Mandolyn Electronic Technology TRC650 User Manual

Download

Table of Contents

Features . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3

Installation Guide . . . . . . . . . . . . . . . . . . . . 4

Diagrams / Operation . . . . . . . . . . . . . . . . 15

LCD Display Diagrams . . . . . . . . . . . . . . . . . 16

Set ºC or ºF . . . . . . . . . . . . . . . . . . . . . . . . . 20

Set Clock . . . . . . . . . . . . . . . . . . . . . . . . . . . 22

Program Heating / Cooling . . . . . . . . . . . . . 23

Humidifier control . . . . . . . . . . . . . . . . . . . . . 26

Fan control / ventilation . . . . . . . . . . . . . . . . 27

System Mode . . . . . . . . . . . . . . . . . . . . . . . . 27

Temporary Override . . . . . . . . . . . . . . . . . . . 28

Hold Function . . . . . . . . . . . . . . . . . . . . . . . . 28

Pre-comfort Recovery . . . . . . . . . . . . . . . . . 29

Usage Monitor . . . . . . . . . . . . . . . . . . . . . . . 29

Filter Change . . . . . . . . . . . . . . . . . . . . . . . . 29

Remote sensor / transmitter . . . . . . . . . . . 30

Optional Settings . . . . . . . . . . . . . . . . . . . . 33

Changing Batteries. . . . . . . . . . . . . . . . . . . . 39

Backlight . . . . . . . . . . . . . . . . . . . . . . . . . . . . 39

Memory backup . . . . . . . . . . . . . . . . . . . . . . 40

Reset. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 40

Specifications . . . . . . . . . . . . . . . . . . . . . . . . 41

Troubleshooting . . . . . . . . . . . . . . . . . . . . . . 41

FEATURES

Therm ostat

Compa tible with central heating /air co ndit ioning system s for autom atic tem perature control

Autom atic chan ge-over for HE ATING/COOLING prog rams

Conne cts t o humidifier for autom atic humidit y control

Displays temperature (°C / °F)

Remote tem perature control via remote sens or / transm itter

Extra-l arge LCD display with backli ght

isplay (12 or 24 hou r format)

Clock d

Temperature can be set in half de grees

Autom atic, m anual and f an modes

Selectable cycle rates for f urna ce ON/OFF i ntervals Usage monit or

Filter chan ge rem inde r

Compa tible with milli volt & 24V hea ting system s

Include s mounting hardw are and 3 “AA” batteri es

Remote Sen sor / Tran smitter

Displays c dit

Adjusts tem perature with rem ote RF trans mission

Temperature can be set in half de grees

Include s mounting hardw are and 2 “AAA” batteri es

urren t tem perature and humi y

Installation

Guide

Installation Guide

Introduction

This thermostat can replace common residential thermostats. It is designed for use with most central heating and air conditioning systems that use low voltage (24V or millivolt) system control. Please see compatibility chart on the next page for more details.

Warning

We recommend consulting a licenced HVAC contractor to ensure the correct installation of the thermostat. The only way to guarantee proper wiring is to have a qualified professional on site.

* NOT COMPATIBLE WITH ANY HIGH VOLTAGE 120/240 VOLT CIRCUIT.

Compatibility

Generally, equipment with low voltage (24V or millivolt) system control is compatible with heating/cooling programmable thermostats.

System Type

Gas - Standing Pilot Gas - Electronic Ignition Gas - Fire Boiler Gas - Millivolt System Oil - Fire Boiler Oil - Fire Furnace

Electric Furnace Electric Air Conditioner Baseboard Electric Heater (120/240V)

Heat Pump/Single-Stage Heat Pump/Multi-Stage

Compatible with Thermostat

Yes Yes

Some models

Yes

Some models

Yes Yes Yes

* NOT COMPATIBLE WITH ANY HIGH VOLTAGE 120/240 VOLT CIRCUIT

Installation

The following tools may be required for installation:

( ) Screwdriver

Masking Tape

(To wrap the exposed wires temporarily and to label the disconnected wires)

Wire Stripper/Cutter

(If necessary, to strip the wires)

Power drill with a 3/16” bit

( If necessary, to drill holes on the wall )

Level

(If necessary, to level the thermostat)

Batteries (included)

Choosing a location for the thermostat

Thermostat should be mounted:

Approximately 5’ (1.5 m) from floor.

Near or in a frequently used room, preferably on an inside partitioning wall.

On a section of wall without pipes or duct-work.

