USB MAGNEPRINT SWIPE READER

WITH ENCRYPTION

TECHNICAL REFERENCE MANUAL

PART NUMBER 99875338-3

MARCH 2009

REGISTERED TO ISO 9001:2000

1710 Apollo Court

Seal Beach, CA 90740

Phone: (562) 546-6400

FAX: (562) 546-6301

Technical Support: (651) 415-6800

www.magtek.com

MagTek®, Inc.

Printed in the United States of America

Information in this document is subject to change without notice. No part of this document may be reproduced or transmitted in any form or by any means, electronic or mechanical, for any purpose, without the express written permission of MagTek, Inc.

MagTek is a registered trademark of MagTek, Inc.

REVISIONS

Rev Number Date Notes

1 5 May 06 Initial Release 2 14 Sep 07 Corrected default setting for polling interval 3 9 Mar 09 Updated MagnePrint Status; updated Warranty and

Agency information

LIMITED WARRANTY

MagTek warrants that the products sold pursuant to this Agreement will perform in accordance with MagTek’s published specifications. This warranty shall be provided only for a period of one year from the date of the shipment of the product from MagTek (the “Warranty Period”). This warranty shall apply only to the “Buyer” (the original purchaser, unless that entity resells the product as authorized by MagTek, in which event this warranty shall apply only to the first repurchaser).

During the Warranty Period, should this product fail to conform to MagTek’s specifications, MagTek will, at its option, repair or replace this product at no additional charge except as set forth below. Repair parts and replacement products will be furnished on an exchange basis and will be either reconditioned or new. All replaced parts and products become the property of MagTek. This limited warranty does not include service to repair damage to the product resulting from accident, disaster, unreasonable use, misuse, abuse, negligence, or modification of the product not authorized by MagTek. MagTek reserves the right to examine the alleged defective goods to determine whether the warranty is applicable.

Without limiting the generality of the foregoing, MagTek specifically disclaims any liability or warranty for goods resold in other than MagTek’s original packages, and for goods modified, altered, or treated without authorization by MagTek.

Service may be obtained by delivering the product during the warranty period to MagTek (1710 Apollo Court, Seal Beach, CA 90740). If this product is delivered by mail or by an equivalent shipping carrier, the customer agrees to insure the product or assume the risk of loss or damage in transit, to prepay shipping charges to the warranty service location, and to use the original shipping container or equivalent. MagTek will return the product, prepaid, via a three (3) day shipping service. A Return Material Authorization (“RMA”) number must accompany all returns. Buyers may obtain an RMA number by contacting Technical Support at (888) 624-8350.

EACH BUYER UNDERSTANDS THAT THIS MAGTEK PRODUCT IS OFFERED AS IS.

MAGTEK MAKES NO OTHER WARRANTY, EXPRESS OR IMPLIED, AND

MAGTEK DISCLAIMS ANY WARRANTY OF ANY OTHER KIND, INCLUDING ANY WARRANTY OF MERCHANTABILITY OR FITNESS FOR A PARTICULAR PURPOSE.

IF THIS PRODUCT DOES NOT CONFORM TO MAGTEK’S SPECIFICATIONS, THE SOLE REMEDY SHALL BE REPAIR OR REPLACEMENT AS PROVIDED ABOVE. MAGTEK’S LIABILITY, IF ANY, SHALL IN NO EVENT EXCEED THE TOTAL AMOUNT PAID TO MAGTEK UNDER THIS AGREEMENT. IN NO EVENT WILL MAGTEK BE LIABLE TO THE BUYER FOR ANY DAMAGES, INCLUDING ANY LOST PROFITS, LOST SAVINGS, OR OTHER INCIDENTAL OR CONSEQUENTIAL DAMAGES ARISING OUT OF THE USE OF, OR INABILITY TO USE, SUCH PRODUCT, EVEN IF MAGTEK HAS BEEN ADVISED OF THE POSSIBILITY OF SUCH DAMAGES, OR FOR ANY CLAIM BY ANY OTHER PARTY.

