Page 1
Floor Machine
Equipment
Reference Guide
September, 2014
Your guide to
selecting proper clutch
plates along with
brush and
pad driver sizes.
Page 2
The Malish Corporation
The listings below are your guide to selecting the proper block size
and clutch plates for your machine.
TABLE OF CONTENTS
rush and Suggested
B
™
al-Lok
M
lock Block Malish C/H Malish Plate
odel Number Diameter Diameter Diameter Number
M
B
ad Holder
P
ADVANCE (see Nilfisk-Advance) ..............................................................10
ALTO / CLARKE-AMERICAN (AMERICAN LINCOLN) ....................................2
ALTO / CLARKE INDUSTRIES ......................................................................3
BETCO ......................................................................................................4
BREUER (TORNADO) ................................................................................13
ASSIDY (Clean-O-Matic) ..........................................................................4
C
CENTAUR ..................................................................................................4
CLARKE (see Alto / Clarke-American) ........................................................2
CLARKE (see Alto / Clarke Industries) ........................................................3
DART ........................................................................................................4
EDIC..........................................................................................................5
EUREKA (Sanitaire) ....................................................................................5
FACTORY CAT / TOMCAT............................................................................5
GENERAL (FLOORCRAFT) ..........................................................................5
HAKO (Minuteman / Multi-Clean) ..............................................................9
HAWK........................................................................................................6
HILD..........................................................................................................6
HILLYARD ..................................................................................................6
HOOVER ....................................................................................................6
HUNTINGTON ............................................................................................6
IPC EAGLE ................................................................................................6
KENT ........................................................................................................6
KLINDEX....................................................................................................8
KOBLENZ ..................................................................................................8
LAWLOR....................................................................................................8
MASTERCRAFT..........................................................................................8
MERCURY..................................................................................................8
MINUTEMAN (Hako / Multi-Clean)..............................................................9
NSS (NATIONAL SUPER SERVICE) ..............................................................9
NILFISK-ADVANCE ..................................................................................10
NOBLES ..................................................................................................11
NORTH AMERICAN / NACECARE ..............................................................12
NUSOURCE..............................................................................................12
PACIFIC / STEAMEX ................................................................................12
POWERBOSS ..........................................................................................12
RPS / FACTORY CAT ................................................................................12
(SSS) STANDARDIZED SANITATION SYSTEMS ..........................................12
TACONY (Powr’ Flite) ..............................................................................13
TENNANT / TENNANT TREND / WETROCK................................................13
THOROMATIC ..........................................................................................13
TORNADO................................................................................................13
TUNDRA ..................................................................................................14
UNITED (Unico) ........................................................................................14
VIPER ....................................................................15 & (also see page 13)
WHITE / PULLMAN-HOLT........................................................................15
WINDSOR ................................................................................................16
L-800 lugs are also available in nylon. Order as L-800P.
ADVANCE (Nilfisk-Advance)
See listing under Nilfisk-Advance on page 10
ALTO / CLARKE-AMERICAN (AMERICAN LINCOLN)
Champion-12 10" 11" 4-1/8" N/A
Champion-14 12" 13" 5" NP-9200
Champion-15 13" 14" 5" NP-9200
Champion-17 15" 16" 5" NP-9200
Champion-19 17" 18" 5" NP-9200
Champion-23 21" 22" 5" NP-9200
Gold Line-12 10" 11" 3-3/4" N/A
Gold Line-14 12" 13" 5" NP-9200
Gold Line-15 13" 14" 5" NP-9200
old Line-17 15" 16" 5" NP-9200
G
3 Deluxe 11" 12" 5" N/A
1
EY + Serial Number 1-6850 4-1/8" N/A
K
erial Number 6851-UP 5" NP-9200
S
+ Serial Number 1-6850 5" NP-91
+
erial Number 6851-UP 5" NP-9200
S
13 Deluxe 11" 12" 4-1/8" NP-9200
14 Deluxe 12" 13" ++
15 Deluxe 13" 14" 4-1/8" N/A
16 Deluxe 14" 15" ++ ++
17 Deluxe 15" 16" 5" NP-9200
17 Deluxe CR 15" 16" 5" NP-9200
19 Deluxe 17" 18" ++ ++
14 Floor King 12" 13" ++
16 Floor King 14" 15" ++ ++
19 Floor King 17" 18" ++ ++
23 Floor King 21" 22" ++
Cadet C-10 9" 10" 3-3/4" N/A
Cadet C-12 11" 12" 3-3/4" N/A
ADM-14 12" 13" ++
ADM-16 14" 15" ++ ++
ADM-19 17" 18" ++ ++
ADM-23 21" 22" ++ ++
ALM-13 11" 12" 4-1/8" N/A
ASM-14 12" 13" ++
ASM-16 Ceram 14" 15" ++ ++
ASM-19 Ceram 17" 18" ++ ++
ASM-23 21" 22" ++ ++
Mini-Max 26 13" 13" 5-1/2" L-800
OTHER
Ceram 13 11" 12" 4-1/8" N/A
EM-16, EPM-16 14" 15" 5" NP-9200
RPM 17 High Speed 15" 16" Special Special
RPM 21 High Speed 19" 20" Special Special
S-214 13" 14" 5" NP-9200
S-221 19" 20" 5" NP-9200
SD-11 10" 11" 5" NP-9200
SD-12 10" 11" 5" NP-9200
SD-14 13" 14" 5" NP-9200
SD-15 14" 15" 5" NP-9200
(continues on next page)
! WARNING Do not use brush or pad with flammable materials (fuels, solvents, thinner, etc.) or serious bodily harm or injury could result from possible fire or
explosion. Any synthetic brush used for carpet shampooing must be broken in properly or carpet damage could result.
2
©All rights reserved. The Malish Corporation
Page 3
www.malish.com
Brush and Suggested
™
Mal-Lok
Model Number Diameter Diameter Diameter Number
D-16 14" 15" 5" NP-9200
S
D-18 17" 18" 5" NP-9200
S
D-19 17" 18" 5" NP-9200
S
D-20 19" 20" 5" NP-9200
S
50 Series 12" 13" 5" NP-9200
1
51 Series 14" 15" 5" NP-9200
1
52 Series 17" 18" 5" NP-9200
1
153 Series 21" 22" 5" NP-9200
156 Series 14" 15" 5" NP-9200
160 Series 12" 13" 5" NP-9200
161 Series 14" 15" 5" NP-9200
162 Series 17" 18" 5" NP-9200
170 Series 11" 12" 4-1/8" N/A
189 Series 15" 16" 5" NP-9200
190 Series 10" 11" 4-1/8" N/A
191-10 Series 13" 14" 4-1/8" N/A
191-11 Series 13" 14" 5" NP-9200
191-15 Series 13" 14" 5" NP-9200
192 Series 15" 16" 5" NP-9200
193 Series 12" 13" 5" NP-9200
196 Series 10" 11" 4-1/8" N/A
197 Series 13" 14" 5" NP-9200
198 Series 15" 16" 5" NP-9200
301 Series 18" 19" 5" NP-9200
319 Series 17" 18" 5" NP-9200
320 Series 18" 19" 5" NP-9200
12 10" 11" 5" NP-9200
012A 10" 11" 5" NP-9200
22 20" 21" 5" NP-9200
116 14" 15" 5" NP-9200
119 17" 18" 5" NP-9200
121 19" 20" 5" NP-9200
187-015 10" 11" 5" NP-91
188-01 13" 14" 5" NP-9200
188-005 15" 16" 5" NP-9200
2112A 11" 12" 5" NP-9200
212 10" 11" 5" NP-9200
214 13" 14" 5" NP-9200
214HD 13" 14" 5" NP-9200
215 14" 15" 5" NP-9200
216 14" 15" 5" NP-9200
219 17" 18" 5" NP-9200
221, S221 19" 20" 5" NP-9200
314 12" 13" 5" NP-9200
315 14" 15" 3-5/8" N/A
316 14" 15" 5" NP-9200
316-021 14" 15" 5" NP-9200
317 15" 16" 5" NP-9200
319 17" 18" 5" NP-9200
321 19" 20" 5" NP-9200
322 20" 21" 5" NP-9200
621CE 19" 20" 5" NP-9200
721 19" 20" 5" NP-9200
Focus 17 17" 17" 5" 4148PMB
L-800 lugs are also available in nylon. Order as L-800P.
Block Block Malish C/H Malish Plate
Pad Holder
Model Number Diameter Diameter Diameter Number
ocus 20 20" 20" 5" 4148PMB
F
ocus 28/S28 (2/set) 14" 14" 4.84" G-100
F
ocus 33/S33 (2/set) 17" 17" 4.84" G-100
F
ocus 38 (2/set) 19" 19" 4.84" G-100
F
UTO SCRUBBERS
A
6, 66D Autoscrubber (2/Set) 14" 14" 4.84" G-100
6
1, 81D Autoscrubber (2/Set) 17" 17" 4.84" G-100
8
26 Autoscrubber (2/Set) 13" 13" 4" N/A
7
30 Autoscrubber (2/Set) 13" 13" 4" N/A
7
30I Autoscrubber (2/Set) 14" 14" 4.84" G-100
9
34 Autoscrubber (2/Set) 17" 17" 4.84" G-100
9
36 Autoscrubber (2/Set) 17" 17" 4" N/A
9
950 Scrubmobile (3/Set) 14" 14" 4.84" G-100
960 Scrubmobile (3/Set) 14" 14" 4.84" G-100
772 Scrubmobile (4/Set) 17-7/8" 17-7/8" 9-9/16" L-330
1030 (2/Set) 14" 14" 4.84" G-100
6200, 6700 (3/Set) 14" 14" 4.84" G-100
7000SS, 7700 Scrubmobile (3/Set) 17" 17" 9-9/16" L-330
American Lincoln 6700 (3/Set) 14" 14" 4.84" G-100
7760 (3/Set) 18" 18" 9-9/16" L-330
7765 (3/Set) 18" 18" 9-9/16" L-330
USTRI
D
N
I
E
ARK
L
C
/
ALTO
ESE MACH
TH
1500
nisher
Bur
LEASE CONT
2000 P
nisher
Bur
15
C-
1600
16, C-
C-
1800
18, C-
C-
S
1800H
C-
2000
20, C-
C-
C2K 13 11"
22 20"
C-
C2K 16, C2K 160, C2K 1600,
S, C2K 1600DS
C2K 1600H
C2K 18, C2K 180,
C2K 1800, C2K 1800H
C2K 200, C2K 2000,
C2K 2000HS, C2K 2000DS
F-16, FM-16 14"
FM-11, FM-1100D 9"
FM-12, 12R
FM-13, 1300 (old)
FM-13 (new) 11"
FM-14
FM-15, 1500
FM-17, 1700
FM-1700HS
FM-18
FM-20
FM-2000 18"
FM-2000HS
FM-23, 2300
GM-15
GM-17
GM-18
S
Brush and Suggested
™
Mal-Lok
Block Block Malish C/H Malish Plate
Pad Holder
ES
D
AND PAD
ES
USH
E MACH
13"
14"
16"
16"
18"
14"
16"
18"
10"
11"
12"
13"
15"
15"
16"
18"
18"
21"
13"
15"
16"
ECIAL BR
E MANUFACTURER FOR
IN
14"
15"
17"
17"
19"
12"
21"
15"
17"
19"
15"
10"
11"
12"
12"
13"
14"
16"
16"
17"
19"
19"
19"
22"
14"
16" 5" NP-9200
17" 5" NP-9200
5"
5"
5"
5"
5"
3/8"
3-
5"
5"
5"
5"
5"
3-3/8"
3-3/8"
3-3/8"
5"
5"
5"
5"
5"
5"
5"
5"
5" NP-9200
5" NP-9200
5" NP-9200
(continues on next page)
AILABILITY.
V
A
INES REQUIRE SP
TH
ACT
RIV
ERS.
! WARNING Do not use brush or pad with flammable materials (fuels, solvents, thinner, etc.) or serious bodily harm or injury could result from possible fire or
explosion. Any synthetic brush used for carpet shampooing must be broken in properly or carpet damage could result.
