Majority Newnham
DAB
CB3-DAB-WHT/BLK
/ DAB+ / FM Radio
User Guide
Contents
3
F
R
Controls and Functions.............................. 1
What’s in the Box? ..................................2
Instruction Guide . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
Basic Operation...........................................3
DAB Radio and Set up Preset for DAB Radio................4
FM Radio and Set up Preset for FM Radio ..................6
Station Information for DAB and FM Radio.................8
Clock and Date Setting...................................10
Dual Alarm Setting ......................................12
Alarm Sound and Snooze ................................13
Other Functions ...................................14
Technical Specification .............................17
Warranty ..........................................17
Troubleshooting Guide ............................18
Important Safety Information ......................19
Y
Y
E
T
N
A
R
R
A
W
A
R
Watch video tutorials and register
your product for a FREE 3-year
E
E
E
D
E
D
N
warranty at www.majorityradios.co.uk
X
T
E
Instructions GuideControls and Functions
10
12131411
1. Power/Source
2. Alarm/Sleep
3. Info/Menu
4. Preset
5. Select/Snooze
6. Scan
7. Previous
123
567
8. Next
9. Volume +/-
10. Display Screen
11. On/Off Switch
12. DC 5V,1A
Power
Connector
15
4
9
8
13. Charging Light
Indicator
14. 3.5mm
Headphone
Socket
15. Antenna
1
Instructions GuideWhat’s in the Box?
● Majority Newnham DAB / DAB+ Radio Clock
● UK Standard Plug DC 5V,1A Power Supply
● User Guide
2
Instructions Guide
Please note all (Ref.) refer to the Controls and Functions
mapping guide on Page 1.
Basic Operation
Plug the connector into the back of the system labelled DC 5V
(Ref.12) and the power supply into the mains, if the station
needs charging.
Position the Power Supply switch on the back of the system to
‘ON’ (Ref.11).
Ensure the antenna (Ref.15) is extended as far as possible so that
you can rotate it, enabling you to get the best possible signal.
The radio will be in standby mode showing the time and date.
This will automatically update after the first time you use the
DAB radio.
Press the ‘Power/Source’ button to turn on the unit (Ref.1).
It will automatically take you to DAB radio mode or the
previous mode you were using.
To change the mode press the ‘Power/Source’ button (Ref.1) to
switch between DAB Radio and FM Radio.
When DAB Radio is activated for the first time it will
automatically start scanning and storing all stations that have a
good signal. If the display shows “No Signal”, press the scan
button. It will take a few minutes for all the stations to be
scanned and saved. Use the ‘Prev’ and ‘Next’ buttons (Ref.7/8)
to scroll through the stations.
3
Instructions Guide
Standby
To place the system in standby mode, press and hold the
‘Power/Source’ button (Ref.1). To turn off fully, press the button
on rear of the unit (Ref.11) and switch off at the mains. The cord
must be out of reach of children.
DAB / DAB+ Radio
Press the ‘Power/Source’ button (Ref.1) to switch to DAB Radio.
On first use it will automatically scan all stations and save them.
Fully extend the antenna (Ref.15).
To auto scan, press the ‘Scan’ button (Ref.6) and then release.
This will start scanning up the frequency band and store all
stations that have a good signal.
The radio will automatically save all the stations with a strong
signal up to 240 MHz.
After searching has finished it will automatically play the first
station stored.
4
IMPORTANT: Please make sure you have
extended the antenna (Ref.15) to its full
length. This will then enable you to rotate it
to get the best signal.
Instructions GuideInstructions Guide
To listen to all stations that have been stored use the ‘Next’ and
‘Prev’ buttons (Ref.7/8) to scroll through them. Once you have
chosen, press ‘Select/Snooze’ button (Ref.5).
The radio will display station information when you press the
‘Info/Menu’ button (Ref.3). Press multiple times for different
information types.
When you power up the radio again after switching off, it will
automatically tune to the same station (DAB or FM) that was
last selected.
How to store a preset radio station
Up to 10 preset stations can be set. To store a station that you
are currently playing:
Press and hold ‘Preset’ button (Ref.4).
“Preset Store <1: (Empty)” will show on the display.
Press ‘Prev’ (Ref.7) or ‘Next’ (Ref.8) button to change the “<1” to
the number you want to store the station as. Then press ‘Select/
Snooze’ button (Ref.5) to save. The display will then show
“Preset (1) stored”.
How to play a preset radio station
Press the ‘Preset’ button (Ref.4).
Press ‘Prev’ (Ref.7) or ‘Next’ (Ref.8) button to scroll through your
preset stations. You can store up to 10 presets.
Press ‘Select/Snooze’ button (Ref.5) to select your choice.
