MAKERFACTORY M5Stack Communication Module User guide [ml]

BN 2108290
M5Stack Communication Module
EN Quick Instru ctions
Version: 1
Delivery Content
l Module
Development Resources
Development resources and additional product information are avail­able from:
https: //www.conrad.de/ https: //docs.makerfactory.io/
Description
The module is a Multi-Communication-Interface-Converter.
The following interfaces are available:
l I2C
l CAN
l RS485
l TT L
The default connections are a follows:
l TT L - UART 0
l RS485 - UAR T2
Since the ESP32 pin map allows re-assigning, you can re-assign or re­map the TTL or R S485 interface to other pins (J6, J7, J9, J10).
1
Pinout / Pin Map
CAN ESP32 Chip
CAN_CS GPIO12
CAN_INT GPIO15
CAN_SCK GPIO18
CAN_MISO GPIO19
CAN_MOSI GPIO23
I2C Interface ESP32 Chi p
IIC_SDA GPIO21
IIC_SCL GPIO22
Specifications
2x I2C
Interfaces
CAN Controller MCP2515-1/SO
RS485 Transceiver SP3485EN-L/TR
Dimensions (approx.) 54 x 54 x 13 mm (W x D x H )
Weight (approx.) 13 g
1x CAN
1x RS485
1x TTL
Disposal
Electronic devices are recyclable waste and must not be dis­posed of in the household waste.
At the end of its service life, dispose of the product in accordance with applicable regulatory guidelines.
You thus fulfill your s tatutory obligations and contribute to the pro­tection of the environment.
2
Legal Notice
This is a publication by Conrad Electronic SE, Klaus-Conrad-Str. 1, D­92240 Hirschau (www.conrad.com).
All rights including translation reserved. Reproduction by any method, e.g. photocopy, microfilming, or the capture in electronic data pro­cessing syst ems require the prior written approval by the editor. Reprinting, also in part, is prohibited.
This publication represent the technical status at the time of printing.
Copyright 2019 by Conrad Electronic SE.
3
BN 2108290
M5Stack Kommunikations-Modul
DE Kurzanleitun g
Version: 1
Lieferumfang
l Modul
Ressourcen für Entwickler
Ressourcen für Entwickler und zusätzliche Informationen zum Pro­dukt sind verfügbar über:
https://www.conrad.de/ https://docs.makerfactory.io/
Beschreibung
Das Modul ist ein Schnittstellenconverter. Folgende Schnittstellen stehen zur Verfügung: l I2C l CAN l RS485 l TTL Die Standardverbindungen sind: l TTL - UART 0 l RS485 - UAR T2 Da die ESP32-Pinzuordnung eine Neuzuordnung ermöglicht, können
Sie die TTL- oder RS485-Schnittstelle anderen Pins zuordnen (J6, J7, J9, J10).
1
Pinout / Pin Map
CAN ESP32 Chip
CAN_CS GPIO12
CAN_INT GPIO15
CAN_SCK GPIO18
CAN_MISO GPIO19
CAN_MOSI GPIO23
I2C Interface ESP32 Chi p
IIC_SDA GPIO21
IIC_SCL GPIO22
Technische Daten
2x I2C
Schnittstellen
CAN-Controller MCP2515-1/SO
RS485-Transceiver SP3485EN-L/TR
Abmessungen (ca.) 54 x 54 x 13 mm (B x T x H)
Gewicht (ca.) 13 g
1x CAN 1x RS485 1x TTL
Entsorgung
Elektronische Geräte sind Wertstoffe und gehören nicht in den Hausmüll.
Entsorgen Sie das Produkt am Ende seiner Lebensdauer gemäß den geltenden gesetzlichen Bestimmungen.
Sie erfüllen damit die gesetzlichen Verpflichtungen und leisten Ihren Beitrag zum Umweltschutz.
2
Impressum
Dies ist eine Publikation der Conrad Electronic SE, Klaus-Conrad-Str. 1, D-92240 Hirschau (www.conrad.com).
Alle Rechte einschließlich Übersetzung vorbehalten. Reproduktionen jeder Art, z. B. Fotokopie, Mikroverfilmung, oder die Erfassung in elek­tronischen Datenverarbeitungsanlagen, bedürfen der schriftlichen Genehmigung des Herausgebers. Nachdruck, auch auszugsweise, verboten.
Die Publikation entspricht dem technischen Stand bei Drucklegung. Copyright 2019 by Conrad Electronic SE.
3
