Thanks for purchasing Mamibot robot vacuum cleaner.
Please read this User Manual carefully before using and
keep it properly for future use.
Page 2
Floor mopping Robot
About Your ProVac Plus2
Top View
1.
Start/Stop
On/Off
Bumper
Bottom View
2.
Dust box cover
Side Brush
Drive wheel
Battery Box
Anti-falling Sensor
Water Tank (Optional Models)
3.
Water Tank Cap
Water Tank
Suction Port
Direction
Wheel
Side Brush
Mounting Pole
Water Leaking Area
Cleaning Cloth
Page 3
Floor mopping Robot
Maintenance of ProVac Plus2
1. Clean or replace the side brush
Remove side brush screw Take off side brush
The side brushes can sometimes be deformed during transportation or when the
product is used under particular conditions. If this happens, it is possible to return to
the original shape by putting bristles in hot water.
2. Clean Anti-falling sensors
Wipe three anti-falling sensors with a clean,dry cloth.
Anti-falling Sensors
3. Clean the Dust Bin and Filter
Page 4
Floor mopping Robot
Maintenance of ProVac Plus2
1
Remove and empty the dust bin after each use
2
Clean the dust bin
2
A.
Push out the cover and clean filter
B.
Clean or replace filter
4. Remove or Install Battery
Use of ProVac Plus2
1. Water Tank Use and Mopping (Optional Model)
For wet mopping, please mount the water tank and mopping cloth before use. When it’s
not in use, please take off water tank and mopping cloth. Pour out left water and dry it for
next use.
2
1
1) Attach Cleaning Cloth to water
tank;
2) Fill clean water into water tank;
3) Attach the water tank to
bottom of the robot, fix the
mounting pole properly.
3
Mounting
Poles
Page 5
2. General Dry Vacuuming &Sweeping
Full Cleaning Mode: Press one (1 time) the Switch On/Off button to start, it cleans for 80-100
minutes and stops automatically when battery is low;
Single room Cleaning Mode: Press twice (2 times) the Switch On/Off button to start, it cleans
45 minutes and stop automatically.
Frequent Asked Questions
Floor mopping Robot
Q: Why does the Side Brush occasionally spin backwards?
A: When caught on items such as carpet tassels or wires, the Side Brush may spin slowly or
briefly spin backwards to free itself. This may also occur on thick or high-pile carpets. If this
behavior should occur on hard floor surfaces or when on tassels or wires are presented, the
Side Brush should be cleaned. Using a small screwdriver, to move the screw from the
center of the Side Brush first, then remove the Side Brush and clean any hair or debris
wrapped around the shaft thoroughly. Re-install the Side Brush properly after cleaning it.
Q:Why does ProVac PLUS2 stops occasionally?
A: It might be stopped because of low power, or stuck by obstacles, or by carpet with long
rugs, or moves onto carpet when cleaning with water tank and mop attached. Plus2 is not
supposed to clean carpet with long rugs, or when with water tank attached. Please be
sure that there are no cables, clothes, curtain belts, or any other materials scattered in it’s
cleaning area, to avoid tangling or trapping your robot during cleaning.
Q: Why doesn’t ProVac Plus2 slow down as it approaches certain obstacles?
A: The ProVac Plus2 uses its light Touch Bumper technology to identify walls and other
obstacles, allowing it to slow down and gently touch the obstacles with its bumper before
changing direction. It may be less effective at sensing and slowing down from extremly
dark or black surfaces, or for objects that are less than two inches wide.
Cleans Multiple Floors
The ProVac Plus2 works on wood, carpet, tile, vinyl, and linoleum, and adjusts automatically
to different floor types. It mops hard floor with water tank, but doesn’t mop carpet with long rugs.
The ProVac Plus automatically senses stairs and other cliffs. It might stall when
confronting rounded edges and might slide over particularly slippery surfaces.
Anti-Tangle System
The ProVac Plus won’t get stuck on cords, carpet fringe or tassels. When it detects that it had
picked up a cord or tassel, it will automatically stop its main brushes or side brush and try
to escape. It may make a clicking noise when anti-tangle is activated.
Page 6
Floor mopping Robot
Important Safety Instructions
► This appliance should only be used for domestic cleaning, as described in this user guide.
