Manatee r82 User Manual
manatee
© 2010 R82 A/S. All rights reserved.
The R82 logo and the bathing chair Manatee are registered trademarks of R82 A/S.
TM
11.2013 - rev.2
English manual
G
B
2
G
B
CONTENTS
Safety ................................................................................ 4
Warranty ............................................................................ 4
Maintenance ...................................................................... 5
Preparing for use ............................................................... 5
Back angling ...................................................................... 6
Leg support angling ........................................................... 6
Seat depth ......................................................................... 7
Seat height ........................................................................ 7
Seat angling....................................................................... 8
Head / sidesupport ............................................................ 8
Hip support ........................................................................ 9
Body support ..................................................................... 9
Pommel with strap ........................................................... 10
Straps for leg control ....................................................... 10
Dismounting and mounting the cover .............................. 11
Folding the chair ............................................................. 12
Frame .............................................................................. 13
Height adjustable Frame ................................................. 14
Wall fittings for frame ....................................................... 15
Product identification ....................................................... 16
Product identification ....................................................... 17
Measurements ................................................................. 18
Technical data..................................................................19
Producer .......................................................................... 19
Distributor ........................................................................ 19
Care and maintenance .................................................... 20
Troubleshooting ............................................................... 20
GB
3
G
B
MANATEE
Congratulations on your new Manatee bathing chair.
In choosing the Manatee, we are sure that you have got a bathing chair,
which will live up to any expectations one can have for a modern aid for
children. The Manatee is designed to be used in bathrooms, in which the
child can not ever be left alone.
The Manatee is a bathing chair for children between 1 and 11 years with
a lesser handicap. The Manatee is constructed to provide both caregivers
and users a wonderful bathing experience. The bathing chair is designed
to place the user in exactly the right sitting position. The depth of the seat
can be adjusted, allowing the bathing chair to "grow" with the child and
provide many years of use. The adjustments and accessories are logically
positioned, affording the caregiver proper working conditions.
This user manual is meant as a guide to assist the user in gaining the full
benefit of the many options offered by the Manatee. Therefore we recommend you to go through this manual before the Manatee is put into use.
GB
4
G
B
SAFETY
The Manatee has earned the CE-mark. This certifies that it meets all relevant European
safety requirements. The durability of this product is 5 years when it is used on a daily
basis. Hereafter the product must be renovated (by R82 personnel) to extend the lifetime.
Remove the CE-mark, when rebuilding the product or when using other than
original R82 spare parts.
Never leave your child unattended in this product. Ensure constant supervision
by an adult. Incorrect use of the product, may cause serious injury to the user.
Ensure that the belt is securely fixed to the product before every use.
The user must be removed from the product, before angling the chair legs.
We recommend to remove the pressure load from the users body and legs, before
angling the back and leg support. Put a gentle back pressure on the back and
leg support to remove the pressure load.
Check the temperature of the water before the Manatee and the child is placed
in the bath.
The enclosed belts and accessories can not be used as long-term supports but
may only be used as an extra help when positioning the user.
Secure the chair when any adjustments have been made. Then place the user
on to the Manatee.
Check on the cover, belts and accessories and make sure that the velcro fastens
securely.
WARRANTY
R82 offers a 2-year warranty against defects in workmanship and materials. The
warranty would be adversely affected if the customer’s responsibility of servicing
and/or daily maintenance is not carried out according to the guidelines and intervals
prescribed by the supplier and/or stated in the manual. For further information, we
refer to the R82 homepage/download. The warranty can only be sustained if the R82
product is in use in the same country where it was purchased and if the product can
be identied by the serial number. The warranty does not cover accidental damage, including damage caused by misuse or neglect. The warranty does not extend
to non-durable parts, which are subject to normal wear and tear and need periodic
replacement. The warranty is null and void if non-original R82 parts/accessories
are used, or if the product is repaired or altered by anyone other than an authorised
R82 representative or by trained personnel ofcially recognised by R82 for repair
and maintenance of R82 products. R82 reserves the right to inspect the product
being claimed for and the relevant documentation before agreeing to the warranty
claim, and to decide upon whether to replace or repair the defective product. It is the
customer’s responsibility to return the item being claimed for under warranty to the
address of purchase. The warranty is given by R82 or, subsequently, an R82 dealer.
GB
GB
5
A
B
C
G
B
PREPARING FOR
USE
We deliver the Manatee folded which means it takes up
as little space as possible during transport. Follow the
instructions below to prepare your bathing chair for use:
1) Press the release buttons (A) on both sides and fold
down the chair legs.
2) Press the release buttons (B) on both sides and fold
down the leg support.
3) Press the release buttons (C) on both sides and pull
up the back.
The Manatee is ready for use.
Please check that all release buttons mesh into
place after adjustment.
Never leave the user unattended in the Manatee.
The user must be removed from the product, before
angling the chair legs.
We recommend to remove the pressure load from
the users body and legs, before angling the back
and leg support. Put a gentle back pressure on the
back and leg support to remove the pressure load.
GB
MAINTENANCE
When the chair has been used in water containing
chlorine it has to be washed out with clean water
and dried with a cloth. Make sure that all water is
out of the frame.
Do not use any cleaning materials containing chlorine or methylated spirit.
All screws on the chair have to be checked regularly
to avoid unintended failures.
Adjustments which are not described in this manual,
must only be made by authorized R82 personnel.
GB
6
B
A
C
A
B
G
B
BACK ANGLING
The back on the Manatee angles individually.
Please follow the description below when angling the back:
1) Press the release buttons (A) in both sides.
2) Angle the back (B) into the required position.
3) Please check that both release buttons (A)
mesh into place after adjustment.
Further, the back also angles by pulling the strap
on the back of the chair.
Please take care not to get your fingers
caught between the rotary joint and the
back (C).
We recommend to remove the pressure
load from the users body and legs, before
angling the back and leg support. Put a
gentle back pressure on the back and leg
support to remove the pressure load.
Secure the chair when any adjustments
have been made. Then place the user into
the Manatee.
GB
LEG SUPPORT
ANGLING
The leg support on the Manatee angles individually. Please follow the description below when
angling the back:
1) Press the release buttons (A) on both sides.
2) Angle the leg support (B) into the required
position.
3) Please check that both release buttons (A)
mesh into place after adjustment.
Further, the leg support also angles by pulling
the strap underneath the chair.
We recommend to remove the pressure
load from the users body and legs, before
angling the back and leg support. Put a
gentle back pressure on the back and leg
support to remove the pressure load.
Secure the chair when any adjustments
have been made. Then place the user into
the Manatee.
GB
