Ma-Line FULL-LinE PRodUCt User Manual

Edition 2016

-LINE

MONTI AND ASSOCIATES, INC.

SPECiALtY PRodUCtS FoR tHE HVAC & R indUStRY

FULL-LinE

PRodUCt

CAtALoG

2016

TERMS AND CONDITIONS

MA-LINE ITEMS WILL NOT BE ACCEPTED BACK FOR CREDIT OR REPLACEMENT

WITHOUT AN AUTHORIZED RETURN GOODS NUMBER. A CREDIT WILL NOT BE ISSUED

UNLESS THE RETURN IS ACCOMPANIED BY A MA-LINE INVOICE OR PACKING SLIP.

A MATERIAL CREDIT WILL BE ISSUED. REFUND CHECKS ARE NOT AVAILABLE.

ALL DISCREPANCIES MUST BE REPORTED WITHIN 24 HOURS OF RECEIPT.

PRICING DISKS ARE AVAILABLE IN EXCEL FORMAT

PAYMENT TERMS: NET 30 DAYS

FREIGHT PREPAID TERMS: $1500.00

PRICES AND TERMS ARE SUBJECT TO CHANGE WITHOUT NOTICE DUE TO THE

FLUCTUATION IN THE METALS MARKET

WEBSITE:

http://www.ma-line.com

MAILING ADDRESS:

P.O. BOX 866 ARLINGTON HEIGHTS, IL 60006-0866 USA

SHIPPING ADDRESS:

1050 EAST ADDISON COURT ARLINGTON HEIGHTS, IL 60005-4796 USA

DON’T FORGET TO INQUIRE ABOUT OUR SPINNING FLOOR DISPLAY RACKS

OR OUR COUNTER DISPLAY RACKS!

MA-LINE PRODUCTS ARE FOR LICENSED AND PROFESSIONAL TRADESPEOPLE ONLY

COPYRIGHT 2016 by  $!# #"$

1

Phone/Fax: [phone] MA-LINE www.ma-line.com

DESIGN YOUR OWN RACK

Purchase APPROVED ELIGIBLE HANGING PRODUCT and you can request a
MA-LINE Spinning Display Rack. Our Display Rack includes: a base, 4 pegboard
panels, hooks, a MA-LINE sign, and re-order cards. Your commitment is simply to
hang only MA-Line Products on the rack.

ELIGIBLE HANGING PRODUCT includes MA-LINE products that are designed

to hang on the MA-LINE Rack. MA-Line products that do not hang on the rack
would not count toward the requirement. For example: Inspection Mirrors are
eligible but Clear Vinyl Tubing is not packaged to hang therefore is not eligible
toward the requirement. CALL US TODAY AND ASK FOR DETAILS!

ASSORTED METERS

FOR ALL PURPOSES

MA-12818

MA-IR9PEN

MA-3268C-6

THERMOMETERS

ASSORTED TYPES AVAILBLE

DIAL

DIGITAL

SOLAR

NON-SOLAR

MA-PDT392B

MA-RT900

MA-RT819

SERVICE

TOOLS

MA-QP400

MA-FB2

VARIETY OF

FITTINGS

NYLON FITTINGS

ELBOWS

ADAPTORS

TEES

BUSHINGS….

AF1200

KNIVES

R

A

C

K

D

I

M

E

N

S

I
O
N

S

79"H
X
20"W
X
20"D

APPROX.

SPINNING DISPLAY RACK

MA06007-1R

D

I

M

E

N

S

I
O
N

S

COUNTER DISPLAY RACK

CR-RACK

20"H

X

24"W

X

9"D

APPROX.

TEST LEADS

INSPECTION MIRRORS

VARIETY OF SHAPE & SIZES

AVAILABLE

MA-149

MA-IM24

MA-142A

FLASHLIGHTS

HEADLAMPS & WORKLIGHTS ALSO

AVAILABLE

MA-FL6278

MA-FL460

ASSORTED TERMINALS

SOLDERLESS

HI-TEMP

INSULATED

NON-INSULATED

RINGS

SPADES

QUICK

DISCONNECTS

WIRE TIES/

WIRE CONNECTORS

(ASSORTED SIZES AVAILABLE)

WIRE

TIES

WIRE

CONNECTORS

MA-49317

HAND TOOLS

2

Phone/Fax: [phone] MA-LINE www.ma-line.com

MECHANICAL

DOORS TO

PREVENT

WRONG

HOOK-UP

MA-33C

PALM SIZE DIGITAL

MULTI-METER

INCLUDES :

MA-DMTL1, MA-DMTP, CASE,

MANUAL & (1) 9V BATTERY

MA-MY69

AUTO-RANGING

DIGITAL

MULTI – METER

INCLUDES :

MA-DMTL1, MA-DMTK, CASE,

MANUAL & (1) 9V BATTERY

MA-12700A

MEGOHMMETER

AUTO-RANGING

INSULATION TESTER

INCLUDES:

TEST LEADS, CASE, MANUAL

& (6) AA BATTERIES

MA-12817B

DIGITAL

MULTI-METER

WITH TEMPERATURE

INCLUDES:

MA-DMTL1, MA-DMTK, CASE,

MANUAL, (1) 9V BATTERY

MECHANICAL

DOORS TO

PREVENT

WRONG

HOOK-UP

MA-12827

COMPACT DIGITAL

MULTI-METER

INCLUDES :

MA-DMTL1, MA-DMTKA, CASE,

MANUAL & (1) 9V BATTERY

MA-12837

AC/DC DIGITAL

MULTI-METER WITH

AUTO SELECTION

INCLUDES:

MA-DMTL1, CASE, MANUAL

& (1) 9V BATTERY

MA-12829

AUTO-RANGING

DIGITAL

MULTI-METER

INCLUDES:

MA-DMTL1, MA-DMTK1, CASE,

MANUAL & (1) 9V BATTERY

MA-12818

DIGITAL

MULTI-METER

INCLUDES:

MA-DMTL1, MA-DMTP, CASE,

MANUAL & (1) 9V BATTERY

FUNCTION

MA-33C

MA-MY69

MA-12700A

MA-12817B

MA-12827

MA-12837

MA-12829

MA-12818

DCV

200mV, 2000mV,

20V, 200V, 500V

400mV - 1000V

0.1mV

200mV, 2V, 20V,

200V, 1000V

1000V

600V

1000V

200mV,2V,20V,

200V, 1000V

ACV

(50/60Hz)

200V, 500V

400mV - 750V

100V,250V,

500V, 1000V

200mV,2V, 20V,

200V, 700V

1000V

600V

1000V

2V,20V,200V,

700V

DCA

2000µA, 20mA,

200mA, 10A

400uA - 10A

2mA, 20mA,
200mA, 10A

10A 10A

2mA, 200mA, 10A

ACA

400uA - 10A

2mA, 20mA,
200mA, 10A

10A 10A

20mA, 200mA,

10A

RESISTANCE

200Ω, 2000Ω,

20KΩ,200KΩ,

20MΩ

400Ω - 40MΩ

1MΩ - 20GΩ

200Ω,2kΩ, 20kΩ,

200kΩ, 2MΩ,

20MΩ, 200MΩ

40MΩ

60MΩ

40MΩ

200Ω, 2kΩ, 20kΩ,

200kΩ,2MΩ,

20MΩ,200MΩ

TEMPERATURE

-40F TO 1832F

(-40C TO 1000C)

-4F - 1400F

(-20C - 750C)

-40F TO 1832F

(-40C TO 1000C)

-58F TO 1832F

(-50C TO 1000C)

-58F TO 1832F

(-50C TO 1000C)

-20F TO 1832F

(-29C TO 1000C)

CAPACITANCE

4nF - 200uF

2nF, 20nF,

200nF,2uF, 200uF

200uF

30mF

100uF

20nF. 200nF, 20µF.

2000µF

FREQUENCY

100Hz - 10MHz

20kHz

10MHz

100kHz

10MHz

2000kHz

DUTY CYCLE

.1% - 99.9%

99.9%

99.9%

99.9%

DIODE TEST

* *

TRANSISTOR TEST

*

CONTINUITY

* * *

3

MA-DM1

DIGITAL MULTI-METER

INCLUDES :

MA-DMTL, CASE, MANUAL & BATTERIES

MA-DMT3

DIGITAL MULTI-METER

WITH TEMPERATURE

INCLUDES:

MA-DMTL, MA-DMTP, CASE, MANUAL &

BATTERIES

Phone/Fax: [phone] MA-LINE www.ma-line.com

MA-DMTL

TEST LEADS

MA-DMTP

TEMPERATURE

PROBE

MA-DMTKA

ADAPTOR FOR

THE MA-DMTK

MA-DMTK

K-PROBE

MA-DMTK1

K-PROBE WITH

ADAPTOR

MA-DMTL1

PROTECTIVE COVER

TEST LEADS

MA-12814

ANALOG MULTI-METER

UNIT SIZE: 3-1/2" X 2-1/4"

INCLUDES :

MA-DMTL4, MANUAL &

(1) AA BATTERY

MA-12816A

ANALOG MULTI-METER

UNIT SIZE: 5-1/2" X 3-3/4"

INCLUDES:

MA-DMTL, MANUAL,

(1) 9V BATTERY & (2) AA BATTERIES

MA-12823

ANALOG CLAMP-ON

METER

WITH TEMPERATURE

INCLUDES:

MA-DMTL, CASE, MANUAL

& (2) AA BATTERIES

FUNCTION

MA-12814

MA-12816A

MA-12823

DCV

1V,10V, 50V,

250V, 500V

0.1V, 0.5V,

2.5V, 10V,

50V, 250V,

1000V

75V

ACV

(50/60Hz)

1V,10V, 50V,

250V, 500V

10V, 50V,

250V, 1000V

150V,300V,

750V

DCA

500µA. 50mA,

250mA

50µA,

2.5mA,

25mA, .25A,

10A

ACA

6A, 15A, 150A,

600A

OHM

Rx 1k (Center

5K)

TEMPERATURE

-4F TO 300F

(-20C TO 150C)

RESISTANCE

x1, x10,

x100, x1K,

x10K

0-2kΩ,

0-200kΩ

CONTINUITY

DECIBEL AC

10V, 50V,

250V

ICEO

x1, x10 hFE x10 DIODE

x1K, x10, x1

FUNCTION

MA-DM1

MA-DMT3

DCV

200mV, 2V, 20V,

200V, 1000V

200mV, 2V, 20V,

200V, 1000V

ACV

(50/60Hz)

200V

(750V)

200V

(750V)

DCA

200µA, 2000µA,

20mA, 200mA, 10A

200µA, 2000µA,

20mA, 200mA, 10A

OHM

200Ω, 2000Ω,20KΩ.

200KΩ, 2000KΩ

200Ω, 2000Ω,20KΩ.

200KΩ, 2000KΩ

TEMPERATURE

NO

-58F TO 2498F

(-50C TO 1370C)

DIODE TEST

Test Current 1.6mA:

Voltage 2.8V

Test Current 1.6mA:

Voltage 2.8V

TRANSISTOR

TEST

0-1000 hFE of PNP or

NPN transistors

0-1000 hFE of PNP or

NPN transistors

TEST SIGNAL

50Hz test signal

appears between

VΩmA and COM

jacks

AUDIBLE

CONTINUITY

Red lead to VΩmA

and COM jacks

Black lead to COM

MA-12361

IMMERSION PROBE

MA-12362

AIR PROBE

4

Phone/Fax: [phone] MA-LINE www.ma-line.com

MA-600CFA

ECONOMY

AUTO-RANGING

CLAMP-ON METER

JAW OPENING: 1-1/8”

INCLUDES:

MA-DMTL1, MA-DMTK, CASE,

MANUAL & (1) 9V BATTERY

MA-12813

DELUXE DIGITAL

CLAMP-ON

METER

JAW OPENING : 1-1/2"

INDLUDES :

MA-DMTL1, MA-DMTP,

CASE, MANUAL & (1) 9V

BATTERY

MA-821

DIGITAL

CLAMP-ON METER

JAW OPENING: 1-1/4"

INCLUDES:

MA-DMTL, CASE, MANUAL

& (2) AAA BATTERIES

MA-823

DIGITAL CLAMP-ON

METER

WITH TEMPERATURE

JAW OPENING: 1-1/4"

INCLUDES:

MA-DMTL1, MA-DMTK1, CASE,

MANUAL & (2) AAA BATTERIES

MA-12826A

HVAC DIGITAL

CLAMP-ON METER

JAW OPENING : 3/4"

INCLUDES :

MA-DMTL1, MA-DMTP, CASE,

MANUAL & (2) AAA BATTERIES

MA-12822A

1000 AMP AC CURRENT

AUTO-RANGING LOW

TEMPERATURE

CLAMP-ON METER

JAW OPENING: 2-1/4”

INCLUDES:

MA-DMTL1, MA-DMTK,

CASE, MANUAL & (1) 9V BATTERY

FLAME SAFE

GUARD

CIRCUITS

WITH MAGNET

MICROAMPS

FUNCTION

MA-600CF

MA-3268C-6

MA-12813

MA-821

MA-823

MA-12822A

MA-12826A

DCV

200mV, 20V,

20V, 200V,

600V

200mV - 600V

600V

600V

40mV - 600V

400mV, 4V, 40V,

400V, 700V

600V

ACV

2V, 20V,

200V, 600V

2V – 600V

600V

600V

4V - 600V

4V, 40V, 400V,

1000V

600V

DCA

200A, 600A

400A, 1000A

4000uF

ACA

2A, 20A,

200A, 600A

2A – 400A

200A, 600A

2A, 20A,

200A,

600A

4A - 600A

400A. 1000A

400A, 1000A

RESISTANCE

200Ω, 2kΩ,

20kΩ,

200kΩ, 2MΩ,

20MΩ

200Ω - 20MΩ

2000Ω

20K -

20MΩ

400Ω,

4kΩ,40kΩ,

400kΩ, 4MΩ,

40MΩ

400MΩ

TEMP.

