Makita WT01W User Manual

INSTRUCTION MANUAL

Cordless Impact Wrench

WT01

IMPORTANT: Read Before Using.

011762

ENGLISH (Original instructions)

SPECIFICATIONS

Model WT01

Capacities

Square drive 9.5 mm (3/8")

No load speed (RPM) 0 -2,300/min.

Impacts per minute 0 - 3,000

Max. fastening torque 110 N.m (1,000 in.lbs)

Overall length 163 mm (6-3/8")

Net weight 0.95 kg (2.1 lbs)

Rated voltage D.C. 10.8V/12Vmax

Standard battery cartridges

• Due to our continuing programme of research and development, the specifications herein are subject to change without notice.

• Specifications and battery cartridge may differ from country to country.

• Weight, with battery cartridge, according to EPTA-Procedure 01/2003

General Power Tool Safety
Warnings

WARNING Read all safety warnings and all

instructions. Failure to follow the warnings and

instructions may result in electric shock, fire and/or
serious injury.

Save all warnings and
instructions for future reference.

The term "power tool" in the warnings refers to your
mains-operated (corded) power tool or battery-operated
(cordless) power tool.

Work area safety

1. Keep work area clean and well lit. Cluttered or
dark areas invite accidents.

2. Do not operate power tools in explosive

atmospheres, such as in the presence of
flammable liquids, gases or dust. Power tools

create sparks which may ignite the dust or fumes.

3. Keep children and bystanders away while
operating a power tool. Distractions can cause
you to lose control.

Electrical safety

4. Power tool plugs must match the outlet. Never
modify the plug in any way. Do not use any
adapter plugs with earthed (grounded) power
tools. Unmodified plugs and matching outlets will

reduce risk of electric shock.

5. Avoid body contact with earthed or grounded

surfaces such as pipes, radiators, ranges and
refrigerators. There is an increased risk of

electric shock if your body is earthed or grounded.

6. Do not expose power tools to rain or wet

Standard bolt M8 - M12 (5/16" - 1/2")

High tensile bolt M6 - M10 (1/4" - 3/8")

BL1014

GEA006-2

conditions. Water entering a power tool will
increase the risk of electric shock.

7. Do not abuse the cord. Never use the cord for

carrying, pulling or unplugging the power tool.
Keep cord away from heat, oil, sharp edges or
moving parts. Damaged or entangled cords

increase the risk of electric shock.

8. When operating a power tool outdoors, use an
extension cord suitable for outdoor use. Use of
a cord suitable for outdoor use reduces the risk of
electric shock.

9. If operating a power tool in a damp location is

unavoidable, use a ground fault circuit
interrupter (GFCI) protected supply. Use of an

GFCI reduces the risk of electric shock.

Personal safety

10. Stay alert, watch what you are doing and use
common sense when operating a power tool.
Do not use a power tool while you are tired or
under the influence of drugs, alcohol or
medication. A moment of inattention while

operating power tools may result in serious
personal injury.

11. Use personal protective equipment. Always
wear eye protection. Protective equipment such
as dust mask, non-skid safety shoes, hard hat, or
hearing protection used for appropriate conditions
will reduce personal injuries.

12. Prevent unintentional starting. Ensure the

switch is in the off-position before connecting
to power source and/or battery pack, picking
up or carrying the tool. Carrying power tools with

your finger on the switch or energising pow er tools
that have the switch on invites accidents.

13. Remove any adjusting key or wrench before

2

turning the power tool on. A w rench or a key left
attached to a rotating part of the power tool may
result in personal injury.

14. Do not overreach. Keep proper footing and
balance at all times. This enables better control
of the power tool in unexpected situations.

15. Dress properly. Do not wear loose clothing or

jewellery. Keep your hair, clothing, and gloves
away from moving parts. Loose clothes,

jewellery or long hair can be caught in moving
parts.

16. If devices are provided for the connection of

dust extraction and collection facilities,
ensure these are connected and properly used.

Use of dust collection can reduce dust-related
hazards.

Power tool use and care

17. Do not force the power tool. Use the correct
power tool for your application. The correct

power tool will do the job better and safer at the
rate for which it was designed.

18. Do not use the power tool if t he switch does
not turn it on and off. Any power tool that cannot
be controlled with the switch is dangerous and
must be repaired.

19. Disconnect the plug from the power source

and/or the battery pack from the power tool
before making any adjustments, changing
accessories, or storing power tools. Such

preventive safety measures reduce the risk of
starting the power tool accidentally.

20. Store idle power tools out of the reach of

children and do not allow persons unfamiliar
with the power tool or these instructions to
operate the power tool. Power tools are

dangerous in the hands of untrained users.

21. Maintain power tools. Check for misalignment

or binding of moving parts, breakage of parts
and any other condition that may affect the
power tool’s operation. If damaged, have the
power tool repaired before use. Many accidents

are caused by poorly maintained power tools.

22. Keep cutting tools sharp and clean. Properly
maintained cutting tools with sharp cutting edges
are less likely to bind and are easier to control.

23. Use the power tool, accessories and tool bits

etc. in accordance with these instructions,
taking into account the working conditions
and the work to be performed. Use of the power

tool for operations different from those intended
could result in a hazardous situation.

Battery tool use and care

24. Recharge only with the charger specified by
the manufacturer. A charger that is suitable for

one type of battery pack may create a risk of fire

when used with another battery pack.

25. Use power tools only with specifically
designated battery packs. Use of any other
battery packs may create a risk of injury and fire.

26. When battery pack is not in use, keep it away

from other metal objects, like paper clips,
coins, keys, nails, screws or other small metal
objects, that can make a connection from one
terminal to another. Shorting the battery

terminals together may cause burns or a fire.

27. Under abusive conditions, liquid may be

ejected from the battery; avoid contact. If
contact accidentally occurs, flush with water . If
liquid contacts eyes, additionally seek medical
help. Liquid ejected from the battery may cause

irritation or burns.

Service

28. Have your power tool serviced by a qualified
repair person using only identical replacement
parts. This will ensure that the safety of the power

tool is maintained.

29. Follow instruction for lubricating and

changing accessories.

30. Keep handles dry, clean and free from oil and
grease.

GEB049-2

CORDLESS IMPACT WRENCH
SAFETY WARNINGS

1. Hold power tool by insulated gripping
surfaces, when performing an operation where
the fastener may contact hidden wiring.

Fasteners contacting a "live" wire may make
exposed metal parts of the power tool "live" and
could give the operator an electric shock.

2. Wear ear protectors.

3. Check the socket carefully for wear, cracks or

damage before installation.

4. Hold the tool firmly.

5. Always be sure you have a firm footing.

Be sure no one is below when using the tool in
high locations.

6. The proper fastening torque may differ
depending upon the kind or size of the bolt.
Check the torque with a torque wrench.

SAVE THESE INSTRUCTIONS.

WARNING:

DO NOT let comfort or familiarity with product
(gained from repeated use) replace strict adherence
to safety rules for the subject product. MISUSE or
failure to follow the safety rules stated in this
instruction manual may cause serious personal
