerful decoding
software, the SG300BT can decode all major 1D codes.
4
CHAPTER 3 INSTALLATION OF THE SG300BT
3.1 SG300BT Unpacking
Unpack the SG300BT as follows:
1. Take the SG300BT and its accessories out of the box.
2. Remove the packing material.
3. Check the packing list to make sure you have received
all of the items ordered.
Shipment Package:
a. SG300BT Linear Barcode Scanner
b. Bluetooth Cradle
c. Communication Cable(RS-232,keyboard wedge or USB)
d. Power Adaptor
e. Product Compact Disc
4. Visually inspect the SG300BT and accessories for any
evidence of physical damage.
5. If anything is missing or appears to be damaged,
immediately contact your dealer.
ATTENTION
Store the packing material and boxes: it should
be used whenever the SG300BT is transported for
service.
3.2 SG300BT Cradle Installation
To setup your SG300BT scanner with Bluetooth technology,
please follow the steps.
1. Connect the supplied communication cable at the
bottom side of the cradle.
2. Connect the other side of the communication cable
to the right connector of your POS or HOST system.
3. Plug the external power supply into the power jack
on the bottom of the cradle.
4. Plug the power supply into the AC outlet.
5. Turn on your POS or HOST system.
6
3.3 SG300BT Setup Bluetooth Communication
3.3.1
Pairing refers to when a SG300BT scanner has been linked
or paired to a specific cradle by scanning that cradle’s
Bluetooth MAC address code. This Bluetooth MAC address
code is unique for each cradle. This address code is
located on the bottom side of the cradle. The pairing of
a SG300BT scanner to a cradle is one to one. Only one
SG300BT scanner can be paired to a cradle at any point in
time.
3.3.2
To setup the communication between the SG300BT scanner
and the cradle, follow the steps:
1. The SG300BT scanner must scan “SPP Master Mode”
2. Scan the Bluetooth MAC address code located on the
3. When the Bluetooth MAC was successfully scanned,
4. Wait approximately five seconds, for completing the
Pairing
Setup SPP Master Mode Communication
barcode to set the SG300BT scanner in Master mode.
bottom of the cradle.
scanner will initiate with 3 short beep sounds. Blue
LED will blink followed by a long beep sound.
connection process. Blue LED will slow flash on
scanner for connecting the cradle.
5. If successful, the blue LED on the cradle will be on.
6. If the connections failed, the blue LED on scanner
will be off, and the cradle indicators blinking blue
LED.
7
ATTENTION
The SG300BT scanner must be charged for a
minimum of 8 hours before the scanner can be
placed in full operation for the first time.
The scanner LED will indicate in red when the
scanner is charged.
After the battery is full, the green LED on
scanner will be on. The charge green LED will
be off when the scanner leaving from cradle.
If the battery power of the SG300BT is too low,
the SG300BT will indicate red LED and beeper
warning.
It is important to know that the SG300BT scanner will
only communicate with the cradle whose unique Bluetooth
MAC address was last scanned.
If a cradle is paired with the SG300BT scanner, another
SG300BT scanner can’t be paired with that cradle until
the original connection is interrupted.
If you pair a second SG300BT scanner to an in-use cradle,
the cradle’s connection to the first SG300BT scanner will
be interrupted and the connection will be re-established
with the second SG300BT scanner.
8
3.3.3
To setup the communication between the SG300BT scanner
and Bluetooth SPP profile application device, follow the
steps.
1. The SG300BT scanner must scan “SPP Slave Mode”
2. When control the Bluetooth device to search the
3. When SG300BT scanner is successful connected, the
3.3.4
To setup the communication between the SG300BT scanner
and Bluetooth HID profile application device, follow the
steps.
1. The SG300BT scanner must scan “HID Slave Mode”
2. When control the Bluetooth device to search the
3. When SG300BT scanner is successful connected,
Setup SPP Slave Mode Communication
barcode, to set the SG300BT scanner in Slave mode.
scanner, enter pin code (default 00:00:00) to setup
comport.
scanner Blue LED will also blink followed by a long
beep sound. Blue LED will slow flash to finish the
setup.
Setup HID Slave Mode Communication
barcode, to set the SG300BT scanner in HID Slave
mode.
scanner, enter pin code to setup pair. You can scan
number barcode on Appendix B.”ASCII VALUE TABLE”
number 0~9 to setup.
scanner Blue LED will also blink followed by a long
beep sound. Blue LED will slow flash to finish the
setup.
3.3.5
The SG300BT scanner enters sleep mode to save battery
energy, when the SG300BT scanner is used for 1 minute or
10 minute time. During sleep mode all the functions and
connection will be halted. After press the red trigger
button the scanner will wake up and reconnect the
communication with the cradle or Bluetooth device.