-38F TO 1750F

(-38C TO 950C)

-4F to 1400F

(-20C to 750C)

-4F TO 2498F

(-20C TO 1370C)

32F TO 752F

(0 - 400C)

-58F TO 1832F

(-50C TO 1000C)

-58F TO 2372F

(-50C TO 1300C)

OHM

400, 4K, 40K,

400K, 4M, 40M

CAPACITANCE

40nF, 400nF,

4uF, 100uF

40nF, 400nF,

4uF, 40uF, 100uF

100uF

FREQUENCY

50/60Hz

10HZ - 10MHZ

40, 400, 4K, 40K,

400K, 4MHz

150KHz

CONTINUITY

* * * * *

DIODE TEST

* * * *

MA-3268C-6

MINI AUTO-RANGING

CLAMP-ON METER

JAW OPENING: 7/8”

INCLUDES:

TEST LEADS, CASE, MANUAL &

(2) AAA BATTERIES

6/CASE OR

1/PKG

5

Phone/Fax: [phone] MA-LINE www.ma-line.com

MA-MHG-2

DIFFERENTIAL

PRESSURE GAUGE

0 - 2.0 INCHES OF

WATER COLUMN

MA-12353

AC CURRENT

CLAMP-ON

ADAPTOR

JAW OPENING: 1/2"

RANGE: 200A (AC)

INCLUDES: TEST LEADS

MA-12358

AC/DC CURRENT

CLAMP-ON

ADAPTOR

JAW OPENING: 1-1/8”

RANGE: 40 TO 400A (AC/DC)

NON-CONTACT VOLTAGE:

50 TO 600 VAC

INCLUDES:

TEST LEADS, CASE &

(2) AAA BATTERIES

MA-12355B

CLAMP-ON PROBE

K-TYPE

THERMOMETER

JAW OPENING 1-3/8"

TEMP:

-40F TO 392F (-40C TO 200C)
10’ LEAD

MA-12357A

STRAP-ON PROBE

K-TYPE

THERMOMETER

TEMP:

-4F TO 300F (-20C TO 149C)

MA-12356

CLAMP-ON PROBE

K-TYPE

THERMOMETER

JAW OPENING 1-1/4”

TEMP:

-40F TO 1100F (-40C TO 590C)

FUNCTION

MA-DLSN7

ACV

ACA

AIR PRESSURE

300 TO 1100hPA

TEMPEMPERATURE

-31F TO 176F

(-35C TO 80C)

HUMIDITY

0 TO 100%RH

READING MEMORY

31,998

MEASURING RATE

2 SEC TO 24HR

SOFTWARE

WINDOWS XP/

VISTA/

WINDOWS 7 & 8

BATTERY

(1) 3.6V

LITHIUM

AIR PRESSURE, HUMIDITY &

TEMPERATURE DATA LOGGER

MA-DLSN71

PRESSURE RATING:

15 PSI(1.03 BAR)

AMBIENT TEMPERATURE RANGE:

20F TO 140F (-70C TO 60C)

6

Phone/Fax: [phone] MA-LINE www.ma-line.com

MA-AN84A

DIGITAL MINI ANEMOMETER (CFM)

WITH MAGNET

INCLUDES: CASE, MANUAL, & (1) 9V BATTERY

MA-12843B

DIGITAL ANEMOMETER (CFM) WITH

FLEXIBLE NECK

INCLUDES: CASE, MANUAL & (1) 9V BATTERY

MA-010669

ENVIRONMENTAL KIT

INCLUDES:

(1) MA-AN84A – (1) MA-12838A –

1) MA-16531B

MA-12835B

DIGITAL DUAL DIFFERENTIAL

MANOMETER WITH MAGNET

INCLUDES: FLEXIBLE TUBING, 1/8”MPT X 1/8” BARB

ACCESS FITTING, CASE, MANUAL & (1) 9V BATTERY

MA-16531B

DIGITAL

PSYCHROMETER

WITH WET BULB
AND DEW POINT

WITH MAGNET

MA-16533

DIAGNOSTIC

PSYCHROMETER

TARGETS SUPER

HEAT &

EVAPORATOR

EXIT

TEMPERATURE

TEMP.

32F TO 122F

(0 TO 50C)

CFM

(CFM=ft³/min)

0-999.900

Ft./Min.

196-4900

M/S

1.00-25.00

Km/h

3.6-90.0

MPH

2.24-56.0

knots

1.94-48.5

TEMP.

14F TO 140F

(-10C TO 60C)

CFM

(CFM=ft³/min)

0-999.900

Ft./Min.

119-5900

M/S

.60-30.00

Km/h

2.2-108.00

MPH

1.4 -67.0

knots

1.2-58.0

inH2O

±55.40"

psi

±2

mbar

±137.8

kPa

±13.79

inHg

±0.407

mmHg

±103.4

ozin²

±32.00

ftH2O

±4.612

cmH2O

±140.6

kgcm²

±.140

bar

±.137

inH2O

±55.40"

psi

±2

mbar

±137.8

kPa

±13.79

inHg

±0.407

mmHg

±103.4

ozin²

±32.00

ftH2O

±4.612

cmH2O

±140.6

kgcm²

±.140

bar

±.137

MA-12838A

MINI DIGITAL DUAL DIFFERENTIAL

MANOMETER WITH MAGNET

INCLUDES: FLEXIBLE TUBING, 1/8”MPT X 1/8” BARB ACCESS

FITTING, CASE, MANUAL & (1) 9V BATTERY

FUNCTION

MA-16531B

MA-16533

HUMIDITY

0 TO 100% RH

0 TO 100% RH

TYPE K

-58F TO 2501F

(-50C TO 1372C)

NTC

32F TO 140F

(0 TO 60C)

DEW POINT

-22F TO 212

(-30C TO 100C)

-22F TO 199F

(-30C TO 100C)

WET BULB

32F TO 170F

(0 TO 80C)

32F TO 176F

(0 TO 80C)

TEMPERATURE

-22F TO 212F

(-30C TO 100C)

-30F TO 199F

(-30C TO 100C)

-55.40 TO +55.40IN
OF

WATER COLUMN

-55.40 TO +55.40IN
OF

WATER COLUMN

INCLUDES:

CASE, MANUAL, & (1) 9V BATTERY

INCLUDES:

MA-DMTK, CASE, MANUAL, & (1) 9V BATTERY

MA-SND80

SOUND LEVEL

METER

LEVEL RANGE:

LOA = 35-100Db

INCLUDES:

CASE, MANUAL & (1) 9V

BATTERY

7

MA-12701

DIGITAL PHASE

ROTATION INDICATOR

INCLUDES: TEST LEADS, CASE & MANUAL

MA-12702

MOTOR & PHASE ROTATION INDICATOR

INCLUDES: TEST LEADS, CASE & MANUAL

MA-12842A


NON-CONTACT

TACHOMETER

2.5 TO 99,999 RPM

INCLUDES:

CASE, MANUAL & (4) AA BATTERIES

MA-12844

REFLECTIVE

TAPE STRIPS

NOMINAL

VOLTAGE

1V TP 400V AC

NOMINAL

VOLTAGE PHASE

INDICATION

120V TO 400V

AC

FREQUENCY

2 TO 400Hz

MA-12821

WATT METER

FOR SINGLE PHASE

APPLICATIONS ONLY

WATTS

AC VOLTAGE

(45-60HZ)

0-2000W, 6000W

0-200V, 600V

DCV

0-200V, 1000V

INPUT

VOLTAGE/CURENT

0 TO 600ACV,

1 TO 10ACA

OVERLOAD

PROTECTION

600V

INPUT

IMPEDANCE

1MΩ

MA-12815A

DIGITAL

CAPACITOR TESTER

MA-12819

OPEN JAW CURRENT

AND VOLTAGE METER

DC/AC VOLTAGE & AC CURRENT

MA-12830A

CARBON MONOXIDE

DETECTOR

0 TO 1000 PPM

INCLUDES:

CASE, MANUAL &

(1) 9V BATTERY

MA-12830A-S

SENSOR ONLY

Phone/Fax: [phone] MA-LINE www.ma-line.com

MA-CO801

CARBON MONOXIDE

DETECTOR

TEMPERATURE:

-4F TO 122F (-20C TO 50C)
0 TO 1000 PPM

INCLUDES:

CASE, MANUAL &

(6) AAA BATTERIES

NOMINAL

VOLTAGE

40V TO 690V

AC

FREQUENCY

2 TO 400Hz

THIS UNIT DETECTS THE ROTARY FIELD OF

THREE PHASE SYSTEMS.

THIS UNIT DETERMINES MOTOR-ROTATION

DIRECTION AND DETECTS THE ROTARY

FIELD OF THREE PHASE SYSTEMS.

INCLUDES:

MA-DMTL1, CASE, MANUAL &

(1) 9V BATTERY

RANGE

RESOLUTION

200pF

0.1pF

2nF

1pF

20nF

10pF

200nF

100pF

2µF

1nF

200µF

10nF

200µF

100nF

2000µF

1uF

20mF

10uF

INCLUDES:

CASE, MANUAL &

(1) 9V BATTERY

FUNCTION

RANGE

DC VOLTAGE

600V

AC VOLTAGE

600V

AC CURRENT

200A

RESISTANCE

240MΩ

CAPACITANCE

200uF

FREQUENCY

9,999MHz

DUTY CYCLE

0.1% - 99.9%

CONTINUITY

BUTTON

*

DIODE TEST

CURRENT

0.3mA
Typical

IDEAL FOR MEASURING RPM ON

MOTORS, GEARS, PULLEYS,

COMPRESSORS AND MUCH MORE

INCLUDES:

TEST LEADS,

CASE, MANUAL

&

(2) AA

BATTERIES

8

Phone/Fax: [phone] MA-LINE www.ma-line.com

MA-7339

PEN PROBE STYLE DIGITAL

MULTI-METER

NOMINAL VOLTAGE RANGE :

12-600V AC/DC

INDICATION : 100-600V AC

TEST : 3 PHASE F WIRE SYSTEM, AC 50/60Hz

CONTINUITY : 0-1MΩ

INLCUDES :

MANUAL & (2) AAA BATTERIES

MA-EM3215

AUTO-RANGING

PROBE STYLE

DIGITAL MULTI-METER

MA-EM3213A

PEN PROBE STYLE

AUTO-RANGING DIGITAL

MULTI-METER WITH CAPACITANCE

VOLTAGE DC

200m,2V,20V,200V,

600V

VOLTAGE AC

2V,20V,200V, 600V

CURRENT DC

20, 200mA

CURRENT AC

20, 200mA

RESISTANCE

4KΩ,40KΩ, 400KΩ,

4MΩ

CAPACITANCE

40n,400n,4µ,40µ,

100µF

DIODE TEST

1.5V/.mA

CONTINUITY

*

INCLUDES:

MANUAL &

(1) CR2032 (3V) BATTERY

VOLTAGE DC

200m,2V,20V,200V,

600V

VOLTAGE AC

2V,20V,200V, 600V

CURRENT DC

20, 200mA

CURRENT AC

20, 200mA

RESISTANCE

200,2k,20k,200k,2M,

20MΩ

DIODE TEST

*

MA-12845A

MICROWAVE LEAK

DETECTOR

CALIBRATED: 2450MHZ

RANGE: 0-9.99 mW/cm²

WARNING VALUE: 5.0mW/cm²

INCLUDES:

CASE, MANUAL & (1) 9V BATTERY

MA-MMD3EA

LCD MOISTURE

INDICATOR FOR

WOOD, DRYWALL OR

CONCRETE

INCLUDES:

REPLACEABLE TEST PROBE PINS,

MANUAL & (1) LR44 BATTERY

MEASURES MOISTURE

FROM 0 T0 100%

MA-7409

LASER TAPE MEASURE

MEASURE DISTANCE, HEIGHT,

AREA AND VOLUME

INCLUDES:

CASE, MANUAL & (1) 9V BATTERY

MEASUREMENT RANGE:

2FT TO 50FT
(0.6 TO 15M)

APPROXIMATELY

MA-S3003

POWER METAL/

STUD SENSOR

Electronically locates cables, gas and water pipes. Traces hidden ceiling

hoists and wall studs. Helps prevent accidents when drilling or sawing.

Senses the presence of main power without touching live wires.

The units LED will flash and alarm will sound when detecting leak

above 5mW/cm².