LIMITATION ON LIABILITY EXCEPT AS PROVIDED IN THE SECTIONS RELATING TO MAGTEK’S LIMITED WARRANTY, MAGTEK’S

LIABILITY UNDER THIS AGREEMENT IS LIMITED TO THE CONTRACT PRICE OF THIS PRODUCT. MAGTEK MAKES NO OTHER WARRANTIES WITH RESPECT TO THE PRODUCT, EXPRESSED OR IMPLIED,

EXCEPT AS MAY BE STATED IN THIS AGREEMENT, AND MAGTEK DISCLAIMS ANY IMPLIED WARRANTY, INCLUDING WITHOUT LIMITATION ANY IMPLIED WARRANTY OF MERCHANTABILITY OR FITNESS FOR A PARTICULAR PURPOSE.

MAGTEK SHALL NOT BE LIABLE FOR CONTINGENT, INCIDENTAL, OR CONSEQUENTIAL DAMAGES TO PERSONS OR PROPERTY. MAGTEK FURTHER LIMITS ITS LIABILITY OF ANY KIND WITH RESPECT TO THE PRODUCT, INCLUDING ANY NEGLIGENCE ON ITS PART, TO THE CONTRACT PRICE FOR THE GOODS.

MAGTEK’S SOLE LIABILITY AND BUYER’S EXCLUSIVE REMEDIES ARE STATED IN THIS SECTION AND IN THE SECTION RELATING TO MAGTEK’S LIMITED WARRANTY.

iii

FCC WARNING STATEMENT

This equipment has been tested and was found to comply with the limits for a Class B digital device pursuant to Part 15 of FCC Rules. These limits are designed to provide reasonable protection against harmful interference when the equipment is operated in a residential environment. This equipment generates, uses, and can radiate radio frequency energy and, if not installed and used in accordance with the instruction manual, may cause harmful interference with radio communications. However, there is no guarantee that interference will not occur in a particular installation.

FCC COMPLIANCE STATEMENT

This device complies with Part 15 of the FCC Rules. Operation of this device is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.

CANADIAN DOC STATEMENT

This digital apparatus does not exceed the Class B limits for radio noise from digital apparatus set out in the Radio Interference Regulations of the Canadian Department of Communications.

Le présent appareil numérique n’émet pas de bruits radioélectriques dépassant les limites applicables aux appareils numériques de la classe B prescrites dans le Réglement sur le brouillage radioélectrique édicté par le ministère des Communications du Canada.

This Class B digital apparatus complies with Canadian ICES-003.

Cet appareil numériqué de la classe B est conformé à la norme NMB-003 du Canada.

CE STANDARDS

Testing for compliance with CE requirements was performed by an independent laboratory. The unit under test was found compliant with standards established for Class B devices.

UL/CSA

This product is recognized per Underwriter Laboratories and Canadian Underwriter Laboratories 1950.

RoHS STATEMENT

When ordered as RoHS compliant, this product meets the Electrical and Electronic Equipment (EEE) Reduction of Hazardous Substances (RoHS) European Directive 2002/95/EC. The marking is clearly recognizable, either as written words like “Pb-free”, “lead-free”, or as another clear symbol ( ).

SECTION 1. FEATURES AND SPECIFICATIONS..................................................................................................1

FEATURES............................................................................................................................................................2

HARDWARE CONFIGURATION ..........................................................................................................................2

ACCESSORIES.....................................................................................................................................................2

REFERENCE DOCUMENTS................................................................................................................................3

SPECIFICATIONS.................................................................................................................................................4

SECTION 2. INSTALLATION...................................................................................................................................7

USB CONNECTION..............................................................................................................................................7

WINDOWS PLUG AND PLAY SETUP..................................................................................................................8

MOUNTING ...........................................................................................................................................................8

SECTION 3. OPERATION......................................................................................................................................11

LED INDICATOR.................................................................................................................................................11

CARD READ........................................................................................................................................................11

SECTION 4. USB COMMUNICATIONS.................................................................................................................13

HID USAGES.......................................................................................................................................................13

MAGNETIC STRIPE READER USAGE PAGE (HID) .........................................................................................14

REPORT DESCRIPTOR (HID)............................................................................................................................14

MAGNETIC STRIPE READER USAGE PAGE (KB)........................................................................................... 16

REPORT DESCRIPTOR (KB).............................................................................................................................17

CARD DATA (HID) ..............................................................................................................................................18

Track 1 Decode Status....................................................................................................................................19

Track 2 Decode Status....................................................................................................................................19

Track 3 Decode Status....................................................................................................................................19

Track 1 Data Length........................................................................................................................................ 19