Sleep Mode
9
3.3.6
This batch mode is enabled when you have scanned “Batch
Mode on”. The scanned data is stored in the memory of the
SG300BT scanner instead of being transmitted. You can
delete the last scanned bar code data by scanning “Delete
Last Data” bar code. This function is disabled when you
scan “Batch Mode OFF”.
When scan bar code “Batch Data Output”, the stored
scanned data will be immediately transmitted to the host.
When scan barcode “Batch Data Clear”, all stored scanned
data will be erased from memory.
The capacity of this memory depends on the scanned data.
The memory size is approximately 30,000 sets of EAN13 bar
code type.
3.3.7
When “Out of Range” function is enabled, and the scanner
is working at out of transmission range, the scanned data
will be stored to out-of-range memory. Memory size is
approximately 25,000 sets of EAN13 bar code type.
The all stored data will send back to device when the
link is reconnected, and the all data store in out-ofrange memory will be cleared.
Batch Mode
Out of Range
10
CHAPTER 4 CONFIGURING THE SG300BT
4.1 Preface
How to configure the SG300BT?
The barcode programming feature gives the possibility to
change the SG300BT scanner settings with programming
labels.
4.1.1
Changing Scanner Settings with
Programming Codes
You can setup your SG300BT by scan all necessary
programming codes that meet applications.
In order to change the scanner settings please follow the
sequence below:
1. Power up the scanner.
2. Open the scanner programming mode by scanning
“Start Configuration”.
3. Change scanner settings by scanning any of the
programming code that meet applications.
4. Close the scanner programming mode by scanning
“End Configuration”.
5. Save configuration by scanning “Save Parameters”.
An Example:
For changing the Baud rate to 38400 the following codes
must be scanned successively:
Start ConfigurationBaud Rate 38400End configuration
Save Parameters
After reading a valid programming code the scanner, will
give three high beep and the green LED indicator will
light on.
11
By scanning “Set All Default” label, the settings will go
back to the factory default settings.
4.1.2
Programming Flow Chart
Abort
Configuration
Start
Configuration
Interface
Selection
Communication
Parameters
Bar codes
Parameters
Misc. Parameters
etc.
End
Configuration
Recall
Parameters
Set all Default
Save
Parameters
12
4.2 Set All Default Parameter
By scanning “Set All Default” label, the all parameters
will go back to the factory default settings for scanner
and cradle.
After reading a valid programming code the scanner will
give a three high beep and the Green LED indicator will
light on.
Set all the parameters to the
factory default settings
4.3 General Process
1
Power up the Scanner
2
Scan the Start Configuration bar
code
Scan the bar code for the desired feature.
3
4
Scan End of Configuration bar code
5
Scan Save Parameters bar code
13
4.3.1
Terminate current programming
status.
4.3.2
Replace the current parameters
by the parameters saved last time
4.3.3
Display the Scanner version
information and date code
Display the Cradle version
information and date code
Display the Scanner Bluetooth
MAC Address
Abort Configuration
Recall
Version Information
Display the Cradle Bluetooth
MAC Address
4.4 CRADLE Interface Selection
4.4.1
Keyboard Mode
Interface
14
RS232 Mode
<USB HID Mode>
USB Virtual Comport Mode
4.5 Bluetooth Scanner Setup
4.5.1
How to configure the Bluetooth function:
The barcode programming feature gives the possibility to
change the SG300BT scanner settings with programming
labels.
4.5.2
BT Parameter set default
SPP Master Mode
SPP Slave Mode
HID Slave Mode
Preface
Scanner Mode
15
4.5.3
Batch Mode ON
<Batch Mode OFF>
***Batch Data Output
***Batch Data Clear
***Delete Last Data
*** Batch Mode
Label”, The function can be executed directly
by scanning barcode instead of doing the
general process.)
(“***” means “Quick Setting
4.5.4
<Out of Range Enable>
Out of Range Disable
4.5.5
Sleep Mode On 1 minute
Out of Range
Sleep Mode
16
Sleep Mode On 10 minute
<Sleep Mode OFF>
4.6 Scanner Operation
4.6.1
<Good Read OFF>
Trigger ON/OFF
Continuous/Trigger OFF
Flash
Auto Sence
4.6.2
<High>
Reading Mode
Beeper Option
Medium
17
Low
Off
4.6.3
Bar Equals High
<Bar Equals Low>
4.6.4
< Require 1 good decoding for a
good scan>
Require 2 consecutive decoding of
the same bar code data for a good
scan
Require 3 consecutive decoding of
the same bar code data for a good
scan
Require 4 consecutive decoding of
the same bar code data for a good
scan
Reading Level
Accuracy Scan
4.6.5
This feature is working under Reading Continuous Mode.
