M5Stack IR Sensor
EN Quick Instru ctions
Version: 1
Delivery Content
l Product
l Grove c able
Development Resources
Development resources and additional product information are available from:
https: //www.conrad.de/ https: //docs.makerfactory.io/
Description
The product integrates an IR emitter and an IR receiver.
Use it to remote control compatible IR devices.
The product connects to Port B on the M5Core (GPIO 26/36).
Features
l Inf rared Emitter
l Inf rared Receiver
l Supports UIF low (Block ly , Py thon), Arduino®
l Two Lego compatible holes
1
Pinout / Pin Map
M5Core GPIO36 GPIO26 5V GND
Product Receiver Pin Transmitter Pin 5V GND
Specifications
Input Voltage 5 V/DC
Range <5 m
Dimensions (approx.)
Weight (approx.) 4.3 g
32.2 x 24.2 x 8.9 mm
(W x D x H )
Disposal
Electronic devices are recyclable waste and must not be disposed of in the household waste.
At the end of its service life, dispose of the product in
accordance with applicable regulatory guidelines.
You thus fulfill your s tatutory obligations and contribute to the protection of the environment.
Legal Notice
This is a publication by Conrad Electronic SE, Klaus-Conrad-Str. 1, D92240 Hirschau (www.conrad.com).
All rights including translation reserved. Reproduction by any method,
e.g. photocopy, microfilming, or the capture in electronic data processing syst ems require the prior written approval by the editor.
Reprinting, also in part, is prohibited.
This publication represent the technical status at the time of printing.
Copyright 2019 by Conrad Electronic SE.