Track 2 Data Length........................................................................................................................................ 19

Track 3 Data Length........................................................................................................................................ 19

Card Encode Type...........................................................................................................................................19

Track Data.......................................................................................................................................................20

Track 1 Data....................................................................................................................................................20

Track 2 Data....................................................................................................................................................20

Track 3 Data....................................................................................................................................................20

Card Status......................................................................................................................................................20

MagnePrint Status...........................................................................................................................................21

MagnePrint Data Length..................................................................................................................................21

MagnePrint Data..............................................................................................................................................21

Device Serial Number......................................................................................................................................22

Sequence Counter...........................................................................................................................................22

CARD DATA (KB)................................................................................................................................................22

Reader Encryption Status................................................................................................................................23

PROGRAMMABLE CONFIGURATION OPTIONS.............................................................................................24

Low Level Communications.............................................................................................................................24

COMMANDS .......................................................................................................................................................24

COMMAND NUMBER.........................................................................................................................................24

DATA LENGTH....................................................................................................................................................25

DATA ...................................................................................................................................................................25

RESULT CODE...................................................................................................................................................25

GET AND SET PROPERTY COMMANDS ......................................................................................................... 25

SOFTWARE_ID PROPERTY..............................................................................................................................27

USB_SERIAL_NUM PROPERTY .......................................................................................................................27

POLLING_INTERVAL PROPERTY.....................................................................................................................28

MAX_PACKET_SIZE PROPERTY (HID)............................................................................................................29

TRACK_ID_ENABLE PROPERTY......................................................................................................................30

TRACK_DATA_SEND_FLAGS PROPERTY (KB)..............................................................................................31

TERMINATION_CHAR PROPERTY (KB)...........................................................................................................32

SS_TK2_7BITS PROPERTY (KB)......................................................................................................................32

SS_TK3_ISO_ABA PROPERTY (KB).................................................................................................................33

SS_TK3_AAMVA PROPERTY (KB)....................................................................................................................33

SS_TK3_7BITS PROPERTY (KB)......................................................................................................................33

PRE_CARD_CHAR PROPERTY (KB)................................................................................................................34

POST_CARD_CHAR PROPERTY (KB) .............................................................................................................34

PRE_TK_CHAR PROPERTY (KB) .....................................................................................................................34

POST_TK_CHAR PROPERTY (KB)...................................................................................................................35

ASCII_TO_KEYPRESS_CONVERSION_TYPE PROPERTY (KB).................................................................... 35

INTERFACE_TYPE PROPERTY........................................................................................................................36

ACTIVE_KEYMAP PROPERTY (KB)..................................................................................................................37

PRE_CARD_STRING PROPERTY (KB) ............................................................................................................ 38

POST_CARD_STRING PROPERTY (KB).......................................................................................................... 38

SS_TK1_ISO_ABA PROPERTY (KB).................................................................................................................39

SS_TK2_ISO_ABA PROPERTY (KB).................................................................................................................39

ES PROPERTY (KB)...........................................................................................................................................40

FS PROPERTY (KB)...........................................................................................................................................40

DEVICE_SERIAL_NUM PROPERTY .................................................................................................................41

SEQUENCE_COUNTER PROPERTY................................................................................................................41

RESET_DEVICE COMMAND .............................................................................................................................42

GET_KEYMAP_ITEM COMMAND (KB) .............................................................................................................42

SET_KEYMAP_ITEM COMMAND (KB)..............................................................................................................43

SAVE_CUSTOM_KEYMAP COMMAND (KB)....................................................................................................45

ENCRYPTION KEYS...........................................................................................................................................46

Load DUKPT Initial Key...................................................................................................................................46

Reinitialize DUKPT Key...................................................................................................................................47

Report DUKPT KSN and Counter...................................................................................................................48

SECTION 5. DEMO PROGRAM.............................................................................................................................51

INSTALLATION...................................................................................................................................................51

OPERATION........................................................................................................................................................51

SOURCE CODE..................................................................................................................................................52

APPENDIX A. KEYBOARD USAGE ID DEFINITIONS.........................................................................................53

KEYBOARD/KEYPAD PAGE (0X07)..................................................................................................................53

APPENDIX B. MODIFIER BYTE DEFINITIONS.................................................................................................... 61