Sensitivity of Continuous Reading
18
<Fast>
Slow
4.6.6
Following code sequences represent the length of time
before a barcode can be rescanned at continuous and flash
reading mode. The value can be defined from 1-50 and they
represent 100ms to 5 seconds in 100ms interval. Default
value is 3(0.3 second).
To setup same code Delay reading interval:
1. Scan the “Begin” label
2. Go the Decimal Value Tables in Appendix B, Scan
label(s),that represents the same code delay reading
interval. They are ranged from 1-50.One step is
represented 0.1 second. So the interval is from 0.1 to 5
seconds.
3. Scan the “Complete” label
Repeat the steps 1-3 to set time out of same symbol
1. Begin
2. Decimal Value (1-50)(Appendix A)
Same Code Delay Reading Interval
3.Complete
19
4.6.7
Example: 012345 543210
Enable
<Disable>
Reverse Output Characters
4.7 RS232 Mode Parameters
4.7.1
1200
2400
4800
Baud Rate
<9600>
19200
38400
57600
20
t to set the parity bit
Select to set the parity bit
o set the parity bit
4.7.2
The number of data/stop bits transmitted for each
character
7 Data Bits
< 8 Data Bits >
< 1 Stop Bits >
2 Stop Bits
4.7.3
A Parity bit is an extra data bit used to check data
transmission errors.
Data/Stop Bits
Parity
<None>
Even – Selec
either 1 or 0 to ensure the number
of 1.
Odd – Select to set the parity bit
either a 1 or 0 to ensure the
number of 1.
Mark –
always 1.
Space– Select t
always 0.
21
4.7.4
Handshaking
RTS/CTS ON – Output a Request to
Send (RTS) signal and wait for a
Clear to Send (CTS) signal before
transmitting data
<RTS/CTS OFF>
ACK/NAK ON – After transmitting
data, wait for host to send an ACK
or a NAK response. If ACK is
received, then complete the data
transmission. If NAK is received,
re-send the last set of data and
wait for ACK/NAK again.
<ACK/NAK OFF>
XON/XOFF ON – After transmitting
data, wait for host to send an XON
or a XOFF response. If XON is
received, then complete the data
transmission. If XOFF is received,
stop the transmission.
<XON/XOFF OFF>
22
4.8 Keyboard Wedge Mode Parameters
4.8.1
<IBM PC/AT,PS/2> - Includes IBM
PS/2 and compatible models 50, 55,
60, 80
IBM PC/XT
IBM PS/2 25, 30
IBM 5550
IBM 102 Key
IBM 122 Key (1)
IBM 122 Key (2)
Terminal Type
NEC 9800
Apple Desktop Bus(ADB)
23
4.8.2
Country/Language
<US English>
UK English
Italian
Spanish
French
German
Swedish
Switzerland
Hungarian
Japanese
Belgium
24
Portuguese
Denmark
Netherlands
Turkey
4.8.3
<No Change>
Enable Lower Case – Transmit all
data as lower case
Enable Upper Case – Transmit all
data as upper case
Enable
<Disable>
Upper/Lower Case
4.8.4
Capslock Detection
25
4.8.5
ALT Method Enable
<ALT Method Disable>
Numerical Pad ON
<Numerical Pad OFF>
4.8.7
<No Delay>
Character by ALT Method
4.8.6
Select Numerical Pad
Interscan Code Delay
5 ms
10 ms
25 ms
50 ms
26
100 ms
200 ms
300 ms
4.9 Output Characters
4.9.1
<CR+LF>– The scanner transmits a
carriage return and a line feed
after each scan
CR Suffix – The scanner transmits a
carriage return after each scan
LF Suffix – The scanner transmits a
line feed after each scan
Space
Tab
STX-ETX – RS232 only
None
Select Terminator
27
4.10 Code Type
4.10.1
If “All Bar Code ON” is selected, the scanner could read
all types of bar code. If “Disable” is selected for a
certain bar code type, the scanner could not read the
particular bar code. The symbol of “<>” means default
setting.
All Bar Codes ON
<UPC-A ON>
UPC-A OFF
<UPC-E ON>
UPC-E OFF
Barcode Selection
<EAN-13 / JAN-13 ON>
EAN-13 / JAN-13 OFF
<EAN-8 / JAN-8 ON>
EAN-8 / JAN-8 OFF
28
<CODE 39 ON>
CODE 39 OFF
Code32 / Italian Pharmacy ON
<Code32 / Italian Pharmacy OFF>
<Code 128 ON>
Code 128 OFF
<Interleave 2 of 5 ON>
Interleave 2 of 5 OFF
<Codabar/NW7 ON>
Codabar/NW7 OFF
Industrial 2 of 5 ON
<Industrial 2 of 5 OFF>
29
Matrix 2 of 5 ON
<Matrix 2 of 5 OFF>
CODE 93 ON
<CODE 93 OFF>
CODE 11 ON
<CODE 11 OFF>
MSI/PLESSEY ON
<MSI/PLESSEY OFF>
Telepen ON
<Telepen OFF>
China Postage ON
<China Postage OFF>
30
GS1 DataBar Omnidirectional ON
<GS1 DataBar Omnidirectional OFF>
GS1 DataBar Expanded ON
<GS1 DataBar Expanded OFF>
GS1 DataBar Limited ON
<GS1 DataBar Limited OFF>
4.11 UPC/EAN/JAN Parameters
4.11.1
UPC-A=EAN-13 ON
Add 0 before UPC-A to make it 13
digits.
