Makita 9553NBK User Manual
11 - 2009 9553NBK 4” DISC GRINDER M10 X 1.25
|
13 |
|
15 |
14 |
|
|
12 |
|
|
11 |
|
|
10 |
|
|
9 |
|
16 |
8 |
|
17 |
||
|
||
18 |
7 |
|
19 |
6 |
|
20 |
5 |
|
21 |
||
4 |
||
|
||
22 |
3 |
|
|
2 |
|
23 |
|
|
24 |
1 |
|
25 |
|
|
26 |
|
|
27 |
37 |
|
|
||
28 |
|
|
29 |
|
|
30 |
39 |
|
31 |
40 |
|
|
||
32 |
41 |
|
|
||
|
45 |
|
|
44 |
|
33 |
43 |
A06 |
49 |
50 |
|
A07 |
|
51 |
48 |
|
|
||
|
|
52 |
|
|
|
54 |
55 |
A08
Item No. |
Part No. |
Description |
Qty |
Unit |
1 |
621711-0 |
FIELD 115V |
1 |
PC. |
2 |
418795-5 |
BAFFLE PLATE |
1 |
PC. |
3 |
421868-5 |
LABYRINTH RUBBER RING 19 |
1 |
PC. |
4 |
210034-7 |
BALL BEARING 607LLB |
1 |
PC. |
5 |
681667-9 |
RESIN WASHER (TYPE 1) - N/L/A |
1 |
PC. |
|
681636-0 |
INSULATION WASHER (TYPE 2) |
1 |
PC. |
6 |
515616-3 |
ARMATURE ASS'Y 115V |
1 |
PC. |
INC. |
|
Item No. 4,5,7 |
|
|
7 |
240076-7 |
FAN 56 |
1 |
PC. |
8 |
317821-6 |
GEAR HOUSING COVER |
1 |
PC. |
9 |
213445-5 |
O-RING 26 |
1 |
PC. |
10 |
210042-8 |
BALL BEARING 629LLB (TYPE1#210071-1, TYPE2#210053-3 - N/L/A) |
1 |
PC. |
11 |
227471-8 |
SPIRAL BEVEL GEAR 11 |
1 |
PC. |
12 |
252186-8 |
HEX. NUT M6 |
1 |
PC. |
13 |
417771-6 |
PIN CAP |
1 |
PC. |
14 |
233376-2 |
COMPRESSION SPRING 8 |
1 |
PC. |
15 |
266361-0 |
TAPPING SCREW 4X30 |
4 |
PC. |
16 |
213960-9 |
O RING 5 |
1 |
PC. |
17 |
256486-8 |
SHOULDER PIN 4 |
1 |
PC. |
18 |
317814-3 |
GEAR HOUSING |
1 |
PC. |
19 |
263002-9 |
RUBBER PIN 4 |
1 |
PC. |
20 |
210033-9 |
BALL BEARING 696ZZ |
1 |
PC. |
21 |
961052-5 |
RETAINING RING S-12 |
1 |
PC. |
22 |
267794-2 |
WAVE WASHER 12 |
1 |
PC. |
23 |
227506-5 |
SPIRAL BEVEL GEAR 36 (OLD# 227472-6 - N/L/A) |
1 |
PC. |
24 |
962151-6 |
RETAINING RING R-32 |
1 |
PC. |
25 |
211129-9 |
BALL BEARING 6201DDW |
1 |
PC. |
26 |
267238-2 |
FLAT WASHER 12 |
1 |
PC. |
27 |
213622-9 |
O RING 45 |
1 |
PC. |
28 |
317819-3 |
BEARING BOX |
1 |
PC. |
29 |
265099-4 |
PAN HEAD SCREW M4X14 |
4 |
PC. |
30 |
345464-4 |
LABYRINTH RING |
1 |
PC. |
31 |
254011-9 |
WOODRUFF KEY 4 |
1 |
PC. |
32 |
324473-6 |
SPINDLE (M10X1.25) |
1 |
PC. |
33 |
265103-9 |
PAN HEAD SCREW M5X14 |
1 |
PC. |
37 |
266325-4 |
TAPPING SCREW 4X70 (OLD# 266362-8 - N/L/A) |
2 |
PC. |
39 |
266007-8 |
TAPPING SCREW BIND PT 3X10 |
4 |
PC. |
40 |
643760-7 |
BRUSH HOLDER |
1 |
PC. |
41 |
194074-2 |
CARBON BRUSH CB-325 2PC/SET (W/O ORIGIN) |
1 |
SET |
|
195001-2 |
CARBON BRUSH CB-325 2PC/SET (W/ ORIGIN) |
1 |
SET |
43 |
650560-8 |
SWITCH DPX-2110-R |
1 |
PC. |
44 |
687123-7 |
STRAIN RELIEF |
1 |
PC. |
45 |
266326-2 |
TAPPING SCREW 4X18 |
2 |
PC. |
47 |
682559-5 |
CORD GUARD 8 |
1 |
PC. |
48 |
664891-9 |
POWER SUPPLY CORD AWG#18-2-2.5 |
1 |
PC. |
49 |
419566-3 |
SWITCH KNOB (OLD#419566-3 - N/L/A) |
1 |
PC. |
50 |
418794-7 |
MOTOR HOUSING |
1 |
PC. |
51 |
643760-7 |
BRUSH HOLDER |
1 |
PC. |
52 |
233121-5 |
COMPRESSION SPRING 4 |
1 |
PC. |
53 |
418796-3 |
SWITCH LEVER C |
1 |
PC. |
54 |
418726-4 |
REAR COVER |
1 |
PC. |
55 |
266326-2 |
TAPPING SCREW 4X18 |
1 |
PC. |
2 MODEL 9553NBK