INCLUDES:

MANUAL & (1) 9V BATTERY

MA-CGD383

COMBUSTIBLE GAS

DETECTOR

GASOLINE/PROPANE/

NATURAL GAS/

FUEL OIL DETECTION

INCLUDES:

SMALL JAR OF LEAK CHECK,

HARD CARRYING CASE, MANUAL

& (4) AA BATTERIES

MA-149

MA-157A

MA-142A

2-1/4" ROUND MIRROR EXTENDS TO 20"

MA-142MA

2-1/4" ROUND MIRROR MAGNIFIED INSPECTION

MIRROR EXTENDS TO 27"

MA-143A

1-1/4" ROUND MIRROR EXTENDS TO 25"

MA-143M

1-1/4" ROUND MIRROR MAGNIFIED INSPECTION

MIRROR EXTENDS TO 25"

MA-149

2-1/8" X 3-1/2" RECTANGULAR MIRROR

EXTENDS TO 20"

MA-157A

1" X 2" OVAL MIRROR EXTENDS TO 25"

MA-IM24

RECTANGLE
TELESCOPIC

INSPECTION

MIRROR WITH 2 LEDS

MA-IM30

ROUND TELESCOPIC

INSPECTION MIRROR

WITH 2 LEDS

MA-SM6

1-1/4" X 2" RECTANGLE

EXTENDS TO 27"

MA-SM7

2" X 3-3/4" RECTANGLE

EXTENDS TO 27”

MA-SM8

3-3/4" ROUND

EXTENDS TO 27”

MA-142A/ MA-142MA

MA-143A/MA-143M

TELESCOPIC INSPECTION MIRRORS

VIDEO BORESCOPE

WITH CASE

MA-VID-1 3' TUBE LENGTH
MA-VID-2 3' TUBE LENGTH

PLUS 10’EXTENSION

STAINLESS STEEL TELESCOPIC

MIRRORS

Phone/Fax: [phone] MA-LINE www.ma-line.com

MA-157-1

1" X 2" OVAL

RANGE

RESOLUTION

COLOR MOSAIC

RGB BAYER PATTERN

VIDEO FORMAT

NTSC COMPOSITE

VIDEO

CAMERA

ILLUMINATION

2 LEDS, WHITE

METAL TUBE

LENGTH

35- 3/4"

DIAMETER OF

CAMERA HEAD

OUTER DIAMETER 3.93"

WATER RESISTANT IP67 CAMERA HEAD:

OUTER DIA. 3.93” WITH TWO DIMMABLE LEDS

LENS: F# 2.8

VIEWABLE OF ANGLE: 54°

FOCAL DISTANCE: 1-1/4” TO 2-1/4”

2.4” TFT LCD: 480 X 234 RESOLUTION

3 BUTTON OPERATION WITH UP/DOWN KEYS

PRESS UP/DOWN KEYS SIMUTANOUSLY TO

ROTATE PICTURE 180°

INCLUDES: CASE, MANUAL

& (4) AA BATTERIES

ADJUSTS TO ANY ANGLE
MIRROR SIZE: 2” X 3-1/4”

LENGTH: 11-2/5”

EXTENDS TO: 34-1/2”

STAINLESS STEEL SHAFT

WITH VINYL GRIP HANDLE

INCLUDES:

(2) CR2032 BATTERIES

ADJUSTS TO ANY ANGLE

MIRROR SIZE: 3”

LENGTH: 11-1/8”

EXTENDS TO: 34-1/4”

STAINLESS STEEL SHAFT

WITH VINYL GRIP HANDLE

INCLUDES:

(1) CR2032 BATTERY

REPLACEMENT GLASS

**MIRROR ONLY**

MA-142-1

2-1/4" ROUND

MA-149-1

2-1/8" X 3-1/2" RECTANGLE

INCLUDES THE FOLLOWING ACCESSORIES:

HOOK FOR RECOVERING PARTS

MAGNET FOR RETRIEVING METALLIC PARTS

10

Phone/Fax: [phone] MA-LINE www.ma-line.com

MA-16509B

MINI INFRARED

THERMOMETER

MA-16551

INFRARED

THERMOMETER

MA-16505A

INFRARED

THERMOMETER

K TYPE PROBE

MA-16506

INFRARED

THERMOMETER

WITH DUAL LASER

TARGETING

MA-IRT203B

SHIRT

POCKET LASER

THERMOMETER

MA-16501 & MA-16513

HIGH & LOW

TEMPERATURE

INFRARED

THERMOMETER

MA-16507

INFRARED

THERMOMETER

WITH 16"

FLEXIBLE NECK

FUNCTION

MA-IR9PEN

MA-16C81

MA-16501

MA-16505A

MA-16506

MA-16507

MA-16509B

MA-16513

MA-16551

MA-IRT203B

TEMP. F/C

-27F ~ 932F
(-33C ~ 500C)

-36F ~ 968F
(-38C ~ 520C)

-58F ~ 1832F

(-50C ~ 1000C)

-58F ~ 1472F

(-50C ~ 800C)

-58F ~ 1202F

(-50C ~ 650C)

-58F ~ 1112F

(-50C ~ 600C)

-58F ~ 1022F

(-50C ~ 550C)

-58F ~ 932F

(-50C ~ 500C)

50F ~ 1900F

(-45C ~ 1035C)

-58F ~ 518F

(-50C ~ 270C)

K-PROBE

-58F ~ 1472F

(-50C ~ 800C)

RATIO

9:1

8:1

12:1

12:1

12:1

8:1

10:1

12:1

50:1

6:1

EMISSIVITY

.95 FIXED

.10 TO 1.0

ADJ.

.1 TO 1.0

ADJ.

.95 FIXED

.10 TO 1.0

ADJ.

F/C

SWITCHABLE

*

*

* * * * * * *

*

MAX/MIN/

DIF/AVG

RECORD

*

* *

DATA HOLD

* * * * * * *

BACKLIGHT

*

*

* * * * * * *

*

AUTO SHUT

OFF

* * * * * * * *

HIGH/LOW

ALARM

* * BATTERY

(1)AA

(2) AAA

(1) 9V

(1) 9V

(1) 9V

(1) 9V

(1) 9V

(1) 9V

(1) 9V

CASE

*

*

* * * * * * *

MA-IR9PEN

POCKET

INFRARED

THERMOMETER

MA-16C81

COLOR INFRARED

THERMOMETER

SETTING OR

READNG

TEMP.

TEMP.

REACHES

BELOW SET

TEMP.

TEMP.

REACHES

ABOVE SET

TEMP.

11

MA-RT343

ROTARY PROBE POCKET

DIGITAL THERMOMETER

TEMPERATURE RANGE:

-58F TO 392F (-50C TO 200C)
F/C SWITCHABLE

WIDE MEASUREMENT RANGE

MIN/MAX TEMPERATURE MEMORY

DATA HOLD FUNCTION

STAINLESS STEEL PROBE – 4-1/2”

ROTARY PROBE DESIGN

HIGH/LOW TEMPERATURE ALARM SETTING

FOR USE IN FOOD PROCESSING,

REFRIGERATION, LABORATORY &

GREENHOUSE

MA-RT900A

HAND HELD DIGITAL

THERMOMETER

TEMPERATURE RANGE:

-58F TO 392F (-50C TO 200C)
F/C SWITCHABLE

WIDE MEASUREMENT RANGE

MIN/MAX TEMPERATURE MEMORY

DATA HOLD FUNCTION

STAINLESS STEEL PROBE

MAGNET ON BACK & FOLDING STAND

NEVER NEEDS TO BE CALIBRATED

MA-RT335

DIGITAL

THERMOMETER

ANTI-ROLLING OVAL DESIGN

DIGITAL THERMOMETER

180 DEGREE

ROTATING HEAD

TEMPERATRUE RANGE:

-58F TO 302F (-50C TO 150C)

ON/OFF SWITCH AND AUTOMATIC

SHUT OFF AFTER 10 MIN.

IT’S UNIQUE FEATURE IS THE 180°

ROTATING HEAD

MA-RT340 WITH 5" STEM

MA-RT340LS WITH 8" STEM

MA-16532

2 IN 1 DIGITAL HUMIDITY

AND TEMPERATURE METER

TEMPERATURE RANGE:

-4F TO 140F (-20C TO 60C)

HUMIDITY: 0 TO 100% RH

F/C SWITCHABLE

MIN, MAX, DATA HOLD FUNCTION

DUAL LCD DISPLAY – AUTO POWER OFF –

BACKLIGHT BUTTON

INCLUDES:

CASE, MANUAL & (1) 9V BATTERY

Phone/Fax: [phone] MA-LINE www.ma-line.com

MA-DMT123

DUAL PROBE DIGITAL

THERMOMETER

TEMPERATURE RANGE:

-328F TO 2498F (-200C TO 1370C)

F/C SWITCHABLE

4” LCD DUAL DISPLAY

RELATIVE FUNCTIONS, MIN, MAX, AVG, HOLD

MA-DMT123KIT

DUAL PROBE

DIGITAL

THERMOMETER KIT

(SUPER HEAT KIT)

INCLUDES:

1) MA-DMT123

2) K-TYPE PROBES

2) MA-12355B WITH 10’ LEADS

INCLUDES:

(2) MA-DMTK, CASE,

MANUAL &

(1) 9V BATTERY

GREAT FOR SUPER HEAT

INCLUDES:

(1) AAA BATTERY

INCLUDES:

(1) AAA BATTERY

TEMPERATURE RANGE:

-58F TO 302F (-50C TO 150C)
F/C SWITCHABLE

ON/OFF SWITCH

AUTOMATIC SHUT OFF AFTER 10 MIN.

INCLUDES:

(1) 1.5V BATTERY

MA-RT330

DIGITAL

THERMOMETER

ANTI-ROLLING DESIGN

INCLUDES:

(1) 1.5V BATTERY

TEMPERATURE RANGE:

-58F TO 392F (-53C TO 200C)
F/C SWITCHABLE

ON/OFF SWITCH

INCLUDES:

(2) 1.5V BATTERY

12

MA-RT818

DIGITAL POCKET THERMOMETER

WITH LARGE DISPLAY

F/C SWITCHABLE - STAINLESS STEEL STEM - ON/OFF SWITCH –

AUTO OFF - HIGH/LOW TEMPERATURE RECALL -

DATA HOLD - WATER RESISTANCE

MA-ST200

PIPING THERMOMETER

TEMPERATURE RANGE:

-50F TO 250F (-40C TO 120C)

2 DIAL SPRING MOUNTED OR

SURFACE THERMOMETER

DESIGNED TO MEASURE SURFACE

TEMPERATURES OF PIPES,

CYLINDERS, SPINDLES, ETC. BETWEEN

3/4"OD TO 6”OD

KIT INCLUDES:

2 CLASP AND 3 DIFFERENT SIZES OF

HIGHLY RESILIENT STAINLESS STEEL

MA-PT160 (12/CASE)
MA-PT160B (1/PKG)

1" DIAL -40F TO 160F

MA-PT220 (12/CASE)
MA-PT220B (1/PKG)

1" DIAL 0 TO 220F

MA-PT550 (12/CASE)

1" DIAL 50F TO 550F

MA-PT70C (12/CASE)

1" DIAL -40C TO 70C

MA-PT110C (12/CASE)

1" DIAL -10C TO 110C

MA-PT138160 (12/CASE)

1-3/8" DIAL -40F TO 160F

MA-PT138220 (12/CASE)

1-3/8" DIAL 0 TO 220F

MA-PT134160 (1/PKG)

1-3/4" DIAL -40F TO 160F

MA-PT134220 (1/PKG)

1-3/4" DIAL 0 TO 220F

MA-PDT392B (1/PKG.)

DIGITAL POCKET THERMOMETER

MA-PDT392B-12 (12/CS)

DIGITAL POCKET THERMOMETER

F/C SWITCHABLE - STAINLESS STEEL STEM - ON/OFF SWITCH –

AUTO OFF - HIGH/LOW TEMPERATURE RECALL -

DATA HOLD - WATER RESISTANCE

Phone/Fax: [phone] MA-LINE www.ma-line.com

MA-RT819

BIG DIGIT PEN SHAPE

HYGRO THERMOMETER

F/C SWITCHABLE - MAX/MIN READING MEMORY -

DUAL DISPLAY FOR TEMPERATURE & HUMIDITY

POCKET STICK THERMOMETER

MA-PS120 -40F TO 160F (12/CTN)

MA-PS220 0F TO 220F (12/CTN)

FAHRENHIET SCALE – 5” IN LENGTH – SPIRIT FILLED

INCLUDES:

(1) 1.5V BATTERY

INCLUDES:

(1) 1.5V BATTERY

INCLUDES:

(1) AAA BATTERY

TEMP. RANGE:

32F TO 122F (0 TO 50C)

HUMIDITY:

20% TO 95% RH

TEMP. RANGE:

-40F TO 392F (-40C TO 200C)

TEMP. RANGE:

-40F TO 392F

(-40C TO 200C)

ADJUSTABLE POCKET

THERMOMETERS

WITH CASE AND 5" STEM

13

MA-ETP110

HUMIDITY ALARM

MEASURES TEMPERATURE,

RELATIVE HUMIDITY, AND DEW

POINT

TEMP. RANGE:

14F TO 140F (-10C TO 60C)

HUMIDITY: 20% TO 95%

DEW POINT:

-20.2F TO 138.2F (-29C TO 59C)

MA-1660A

FREEZER ALERT

ALARM SOUNDS WHEN FOOD

STARTS TO DEFROST

112” TEMP. PROBE

MA-1665C

FLOOD
ALERT

DETECTS WATER

OVERFLOW.

112” SENSOR

CABLE

INCLUDES:

(1) AA BATTERY

MA-BDIOT

INDOOR TEMP: -4F TO 122F (-20C TO 50C)

OUTDOOR TEMP: -4F TO 122F (-20C TO 50C)

MA-BDHTR

INDOOR TEMP: -58F TO 158F (-50C TO 70C)

OUTDOOR TEMP: -58F TO 158F (-20C TO 70C)

HUMIDITY: 20% TO 90%

INDOOR/OUTDOOR

THERMOMETER WITH CLOCK

INSTANT F/C SWITCH – WALL MOUNT OR

TABLE DESIGN – TIME, DATE DISPLAY &

ALARM – 12/24 HOURS SYSTEM CLOCK

MA-RT1

REFRIG./FREEZER THERM.