<UPC-A = EAN-13 OFF>
ISBN Enable
<ISBN Disable>
Reading Type
31
ISSN Enable
<ISSN Disable>
Decode with Supplement
<Auto Discriminate Supplement>
Expand UPC-E Enable
<Expand UPC-E Disable>
EAN8=EAN13 Enable
<EAN8=EAN13 Disable>
GTIN Format Enable
<GTIN Format Disable>
32
4.11.2
<Not Transmit>
2 Digit Supplemental
5 Digit Supplemental
2 & 5 Digit Supplemental
4.11.3
<UPC-A Check Digit Transmission ON>
UPC-A Check Digit Transmission OFF
Supplemental Setup
Check Digit Transmission
<UPC-E Check Digit Transmission ON>
UPC-E Check Digit Transmission OFF
<EAN-8 Check Digit Transmission ON>
EAN-8 Check Digit Transmission OFF
33
<EAN-13 Check Digit Transmission
ON>
EAN-13 Check Digit Transmission OFF
<ISSN Check Digit Transmission ON>
ISSN Check Digit Transmission OFF
4.12 Code 39 Parameters
4.12.1
<Standard Code 39>
Full ASCII Code 39
Type of Code
<Italian Pharmacy/Code 32 Off>
Italian Pharmacy/Code 32 ON
4.12.2
<Do Not Calculate Check Digit>
Check Digit Transmission
34
Calculate Check Digit and Transmit
Calculate Check Digit and Not
Transmit
4.12.3
Enable
<Disable>
4.12.4
Enable
<Disable>
Output Start/Stop Character
Decode Asterisk
4.12.5
To set the fixed length: (2 sets available)
1. Scan the “Begin” programming code of the desired
set.
2. Go to the Decimal Value Table in Appendix A. Scan
programming codes that represent the length to be
read.
3. Scan the “Complete” programming code of the desired
set.
Repeat the steps 1 – 3 to set additional code length.
Setup Code Length
35
<Variable>
Fixed Length 1st Set
1st Set Begin
Decimal Value See Appendix A
1st Set Complete
Fixed Length 2nd Set
2nd Set Begin
Decimal Value See Appendix A
2nd Set Complete
Minimum Length
Minimum Length Begin
36
Decimal Value See Appendix A
Minimum Length Complete
4.13 Code 128 Parameters
4.13.1
UCC/EAN-128 Enable
<UCC/EAN-128 Disable>
<Enable ‘]C1’ Code Format>
Disable ‘]C1’ Code Format
<Enable Code128 Group Separators
(GS)>
Reading Type
Disable Code128 Group Separators
(GS)
37
4.13.2
Do Not Calculate Check Digit
Calculate Check Digit and Transmit
<Calculate Check Digit and Not
Transmit>
4.13.3
ON
<OFF>
Check Digit Transmission
Append FNC2
4.13.4
To set the fixed length: (2 sets available)
1. Scan the “Begin” programming code of the desired
set
2. Go to the Decimal Value Table in Appendix A. Scan
programming codes that represent the length to be
read.
3. Scan the “Complete” programming code of the desired
set.
Repeat the steps 1 – 3 to set additional length.
<Variable>
Setup Code Length
38
Fixed Length 1st Set
1st Set Begin
Decimal Value See Appendix A
1st Set Complete
Fixed Length 2nd Set
2nd Set Begin
Decimal Value See Appendix A
2nd Set Complete
Minimum Length
Minimum Length Begin
Decimal Value See Appendix A
Minimum Length Complete
39
4.14 Interleave 2 of 5 Parameters
4.14.1
<Do Not Calculate Check Digit>
Calculate Check Digit and Transmit
Calculate Check Digit and Not
Transmit
4.14.2
<Even>
Odd
Check Digit Transmission
Setup Number of Character
4.14.3
Enable
<Disable>
Brazilian Banking Code
40
4.14.4
To set the fixed length: (2 sets available)
1. Scan the “Begin” programming code of the desired
set
2. Go to the Decimal Value Table in Appendix A. Scan
programming codes that represent the length to be
read.
3. Scan the “Complete” programming code of the desired
set.
Repeat the steps 1 – 3 to set additional length.
