Makita BFS450H2 User Manual

06 - 2009

BFS450, BFS450Z, BFS450H2

18V SCREWDRIVER

1

2

3

4

5

6

7 8

44

13

43

14

15

42

16

41

17

40

18

28

19

39

29

30

20

31

21

22

32

33

23

24

10

12

9

25

26

27

10

38

37

34

35

36

Item Part No. Description

Q'tyUnit

T

T

T

T

T

T

T

T

R

T

L

T

A

1 450691-1 LOCK RING 1 PC.
2 158753-6 LOCATOR L COM. 1 PC.

2 INC. Item No. 3, 4 1 PC.

3 424133-1 BRAKE PIN 1 PC.
4 424134-9 DUST SEAL RING 1 PC.
5 233967-9 RING SPRING 33 1 PC.
6 232245-4 LEAF SPRING 1 PC.
7 158755-2 LOCATOR BASE COM. 1 PC.
8 911148-2 P.H. SCREW M4X25 1 PC.

9 450689-8 LIGHT HOLDER 1 PC.
10 188559-8 HOUSING SE
12 265995-6
13 214174-3 PLANE BEARING 14 1 PC.
14 213262-3 O RING 18 1 PC.
15 421927-5 SLEEVE 20 1 PC.
16 232050-9 LEAF SPRING 1 PC.
17 216001-0 STEEL BALL 3.5 1 PC.
18 324925-7 SPINDLE 1 PC.
19 256509-2 SHOLDER PIN 8-10 1 PC.
20 267331-2 FLAT WASHER 25 1 PC.
21 267331-2 FLAT WASHER 25 1 PC.
22 234017-3 COMPRESSEION SPRING 25 1 PC.
23 267332-0 FLAT WASHER 26 1 PC.
24 223169-5 CLUTCH CAM C 1 PC.
25 216008-6 STEEL BALL 4 3 PC.
26 226670-9 HELICAL GEAR 48 1 PC.
27 211034-0 BALL BEARING 608 1 PC.
28 165115-1 RUBBER SLEEVE 10 1 PC.
29 214017-9 PLANE BEARING 5 1 PC.
30 253811-4 FLAT WASHER 5 1 PC.
31 154937-4 GEAR COMPLETE 18-44 1 PC.
32 214017-9 PLANE BEARING 5 1 PC.
33 213055-8 O RING 10 1 PC.
34 419304-3 CHANGE LEVER F/R 1 PC.
35 650603-6 SWITCH(TRIGGER)TG513SBA-1 1 PC.
36 643812-4

36 643843-3

37 631818-4 LIGHT CIRCUI
38 638426-2 YORK UNI
39 619216-2 ARMATURE 1 PC.
40 194427-5 CARBON BRUSH CB-440 2/SE
41 638433-5 BRUSH HOLDER COM. (INCLUDES 231696-8 - 1 PC.

41 INC. 231696-8
41 INC. 231697-6

42 263032-0 RUBBER PIN 4 2 PC.
43 450692-9 FRONT COVER 1 PC.
44 265995-6

101 654208-4 RECEPTACLE 2 PC.
102 654510-5 INSULATED CONNECTOR 5.5-SD 2 PC.

APPING SCREW 4X18 9 PC.

ERMINAL (BLACK) - TYPE 1 1 PC.
ERMINAL (YELLOW) - TYPE 2 1 PC.

ORSION SPRING
ORSION SPRING

APPING SCREW 4X18 2 PC.

1 SET

1 PC.
1 PC.

1 SET

1 PC.
1 PC.

CCESSORIES

A01 281220-7 HOOK 1 PC.
A02 784212-0 PHILLIPS INSERT BIT 1-25 1 PC.

784211-2 PHILLIPS INSERT BIT 2-25 1 PC.
784213-8 PHILLIPS INSERT BIT 3-25 1 PC.

2MODELBFS450,BFS450Z,BFS450H2