Thermostat should NOT be mounted:

Near a window, on an outside wall, or next to a door leading outside.

Exposed to direct light or heat from a lamp, sun, fireplace, or other

temperature-radiating objects which may cause false readings.

Near or in direct airflow from heat registers and air conditioners.

Near concealed pipes and chimneys.

In areas with poor air circulation, such as behind a door or in an alcove.

Replacing the Old Thermostat

Test the system to make sure that your heating and cooling systems are working properly before

(

installation If either does not work, contact a heating/air conditioning service person to fix the

)

problem before installation

TURN OFF POWER to system at the furnace, or at the fuse/circuit breaker panel

Carefully unpack your new thermostat and mounting plate; save package of screws,

instructions and receipt

Wiring

NOTE: WIRING COLORS ARE NOT ALWAYS STANDARDIZED, SO IT IS VERY IMPORTANT TO LABEL ALL WIRES ACCORDING THE LETTER DESIGNATION ON YOUR OLD THERMOSTAT

(The wires are usually designated 'W', 'Y', 'G', 'RH', 'RC', 'W' ,'B', ‘O' or humidistat wires

Disconnect wires from old thermostat or sub-base

As you disconnect each wire, label it with the old terminal designation

Take care not to let the wires fall back into the wall or let the ends of the wires touch one another

If there is an extra wire that is not connected to your old thermostat, then you won't need to connect

it to the new thermostat

)

2-WIRE HEATING

(OPTIONAL)

JUMPER

3-WIRE HEATING

Wiring Key

Regular Wiring

G - Fan output Y - Cool output H1 / H2 - Humidifier control Rc - Common for Cooling and Fan Rh - Common for Heating W - Heat output

2 Wire Heating

Rc / Rh - Common (Rc and Rh jumper is optional)

Rc / Rh - Common (Rc and Rh must be connected with jumper)

3 Wire Heating

Wiring Diagrams

4-WIRE HEATING/COOLING

5-WIRE HEATING/COOLING

Wiring Key

Regular Wiring

G - Fan output Y - Cool output H1 / H2 - Humidifier control Rc - Common for Cooling and Fan Rh - Common for Heating W - Heat output

4 Wire Heating Rc / Rh - Common (Rc and Rh must be connected with jumper)

2 separate transformers (Heat / Cool) Rc / Rh - Common (wire separately, jumper must not be installed)

5 Wire Heating

Humidifier Wiring

To wire a humidifier, the 2 wires connecting the original humidistat need to be

connected to the 2 terminals marked 'H1' and 'H2' on the thermostat.

The original humidistat should be removed or set to 'OFF' position.

Note: The 2 humidifier control terminals 'H1' and 'H2' are electrically isolated from the Heat/Cool terminals.

Note: H1 and H2 terminals are non polarized and there is no function difference between H1 and H2.

Humidistat should be OFF or disconnected

Connecting the Wires to the Terminals

Connect the previously labeled wires to the corresponding terminals, matching the designations. Use a screwdriver to loosen the terminal, wrap the wires around the terminal then tighten to securely fasten the wires. Make sure the wires do not touch or short-circuit with other terminals.

Depending on your heating/cooling equipment, you may need to connect between 2 to 7 wires

If you have two ‘R’ wires, then connect each wire to its corresponding terminal and remove the

JUMPER between the RC and RH terminals

If you are unsure of the connections please consult a certified HVAC contractor for the correct

installation of your thermostat.

Mounting the back cover of the thermostat

The back cover should be mounted vertically with the terminals on the top

Thread the existing wiring through the big center hole from the back and set the back cover

vertically on the wall

Select two appropriate mounting holes and mark the locations with a pencil (If necessary, use a

level to make sure the thermostat is positioned straight)

Remove the back cover from the wall and drill two 3/16 inch holes in the marked screw positions

Insert the wall anchors into the holes completely (If necessary, use a hammer to tap-in lightly)

Mount the back cover to the wall using the two screws (Make sure the metal terminals are on the top)

Attach the thermostat body to the back cover (that is already mounted on the wall)

by carefully aligning the two pieces and pressing firmly until they snap together