APPENDIX C. GUIDE ON DECRYPTING DATA...................................................................................................63

TABLES AND FIGURES

Figure 1-1. USB MagnePrint Swipe Reader with Encryption................................................................................. viii

Table 1-2. Specifications........................................................................................................................................ 4

Figure 1-2. Dimensions..........................................................................................................................................5

Figure 2-1. Reader Cable and Connector.............................................................................................................. 7

Table 2-1. 4-Pin Connector.................................................................................................................................... 7

Figure 2-2. Mounting Hole Dimensions.................................................................................................................. 9

Table A-1. Keyboard/Keypad................................................................................................................................. 53

Table B-1. Modifier Byte......................................................................................................................................... 61

vii

viii

Figure 1-1. USB MagnePrint Swipe Reader with Encryption

SECTION 1. FEATURES AND SPECIFICATIONS

The USB (Universal Serial Bus) Swipe Reader is a compact magnetic stripe card reader that conforms to ISO standards. In addition to reading three tracks of data from a card, this Reader also includes MagnePrint technology. The MagnePrint data will be included with the track data on each transaction. In order to maximize card security, this model of the Reader incorporates data encryption to protect the card contents and MagnePrint information. The Reader is compatible with any device having a host USB interface. A card is read by sliding it, stripe down and facing the LED side, through the slot either forward or backward.

An LED (Light Emitting Diode) indicator on the Reader panel provides the operator with continuous status of the Reader operations.

The reader conforms to the USB HID (Human Interface Device) Class specification Version 1.1. This allows host applications designed for most versions of Windows to easily communicate to the device using standard Windows API calls that communicate to the device through the HID driver that comes with Windows.

The Reader can be operated in two different modes:

• HID (herein referred to as “HID mode”) and

• HID with Keyboard Emulation (herein referred to as “KB mode”)

When operating in the HID mode, this device will not use keyboard emulation. It behaves like a vendor defined HID device so that a direct communication path can be established between the host application and the device, without interference from other HID devices.

When configured for the Keyboard Emulation (KB) mode, the Reader emulates a USB HID United States keyboard or, optionally, any international keyboard using ALT ASCII code keypad key combinations or customizable key maps. This allows host applications designed to acquire card data from keyboard input to seamlessly acquire the card data from the USB swipe reader.

Caution

When in Keyboard Emulation mode, if another keyboard is connected to the same host as this device and a key is pressed on the other keyboard while this device is transmitting, then the data transmitted by this device may get corrupted.

When a card is swiped through the Reader, the track data and MagnePrint information will be TDEA (Triple Data Encryption Algorithm, aka, Triple DES) encrypted using DUKPT (Derived Unique Key Per Transaction) key management. This method of key management uses a base derivation key to encrypt a key serial number that produces an initial encryption key which is injected into the Reader prior to deployment. After each transaction, the encryption key is modified per the DUKPT algorithm so that each transaction uses a unique key. Thus, the data will be encrypted with a different encryption key for each transaction.

USB MagnePrint Swipe Reader with Encryption

FEATURES

Major features of the Swipe Reader are as follows:

• Powered through the USB – no external power supply required

• Hardware Compatible with a PC or any computer or terminal having a USB interface

• Bi-directional card reading

• Reads encoded data that meets ANSI/ISO/AAMVA standards and some custom formats such

as ISO track 1 format on track 2 or 3

• Reads up to three tracks of card data

• Red/Green LED for status

• Compatible with USB specification Revision 1.1

• Compatible with HID specification Version 1.1

• Can use standard Windows HID driver for communications; no third party device driver is

required

• Programmable USB serial number descriptor

• Programmable USB Interrupt In Endpoint polling interval

• Programmable Keyboard Table to support alternate languages

• Non-volatile memory for property storage

• Built-in 6 foot USB cable

• Supplies 54 byte MagnePrint™ value

• Includes Device serial number and Sequence counter

• Encrypts all track data and the MagnePrint value

• Provides clear text confirmation data including card holder’s name, expiration date, and a

portion of the PAN

HARDWARE CONFIGURATION

The hardware configuration is as follows:

Part Number Tracks Configuration Cable

21073008 TK 1,2,3 21073023 TK 1,2,3 Black Mini 6’ USB-A

ACCESSORIES

The accessories are as follows:

Part Number Description

21042806 USB MSR Demo Program with Source Code (Diskette) 99510026 USB MSR Demo Program with Source Code (WEB)

Gray Full

Size

6’ USB-A

Section 1. Features and Specifications

REFERENCE DOCUMENTS

Axelson, Jan. USB Complete, Everything You Need to Develop Custom USB Peripherals, 1999. Lakeview Research, 2209 Winnebago St., Madison WI 53704, 396pp., http://www.lvr.com.