9200
-
P
N
9200
-
P
N
9200
-
P
N
9200
-
NP
9200
-
NP
900
-
P
9200
-
P
N
9200
-
NP
9200
-
P
N
9200
-
P
N
NP-9200
P-900
P-900
P-900
P-9200
N
NP-9200
NP-9200
NP-9200
P-9200
N
NP-9200
NP-9200
NP-9200
3
Page 4
The Malish Corporation
Brush and Suggested
™
Mal-Lok
Model Number Diameter Diameter Diameter Number
P-80, LP-136 15" 16" 5" NP-9200
L
P-18 16" 17" 5" NP-9200
M
-11 9" 10" 5" NP-9200
P
P-12 10" 11" 1-3/4" N/A
P-13 11" 12" 5" NP-9200
P-15 13" 14" 5" NP-9200
P-17 15" 16" 5" NP-9200
P-20 18" 19" 5" NP-9200
-22 20" 21" 5" NP-9200
P
-23 21" 22" 5" NP-9200
P
E-20 18" 19" 5" NP-9200
P
-13 11" 12" 5" NP-9200
S
S-15 13" 14" 5" NP-9200
-16 14" 15" 5" NP-9200
S
S-18 16" 17" 5" NP-9200
-20, SS-20 18" 19" 5" NP-9200
S
THER
O
irect Speed 20 (DS20) 18" 19" 5" NP-9200
D
E-15 13" 14" 5" NP-9200
E-18 16" 17" 5" NP-9200
EM-16 14" 15" 5" NP-9200
IN-15 13" 14" 5" NP-9200
IN-17 15" 16" 5" NP-9200
IN-20 18" 19" 5" NP-9200
LP-80 15" 16" 5" NP-9200
LP-136 15" 16" 5" NP-9200
VP-16 14" 15" 5" NP-9200
VP-18 16" 17" 5" NP-9200
VP-20 18" 19" 5" NP-9200
GM-15 13" 14" 5" NP-9200
GM-17 15" 16" 5" NP-9200
GM-18 16" 17" 5" NP-9200
820 18" 19" 5" NP-9200
Ultra Speed 202
Ultra Speed 2025
Ultra Speed 322
AC1000
AC1500
AC2000
DCR1500
1000 Hi Speed Burnisher
AUTO SCRUBBERS
34 RST (2/Set) 17" 17" 4.84" G-100
TB-20E (2/Set) 10" 11" 2-3/4" N/A
TB-21 (2/Set) 10" 11" 2-3/4" N/A
PS-26 (2/Set) 12" 13" 6-15/16" N/A
PS-30 (2/Set) 14" 15" 6-15/16" N/A
Leader 1700E/1700B 16" 17" 5" NP-9200DA
Leader 2000E/2000B 18" 19" 5" NP-9200DA
Some older model 2000’s take G-100. Ask if machine uses flat plate or snap on hardware.
Leader 2400/2400D (2/Set) 13" 13" 4.84" G-100
Leader 2400UDS (2/Set) 13" 13" 4.84" G-100
Leader 3200/3200D (2/Set) 17" 17" 4.84" G-100
Leader 3400 (2/Set) 17" 17" 4.84" G-100
Vision V (2/Set) 13" 13" 4.84" G-100
L-800 lugs are also available in nylon. Order as L-800P.
Block Block Malish C/H Malish Plate
THESE MACHINES REQUIRE SPECIAL BRUSHES
AND PAD DRIVERS. PLEASE CONTACT THE MACHINE
MANUFACTURER FOR AVAILABILITY.
Pad Holder
Model Number Diameter Diameter Diameter Number
ision 17 16" 17" 5" NP-9200DA
V
ision 20 18" 19" 5" NP-9200DA
V
ision 21 I (2/Set) 11" 11" 4.84" G-100
V
ision 26 I (2/Set) 14" 14" 4.84" G-100
V
ision 32 I (2/Set) 17" 17" 4.84" G-100
V
Vision 38 I (2/Set) 19" 19" 4.84" G-100
3400 (Rider 2/Set) 17" 17" 4.84" G-100
6200 (Rider 3/Set) 14" 14" 4.84" G-100
Encore 32 16" 17" 4.84" G-100
Encore 20, L20, S20, S20E 18" 19" 5" NP-9200DA
Encore 28, L28, S28 (2/Set) 14" 14" 4.84" G-100
ncore 33, L33, S33, R34 (2/Set) 17" 17" 4.84" G-100
E
ncore 38, L38, S38, R38 (2/Set) 19" 19" 4.84" G-100
E
ncore 34 17" 17" 4.84" G-100
E
Encore 35 16" 16" 4.84" G-100
Encore S2426 (2/Set) 13" 13" 5" NP-9200DA
Encore L2426 (2/Set) 13" 13" 4.84" G-100
Encore 17 17" 17" 5" NP-9200DA
Encore 30 (2/Set) 15" 15" 4.84" G-100
BETCO
FL 17, FL 17HD, FL 17DS 15" 16" 5" NP-9200
FL 19, FL 19HD, FL 19DS 17" 18" 5" NP-9200
Foreman N/A
Foreman 32 16" 16" 5.53" L-800
Foreman AS20B 18" 19" 5" NP-9200
NOTE: All Betco auto scrubbers are proprietary.
BREUER (TORNADO)
See listing under Tornado on page 13
CASSIDY (Clean-O-Matic)
12 10" 11" 5" NP-9200
14,14A, 140 12" 13" 5" NP-9200
15, VP-15, 150 13" 14" 5" NP-9200
16, 160 14" 15" 5" NP-9200
17, VP-17, 170 15" 16" 5" NP-9200
190 17" 18" 5" NP-9200
20, VP-20 18" 19" 5" NP-9200
23, 230, 230A 21" 22" 5" NP-9200
CENTAUR
All Centaur machines take NP-9200 clutch plate.
CLARKE
See listing under Alto/Clarke on pages 2-3.
DART
15A 13" 14" 5" NP-9200
18A 16" 17" 5" NP-9200
21A 19" 20" 5" NP-9200
123 21" 22" 5" NP-9200
130, 131 11" 12" 5" NP-9200
140, 141, 142 12" 13" 5" NP-9200
150, 151, 152, 153 13" 14" 5" NP-9200
160, 161, 162 14" 15" 5" NP-9200
170, 171, 172 15" 16" 5" NP-9200
190, 191 17" 18" 5" NP-9200
323 21" 22" 5" NP-9200
Brush and Suggested
™
Mal-Lok
Block Block Malish C/H Malish Plate
Pad Holder
(continues on next page)
! WARNING Do not use brush or pad with flammable materials (fuels, solvents, thinner, etc.) or serious bodily harm or injury could result from possible fire or
explosion. Any synthetic brush used for carpet shampooing must be broken in properly or carpet damage could result.
4
Page 5
www.malish.com
rush and Suggested
Brush and Suggested
™
Mal-Lok
Model Number Diameter Diameter Diameter Number
41, 342, 343 (340 Series) 12" 13" 5" NP-9200
3
60, 361, 362 (360 Series) 14" 15" 5" NP-9200
3
Block Block Malish C/H Malish Plate
371, 372 (370 Series) 15" 16" 5" NP-9200
390, 391 17" 18" 5" NP-9200
410 9" 10" 5" NP-9200
423 19" 20" 5" NP-9200
430 11" 12" 5" NP-9200
451, 452, 453 13" 14" 5" NP-9200
482, 483 (480 Series) 16" 17" 5" NP-9200
23 21" 22" 5" NP-9200
6
30, 631 11" 12" 5" NP-9200
6
41, 642, 643 (640 Series) 12" 13" 5" NP-9200
6
61, 662, 663 (660 Series) 14" 15" 5" NP-9200
6
672, 673 (670 Series) 15" 16" 5" NP-9200
692, 693 (690 Series) 17" 18" 5" NP-9200
23 19" 20" 5" NP-9200
7
51, 752, 753 13" 14" 5" NP-9200
7
782, 783 16" 17" 5" NP-9200
23 19" 20" 5" NP-9200
8
63 14" 15" 5" NP-9200
8
873 15" 16" 5" NP-9200
893 17" 18" 5" NP-9200
921 19" 20" 5" NP-9200
923 21" 22" 5" NP-9200
961, 962 14" 15" 5" NP-9200
971, 972 15" 16" 5" NP-9200
991 17" 18" 5" NP-9200
G1 (180 Series) 14" 15" 5" NP-9200
EDIC
Saturn 13 11" 12" 5" NP-9200
Saturn 17 15" 16" 5" NP-9200
Saturn 20 18" 19" 5" NP-9200
EUREKA (Sanitaire)
15 Sanitaire 13" 14" 5" NP-9200
17 Sanitaire 15" 16" 5" NP-9200
20 Sanitaire 18" 19" 5" NP-9200
FACTORY CAT / TOMCAT
21, 2100 (2/Set) 10" 10" N/R 5" 4110MBS
25, 2500 12" 12" N/R 5" 4110MBS
27, 2700 13" 13" N/R 5" 4110MBS
29 (6 Point Plate – 2/Set) 14" 14" N/R 5" G-400X
29 (8 Point Plate – 2/Set) 14" 14" N/R 5" 4110MB
35 (6 Point Plate – 2/Set) 16" 16" N/R 5" G-400X
35 (8 Point Plate – 2/Set) 16" 16" N/R 5" 4110MB
38, 40, 40HD, 3700
3400 16" 16" N/R 5" 4110MB
52, 5100 (6 Point Plate – 2/Set) 17" 17" N/R 5" G-400X
52, 5100 (8 Point Plate – 2/Set) 17" 17" N/R 5" 4110MB
SS1017, SS1517HD, SS1517-2S 15" 16" N/R 5" NP-9200
SS1020, SS1520HD, SS1520-2S 18" 19" N/R 5" NP-9200
2200 (2/Set) 10" 10" N/R 5" 4110MBS
23 21" 21" N/R 5" 4110MB
29SS 14" 14" N/R 5" 4110MB
35SS 16" 16" N/R 5" 4110MB
L-800 lugs are also available in nylon. Order as L-800P.
Pad Holder
odel Number Diameter Diameter Diameter Number
M
90D 14" 14" N/R 5" 4110MB
2
50D 16" 16" N/R 5" 4110MB
3
390D 19" 19" N/R 5" 4110MB
420D 21" 21" N/R 5" 4110MB
430D 21" 21" N/R 5" 4110MB
490D 16" 16" N/R 5" 4110MB
550D 18" 18" N/R 5" 4110MB
8, 40, 40HD, 3700 18" 18" N/R 5" 4110MB
3
P 370-40D 20" 20" N/R 5" 4110MB
X
P 370-34D, 52, 5100 17" 17" N/R 5" 4110MB
X
INI MAG 17 16" 16" N/R 5" 4110MB
M
MINI MAG 20 19" 19" N/R 5" 4110MB
MINI MAG 23 21" 21" N/R 5" 4110MB
MINI MAG 26 12" 12" N/R 5" 4110MBS
TX26 12" 12" 5" G-400X
G
MAGNUM 26 12" 12" N/R 5" 4110MBS
MAGNUM 30 14" 14" N/R 5" 4110MB
AGNUM 34 16" 16" N/R 5" 4110MB
M
50-13 12" 12" N/R 5" 4110MBS
2
250-15 14" 14" N/R 5" 4110MB
250-17 16" 16" N/R 5" 4110MB
NOTE: Tomcat auto scrubbers need NP-SP spacer on pad drivers ONLY.
GENERAL (FLOORCRAFT)
GF-12 10" 11" 5" NP-9200
GF-15 13" 14" 5" NP-83
GF-17 15" 16" 5" NP-83
GF-19 16" 18" 5" NP-83
GF-21 18" 20" 5" NP-83
GF-23 20" 21" 5" NP-83
GVS-17 15" 16" 5" NP-83
GVS-19 16" 17" 5" NP-83
GVS-21 19" 20" 5" NP-83
K-12 11" 12" 5" NP-83
K-14 13" 14" 5" NP-83
K-15 13" 14" 5" NP-83
K-16 15" 16" 5" NP-83
K-18 16" 17" 5" NP-83
K-22 20" 21" 5" NP-83
KC-12 11" 12" 5" NP-83
KC-14 13" 14" 5" NP-83
KC-16 15" 16" 5" NP-83
KC-17 15" 16" 5" NP-83
KC-18 16" 17" 5" NP-83
KC-20 18" 19" 5" NP-83
KC-22 20" 21" 5" NP-83
KC-14DHS 12" 13" 5" NP-9200
KC-16DHS 14" 15" 5" NP-9200
KC-18DHS 16" 17" 5" NP-9200
KC-20DHS 18" 19" 5" NP-9200
KL-13 11" 12" 5" NP-83
KL-14 13" 14" 5" NP-83
KL-15 13" 14" 5" NP-83
KL-16 15" 16" 5" NP-83
KL-17 15" 16" 5" NP-83
KR-13 11" 12" 5" NP-83
KR-12 11" 12" 5" NP-83
! WARNING Do not use brush or pad with flammable materials (fuels, solvents, thinner, etc.) or serious bodily harm or injury could result from possible fire or
explosion. Any synthetic brush used for carpet shampooing must be broken in properly or carpet damage could result.