First attach to backplate to the wall, then press the faceplate into place

Diagrams and

Operation

Thermostat LCD display

WEEKDAY

CLOCK SYMBOL

flashes when the

lithium battery is low

SET CLOCK

THERMOSTAT

LOW BATTERY

HOLD FUNCTION

HUMIDITY

VENTILATION MODES

OPERATION MODES

HEAT/COOL RUNNING

FAN

CLOCK

PROGRAM NUMBER

USAGE MONITOR

SET/PROGRAM TEMPERATURE

OVERRIDE INDICATION

REMOTE SENSOR LOW BATTERY

SET OPTIONS FILTER CHANGE INDICATION REMOTE SENSOR

TEMPERATURE CONTROL

REMOTE TEMPERATURE

THERMOSTAT TEMPERATURE,

REMOTE TEMPERATURE

AND HUMIDITY

Remote Sensor / Transmitter LCD display

TEMPERATURE

TREND

PROGRAM

NUMBER

LOW BATTERY

INDICATOR

OVERRIDE WARMER

OR COOLER

CURRENT REMOTE TEMPERATURE

REMOTE THERMOSTAT CONTROL IS ACTIVE

REMOTE TEMPERATURE TRANSMISSION ICON

TEMPERATURE OVERRIDE (+ or - 3 degrees)

BUTTON LOCATION

THERMOSTAT

DOWN

REMOTE CONTROLLER / SENSOR

ON/OFF

Temperature

Control

INSERT BATTERIES - REMOTE CONTROL / SENSOR

Press and hold the button on the top of the unit, then gently but firmly remove the back cover (DO NOT pry open with a screwdriver)

Insert 2 “AAA” batteries

IMPORTANT - (°C o r °F)

CELSIUS DEFAULT: Si nc e Ce ls iu s (° C) i s th e de fa ul t mo de n o ac ti on i s re qu ir ed t o use the thermostat in this mode. However, if y ou w is h to c ho os e Fahrenheit (°F) you must do so before you begin using the thermostat. If you proceed to set the clock and program settings with the default Celsius(°C)and THEN change to Fahrenheit (°F); the clock, programs and all system settings will be deleted. To change the temperature scale see the “Optional Settings” section.

REMOVE BACK COVER / INSERT BATTERIES / PRESS RESET / ACCES S BUTTON S

** **

To prepare for wiring, gently pull off the back cover, DO NOT pry open

RESET (R) key

Lithium battery for memory backup

Insert 3 “AA” batteries

Flip cover

open

to access

the buttons

Thermostat LCD display

Check Pro grams

Press PROGRAM at any time to scroll

throu gh and che ck all other prog rams

The current prog ram setti ng is displayed

in the middle of the LC D screen

Press PROGRAM r epea tedly to r eturn to the

norm al display

Local/Remote Tempera ture

The l ocal/r emote tem perature is displayed

on the bottom of the LC D screen

Relati ve Humidity

Relative humidi ty is displayed on the bottom

on the LCD screen

It is shown alt ernatively with current (room) temperature (The display alterna tes: 2 seco nds humidity display , 4 seco nds tempe rature display)

Current program period

Program temperature

Current (room) temperature display, alternating with the relative humidity display

Set clock

- Press SET to beg in setti ng the time (the TIM E sym bol wil l appear)

Press AHEAD or BA CK to set t he current time

Press SET again (the DAY sym bol will ap pear)

Use AH EAD or BA CK to set the current day

Press SET again to exit

Set 12 or 24 ho ur format

12 hou r mod e is t he defau lt, so no acti on is r equired to use the the rmostat in this mode

To select 12 or 24 hour form at:

- Press SET for 3 seco nds to enter the optiona l setting mod e

- Press UP/DOWN t o select 12 or 24 hou r format

- Press SET to con firm

- Press SET repea tedly to exit the optiona l setting mod e

Program Heating and Cooling

This thermostat is equipped with 5+1+1 DAY PROGRAMMING. Program Monday-Friday as a group + Saturday + Sunday, with 4 settings per day. This thermostat is pre-programmed for your convenience or you can set your own programs as desired.

P1: MORNING P2: DAY

P3: EVENING

P4: NIGHT

DEFAULT PRE -PROG RAMME D TIME AN D TEMPERAT URE SETTING S

PER IOD

MORNING DAY EVENING NIGHT

(SEE OPTI ONAL SETTING S SECTION)

In the morning period, when you wake up, you may prefer a warmer temperature.

The daytime period is an energy-savings mode for the time you are away from home. The settings can be adjusted to minimize energy consumption.

The evening period is for when you return home and want the house at a comfortable temperature, typically set warmer during the winter and cooler during the summer.

The night period is the time when you are usually asleep. You may choose to lower the temperature for energy savings and comfort.

