Maisi M30, M20 Quick Start Manual

QUICK START GUIDE

Maisi Camcorder M30

Page 1 of 16

PRIOR TO USE

* Install the device near the rear-view mirror to obtain the best open-field view. Do NOT install
the camcorder in a location that will obstruct your required driving view.
* Make sure that the lens is within the wiping range of the windscreen wiper to ensure a clear
view even when it rains.
* Do not touch the lens with your fingers. Finger grease may be left on the lens and will result
in unclear videos or snapshots. Clean the lens on a regular basis.
* Do not install the device on a tinted window. Doing so may damage the tint film.
* Make sure that the installation position is not hindered by the tinted window.

CAUTION

* Use the authorized car charger only.
* Never disassemble or attempt to repair of this product. Doing so may damage the camcorder,
cause electric shock and void your product warranty.
* Never short-circuit the battery.
* Set up time and date accurately before you use this camcorder.
* Exposing the camcorder to open flames can cause explosion.
* Due to local laws and vehicles safety considerations, do not manually operate the camcorder
while driving.
* The supplier is NOT responsible for the loss of any data/content during operation.
* Strictly observe relevant laws as this product cannot be used for any illegal purpose. The
user is responsible for any legal matters.

Before you start using the Car Camcorder it is assumed that you agree to the above
statements.

How to contact us?

If you come across any issue, please feel free to drop us a quick email at:
[e-mail]. We answer most emails within 12-24 hours. If you purchase from
Amazon, you can contact us via Amazon Message as well.

Page 2 of 16

1 Introduction

Thank you for purchasing this MAISI camcorder. This camcorder is specifically designed for
real time video and audio recording when driving.

1.1 Features

* High Dynamic Range Imaging (HDR)
* HD Image 2304*1296
* Up to 150 Degree Wide Angle Glass Lens & IR-Filter
* Built-in G-sensor
* Collision Detection
* Emergency Recording File

1.2 Package Contents

The package contains the following items. In case there is any missing or damaged item,
contact us immediately.

* 1x Camcorder
* 1x Mounting Bracket
* 2x Red 3M Pad
* 1x Power Charger (4M)
* 1x USB Cable
* 1x Quick Start Guide

Page 3 of 16

1.3 Product Overview

Button Illustration

Number

Button Name

Button Illustration

①

Menu Button

1.Press to bring up the Record/Picture/Preview/
System menu;

2. Press to achieve emergency recording while the
device is recording.

②

Mode button

Press to switch among Record/ Picture/Preview
Mode.

③

Up/Mic

1.Press to go upward in the menu;

2.Press to enable/disable Microphone

④

Down/EV

1.Press to go downward in the menu;

2.Press to enable/disable Microphone

⑤

Left/LED

1.Press to go left in the menu;

2. Press to enable/disable front LED light

⑥

Right

Press to go right in the menu;

⑦

Power Button

1.Long press to turn on/off the device

2.Short press to turn on/off the screensaver
function (recording continues)

Page 4 of 16

⑧

OK

1. Press to start/stop recording;

2. Press to take pictures;

3. Press to confirm the setting you modified.

⑨

GPS Port

To insert the GPS dongle

⑩

Charging Indicator

When the battery is charging, this indicator will
blink red light.

⑪

Recording Indicator

When the camcorder is recording, this indicator will
blink blue light.

⑫

GPS Indicator

GPS dongle required.

⑬

Camera Lens

The camera lens is fixed and provide a viewing
angle of approx. 150°

⑭

Front LED

For light compensation in dark/dim environment

⑮

USB Port

For data transmission

⑯

HDMI Port

For HDMI connection to TV etc.

⑰

Reset Button

Press to reset the camcorder in abnormal
situations.

⑱

Micro SD Card Slot

Please insert the SD card with the gold plate facing
the back of the camera; Press to eject the SD card

⑲

DC IN Port

For power supply

Note:

* Power Button: Press it once to turn on the camera, long press (2-3s) to turn off the camera.
Press it once when recording to turn the camera into screen saver mode.
* To go to Menu, make sure the camera is not recording. If the camera is recording, press OK
button to stop the recording first, then press Menu button to go to Menu.
* Same rules apply (stop recording first) if you want to change the camera from recording
mode to Picture Mode or Playback Mode.

1.4 Screen Interface Illustration

Page 5 of 16

Number

Icon Name

Icon Illustration

①

Movie Camera

Indicating the camcorder is in Recording Mode

②

Battery

Indicating the remaining power for the device. The
average life of the battery is about 30min. Please
charger your camcorder when the power is low.

③

Micro SD Card

When the card is properly inserted and recognized by
the camcorder, this icon will show up. Otherwise it will
be a “X”.

④

G-Sensor

Indicating the sensitivity of the G-sensor you set.
The higher the blue color stands, the more sensitive it
is.

⑤

Motion Detection

This icon shows up only when motion detection is
enabled. Please disable it while driving.

⑥

Emergency Recording

This Icon shows up when collision/vibration occurs and
followed by device mandatory file protection (see
G-Sensor). You can enable the emergency recording
by pressing the Menu button while recording.

⑦

Microphone

It only shows up in Recording Mode, press the
“Left/MIC” button to turn it On/Off.

⑧

GPS

GPS dongle required for this function.

⑨

HDR

When resolution is set to 1920x1080@30P HDR, it
appears. HDR function can achieve more clear images
in dark//dim environment.

⑩

Speed Limit

GPS dongle required for this function.

⑪

ADAS

GPS dongle required for this function.

⑫

LED

Press Left button to enable/disable the front LED light.

⑬

EV

Exposure Value, “+” means brighter, “-“ means dimmer

⑭

Video Resolution

The video resolution you set.

⑮

Loop Recording

The loop setting time you chosen will be displayed in
the middle of this icon. For the current setting, the loop
time is 3 Minutes.

⑯

Date/Time Stamp

If enabled, the model number/car plate number/date/
time/ will be displayed on the right bottom corner on the
screen, and this info will be saved on the recording/
pictures.