TEMPERATURE RANGE:

-20F TO 80F (-30C TO 30C)

MA-OVN1

OVEN THERMOMETER

TEMPERATURE RANGE:

100F TO 550F (-50C TO 300C)

MA-SUT45

STICK-UP THERMOMETER

TEMPERATURE RANGE:

-20F TO 120F (-30C TO 50C)

MA-HRFT1

HORIZONTAL

REFRIG./FREEZER THERM.

TEMPERATURE RANGE:

-40F TO 80F (-40C TO 30C)

MA-1001S

SOLAR HORIZONTAL

THERMOMETERS

TEMPERATURE RANGE:

-58F TO 302F (50C TO 150C)

F/C SWITCHABLE – 48” CAPILLARY –

1-1/2” X 1/2" DISPLAY

MA-RT8101

SOLAR POWERED DIGITAL

THERMOMETER

TEMPERATURE RANGE:

INTERNAL SENSOR:

32F TO 122F (0 TO 500C)

EXTERNAL SENSOR:

-58F TO 158F (-50TO 70C)

F/C SWITCHABLE - MAX/MIN MEMORY

MA-2001S 2" DIAL, FRONT FLANGE, W/48" CAPILLARY
MA-2002S 2" DIAL, BACK FLANGE, W/48" CAPILLARY
MA-2003S 2" DIAL U-CLAMP, W/48" CAPILLARY

REMOTE READING

SOLAR

THERMOMETERS

TEMPERATURE RANGE:

-58F TO 302F (-50C TO 150C)
F/C SWITCHABLE

ALL STAINLESS STEEL CASE

REMOTE READING

VAPOR TENSION

THERMOMETERS

TEMPERATURE RANGE:

-40F TO 60F (-40C TO 15C)

ALL STAINLESS STEEL CASE

MA-50ABF 2" DIAL, BACK FLANGE, W/60" CAPILLARY
MA-60A 2-1/2" DIAL, STRAP MOUNT, W/60" CAPILLARY
MA-60AFF 2-1/2" DIAL, FRONT FLANGE, W/60" CAPILLARY

MA-RT8100

FRIDGE/FREEZER

THERMOMETER

WITH ALARM

TEMPERATURE RANGE:

-40F TO 158F (-40C TO 70C)

F/C SWITCHABLE – ALARM – DUAL

DISPLAY – MIN/MAX MEMORY –

MAGNET, DESK STAND

& TWO SUCTIONS CUPS

Phone/Fax: [phone] MA-LINE www.ma-line.com

INCLUDES:

(1) AA

BATTERY

INCLUDES:

(1) AAA BATTERY

INCLUDES: (2) AAA

BATTERIES

(2) AAA BATTERIES NOT INCLUDED

14

Phone/Fax: [phone] MA-LINE www.ma-line.com

MA-CVT316

3/16"ID X 100'

MA-CVT14

1/4"ID X 100'

MA-CVT38

3/8"ID X 100'

MA-CVT12

1/2"ID X 100'

MA-HDT316

3/16”ID X 50’

MA-HDT14

1/4"ID X 50'

MA-HDT38

3/8"ID X 50'

MA-HDT12

1/2"ID X 50'

ALUMINUM TUBING 5’ KIT

INCLUDES FITTINGS

50’ COILS ALUMINUM TUBING

WITHOUT FITTINGS

MA-AT18 1/8"OD
MA-AT316 3/16"OD
MA-AT14 1/4"OD
MA-AT516 5/16"OD

MA-AT38 3/8"OD
MA-AT716 7/16"OD
MA-AT12 1/2"OD
MA-AT58 5/8"OD

5’ SQUARE BLACK NEOPRENE TUBING

MA-SNAT316-5

BLACK NEOPRENE

AIR TUBING

MA-NAT18-5 1/8"ID X 5'
MA-NAT316-5 3/16"ID X 5'
MA-NAT316 3/16"ID X 100'

RED SILICONE RUBBER TUBING

FLEXOGEN GARDEN

HOSE

MA-GH25

5/8"ID GREY 25' LONG

MA-GH50

5/8"ID GREY 50' LONG

INSULATED SPRAY NOZZLE

6 SPRAY PATTERNS

MA-572A

SOAKER, SHOWER, CONE, FLAT,

MIST AND JET

MA-W455

HOSE WASHERS (10/PK)

POLYETHYLENE TUBING

HEAT SHRINK

TUBING

MA00478-1 ASSORTED 3/16", 1/4" & 3/8" (8/PK)
MA00479-1 ASSORTED 1/2", 3/4" & 1" (5/PK)
MA00480-1 ASSORTED 1/16" THRU 1" (7/PK)
MA03383-1 1/8" (10/PK) MA03391-1 1/2" (5/PK)
MA03385-1 3/16" (8/PK) MA03393-1 3/4" (4/PK)
MA03387-1 1/4" (7/PK) MA03394-1 1" (3/PK)
MA03389-1 3/8" (10/PK) ** TUBING IS 4" IN LENGTH

MA-CVT58

5/8"ID X 100'

MA-CVT34

3/4"ID X 100'

MA-CVT78

7/8"ID X 50'

MA-CVT1

1"ID X 50'

CLEAR VINYL

TUBING

PILOT LIGHT (BREAKAWAY) FITTINGS

MA-PT516

5/16"OD X 100'

RUBBER DRAIN LINE ELBOWS

MA-38RUEL 3/8" I.D.
MA-34RUEL 3/4" I.D.

MA-SRT18-5 1/8"ID X 5/16"OD
MA-SRT316-5 3/16"ID X 5/16"OD
MA-SRT14-5 1/4"ID X 3/8"OD

MA-AT14-5 1/4"
MA-AT18-5 1/8"

MA-AT316-5 3/16"
MA-AT38-5 3/8"

5' LENGTH

181SP-02 1/8"
181SP-03 3/16"

181SP-04 1/4"
181SP-06 3/8"

Nut with breakaway sleeve screws into gas control
valves for furnaces, water heaters, etc. Fittings are sold individually.

MA-PT14

1/4"OD X 100'

MA-PT38

3/8"OD X 100'

FOR QUICK

DISCONNECT

AND

RECONNECT

OF DRAIN

LINE

ASTM: B483

ALLOY: 3003

WALL THICKNESS: .035

MA-HDT58

5/8"ID X 50'

MA-HDT34

3/4"ID X 50'

MA-HDT78

7/8"ID X 50'

MA-HDT1

1"ID X 50'

HEAVY DUTY BRAIDED TUBING

15

Phone/Fax: [phone] MA-LINE www.ma-line.com

MICRO GEAR HOSE CLAMP

1/4" HEX HEAD

ZINC-PLATED CARBON STEEL SCREW

300 STAINLESS BAND & HOUSING

TINY BUT TOUGH

COMBO-HEX CLAMP

3/8" HEX HEAD COLLARED SCREW

ZINC-PLATED CARBON STEEL SCREW

300 STAINLESS BAND & HOUSING

MICRO CLAMPS

COMBO CLAMPS

10/BOX – SOLD PER BOX

MA-6202BX SIZE 04, 1/4" TO 5/8" DIA.
MA-6203BX SIZE 06, 5/16" TO 7/8" DIA.
MA-6204BX SIZE 12, 3/4" TO 1-1/4" DIA.
MA-6205BX SIZE 16, 13/16" TO 1-1/2" DIA.
MA-6206BX SIZE 20, 7/8" TO 1-3/4" DIA.

10/BOX – SOLD PER BOX

MA-5406BX SIZE 06, 1/2" TO 7/8" DIA.
MA-5408BX SIZE 08, 9/16" TO 1" DIA.
MA-5410BX SIZE 10, 11/16" TO 1-1/16" DIA.
MA-5412BX SIZE 12, 11/16" TO 1-1/4" DIA.
MA-5416BX SIZE 16, 13/16" TO 1-1/2" DIA.
MA-5420BX SIZE 20, 13/16" TO 1-3/4" DIA.
MA-5428BX SIZE 28, 1-5/16" TO 2-1/4" DIA.
MA-5432BX SIZE 32, 1-9/16" TO 2-1/2" DIA.
MA-56188 SIZE 188, 11" TO 12" DIA.

HANGING WIRE

18 GAUGE

MA-HWA02 2LB. BLACK ANNEALED WIRE
MA-HWA05 5LB. BLACK ANNEALED WIRE
MA-HWG02 2LB. GALVANIZED WIRE
MA-HWG05 5LB. GALVANIZED WIRE

PLASTIC HANGING STRAP

MA-PH50 3/4" X 50'
MA-PH100 3/4" X 100'

USED AS PIPE HANGER, DUCT HANGER,
TUBING STRAP AND UTILITY STRAP

PERFORATED STRAPS

20 GAUGE

MA-GF1 3/4" X 10' GALVANIZED
MA-GF-50 3/4" X 50' GALVANIZED
MA-GF-100 3/4" X 100' GALVANIZED
MA-CF1 3/4" X 10' COPPER
MA-CF-50 3/4" X 50' COPPER
MA-CF-100 3/4" X 100' COPPER

J-HOOKS 20 GAUGE

MA-J1500 1-1/2" DRAIN PIPE HOLDER
MA-J2000 2" DRAIN PIPE HOLDER
MA-J3000 3" DRAIN PIPE HOLDER
MA-J4000 4" DRAIN PIPE HOLDER
MA-SH1500 1-1/2" SWIVEL ADJ. HANGER
MA-SH2000 2" SWIVEL ADJ. HANGER
MA-SH3000 3" SWIVEL ADJ. HANGER
MA-SH4000 4" SWIVEL ADJ. HANGER

The hangers hold pipe firmly and it eliminates noise from vibrating pipes.
Includes nails to prevent soldering and eliminates hanger/pipe corrosion and
electrolysis. The SH series has a rotating feature to hang pipe on an angle.

1-HOLE PIPE CLAMPS

HANGING THINWALL CONDUIT
GALVANIZED

MA-DT12 1/2" ID (100/PKG)
MA-DT34 3/4" ID (100/PKG)
MA-DT1 1" ID (50/PKG)
MA-DT114 1-1/4" ID (25/PKG)
MA-DT112 1-1/2" ID (25/PKG)
MA-DT2 2" ID (25/PKG)

MA-10DT12 1/2" ID (10/PKG)
MA-10DT34 3/4" ID (10/PKG)
MA-5DT1 1" ID (5/PKG)
MA-5DT114 1-1/4" ID (5/PKG)
MA-5DT112 1-1/2" ID (5/PKG)

2-HOLE TUBING CLAMPS

HANGING THINWALL CONDUIT

MA-BT12 1/2" ID (250/PKG)
MA-BT34 3/4" ID (200/PKG)
MA-BT1 1" ID (100/PKG)
MA-BT114 1-1/4" ID (50/PKG)
MA-BT112 1-1/2" ID (50/PKG)
MA-BT2 2" ID (25/PKG)

HANGING COPPER TUBING

MA-BC14 1/4" ID (500/PKG)
MA-BC38 3/8" ID (500/PKG)
MA-BC12 1/2" ID (250/PKG)
MA-BC34 3/4" ID (150/PKG)
MA-BC1 1" ID (100/PKG)
MA-BC114 1-1/4" ID (50/PKG)
MA-BC112 1-1/2" ID (50/PKG)
MA-BC2 2" ID (25/PKG)

CONDUIT PIPE CLAMPS WITH BOLTS

MA-K12 1/2" ID (100/PKG)
MA-K34 3/4" ID (100/PKG)
MA-K1 1" ID (100PKG)
MA-K114 1-1/4" ID (100/PKG)
MA-K112 1-1/2" ID (100/PKG)
MA-K2 2" ID (50/PKG)
MA-K212 2-1/2" ID (50/PKG)
MA-K3 3" ID (25/PKG)

GALVANIZED

COPPER

HANGING BLACK IRON PIPE

MA-NW124 1/2" X 4"
MA-NW126 1/2" X 6"
MA-NW128 1/2" X 8"
MA-NW1210 1/2" X 10"
MA-NW344 3/4" X 4"
MA-NW346 3/4" X 6"
MA-NW348 3/4" X 8"
MA-NW3410 3/4" X 10"
MA-NW16 1" X 6"
MA-NW18 1" X 8"
MA-NW110 1" X 10"
MA-NW1146 1-1/4" X 6"
MA-NW1148 1-1/4" X 8"
MA-NW114101-1/4" X 10"
MA-NW1126 1-1/2" X 6"
MA-NW1128 1-1/2" X 8"
MA-NW11210 1-1/2" X 10"

HANGING
CONDUIT

OR

IRON PIPE

HANGING COPPER TUBE

MA-NW124-C 1/2" X 4"
MA-NW126-C 1/2" X 6"
MA-NW128-C 1/2" X 8"
MA-NW344-C 3/4" X 4"
MA-NW346-C 3/4" X 6"
MA-NW348-C 3/4" X 8"
MA-NW16-C 1" X 6"
MA-NW18-C 1" X 8"
MA-NW1146-C 1-1/4" X 6"
MA-NW1148-C 1-1/4" X 8"
MA-NW1126-C 1-1/2" X 6"
MA-NW1128-C 1-1/2" X 8"