B
™
al-Lok
M
lock Block Malish C/H Malish Plate
B
ad Holder
P
(continues on next page)
5
Page 6
The Malish Corporation
Brush and Suggested
™
Mal-Lok
Model Number Diameter Diameter Diameter Number
R-14 13" 14" 5" NP-83
K
R-16 15" 16" 5" NP-83
K
R-17 15" 16" 5" NP-83
K
KR-18 16" 17" 5" NP-83
KR-20 18" 19" 5" NP-83
KR-22 20" 21" 5" NP-83
S-11 10" 11" 5" NP-83
S-13 11" 12" 5" NP-83
-15 13" 14" 5" NP-83
S
-18 16" 17" 5" NP-83
S
-22 20" 21" 5" NP-83
S
NOTE: Models made after 1990 may take NP-9200 clutch plate. Look at hub. If there is an Allen
Set, use NP-83. Otherwise, use NP-9200.
OTE: Floor machine Serial Number identifies the clutch plate to be used. 84xxx or lower use
N
NP-83. 85xxx or higher take NP-9200.
Block Block Malish C/H Malish Plate
Pad Holder
HAKO (Minuteman)
ee listing under Minuteman on page 9.
S
HAWK
HP 1017, HP 1517HD 15" 16" 5" NP-9200
HP 1020, HP 1520HD 18" 19" 5" NP-9200
NOTE: ALL HAWK MACHINES TAKE NP-9200
HILD
B-11 9" 10" 2-1/8" N/A
JR-11 9" 10" 2-1/8" N/A
L-12 10" 11" 5" NP-46
P-12 10" 11" 5" NP-46
K-12-1/2 11" 12" 5" NP-46
P-13 11" 12" 5" NP-46
A-14 12" 13" 2-1/8" N/A
L-14 12" 13" 5" NP-46
L-15 13" 14" 5" NP-46
P-14 12" 13" 5" NP-46
VA-14 12" 13" 5" NP-46
CP-15 13" 14" 5" NP-46
P-15 13" 14" 5" NP-46
C-Master-16 14" 15" 2-1/8" N/A
C-16 14" 15" 5" NP-46
P-16 14" 15" 5" NP-46
UC-16 14" 15" 5" NP-46
2-17 15" 16" 5" NP-46
PRO2-17 15" 16" 5" NP-46
G-18 16" 17" 5" NP-46
GP-15A 13" 14" 5" NP-46
P-18 16" 17" 5" NP-46
C-18 16" 17" 5" NP-46
D-19 17" 18" 5" NP-46
UD-19 17" 18" 5" NP-46
D-Master-19 17" 18" 3-1/4" N/A
219 17" 18" 5" NP-46
PRO2-20 18" 19" 5" NP-46
21 18" 19" 5" NP-46
210 19" 20" 10-1/4" N/A
PRO2-22A (22A-PROII) 20" 21" 5" NP-46
F-22 20" 21" 5" NP-46
L-800 lugs are also available in nylon. Order as L-800P.
rush and Suggested
B
™
al-Lok
M
lock Block Malish C/H Malish Plate
odel Number Diameter Diameter Diameter Number
M
P-16 14" 15" 5" NP-46
H
-22 20" 21" 5" NP-46
H
-24 23" 24" 5" NP-46
E
E-25 23" 24" 5" NP-46
J-25 23" 24" 5" NP-46
K-13 11" 12" 5" NP-46
UC-17 15" 16" 5" NP-46
P-17 15" 16" 5" NP-46
-22A 20" 21" 5" NP-46
P
P-13 11" 12" 5" NP-46
H
P-15 13" 14" 5" NP-46
H
P-18 16" 17" 5" NP-46
H
17-PRO II 15" 16" 5" NP-46
0-PRO II 18" 19" 5" NP-46
2
UD-219 17" 18" 5" NP-46
G-18 16" 17" 5" NP-46
U
B
ad Holder
P
HILLYARD
eluxe Single 14 12" 13" 5" NP-47
D
Standard Single 16 14" 15" 5" NP-47
Standard Single 18 16" 17" 5" NP-47
Standard Single 20 18" 19" 5" NP-47
16" Hillboy 14" 15" 5" N/A
17" Hillboy 15" 16" 5-5/8" N/A
21" Hillboy 18" 18" 5-5/8" N/A
HOOVER
C5023 14" 15" 5" NP-9200
C5025, C5033, C5035 18" 19" 5" NP-9200
C5027 16" 17" 5" NP-9200
C5031 15" 16" 5" NP-9200
F7089 15" 16" 5" NP-47
F7091, F7093 18" 19" 5" NP-47
HUNTINGTON
Malish is unable to supply products for this manufacturer.
IPC EAGLE
CT40 19" 19" 5" NP-500
CT70 (2/Set) 12" 12" 5-1/4" L-800
KENT
C-13 12" 13" 5" N/A
C-13-13" 11" 12" 5-5/8" N/A
C-13-15" 14" 14" 5-5/8" N/A
C-15 15" 16" 5" N/A
C-17 15" 16" 5" N/A
C-18 17" 18" 5" N/A
GA-15 13" 14" 5" NP-9200
GA-17 15" 16" 5" NP-9200
GA-20 18" 19" 5" NP-9200
K-11 9" 10" 5" NP-11
K-12 11" 12" 5" NP-11
KM-13 11" 12" 5" NP-11
KF-13, KF-13DL, KF-13SL 11" 12" 5" NP-9200
KF-17, KF-17DL, KF-17SL & 17SL2 15" 16" 5" NP-9200
KF-20, KF-20DL, KF-20HD 18" 19" 5" NP-9200
KF-20SL & 20SL2
(continues on next page)
! WARNING Do not use brush or pad with flammable materials (fuels, solvents, thinner, etc.) or serious bodily harm or injury could result from possible fire or
explosion. Any synthetic brush used for carpet shampooing must be broken in properly or carpet damage could result.
6
Page 7
www.malish.com
rush and Suggested
Brush and Suggested
™
Mal-Lok
Model Number Diameter Diameter Diameter Number
Block Block Malish C/H Malish Plate
K-130 11" 12" 5" NP-9200
K-13 11" 12" 5" N/A
-13HD 12" 13" 5" N/A
K
-14 11" 12" 5" N/A
K
F-130 11" 12" 5" NP-9200
K
F-150A 13" 14" 5" NP-9200
K
-15 14" 15" 5" N/A
K
K-16 14" 15" 5" N/A
KF-170A 15" 16" 5" NP-9200
KF-175A, KF-174SL 15" 16" 5" NP-9200
KF-176, 176SL2 15" 16" 5" NP-9200
K-17 15" 16" 5" N/A
-17HD 15" 16" 5" N/A
K
K-117 15" 16" 5" N/A
K-170 15" 16" 5" NP-9200
K-19 17" 19" 5" N/A
K-19HD 17" 18" 5" N/A
A-17 Select Scrub 15" 16" 5" NP-9200
K
KA-20BT, KA-20E, KA-20B 19" 20" 5" NP-9200
F-175SA 16" 17" 5" NP-9200
K
Balance for High Speed machine
KF-195, 195M 17" 18" 5" NP-9200
KF-200, 201, 204SL 18" 19" 5" NP-9200
KF-202S 18" 19" 5" NP-9200
KF-204 18" 19" 5" NP-9200
Balance for High Speed machine
KF-205A, 205S 18" 19" 5" NP-9200
KF-205H High Speed 18" 18" Special Special
KF-206, 206SL 18" 19" 5" NP-9200
K-22 19" 20" 5" N/A
K-122 19" 20" 5" N/A
K-122DS 19" 20" 5" N/A
M-13, MA-13 11" 12" 5" NP-9200
M-15 13" 14" 5" NP-9200
MA-15 13" 14" 5" NP-9200
M-17 15" 16" 5" NP-9200
MA-17 15" 16" 5" NP-9200
M-20, MA-20 18" 19" 5" NP-9200
M-23 21" 22" 5" NP-9200
MA-23 21" 22" 5" NP-9200
XP-15 13" 14" 5" NP-9200
XP-17 15" 16" 5" NP-9200
XP-20 18" 19" 5" NP-9200
XP-23 21" 22" 5" NP-9200
170E 15" 16" 5" NP-9200
Select Line 13 11" 12" 5" NP-9200
Select Line 17, 17HD 15" 16" 5" NP-9200
Select Line 20, 20HD, 20TS 18" 19" 5" NP-9200
ECFM 17 15" 16" 5" NP-9200
ECFM 20 18" 19" 5" NP-9200
Razor 17, E17, SV17 16" 16" 5" 4148PMB
Razor 20, 20T 19" 19" 5" 4148PMB
Razor 24 12" 12" 5" 4148PMB
Razor 26 13" 13" 5" 4148PMB
Razor 28 (Razor Plus) (2/Set) 14" 14" 5" 4148PMB
L-800 lugs are also available in nylon. Order as L-800P.
Pad Holder
odel Number Diameter Diameter Diameter Number
M
OTHER
A-11 9" 10" 5" N/A
B-11 9" 10" 5" N/A
-20 19" 20" 5" NP-9200
D
-12 11" 12" 5" NP-9200
E
-13 11" 12" 5" NP-9200
E
-119 17" 18" 5" NP-85
L
NA-13 11" 12" 5" NP-9200
1000E 18" 19" 5" NP-9200
2000E 18" 18" Special Special
AUTO SCRUBBERS
KA-18 (2/Set) 9" 9" 1-7/8" L-801P
B-18 (2/Set) 9" 9" 1-7/8" L-801P
K
E-20 (2/Set) 10" 10" 1-7/8" L-801P
K
A-20 (2/Set) 10" 10" 1-7/8" L-801P
K
KA-200E (2/Set) 10" 10" 1-7/8" L-801P
A-201BST (2/Set) 10" 10" 1-7/8" L-801P
K
KA-26 (2/Set) 12" 13" 1-7/8" L-801P
KA-26HD (2/Set) 13" 13" 1-7/8" L-801P
KA-266EB, 26ERB2 (2/Set) 12" 13" 1-7/8" L-801P
KA-27 Durascrub (2/Set) 13" 14" 2-7/8" L-801P
KA-32 (2/Set) 15" 15" 1-7/8" L-801P
KA-36 (2/Set) 15" 15" 1-7/8" L-801P
KA-33 Durascrub (2/Set) 16" 17" 2-7/8" L-801P
KA-33BR Rider (2/Set) 16" 16" 5-1/4" L-800P
KA-33SS, KA-33SSA (2/Set) 16" 17" 2-7/8" L-801P
KA-34BR2 Rider (2/Set) 16" 16" 5-1/4" L-800P
KA-325B (2/Set) 15" 15" 1-7/8" L-801P
KA-326EB (2/Set) 15" 15" 1-7/8" L-801P
KA-260B (2/Set) 12" 13" 1-7/8" L-801P
KA-261 (2/Set) 13" 13" 1-7/8" L-801P
KA-171B 15" 16" 5" NP-9200
*NOTE: For 27", 33" and 39", 4-1/2" bolt circle, .25"x 45 degree, chamfer on lug side,
use fixture .0145-W.