P TIM E

P1 P2 P3 P4

6:00am 8:00am 5:00pm 10:00pm

HEAT S ETPOINT COO L SETP OIN T

o o

69.0 F (2 0.5 C)

o o

63.5 F (1 7.5 C)

o o

70.0 F (2 1.0 C)

o o

62.5 F (1 7.0 C)

77.0 F (2 5.0 C)

84.0 F (2 9.0 C)

77.0 F (2 5.0 C)

79.0 F (2 6.0 C)

o o

Note: Program periods can

be set to different or the same temperatures.

For example: Period 1, 2, or 3 can all be set to (22 ) if you are home all day and want the temperature to stay warm, but at night it

be C

can set cooler. (17 )

Heating Program

Press MODE until the HEAT symbol appears

Press PROGRAM once (P1 and the PROGRAM symbol will appear on the display)

Press PROGRAM again to scroll through the day(s) you wish to program (Monday - Friday mode will display first, then Saturday, then Sunday)

Press AHEAD or BACK to scroll to the desired start time for Period 1 (displayed as P1) Press UP or DOWN to set the desired temperature for P1

5 6

After setting the desired time and temperature for P1, press PROGRAM again to advance to P2

Repeat the steps above to set the times and temperatures for P2, P3 and P4

After Sunday P4 is set, press PROGRAM again to exit the programming mode

- The heating and cooling programs are linked, so same program start times (chosen for either heating or cooling) will automatically be applied to the other

- The HEAT temperature setting will always be at least 3°C (6°F) lower than the COOL temperature setting, to prevent a mistake or overlap in temperature settings

- The PROGRAM button can also be used at any time to review all the set programs

- Tip: Press and hold down the AHEAD/BACK or UP/DOWN buttons to scroll through the numbers quickly

- Program times can be set in increments of 10 minutes

- Temperature can be set in increments of 0.5°

- The temperature range for heating is 5°C to 32°C (41°F to 89°F)

Cooling Program

Setting the cooling program is nearly identical to setting the heating program

Press MODE until the COOL symbol appears

Press PROGRAM once (P1 and the PROGRAM symbol will appear on the display)

Press PROGRAM again to scroll through the day(s) you wish to program (Monday - Friday mode will display first, then Saturday, then Sunday)

Press AHEAD or BACK to scroll to the desired start time for Period 1 (Displayed as P1)

Press UP or DOWN to set the desired temperature for P1

After setting the desired time and temperature for P1, press PROGRAM again to advance to P2

Repeat above steps to set the times and temperatures for P2, P3 and P4

After Sunday P4 is set, press PROGRAM again to exit the programming mode

- The heating and cooling programs are linked, so same program start times (chosen for either heating or cooling) will automatically be applied to the other

- The COOL temperature setting will always be at least 3°C (6°F) higher than the HEAT temperature setting, to prevent a mistake or overlap in temperature settings (For example, if the initial COOL program temperature was set at 24°C (75°F) and you decide to adjust the HEAT program temperature to 24°C (75°F), the thermostat will automatically push the COOL program temperature up to 27°C (81°F)

- The temperature range is 8°C to 35°C (48°F to 95°F) for cooling

Humidifier Control

Verify the humidifier is correctly wired to the thermostat. (see installation guide or contact an electrician)

1 2

Ensure the thermostat is in HEAT mode

Press PROGRAM until the HUMIDITY icon displays

Set the humidity level using the UP / DOWN buttons

Note:

- The humidifier will automatically turn on if the relative humidity is lower than the humidity setting

- Humidity is set in increments of 5%

- The humidity level can be set from 20% to 70%

- The humidifier setting only functions when thermostat is in HEAT mode

- Humidity is not pre-programmable, it must be set manually

- When the humidifier is on, the HUMIDITY symbol will appear

- To de-activate the humidifier, scroll DOWN to it’s lowest setting

Fan Control / Ventilation

For automatic control of the fan, press FAN until the AUTO symbol appears In cooling mode, the fan starts/stops with the cooling equipment In heating mode, the fan is controlled by the heating equipment There may be a few minutes of delay between the fan setting selection and the fan becoming activated

For the fan to run continuously, press FAN until the ON symbol appears

For the Automatic Ventilation feature - where the thermostat will turn the fan on periodically for better ventilation press FAN until the VENT symbol appears

System Mode: HEAT / COOL / OFF

Press MODE to toggle between the modes HEAT - The system is in HEAT mode and furnace or heating system is activated COOL - The system is in COOL mode and air conditioner or cooling system is activated OFF - If the thermostat is in the OFF mode, both the heating and cooling systems will be turned off, and all programs will be disabled

