1 Introduction

__________________________________________________

Thank you for purchasing the EasyLocator WideRange.
The EasyLocator series of products is the most widely used

GPR-system for utility detection, world-wide. The WideRange
is the latest in a line of easy-to-use tools for the locating
industry. It builds on its predecessors in terms of handling and
user interface while incorporating the latest and most potent
technology currently available.

We at Malå GeoScience welcome comments from you
concerning the use and experience of this equipment, as well
as the contents and usefulness of this manual. Please take the
time to read through the assembling instructions carefully and
address any questions or suggestions to the following:

Main Office: Subsidiary:

Malå GeoScience Malå GeoScience USA, Inc.
Skolgatan 11 465 Deanna Lane
S-930 70 Malå Charleston, SC 29492
Sweden USA
Phone: [phone] Phone: [phone]
Fax: [phone] Fax: [phone]
E-mail: [e-mail] E-mail: [e-mail]

Technical support issues can be sent to: [e-mail]
Information about MALÅ GeoSciences products is also

available on Internet: http://www.malags.com

Copyright© 2012 Malå Geoscience AB

Draft www.malags.com

5

1.1 Unpacking and Inspection

Great care should be taken when unpacking the equipment.
Be sure to verify the contents shown on the packing list and
inspect the equipment for any loose parts or other damage. All
packing material should be preserved in the event that any
damage occurred during shipping. Any claims for shipping
damage should be filed to the carrier. Any claims for missing
equipment or parts should be filed with Mala GeoScience.

1.2 Repacking and Shipping

If original packing materials are unavailable, the equipment
should be packed with at least 80 mm of shock-absorbing
material. Do not use shredded fibres, paper wood, or wool, as
these materials tend to get compacted during shipment and
permit the instruments to move around inside the package.

1.3 Limited Warranty and Liability

Malå Geoscience warrants that, for a period of 12 months from the delivery
date to the original purchaser, Malå Geoscience products will be free from
defects in materials and workmanship. Except for the foregoing limited

warranty, Malå Geoscience disclaims all warranties, express or
implied, including nay warranty of merchantability or fitness for a
particular purpose. Malå Geoscience will repair and replace parts or

equipment which are returned to Malå Geoscience, transportation and
insurance pre-paid, without alteration or further damage, and which in Malå
Geoscience´s judgement, were defective or became defective during
normal use.

Malå Geoscience assumes no liability for any direct, indirect, special,
incidental or consequential damages or injures caused by proper or
improper operation of its equipment or software, whether or not
defective.

Draft www.malags.com

6

1.4 Important information regarding the use of
this MALA GPR unit

According to the regulations stated in ETSI EN 302 066-1 (European
Telecommunication Standards Institute):

- The CX unit should not be left ON when leaving the system unintended. It

should always be turned OFF when not in use.

- The antennas should point towards the ground, walls etc. during

measurement and not towards the air.

- The antennas should be kept in close proximity to the media under

investigation.

Canadian regulations states that whenever GPR-antennas are in use the
following note apply:

This Ground penetrating Radar device shall be operated only when in
contact with or within 1 m of the ground.

This Ground Penetrating Radar Device shall be used only by law
enforcement agencies, scientific research institutes, commercial mining
companies, construction companies and emergency rescue or firefighting
organizations.

This equipment has been tested and found to comply with part 15 of the
FCC Rules. Malå GeoScience has not approved any changes or
modifications to this device by the user. Any changes or modifications

could void the user’s authority to operate the equipment. See 47 CFR Sec.

15.21.
