MAKERFACTORY M5Stack Relay User guide [ml]

BN 2108279
M5Stack Relay
EN Quick Instru ctions
Version: 1
Safety Instructions
Electric Sho ck
Do not to touch connections carrying voltages above 25 V/AC or 35 V/DC.
l Be espec ially careful when dealing with voltages higher than
25 V alternat ing (AC ) or 35 V direct volt age (DC )! Even at thes e voltages it is possible to receive a fatal elect ric shoc k if you touch elec t ric al conduct ors.
Delivery Content
l Unit
l Grove c able
l VH3. 96 connect or
Development Resources
Development resources and additional product information are avail­able from:
https: //www.conrad.de/ https: //docs.makerfactory.io/
1
Description
This unit is a relay. There are 3 pins named: NO, NC, and COM. Your program will switch the pin connections between NO/COM and NC/COM through digital signal.
Features
l Swit ching: 30 V/DC or 220 V/AC, max. 3 A
l Supports UIF low, Arduino®
l Two Lego compatible holes
Applications
l Remote control of high-power appliances, suc h as ref ri-
gerators, air conditioners, TVs, etc .
Pinout / Pin Map
M5Core GPIO36 GPIO26 5V GND
Unit
Relay Controlling Pin
5V GND
Specifications
Operating Voltage 5 V/DC
Switching Voltage 30 V/DC or 220 V/AC
Switching Current (max.) 3 A
Control Single BUS
Dimensions (approx.)
Weight (approx.) 11.7 g
48.2 x 24.2 x 21.4 mm (W x D x H )
2
Disposal
Electronic devices are recyclable waste and must not be dis­posed of in the household waste.
At the end of its service life, dispose of the product in accordance with applicable regulatory guidelines.
You thus fulfill your s tatutory obligations and contribute to the pro­tection of the environment.
Legal Notice
This is a publication by Conrad Electronic SE, Klaus-Conrad-Str. 1, D­92240 Hirschau (www.conrad.com).
All rights including translation reserved. Reproduction by any method, e.g. photocopy, microfilming, or the capture in electronic data pro­cessing syst ems require the prior written approval by the editor. Reprinting, also in part, is prohibited.
This publication represent the technical status at the time of printing.
Copyright 2019 by Conrad Electronic SE.
3
BN 2108279
M5Stack Relais
DE Kurzanleitun g
Version: 1
Sicherheitshinweise
Stromschlag
Berühren Sie keine Anschlüsse, die Spannungen über 25 V/AC oder 35 V/DC aufweisen.
l Seien Sie besonders vorsicht ig beim Umgang mit Spannungen
größer als 25 V Wechsels pannung (AC) oder 35 V Gleich­spannung (DC)! Selbs t bei diesen Spannungen ist es möglich, einen tödlichen elekt ris chen Schlag zu erleiden, wenn Sie elek ­trische Leiter berühren.
Lieferumfang
l Produkt l Grove Kabel l VH3. 96 Stec ker
Ressourcen für Entwickler
Ressourcen für Entwickler und zusätzliche Informationen zum Pro­dukt sind verfügbar über:
https://www.conrad.de/ https://docs.makerfactory.io/
1
Beschreibung
Das Produkt ist ein Relais. Es sind 3 Kontakte verfügbar: NO, NC und COM. Ihr Programm steuert die Kontaktverbindungen zwischen NO/COM und NC/COM durch ein digitales Signal.
Produktmerkmale
l Schaltspannung-/ strom: 30 V/DC or 220 V/AC, max. 3 A l Unterstüt zt UIF low und Arduino® l Zwei Lego kompatible Löcher
Anwendungen
l Ferns teuerung von Hochleistungsgeräten wie Kühlsc hränk en,
Klimaanlagen, Ferns ehern usw.
Pinout / Pin Map
M5Core GPIO36 GPIO26 5V GND
Produkt
Relais Steuerpin
5V GND
Technische Daten
Betriebsspannung 5 V/DC
Schaltspannung 30 V/DC oder 220 V/AC
Schaltstrom (max.) 3 A
Steuerung Single BUS
Abmessungen (ca.)
Gewicht (ca.) 11,7 g
48,2 x 24,2 x 21,4 mm (B x T x H)
2
Entsorgung
Elektronische Geräte sind Wertstoffe und gehören nicht in den Hausmüll.
Entsorgen Sie das Produkt am Ende seiner Lebensdauer gemäß den geltenden gesetzlichen Bestimmungen.
Sie erfüllen damit die gesetzlichen Verpflichtungen und leisten Ihren Beitrag zum Umweltschutz.
Impressum
Dies ist eine Publikation der Conrad Electronic SE, Klaus-Conrad-Str. 1, D-92240 Hirschau (www.conrad.com).
Alle Rechte einschließlich Übersetzung vorbehalten. Reproduktionen jeder Art, z. B. Fotokopie, Mikroverfilmung, oder die Erfassung in elek­tronischen Datenverarbeitungsanlagen, bedürfen der schriftlichen Genehmigung des Herausgebers. Nachdruck, auch auszugsweise, verboten.
Die Publikation entspricht dem technischen Stand bei Drucklegung. Copyright 2019 by Conrad Electronic SE.
3