When the heating or cooling systems are ON, the following symbols will display: will flash when the heating system is running will flash when the cooling system is running

Temporary OVERRIDE

This function will change the temperature temporarily until the next program period starts

Press the UP / DOWN buttons to set the desired temperature

- The OVERRIDE icon will display, to indicate the OVERRIDE function is active

- If the system is in AUTO mode, only the currently active mode (heat or cool) setting will be changed

- The thermostat has an automatic delay function to protect the heating and cooling systems from irregular on/off sequences, so there may be a delay of several minutes before the override setting will activate the heating/cooling system

HOLD Function

This function will maintain a constant temperature until it is turned off by pressing HOLD again

Press the HOLD button

Press the UP / DOWN buttons to change the temperature

Press HOLD again to release the hold function

- The HOLD symbol will display when the HOLD function is activated

- The HEAT/COOL system mode cannot be changed while HOLD is on

- The HOLD function disables all program settings, and new temperature will then remain the same, until the HOLD button is pressed again

Pre-comfort Recovery

This thermostat is equipped with a ‘Pre-comfort Recovery’ system that will activate the heating or cooling in advance of the actual set program time, so that the room will be at the desired temperature at the start of the program time

When the thermostat is in ‘recovery’, the OVERRIDE symbol will be flashing

It is normal for the system to be activated earlier than the actual set program time (up to one hour)

The Pre-comfort Recovery can be disabled if desired. (See "Optional Settings”)

Usage Monitor

l The thermostat tracks the system "ON" time; the time the heating/cooling equipment is running

Press BACK once to view USAGE TODAY Press BACK again to view USAGE THIS WEEK

- USAGE TODAY automatically resets itself daily at midnight

- USAGE THIS WEEK automatically resets itself at midnight on Sunday

- A new week begins Monday morning

Filter Change

The FILTER CHANGE indicator will display on the LCD screen when the system "ON" time (HEAT, COOL

or FAN) has accumulated to approximately 500 hours. It is an indication that the filter should be changed at this time

To reset the FILTER CHANGE counter:

- Press and hold FAN for 3 seconds until the buzzer beeps, this will bring the counter back to zero

REMOTE SENSOR / TRANSMITTER

This thermostat is equipped with a remote sensor, which monitors the temperature in a remote location and can control the thermostat by sending a radio signal.

Controlling the thermostat with the remote sensor / transmitter: Note: If you wish to use the remote sensor make sure the RF option is set to RF1 (see optional settings)

The remote sensor is capable of doing three things:

l Transmitting the room temperature from a remote location to display on the thermostat LCD screen

l The thermostat will heat o cool your home based on the temperature transmitted by the remote instead

of the temperature of the thermostat.

l Overriding the current temperature setting to raise or lower the temperature up to 3°C ( )

F Fahrenheit

or 6 ° ( ).

Celsius

REMOTE SENSOR / TRANSMITTER

SYMBOLS:

- REMOTE TEMPERATURE CONTROL - REMOTE TEMPERATURE DISPLAY

THE LEARN PROCEDURE

The learn procedure initiates a radio signal connection between the transmitter and thermostat To begin:

Bring the the thermostat

l remote transmitter near to

thermostat s

l Press and hold the BACK button on the for 3 second

(until t remote temperature display begins to on the thermostat’s LCD screen)

he symbol flash

l elease the BACK button

l Press and hold the ON/OFF button o the remote transmitter

(The remote temperature control will flash on the remote’s LCD screen after 3 seconds)

LEARN d by the thermostat

l When the signal is receive , the thermostat will beep and you can

release the ON/OFF button on the remote transmitter

A second beep will sound within 30 seconds, to indicate that the temperature data has

been received (after the 2nd beep, the remote data should display on the thermostat LCD screen)

REMOTE SENSOR / TRANSMITTER

Viewing the temperature of the remote transmitter:

The local and remote temperatures display alternates every 8 seconds on the thermostat LCD screen. To view the remote transmitter temperature, press AHEAD on the thermostat. The temperature will be shown on the bottom pane and the Remote Temperature Display symbol (antenna) will appear indicating the temperature displayed is from the remote transmitter. If the bottom pane is already showing remote temperature (the Remote Temperature Display symbol already on), pressing AHEAD key will show the local temperature of the thermostat.