KA-262B (2/Set) 12" 13" 1-7/8" L-801P
KA-265 13" 13" 1-7/8" L-801P
KA-38, KA-381EB, 38ERB2 (2/Set) 18" 18" 1-7/8" L-801P
KA-382 (2/Set) 18" 18" 1-7/8" L-801P
KA-3818 (2/Set) 18" 18" 1-7/8" L-801P
KA-170B 15" 16" 5" NP-9200
Select Scrub AND Durascrub Auto Scrubbers (2/Set)
27" 13" 14" 2-7/8" L-801P
33" 16" 17" 2-7/8" L-801P*
39" 19" 20" 2-7/8" L-801P*
Durascrub Rider 33 (2/Set) 16" 16" 5-1/4" L-800P
Durascrub Rider 34R (2/Set) 16" 16" 5-1/4" L-800P
Select Scrub 26BT (2/Set) 12" 13" 2-7/8" L-801P
KA-26BT Select Scrub (2/Set) 12" 13" 2-7/8" L-801P*
KA-27SS, KA-27SSA 13" 14" 2-7/8" L-801P*
Select Scrub (2/Set)
KA-32ERB2 (2/Set) 15" 15" 1-7/8" L-801P
*NOTE: For 27", 33" and 39", 4-1/2" bolt circle, .25"x 45 degree, chamfer on lug side,
use fixture .0145-W.
KLINDEX
Requires special clutch plate, refer to manufacturer. Malish can prep the block for a clutch plate
assembly.
! WARNING Do not use brush or pad with flammable materials (fuels, solvents, thinner, etc.) or serious bodily harm or injury could result from possible fire or
explosion. Any synthetic brush used for carpet shampooing must be broken in properly or carpet damage could result.
B
™
al-Lok
M
lock Block Malish C/H Malish Plate
B
ad Holder
P
*
*
*
*
*
7
Page 8
The Malish Corporation
Brush and Suggested
™
Mal-Lok
Model Number Diameter Diameter Diameter Number
Block Block Malish C/H Malish Plate
Pad Holder
rush and Suggested
B
™
al-Lok
M
lock Block Malish C/H Malish Plate
odel Number Diameter Diameter Diameter Number
M
B
ad Holder
P
KOBLENZ
P-1710, TP-1715 15" 16" 5" NP-9200
T
P-2010, TP-2015 18" 19" 5" NP-9200
T
LAWLOR
-12, C-13 11" 12" 5" NP-9200
C
C-16, CF-16 14" 15" 5" NP-9200
C-19, CF-19 17" 18" 5" NP-9200
C-22, CF-22 20" 21" 5" NP-9200
K-13, L-1300 12" 13" 5" NP-9200
K-16, L-1600 14" 15" 5" NP-9200
-19, L-1900 17" 18" 5" NP-9200
K
5W, 16, 151, 151W 14" 15" 6" N/A
1
19, 20D, 181, 181W 17" 18" 6" N/A
21, 221R 20" 20" 8" N/A
2
MASTERCRAFT
1300 11" 12" 5" NP-9200
1330 11" 12" 5" NP-9200
550 13" 14" 5" NP-9200
1
1575 13" 14" 5" NP-9200
1700 15" 16" 5" NP-9200
1775 15" 16" 5" NP-9200
1900 17" 18" 5" NP-9200
2550 13" 14" 5" NP-9200
3300 11" 12" 5" NP-9200
3550 13" 14" 5" NP-9200
3575 13" 14" 5" NP-9200
3700 15" 16" 5" NP-9200
3775 15" 16" 5" NP-9200
3900 17" 18" 5" NP-9200
4550 13" 14" 5" NP-9200
4575 13" 14" 5" NP-9200
4775 15" 16" 5" NP-9200
MD-13-A 11" 12" 5" NP-9200
MD-15-B 13" 14" 5" NP-9200
MD-15-C 13" 14" 5" NP-9200
MD-15-D 13" 14" 5" NP-9200
MD-17-C 15" 16" 5" NP-9200
MD-17-D 15" 16" 5" NP-9200
MD-20-D, MD-20 18" 18" 5" NP-9200
MD-20-E 18" 18" 5" NP-9200
MD-21-D 19" 20" 5" NP-9200
MD-21-E 19" 20" 5" NP-9200
MD-24-E 22" 23" 5" NP-9200
MH-17-E 15" 16" 5" NP-9200
MH-20-E 18" 19" 5" NP-9200
3990 Series 17" 18" 5" NP-9200
4500 Series 13" 14" 5" NP-9200
MTS-17E 15" 16" 5" NP-9200
MTS-20E 18" 19" 5" NP-9200
MTSV-17E 15" 16" 5" NP-9200
MTSV-20E 18" 19" 5" NP-9200
PR-13B 11" 12" 5" NP-9200
PR-17D 15" 16" 5" NP-9200
PR-17E 15" 16" 5" NP-9200
PR-20E 18" 19" 5" NP-9200
L-800 lugs are also available in nylon. Order as L-800P.
MERCURY
BDP-13A 11" 12" 5" NP-9200
BDP-14C 12" 13" 5" NP-9200
DP-15, 15-1/2C, 15-1/2D 13" 14" 5" NP-9200
B
DP-16C 14" 15" 5" NP-9200
B
DP-16D 14" 15" 5" NP-9200
B
DP-17, 17C, 17D 15" 16" 5" NP-9200
B
DP-19, 19D 17" 18" 5" NP-9200
B
BDP-21D 19" 18" 5" NP-9200
BGM-17 15" 16" 5-1/4" N/A
BGM-19 17" 18" 5-1/4" N/A
DC-17 15" 16" 5-1/4" N/A
DC-19 17" 18" 5-1/4" N/A
C-21 19" 20" 5-1/4" N/A
D
-15, L-15 13" 14" 5" NP-9200
H
H-15C 13" 14" 5" NP-9200
H-15D 13" 14" 5" NP-9200
H-15E 13" 14" 5" NP-9200
H-17C 15" 16" 5" NP-9200
H-17D 15" 16" 5" NP-9200
H-17E 15" 16" 5" NP-9200
H-19D 17" 18" 5" NP-9200
H-19E 17" 18" 5" NP-9200
H-21D 19" 20" 5" NP-9200
H-21E 19" 20" 5" NP-9200
HSP-15 13" 14" 5" NP-9200
HSP-17, H-17 15" 16" 5" NP-9200
HSP-19 17" 18" 5" NP-9200
HSP-21 19" 20" 5" NP-9200
L-15-1/2C 13" 14" 5" NP-9200
L-15-1/2D 13" 14" 5" NP-9200
L-15-1/2E 13" 14" 5" NP-9200
L-16C 14" 15" 5" NP-9200
L-16D 14" 15" 5" NP-9200
L-16E 14" 15" 5" NP-9200
L-17C 15" 16" 5" NP-9200
L-17D 15" 16" 5" NP-9200
L-17E 15" 16" 5" NP-9200
L-19 17" 18" 5" NP-9200
L-19D 17" 18" 5" NP-9200
L-19E 17" 18" 5" NP-9200
L-21D 19" 20" 5" NP-9200
L-21E 19" 20" 5" NP-9200
L-23D 21" 22" 5" NP-9200
L-23E 21" 22" 5" NP-9200
TS-17 (Timesaver) 15" 16" 5" NP-9200
TS-19 (Timesaver) 17" 18" 5" NP-9200
TS-21 (Timesaver) 19" 20" 5" NP-9200
OTHER
13 11" 12" 5" NP-9200
14 12" 13" 5" NP-9200
15-1/2 13" 14" 5" NP-9200
16-SpeedMaster 14" 15" 5" NP-9200
16 14" 15" 5" NP-9200
GM-17 15" 16" 5-1/4" N/A
17 15" 16" 5" NP-9200
(continues on next page)
! WARNING Do not use brush or pad with flammable materials (fuels, solvents, thinner, etc.) or serious bodily harm or injury could result from possible fire or
explosion. Any synthetic brush used for carpet shampooing must be broken in properly or carpet damage could result.
8
Page 9
Brush and Suggested
™
Mal-Lok
Model Number Diameter Diameter Diameter Number
Block Block Malish C/H Malish Plate
Pad Holder
www.malish.com
rush and Suggested
B
™
al-Lok
M
lock Block Malish C/H Malish Plate
odel Number Diameter Diameter Diameter Number
M
B
ad Holder
P
GM-19 17" 18" 5-1/4" N/A
19 17" 18" 5" NP-9200
GM-21 19" 20" 5-1/4" N/A
21 H, L, M 19" 20" 5" NP-9200
23 M, L, P 21" 22" 5" NP-9200
P-19 17" 18" 5" NP-9200
MINUTEMAN (Hako / Multi-Clean)
ite-12 10" 11" 5" NP-9200
L
ite-12W 10" 11" 5" NP-9200
L
ite-13 11" 12" 5" NP-9200
L
Lite-14 12" 13" 5" NP-9200
M-17 15" 16" 5" NP-9200
M-20 18" 19" 5" NP-9200
MC-1100 19" 19" 5" NP-9200
MC-12 10" 11" 5" NP-9200
MC-14 12" 13" 5" NP-9200
MC-EX-14 12" 13" 5" NP-9200
MC-15 12" 13" 5" NP-9200
C-16 14" 15" 5" NP-9200
M
MC-EX-16 14" 15" 5" NP-9200
MC-19 17" 18" 5" NP-9200
MC-22 20" 21" 5" NP-9200
MCS-12 10" 11" 5" NP-9200
MCS-14 12" 13" 5" NP-9200
MCS-16 14" 15" 5" NP-9200
MCS-19 17" 18" 5" NP-9200
MCS-22 20" 21" 5" NP-9200
L-13 11" 12" 5" NP-9200
FR-15 (Frontrunner) 13" 14" 5" NP-9200
FR-17 (Frontrunner) 15" 16" 5" NP-9200
FR-20 (Frontrunner) 18" 19" 5" NP-9200
PR20E 17" 18" 5" NP-9200
Special-17, S-17, S-17HD 15" 16" 5" NP-9200
Special-20, S-20, S-20HD 18" 19" 5" NP-9200
V-13 11" 12" 5" NP-9200
V-16 14" 15" 5" NP-9200
V-18 16" 17" 5" NP-9200
V-20 18" 19" 5" NP-9200
V-23 21" 22" 5" NP-9200
OTHER
Deluxe-16, D-16, D-16HD 14" 15" 5" NP-9200
Deluxe-20, D-20, D-20HD 18" 19" 5" NP-9200
Deluxe 24, D-24 21" 22" 5" NP-9200
18 16" 17" 5" NP-9200
M17200/M17760 15" 16" 5" NP-9200
M20400/M20250/M20760 18" 19" 5" NP-9200
M2400-00 18" 19" 5" NP-9200
MC260024 (2/Set) 13" 14" 5" G-200MM
AUTO SCRUBBERS
21 (2/Set) 10" 10" 4" N/A
24 (2/Set) 12" 12" 4" N/A
32 (2/Set) 15" 15" 4" N/A
MC-31 (2/Set) 10" 11" 5" NP-9200
170E/B, 175 15" 16" 5" G-200MM
L-800 lugs are also available in nylon. Order as L-800P.
ako Matic B-43 16" 16" 5" G-200MM
H
ako Matic B-53 19" 19" 5" G-200MM
H
*
*
Hako Matic 24-B (2/Set) 12" 12" 5" G-200MM*
Hako Matic 32-B (2/Set) 16" 16" 5" G-200MM*
HAKO 200, 205, 200X 19" 19" 5" G-200MM*
HI-BUFF 19" 19" 5" NP-9200
26-B (2/Set) 13" 13" 5" G-200MM
60-B, 265-B (2/Set) 13" 13" 5" G-200MM
2
8-B (2/Set) 19" 19" 5" G-200MM
3
80, (3800) (2/Set) 19" 19" 5" G-200MM
3
20, 340 (2/Set) 16" 16" 5" G-200MM
3
C-20001QP (2/Set) 19" 19" 5" G-200MM
M
*
*
*
*
*
*
SBR-50 (2/Set) 10" 10" 5-1/2" L-800
SBR-60 (2/Set) 12" 12" 5-1/2" L-800
SBR-70 (2/Set) 14" 14" 5-1/2" L-800
SBR-85 (2/Set) 17" 17" 5-1/2" L-800
SBR-100 (2/Set) 19" 19" 5-1/2" L-800
240X (2/Set) 12" 12" 5" G-200MM
NOTE: Blocks requiring preparation for G200MM, call Customer Service.