ANS X9.24-2004 Retail Financial Services Symmetric Key Management Part 1: Using Symmetric Techniques

USB Human Interface Device (HID) Class Specification Version 1.1.

Universal Serial Bus (USB): HID Usage Tables Version 1.12 (1/21/2005)

Corporation, Intel Corporation, Microsoft Corporation, NEC Corporation.

USB Implementers Forum, Inc., www.usb.org.

USB MagnePrint Swipe Reader with Encryption

SPECIFICATIONS

Table 1-2 lists the specifications for the USB Swipe Reader. Figure 1-2 shows the dimensions

for the Reader.

Table 1-2. Specifications

Reference Standards ISO 7810 and ISO 7811/ AAMVA* Power Input 5V From USB bus Recording Method Two-frequency coherent phase (F2F) Message Format ASCII Card Speed 4 to 60 ips (10.1 to 152.4 cm/s)

ELECTRICAL

Current Normal Mode (including power-up) Suspend Mode

Dimensions Length 6.50” (165.1mm)

Weight 6.5 oz. (184.3 gr) Cable length 6 ft. Connector USB Type A plug

Dimensions Weight 4.7 oz. (133.2 gr)

Cable length 6 ft. Connector USB Type A plug

Temperature Operating 0 °C to 70 °C (32 oF to 158 oF) Storage -40 oC to 70 oC (-40 oF to 158 oF) Humidity Operating 10% to 90% noncondensing Storage 10% to 90% noncondensing Altitude Operating 0-10,000 ft. (0-3048 m.) Storage 0-50,000 ft. (0-15240 m.)

* ISO (International Standards Organization) and AAMVA (American Association of Motor Vehicle

Administrators).

100mA maximum 500uA maximum

MECHANICAL- Full Size

Width 1.74” (44.2mm) Height 1.50” (38.1mm)

Length 3.94” (100.0mm) Width 1.28” (32.5mm) Height 1.23” (31.3mm)

MECHANICAL – Mini

ENVIRONMENTAL

Section 1. Features and Specifications

Figure 1-2. Dimensions

USB MagnePrint Swipe Reader with Encryption

SECTION 2. INSTALLATION

This section describes the cable connection, the Windows Plug and Play Setup, and the physical mounting of the unit.

USB CONNECTION

Connect the USB cable to a USB port on the host. The Reader, LED Indicator, and pin numbers for the 4-pin connector are shown in Figure 2-1.

Figure 2-1. Reader Cable and Connector

Pin numbers and signal descriptions for the cable shown in the illustration are listed in Table 2-1.

Table 2-1. 4-Pin Connector

Pin Number Signal Cable Color

1 VBUS Red 2 - Data White 3 +Data Green 4 Ground Black

USB MagnePrint Swipe Reader with Encryption

WINDOWS PLUG AND PLAY SETUP

On hosts with the Windows operating system, the first time the device is plugged into a specific USB port, Windows will pop up a dialog box, which will guide you through the process of installing a device driver for the device. After this process is completed once, Windows will no longer request this process as long as the device is plugged into the same USB port. The device driver that Windows will install for this device is the driver used for HID devices and it is part of the Windows operating system. When the dialog box pops up, follow the instructions given in the dialog box. Sometimes Windows will find all the files it needs on its own without giving any prompts. Other times Windows will need to know the location of the files it needs. If Windows prompts for the file locations, insert the CD that was used to install Windows on your PC and point Windows to the root directory of the CD. Windows should find all the files it needs there.

MOUNTING

The Reader may be mounted with screws or fastening tape as described below.

1. The Reader can be mounted on a surface in various ways:

• By two screws through the surface attached to the bottom of the unit and running the cable on

the top of the surface

• By two screws through the surface attached to the bottom of the unit and by drilling a hole in

the surface for the cable and running the cable through the hole

• By attaching the unit to the surface with fastening tape and running the cable on the top of the

surface

Note

The two mounting inserts are 3mm diameter, 0.5mm pitch, 6.4mm deep. The length of the screws used depends on the mounting surface thickness and the thickness of washers (if used).

