Makita 6802BV User Manual [en, ru, de, pl]

Screwdriver
Instruction Manual
Schrauber
Betriebsanleitung
Wkrętarka
Instrukcja obsługi
Отвертка
Инструкция по эксплуатации
1
2
3
5
7
4
6
8
2
Symbols
The following show the symbols used for the tool. Be sure that you understand their meaning before use.
Symbole
Die folgenden Symbole werden für die Maschine verwendet. Machen Sie sich vor der Benutzung unbedingt mit ihrer Bedeutung vertraut.
Symbole
Poniższe symbole używane są do opisu urządzenia. Przed użyciem należy upewnić się, że rozumie się ich znaczenie.
Символы
Следующие объяснения показывают символы, используемые для инструмента. Убедитесь перед использованием, что Вы понимаете их значение.
Read instruction manual. Bitte Betriebsanleitung lesen.Przeczytaj instrukcję obsługi. Прочитайте инструкцию по эксплуатации.
DOUBLE INSULATION DOPPELT SCHUTZISOLIERT PODWÓJNA IZOLACJAДВОЙНАЯ ИЗОЛЯЦИЯ
3
ENGLISH
Explanation of general view
1 Locking position 2 Locator 3 Locking sleeve 4 Magnetic socket bit 5 Gear housing
6 Socket bit 7 Low 8 High 9 Speed control screw 10 Switch trigger
SPECIFICATIONS
Model 6802BV
Capacities
Self drilling screw ...........................................6 mm
Bit shank size ............................................... 1/4” Hex
No load speed (RPM) ................................. 0 – 2,500
Overall length ................................................ 265 mm
Net weight ........................................................ 1.7 kg
• Due to the continuing program of research and
development, the specifications herein are subject
to change without prior notice.
• Note: Specifications may differ from country to
country.
Power supply
The tool should be connected only to a power supply of the same voltage as indicated on the nameplate, and can only be operated on single-phase AC supply. They are double-insulated in accordance with Euro­pean Standard and can, therefore, also be used from sockets without earth wire.
SAFETY INSTRUCTIONS
Warning! When using electric tools, basic safety precautions should always be followed to reduce the risk of fire, electric shock and personal injury, including the following. Read all these instruc­tions before attempting to operate this product and save these instructions.
For safe operation:
1. Keep work area clean
Cluttered areas and benches invite injuries.
2. Consider work area environment
Don’t expose power tools to rain. Don’t use power tools in damp or wet locations. Keep work area well lit. Don’t use power tools in presence of flammable liquids or gases.
3. Guard against electric shock
Prevent body contact with grounded surfaces (e.g. pipes, radiators, ranges, refrigerators).
4. Keep children away
Do not let visitors contact tool or extension cord. All visitors should be kept away from work area.
5. Store idle tools
When not in use, tools should be stored in dry, high, or locked-up place, out of the reach of chil­dren.
6. Don’t force tool
It will do the job better and safer at the rate for which it was intended.
11 Lock button 12 Reversing switch lever 13 Insert bit 14 Magnetic bit holder
7. Use right tool
Don’t force small tools or attachments to do the job of a heavy duty tool. Don’t use tools for pur­poses not intended; for example, don’t use circu­lar saw for cutting tree limbs or logs.
8. Dress properly
Do not wear loose clothing or jewelry. They can be caught in moving parts. Rubber gloves and non-skid footwear are recommended when work­ing outdoors. Wear protective hair covering to contain long hair.
9. Use safety glasses and hearing protection
Also use face or dust mask if cutting operation is dusty.
10. Connect dust extraction equipment
If devices are provided for the connection of dust extraction and collection facilities, ensure these are connected and properly used.
11. Don’t abuse cord
Never carry tool by cord or yank it to disconnect it from receptacle. Keep cord from heat, oil and sharp edges.
12. Secure work
Use clamps or a vise to hold work. It’s safer than using your hand and it frees both hands to oper­ate tool.
13. Don’t overreach
Keep proper footing and balance at all times.
14. Maintain tools with care
Keep tools sharp and clean for better and safer performance. Follow instructions for lubricating and changing accessories. Inspect tool cords periodically and, if damaged, have repaired by authorized service facility. Inspect extension cords periodically and replace if damaged. Keep handles dry, clean and free from oil and grease.
15. Disconnect tools
When not in use, before servicing, and when changing accessories such as blades, bits and cutters.
16. Remove adjusting keys and wrenches
Form the habit of checking to see that keys and adjusting wrenches are removed from tool before turning it on.
17. Avoid unintentional starting
Don’t carry plugged-in tool with finger on switch. Be sure switch is off when plugging in.
18. Outdoor use extension cords
When tool is used outdoors, use only extension cords intended for use outdoors and so marked.
19. Stay alert
Watch what you are doing. Use common sense. Do not operate tool when you are tired.
