SuperSpeed USB-C to HDMI/VGA 4-in-1 Docking
Converter
USB 3.1 C Male to HDMI or VGA Converter, Two-Port USB 3.0 Hub and SD Card
Reader, Aluminum, Black
Part No.: 152631
Easily connect a USB Type-C device to an HDMI or VGA display, USB peripherals and SD
memory card.
The Manhattan SuperSpeed USB-C to HDMI/VGA 4-in-1 Docking Converter establishes a
fast, simple and convenient link between newer USB type-C equipped media sources
(computers, tablets, Smartphones, etc.) and existing HDMI/VGA displays (monitors,
projectors, etc.), in either mirror- or extended-display mode. Create a mini-workstation by
adding any USB 3.0 peripheral such as a mouse, keyboard, hub, external memory device
and more with the integrated USB 3.0 ports and SD card slot.
The Manhattan SuperSpeed USB-C to HDMI/VGA 4-in-1 Docking Converter is easy and
quick to install. No complicated configuration or setup is required to enhance the
functionality of your type-C device. Its all-in-one design achieves a compact, integrated
solution that eliminates unnecessary cables, tangles and clutter to keep installations and
work spaces neat and orderly.
Features:
Multi-function docking converter connects a USB Type-C port to an HDMI or VGA
display, two-port USB 3.0 hub and SD Card Reader
Offers Ultra-High-Definition (UHD) 4K@30Hz video and audio with an HDMI
connection or HD 1080p video with a VGA connection
Mirror or Extended display modes support video resolutions up to 1080p@60Hz or
3840x2160 at 30 Hz (4K) Full UHD
Provides a USB 3.0 two-port hub to connect mice, keyboards or portable memory
devices (and more) or to charge and sync a portable electronic device
USB-A ports support SuperSpeed (5 Gbps) data transmission and charging up to 7.5
All names of products or services mentioned herein are trademarks or registered trademarks of their respective owners. Distribution and
For more information on Manhattan products, consult your local dealer or visit www.manhattan-products.com.
reproduction of this document, and use and disclosure of the contents herein, are prohibited unless specifically authorized.
W (5 V / 1.5 A); BC1.2 compliant
Easy access to media and content management with read/write/copy SD slot;
supports automatic card detection and data transfer speeds up to 480 Mbps
USB-C supports 5 Gbps data transmission
Angled, aluminum housing makes this durable converter the perfect desktop or travel
companion
Compatible with all USB Type-C, DP Alt mode supported desktops, notebooks and
tablets including Apple MacBook, Chromebook Pixel and more
Compliant with DisplayPort 1.2 Alternate Mode (DP Altmode)
Plug and Play
Fully shielded to reduce EMI and other interference sources
Molded PVC boot and strain relief
Three-Year Warranty
Specifications:
Standards and Certifications
• USB 3.1
• HDMI
• HDCP 1.4
• CE
• FCC
• RoHS2
• WEEE
General
• Video Resolutions: 640 x 480, 800 x 600, 1024 x 768, 1920 x 1200, 3840 x 2160p at 30
Hz, 4K
• USB A ports: 5 Gbps
• Supported flash cards: SD / SDHC / SDXC / EXTREME SD / EXTREME II SD /
EXTREME III SD / ULTRA SD / ULTRA II SD / ULTRA II SD P PLUS / SD-ULTRA-X /
ULTRA SPEED SD / SD PRO / SD ELITE PRO / HS SD / MMC / MMC 4.0 / HS MMC / HS
RS MMC / RS MMC / RS MMC 4.0 / MMC Mobile
• Transfer speed: up to 480 Mbps
• 24-AWG cable gauge
• Bus powered
• Mylar and aluminum shielding
• Withstanding voltage: 300 VDC
• Insulation resistance: 10 MOhm
• Conductive resistance: 5 Ohm
Connections
• One USB Type-C 24-pin, male
• One HDMI 19-pin, female
• One VGA 15-pin female
• Two USB Type-A 4-pin, female
• One SD memory slot