*
*
ES Series: Uses Powerboss Hub currently available as the G-200PB by Malish. Prep for G-200MM only.
Old (OEM): Drill mounting holes first, then drill a 4.25" Center Hole.
Newer Models: Without spacer ZSPACERMM takes a 5" Center Hole, with spacer ZSPACERMM
takes a 4-1/4" Center Hole.
NSS (NATIONAL SUPER SERVICE)
2016 18" 19" 5" NP-9200
Port-Able 13 (Old Style) 11" 12" 5" N/A
Port-Able 13-SP 11" 12" 5" NP-9200
SP-15 13" 14" 5" NP-9200
SP-16 14" 15" 5" NP-9200
SP-17 15" 16" 5" NP-9200
SP-19 17" 18" 5" NP-9200
SP-20 18" 19" 5" NP-9200
SS-13 11" 12" 5" NP-9200
SS-15 13" 14" 5" NP-9200
SS-16 14" 15" 5" NP-9200
SS-17 15" 16" 5" NP-9200
SS-19 17" 18" 5" NP-9200
SS-20 18" 19" 5" NP-9200
OTHER
21 (2/Set) 10" 10" 5" N/A
24B (2/Set) 12" 12" 5" N/A
32 15" 15" 5" N/A
Filly 13 11" 12" 5" NP-9200
FP-15 Thouroughbred 13" 14" 5" NP-9200
15 Maverick II 13" 14" 5" NP-9200
17 Thouroughbred 15" 16" 5" NP-9200
17 Maverick II, 300-17 15" 16" 5" NP-9200
*
*
Maverick 300 18" 19" 5" NP-9200
Mustang 17, 300-17 15" 16" 5" NP-9200
Mustang 20, 300-20 18" 19" 5" NP-9200
20 Thouroughbred 18" 19" 5" NP-9200
20 Maverick II, 300-20 18" 19" 5" NP-9200
Charger 20 High Speed 18" 19" Special Special
23 Thouroughbred 21" 22" 5" NP-9200
Charger 1500 18" 18" Special Special
(continues on next page)
! WARNING Do not use brush or pad with flammable materials (fuels, solvents, thinner, etc.) or serious bodily harm or injury could result from possible fire or
explosion. Any synthetic brush used for carpet shampooing must be broken in properly or carpet damage could result.
9
Page 10
The Malish Corporation
Brush and Suggested
™
Mal-Lok
Model Number Diameter Diameter Diameter Number
Block Block Malish C/H Malish Plate
Pad Holder
rush and Suggested
B
™
al-Lok
M
lock Block Malish C/H Malish Plate
odel Number Diameter Diameter Diameter Number
M
B
ad Holder
P
AUTO SCRUBBERS
2625 (2/Set) 12" 12" 5-1/2" L-800T
hamp ZS29 (2/Set) 14" 15" 5-1/2" L-800T
C
rangler 33, 3330 (2/Set) 16" 16" 5-1/2" L-800T
W
rangler 27 (2/Set) 13" 13" 5-1/2" L-800T
W
rangler 17 15" 17" 5" NP-9200
W
rangler 20 18" 20" 5" NP-9200
W
Wrangler 26 (2/Set) 12" 13" 5-1/2" L-800T
Wrangler 24 (2/Set) 11" 12" 5-1/2" L-800T
Wrangler 1708C 17" 17" 5" NP-9200
Wrangler 2008C 19" 19" 5" NP-9200
Wrangler 2016 18" 19" 5" NP-9200
hamp ZS35 (2/Set) 17" 18" 5-1/2" L-800T
C
NILFISK-ADVANCE
Adgressor 3220 (2/Set) 16" 16" 5-1/2" L-800
Adgressor 3520 (3/Set) 11" 11" 5-1/2" L-800
Adgressor 3820 (3/Set) 12" 12" 5-1/2" L-800
Advenger 2400 12" 12" 5-1/2" L-800
Advenger 2600 12" 12" 5-1/2" L-800
Advenger 2801 13" 14" 5-1/2" L-800
Advenger 3210 15" 15" 5-1/2" L-800
Centurian 17 15" 16" 5" NP-47
Centurian 20 18" 19" 5" NP-47
Centurian 150 13" 14" 5" NP-47
Centurian 155 13" 14" 5" NP-47
Galaxie 14 (New Style) 12" 13" 4-29/32" N/A
Galaxie 16, 160 14" 15" 5" NP-47
Galaxie 16 (New Style) 14" 15" 4-29/32" N/A
Galaxie 400 14" 15" 4-29/32" N/A
Galaxie G1600 14" 15" 5" NP-47
Galaxie 18, 180 16" 17" 5" NP-47
Galaxie 20 18" 19" 5" NP-47
Gyro 12 10" 11" 5" NP-47
Gyro 13 11" 12" 5" NP-47
Gyro 14 12" 13" 5" NP-47
Gyro 11-14 12" 13" 5" NP-47
Gyro Magic 12 10" 11" 5" NP-47
Matador 17 15" 16" 5" NP-47
All Purpose Matador 17 15" 16" 5" NP-47
Matador 20 18" 19" 5" NP-47
All Purpose Matador 20 18" 19" 5" NP-47
Matador 24 22" 23" 5" NP-47
High Speed Matador 17 15" 16" 5" NP-47
High Speed Matador 20 18" 19" 5" NP-47
Pacemaker 15 13" 14" 5" NP-47
Pacemaker 17 15" 16" 5" NP-47
Pacemaker 20, P20E 18" 19" 5" NP-47
Pacemaker 22 20" 21" 5" NP-47
Pacemaker 24 22" 23" 4-7/8" N/A
PaceSetter 17 15" 16" 5" NP-9200
PaceSetter 20 18" 19" 5" NP-9200
SD 17, SD 4317 15" 16" 5" NP-9200
SD 20, SD5120 18" 19" 5" NP-9200
SD 130 11" 12" 5" NP-9200
Speedboy Deluxe 16 14" 15" 4-7/8" N/A
peedboy Deluxe 19 17" 18" 4-7/8" N/A
S
Speedboy Deluxe 24 22" 23" 4-7/8" N/A
peedboy Special 12 10" 11" 5" NP-47
S
peedboy Special 15 13" 14" 5" NP-47
S
hadow 17 15" 16" 5" NP-9200
S
hadow 20 18" 19" 5" NP-9200
S
Spin 17 15" 16" 5" NP-9200
Spin 20 18" 19" 5" NP-9200
Adfinity 17ST 16" 16" 5" 4148PMB
Adfinity 20ST 19" 19" 5" 4148PMB
Galaxie 18 (New Style) 16" 17" 5" N/A
aceSetter 13 11" 12" 5" NP-9200
P
dfinity 20 19" 19" 5" 4148PMB
A
dfinity 20D 19" 19" 5" 4148PMB
A
Adfinity 24 (2/Set) 11" 11" 5" 4148PMB
Razor Plus 26D (2/Set) 12" 12" 5" 4148PMB
ll Standard Single Disc Machines After 1997 Require NP-9200 Clutch Plate
A
OTHER
EXPL-PROOF 16 14" 15" 4-7/8" N/A
17A 15" 16" 5" NP-47
17B 15" 16" 5" NP-9200
V-17D 14" 15" 4-7/8" N/A
V-17E 14" 15" 4-7/8" N/A
Velvet Touch 12 10" 11" 5" NP-47
PM1000 15" 16" 5" NP-47
Whisper 17 15" 16" 5" NP-47
Whisper 20 18" 19" 5" NP-47
G2000 18" 19" 5" NP-47
Wizard 13 11" 12" 5" NP-47
130 11" 12" 5" NP-47
135 11" 12" 5" NP-47
Wildcat-15 13" 14" 5" NP-47
150 13" 14" 5" NP-47
155 13" 14" 5" NP-47
Wolverine-16 14" 15" 5" NP-47
Wildcat 17 15" 16" 5" NP-47
170 15" 16" 5" NP-47
175 15" 16" 5" NP-47
Wildcat-20 18" 19" 5" NP-47
200 18" 19" 5" NP-47
Wildcat-22 20" 21" 5" NP-47
220 20" 21" 5" NP-47
225 20" 21" 5" NP-47
Wolverine-20 18" 19" 5" NP-47
Micro-Matic 17B 15" 16" 5" NP-9200
450 OR 45 11" 11" 5-1/2" N/A
Lynx 285 14" 15" 5-1/2" L-800
Lynx 325 16" 17" 5-1/2" L-800
Lynx 385 19" 20" 5-1/2" L-800
Micromax 17B, 17E 16" 16" 5" 4148PMB
Micromax 20B, 20DD 19" 19" 5" 4148PMB
MP-20 HS 18" 19" 5" NP-47
All Standard Single Disc Machines After 1997 Require NP-9200 Clutch Plate
Speedboy Deluxe 14 12" 13 4-7/8" N/A
L-800 lugs are also available in nylon. Order as L-800P.
(continues on next page)
! WARNING Do not use brush or pad with flammable materials (fuels, solvents, thinner, etc.) or serious bodily harm or injury could result from possible fire or
explosion. Any synthetic brush used for carpet shampooing must be broken in properly or carpet damage could result.
10
Page 11
www.malish.com
rush and Suggested
Brush and Suggested
™
Mal-Lok
Model Number Diameter Diameter Diameter Number
UTO SCRUBBERS
A
dvance Eco Flex SC 750 26D (2/Set) 12" 12" 5-1/2" L-800
A
A5321/D 19" 19" 5" 4148PMB
B
S7000 (3/Set) 16" 16" 5-1/2" L-800
C
Block Block Malish C/H Malish Plate
Hydro Cat (2/Set) 12" 12" 5-1/2" L-800
Hydro Retriever 200 18" 18" 5" NP-47
Hydro Retriever 240 (2/Set) 11" 11" 5-1/2" L-800
Hydro Retriever 3800 (2/Set) 19" 19" 5-1/2" L-800
Hydro Retriever 2800 (2/Set) 14" 14" 5-1/2" L-800
ydro Retriever 3200 (2/Set) 16 16" 5-1/2" L-800
H
65 LX 12" 12" 5-1/2" L-800
2
onvertamatic 200 18" 18" 5" NP-47
C
Convertamatic 320, 325 (2/Set) 16" 16" 5-1/2" L-800
Convertamatic 38B 19" 19" 5-1/2" L-800
Convertamatic 3800 (2/Set) 19" 19" 5-1/2" L-800
onvertamatic 380/385 (2/Set) 19" 19" 5-1/2" L-800
C
onvertamatic TRAC 5000B (4/Set) 12" 12" 5-1/2" L-800
C
Convertamatic 17B 15" 15" 5" NP-47
onvertamatic 18B 16" 16" 5-1/2" L-800
C
Convertamatic 20E & B 18" 18" 5" NP-47
Convertamatic 21B 19" 19" 5-1/2" L-800
Convertamatic 24B (2/Set) 11" 11" 5-1/2" L-800
Convertamatic 240 (2/Set) 11" 11" 5-1/2" L-800
Convertamatic 26B (2/Set) 12" 12" 5-1/2" L-800
Convertamatic 260, 265 (2/Set) 12" 12" 5-1/2" L-800
Convertamatic 28B (2/Set) 14" 14" 5-1/2" L-800
Convertamatic 280, 285 (2/Set) 14" 14" 5-1/2" L-800
Convertamatic 32B, 320 (2/Set) 15" 15" 5-1/2" L-800
Convertamax (C-MAX) 20 19" 19" 5" 4148PMB
Convertamax (C-MAX) 26 (2/Set) 12" 12" 5-1/2" L-800
Convertamax (C-MAX) 28 (2/Set) 14" 14" 5-1/2" L-800
Convertamax (C-MAX) 34 (2/Set) 16" 16" 5-1/2" L-800
Mobile-Matic 17 15" 16" 5-1/2" NP-47
Mobile-Matic 20 18" 19" 5-1/2" NP-47
Mobile-Matic 64, 6400 (4/Set) 15" 15" 5-1/2" L-800
Whirlamatic-180 16" 16" 5-1/2" L-800
Whirlamatic-200E 18" 18" 5" NP-47
Whirlamatic-205E 18" 18" 5" NP-47
Whirlamatic-210B 19" 19" 5-1/2" L-800
Whirlamatic-215C 19" 19" 5-1/2" L-800
Whirlamatic-240B, E (2/Set) 11" 11" 5-1/2" L-800
Whirlamatic-245B, E (2/Set) 11" 11" 5-1/2" L-800
Whirlamatic-260B (2/Set) 12" 12" 5-1/2" L-800
Whirlamatic-320B (2/Set) 15" 15" 5-1/2" L-800
Whirlamatic-325B, D (2/Set) 15" 15" 5-1/2" L-800
Whirlamatic-1000 Special Special Special Special
Trac 2800 (2/Set) 14" 14" 5-1/2" L-800
Captor 4300 (3/Set) 14" 14" 5-1/2" L-800
Captor 4800 (3/Set) 16" 16" 5-1/2" L-800
Captor 5400 (4/Set) 13" 13" 5-1/2" L-800
Convertamatic 32D 15" 15" 5-1/2" L-800
Covertamatic 38 (2/Set) 19" 19" 5-1/2" L-800
Warrior 28 (2/Set) 13" 13" 5-1/2" L-800
Warrior 32 (2/Set) 15" 15" 5-1/2" L-800
Warrior 34RST (2/Set) 17" 17" 4.84" G-100
Nilfisk SC750 (26") 13" 13" 5-1/2" L-800
L-800 lugs are also available in nylon. Order as L-800P.
