MAKERFACTORY M5Stack Weighing Interface User guide [ml]

BN 2108266
M5Stack Weighing Interface
EN Quick Instru ctions
Version: 1
Delivery Content
l Product
l Screw terminal plug
l Grove c able
Development resources and additional product information are avail­able from:
https: //www.conrad.de/ https: //docs.makerfactory.io/
Description
The product is a weighing interface. It integrates a 24 bit A/D chip HX711.
The input multiplexer selects either channel A or B differential input to the low-noise programmable gain amplifier (PGA).
Channel A can be programmed with a gain of 128 or 64, cor­responding to a full-scale differential input voltage of ±20 mV or ±40 mV respectively, when a 5 V supply is connected to the AVDD analog power supply pin. Channel B has a fixed gain of 32.
There is no programming needed for the internal registers. All controls to the HX711 are through t he pins.
This product communicates with the M5Core through GPIO (26/36).
1
Features
l Two selec table differential input channels
l On-chip act ive low noise PGA with selec table gain of 32, 64
and 128
l On-chip power supply regulator for load-c ell and ADC analog
power supply
l On-chip oscillat or requiring no external component wit h
optional ext ernal cryst al
l On-chip power-on-reset
l Simple digital cont rol and serial interface: pin-driven controls,
no programm ing needed
l Selectable 10 SPS or 80 SPS output data rat e
l Simultaneous 50 Hz and 60 Hz supply reject ion
l 16 pin SOP-16 package
l Supports UIF low (Block ly , Py thon), Arduino®
l Two Lego compatible holes
Applications
l Mic ro Weight Meter
l Kitc hen Scale
Pinout / Pin Map
M5Core GPIO36 GPIO26 5V GND
Product Data Pin (DAT) Clock Pin (CLK) 5V GND
Specifications
Input Voltage 2.6 - 5.5 V/DC
Current Consumption
Operating Temperature range -40 t o +85 °C
Dimensions (approx.)
Weight (approx.) 8 g
Operation: <1.5 mA
Standby: <1µA
32.2 x 24.2 x 10.5 mm (W x D x H )
2
Disposal
Electronic devices are recyclable waste and must not be dis­posed of in the household waste.
At the end of its service life, dispose of the product in accordance with applicable regulatory guidelines.
You thus fulfill your s tatutory obligations and contribute to the pro­tection of the environment.
Legal Notice
This is a publication by Conrad Electronic SE, Klaus-Conrad-Str. 1, D­92240 Hirschau (www.conrad.com).
All rights including translation reserved. Reproduction by any method, e.g. photocopy, microfilming, or the capture in electronic data pro­cessing syst ems require the prior written approval by the editor. Reprinting, also in part, is prohibited.
This publication represent the technical status at the time of printing.
Copyright 2019 by Conrad Electronic SE.
3
BN 2108266
M5Stack Wägeschnittstelle
DE Kurzanleitun g
Version: 1
Lieferumfang
l Produkt l Stec ker mit Klemmleiste l Grove Kabel
Ressourcen für Entwickler
Ressourcen für Entwickler und zusätzliche Informationen zum Pro­dukt sind verfügbar über:
https://www.conrad.de/ https://docs.makerfactory.io/
Beschreibung
Das Produkt ist eine Wägeschnittst elle. Es integriert einen 24-Bit A/D Chip HX711.
Der Eingangsmultiplexer wählt entweder Kanal A oder B als Dif­ferenzeingang für den rauscharmen programmierbaren Verstärker (PGA, Programmable Gain Amplifier).
Kanal A kann mit einer Verstärkung von 128 oder 64 programmiert werden, was einer differentiellen Eingangsspannung von ±20 mV bzw. ±40 mV entspricht, wenn eine 5 V Spannung an den analogen AVDD­Kontakt angelegt wird. Kanal B hat eine festgelegte Verstärkung von
32. Für die internen Register ist keine Programmierung erforderlich. Der
HX711 wird über die Anschlüsse gesteuert.
1
Das Produkt kommuniziert mit dem M5Core über GPIO (26/36).
Produktmerkmale
l Zwei wählbare diff erent ielle Eingangskanäle l On-Chip aktiver rauscharmer PGA mit wählbarer Verst ärkung
von 32, 64 und 128
l On-Chip Stromversorgungsregler für Wägezellen und ADC-
Stromversorgung
l On-Chip-Osz illator, der keine ext erne Komponente mit optio-
nalem externen Kristall benötigt l On-Chip Power-On-Reset l Einfache digitale Steuerung und serielle Schnittstelle: Steue-
rung über Kontak te, keine Program mierung erforderlic h l Wählbare Ausgangs datenrate: 10 SPS oder 80 SPS l Gleichzeitige 50 Hz und 60 Hz Netzstörunterdrückung l SOP-16 mit 16 Kontak ten l Unterstüt zt UIF low (Blockly , Python), Arduino® l Zwei Lego kompatible Löcher
Anwendungen
l Mikrowaage l Küchenw aage
Pinout / Pin Map
M5Core GPIO36 GPIO26 5V GND
Produkt Daten (DAT) Uhr (CLK) 5V GND
Technische Daten
Eingangsspannung 2.6 - 5.5 V/DC
Stromverbrauch
Betriebstemperatur -40 bis +85 °C
Abmessungen (ca.)
Betrieb: <1.5 mA Standby: <1µA
32,2 x 24,2 x 10,5 mm
2
(B x T x H)
Gewicht (ca.) 8 g
Entsorgung
Elektronische Geräte sind Wertstoffe und gehören nicht in den Hausmüll.
Entsorgen Sie das Produkt am Ende seiner Lebensdauer gemäß den geltenden gesetzlichen Bestimmungen.
Sie erfüllen damit die gesetzlichen Verpflichtungen und leisten Ihren Beitrag zum Umweltschutz.
Impressum
Dies ist eine Publikation der Conrad Electronic SE, Klaus-Conrad-Str. 1, D-92240 Hirschau (www.conrad.com).
Alle Rechte einschließlich Übersetzung vorbehalten. Reproduktionen jeder Art, z. B. Fotokopie, Mikroverfilmung, oder die Erfassung in elek­tronischen Datenverarbeitungsanlagen, bedürfen der schriftlichen Genehmigung des Herausgebers. Nachdruck, auch auszugsweise, verboten.
Die Publikation entspricht dem technischen Stand bei Drucklegung. Copyright 2019 by Conrad Electronic SE.
3