The mounting dimensions are shown in Figure 2-2. Determine the method of mounting required.

Section 2. Installation

Figure 2-2. Mounting Hole Dimensions

2. Ensure the Reader is positioned on a flat, accessible surface with at least 4 inches clearance on either end for room to swipe a card. Orient the Reader so the side with the LED is facing the direction of intended use.

If fastening tape is to be used, clean the area that the Reader will be mounted on with isopropyl alcohol. Remove the adhesive protective cover on the fastening tape, and position the Reader and push down firmly.

3. Mount the Reader.

USB MagnePrint Swipe Reader with Encryption

SECTION 3. OPERATION

This section describes the LED Indicator and Card Read operation.

LED INDICATOR

The LED indicator will be either off, red, or green. When the device is not powered, the LED will be off. When the device is first plugged in, the LED will be red. As soon as the device is plugged in, the host will try to enumerate the device. Once the device is enumerated the LED will turn green indicating that the device is ready for use. When a card is being swiped, the LED will turn off temporarily until the swipe is completed. If there are no errors after decoding the card data then the LED will turn green. If there are any errors after decoding the card data, the LED will turn red for approximately two seconds to indicate that an error occurred and then turn green. Anytime the host puts the device into suspend mode, the LED will turn off. Once the host takes the device out of suspend mode, the LED will return to the state it was in p rior to entering suspend mode.

The LED will blink green if the MagnePrint circuit is sensing excessive electrical noise in the environment. If this occurs, the reader will still read cards and send card data to the host until it is moved away from the noise source at which time the LED will stop blinking and stay green. When this occurs, re-position the reader away from the noise source. Note that the reader will not check for noise until after a card swipe occurs. So a card has to be swiped to initiate noise detection. If noise is detected after the swipe, the reader will continue to check for noise until the noise is no longer present. If no noise is detected after the swipe, the reader will not check for noise again until after the next swipe.

CARD READ

A card may be swiped through the Reader slot when the LED is green. The magnetic stripe must face toward the front (the side with the LED) and may be swiped in either direction. If there is data encoded on the card, the device will attempt to decode the data and then send the results to the host via a USB HID input report or, if in Keyboard Emulation mode, as if the data was being typed on a keyboard. After the results are sent to the host, the device will be ready to read the next card.

USB MagnePrint Swipe Reader with Encryption

SECTION 4. USB COMMUNICATIONS

This device conforms to the USB specification revision 1.1. This device also conforms to the Human Interface Device (HID) class specification version 1.1. The device communicates to the host either as a vendor-defined HID device or as a HID Keyboard Emulation device. (Refer to

Interface_Type Property

Windows operating system come with standard Windows USB drivers that will support both modes.

The device has an adjustable endpoint descriptor polling interval value that can be set to any value in the range of 1ms to 255ms. This property can be used to speed up or slow down the card data transfer rate. The device also has an adjustable serial number descriptor. More details about these properties can be found later in this document in the command section.

The device will go into suspend mode when directed to do so by the host. The device will wake up from suspend mode when directed to do so by the host. The device does not support remote wakeup.

This is a full speed USB device. It is powered from the USB bus. The vendor ID is 0x0801. The product ID is 0x000E when in the HID mode and 0x0001 when in the Keyboard Emulation mode.

Since there are two modes of operation, there are some properties and commands that are exclusive to one of the two modes. Where a property or command is unique, it will be identified with either HID or KB. Properties and commands that are common to both modes do not include any modifier.

HID USAGES

for information on how to change modes.) The latest versions of the

HID devices send data in reports. Elements of data in a report are identified by unique identifiers called usages. The structure of the device’s reports and the device’s capabilities are reported to the host in a report descriptor. The host usually gets the report descriptor only once, right after the device is plugged in. The report descriptor usages identify the devices capabilities and report structures. For example, a device could be identified as a keyboard by analyzing the device’s report descriptor. Usages are four byte integers. The most significant two bytes are called the usage page and the least significant two bytes are called usage IDs. Usages that are related can share a common usage page. Usages can be standardized or they can be vendor defined. Standardized usages such as usages for mice and keyboards can be found in the HID Usage Tables document and can be downloaded free at www.usb.org

. Vendor-defined usages must have a usage page in the range 0xFF00 – 0xFFFF. All usages for this device use vendor-defined magnetic stripe reader usage page 0xFF00. The usage IDs for this device are defined in the following tables. The usage types are also listed. These usage types are defined in the HID Usage Tables document.