5
Instructions Guide
FM Radio
Press the ‘Power/Source’ button (Ref.1) multiple times to switch
to FM. The first time you do this FM frequency “87.5 MHz” will
be displayed on the screen.
Fully extend the antenna (Ref.15).
To auto scan, press and release the ‘Scan’ button (Ref.6).
This will then start scanning up the frequency band and play
the first station it finds with a good signal.
To scan down the frequency band, press and hold the ‘Scan’
button (Ref.6) for a few seconds.
How to tune a specific frequency manually
To listen to a specific frequency press and hold the ‘Nex t’
button (Ref.8) to search forward quickly and ‘Prev’ button
(Ref.7) to search back quickly. It will stop searching when the
button is released. To search slowly press the ‘Next’ and ‘Prev’
button (Ref.7/8) multiple times rather than holding.
IMPORTANT: Please make sure you have
extended the antenna (Ref.15) to its full
length. This will then enable you to rotate it
to get the best signal.
6
Instructions Guide
How to set Mono or Stereo
Press the ‘Select/Snooze’ button (Ref.5) multiple times to
change between Mono and Stereo. The receiver will
automatically switch between Stereo and Mono You can,
however, override this using the above instructions.
How to store a preset radio station
Up to 10 preset stations can be set. To store a station that you
are currently playing:
Press and hold ‘Preset’ button (Ref.4).
“Preset Store <1: (Empty)” will show on the display.
Press ‘Prev’ (Ref.7) or ‘Next’ (Ref.8) button to change the “<1” to
the number you want to store the station as. Then press ‘Select/
Snooze’ button (Ref.5) to save. The display will then show
“Preset (1) stored”.
How to play a preset radio station
Press the ‘Preset’ button (Ref.4).
Press the ‘Prev’ (Ref.7) or ‘Next’ (Ref.8) button to scroll through
your preset stations. You can store up to 10 presets.
Press ‘Select/Snooze’ button (Ref.5) to select your choice.
7
Instructions Guide
Station Information for DAB and FM Radio
DAB
/ DAB+ Radio
Press the ‘Info/Menu’ button (Ref.3) repeatedly to show the
different programme information.
Bit Rate: Shows the data rate at which the signal is being
transmitted.
Bit Error Rate (BER): Provides details of the signal error rate.
Channel and Frequency: Displays the station’s transmission
channel number and frequency.
PTY (Programme Type): Shows the type and description of the
programme provided by the DAB station.
Time and Date: Displays the time and date information
provided by the broadcaster.
DAB Indication: Indicates DAB mode.
Dynamic Label Segment (DLS): Displays scrolling text
information supplied by the broadcaster.
8
Instructions Guide
3
F
R
FM Radio
Press the ‘Info/Menu’ button (Ref.3) repeatedly to show the
different programme information.
Signal Strength: Displays a signal bar with the strength of the
current station.
Time and Date: Displays the time and the date.
Frequency: Displays the station’s transmission frequency.
Audio Type: Displays the audio type of the station you are
listening to. It will either be Stereo or Mono.
Radio Text: Displays scrolling text information supplied by the
broadcaster.
Programme Type: Displays a description of the type of
programme provided by the broadcaster.
Y
Y
E
T
N
A
R
R
A
W
A
R
Watch video tutorials and register
your product for a FREE 3-year
E
E
E
D
E
D
N
warranty at www.majorityradios.co.uk
X
T
E
9
Instructions Guide
Clock and Date Setting
Manually Setting the Time
Ensure the unit is in working mode. The time will automatically
update after the first time of using DAB Radio, but you can still
set the time manually as follows:
Press and hold the ‘Info/Menu’ button (Ref.3).
Use the ‘Prev/Next’ buttons (Ref.7/8) to choose your option.
Choose “Time/Date” and press the ‘Select/Snooze’ button
(Ref.5).
The hour will then flash on the display screen.
Press the ‘Prev’ (Ref.7) or ‘Next’ (Ref.8) button until the required
hour is displayed.
To confirm the hour press the ‘Select/Snooze’ button (Ref.5).
The minutes will then flash on the display screen. Press the
‘Prev’ (Ref.7) or ‘Next’ (Ref.8) buttons press until the required
minute is displayed.
To confirm the minute press the ‘Select/Snooze’ button (Ref.5).
The time is now set.
10
Instructions Guide
3
F
R
Manually Setting the Date
The date can be changed straight after changing the time.
The year will flash on the display screen. Press the ‘Prev’ (Ref.7)
or ‘Next’ (Ref.8) buttons until the required year is displayed.
To confirm the year, press the ‘Select/Snooze’ button (Ref.5).
The month will then flash on the display screen. Press the ‘Prev’
(Ref.7) or ‘Next ’ (Ref.8) buttons until the required month is
displayed.