9 GAUGE WIRE

50/BOX

25 PER BAG

WIRE PIPE HANGERS

HWA = TENSILE STRENGTH – 60,000 – 75,000
HWG = TENSILE STRENGTH – 95,000 – 115,000

16

Phone/Fax: [phone] MA-LINE www.ma-line.com

BUSS FUSES

DUAL ELEMENT

TIME DELAY, 250V,

CLASS RK5 FUSES

BUSS FUSES

DUAL ELEMENT

TIME DELAY, 600V,

CLASS RK5 FUSES

BUSS HEATING

& A/C FUSES

TIME DELAY, 250V

CURRENT LIMITING,

CLASS RK5,

UL LISTED,

CSA CERTIFIED

BUSS HEATING

& A/C FUSES

TIME DELAY, 600V

CURRENT LIMITING,

CLASS RK5,

UL LISTED,

CSA CERTIFIED

PART # AMP PKG

MA-FRNR1 1 10
MA-FRNR1.25 1.25 10
MA-FRNR1.6 1.6 10
MA-FRNR2 2 10
MA-FRNR2.5 2.5 10
MA-FRNR3.2 3.2 10
MA-FRNR4 4 10
MA-FRNR5 5 10
MA-FRNR6.25 6.25 10
MA-FRNR8 8 10
MA-FRNR10 10 10
MA-FRNR12 12 10
MA-FRNR15 15 10
MA-FRNR20 20 10
MA-FRNR25 25 10
MA-FRNR30 30 10
MA-FRNR35 35 10
MA-FRNR40 40 10
MA-FRNR45 45 10
MA-FRNR50 50 10
MA-FRNR60 60 10
MA-FRNR70 70 5
MA-FRNR80 80 5
MA-FRNR90 90 5
MA-FRNR100 100 5
MA-FRNR110 110 1
MA-FRNR125 125 1
MA-FRNR150 150 1
MA-FRNR175 175 1
MA-FRNR200 200 1
MA-FRNR225 225 1

PART # AMP PKG

MA-FRSR1 1 10
MA-FRSR1.25 1.25 10
MA-FRSR1.6 1.6 10
MA-FRSR2 2 10
MA-FRSR2.5 2.5 10
MA-FRSR3.2 3.2 10
MA-FRSR4 4 10
MA-FRSR5 5 10
MA-FRSR6.25 6.25 10
MA-FRSR8 8 10
MA-FRSR10 10 10
MA-FRSR12 12 10
MA-FRSR15 15 10
MA-FRSR20 20 10
MA-FRSR25 25 10
MA-FRSR30 30 10
MA-FRSR35 35 10
MA-FRSR40 40 10
MA-FRSR45 45 10
MA-FRSR50 50 10
MA-FRSR60 60 10
MA-FRSR70 70 5
MA-FRSR80 80 5
MA-FRSR90 90 5
MA-FRSR100 100 5
MA-FRSR110 110 1
MA-FRSR125 125 1
MA-FRSR150 150 1
MA-FRSR175 175 1
MA-FRSR200 200 1
MA-FRSR225 225 1

PART # AMP PKG

MA-ECNR3.2 3.2 10
MA-ECNR5 5 10
MA-ECNR6.25 6.25 10
MA-ECNR10 10 10
MA-ECNR15 15 10
MA-ECNR20 20 10
MA-ECNR25 25 10
MA-ECNR30 30 10
MA-ECNR35 35 10
MA-ECNR40 40 10
MA-ECNR45 45 10
MA-ECNR50 50 10
MA-ECNR60 60 10
MA-ECNR70 70 5
MA-ECNR80 80 5
MA-ECNR100 100 5
MA-ECNR125 125 1
MA-ECNR200 200 1

PART # AMP PKG

MA-ECSR10 10 10
MA-ECSR15 15 10
MA-ECSR20 20 10
MA-ECSR25 25 10
MA-ECSR30 30 10
MA-ECSR35 35 10
MA-ECSR40 40 10
MA-ECSR45 45 10
MA-ECSR50 50 10
MA-ECSR60 60 10
MA-ECSR70 70 5
MA-ECSR80 80 5
MA-ECSR90 90 5
MA-ECSR100 100 5
MA-ECSR125 125 5
MA-ECSR150 150 1
MA-ECSR200 200 1

FRNR & FRSR

SERIES

ECNR & ECSR

SERIES

BUSS ONE TIME FUSE

250 VOLT

PART # AMP PKG

MA-NON45 45 10
MA-NON50 50 10
MA-NON60 60 10
MA-NON70 70 5
MA-NON80 80 5
MA-NON100 100 5
MA-NON150 150 1
MA-NON175 175 1
MA-NON200 200 1

PART # AMP PKG

MA-NON1 1 10
MA-NON3 3 10
MA-NON6 6 10
MA-NON10 10 10
MA-NON15 15 10
MA-NON20 20 10
MA-NON25 25 10
MA-NON30 30 10
MA-NON35 35 10

MA-NON40 40 10

BUSS S PLUG FUSES TIME DELAY, 250 VOLT

PART # AMP PKG

MA-S1A 1 4
MA-S11/4A 1.25 4
MA-S16A 1.6 4
MA-S2A 2 4
MA-S21/2A 2.5 4
MA-S32 3.2 4
MA-S4A 4 4
MA-S5A 5 4

PART # AMP PKG

MA-S6A 6 4
MA-S61/4A 6.25 4
MA-S8A 8 4
MA-S10A 10 4
MA-S12A 12 4
MA-S15A 15 4
MA-S20A 20 4
MA-S25A 25 4
MA-S31A 30 4

TYPE S

FUSE

ADAPTOR

PART # AMP PKG

MA-16SA 1.6 4
MA-21/2SA 2.5 4
MA-32SA 3.2 4
MA-61/4SA 6.25 4
MA-15SA 15 4
MA-20SA 20 4

PART # AMP PKG

MA-30SA 30 4

BUSS T PLUG FUSES

TIME DELAY, 250 VOLT

PART # AMP PKG

MA-T1A 1 4
MA-T11/4A 1.25 4
MA-T16A 1.6 4
MA-T2A 2 4
MA-T21/2A 2.5 4
MA-T32A 3.2 4
MA-T4A 4 4
MA-T5A 5 4

PART # AMP PKG

MA-T61/4A 6.25 4

MA-T7A 7 4

MA-T8A 8 4
MA-T10A 10 4
MA-T12A 12 4
MA-T15A 15 4
MA-T20A 20 4
MA-T25A 25 4
MA-T30A 30 4

BUSS SL & TL PLUG FUSES

TIME DELAY, 250 VOLT

PART # AMP PKG

MA-TL15A 15 4
MA-TL20A 20 4
MA-TL25A 25 4
MA-TL30A 30 4

PART # AMP PKG

MA-SL15A 15 4
MA-SL20A 20 4
MA-SL25A 25 4
MA-SL30A 30 4

BUSS W PLUG FUSES

TIME DELAY, 250 VOLT

PART # AMP PKG

MA-W3A 3 4
MA-W5A 5 4
MA-W6A 6 4

PART # AMP PKG

MA-W8A 8 4
MA-W10A 10 4

17

Phone/Fax: [phone] MA-LINE www.ma-line.com

BUSSMANN BOX-COVER UNITS

IN LINE FUSE

HOLDER

MA00014-1 (2/PKG)

18 GAUGE WITH 15 AMP FUSE

MA00030-1 (2/PKG)

12 GAUGE WITH 30 AMP FUSE

FUSE PULLER

MA-7519

OVERALL LENGTH 7"

1/2" DIA & 3/8" DIA.

CARTRIDGE TYPE FUSES

0 TO 200A, 250V

MA-SSX

MA-SSW

MA-SSU COVER FOR 2-1/4" HANDY BOX
MA-SSW COVER FOR 2-3/4" SWITCH BOX
MA-SSX COVER FOR 4" OCTAGON BOX)
MA-SSY COVER FOR 4" SQUARE BOX

MA-SRU

MA-SRY

1/4" X 1-1/4"
CERAMIC FUSES

UL LISTED,
CSA CERTIFICATION

PART # AMP VOLT PKG

MA-ABC-1 1 250 5
MA-ABC-2 2 250 5
MA-ABC-3 3 250 5
MA-ABC-5 5 250 5
MA-ABC-6 6 250 5
MA-ABC-8 8 250 5
MA-ABC-10 10 250 5
MA-ABC-12 12 250 5
MA-ABC-15 15 250 5
MA-ABC-20 20 250 5

MA-ABC-30 30 250 5

1/4" X 1-1/4"
GLASS FUSES

UL LISTED,
CSA CERTIFICATION

PART # AMP VOLT PKG

MA-AGC-1/32 1/32 250 5
MA-AGC-1/4 1/4 250 5
MA-AGC-1/2 1/2 250 5
MA-AGC-3/4 3/4 250 5
MA-AGC-1 1 250 5
MA-AGC-1-1/4 1-1/4 250 5
MA-AGC-1-1/2 1-1/2 250 5
MA-AGC-2 2 250 5
MA-AGC-2-1/2 2-1/2 250 5
MA-AGC-3 3 250 5

MA-AGC-4 4 250 5

MA-AGC-5 5 250 5
MA-AGC-6 6 250 5
MA-AGC-7 7 250 5
MA-AGC-8 8 250 5
MA-AGC-9 9 250 5
MA-AGC-10 10 250 5
MA-AGC-15 15 250 5
MA-AGC-20 20 250 5
MA-AGC-25 25 250 5
MA-AGC-30 30 250 5

BLADE – TYPE

FUSES

FAST ACTING
32V, DC, UL LISTED

PART # AMP VOLT PKG

MA-ATC2 2 32 5
MA-ATC3 3 32 5
MA-ATC4 4 32 5
MA-ATC5 5 32 5
MA-ATC7.5 7.5 32 5
MA-ATC10 10 32 5
MA-ATC15 15 32 5
MA-ATC20 20 32 5
MA-ATC25 25 32 5

MA-ATC30 30 32 5

1/4" X 1-1/4" GLASS FUSES

TIME DELAY, 250V/32V
CSA CERTIFICATION

CLASS G FUSE

TIME DELAY, 480V
UL LISTED, CSA CERTIFIED

PART # AMP VOLT PKG

MA-SC10 10 480 10
MA-SC15 15 480 10
MA-SC20 20 480 10
MA-SC25 25 480 10
MA-SC30 30 480 10

PART # AMP VOLT PKG

MA-SC35 35 480 10
MA-SC40 40 480 10
MA-SC45 45 480 10
MA-SC50 50 480 10
MA-SC60 60 480 10

13/32" X 1-1/2"
SUPPLEMENTARY
FUSES

TIME DELAY, 250V/500V
UL LISTED, CSA CERTIFIED

PART # AMP VOLT PKG

MA-FNM10 10 250 10
MA-FNM12 12 250 10
MA-FNM15 15 250 10
MA-FNM20 20 250 10
MA-FNM25 25 250 10
MA-FNM30 30 250 10
MA-FNM35 35 250 10
MA-FNM40 40 250 10

PART # AMP VOLT PKG

MA-FNQ10 10 500 10
MA-FNQ12 12 500 10
MA-FNQ15 15 500 10
MA-FNQ20 20 500 10
MA-FNQ25 25 500 10
MA-FNQ30 30 500 10

FNM
250V

FNQ

500V

FUSE REDUCERS

MA-263

MA-213

MA-263-R

MA-263-R FOR CLASS R FUSES

250V, FUSE SIZE 30A
DESIRED SIZE 60A

MA-263 FOR CLASS H & K FUSES

250V, FUSE SIZE 30A
DESIRED SIZE 60A

MA-213 FUSE REDUCER

PART # AMP VOLT PKG

MA-MDL-1/4 1/4 250 5
MA-MDL-1/2 1/2 250 5
MA-MDL-3/4 3/4 250 5
MA-MDL-1 1 250 5
MA-MDL-1-1/4 1-1/4 250 5
MA-MDL-2 2 250 5
MA-MDL-2-1/2 2-1/2 250 5
MA-MDL-3 3 250 5

MA-MDL-3.2 3-2/10 250 5

MA-MDL-4 4 250 5

PART # AMP VOLT PKG

MA-MDL-5 5 250 5
MA-MDL-6 6 250 5
MA-MDL-7 7 250 5
MA-MDL-8 8 250 5
MA-MDL-10 10 32 5
MA-MDL-15 15 32 5
MA-MDL-20 20 32 5
MA-MDL-25 25 32 5
MA-MDL-30 30 32 5

MA-SSU

MA-SSY

Fuse Holder and Switch

units provide both

protection for the motor

and the switch for turning

the device on and off

Fuse Holder and Plug-In Receptacle units provide convenient and
unique protection for devices permanently connected to a circuit where
switch control is desired. The grounding type Plug-In Receptacle uses
either ordinary 2-prong attachment plug caps, a 2-prong parallel
polarized cap with (1) wide prong, or a 3-prong grounding type cap.
These units are intended for use on maximum 3/4HP and 125V

MA-SRU COVER FOR 2-1/4" HANDY BOX
MA-SRY COVER FOR 4" SQUARE BOX

10/BOX

PRICE PER PIECE

MA-30301 DELAY ON MAKE
MA-30303 DELAY ON BREAK

TIME DELAYS

18

Phone/Fax: [phone] MA-LINE www.ma-line.com

METALLIC STRAIGHT
CONNECTOR

MA-E50A 1/2" (10/BOX)
MA-4E50A 1/2" (4/PKG)
MA-E75 3/4" (25/BOX)
MA-4E75 3/4" (4/PKG)
MA-E100 1" (5/PKG)
MA-LT125 1-1/4" (5/PKG)
MA-LT150 1-1/2" (2/PKG)

LIQUID TIGHT FITTINGS

METALLIC AND NON-METALLIC

METALLIC 90 DEGREE
ELBOW

MA-E5090A 1/2" (10/BOX
MA-4E5090A 1/2" (4/PKG)
MA-E7590 3/4" (25/BOX)
MA-4E7590 3/4" (4/PKG)
MA-E10090 1" (5/BOX)
MA-E12590 1-1/4" (2/BOX)
MA-E15090 1-1/2" (2/BOX)