► Always switch off and remove the charger from the socket before cleaning the appliance
or any maintenance task.
► This Appliance can be used by children aged from 16 years and above and persons with
reduced physical, sensory or mental capabilities or lack of experience and knowledge if they
have been given supervision or instruction concerning use of the appliance in a safe way and
understand the hazards involved. Children shall not play with the appliance.
► If the power cord is damaged, stop using the appliance immediately. To avoid a safety
hazard, an authorized service engineer must replace the power cord.
If the area to be cleaned containers a balcony, a physical barrier should be used to prevent
access to the balcony and ensure safe operation.
► Small children and pets must be supervised while the cleaner is cleaning.
► Use only the original charger supplied with the appliance. Check that your supply voltage is
the same as that stated on the charger.
► Leaks from battery cells can occure under extreme usage or temperature conditions. If the
liquid gets on skin, wash quickly with water. If the liquid gets into eyes, flush them immediately
with clean water for a minimium 10 minutes. See medical attention.
► It is normal for the charger to become warm to the touch when charging.
Don’t pick up hard or sharp objects, matches, hot ashes, cigarette ends or other similar items.
► Don’t spray with or pick up flammable liquids, cleaning fluids, aerosols or their vapours.
► Don’t continue to user your appliance or charger if it appears faulty.
► To ensure the continued safe and efficient operation of this appliance we recommend that
any servicing or repairs are only carried out by an authourised service engineers.
► Don’t replace the robot batteries with non-rechargeable batteries.
► End of life battery removal. If the appliance is to be disposed, the batteries must firstly be
removed. It must be disconnected from the supply mains when removing the battery.
Page 7
Specifications:
Model No.: ProVac Plus2 Cleaning Modes: 3 modes (edge, spiral, random)
Battery: 7.4V 2200/2600mAh Lithium Charging time: 3-4 hours
Working time: 80-100min Dimension:25.5*24.3*8.1cm
Adapter: AC100-240V 50/60Hz Dust box: 0.30l
Noise Level: <60dB Cleaning surface: multiple (wooden, marble, ceramic)
Quality
Factories have been independently assessed by authorized Party for quality and production
management.
The Environment
The symbol on this appliance indicates that this appliance may not be treated as
household waste. Instead it must be handed over to the applicable collection point for the
recycling of electrical and electronic equipment. Disposal must be carried out in accordance with
local environmental regulations for waste disposal. For more detailed information about treatment,
recovery and recycling of this appliance, please contact your local city office, your household
and waste disposal service or the shop where you purchased the appliance.
This appliance complies with the European Directives 2014/30/EU, 2014/35/EU, and
2014/53/EU.
Your Guarantee
The guarantee conditions for this appliance are as defined by our representative in the country in
which it is sold. Details regarding these conditions can be obtained from the dealer from whom the
appliance was purchased. The bill of sale or receipt must be produced when making any claim
under the terms of this guarantee. Subject to change without notice.
Mamibot Manufacturing USA Inc.
Orange St. #600, Wilmington, New Castle, 19899, Delaware, USA
sales@mamibot.com www.mamibot.com
Page 8
Problems
Causes and Solutions
The robot cleaner doesn’t work
Cleaning power is weak
The robot cleaner is very noisy while
leaning
The robot cleaner stops working/cleans
intermittently
The robot cleaner fails to detect stairs
The robot cleaner is trapped
★ Check that the robot cleaner is switched on.
★ Check the dust container, filter and motor are clean
or not.
★ Check if the robot cleaner needs to be charged.
Turn power off and:
★ Empty dust container.
★ Check and clean the filter and motor.
★ Check and clean the floor brushes.
★ Check and clean the sensors.
★ Check and clean the drive wheels..
★ Clean the dust container and filter.
★ Check the brushes and drive wheels for dirt and
debris.
★ Check the cleaning mode setting.
★ No Power, charge the robot and use it again.
★ Check and clean the sensors.
★ The robot cleaner will attempt to free itself but in
some cases assist the robot cleaner manually.
***Remarks***:
Please be aware of that the robot is not supposed to clean on carpet when the water tank and
mop are attached;
Please empty and clean the dust bin in time, dirty dust bin will reduce the cleaning power and
efficiency.