USB MagnePrint Swipe Reader with Encryption

MAGNETIC STRIPE READER USAGE PAGE (HID)

Magnetic Stripe Reader usage page 0xFF00:

Usage ID

(Hex)

1 Decoding reader device Collect

20 Track 1 decode status Data Input 21 Track 2 decode status Data Input 22 Track 3 decode status Data Input 23 MagnePrint status Data Input 28 Track 1 data length Data Input 29 Track 2 data length Data Input 2A Track 3 data length Data Input 2B MagnePrint data length Data Input 30 Track 1 data Data Input 31 Track 2 data Data Input 32 Track 3 data Data Input 33 MagnePrint data Data Input 38 Card encode type Data Input 39 Card status Data Input 40 Device serial number Data Input 41 Sequence counter Data Input 42 Reader Encryption Status Data Input 42 Masked PAN Data Input 43 Cardholder Name Data Input 44 Expiration Date Data Input 45 DUKPT serial number/counter Data Input 20 Command message Data Feature

Usage Name Usage

Type

ion

Report

Type

None

REPORT DESCRIPTOR (HID)

The Report Descriptor is structured as follows:

Item

Usage Page (Magnetic Stripe Reader) 06 00 FF Usage (Decoding reader device) 09 01 Collection (Application) A1 01 Logical Minimum (0) 15 00 Logical Maximum (255) 26 FF 00 Report Size (8) 75 08 Usage (Track 1 decode status) 09 20 Usage (Track 2 decode status) 09 21 Usage (Track 3 decode status) 09 22 Usage (Track 1 data length) 09 28 Usage (Track 2 data length) 09 29 Usage (Track 3 data length) 09 2A Usage (Card encode type) 09 38

Value

(Hex)

Section 4. USB Communications

Item

Report Count (7) 95 07 Input (Data, Variable, Absolute, Bit Field) 81 02 Usage (Track 1 data) 09 30 Report Count (112) 95 70 Input (Data, Variable, Absolute, Buffered Bytes) 82 02 01 Usage (Track 2 data) 09 31 Report Count (112) 95 70 Input (Data, Variable, Absolute, Buffered Bytes) 82 02 01 Usage (Track 3 data) 09 32 Report Count (112) 95 70 Input (Data, Variable, Absolute, Buffered Bytes) 82 02 01 Usage (Card status) 09 39 Report Count (1) 95 01 Input (Data, Variable, Absolute, Bit Field) 81 02 Report Size (32) 75 20 Usage (MagnePrint status) 09 23 Report Count (1) 95 01 Input (Data, Variable, Absolute, Bit Field) 81 02 Report Size (8) 75 08 Usage (MagnePrint data length) 09 2B Report Count (1) 95 01 Input (Data, Variable, Absolute, Bit Field) 81 02 Usage (MagnePrint data) 09 33 Report Count (128) 95 80 Input (Data, Variable, Absolute, Buffered Bytes) 82 02 01 Usage (Device serial number) 09 40 Report Count (16) 95 10 Input (Data, Variable, Absolute, Buffered Bytes) 82 02 01 Usage (Sequence counter) 09 41 Report Count (8) 95 08 Input (Data, Variable, Absolute, Buffered Bytes) 82 02 01 Usage (Reader Encryption Status) 09 42 Report Count (2) 95 02 Input (Data, Variable, Absolute, Buffered Bytes) 82 02 01 Usage (Masked PAN) 09 43 Report Count (20) 95 14 Input (Data, Variable, Absolute, Buffered Bytes) 82 02 01 Usage (Cardholder Name) 09 44 Report Count (27) 95 1B Input (Data, Variable, Absolute, Buffered Bytes) 82 02 01 Usage (Expiration Date) 09 45 Report Count (5) 95 05 Input (Data, Variable, Absolute, Buffered Bytes) 82 02 01 Usage (DUKPT Serial Number/Counter) 09 46 Report Count (10) 95 0A

Value

(Hex)