NON-METALLIC
STRAIGHT CONNECTOR

MA-LC43D 1/2" SCREW ON (10/BOX)
MA-4LC43D 1/2" SCREW ON

(4/PKG)

MA-LC43E 3/4" SCREW ON

(10/BOX)

MA-4LC43E 3/4" SCREW ON

(4/PKG)

MA-NMLT50 1/2" 2 PIECE
MA-4NMLT50 1/2" 2 PIECE

(4/PKG)

MA-NMLT75 3/4" 2 PIECE
MA-4NMLT75 3/4" 2 PIECE (4/PKG)

A/C WHIPS

METAL FITTINGS:

MA-4012W

1/2" X 4' #10 THHN WIRE
FITTINGS: 1 STRAIGHT + 1 90

MA-6012W

1/2" X 6' #10 THHN WIRE
FITTINGS: 1 STRAIGHT + 1 90

MA-4034W

3/4" X 4' #8 THHN WIRE
FITTINGS: 1 STRAIGHT + 1 90

MA-6034W

3/4" X 6' #8 THHN WIRE
FITTINGS: 1 STRAIGHT + 1 90

PLASTIC FITTINGS:

MA-P4012W

1/2" X 4' #10 THHN WIRE
FITTINGS: 1 STRAIGHT + 1 90

MA-P6012W

1/2" X 6' #10 THHN WIRE
FITTINGS: 1 STRAIGHT + 1 90

MA-P4034W

3/4" X 4' #8 THHN WIRE
FITTINGS: 1 STRAIGHT + 1 90

MA-P6034W

3/4" X 6' #8 THHN WIRE
FITTINGS: 1 STRAIGHT + 1 90

ASSEMBLED WITH

UL APPROVED COMPONENTS

3 PHASE DISCONNECTS

240 VAC, THREE PHASE, NEMA TYPE 3R,

OUTDOOR ENCLOSURE

1/CASE – SOLD PER CASE

MA-60NF3 MA-30F3

60A, NON-FUSED 30A, FUSED

MA-60F3 60A, FUSED

“EXTRA-BOOST”

HARD START KITS

These units can increase starting torque from
300% to over 600% depending on the model
used. They can be used on room A/C, all
residential and commercial PSC A/C units and
heat pumps. They can be used on units rated
from 4,000 to 120,000 BTU’s and they
can be used on 120 through 288 VAC units.
All models are UL recognized and are
for low voltage and hard starting
compressors. All units contain a start
capacitor and relay for extra starting torque.
Installs in seconds across run capacitor
terminals.

Voltage: 120 230 Residential/Commercial

MA-XP5

BTU 4,000-60,000

MA-XP6

BTU 4,000-120,000

MA-XP8

BTU 4,000-120,000

UL & CSL LISTED

1/CASE – SOLD PER CASE

MA-UO65P010

KIT COMES WITH

2 REDUCING WASHERS

WORLD SOURCE A/C

METAL DISCONNECTS

UL & CUL LISTED

240 VAC, SINGLE PHASE, NEMA TYPE 3R,

OUTDOOR ENCLOSURE

MA-WSFD30A MA-WSNFD60A

30A, FUSED 60A, NON-FUSED

MA-WSFD60A

60A, FUSED

NON-METALLIC
90 DEGREE ELBOW

MA-LC20D 1/2" SCREW ON (10/BOX)
MA-4LC20D 1/2" SCREW ON

(4/PKG)

MA-LC20E 3/4" SCREW ON (10/BOX)
MA-4LC20E 3/4" SCREW ON

(4/PKG)

MA-NMLT9050 1/2" 2 PIECE
MA-4NMLT9050 1/2" 2 PIECE

(4/PKG)

MA-NMLT9075 3/4" 2 PIECE
MA-4NMLT9075 3/4" 2 PIECE

(4/PKG)

MA-EXT4

4” EXTENSION FOR
2 PIECES HEAT
PUMP STANDS

HEAT PUMP STANDS

NSA’S FURNACE

MOUNTING BLOCK

MA-68150

PATENT #

8,262,054, 8,882,075

& D465022

12 PER CASE - SOLD PER CASE

A/C DISCONNECTS
WITH GFI OUTLET

MA-HP3 3” 1 PIECE
MA-HP6 6” 1 PIECE

MA-HP3-2P 3” 2 PIECE
MA-HP6-2P 6” 2 PIECE

19

FLEXIBLE CONDUIT

TYPE ULC – UL APPROVED ONLY

MA-10050 1/2" X 100'
MA-10075 3/4" X 100'
MA-10010 1" X 100'

LIQUID TIGHT

NON-METALLIC CONDUIT
U.L. AND CSA APPROVED

MA-15005 1/2" X 100'
MA-15007 3/4" X 100'
MA-15008 1" X 100'

FLEXIBLE CONDUIT

LIQUID TIGHT
TYPE EFC-NON-UL

MA-20050 1/2" X 100'
MA-20075 3/4" X 100'
MA-20010 1" X 100'

MEETS JIC REQUIREMENTS
DOES NOT CONTAIN CONTINUOUS COPPER GROUND.

ALUMINUM (GREENFIELD)

MA-30038 3/8" X 100'
MA-30050 1/2" X 100'
MA-30075 3/4" X 100'

STEEL (GREENFIELD)

MA-40038 3/8" X 100'
MA-40050 1/2" X 100'
MA-40075 3/4" X 100'

FLEXIBLE

CONDUIT

ALUMINUM AND STEEL

MA-MC42C

14/2 – 100'

MA-MC22C

12/2 – 100'

MA-MC43C

14/3 – 100'

MA-MC23C

12/3 – 100'

MA-LINE TYPE MC CABLE IS USED IN COMMERCIAL, INDUSTRIAL AND
UTILITY APPLICATIONS WHERE SPACE AND EASE OF INSTALLATION IS
CRITICAL. MC CABLE HANDLES POWER SERVICE, LIGHTING,
CONTROL AND SIGNAL CIRCUITS. MAY BE USED IN CABLE TRAYS,
APPROVED RACEWAYS, OR AS AN OPEN RUN OF CABLE. MADE OF
ALUMINUM INTERLOCKED ARMOR, SOLID COPPER CONDUCTORS.

600 VOLTS – THHN CONDUCTORS WITH GREEN INSULATED GROUND.
MEETS U.L. 1569.

Phone/Fax: [phone] MA-LINE www.ma-line.com

CABLE STRAPS

MA-E2PL-1 1/2" WIDE 100/PKG

2-NAIL STRAPS FITS 2 - 3 #12 NM

CABLE, OR 2 #12 UF CABLE

MA-E3PL-1 3/4" WIDE 100/PKG

2-NAIL STRAPS FITS 2 #8 NM & UF

CABLE, OR 3 #12 UF CABLE

MA-E2PL25 1/2" WIDE 25/PKG

2-NAIL STRAPS FITS 2 - 3 #12 NM

CABLE, OR 2 #12 UF CABLE

MA-E3PL25 3/4" WIDE 25/PKG

2-NAIL STRAPS FITS 2 #8 NM & UF

CABLE, OR 3 #12 UF CABLE

2 NAIL STRAP

STEEL & ALUMINUM FLEX, AC & MC CABLE

MA-E42-1 1/2" STRAIGHT SQUEEZE CONN.(TYPE A) 25/PKG.
MA-E42-2 3/4" STRAIGHT SQUEEZE CONN.(TYPE A) 25/PKG.
MA-E42-3 1" STRAIGHT SQUEEZE CONN.(TYPE A) 10/PKG.
MA-E42-4 1-1/4" STRAIGHT SQUEEZE CONN.(TYPE A) 10/PKG.
MA-E42-5 1-1/2" STRAIGHT SQUEEZE CONN.(TYPE A) 5/PKG.
MA-E110 3/8" 90 DEGREE SET SCREW CONN.(TYPE B) 50/PKG.
MA-E110-1 1/2" 90 DEGREE SET SCREW CONN.(TYPE B) 25/PKG.
MA-E110-2 3/4" 90 DEGREE SET SCREW CONN.(TYPE B) 15/PKG.
MA-E110-3 1" 90 DEGREE SET SCREW CONN.(TYPE B) 10/PKG.
MA-E110-4 1-1/4" 90 DEGREE SET SCREW CONN.(TYPE B) 5/PKG.
MA-E110-5 1-1/2" 90 DEGREE SET SCREW CONN.(TYPE B) 1/PKG.
MA-E57 3/8" COMBINATION CONNECTOR (TYPE D) 100/PKG.
MA-4E421 1/2" STRAIGHT SQUEEZE CONN. (TYPE A) 4/PKG.
MA-4E422 3/4" STRAIGHT SQUEEZE CONN. (TYPE B) 4/PKG.
MA-4E110 3/8" 90 DEGREE SET SCREW CONN.(TYPE B) 4/PKG.
MA-4E1101 1/2" 90 DEGREE SET SCREW CONN.(TYPE B) 4/PKG.
MA-4E1102 3/4" 90 DEGREE SET SCREW CONN.(TYPE B) 4/PKG.
MA-4E57 3/8" COMBINATION CONNECTOR (TYPE D) 4/PKG.

NM CABLE

MA-E104A 3/4" CABLE CONNECTOR (TYPE E) 50/PKG.
MA-E105 1" CABLE CONNECTOR (TYPE E) 25/PKG.
MA-E106 1-1/4" CABLE CONNECTOR (TYPE E) 10/PKG.
MA-E107 1-1/2" CABLE CONNECTOR (TYPE E) 10/PKG.
MA-E51 3/8" ROMEX CONNECTOR (TYPE E) 100/PKG
MA-4E104A 3/4" CABLE CONNECTOR (TYPE E) 4/PKG.
MA-4E51 3/8" ROMEX CONNECTOR (TYPE E) 4/PKG

FLEX, MC & AC CABLE

MA-E58 3/8" SET SCREW CONNECTOR (TYPE F) 100/PKG.
MA-E48 1/2" SET SCREW CONNECTOR (TYPE F) 25/PKG.
MA-4E58 3/8" SET SCREW CONNECTOR (TYPE F) 4/PKG.
MA-4E48 1/2" SET SCREW CONNECTOR (TYPE F) 4/PKG.

FITTINGS FOR BX-FLEXIBLE METAL CONDUIT

ANTI-SHORT

BUSHINGS

FOR FLEX – AC – MC CABLE

MA-E0PL FITS CABLE SIZE: 14/2, 14/3, 12/2

TRADE SIZE: 5/16" 100/PKG

MA-E1PL FITS CABLE SIZE: 14/4, 12/3, 6/1, 4/1

TRADE SIZE: 3/8" 100/PKG

MA-E2PL FITS CABLE SIZE: 12/4, 10/2, 10/3, 2/1

TRADE SIZE: 7/16" 50/PKG

MA-E3PL FITS CABLE SIZE: 10/4, 8/2, 8/3, 1/1

TRADE SIZE: 1/2" 50/PKG

MA-E4PL FITS CABLE SIZE: 8/4, 6/2, 6/3, 6/4, 4/2, 4/3

TRADE SIZE: 3/4" 10/PKG

UV (SUNLIGHT) RESISTANT

20

Phone/Fax: [phone] MA-LINE www.ma-line.com

FITTINGS FOR RIGID CONDUIT

MA-E376 1/2" OFFSET NIPPLES (TYPE A) 20/PKG.
MA-E377 3/4" OFFSET NIPPLES (TYPE A) 10/PKG.
MA-E378 1" OFFSET NIPPLES (TYPE A) 10/PKG.
MA-E379 1-1/4" OFFSET NIPPLES (TYPE A) 10/PKG.
MA-E380 1-1/2" OFFSET NIPPLES (TYPE A) 10/PKG.
MA-E96-1CG 1/2" LB TYPE THREADED OVAL CONDUIT BODY

WITH COVER AND GASKET (TYPE B) 10/PKG.

MA-E96-2CG 3/4" LB TYPE THREADED OVAL CONDUIT BODY

WITH COVER AND GASKET (TYPE B) 10/PKG.

MA-E96-4CG 1-1/4" LB TYPE THREADED OVAL CONDUIT BODY

WITH COVER AND GASKET (TYPE B) 2/PKG.

MA-E96-5CG 1-1/2" LB TYPE THREADED OVAL CONDUIT BODY

WITH COVER AND GASKET (TYPE B) 2/PKG.

MA-E900 1/2" SLB SERVICE ENTRANCE ELBOW (TYPE C) 10/PKG.
MA-E901 3/4" SLB SERVICE ENTRANCE ELBOW (TYPE C) 10/PKG
MA-E902 1" SLB SERVICE ENTRANCE ELBOW (TYPE C) 5/PKG
MA-E903 1-1/4" SLB SERVICE ENTRANCE ELBOW (TYPE C) 5/PKG
MA-E904 1-1/2" SLB SERVICE ENTRANCE ELBOW (TYPE C) 2/PKG
MA-E59 1/2" CONDUIT LOCKNUTS FULLY REVERSIBLE

(TYPE D) 200/PKG.

MA-E80 3/4" CONDUIT LOCKNUTS FULLY REVERSIBLE

(TYPE D) 100/PKG.

MA-E81 1" CONDUIT LOCKNUTS FULLY REVERSIBLE

(TYPE D) 100/PKG.

MA-E82 1-1/4" CONDUIT LOCKNUTS FULLY REVERSIBLE

(TYPE D) 50/PKG.

MA-E83 1-1/2" CONDUIT LOCKNUTS FULLY REVERSIBLE

(TYPE D) 50/PKG.

MA-4E59 1/2" CONDUIT LOCKNUTS FULLY REVERSIBLE

(TYPE D) 4/PKG

MA-25E59 1/2" CONDUIT LOCKNUTS FULLY REVERSIBLE

(TYPE D) 25/PKG.