To confirm the month press the ‘Select/Snooze’ button (Ref.5).
The day will then flash on the display screen. Press the ‘Prev’
(Ref.7) or ‘Next ’ (Ref.8) buttons until the required date is
displayed.
To confirm the date, press the ‘Select/Snooze’ button (Ref.5).
Y
Y
E
T
N
A
R
R
A
W
A
R
Watch video tutorials and register
your product for a FREE 3-year
E
E
E
D
E
D
N
warranty at www.majorityradios.co.uk
X
T
E
11
Instructions Guide
Dual Alarm Setting
Alarm 1/Alarm 2 Setting
Press (do not hold) the ‘Alarm/Sleep’ button (Ref.5) and
“Alarm 1” will be displayed. Press twice for “Alarm 2”.
Press the ‘Select/Snooze’ button (Ref.5) to use Alarm 1.
To turn the Alarm on, press the ‘Next’ button (Ref.8) so that
“ON” is flashing, then press the ‘Select/Snooze’ button (Ref.5)
to confirm.
The hour digits for the alarm will flash. Press the ‘Prev’ or ‘Next’
buttons (Ref.7/8) to change the hour and press the ‘Select/
Snooze’ button (Ref.5) to confirm.
Press the ‘Prev’ or ‘Next’ buttons (Ref.7/8) to change the minute
and press ‘Select/Snooze’ (Ref.5) to confirm.
Press the ‘Prev’ or ‘Next’ buttons (Ref.7/8) to change the volume
and press ‘Select/Snooze’ (Ref.5) to confirm.
Press the ‘Prev’ or ‘Next’ buttons (Ref.7/8) to change which
sound you would like: Alarm, DAB or FM Radio. Press the
‘Select/Snooze’ button (Ref.5) to confirm.
To set Alarm 2, follow Alarm 1 instructions but choose
“Alarm 2 Set”.
NOTE: You can press the ‘Info/Menu’ button (Ref.3) to go back
to the previous step when programming the alarm.
12
Instructions Guide
To Turn off Alarm 1 or Alarm 2
Press the ‘Alarm/Sleep’ button (Ref.2) and “Alarm 1” will be
displayed. Choose which alarm you would like to turn off using
the ‘Next’ (Ref.8) button. Press the ‘Select/Snooze’ (Ref.5)
button to confirm.
To turn the alarm off, press the ‘Next’ (Ref.8) button so that the
word “OFF” is flashing and press the ‘Select/Snooze’ button
(Ref.5) to confirm.
Alarm Sound and Snooze
Alarm Sound
The alarm will sound for a maximum of 60 minutes unless it is
manually turned off.
Snooze/Switch off Alarm when Sounding
When the alarm sounds, press the ‘Select/Snooze’ button
(Ref.5) to snooze for another 9 minutes. The radio will go into
standby mode.
To turn the alarm off completely, press the ‘Alarm/Sleep’ button
(Ref. 2).
13
Instructions Guide
3
F
R
Other Functions
Sleep Setting
This enables you to programme the radio to switch off at a
selection of set times up to 120 minutes from activation.
Press and hold the ‘Alarm/Sleep’ button (Ref.2) for 1 second
and release.
Using the ‘Prev/Next’ (Ref.7/8) buttons choose from: 5mins,
15mins, 30mins, 45min, 60mins, 90mins, 120mins or OFF.
When your choice is displayed press the ‘Select/Snooze’ button
(Ref.5). The system will automatically start the timer.
To turn the sleep timer off, follow the above instructions and
choose “OFF” from the choices.
Once the timer has been set, the minutes will count down on
the display screen. For example, if set to turn off in 5 minutes
“S5” will flash, counting down to “S0”. The radio will then go into
standby mode.
14
Y
Y
E
T
N
A
R
R
A
W
A
R
Watch video tutorials and register
your product for a FREE 3-year
E
E
E
D
E
D
N
warranty at www.majorityradios.co.uk
X
T
E
Instructions Guide
System Reset
Press and hold the ‘Info/Menu’ button (Ref.3).
Use the ‘Prev/Next’ buttons (Ref.7/8) to make your selection
Choose “Factory Reset” and press the ‘Select/Snooze’ button
(Ref.5). The display screen will show “Factory Reset Yes or No?”
Use the ‘Next’ button (Ref.8) to choose between “Yes” and “No”.
Press the ‘Select/Snooze’ button (Ref.5) to confirm.
SW Version – Software Version Display
Press and hold the ‘Info/Menu’ button (Ref.3).
Use the ‘Prev/Next’ button (Ref.7/8) to make your selection.
Choose “SW Version” and press the ‘Select/Snooze’ button (Ref.5).
Headphones
You can listen to your DAB/FM Radio using headphones.