Pad Holder
odel Number Diameter Diameter Diameter Number
M
ilfisk SC750 (28") 14" 14" 5-1/2" L-800
N
ilfisk SC800 (2/Set) 13" 13" 5-1/2" L-800
N
ilfisk SC1500 (2/Set) 19" 19" 5-1/2" L-800
N
NOBLES
PS-14 12" 13" 5" NP-9200
PS-17 15" 16" 5" NP-9200
PS-20 18" 19" 5" NP-9200
PS-16 14" 15" 5" NP-9200
S-19 17" 18" 5" NP-9200
P
S-22 20" 21" 5" NP-9200
P
S-23 21" 22" 5" NP-9200
P
S-14, SPR-14 12" 13" 5" NP-9200
S
SS-16, SPR-16 14" 15" 5" NP-9200
S-17, SPR-17 15" 16" 5" NP-9200
S
SS-19, SPR-19 17" 18" 5" NP-9200
S-20, SPR-20 18" 19" 5" NP-9200
S
S-22, SPR-22 20" 21" 5" NP-9200
S
SS-23, SPR-23 21" 22" 5" NP-9200
SS-24 (2/Set) 11" 11" 5" G-400S
MSS5 12" 12" 5" G-400S
OTHER
1125 LT 9" 10" 5" NP-9200
14, 1400 Series 12" 13" 5" NP-9200
1433 LT 12" 13" 5" NP-9200
1450 LT 12" 13" 5" NP-9200
1450 SD 12" 13" 5" NP-9200
1450 DX 12" 13" 5" NP-9200
1433 MD 12" 13" 5" NP-9200
1450 M 12" 13" 5" NP-9200
1701-3 15" 16" 5" NP-9200
1775 LT 15" 16" 5" NP-9200
1775 SD 15" 16" 5" NP-9200
1775 DX 15" 16" 5" NP-9200
1775 MD 15" 16" 5" NP-9200
2001-3 18" 19" 5" NP-9200
2001 SD 18" 19" 5" NP-9200
2001 DX 18" 19" 5" NP-9200
2075 LT 18" 19" 5" NP-9200
2075 SD 18" 19" 5" NP-9200
2075 DX 18" 19" 5" NP-9200
2075 MD 18" 19" 5" NP-9200
23, 2300 Series 21" 22" 5" NP-9200
2301 SD 21" 22" 5" NP-9200
2301 DX 21" 22" 5" NP-9200
20 High Speed 18" 19" Special Special
23 High Speed 21" 22" Special Special
20015-3 18" 19" 5" NP-9200
20-H 18" 19" 5" NP-9200
20 VS 18" 19" 5" NP-9200
20-DC-HB 18" 19" 5" NP-9200
2000 E 18" 19" 5" NP-9200
WB 20 18" 19" 5" NP-9200
AUTO SCRUBBERS
21 (2/Set) 10" 10" 4" N/A
24 (2/Set) 12" 12" 4" N/A
! WARNING Do not use brush or pad with flammable materials (fuels, solvents, thinner, etc.) or serious bodily harm or injury could result from possible fire or
explosion. Any synthetic brush used for carpet shampooing must be broken in properly or carpet damage could result.
B
™
al-Lok
M
lock Block Malish C/H Malish Plate
B
ad Holder
P
(continues on next page)
11
Page 12
The Malish Corporation
rush and Suggested
Brush and Suggested
™
Mal-Lok
Model Number Diameter Diameter Diameter Number
2 (2/Set) 15" 15" 4" N/A
3
obles XC 11" 11" 3.966" L-800
N
SS 18" 18" 5" NP-9200
V
S-20 18" 18" 5" NP-9200
S
SS-27 (2/Set) 13" 13" 5-1/2" L-800
SS-33 (2/Set) 16" 16" 5-1/2" L-800
SS-1700, SS-1701 15" 16" 5-1/2" L-800
SS-2000 19" 19" 5-1/2" L-800
SS-2001 19" 19" 5-1/2" L-800
S-2200 19" 19" 5-1/2" L-800
S
S-2400 (2/Set) 11" 12" 5-1/2" L-800
S
S-2401 (2/Set) 11" 12" 5.53" L-800
S
S-265 XP (2/Set) 12" 13" 5" G-400S
A
SS-2601 (2/Set) 12" 12" 5.53" L-800
S-2700 (2/Set) 13" 13" 5-1/2" L-800
S
S-2701 (2/Set) 13" 13" 5.53" L-800
S
800 (2/Set) 13" 13" 5" G-400S
2
SS-3300 (2/Set) 16" 16" 5-1/2" L-800
S-3301 (2/Set) 16" 16" 5.53" L-800
S
5300 T 19" 19" 5-1/2" L-800T
5300, SS-5300 19" 19" 5-1/2" L-800
11, 1100 Series 9" 10" 5" NP-9200
260, 260XP (2/Set) 13" 13" 4-31/32" N/A
320 (2/Set) 15" 15" 4-31/32" N/A
EZ Rider HP (2/Set) 14" 14" 5" G-400X
Tuff Scrub 3300 (2/Set) 16" 16" 5-1/2" L-800
Block Block Malish C/H Malish Plate
akes 5.906" b/c. Requires fixture 243-W.
T
11" bolt circle and no riser
Takes 11" b/c.
NORTH AMERICAN / NACECARE
Note: Call customer service for additional information.
NUSOURCE
Auto Scrubbers 5-1/4" C/H 7.94" B/C L-800
PACIFIC / STEAMEX
13 11" 12" 5" NP-9200
Satellite 13 11" 12" 5" NP-9200
14 12" 13" 5" NP-9200
15 13" 14" 5" NP-9200
16 14" 15" 5" NP-9200
Satellite 16 14" 15" 5" NP-9200
17 15" 16" 5" NP-9200
19 17" 18" 5" NP-9200
19-A 17" 18" 5" NP-9200
21 19" 20" 5" NP-9200
23 21" 22" 5" NP-9200
23-A 21" 22" 5" NP-9200
24 22" 23" 5" NP-9200
28 25" 26" 5" NP-9200
22 20" 21" 5" NP-9200
VS-20 18" 19" 5" NP-9200
HS-17 15" 16" 5" NP-9200
HS-19 17" 18" 5" NP-9200
HS-20-DC 18" 19" 5" NP-9200
P-20, PS-20 18" 19" 5" NP-9200
L-800 lugs are also available in nylon. Order as L-800P.
Pad Holder
odel Number Diameter Diameter Diameter Number
M
CP-13 11" 12" 5" NP-9200
P
CP-15 13" 14" 5" NP-9200
P
PCP-17 15" 16" 5" NP-9200
PCP-20 18" 19" 5" NP-9200
PCP-23 21" 22" 5" NP-9200
PHS-17 15" 16" 5" NP-9200
PHS-19 17" 18" 5" NP-9200
HS-20DC 18" 19" 5" NP-9200
P
Proteus 26, 26R (2/Set) N/A
earay 133-13" 11" 12" 5" NP-9200
S
earay 175-17" 15" 16" 5" NP-9200
S
earay 205-20" 18" 19" 5" NP-9200
S
earay 175 DS 15" Use 16" Sure-Lok w/ High Speed Riser & NP-9200
S
Searay 175 HD 15" 16" 5" NP-9200
earay 205 DS Use 19" Sure-Lok w/ High Speed Riser & NP-9200
S
crubMaster 210 (2/Set) N/A
S
crubMaster 26B, 26C N/A
S
520 18" 19" 5" AMP-154
POWERBOSS
88,90 (3/Set) 16" 16" 5-1/2" L-800
62, 65, 78, 80, 85 (3/Set) 14" 14" 5-1/2" L-800
SB/26 (2/Set) 12" 12" 1-7/8" L-801P
SB/28 (2/Set) 13" 13" 2-7/8" L-801P
SB/32 (2/Set) 15" 15" 1-7/8" L-801P
SB/34 (2/Set) 16" 16" 2-7/8" L-801P
SB/40 (2/Set) 19" 19" 2-7/8" L-801P
CP 28 14" 14" 5" G-200PB
CP 32 16" 16" 5" G-200PB
Note: Call Customer Service for cross-reference on PowerBoss sidebrooms.
RPS / FACTORY CAT
See listing under Factory Cat on page 5.
(SSS) STANDARDIZED SANITATION SYSTEMS
21 19" 20" 5" NP-9200
23 21" 22" 5" NP-9200
23A 21" 22" 5" NP-9200
17VS 15" 16" 5" NP-9200
21VS 19" 20" 5" NP-9200
17HS 15" 16" 5" NP-9200
20HS 18" 19" 5" NP-9200
15 13" 14" 5" NP-9200
16 14" 15" 5" NP-9200
17 15" 16" 5" NP-9200
19, 19A 17" 18" 5" NP-9200
DR17125, DR17175 15" 16" 5" NP-9200
DR20125, DR20175 18" 19" 5" NP-9200
VN1720P – 17" Deck 15" 16" 5" NP-9200
VN1720P – 20" Deck 18" 19" 5" NP-9200
20" & 20T (SSS Panther 20T) 19" 19" 5" L-800
26" Twin Disc Fang 12" 13" 5" L-800
28" Twin Disc Fang 13" 14" 5" L-800
VN1715 (SSS Cougar 17) 15" 16" 5" NP-9200
VN2015 (SSS Cougar 20) 18" 19" 5" NP-9200
Fang 15B (SSS Panther) 15" 15" 5" NP-9200
Fang 18C (SSS Panther 18C) 17" 17" 4-3/4" L-800
! WARNING Do not use brush or pad with flammable materials (fuels, solvents, thinner, etc.) or serious bodily harm or injury could result from possible fire or
explosion. Any synthetic brush used for carpet shampooing must be broken in properly or carpet damage could result.
12
B
™
al-Lok
M
lock Block Malish C/H Malish Plate
B
w/1/4" Chamfer. Takes 6.64" b/c. Requires fixture 238-W.
ad Holder
P
(continues on next page)
Page 13
Brush and Suggested
™
Mal-Lok
Model Number Diameter Diameter Diameter Number
Block Block Malish C/H Malish Plate
Pad Holder
www.malish.com
rush and Suggested
B
™
al-Lok
M
lock Block Malish C/H Malish Plate
odel Number Diameter Diameter Diameter Number
M
B
ad Holder
P
TACONY (Powr’ Flite)
ll models require the NP-9200 clutch plate. Call Customer Service with questions.
A
f the model requires Gimbal plate, use 4103MB.