MA-25E80 3/4" CONDUIT LOCKNUTS FULLY REVERSIBLE

(TYPE D) 25/PKG.

MA-E52PL 1/2" PLASTIC INSULATED BUSHING (TYPE E) 100/PKG.
MA-E60PL 3/4" PLASTIC INSULATED BUSHING (TYPE E) 100/PKG.
MA-E61PL 1" PLASTIC INSULATED BUSHING (TYPE E) 50/PKG.
MA-E65PL 1-1/4" PLASTIC INSULATED BUSHING (TYPE E) 25/PKG.
MA-E69PL 1-1/2" PLASTIC INSULATED BUSHING (TYPE E) 25/PKG.
MA-E298-21 3/4" X 1/2" REDUCING WASHER (TYPE F) 250/PKG.
MA-E298-31 1" X 1/2" REDUCING WASHER (TYPE F) 100/PKG.
MA-E298-32 1" X 3/4" REDUCING WASHER (TYPE F) 100/PKG.
MA-E298-41 1-1/4" X 1/2" REDUCING WASHER (TYPE F) 200/PKG.
MA-E298-42 1-1/4" X 3/4" REDUCING WASHER (TYPE F) 200/PKG.
MA-E298-43 1-1/4" X 1" REDUCING WASHER (TYPE F) 200/PKG.
MA-E298-51 1-1/2" X 1/2" REDUCING WASHER (TYPE F) 100/PKG.
MA-E298-52 1-1/2" X 3/4" REDUCING WASHER (TYPE F) 100/PKG.
MA-E298-53 1-1/2" X 1" REDUCING WASHER (TYPE F) 100/PKG.
MA-E298-54 1-1/2" X 1-1/4" REDUCING WASHER (TYPE F) 100/PKG.
MA-25E29821 3/4" X 1/2" REDUCING WASHER (TYPE F) 25/PKG.
MA-25E29831 1" X 1/2" REDUCING WASHER (TYPE F) 25/PKG.
MA-25E29832 1" X 3/4" REDUCING WASHER (TYPE F) 25/PKG.

COMPRESSION TYPE – RAIN TIGHT

MA-E21 1/2" CONNECTOR (TYPE A) 50/PKG.
MA-E23 3/4" CONNECTOR (TYPE A) 25/PKG.
MA-E25 1" CONNECTOR (TYPE A) 15/PKG.
MA-E27 1-1/4" CONNECTOR (TYPE A) 5/PKG.
MA-E29 1-1/2" CONNECTOR (TYPE A) 10/PKG.
MA-E22 1/2" CONNECTOR (TYPE B) 50/PKG.
MA-E24 3/4" CONNECTOR (TYPE B) 25/PKG.
MA-E26 1" CONNECTOR (TYPE B) 15/PKG.
MA-E28 1-1/4" CONNECTOR (TYPE B) 10/PKG.
MA-E30 1-1/2" CONNECTOR (TYPE B) 10/PKG.
MA-4E21 1/2" CONNECTOR (TYPE A) 4/PKG.
MA-4E23 3/4" CONNECTOR (TYPE A) 4/PKG.
MA-4E22 1/2" CONNECTOR (TYPE B) 4/PKG.
MA-4E24 3/4" CONNECTOR (TYPE B) 4/PKG.

SET SCREW TYPE – CONCRETE TIGHT

MA-E121 1/2" CONNECTOR (TYPE C) 50/PKG.
MA-E123 3/4" CONNECTOR (TYPE C) 25/PKG.
MA-E125 1" CONNECTOR (TYPE C) 20/PKG.
MA-E127 1-1/4" CONNECTOR (TYPE C) 5/PKG.
MA-E129 1-1/2" CONNECTOR (TYPE C) 10/PKG.
MA-E122 1/2" COUPLING (TYPE D) 50/PKG.
MA-E124 3/4" COUPLING (TYPE D) 25/PKG.
MA-E126 1" COUPLING (TYPE D) 15/PKG.
MA-E128 1-1/4" COUPLING (TYPE D) 20/PKG.
MA-E130 1-1/2" COUPLING (TYPE D) 10/PKG.
MA-4E121 1/2" CONNECTOR (TYPE C) 4/PKG.
MA-4E123 3/4" CONNECTOR (TYPE C) 4/PKG.
MA-4E122 1/2" COUPLING (TYPE D) 4/PKG.
MA-4E124 3/4" COUPLING (TYPE D) 4/PKG.

CONNECTORS, ELBOWS & STRAPS

MA-E2390-2 3/4" 90 DEG. EMT CONNECTOR (TYPE E) 20/PKG
MA-E37-1 1/2" OFFSET CONNECTOR EMT TO BOX (TYPE F) 20/PKG
MA-E37-2 3/4" OFFSET CONNECTOR EMT TO BOX (TYPE F) 20/PKG
MA-E37-3 1" OFFSET CONNECTOR EMT TO BOX (TYPE F) 20/PKG
MA-E144-1 1/2" EMT PULL ELBOWS (TYPE G) 10/PKG
MA-E144-2 3/4" EMT PULL ELBOWS (TYPE G) 5/PKG
MA-2E14411/2" EMT PULL ELBOWS (TYPE G) 2/PKG
MA-2E1442 3/4" EMT PULL ELBOWS (TYPE G) 2/PKG
MA-E5S 1/2" STEEL DRIVE STRAPS (TYPE H) 100/PKG
MA-E7S 3/4" STEEL DRIVE STRAPS (TYPE H) 100/PKG
MA-E10S 1" STEEL DRIVE STRAPS (TYPE H) 100/PKG

FITTINGS FOR THINWALL CONDUIT

(EMT)

21

COPPER TUBE EXTENSIONS

WITH MULTI-STEPS

AF1500 (3/PKG) AF1500-50 (50/PKG)

1/8"OD, 3/16", 1/4" AND 5/16"ODF MULTI STEPS

AF1600 (3/PKG) AF1600-50 (50/PKG)

3/16"OD X 1/8"ID, 1/4" AND 3/8"ODF MULTI STEPS

PRICE PER PACKAGE

SWIVEL FLARE CONNECTION

AF1700 (3/PKG) AF1700-50 (50/PKG)

1/4"FE SAE SWIVEL NUT ON BRANCH

AF1800 (3/PKG) AF1800-50 (50/PKG)

1/4"FE SAE SWIVEL NUT ON RUN

MULTI-STEP BRASS BODY

AF1900 (3/PKG) AF1900-50 (50/PKG)

1/8"OD X 3/16", 1/4", OR 5/16"ODF STEPS

PRICE PER PACKAGE

REFRIGERANT RETENTION
CONTROL VALVE

MA-33002 1/4"FLF X 1/4"FLM
MA-33005 5/16"FLF X 5/16"FLM
MA-33008 5/16"FLF X 1/4"FLM

MA-33008

MA-33005

MA-33002

COPPER TUBE

EXTENSIONS

WITH 5/16" FITTING

5/16" MALE FLARE –

COPPER EXTENTION 2" LONG

PRICE PER PACKAGE

AF11516 3/16"ODS X 1/4"ODF (3/PKG)
AF12516 1/4"ODS X 5/16”ODF (3/PKG)
AF13516 5/16"ODS X 3/8”ODF (3/PKG)

AF2000

VALVE CORE TOOL

AF2200-M (1/PKG)

INCLUDES 6 CORES

COPPER SOLDER TEES

WITH 1/4" MALE FLARE

AF3134 (3/PKG) AF3140 (1/PKG)

1/4"ODS X 5/16”ODF 5/8"ODS

AF3135 (3/PKG) AF3142 (1/PKG)

5/16"ODS X 3/8”ODF 3/4"ODS

AF3136 (3/PKG) AF3144 (1/PKG)

3/8"ODS X 1/2”ODF 7/8"ODS

AF3138 (3/PKG) AF3148 (1/PKG)

1/2"ODS 1-1/8"ODS

D109 (2/PKG) INLET: 1/4" OUTLET: 1/4"

3/4" X 8-1/2" NON-DIRECTIONAL DRIER

D110 (2/PKG) INLET: 1/4" OUTLET: 1/4"

3/4" X 8-3/4" DIRECTIONAL FUSED ENDS
DRIER

D111 (2/PKG) INLET: 1/4" OUTLET: 1/4" OR CAP

1" X 8-3/4" DIRECTIONAL CHARGING DRIER

D112 (2/PKG) INLET: 5/16" OUTLET: 5/16"

1" X 10-3/4" DIRECTIONAL STEP DOWN DRIER

D113 (2/PKG) INLET: (2)1/4" OUTLET: 1/4"

1" X 8-3/4" DIRECTIONAL DOUBLE INLET DRIER

D114 (2/PKG) INLET: MULITPLE OUTLET: 1/4"

1" X 9" DIRECTIONAL FUSED ENDS DRIER

D115 (2/PKG) INLET: 1/4"ID, 1/4"OD & 1/4" FLARE OUTLET: 1/4"

3/4" X 9" DIRECTIONAL CHARGING DRIER

PRICE PER PACKAGE

COPPER SPUN

DRIERS

DRIERS CONTAIN XH-9

DESICCANT

ADJUSTABLE

LINE TAP VALVE

MA-V1 1/4", 5/16", & 3/8" OD
MA-V2 1/2" & 5/8" OD

MA-18975

1/4" WITH SIDE PORT

MA-18985

5/16" WITH SIDE PORT

4 IN 1 VACUUM/CHARGE
VALVE AND CORE TOOL

COPPER TUBE EXTENSIONS

WITH 1/4" FITTING

5/PKG-PRICE/PKG

AF1000 1/8"OD
AF1100 3/16"OD
AF1200 1/4"OD
AF1300 5/16"OD
AF1400 3/8"OD

CAP AND REPLACEMENT VALVE CORES

PRICE PER PACKAGE

AF2000 (10/PKG)
AF2000BX (100/PKG)

1/4"SAE GASKET SEAL CAP
W/CORE REMOVER

AF2100 (5/PKG) AF2100-25 (25/PKG) AF2100-100 (100/PKG)

1/4" VALVE CORE

MA-SVOM18

18MM/.75"

SOLENOID VALVE

OPERATING MAGNET

Phone/Fax: [phone] MA-LINE www.ma-line.com

50/PKG-PRICE/PKG

AF1000-50 1/8"OD
AF1100-50 3/16"OD
AF1200-50 1/4"OD
AF1300-50 5/16"OD
AF1400-50 3/8"OD

PRICE PER PACKAGE

PRICE PER PACKAGE

5/16" ADAPTOR
FOR R-410 SYSTEMS

MA-19173

22

DCH DRIER WITH SAE

CONNECTION

DIMENSIONS

DCH DRIER WITH ODS

CONNECTION

DIMENSIONS

DCH BI-FLOW DRIER WITH ODS

CONNECTION DIMENSIONS

DCH052F

1/4" SAE LIQUID LINE FILTER DRIER

1/4" SAE CONNECTION,

4.88" OVERALL LENGTH

DRAWING 1

DCHBF083S

3/8" ODS LIQUID LINE FILTER DRIER

BI-FLOW, 3/8" ODS CONNECTION,

5.78" OVERALL LENGTH

DCHBF163S

3/8" ODS LIQUID LINE FILTER DRIER

BI-FLOW, 3/8" ODS CONNECTION,

6.57" OVERALL LENGTH

DRAWING 2

DCH303S

3/8" ODS LIQUID LINE FILTER DRIER

3/8" ODS CONNECTION,

9.45" OVERALL LENGTH

DCH304S

1/2" ODS LIQUID LINE FILTER DRIER

1/2" ODS CONNECTION,

9.45" OVERALL LENGTH

DCH305S

5/8" ODS LIQUID LINE FILTER DRIER

5/8" ODS CONNECTION,

9.45" OVERALL LENGTH

DCH306S

3/4" ODS LIQUID LINE FILTER DRIER

3/4" ODS CONNECTION,

9.45" OVERALL LENGTH

DCH307S

7/8" ODS LIQUID LINE FILTER DRIER

7/8" ODS CONNECTION,

10.39" OVERALL LENGTH

DCH309S

1-1/8" ODS LIQUID LINE FILTER DRIER

1-1/8" ODS CONNECTION,

10.39" OVERALL LENGTH

DRAWING 3

DRAWING 3

DRAWING 2

DRAWING 1

Phone/Fax: [phone] MA-LINE www.ma-line.com

DCH052S

1/4" ODS LIQUID LINE FILTER DRIER

1/4" ODS CONNECTION,

5.04" OVERALL LENGTH

DCH053S

3/8" ODS LIQUID LINE FILTER DRIER

3/8" ODS CONNECTION,

5.04" OVERALL LENGTH

DCH082S

1/4" ODS LIQUID LINE FILTER DRIER

1/4" ODS CONNECTION,

5.86" OVERALL LENGTH

DCH083S

3/8" ODS LIQUID LINE FILTER DRIER

3/8" ODS CONNECTION,

5.86" OVERALL LENGTH

DCH163S

3/8" ODS LIQUID LINE FILTER DRIER

3/8" ODS CONNECTION,

6.77" OVERALL LENGTH

DCH164S

1/2" ODS LIQUID LINE FILTER DRIER

1/2" ODS CONNECTION,

6.77" OVERALL LENGTH

DCH165S

5/8" ODS LIQUID LINE FILTER DRIER

35/8" ODS CONNECTION,

6.77" OVERALL LENGTH

DRAWING 3

DCH032S

1/4" ODS LIQUID LINE FILTER DRIER

1/4" ODS CONNECTION,

4.61" OVERALL LENGTH

DCH033S

3/8" ODS LIQUID LINE FILTER DRIER

3/8" ODS CONNECTION,

4.61" OVERALL LENGTH

DRAWING 3

LIQUID LINE FILTER DRIER

DCH SERIES

(SOLID CORE TYPE)

INTERNAL

ASSEMBLY

CORE TYPE

MAXIMUM WORKING

PRESSURE

45 BAR (653 PSIG)

SAE TYPE CONNECTION

NICKEL PLATED

STEEL

ODS TYPE CONNECTION

COPPER

23

Phone/Fax: [phone] MA-LINE www.ma-line.com

WELDED STEEL

BLACK IRON PIPE NIPPLES

PART # DESCRIPTION PKG.

