© Baxi Heating UK Ltd 2009
Main HE
Condensing
Central Heating Boiler
User Guide and
Important Warranty Information
Please keep these instructions in a safe place.
If you move house, please hand them over to the next occupier.
2
© Baxi Heating UK Ltd 2009
Natural Gas
Main 9 HE
G.C.No41 474 01
Main 12 HE
G.C.No41 474 02
Main 15 HE
G.C.No41 474 03
Main 18 HE
G.C.No41 474 04
Main 24 HE
G.C.No41 474 05
© Baxi Heating UK Ltd 2009 All rights reserved. No part of this publication may
be reproduced or transmitted in any form or by any means, or stored in any
retrieval system of any nature (including in any database), in each case whether
electronic, mechanical, recording or otherwise, without the prior written
permission of the copyright owner, except for permitted fair dealing under
Copyrights, Designs and Patents Act 1988.
Applications for the copyright owner’s permission to reproduce or make other
use of any part of this publication should be made, giving details of the proposed
use, to the following address:
The Company Secretary, Baxi Heating UK Ltd, The Wyvern Business Park,
Stanier Way, Derby, DE21 6BF.
Full acknowledgement of author and source must be given.
WARNING: Any person who does any unauthorised act in relation to a
copyright work may be liable to criminal prosecution and civil claims for damages.
1.0 Quick Reference Guide 3
2.0 Troubleshooting 4
3.0 Clearances/Care of the Boiler 6
4.0 Legislation 7
5.0 Warranty & Service 8
Section Page
Contents
Boiler Controls - see opposite page
for Operating Quick Reference Guide
The Benchmark Scheme
Baxi Heating UK Ltd is a licensed member of the Benchmark Scheme which aims
to improve the standards of installation and commissioning of domestic heating
and hot water systems in the UK and to encourage regular servicing to optimise
safety, efficiency and performance.
Benchmark is managed and promoted by the Heating and Hotwater Industry
Council. For more information visit www.centralheating.co.uk
0086
ISO 9001
FM 00866
1.0 Quick Reference Guide
3
© Baxi Heating UK Ltd 2009
Lockout
(Red Light)
Burner On
(Green Light)
Mains On
(Green Light)
Boiler Temperature
Control Knob
If Lockout Light is ON or flashing the boiler will need resetting. If
Lockout occurs persistently consult your Installer or Service Engineer.
This indicates that the Burner has fired up and is heating
your system.
This indicates that there is electricity to the Boiler.
Turn the Boiler Temperature Control Knob clockwise to
increase or anticlockwise to decrease the temperature.
Boiler Temperature Control
Turn the Boiler Temperature Control Knob
clockwise to increase or anticlockwise to
decrease the temperature.
Resetting the Boiler
If the Red Lockout Light ( ) is ON or
FLASHING, turn the temperature control
knob to the off (•) position and when the
lockout light goes off, turn control knob back
to required setting, the boiler will fire up and
return to normal operation. If lockout occurs
frequently a fault is indicated and you should
contact your installer.