<Variable>
Fixed Length 1st Set
1st Set Begin
Decimal Value See Appendix A
Setup Code Length
1st Set Complete
Fixed Length 2nd Set
2nd Set Begin
Decimal Value See Appendix A
41
2nd Set Complete
Minimum Length
Minimum Length Begin
Decimal Value See Appendix A
Minimum Length Complete
4.15 Industrial 2 of 5 Parameters
4.15.1
IATA25 Enable
Reading Type
<IATA25 Disable>
4.15.2
<Do Not Calculate Check Digit>
Calculate Check Digit and Transmit
Check Digit Transmission
42
Calculate Check Digit and Not
Transmit
4.15.3
Setup Code Length
To set the fixed length: (2 sets available)
1. Scan the “Begin” programming code of the desired
set
2. Go to the Decimal Value Table in Appendix A. Scan
programming codes that represent the length to be
read.
3. Scan the “Complete” programming code of the desired
set.
Repeat the steps 1 – 3 to set additional length.
<Variable>
Fixed Length 1st Set
1st Set Begin
Decimal Value See Appendix A
1st Set Complete
Fixed Length 2nd Set
nd
2
Set Begin
43
Decimal Value See Appendix A
2nd Set Complete
Minimum Length
Minimum Length Begin
Decimal Value See Appendix A
Minimum Length Complete
4.16 Matrix 2 of 5 Parameters
4.16.1
<Do Not Calculate Check Digit>
Check Digit Transmission
Calculate Check Digit and Transmit
Calculate Check Digit and Not
Transmit
44
4.16.2
To set the fixed length: (2 sets available)
1. Scan the “Begin” programming code of the desired
set
2. Go to the Decimal Value Table in Appendix A. Scan
programming codes that represent the length to be
read.
3. Scan the “Complete” programming code of the desired
set.
Repeat the steps 1 – 3 to set additional length.
<Variable>
Fixed Length 1st Set
1st Set Begin
Decimal Value See Appendix A
Setup Code Length
1st Set Complete
Fixed Length 2nd Set
2nd Set Begin
Decimal Value See Appendix A
45
2nd Set Complete
Minimum Length
Minimum Length Begin
Decimal Value See Appendix A
Minimum Length Complete
4.17 CODABAR/NW7 Parameters
4.17.1
Setup Start/Stop Characters upon
Transmission
ON
<OFF>
4.17.2
A/B/C/D <Start>
A/B/C/D <Stop>
Transmission Type of Start/Stop
46
A Start
A Stop
B Start
B Stop
C Start
C Stop
D Start
D Stop
4.17.3
To set the fixed length: (2 sets available)
1. Scan the “Begin” programming code of the desired
set
2. Go to the Decimal Value Table in Appendix A. Scan
programming codes that represent the length to be
read.
3. Scan the “Complete” programming code of the desired
set.
Repeat the steps 1 – 3 to set additional length.
Setup Code Length
47
<Variable>
Fixed Length 1st Set
1st Set Begin
Decimal Value See Appendix A
1st Set Complete
Fixed Length 2nd Set
2nd Set Begin
Decimal Value See Appendix A
2nd Set Complete
Minimum Length
Minimum Length Begin
48
Decimal Value See Appendix A
Minimum Length Complete
4.18 Code 93 Parameters
4.18.1
Do Not Calculate Check Digit
<Calculate Check 2 Digit and Not
Transmit>
4.18.2
To set the fixed length: (2 sets available)
1. Scan the “Begin” programming code of the desired
set
2. Go to the Decimal Value Table in Appendix A. Scan
programming codes that represent the length to be
read.
3. Scan the “Complete” programming code of the desired
set.
Repeat the steps 1 – 3 to set additional length.
Check Digit Transmission
Setup Code Length
<Variable>
Fixed Length 1st Set
49
1st Set Begin
Decimal Value See Appendix A
1st Set Complete
Fixed Length 2nd Set
2nd Set Begin
Decimal Value See Appendix A
2nd Set Complete
Minimum Length
Minimum Length Begin
Decimal Value See Appendix A
Minimum Length Complete
50
4.19 Code 11 Parameters
4.19.1
<Do Not Calculate Check Digit>
Calculate Check 1 Digit and
Transmit
Calculate Check 1 Digit and Not
Transmit
Calculate Check 2 Digit and
Transmit
Calculate Check 2 Digit and Not
Transmit
4.19.2
Check Digit Transmission
Setup Code Length
To set the fixed length: (2 sets available)
1. Scan the “Begin” programming code of the desired
set
2. Go to the Decimal Value Table in Appendix A. Scan
programming codes that represent the length to be
read.
3. Scan the “Complete” programming code of the desired
set.
Repeat the steps 1 – 3 to set additional length.