Controlling the thermostat based on the remote transmitter temperature (Heating or Cooling):

The thermostat can heat or cool your home based on the temperature transmitted by the remote, instead of the thermostat's own temperature. To begin, place the remote sensor in the part of the house you wish to use for temperature control. Press the ON/OFF button on the remote transmitter until the Remote Temperature Control symbol displays. The thermostat will now control the heating and cooling based on the temperature as sensed by the remote transmitter. (Note: If the local temperature on the thermostat and remote vary by more than 4 degrees, or either remote transmitter or thermostat battery is low, the remote function will be cancelled.)

Remote Override:

Although the remote cannot permanently change the thermostat's program settings, it can temporarily override the current program to F

the remote override value displayed as a plus or minus value on the LCD screen of the remote. It will also appear on the thermostat LCD screen, alternating with the temperature .

to change the temperature in half degree increments. The will be

regular set on the thermostat

raise or lower the set temperature by up to 3 °C or 6 ° . Press the UP or DOWN buttons on

OPTIONAL SETTINGS

The thermostat has a number of OPTIONS which the user can change. (*NOTE: Adjust these settings before programming the thermostat, because changing certain options will erase all programming) There are 9 OPTIONS. To begin, press SET for 3 seconds to enter the optional settings mode, then press UP or DOWN to select the VALUE. Once the correct value is displayed, press SET again to confirm the setting and to advance to next option. The optional settings are explained in detail on the next few pages.

OPTIONAL SETTINGS:

1) 12/24 - hour display format

2) CR - Cycle Rate setting (select cycle rate to match the heating equipment)

3) RE - Pre-comfort Recovery ON or OFF

4) BL - Backlight setting

5) RF - Remote Control ON or OFF

6) FN - Additional fan control settings for the humidifier and the HE/HG setting

7) SY - System (heat pump option)

8) PG - Default programs

9) C/F - (Celsius/Fahrenheit)

OPTIONAL SETTINGS

1) 12/24 hour display format

- Press and hold SET 3 seconds

- The SET OPTION symbol will appear and either 12hr or 24hr will appear

- Select your preference of 12hr or 24hr by pressing UP or DOWN

- Press SET to confirm the setting and to advance to the next option

2) CR - Cycle Rate setting (select cycle rate to match the heating equipment)

- Choose from Cr-0 to Cr-5 by pressing UP or DOWN (See Chart 1)

- Press SET to confirm the setting and to advance to the next option Note: The default setting is Cr-4 for g . Cr-0 is a fixed span operation (no cycle rate) for

as or oil forced air

heating and cooling. Choosing the correct cycle rate for your system promotes energy efficiency and a more stable temperature.

Cr-0 Cr-1

Hydronic heat, condensing gas furnaces

Cr-2 Cr-3

Commercial Unit Gas or oil forced air (default)

Cr-4 Cr-5

Electric Heat

Syst em Cycl es per hour

– –

+/- 0. 5 °C fixed span

+/- 0. 3 °C fixed span

2 3 5 7

Chart 1

OPTIONAL SETTINGS

3) RE- Pre-comfort Recovery ON or OFF

- Select the setting by pressing or RE1 = ON (default) RE0 = OFF

- Press SET to confirm the setting and to advance to the next option

4) BL - Backlight setting

- Select the setting by pressing or BL (default)

1 = ON (If the backlight is enabled, pressing any button will turn the backlight on for 8 seconds)

BL0 = OFF

- Press SET to confirm the setting and to advance to the next option .

5) RF - Remote Control ON of OFF

- Select the setting by pressing or RF (default)

1 = ON

0 = OFF (if OFF is selected all remote control features will be disabled)

- Press SET to confirm the setting and to advance to the next option

UP DOWN

OPTIONAL SETTINGS

6) FN - Additional fan control settings for the humidifier

- Press SET to advance to the next setting

- Select the setting by pressing or

- Press SET to confirm the setting and to advance to the next option

HE: Use this setting for electric furnaces. With this setting, the thermostat will turn the fan on immediately with the heating system. HG: Use this setting for gas or oil-fired furnaces. This setting allows the fan operation to be controlled by the heating system; not the thermostat. This is the correct setting for most systems.