I
TENNANT / TENNANT TREND / WETROCK
Powerline 20-HD 18" W/1-1/2" RISER 19" W/1-1/2" RISER 4-15/16" N/A
Powerline 17-SD 15" W/1-1/2" RISER 16" W/1-1/2" RISER 4-15/16" N/A
Powerline 17-HS 15" W/1-1/2" RISER 16" W/1-1/2" RISER 4-15/16" N/A
Powerline 20-HS 18" W/1-1/2" RISER 19" W/1-1/2" RISER 4-15/16" N/A
ower Trend 15 14" 15" 5" NP-9200
P
ower Trend 17 16" 17" 5" NP-9200
P
ower Trend 20 19" 20" 5" NP-9200
P
ervomatic 17 15" 16" 4-15/16" N/A
S
Servomatic 3200, 32 (2/Set)
Servomatic 26, 261 (2/Set)
15 14" 15" 4-1/8" DWO
iking (15) 14" 15" 4-1/8" DWO
V
AUTO SCRUBBERS
426 (2/Set) 12" 12" 4.35" Special
465, 1465 (2/Set) 12" 12" 5" G-400S
480, 1480 (2/Set) 16" 16" 5" G-400X
490, 1490 (2/Set) 18" 18" 5" G-400X
510E, 515, 7300, 8010, 20" 20" 5" G-400X
8200, 8210, 8300 (2/Set)
515, 7400, 8010, 8200, 16" 16" 5" G-400X
8210, 8300 (2/Set)
7300
MAX PRO 1000 (2/Set) 20" 20" 5" G-400X
MAX PRO 1200 (3/Set) 16" 16" 5" G-400X
528, 530 12" 12" 5" G-400S
2100 11" 12" 5" NP-9200
2120, 2140, 2160 15" 16" 5" NP-9200
2130, 2150, 2170 18" 19" 5" NP-9200
260, 260XP (2/Set) 12" 13" 4-31/32" N/A
261 (2/Set) 12" 13" 5" G-400S
SD-32 (2/Set) 15" 16" 4.35" Special
432 (2/Set) 16" 16" 5-1/2" Obsolete
320 (2/Set) 15" 15" 4-31/32" N/A
S520 (2/Set) 12" 12" 5.53" L-800
T3 – 17" 15" 15" 5" L-800T3
T3 – 20" 18" 18" 5" L-800T3
T3+ (2/Set) 11" 11" 4" L-800
5200 19" 20" 5-1/2" L-800
5280, 5300T 19" 19" 5-1/2" L-800T
5100 (2/Set) 16" 16" 5" N/A
5400-24D (2/Set) 11" 11" 5" G-400S
5400-26D (2/Set) 12" 12" 5" G-400S
5500 (2/Set) 11" 11" 5-1/2" L-800
5520 (2/Set) 12" 12" 5-1/2" L-800
5540 (2/Set) 13" 13" 5-1/2" L-800
L-800 lugs are also available in nylon. Order as L-800P.
15" 15" 4.35" Special
12" 12" 4.35" Special
Takes 7.94" b/c. Requires fixture 125-W.
Takes 7.94" b/c. Requires fixture 125-W.
Takes 5.906" b/c. Requires fixture 243-W.
11" bolt circle and no riser
5560 (2/Set) 16" 16" 5-1/2" L-800
T5 – 24" (2/Set) 11" 11" 5" G-400S
T5 – 28" (2/Set) 13" 13" 5" G-400S
T5 – 32" (2/Set) 15" 15" 5" G-400S
7 – 26" (2/Set) 12" 12" 5" G-400S
T
7 – 32" (2/Set) 16" 16" 5" G-400X
T
12-32" (2/Set) 16" 16" 5" G-400X
T
16 (2/Set) 18" 18" 5" G-400X
T
20 (2/Set) 14" 14" 5" G-400X
T
5 18" 19" 5" NP-9200
F
680/5700 (2/Set) 14" 14" 5" G-400X
5
5680/5700 (2/Set) 16" 16" 5" G-400X
5680/5700 (2/Set) 18" 18" 5" G-400X
8400, 8410, 16" 16" 5” G-400X
ax Pro 1200 (2/Set)
M
7100 28" (2/Set) 14" 14" 5" G-400X
100 32" (2/Set) 16" 16" 5" G-400X
7
200 (2/Set) 18" 18" 5" G-400X
7
200D (2/Set) 18" 18" 5" G-400X
7
7200 Tight Aisle (2/Set) 14" 14" 5" G-400X
8200 (2/Set) 20" 20" 5" G-400X
THOROMATIC
SE 15 13" 14" 5" NP-9200
SE 17 15" 16" 5" NP-9200
SE 20 18" 19" 5" NP-9200
SE 22 20" 21" 5" NP-9200
TM-12 10" 11" 3-25/32" N/A
TM-13 11" 12" 5" NP-9200
TM-15 13" 14" 5" NP-9200
TM-17 15" 16" 5" NP-9200
TM-20 18" 19" 5" NP-9200
TM-22 20" 21" 5" NP-9200
TM-17TS 15" 16" 5" NP-9200
TM-20TS 18" 19" 5" NP-9200
TM-300-17 15" 16" 5" NP-9200
TM-300-20 18" 19" 5" NP-9200
TM-1000 18" 19" 5" NP-9200
TORNADO
Champion 10" 11" 5-1/4" N/A
Jumbo 14" 15" 6-1/8" N/A
Majestic 18" 19" 6-1/8" N/A
Royal 12" 13" 5-1/4" N/A
Standard 16" 17" 6-1/8" N/A
Thrifty150 13" 14" 5" NP-9200
14-1/2 Cyclone 12" 13" 5" NP-9200
15 13" 14" 5" NP-9200
16-1 Cyclone 14" 15" 5" NP-9200
17 15" 16" 5" NP-9200
17-1 16" 17" 5" NP-9200
18-1 Cyclone 16" 17" 5" NP-9200
19 17" 18" 5" NP-9200
19-1 Cyclone 17" 18" 5" NP-9200
20-1 18" 19" 5" NP-9200
22 20" 21" 5" NP-9200
(continues on next page)
! WARNING Do not use brush or pad with flammable materials (fuels, solvents, thinner, etc.) or serious bodily harm or injury could result from possible fire or
explosion. Any synthetic brush used for carpet shampooing must be broken in properly or carpet damage could result.
13
Page 14
The Malish Corporation
Brush and Suggested
™
Mal-Lok
Model Number Diameter Diameter Diameter Number
Block Block Malish C/H Malish Plate
Pad Holder
rush and Suggested
B
™
al-Lok
M
lock Block Malish C/H Malish Plate
odel Number Diameter Diameter Diameter Number
M
B
ad Holder
P
3 Series 12" 13" 5" N/A
7
5 Series 14" 15" 5" N/A
7
7 Series 16" 17" 5" N/A
7
94 Series 12" 13" 5" NP-9200
96 Series 14" 15" 5" NP-9200
97 Series 14" 15" 5" NP-9200
98 Series 16" 17" 5" NP-9200
130 11" 12" 4" N/A
31 11" 12" 4" N/A
1
32 11" 12" 4" N/A
1
50 13" 14" 5" NP-9200
1
280-15 13" 14" 5" NP-9200
280-17 15" 16" 5" NP-9200
80-19 17" 18" 5" NP-9200
2
280-22 20" 21" 5" NP-9200
283-15 13" 14" 5" NP-9200
283-17 15" 16" 5" NP-9200
283-19 17" 18" 5" NP-9200
283-22 20" 21" 5" NP-9200
940 Series 12" 13" 5" NP-9200
941 Series 12" 13" 5" NP-9200
960 Series 14" 15" 5" NP-9200
961 Series 14" 15" 5" NP-9200
962 Series 14" 15" 5" NP-9200
980 Series 16" 17" 5" NP-9200
981 Series 16" 17" 5" NP-9200
990 Series 20" 21" 5" NP-9200
6200 10" 11" 5" N/A
6300 10" 11" 5" N/A
6400 12" 13" 5" N/A
6500 12" 13" 5" N/A
6600 14" 15" 5" N/A
6700 14" 15" 5" N/A
6800 16" 17" 5" N/A
6900 16" 17" 5" N/A
97800 (16" Series I) 14" 15" 5" NP-9200
97805 (18" Series I) 16" 17" 5" NP-9200
97810 (20" Series I) 18" 19" 5" NP-9200
Tornado Screen Hi Speed 18" 19" Special N/A
98400 13" 14" 5" NP-9200
98405 (17" Series II) 15" 16" 5" NP-9200
98410 (19" Series II) 17" 18" 5" NP-9200
98415 (22" Series II) 20" 21" 5" NP-9200
97820 (14" Series I) 12" 13" 5" NP-9200
98480 (20" Bi-Speed) 18" 19" 5" NP-9200
98470 (16" Bi-Speed) 14" 15" 5" NP-9200
98666 (Tri-Drive 1520) 18" 18" 5" NP-9200
98656 (Tri-Drive 1020) 18" 19" 5" NP-9200
98490 18" 19" N/A N/A
98495 18" 19" N/A N/A
98473 (17" Bi-Speed) 15" 16" 5" NP-9200
98653 (Tri-Drive 1017) 15" 16" 5" NP-9200
98663 (Tri-Drive 1517) 15" 16" 5" NP-9200
98672 (17" ES Deluxe) 15" 16" 5" NP-9200
98673 (ES 8673-17" Deluxe) 15" 16" 5" NP-9200
98674 (20" ES Deluxe) 18" 19" 5" NP-9200
L-800 lugs are also available in nylon. Order as L-800P.
98675 (ES8675-20" Deluxe) 18" 19" 5" NP-9200
98677 (1517SSM) 15" 16" 5" NP-9200
8682 (ES8682-17" Standard) 15" 16" 5" NP-9200
9
8683 (ES8683-17" Standard 15" 16" 5" NP-9200
9
8684 (ES8684-20" Standard) 18" 19" 5" NP-9200
9
8685 (ES8685-20" Standard) 18" 19" 5" NP-9200
9
9125, 99105 (EZ20) 19" 20" 5" NP-9200
9
M7580 (97580) 15" 16" 5" NP-9200
M7585 (97585) 18" 19" 5" NP-9200
M8473 (98473) 15" 16" 5" NP-9200
M8480 (98480) 18" 19" 5" NP-9200
P7562 (97562) 15" 16" 5" NP-9200
7564 (97564) 18" 19" 5" NP-9200
P
UTO SCRUBBERS
A
BD14 13" 13" 5.265" L-800
Takes 7.892" bolt circle, fixture 0246-W
D26-27 (2/Set) 12" 12" 5-1/2" L-800
B
Takes 7.84" bolt circle, fixture 134-W
99200 (2/Set) 10" 11" 5-1/2" N/A
EZ20 18" 18" 5" NP-9200
EZ22 20" N/R 20" N/R 5" NP-9200
EZ24 22" N/R 22" N/R 5" NP-9200
Auto-Mite 16E (95678) 14" 14" 4-5/8" N/A
Auto-Mite 16B (95679) 14" 14" 4-5/8" N/A
Auto-Mite 21B (95625) 19" 19" 4-5/8" N/A
3500 Floorkeeper (2/Set) 15" 15" 2.95" 4103MB
3800 Floorkeeper (2/Set) 11" 12" 2.95" 4103MB
Floorkeeper 24 (99300/301) (2/Set) 12" 12" 2.95" 4103MB
Floorkeeper 24 (99320/321) (2/Set) 12" 13" 2.95" 4103MB
Floorkeeper 26 (99307) (2/Set) 14" 14" 2.95" 4103MB
Floorkeeper 28 (99350/351) (2/Set) 14" 14" 2.95" 4103MB
Floorkeeper 30 (99430) (2/Set) 16" 16" 5" G-400X
Floorkeeper 32 (99420/421) (2/Set) 16" 16" 2.95" 4103MB
Floorkeeper 33 (99400/401) (2/Set) 16" 16" 2.95" 4103MB
Floorkeeper 36 (99450/451) (2/Set) 18" 18" 2.95" 4103MB
99407 33" Mid-Range Floorkeeper (2/Set)
16" 16" 2.95" 4103MB
Pad Drivers requiring the 4103MB plate are to include NP-SP spacer and no riser.