Just plug the your headphones into the 3.5mm socket at the
rear of the unit (Ref.14).
15
Instructions Guide
Play Time
Your radio has a play time of around 4-6 hours. To charge it,
plug your radio into the mains with the power adapter
provided.
Charging
The unit will charge in standby and working mode if it is
connected to the mains. To confirm that the unit is on charge,
a red light will appear on the back of the system (Ref .13).
The unit takes approximately 2.5 Hours to fully charge, after
which the light will show blue.
16
3
R
Technical Specifications and Warranty
Technical Specifications
Power Supply In-built Battery
Mode
Output Connector 3.5mm Earphone Socket
Aerial Integral Telescopic Aerial
Warranty
All products come with a standard 12 month warranty.
All items must be registered on www.majorityradios.co.uk
for the warranty to be valid. Once on the web page use the
menu to find “register your product”.
You will also be given the chance to extend your warranty for
an additional 24 months free of charge.
FM (87.5MHz – 108MHz) DAB /
DAB+
(174 -240 MHz)
Y
Y
E
T
N
A
R
R
A
W
A
R
Watch video tutorials and register
F
your product for a FREE 3-year
E
E
D
E
warranty at www.majorityradios.co.uk
X
E
T
D
E
N
17
Troubleshooting Guide
Observation Potential cause/solution
No sound The station is not tuned in. Fine tune the station.
The volume is set to a low position. Increase the volume.
Headphones may be connected. Disconnect the
headphones.
Buttons are not
working
FM: Static sound
DAB: Burbling/
intermittent cut-out
Sound is distorted The volume is too high. Adjust the volume control.
Desired station not
found
Display shows
"No Service"
Display is blank This may occur if the broadcaster changes the label of a
Time and date
not setting
automatically
Turn off the unit and turn on after a few seconds.
Signal reception is low. Adjust the aerial or move the unit
to a stonger signal location.
Rescan stations.
Weak signal. Use the manual tune function.
There is no DAB coverage in your area, or poor reception.
Adjust the position of the aerial, or move the unit to a
stronger signal location.
service or removes a label while tuned. The radio will try
to retune or perform a scan.
For the time and date to set automatically you need to
turn on the system and switch to DAB radio and let this
scan. Then press the ‘Power Mode’ button and the
system will go into standby and the date and clock will
have been updated automatically.
18
IMPORTANT SAFETY INFORMATION
1. Read these instructions.
2. Keep these instructions. Instructions are also
available for download at
www.majorityradios.co.uk
3. Heed all Warnings.
4. Follow all instructions.
5. Do not clean the apparatus near or with water.
6. Clean only with a dry cloth.
7. Do not block any ventilation openings.
Install in accordance with the manufacturer’s
instructions.
8. Do not install near any heat sources such as
radiators, heat registers, stoves, or other
apparatus (including amplifiers) that produce
heat.
9. Protect the power cord from being walked on or
pinched particularly at plugs, convenience
receptacles, and the point where they exit from
the apparatus.
10. Only use attachments/accessories
specified by the manufacturer.
11. Unplug this apparatus during light storms or
when unused for long periods of time.
12. Refer all servicing to qualified service
personnel.
Servicing is required when the apparatus has
been damaged in any way, such as powersupply cord or plug is damaged, liquid has
been spilled or objects have fallen into the
apparatus, the apparatus has been exposed to
rain or moisture, does not operate normally or
has been dropped.
13. No naked flame sources, such as lit candles,
should be placed on the apparatus.
14. Dispose of used electrical products and
batteries safely according to your local
authority and regulations.
CAUTION
RISK OF ELECTRIC SHOCK
DO NOT OPEN
ADDITIONAL WARNINGS
The apparatus shall not be exposed to dripping or
splashing and no objects filled with liquid, such as
vases, shall be placed on apparatus.
Main plug is used to disconnect device and it
should remain readily operable during intended
use. In order to disconnect the apparatus from the
main mains completely, the mains plug should be
disconnected from the main socket outlet
completely.
Battery shall not be exposed to excessive heat
such as sunshine, fire or the like.
RECYCLING ELECTRICAL PRODUCTS
You should now recycle your waste electrical
goods and in doing so help the environment.
This symbol means an electrical product
should not be disposed of with normal
household waste. Please ensure it is
taken to a suitable facility for disposal
when finished with.
IMPORTANT: Please read all instructions carefully
before use and keep for future reference
Risk of electric shock.
Do not open
Read all instructions carefully before use
and keep for future reference
When servicing, use only identical
replacement parts
ATTENTION
RISQUE D'ELECTROCUTION
NE PAS OUVRIR
IMPORTANT: Please read all instructions carefully
before use and keep for future reference
19
20
21
www.majorityradios.co.uk
Loading...