<Variable>
51
Fixed Length 1st Set
1st Set Begin
Decimal Value See Appendix A
1st Set Complete
Fixed Length 2nd Set
2nd Set Begin
Decimal Value See Appendix A
2nd Set Complete
Minimum Length
Minimum Length Begin
Decimal Value See Appendix A
Minimum Length Complete
52
4.20 MSI/Plessey Code Parameters
4.20.1
<Do Not Calculate Check Digit>
Calculate Check Digit and Transmit
Calculate Check Digit and Not
Transmit
4.20.2
To set the fixed length: (2 sets available)
1. Scan the “Begin” programming code of the desired
set
2. Go to the Decimal Value Table in Appendix A. Scan
programming codes that represent the length to be
read.
3. Scan the “Complete” programming code of the desired
set.
Repeat the steps 1 – 3 to set additional length.
Check Digit Transmission
Setup Code Length
<Variable>
Fixed Length 1st Set
1st Set Begin
53
Decimal Value See Appendix A
1st Set Complete
Fixed Length 2nd Set
2nd Set Begin
Decimal Value See Appendix A
2nd Set Complete
Minimum Length
Minimum Length Begin
Decimal Value See Appendix A
Minimum Length Complete
54
4.21 Telepen Parameters
4.21.1
<Telepen ASCII ON>
Telepen Numeric
4.21.2
Do Not Calculate Check Digit
Calculate Check Digit and Transmit
<Calculate Check Digit and Not
Transmit>
Type of Code
Check Digit Transmission
4.21.3
To set the fixed length: (2 sets available)
1. Scan the “Begin” programming code of the desired
set
2. Go to the Decimal Value Table in Appendix A. Scan
programming codes that represent the length to be
read.
3. Scan the “Complete” programming code of the desired
set.
Repeat the steps 1 – 3 to set additional length.
Setup Code Length
55
<Variable>
Fixed Length 1st Set
1st Set Begin
Decimal Value See Appendix A
1st Set Complete
Fixed Length 2nd Set
2nd Set Begin
Decimal Value See Appendix A
2nd Set Complete
Minimum Length
Minimum Length Begin
Decimal Value See Appendix A
Minimum Length Complete
56
4.22 GS1 Databar Omnidirectional Parameters
4.22.1
<Calculate Check Digit and
Transmit>
Calculate Check Digit and Not
Transmit
4.22.2
<Transmit Application ID>
Add 01 before GS1 Databar
Omnidirectional
Do Not Transmit Application ID
4.22.3
Check Digit Transmission
Application ID
Symbology ID
Transmit Symbology ID
Add ]e0 before GS1 Databar
Omnidirectional.
<Do Not Transmit Symbology ID>
57
4.23 GS1 Databar Limited Parameters
4.23.1
<Calculate Check Digit and
Transmit>
Calculate Check Digit and Not
Transmit
4.23.2
<Transmit Application ID>
Add 01 before GS1 Databar Limited.
Don’t Transmit Application ID
4.23.3
Check Digit Transmission
Application ID
Symbology ID
Transmit Symbology ID
Add ]e0 before GS1 Databar Limited.
<Don’t Transmit Symbology ID>
58
4.24 GS1 Databar Expanded Parameters
4.24.1
Transmit Symbology ID
Add ]e0 before GS1 Databar
Expanded.
<Don’t Transmit Symbology ID>
Symbology ID
59
CHAPTER 5 MISCELLANEOUS PARAMETERS
5.1 Bar Code ID
5.1.1
With this function on, a leading character will be added
to the output string while scanning code. User may refer
to the following table to know what kind of barcode has
being scanned.
Code Type ID Code Type ID
Interleave 2 of 5 G Industrial 2 of 5 H
Matrix 2 of 5 I Codabar/NW7 J
China Postage M MSI/Plessey N
Default Barcode ID
UPC-A A UPC-E B
EAN-8 C EAN-13 D
Code 39 E Code 128 F
Code 93 K Code 11 L
Telepen T GS1 DataBar Omni. U
GS1 DataBar Lim. V GS1 DataBar Exp. W
60
Bar Code ID ON
<Bar Code ID OFF>
Default – Return from User Define
to Default
5.1.2
To set the code ID
1. Scan the symbologies programming code.
2. Go to the ASCII Table in Appendix B. Scan
Note: User define code ID will override default value.
Program will not check the conflict. It is possible to
have more than two symbologies which have same code ID.
UPC-A
User Define Code ID
programming codes that represent the desired ID.
