Makita 9016DBZ, 9016DB User Manual

40

02 - 2010

9016DB / 9016DBZ

6” GRINDER AC/DC

1

2

3

4

5

6

7

8

9

5/8” 11UNC

A06

A05

A04

38

36

35

34

33

37

10

11

12

13

19

17

16

18

15

14

A03

21

20

22

15

23

24

25

26

28

27

Item No. Type Sub Part No. Description (* see Service Changes on the bottom) Qty Unit

1 416449-8 PIN CAP 1 PC.
2 233089-5 COMPRESSION SPRING 12 1 PC.
3 266173-1 TAPPING SCREW 5X30 4 PC.
4 153374-9 * GEAR HOUSING COM. (OLD# 159995-5 - N/L/A) 1 PC.
5 961003-8 RETAINING RING S-7 1 PC.
6 226756-9 SPIRAL BEVEL GEAR 11 1 PC.
7 211131-2 BALL BEARING 6001DDW 1 PC.
8 317323-2 * GEAR HOUSING COVER (OLD# 316992-6 - N/L/A) 1 PC.
9 240010-7 FAN 70 1 PC.
10 516331-2 ARMATURE ASS'Y 115V 1 PC.

10 INC. Item No. 9,11,12

11 681644-1 INSULATION WASHER 1 PC.
12 210005-4 BALL BEARING 608DDW 1 PC.
13 416448-0 BAFFLE PLATE 1 PC.
14 265995-6 TAPPING SCREW 4X18 4 PC.
15 183274-9 * HANDLE SET (F/ 9016DB) 1 SET

15 183010-3 HANDLE SET (F/ 9016DBZ) 1 SET

16 522846-9 * FIELD ASS'Y 115V 1 PC.

16 INC. 654020-2 RING TERMINAL 2 PC.
16 INC. 654501-6 CONNECTOR P-1.25 2 PC.

17 266029-8 TAPPING SCREW 5X65 2 PC.
18 183159-9 * MOTOR HOUSING (OLD# 159996-3 - N/L/A) 1 PC.

18 INC. 643708-9 * BRUSH HOLDER 5-11 2 PC.
18 INC. * Item No. 20 0

19 1 266027-2 * TAPPING SCREW CT5X16 4 PC.

19 2 265096-0 * PAN HEAD SCREW M5X16 4 PC.

20 819001-5 MAKITA LABEL 2 PC.
21 643750-0 BRUSH HOLDER CAP 2 PC.
22 1 191963-2 CARBON BRUSH CB-303 2PC/SET (W/O ORIGIN) 1 SET

22 2 194996-6 CARBON BRUSH CB-303 2PC/SET (W/ ORIGIN) 1 SET

23 866512-1 NAME PLATE 9016DB 1 PC.
24 651166-5 * SWITCH (AC/DC) (F/ 9016DB) 1 PC.

24 651128-3 * SWITCH (AC/DC) (F/ 9016DBZ) 1 PC.

25 265995-6 TAPPING SCREW 4X18 2 PC.
26 687063-9 CORD CLAMP 1 PC.
27 664265-4 CORD W/PLUG 2P-16-2.5M,SJ 1 PC.
28 682505-8 CORD GUARD 10-90 1 PC.
33 251391-4 PAN HEAD SCREW M5X16 1 PC.
34 152573-0 SPINDLE COMPLETE 1 PC.

34 INC. 344347-5 LABYRINTH RING 1 PC.

35 316991-8 BEARING BOX 1 PC.
36 211129-9 BALL BEARING 6201DDW 1 PC.
37 962151-6 RETAINING RING R-32 1 PC.
38 226754-3 SPIRAL BEVEL GEAR 35 1 PC.
40 256446-0 PIN 6 1 PC.
41 262086-4
42 442126-6

* RUBBER RING 29 (Added) 1 PC.
* GASKET (Added) 1 PC.

43 163434-9 * SWITCH LEVER COMPLETE (F/ 9016DB) (Added) 1 PC.
44 417313-6

* SWITCH BASE (F/ 9016DB) (Added) 1 PC.

100 652039-5 * + BINDING HEAD SCREW M3.5X6.8 (F/ 9016DB) 4 PC.

100 652014-1 P.H. SCREW M4X8 (F/ 9016DBZ) 4 PC.

101 654037-5 * INSULATED TERMINAL RBV1.25-3.5 (F/9016DB) 4 PC.

101 654002-4 TERMINAL 1.25-M4 (F/ 9016DBZ) 4 PC.

2 MODEL 9016DB, 9016DBZ
