T
ECHNICAL INFORMATION
New Tool
Models No.
Description
9035N
Finishing Sander
CONCEPT AND MAIN APPLICATIONS
Model 9035N has the switching arrangement for
orbital and straight movement. The orbital
movementis for general finishing, and the straight
moveme nt is for grain finishing.
Specifications
Voltage(V) Current(A) Cycle(Hz)
100 1.7 50/60 130 30 40
115 1.5 50/60 130 30 40
200 0.9 50/60 130 30 40
220 0.8 50/60 130 30 40
230 0.7 50/60 130 30 40
240 0.7 50/60 130 30 40
Continuous rating
Input(W)
148
93
Output(W)
235
Max.output(W)
No load speed (R.P.M.) 7000/min.
Abrasive paper si ze 93 x 228 mm
Pad size 93 x 185mm
Net weight 1.45 kg
Power supply cord 2.5 m
Standard equipment
Sanding paper 93-60 2 sheets
Sanding paper 93-100 2 sheets
Sanding paper 93-150 2 sheets
Optional accessories
Sanding paper 93-60
Sanding paper 93-10
Sanding paper 93-150
Features and benefits
1. You can switch the movem ent with one touch of a finger.
2. Use straight movement for grain finishing.
3. This model is light and compact.
4. Double insulated structure promises safe operation.
Capacity
1. Sanding efficiency is almost t he same a s 9035SB, 9035, B%D(7436).
The standard equipment for the tools shown may differ form country to country
The standard equipment for the tools shown may differ form country to country
Page 2
Repair
1. Remove screws fixing the base at 4 points to de tach t he base.
2. Except the above step, follow the procedures for 9035SB and 9035.