TUNDRA
T17 Pro 15" 16" 5" NP-9200
T20 Pro 18" 19" 5" NP-9200
T17 Heavy 15" 16" 5" NP-9200
T20 Heavy 18" 19" 5" NP-9200
T17 Super Heavy 15" 16" 5" NP-9200
T20 Super Heavy 18" 19" 5" NP-9200
T20 Dual Speed 18" 19" 5" NP-9200
TL 17 15" 16" 5" NP-9200
TL 20 18" 19" 5" NP-9200
UNITED (Unico)
112, 112B, 112C 10" 11" 5" NP-9200
CSU-12B 10" 11" 5" NP-9200
CSU-13 11" 12" 5" NP-9200
CSU-14 12" 13" 5" NP-9200
CSU-15 13" 14" 5" NP-9200
CSU-16 14" 15" 5" NP-9200
CSU-17 15" 16" 5" NP-9200
! WARNING Do not use brush or pad with flammable materials (fuels, solvents, thinner, etc.) or serious bodily harm or injury could result from possible fire or
explosion. Any synthetic brush used for carpet shampooing must be broken in properly or carpet damage could result.
14
(continues on next page)
Page 15
www.malish.com
www.malish.com
Brush and Suggested
™
Mal-Lok
Model Number Diameter Diameter Diameter Number
SU-20 18" 19" 5" NP-9200
C
SU-112 10" 11" 5" NP-9200
C
P60-15 13" 14" 5" NP-9200
P60-17 15" 16" 5" NP-9200
P60-20 18" 19" 5" NP-9200
S-12 Aero 10" 11" 5" NP-9200
SBU-13 11" 12" 5" NP-9200
BU-14 12" 13" 5" NP-9200
S
BU-15, S60-16 13" 14" 5" NP-9200
S
BU-16 14" 15" 5" NP-9200
S
SBU-17, S60-17 15" 16" 5" NP-9200
SBU-20, S60-20 18" 19" 5" NP-9200
SBU-24 22" N/A 5" NP-9200
Block Block Malish C/H Malish Plate
Pad Holder
VIPER
DR17125, DR17175 15" 16" 5" NP-9200
DR20125, DR20175 18" 19" 5" NP-9200
VN1720P – 17" Deck 15" 16" 5" NP-9200
VN1720P – 20" Deck 18" 19" 5" NP-9200
0" & 20T (SSS Panther 20T) 19" 19" 5" L-800
2
24" Twin Disc Fang 11" 12" 5" L-800
26" Twin Disc Fang 12" 13" 5" L-800
28" Twin Disc Fang 13" 14" 5" L-800
VN1715 (SSS Cougar 17) 15" 16" 5" NP-9200
VN2015 (SSS Cougar 20) 18" 19" 5" NP-9200
Fang 15B (SSS Panther) 15" 15" 5" NP-9200
Fang 18C (SSS Panther 18C) 17" 17" 4-3/4" L-800
w/1/4" Chamfer. Takes 6.64" b/c. Requires fixture 238-W.
WHITE / PULLMAN-HOLT
A-14 12" 13" 4-5/8" N/A
A-16 14" 15" 4-5/8" N/A
A-12 9" 10" 4-5/8" N/A
B-13-D, B-13-B 11" 12" 5" NP-9200
B-14-D 12" 13" 5" NP-9200
B-16-D, B-16-E 14" 15" 5" NP-9200
B-18-D, B-18-E 16" 17" 5" NP-9200
B-20 Series 18" 19" 5" NP-9200
B-22F 20" 21" 5" NP-9200
C-16-D, C-16-E 14" 15" 5" NP-9200
C-18-D, C-18-E 16" 17" 5" NP-9200
C-20 Series 18" 19" 5" NP-9200
C-22-F 20" 21" 5" NP-9200
C-24-F 22" 23" 5" NP-9200
C-12 9" 10" 5" NP-9200
CD-12 9" 10" 4-5/8" N/A
CD-14 12" 13" 4-5/8" N/A
CD-16 14" 15" 4-5/8" N/A
CH-11 9" 10" 5" NP-9200
M-13-1/2 11" 12" 5" NP-83
M-15-1/2 13" 14" 5" NP-83
M-16 14" 15" 5" NP-83
M-16-E, M-16-EE, M-16-F 14" 15" 5" NP-9200
M-17 15" 16" 5" NP-83
M-18 Series 16" 17" 5" NP-9200
M-20 18" 19" 5" NP-83
M-23 21" 22" 5" NP-83
L-800 lugs are also available in nylon. Order as L-800P.
Model Number Diameter Diameter Diameter Number
-12 10" 11" 5" NP-9200
P
-12B, P-12C 10" 11" 5" NP-9200
P
B-12C 10" 11" 5" NP-9200
P-12-1/2 11" 12" 5" NP-9200
P-13B 11" 12" 5" NP-9200
P-13C 11" 12" 5" NP-9200
P-14 12" 13" 5" NP-9200
C-14, PR-14 12" 13" 5" NP-9200
P
-16 14" 15" 5" NP-9200
P
C-16 14" 15" 5" NP-9200
P
PR-16 14" 15" 5" NP-9200
PX-16 14" 15" 5" NP-9200
P-18 16" 17" 5" NP-9200
C-18 16" 17" 5" NP-9200
P
R-18 16" 17" 5" NP-9200
P
P-20 18" 19" 5" NP-9200
C-20 18" 19" 5" NP-9200
P
R-20 18" 19" 5" NP-9200
P
PES-2000 18" 19" 5" NP-9200
PX-20 18" 19" 5" NP-9200
PC-22 20" 21" 5" NP-9200
PC-22E 20" 21" 5" NP-9200
PC-22F 20" 21" 5" NP-9200
PC-24 22" 23" 5" NP-9200
PC-24E 22" 23" 5" NP-9200
PC-24F 22" 23" 5" NP-9200
Single-13 11" 12" 5" NP-9200
Single-14 12" 13" 5" NP-9200
Single-16 14" 15" 5" NP-9200
Single-18 16" 17" 5" NP-9200
Single-19 16" 17" 5" NP-9200
Single-20 17" 18" 5" NP-9200
Single-22 20" 21" 5" NP-9200
Single-24 21" 22" 5" NP-9200
OTHER
Jubilee 12 9" 10" 4-5/8" N/A
2S-16 14" 15" 4-5/8" N/A
2S-17 15" 16" 4-5/8" N/A
2S-20 18" 19" 4-5/8" N/A
2S-23 21" 22" 4-5/8" N/A
D-18-F, HS-18-F 16" 17" 5" NP-9200
DS-20F 18" 19" 5" NP-9200
ES2000 18" 19" 5" NP-9200
Expert-13 11" 12" 5" NP-9200
Expert-16 14" 15" 5" NP-9200
Expert-18 16" 17" 5" NP-9200
Expert-20 18" 19" 5" NP-9200
Expert-22 20" 21" 5" NP-9200
Gloss Boss High Speed (Ultra High) 18" 18" N/R 1-3/4" Special
(1090, 1500, 2000) Balanced for High Speed machine
HST-20 (2 Brushes) 9" 9" 5" NP-9200
Super-12 9" 10" 5" NP-9200
Super-16 14" 15" 5" NP-9200
J-12A 9" 10" 5" NP-9200
JW-12 10" 11" 5" NP-9200
Special-12 10" 11" 5" NP-9200
Brush and Suggested
™
Mal-Lok
Block Block Malish C/H Malish Plate
Pad Holder
(continues on back)
! WARNING Do not use brush or pad with flammable materials (fuels, solvents, thinner, etc.) or serious bodily harm or injury could result from possible fire or
explosion. Any synthetic brush used for carpet shampooing must be broken in properly or carpet damage could result.
15
Page 16
Brush and Suggested
™
Mal-Lok
Model Number Diameter Diameter Diameter Number
pecial-16 14" 15" 5" NP-9200
S
W-13 11" 12" 5" NP-9200
J
W-16 14" 15" 5" NP-9200
J
W-18 16" 17" 5" NP-9200
J
W-20 17" 18" 5" NP-9200
J
W-22 20" 21" 5" NP-9200
J
Block Block Malish C/H Malish Plate
Pad Holder
50 14" 15" 5" NP-9200
Special-20E 18" 19" 5" NP-9200
J-13 11" 12" 5" NP-9200
AUTO SCRUBBERS
HST-12 (2/Set) 5" 6" Special N/A
-22 Series 20" 21" 5" NP-9200
P
-24 Series 21" 22" 5" NP-9200
P
-17 Series 15" 16" 5" NP-9200
S
-20 Series 18" 19" 5" NP-9200
S
Scrub Boss SB26 (2/Set) 12" 12" 5-1/8" N/A
Scrub Boss SB32 (2/Set) 15" 15" 5-1/8" N/A
WINDSOR
TANDARD SPEED
S
P-175-18 16" 17" 5" NP-9200
ightning 175-17 15" 16" 5" NP-9200
L
ightning 175-20 18" 19" 5" NP-9200
L
Merit MP 15 13" 14" 5" NP-9200
Merit MP 17X 15" 16" 5" NP-9200
Merit MP 20X 18" 19" 5" NP-9200
Merit MP 13 11" 12" 5" NP-9200
HIGH SPEED
Storm 13 (SP13) 11" 12" 5" NP-9200
Storm 15 (SP15) 13" 14" 5" NP-9200
Storm 17 (SP17) 15" 16" 5" NP-9200
Storm 17X (SP17X) 15" 16" 5" NP-9200
Storm 20 (SP20) 18" 19" 5" NP-9200
Storm 20X (SP20X) & SPS20D 18" 19" 5" NP-9200
Saber 28 (2/Set) 13" 13" 5" NP-9200
P-300-18 16" 17" 5" NP-9200
P-300-20 18" 19" 5" NP-9200
P-360-18 16" 17" 5" NP-9200
Brush and Suggested
™
Mal-Lok
Model Number Diameter Diameter Diameter Number
Block Block Malish C/H Malish Plate
Pad Holder
P-360-20 18" 19" 5" NP-9200
PA-18 16" 17" 5" NP-9200
PG-18 16" 17" 5" NP-9200
AUTO SCRUBBERS
-Scrub 26" (2/Set) 12" 12" 5" 4112MB
I
ower Tec 26" (2/Set) 13" 13" 6.625"
P
ower Tec 32" (2/Set) 16" 16" 6.625"
P
ower Tec 20" 18" 18" 5.25"
P
ower Tec 17" 16" 16" 6.625"
P
*
*
*
*
*
*
*
*
Power Tec 24" 21" 21" 5.25" **
Power Tec 28" (2/Set) 14" 14" 6.625" **
Power Tec 34" (2/Set) 17" 17" 6.625" **
Saber 24 (2/Set) 11" 11" 5" 4112MB
Saber 26 (2/Set) 12" 12" 5" 4112MB
aber Cutter 26 (2/Set) 12" 12" 5" 4112MB
S
aber 34 (2/Set) 16" 16" 5" 4112MB
S
uick 32 (2/Set) 15" 15" 5" 4112MB
Q
Tracker AS34 (2/Set) 17" 17" 5" 4112MB*
rident Compact 17 16" 16" 5" 4112MB
T
Trident Compact 20 19" 19" 5" 4112MB*
Trident TR28 (2/Set) 14" 14" 6.625" **
Trident TR34 (2/Set) 17" 17" 6.625" **
Saber 17" Compact 17" 17" 5" L-800
5" C/H = 6.5" Bolt Circle, Fixture #0054-W
Saber 20" Compact 19" 19" 5" 4112MB
Trident Special Special Special Special
NOTE: The Windsor automatic scrubbers listed above do not use a riser with the pad driver.
Merit 175-17 (MD-17) 15" 16" 5" NP-9200
Merit 175-20 (MD-20) 18" 19" 5" NP-9200
Saber Glide 28 (2/Set) 13" 13" 5" 4112MB
Saber Glide 28/36 (3/Set) 11" 11" 5" 4112MB
Saber Glide 32 (2/Set) 15" 15" 5" 4112MB
Saber Cutter 32 (2/Set) 15" 15" 5" 4112MB*
Chariot 20 (1) (new style) 20" 20" 5" 4112MB*
Chariot 24 (2) (new style) 12" 12" 5" 4112MB*
*
*
*
*
*
*Fits new machines with star style plates only. Old Style hex shaped plate not available.
**Call Customer Service
NOTE: All auto scrubbers-when ordering pad driver with 792460, use NP-SP Spacer.
When using the 4112MB Plate, must use NP-SP spacer.
4260 Hamann Parkway • Willoughby, OH 44094
The Malish Corporation
440.951.5356 • 800.321.7044 • Fax 440.951.0293
[email protected] • www.malish.com
Loading...