UPC-E
EAN-13/JAN-13
EAN-8/JAN-8
CODE 39
61
CODE 128
Codabar/NW7
Interleave 2 of 5
Industrial 2 of 5
Matrix 2 of 5
CODE 93
CODE 11
China Postage
MSI/PLESSEY
Telepen
GS1 DataBar Omnidirectional
62
GS1 DataBar Expanded
GS1 DataBar Limited
5.2 Preamble and Postamble Insertion
5.2.1
To set the insertion of the output characters:
1. Scan the programming code of the desired set.
2. Scan the programming code of the desired symbology
3. Go to the Decimal Value Table in Appendix A. Scan
4. Scan the “Complete” programming code of “Character
5. Go to the ASCII Table in Appendix C, Scan
6. Scan the “Complete” programming code of “Characters
Setup Insertion
programming codes that represent the desired
position to be inserted (1: the first digit, 99:
the last digit).
Position to Be Inserted”.
programming codes that represent the desired
characters to be inserted.
to Be Inserted”.
Repeat the steps 1 – 6 to set additional insertion.
Example: Insert $ as Preamble for Code UPC-A.
Start Configuration
st
1
Set
63
Code UPC-A
1st Digit
Complete
$
Complete
End Configuration
Save Parameters
1st Set
2nd Set
3rd Set
4th Set
5.2.2
Insertion Set Number
64
5th Set
6th Set
5.2.3
UPC-A
UPC-E
EAN-13/JAN-13
EAN-8/JAN-8
Code Type for Insertion
CODE 39
CODE 128
Codabar/NW7
Interleave 2 of 5
65
Industrial 2 of 5
Matrix 2 of 5
CODE 93
CODE 11
China Postage
MSI/PLESSEY
Telepen
GS1 DataBar Omnidirectional
GS1 DataBar Expanded
GS1 DataBar Limited
All Codes
66
None
5.2.4
Decimal Value See Appendix A
Complete
5.2.5
ASCII Table See Appendix B and C
Complete
Position to Be Inserted
Characters to Be Inserted
5.3 Character Deletion
To setup the deletion of output characters:
1. Scan the programming code of the desired set.
2. Scan the programming code of the desired symbology.
3. Go to the Decimal Value Table in Appendix A. Scan
programming codes that represent the desired
position to be deleted.
4. Scan the “Complete” programming code of “Character
Position to Be Deleted”.
5. Go to the Decimal Value Table in Appendix A. Scan
programming codes that represent the number of
characters to be deleted.
6. Scan the “Complete” programming code of “Number of
Characters to Be Deleted”.
67
Repeat the steps 1 – 6 to set additional deletion.
Example: Delete first 3 digits Code EAN-13.
Start Configuration
1st Set
Code EAN-13
1st Digit
– Delete from the 1st digit
Complete
3
– Delete 3 digits
Complete
End Configuration
Save Parameters
68
1st Set
2nd Set
3rd Set
4th Set
5th Set
6th Set
5.3.1
Deletion Set Number
5.3.2
UPC-A
UPC-E
EAN-13/JAN-13
EAN-8/JAN-8
Code Type for Deletion
69
CODE 39
CODE 128
Codabar/NW7
Interleave 2 of 5
Industrial 2 of 5
Matrix 2 of 5
CODE 93
CODE 11
China Postage
MSI/PLESSEY
Telepen
70
GS1 DataBar Omnidirectional
GS1 DataBar Expanded
GS1 DataBar Limited
All Codes
None
5.3.3
Decimal Value See Appendix A
Position to Be Deleted
Complete
5.3.4
Decimal Value See Appendix A
Complete
Number of Characters to Be Deleted
71
APPENDIXES
A. Decimal Value Table
72
B. ASCII Value Table
0
2
4
6
8
1
3
5
7
9
Enter
73
C. ASCII Table
NULL
STX
EOT
ACK
BS
LF
FF
SOH
ETX
ENQ
BEL
HT
VT
CR
SO
DLE
DC2
SI
DC1
DC3
74
DC4
SYN
CAN
SUB
FS
RS
SPACE
NAK
ETB
EM
ESC
GS
US
!
″
$
&
(
#
%
'
)
75
*
+
,
Comma
.
Period
0
Number
Zero
2
4
6
8
-
Minus
/
1
Number One
3
5
7
9
:
<
Less Than
>
Greater Than
;
=
?