UP DOWN

Add ition al fan co ntrol s ettin g for the h umidi fier:

Fn- 0

Fn- 1

Fn- 2 Fn- 3

HE/ HG

HG HE HG

Fan o perat ion for h umidi fier

(default) Humidifier on will not activate the FAN

Hum idifi er on wil l not act ivate t he FAN

Hum idifi er on wil l turn on FA N

7) SY - System (heat pump)

- Select the setting by pressing or

UP DOWN

SY0 = NON HEAT PUMP (default) recommended SY1 = HEAT PUMP (single-stage) not recommended with most systems SY2 = HEAT PUMP (multi-stage) not recommended

- Press SET to confirm the setting and to advance to the next option

OPTIONAL SETTINGS

8) Default

This thermostat offers 9 weekly heating / cooling programs built-in for your convenience. The first setting (PG1) is the main factory default which will auto-activate when you first install the thermostat. Note: If you do not wish to change your current program settings, selecting PG0 will maintain the existing program. (See chart 1 on the next page for a list of all program options)

9) C/F Selection

Since Celsius (°C) is the default mode, no action is required to use the thermostat in this mode To change the temperature scale display:

- Select the setting by pressing or C = Celsius (default) F = Fahrenheit

- Press SET to confirm the setting and to exit the optional settings mode

programs

UP DOWN

OPTIONAL SETTINGS

Chart 1. - Default Program Options

- Select the setting by pressing or to choose between 9 program selections PG1-PG9

Note: If you do not wish to change your current program settings, selecting PG0 will maintain the existing program.

UP DOWN

Changing Batteries

When the AA batteries are low and need to be replaced the low battery symbol will appear on the LCD screen and a beep will sound every hour. However, it is recommended that the batteries be replaced every year, even if the battery symbol does not appear.

To replace the batteries:

Select OFF to change the thermostat to OFF mode

Remove the thermostat from its mounting plate (back cover) carefully

Remove the old AA batteries and install new ones

Place the thermostat back into its original position

Note: If the batteries are low the backlight will not turn on and the remote control feature will not work. After changing the batteries, complete the LEARN PROCEDURE again to connect the thermostat and remote sensor / transmitter. (see the remote sensor/transmitter section)

Backlight

The backlight helps you to clearly see the thermostat display at night. However, frequent backlight use will reduce your battery life. To disable the backlight see the “Optional Settings” section.

Memory backup for the Programs and Thermostat Settings

In case of power outages, this thermostat has a memory backup powered by a lithium battery. The lithium battery will typically last for several years. Memory storage includes all set programs and thermostat settings. Do not remove the Lithium battery and the AA batteries at the same time, otherwise all memory and settings will be lost.

RESET

SOFT RESET - If the thermostat has an abnormal display, press the RESET (R) button located at the back of the thermostat. The programs and thermostat settings will remain stored in memory but the clock will have to be set again.

HARD RESET - To clear the permanent memory (including all stored programs and settings) or to change the temperature scale (°C or °F), a hard reset must be performed. Press and hold the HOLD button, and at the same time press and release the RESET (R) key located on the back of the thermostat. The LCD screen will blank out momentarily. When the display reappears, release the HOLD key. The thermostat will be back to its default settings.

Specifications:

Number of programs: 5+1+1 day programming, with 4 settings per day Temperature setting range: 5 – 35°C (41 – 95°F) Temperature display range: 0 – 55°C (34 – 99.5°F) Humidity setting range: 20 to 70% Humidity display range: 20 to 95% Battery: 3 x “AA” size batteries

TROUBLESHOOTING GUIDE

PROBLEM SOLUTION

LCD screen is blank.

Battery symbol ( ) is flashing.

Heat will not come on.

- Check if the batteries are installed correctly.

- Check if the batteries are fresh and of the correct type.

- Select RESET button on the back of the unit.

- This is an indication that the batteries are running low. Replace with fresh alkaline batteries. Note: We recommend replacing the batteries at least once a year even if the battery symbol is not flashing.

1) Check and ensure that the thermostat is set to the HEAT or AUTO mode.

2) Check and ensure that the set temperature is higher than the current (room) temperature.

3) You may have to wait up to 5 minutes before the heat will turn on. The thermostat has a built-in time delay to prevent undesirable on/off sequences.

4) After a 5-minute wait, the heat should now be on. Whenever the heating system is running, the symbol will be animated.

PROBLEM SOLUTION

Heat will not come on but the symbol is animated.

Air conditioning will not come on.

Air conditioning will not come on but the symbol is animated.

The thermostat turns the heating or cooling systems on before my programmed set times.

Heating system seems to cycle too often.

1) Check if the furnace switch and/or pilot flame is turned on, as it may have been turned off.

2) Allow several minutes for the heating system to heat up and the fan to activate. Most heaters will heat up the system for a short while before warm air can be ventilated by the fan. Also check that the HE/HG setting is set correctly. (see optional settings)

3) If the heat still does not come on, check the wiring installation again.

