MAKERFACTORY M5Stack Heartbeat Sensor User guide [ml]
BN 2108276
M5Stack Heartbeat Sensor
EN Quick Instru ctions
Version: 1
Delivery Content
l Product
l Grove c able
Development Resources
Development resources and additional product information are available from:
https: //www.conrad.de/ https: //docs.makerfactory.io/
Description
The product combines a pulse oxymeter and heartrate sensor into
one. It integrates a MAX30100.
Put your finger on the detection area to read heartrate and oxygen
level (oxygen saturation).
Do not use this product to assess a person’s medical
condition.
Features
l Programmable sampling rate and LED for power cons ervation.
l Low shutdow n current of 0.7 µA
1
l Supports Arduino®
l Two Lego compatible holes
Pinout / Pin Map
M5Core GPIO22 GPIO21 5V GND
Product SCL SDA 5V GND
Specifications
Input Voltage 5 V/DC
Shutdown current 0.7 µA
Protocol I2C (Address: 0x57)
Dimensions (approx.)
Weight (approx.) 4.6 g
32.2 x 24.2 x 8.2 mm
(W x D x H )
Disposal
Electronic devices are recyclable waste and must not be disposed of in the household waste.
At the end of its service life, dispose of the product in
accordance with applicable regulatory guidelines.
You thus fulfill your s tatutory obligations and contribute to the protection of the environment.
Legal Notice
This is a publication by Conrad Electronic SE, Klaus-Conrad-Str. 1, D92240 Hirschau (www.conrad.com).
All rights including translation reserved. Reproduction by any method,
e.g. photocopy, microfilming, or the capture in electronic data processing syst ems require the prior written approval by the editor.
Reprinting, also in part, is prohibited.
This publication represent the technical status at the time of printing.
Copyright 2019 by Conrad Electronic SE.