4
20. Check damaged parts
Before further use of the tool, a guard or other part that is damaged should be carefully checked to determine that it will operate properly and per­form its intended function. Check for alignment of moving par ts, binding of moving par ts, breakage of parts, mounting, and any other conditions that may affect its operation. A guard or other part that is damaged should be properly repaired or replaced by an authorized service center unless otherwise indicated elsewhere in this instruction manual. Have defective switches replaced by and authorized service center. Do not use tool if switch does not turn it on and off.
21. Warning
The use of any other accessory or attachment other than recommended in this operating instruction or the catalog may present a risk of personal injury.
22. Have your tool repaired by an expert
This electric appliance is in accordance with the relevant safety rules. Repairing of electric appli­ances may be carried out only by experts other­wise it may cause considerable danger for the user.
ADDITIONAL SAFETY RULES
1. Always be sure you have a firm footing. Be sure no one is below when using the tool in high locations.
2. Hold the tool firmly.
3. Keep hands away from rotating parts.
4. When driving into walls, floors or wherever “live” electrical wires may be encountered, DO NOT TOUCH ANY METAL PARTS OF THE TOOLtool! Hold the tool by the insulated grasping surfaces to prevent electric shock if you drive into a “live” wire.
5. Do not touch the bit or the workpiece immedi­ately after operation; they may be extremely hot and could burn your skin.
SAVE THESE INSTRUCTIONS.
OPERATING INSTRUCTIONS
Removing or installing locator assembly (Fig. 1)
To remove the locator assembly, pull the locking sleeve forward and then turn it counterclockwise. To install the locator assembly, screw it clockwise and then push the locking sleeve back in lightly toward the motor. Turn the locking sleeve slightly to match the locking positions and then push in firmly to lock the locator in place.
Removing or installing magnetic socket bit (Fig. 2)
Important: Always be sure that the tool is switched off and unplugged before removing or installing the bit.
After removing the locator assembly, pull firmly to remove the magnetic socket bit. To install the bit, insert it into the tool as far as it will go.
Depth adjustment (Fig.3 & 4)
Pull the locking sleeve forward and then turn it to adjust the depth.
Initially, adjust the locator assembly to create a dis­tance of approximately 0.5 mm from the tip of the locator to the tip of the socket bit. One full turn of the locator equals 1.5mm change in depth. After adjust­ing the locator assembly, push the locking sleeve in to lock the locator in place. Drive a trial screw into your material or a piece of duplicate material. If the depth is not suitable for the screw, continue adjusting until the proper depth setting is obtained.
Switch action (Fig. 5)
CAUTION: Before plugging in the tool, always check to see that the switch trigger actuates properly and returns to the “OFF” position when released.
To start the tool, simply pull the trigger. Machine speed is increased by increasing pressure on the trigger. Release the trigger to stop. For continuous operation, pull the trigger and then push in the lock button. To stop the tool from the locked position, pull the trigger fully, then release it. A speed control screw is provided so that maximum tool speed can be lim­ited (variable). Turn the speed control screw clock­wise for higher speed, and counterclockwise for lower speed.
NOTE: Even with the switch on and motor running, the bit will not rotate until you fit the point of the bit in the screw head and apply forward pressure to engage the clutch.
Reversing switch action (Fig. 6)
CAUTION:
• Always check the direction of rotation before opera­tion.
• Use the reversing switch only after the tool comes to a complete stop. Changing the direction of rota­tion before the tool stops may damage the tool.
This tool has a reversing switch to change the direc­tion of rotation. Move the reversing switch lever to the i position for clockwise rotation or the j position for counterclockwise rotation.
5
Operation
Fit the screw on the point of the bit and place the point of the screw on the surface of the workpiece to be fastened. Apply pressure to the tool. Start the tool slowly and then increase the speed gradually. With­draw the tool as soon as the clutch cuts in.
CAUTION:
• Use the proper bit for the head of the screw that you wish to use.
• When fitting the screw onto the point of the bit, be careful not to push in on the screw. If the screw is pushed in, the clutch will engage and the screw will rotate suddenly. This could damage a workpiece or cause an injury.
• Do not continue unnecessary clutching operation.
NOTE: Make sure that the bit is inserted straight in the screw head, or the screw and/or bit may be damaged.
When using insert bit (Fig. 7 &8)
Fit together the insert bit and magnetic bit holder. Install a locator assembly for an insert bit.
Then adjust depth setting. Initially, adjust the locator assembly to create a distance of approximately 1 mm from the tip of the locator to the base of the screw head. Continue adjusting until the proper depth set­ting is obtained by following the method of “Depth adjustment”.
To remove the bit, pull the magnetic bit holder firmly. Hold the magnetic bit holder in your hand and grasp the bit with a pair of pliers. Pull the bit out of the mag­netic bit holder. Sometimes, it helps to wiggle the bit with the pliers as you pull.
MAINTENANCE
CAUTION: Always be sure that the tool is switched off and unplugged before carrying out any work on the tool.
To maintain product safety and reliability, repairs, maintenance or adjustment should be carried out by Makita Authorized Service Center.
6
