Malone MPG322 User Manual

MALONE

MALONE

R

~ STORAGE

R

~ FS RACK STORAGE SYSTEM

~ BASE FRAME

NOW WITH SILVER POWDER COAT!!

MPG322

MPG331

Shown Above

MALONE

R

Important Note

Product Warranty & Registration Form

All information is condential and used exclusively by MALONE only.

Dear Customer,

Thank you for your purchase of a Malone Product.

In order to be eligible for the Malone Warranty program, we ask that you contact us by email or
online at one of the following: With-in 30 days of purchase. You can also mail this letter back to the address at
the bottom.

• Online: www.maloneautoracks.com

• Email: [e-mail]

We will require the information below.

Here is the information collected:

First Name:

Last Name:

Address:

Address2:

City:

State:

Zip:

Country:

Email:

Phone:

Product Description/Name:

Product MPG#

Date Purchased:

Store Where Purchased:

Purchase Price:

Thank you for choosing Malone!

81 County Rd. Ste 1, Westbrook, ME 04092

P: 207.774.9100 F: 207.615.0551

E: [e-mail] W: www.maloneautoracks.com

MALONE

R

NOW WITH SILVER POWDER COAT!!

FS Rack Storage System

(MPG318 - MPG331 - MPG332 - MPG334 - MPG338 - MPG386 - MPG387 - MPG388)

B Top Upright (2)

A Frame Leg (2)

E Cross

Supports (5))

C Lower Upright (2)

D Upright Brace (4)

Warnings / Limitations: Do not exceed the published load bearing weight of the product.

Use on a at dry surface.

OUTSIDE USE: Boats must be turned with cockpit facing inwards to avoid lling with water.

Under no circumstances will the manufacturer be responsible for

damages or failures that occur as a result of improper assembly or usage.

G Frame Hardware

45mm (8pcs)

I Upright Brace

Hardware 55mm (2pcs)

H Cross Support

Hardware 45mm(10pcs)

J Frame Levers

K Frame Hardware

40mm (6pcs)

(6pcs)

1). Begin by opening the carton, remove the contents and conrm that all the components of the rack have
been included. Identify and pre-stage the following parts for building a lower side assembly. See images 1
and 2 below. Repeat for the second side.

1

A

J

Installation Instructions - Please Read Before Beginning

G

C

I

G

J

G G

J

2

I

GG G G
