Malyan MA10 User Manual

MALYAN

MA10 3D Printer

User's Manual

CONTENTS

SAFETY WARNINGS AND GUIDELINES ............................................................................... 3

INTRODUCTION .......................................................................................................................... 4

PACKAGE CONTENTS .............................................................................................................. 4

PRODUCT OVERVIEW .............................................................................................................. 5

USING THE MENU SYSTEM .................................................................................................... 5

Installation ..................................................................................................................................... 6

SETUP ........................................................................................................................................... 7

SOFTWARE INSTALLATION AND SETUP .......................................................................... 10

Installing Cura for Windows .................................................................................................. 10

Repetier-Host .......................................................................................................................... 13

FCC Notice .................................................................................................................................. 15

2

SAFETY WARNINGS AND GUIDELINES

 Be careful not to damage the PC paper on the build plate.
 Take care to avoid touching hot parts, including heat blocks, extruder nozzle,

extruded filament, and the heated build plate.

 Do not wear gloves when operating or repairing to avoid entanglement.
 Keep the printer and all accessories out of reach of children.
 Do not remove or disconnect the USB cable when printing from a computer.
 Do not pull or twist the black cable at any time.
 Do not force or tear anything when during unpacking and setup. This may cause

damage to the printer and/or its accessories.

 Do not reach inside the printer during operation.
 Always allow the printer and extruded filament to cool before reaching inside.
 Ensure that the printer is turned off and unplugged from its power source before

making repairs or performing service.

 Do not install this device on an unstable surface where it could fall and cause

either personal injury or damage to the device and/or other equipment.

 Do not subject the product to extreme force, shock, or fluctuations in temperature

or humidity.

 This device is intended for indoor use only.
 Do not expose this device to water or moisture of any kind. Do not place drinks or

other containers with moisture on or near the device. If moisture does get in or on
the device, immediately unplug it from the power outlet and allow it to fully dry
before reapplying power.

 Do not touch the device, the power cord, or any other connected cables with wet

hands.

 Use only in a well-ventilated area. Do not use in close, confined spaces.
 Prior to operation, check the unit and power cord for physical damage. Do not

use if physical damage has occurred.

 Before plugging the unit into a power outlet, ensure that the outlet provides the

same type and level of power required by the device.

 Unplug this device from the power source when not in use.
 Take care to prevent damage to the power cord. Do not allow it to become

crimped, pinched, walked on, or become tangled with other cords. Ensure that
the power cord does not present a tripping hazard.

 Never unplug the unit by pulling on the power cord. Always grasp the connector

head or adapter body.

3

INTRODUCTION

Thank you for purchasing this 3D printer from Malyan! This printer features a single
extruder, which is capable of printing in PLA, ABS, and other materials. You can print
from a Windows® or Mac® PC using a USB connection or can print from 3D model files
stored on a memory card, without the need for a PC connection of any kind. This printer
is easy to setup and easy to use following the instructions in this manual.

PACKAGE CONTENTS

Please take an inventory of the package contents to ensure you have all the items listed
below.

1x 3D printer
1x Filament rack
1x Plastic scraper
1x USB cable
1x Memory card
4x Hex wrench(2.0mm, 2.5mm, 3mm, 4.0mm)
5x M5*20 Screw
13 xM4*6 Screw
1x Open-end Wrench(8mm)
1x AC power cord

4

PRODUCT OVERVIEW

1. Extruder

2. LCD Screen

3. Micro USB and Micro SD Ports

4. Power Switch

5. Input Power Jack

6. Filament Rack

7. Feed Mechanism

USING THE MENU SYSTEM

 Rotating the control wheel counterclockwise moves the highlight/pointer to the up.
 Rotating the control wheel clockwise moves the highlight/pointer to the down.
 Rotating the control wheel counterclockwise while editing a value decreases that value.
 Rotating the control wheel clockwise while editing a value increases that value.
 Press the center of the control wheel to activate the selected menu item or to save an

edited value.

5