76
@
B
D
F
H
J
L
A
C
E
G
I
Letter I
K
M
N
P
O
Letter O
Q
R
T
S
U
77
V
X
Z
\
^
`
b
W
Y
[
]
_
Underscore
a
c
d
f
h
j
e
g
i
k
78
l
n
p
r
t
v
x
m
o
q
s
u
w
y
z
|
Vertical
{
}
Slash
~
DEL
79
D. Function Key Table
F1
F2
F3
F4
F5
F6
Insert
F7
F8
F9
F10
F11
F12
Delete
Home
Page Up
Left
End
Page Down
Right
80
Up
Down
E. Technical Specifications
Physical Characteristics: Scanner
Scanner Weight Approx. 215g (include batteries)
Charger Weight Approx. 135g (include adaptor)
Material ABS Plastic
Dimension 82.9 mm(L) x 75.0 mm(W) x 171.3 mm(H)
Physical Characteristics: Bluetooth Cradle
Weight Approx 150 g
Material ABS Plastic
Connector RJ 45C 10Pins
Dimension 130.6 mm(L) x 112.2 mm(W) x 84.6 mm(H)
Operational
Light Source Visible Red light 632nm LED
Sensor Linear CCD Sensor
Processor Type ARM Cortex™-M3, 32-bit
Operating Freq. 8 MHz
Scan Speed Smart detection up to maximum 500
scans/sec
Depth of Field Up to 500mm@20mil/0.5mm, PCS90%, Code39
Print Contrast
Ratio
Minimum
Resolution
Reading Angle
Pitch Angle
Skew Angle
PCS45%@5mil/0.127mm
4mil/0.1mm@PCS90%,Code39
Test Conditions:PCS90%
Code 39, 10mil/0.25mm
±5°~60° (±5°)
±5°~60° (±5°)
81
Error / Alarm
Bluetooth Communication
Bluetooth Module
RF Output Power
Transmission Range
Electrical Characteristics
Scanner:
Voltage Battery Li-Ion 3.7V/2600 mAh
Charge Time 5.5 hours
Reads per Charge 20,000 Times
Scanner LED Indicator
Good read Green
Red
Blue
Power Consumption
Power On 400mA
Stand by 270mA
Operation 290mA
Sleep 36mA
Cradle:
Voltage 5 VDC@2A / Input AC 110-240V
Cradle LED Indicator
Good read Green
Transmitted Success Blue
Power Consumption
Power On 95mA
Stand by 55mA
Operation 70mA
Radio Characteristics
Frequency Band 2.402GHz ~ 2.480GHz
Modulation Method GFSK for 1Mbps
Bluetooth V2.0 Standard
Class 1 (under 20dBm)
Up to 80m(266.67ft) line of sight
82
Environmental
Operating Temp. 0°C to 50°C (32°F to 122°F)
Storage Temp. -20°C to 70°C (-4°F to 158°F)
Relative Humidity 20 to 95% non-condensing
Ambient Light
Immunity
Ingress Protection Sealed with IP42 rating protection
Scanner Drop
Specification
Sealing IP42
Regulatory of Compliance
FCC
CE
10,000 LUX max @ Direct sun Light
Functions normally after repeated
1.2m(4ft)drops to concrete surface
F. Scan Map
Typical Reading Distance
83
Bi per 10
G. LED Indicator Status
Status
Scanner Indicators
LED Buzzer
Green Light and
Power On
Buzzer
Be-Be-Be* 2 loops
Simultaneously
Battery No Power Red Blink 3 times Bi-Bi-Bi
Battery Low Power
Alarm
Battery Very Low
Power Alarm
Red Blink 1 time Be per 20 seconds
Red Blink 4 times
Bi-Bi-Bi-
seconds
Memory Full Red Blink 2 times Be-Be
Transmitted
Green Blink 1 time Be
Succeed
Transmitted Fail Red Blink 2 times Be-Be
Green Light and
Configure Setup
Buzzer
Bi-Bi-Bi
Simultaneously
BT Connecting
Build
BT Connecting
Succeed
BT Connected
Blue Blink 2 times
per second
N/A
Blue light 2 second Up-Tone
Blue Blink per
Second
N/A
BT Disconnect Blue Light 2 Second Down-Tone
Charging Red Light Continue N/A
Full Charge
Enter Sleep N/A Down-Tone
Link Quality not
Good
Remarks: ‘Be’ means Long Beep, ‘Bi’ means short beep.
Green Light
Continue
N/A
Green/Red Blink Di Do
84
Status
Cradle Indicators
LED Buzzer
Power On Red Light Continue N/A
Transmitted
Succeed
BT Connected
BT Disconnect
Green Blink 1 Time N/A
Blue Blink
Continue
Blue Blink 2 Times
per Second
N/A
N/A
H. Test Symbologies
Scan one or more of these bar codes to test symbologies
you enabled.
1D Symbology
Codabar/NW7
CODE 11
CODE 39
CODE 128
CODE 93
EAN 8
1234 5670
85
EAN 13
1 234567 890128
ISBN
Interleave 2 of 5
ISSN
GS1 DataBar Omnidirectional GS1 DataBar Expanded
GS1 Databar Limited
MSI / Plessey
Matrix 2 of 5
Industrial 2 of 5
UPC A
UPC E
Telepen
12345 67890
0
5
123456
0
5
China Postage
86
QUICK CONFIGURATION
Start Configuration
(Select your Settings)
End Configuration
Save Parameters
Set All Defaults
Recall Stored Parameters
Abort Configuration
Version Information
87
Loading...