1) Check and ensure that the thermostat is set to the COOL or AUTO mode.

2) Check and ensure that the set temperature is lower than the current (room) temperature.

3) You may have to wait up to 5 minutes before the air conditioning will turn on. The thermostat has a built-in time delay to protect the air conditioner compressor from undesirable on/off sequences.

4) After a 5-minute wait, the air conditioning should now be on. Whenever the cooling system is running, the symbol will be animated.

1) Check if the air conditioning system’s main switch is turned on, as it may have been turned off.

2) Wait several minutes for the air conditioning system to activate. If the air conditioning still does not come on, check the wiring installation again.

This is normal if the Pre-comfort Recovery system is enabled. The Pre-comfort Recovery will activate the heating/cooling in advance of the actual programmed set time so that the room will be at the desired temperature at the start of the program time. See the “optional settings” section.

Check and ensure that you have selected a Cycle Rate that matches your particular heating system. If you find it still cycling too often, you may wish to try a slower cycle rate or disable the cycling. When disabled, the thermostat will operate at a fixed span of (plus or minus) ±0.5°C (±1.0°F). For example, if the programmed temperature is set at 20°C (68°F), the thermostat will turn the heat on if the current (room) temperature falls below 19.5°C (67°F) and turn the heat off when the current (room) temperature reaches 20.5°C (69°F). See the “optional settings” section.

PROBLEM SOLUTION

Thermostat is set on AUTO mode, but the thermostat does not seem to automatically change-over from HEAT to COOL or vice-versa.

While adjusting the program temperature or program times in the HEAT mode, you notice the changes affect the settings in the COOL mode; and/or vice-versa

Cannot change the thermostat scale from °C to °F or vice-versa.

The thermostat is not receiving a signal from the remote transmitter.

The clock symbol is flashing

The thermostat has a built-in safeguard time delay of 30 minutes to prevent undesirable change-over sequences from HEAT to COOL or COOL to HEAT. For example, if the thermostat was just running the cooling system, it will take at least 30 minutes before it changes to heating. You may override this manually by pressing MODE to change the operation to HEAT or COOL only.

The heating and cooling program times are linked, so same program start times (chosen for either heating or cooling) will automatically be applied to the other.

When you set the HEAT and COOL program temperatures fairly close to one another, the thermostat automatically restricts the two temperature settings from getting within 3°C (6°F) of one another. The COOL temperature setting will always be at least 3°C (6°F) higher than the HEAT temperature setting. For example, if the initial COOL program temperature was set at 24°C (75°F) and you decide to adjust the HEAT program temperature to 24°C (75°F), the thermostat will automatically push the COOL program temperature up to 27°C (81°F) to prevent overlapping.

Selecting the temperature scales is a one-time start-up process. After the first battery installation, you must HARD reset the thermostat and choose the desired display in °C or °F. Otherwise, you CANNOT change the temperature scale (°C or °F) later on unless you perform another HARD reset which will clear all the programs and thermostat settings. To perform a HARD reset and select °C or °F, first press and hold the HOLD, while at the same time press and release the RESET button on the back of the thermostat. The LCD screen will blank out momentarily. To select °F, select see the “optional settings” section.

Re-do the “Lean Procedure” to ensure an RF signal is being transmitted from the remote sensor to the thermostat. (See “Remote transmitter” section)

This indicates that the 3V (CR2025) lithium battery is low. This will not affect the normal operation of the thermostat, but it should be replaced to ensure memory backup is maintained. Replace the lithium battery with a screwdriver. (See diagrams for the location of the lithium battery)

FCC Statement

The statement required by 15.105 is as follows:

This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures:

- Reorient or relocate the receiving antenna.

- Increase the separation between the equipment and receiver.

- Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.

- Consult the dealer or an experienced radio/TV technician for help.

Statement required by 15.19 and RSS210

This device complies with Part 15 of the FCC Rules and with RSS-210 of Industry Canada. Operation is subject to the following two conditions:

(1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that

may cause undesired operation.

Manual Requirements according 15.21

NOTICE:

Changes or modifications made to th is e q uip me n t not expressly approved by UPM may void the FCC authorization to operate this equipment.

ICES - 003

The statement required by ICES - 003 is as follows:

NOTICE:

This Class B digital apparatus complies with Canadian ICES-003. Cet appareil numérique de la classe B est conforme à la norme NMB-003 du Canada.

Mandolyn Electronic Technology TRC650 User Manual

Specifications and Main Features

Frequently Asked Questions

User Manual