MA-BN12CL 1/2" X CL-1-1/8" 25
MA-BN12112 1/2" X 1-1/2" 25
MA-BN122 1/2" X 2" 25
MA-BN12212 1/2" X 2-1/2" 25
MA-BN123 1/2" X 3" 25
MA-BN12312 1/2" X 3-1/2" 25
MA-BN124 1/2" X 4" 25
MA-BN12412 1/2" X 4-1/2" 25
MA-BN125 1/2" X 5" 25
MA-BN12512 1/2" X 5-1/2" 25
MA-BN126 1/2" X 6" 25
MA-BP1212 1/2" X 12" 1
MA-BP1218 1/2" X 18" 1
MA-BP1224 1/2" X 24" 1
MA-BP1230 1/2" X 30" 1
MA-BP1236 1/2" X 36" 1
MA-BP1248 1/2" X 48" 1
MA-BP1260 1/2" X 60" 1

PART # DESCRIPTION PKG.

MA-BN34CL 3/4" X CL-1-3/8" 25
MA-BN34112 3/4" X 1-1/2" 25
MA-BN342 3/4" X 2" 25
MA-BN34212 3/4" X 2-1/2" 25
MA-BN343 3/4" X 3" 25
MA-BN34312 3/4" X 3-1/2" 25
MA-BN344 3/4" X 4" 25
MA-BN34412 3/4" X 4-1/2" 25
MA-BN345 3/4" X 5" 25
MA-BN34512 3/4" X 5-1/2" 25
MA-BN346 3/4" X 6" 25
MA-BP3412 3/4" X 12" 1
MA-BP3418 3/4" X 18" 1
MA-BP3424 3/4" X 24" 1
MA-BP3430 3/4" X 30" 1
MA-BP3436 3/4" X 36" 1
MA-BP3448 3/4" X 48" 1
MA-BP3460 3/4" X 60" 1

PART # DESCRIPTION PKG.

MA-BN1CL 1" X CL-1-1/2" 25
MA-BN12 1" X 2" 25
MA-BN1212 1" X 2-1/2" 25
MA-BN13 1" X 3" 25
MA-BN1312 1" X 3-1/2" 25
MA-BN14 1" X 4" 25
MA-BN1412 1" X 4-1/2" 25
MA-BN15 1" X 5" 25
MA-BN1512 1" X 5-1/2" 25
MA-BN16 1" X 6" 25
MA-BP112 1" X 12" 1
MA-BP118 1" X 18" 1
MA-BP124 1" X 24" 1
MA-BP130 1" X 30" 1
MA-BP136 1" X 36" 1
MA-BP148 1" X 48" 1
MA-BP160 1" X 60" 1

PIPE NIPPLES MEET THE ASTM A733
SPECIFICATIONS

SOLD PER PIECE

PRICE PER PIECE

SPECIFICATIONS:

MATERIAL: ASTM A-197
DIMENSIONS: ANSI B16.3 & ANSI B16.14
THREADS: ANSI B1.20.1

CAP

PART # DESCRIPTION PKG.

MA-12U 1/2" UNION 50
MA-34U 3/4" UNION 35
MA-1U 1" UNION 20
MA-12CPLG 1/2" COUPLING 120
MA-34CPLG 3/4" COUPLING 75
MA-1CPLG 1" COUPLING 50
MA-3412CPLG 3/4" X 1/2" RED. COUPLING 90
MA-112CPLG 1" X 1/2" RED. COUPLING 30
MA-134CPLG 1" X 3/4" RED. COUPLING 50
MA-1290EL 1/2" 90 DEGREE ELBOW 100
MA-3490EL 3/4" 90 DEGREE ELBOW 35
MA-190EL 1" 90 DEGREE ELBOW 30
MA-1245EL 1/2" 45 DEGREE ELBOW 100
MA-3445EL 3/4" 45 DEGREE ELBOW 60
MA-145EL 1" 45 DEGREE ELBOW 30
MA-1290STEL 1/2" 90 DEG. STR. ELBOW 90
MA-3490STEL 3/4" 90 DEG. STR. ELBOW 35
MA-190STEL 1" 90 DEG. STR. ELBOW 30

MALLEABLE BLACK IRON PIPE FITTINGS

PART # DESCRIPTION PKG.

MA-12T 1/2" TEE 60
MA-34T 3/4" TEE 35
MA-1T 1" TEE 20
MA-341212T 3/4" X 1/2" X 1/2" TEE 50
MA-343412T 3/4" X 3/4" X 1/2" TEE 40
MA-1238BG 1/2" X 3/8" HEX BUSHING 300
MA-3412BG 3/4" X 1/2" HEX BUSHING 150
MA-112BG 1" X 1/2" HEX BUSHING 100
MA-134BG 1" X 3/4" HEX BUSHING 100
MA-12CAP 1/2" CAP 150
MA-34CAP 3/4" CAP 80
MA-1CAP 1" CAP 50
MA-12PLG 1/2" PLUG 300
MA-34PLG 3/4" PLUG 180
MA-1PLG 1" PLUG 120

MA-T1005 1/2" NIPPLE TRAY
MA-T1007 3/4" NIPPLE TRAY
MA-T1010 1" NIPPLE TRAY
MA-T1057 1/2" & 3/4" NIPPLE TRAY

PLASTIC

NIPPLE TRAYS

CARDBOARD NIPPLE TRAYS

WITH ASSORTED NIPPLES

MA-1266T 1/2" (66 PCS)

6EA. OF CLOSE TO 6"

MA-3466T 3/4" (66 PCS)

6EA. OF CLOSE TO 6"

MA-0160T 1" (60 PCS)

6EA. OF CLOSE TO 6"

24

SCHEDULE 40 PVC FITTINGS

PART # DESCRIPTION PKG. TYPE

MA-30105 COUPLING 1/2" SLIP X SLIP 100 A
MA-30107 COUPLING 3/4" SLIP X SLIP 50 A
MA-30110 COUPLING 1" SLIP X SLIP 50 A
MA-30605 ELBOW 45 1/2" SLIP X SLIP 50 B
MA-30607 ELBOW 45 3/4" SLIP X SLIP 50 B
MA-30610 ELBOW 45 1" SLIP X SLIP 50 B
MA-30705 ELBOW 90 1/2" SLIP X SLIP 50 C
MA-30707 ELBOW 90 3/4" SLIP X SLIP 50 C
MA-30710 ELBOW 90 1" SLIP X SLIP 50 C
MA-31318 1/2" CLEAN OUT TEE 1 L
MA-31348 3/4" CLEAN OUT TEE 1 L
MA-31405 TEE 1/2" SLIP X SLIP X SLIP 50 D
MA-31407 TEE 3/4" SLIP X SLIP X SLIP 50 D
MA-31410 TEE 1" SLIP X SLIP X SLIP 50 D
MA-30305 ADAPTOR 1/2" SLIP X FPT 100 E
MA-30307 ADAPTOR 3/4" SLIP X FPT 50 E
MA-30311 ADAPTOR 1" SLIP X FPT 50 E
MA-30357 REDUCING FPT ADAPTOR 50 F

1/2" SLIP X 3/4"FPT

MA-30405 ADAPTOR 1/2" SLIP X MPT 100 G
MA-30407 ADAPTOR 3/4" SLIP X MPT 50 G
MA-30410 ADAPTOR 1" SLIP X MPT 50 G
MA-30457 REDUCING MPT ADAPTOR 50 H

1/2" SLIP X 3/4"MPT

MA-30155 CAP 1/2" SLIP 100 I
MA-30157 CAP 3/4" SLIP 50 I
MA-30158 CAP 1" SLIP 50 I
MA-448007 CAP 3/4" FPT 100

Phone/Fax: [phone] MA-LINE www.ma-line.com

PART # DESCRIPTION PKG. TYPE

MA-450007 PLUG 3/4" MPT 50
MA-30275 REDUCING BUSHING 100 J

3/4" SLIP X 1/2" SLIP

MA-437131 REDUCING BUSHING 100 J

1" SLIP X 3/4" SLIP

MA-436074 REDUCING MPT ADAPTOR 100 H

3/4" SLIP X 1/2" MPT

MA-32905 STREET ELBOW 90 1/2" SLIP 50 M
MA-32907 STREET ELBOW 90 3/4" SLIP 50 M
MA-409010 STREET ELBOW 90 1" SLIP 50 M
MA-33905 ELBOW 90 1/2" SLIP X FPT 50 K
MA-33907 ELBOW 90 3/4" SLIP X FPT 50 K
MA-33910 ELBOW 90 1" SLIP X FPT 50 K
MA-401020 TEE 2" SLIP X SLIP X SLIP 25 D
MA-407074 ELBOW 90 3/4" FPT X 1/2"SLIP 50 K
MA-410005 STREET ELBOW 90 50 M

1/2" MPT X 1/2"SLIP

MA-410007 STREET ELBOW 90 50 M

3/4" MPT X 3/4"SLIP

MA-410010 STREET ELBOW 90 50 M

1" MPT X 1"SLIP

MA-410101 STREET ELBOW 90 50 M

3/4" MPT X 1/2"SLIP

MA-457005 UNION 1/2" SLIP X SLIP 10 N
MA-457007 UNION 3/4" SLIP X SLIP 10 N
MA-457010 UNION 1" SLIP X SLIP 10 N
MA-457012 UNION 1-1/4" SLIP X SLIP 5 N
MA-457015 UNION 1-1/2" SLIP X SLIP 5 N
MA-457020 UNION 2" SLIP X SLIP 2 N

PART # DESCRIPTION PKG. TYPE

MA-70115 COUPLING 1-1/2" 100 A
MA-70120 COUPLING 2" 100 A
MA-429025 COUPLING 2-1/2" SCH 40 10 A
MA-70130 COUPLING 3" 60 A
MA-D100040 COUPLING 4" 25 A
MA-70121 RED. COUPLING 2" X 1-1/2" 25 B
MA-70132 RED. COUPLING 3" X 2" 20 B
MA-D102420 RED. COUPLING 4" X 2" 10 B
MA-D102422 RED. COUPLING 4" X 3" 10 B
MA-70116 REPAIR COUPLING 1-1/2" 25 C
MA-70122 REPAIR COUPLING 2" 25 C
MA-70133 REPAIR COUPLING 3" 10 C
MA-D130040 REPAIR COUPLING 4" 5 C
MA-70151 CAP SCH. 40 1-1/2" 25 D
MA-70152 CAP SCH. 40 2" 25 D
MA-447025 CAP SCH. 40 2-1/2" 10 D
MA-70153 CAP SCH. 40 3" 10 D
MA-447040 CAP SCH. 40 4" 5 D
MA-72815 90 DEG. ELBOW 1-1/2" 100 E
MA-72820 90 DEG. ELBOW 2" 50 E
MA-406025 90 DEG. ELBOW SCH 40 2-1/2"10 E
MA-72830 90 DEG. ELBOW 3" 25 E
MA-D300040 90 DEG. ELBOW 3" 10 E
MA-70615 45 DEG. ELBOW 1-1/2" 100 H
MA-70620 45 DEG. ELBOW 2" 50 H
MA-417025 45 DEG. ELBOW 2-1/2" SCH 40 10 H
MA-70630 45 DEG. ELBOW 3" 20 H

PART # DESCRIPTION PKG. TYPE

MA-D321040 45 DEG. ELBOW 4" 100 H
MA-73815 90 DEGREE 50 F

LONG SWEEP ELBOW 1-1/2"

MA-73820 90 DEGREE 25 F

LONG SWEEP ELBOW 2"

MA-73830 90 DEGREE 10 F

LONG SWEEP ELBOW 3"

MA-D304040 90 DEGREE 5 F

LONG SWEEP ELBOW 4"

MA-71115 TEE 1-1/2" 100 G
MA-71120 TEE 2" 35 G
MA-401025 TEE SCH. 40 2-1/2" 10 G
MA-71130 TEE 3" 30 G
MA-D400040 TEE 4" 5 G
MA-70221 BUSHING SCH. 40 2" X 1-1/2" 50 I
MA-437292 BUSHING SCH. 40 2-1/2" X 2" 10 I
MA-70231 BUSHING SCH. 40 3" X 1-1/2" 30 I
MA-70232 BUSHING 3" X 2" 30 I
MA-437339 BUSHING SCH. 40 3" X 2-1/2" 10 I
MA-D309015 LONG SWP. STR. ELB. 1-1/2" 10
MA-D309020 LONG SWP. STR. ELB. 2" 25
MA-D309030 LONG SWP. STR. ELB. 3" 20
MA-D323015 45 DEG. STR. ELB. 1-1/2" 100
MA-D323020 45 DEG. STR. ELB. 2" 50
MA-D323030 45 DEG. STR. ELB. 3" 20
MA-207013 NIPPLE TBE SCH. 80 3/4" X CL 50
MA-207030 NIPPLE TBE SCH. 80 3/4" X 3" 50

SCHEDULE 40

PVC-DWV

FITTINGS