USB MagnePrint Swipe Reader with Encryption

Item

Input (Data, Variable, Absolute, Buffered Bytes) 82 02 01 Usage (Command Message) 09 20 Report Count (32) 95 20 Feature (Data, Variable, Absolute, Buffered Bytes) B2 02 01 End Collection C0

Value

(Hex)

MAGNETIC STRIPE READER USAGE PAGE (KB)

Magnetic Stripe Reader usage page 0xFF00:

Usage ID

(Hex)

20 Command message Data Feature

Usage Name Usage

Type

Report

Type

Section 4. USB Communications

REPORT DESCRIPTOR (KB)

The Report Descriptor is structured as follows:

Item Value(Hex)

Usage Page (Generic Desktop) 05 01 Usage (Keyboard) 09 06 Collection (Application) A1 01 Usage Page (Key Codes) 05 07 Usage Minimum (224) 19 E0 Usage Maximum (231) 29 E7 Logical Minimum (0) 15 00 Logical Maximum (1) 25 01 Report Size (1) 75 01 Report Count (8) 95 08 Input (Data, Variable, Absolute) 81 02 Report Count (1) 95 01 Report Size (8) 75 08 Input (Constant) 81 03 Report Count (5) 95 05 Report Size (1) 75 01 Usage Page (LEDs) 05 08 Usage Minimum (1) 19 01 Usage Maximum (5) 29 05 Output (Data, Variable, Absolute) 91 02 Report Count (1) 95 01 Report Size (3) 75 03 Output (Constant) 91 03 Report Count (6) 95 06 Report Size (8) 75 08 Logical Minimum (0) 15 00 Logical Maximum (101) 25 66 Usage Page (Key Codes) 05 07 Usage Minimum (0) 19 00 Usage Maximum (101) 29 66 Input (Data, Array) 81 00 Logical Maximum (255) 26 FF 00 Usage Page (vendor defined (MSR)) 06 00 FF Usage (command data) 09 20 Report Count 95 18 Feature (Data, Variable, Absolute, Buffered Bytes) B2 02 01 End Collection C0

USB MagnePrint Swipe Reader with Encryption

CARD DATA (HID)

The details about how the card data and commands are structured into HID reports follow later in this section. Windows applications that communicate to this device can be easily developed. These applications can communicate to the device using standard windows API calls that communicate to the device using the standard Windows USB HID driver. These applications can be easily developed using compilers such as Microsoft’s Visual Basic or Visual C++. A demonstration program and its source code, written in Visual Basic, that communicates with this device is available. This demo program can be used to test the device and it can be used as a guide for developing other applications. More details about the demo program follow later in this document.

It is recommended that application software developers become familiar with the HID specification the USB specification before attempting to communicate with this device. This document assumes that the reader is familiar with these specifications. These specifications can be downloaded free from www.usb.org

Card data is only sent to the host on the Interrupt In pipe using an Input Report. The device will send only one Input Report per card swipe. If the host requests data from the device when no data is available, the device will send a NAK to the host to indicate that it has nothing to send. When a card is swiped, the Input Report will be sent even if the data is not decodable. The following table shows how the input report is structured.

Offset Usage Name

0 Track 1 decode status 1 Track 2 decode status 2 Track 3 decode status 3 Track 1 data length 4 Track 2 data length 5 Track 3 data length 6 Card encode type

7 – 118 Track 1 data

119 – 230 Track 2 data

231 - 342 Tra ck 3 data

343 Card status

344 – 347 MagnePrint status

348 MagnePrint data length

349 - 476 MagnePrint data 477 – 492 Device serial number 493 – 500 Sequence counter

501-502 Reader Encryption Status 503-522 Masked PAN 523-549 Cardholder Name 550-554 Expiration Date 555-564 DUKPT serial number/counter

Section 4. USB Communications

Track 1 Decode Status

Bits 7-1 0 Value Reserved Error

This is a one-byte value, which indicates the status of decoding track 1. Bit position zero indicates if there was an error decoding track 1 if the bit is set to one. If it is zero, then no error occurred. If a track has data on it that is not noise, and it is not decodable, then a decode error is indicated. If a decode error is indicated, the corresponding track data length value for the track that has the error will be set to zero and no valid track data will be supplied.

Track 2 Decode Status

Bits 7-1 0 Value Reserved Error

This is a one-byte value, which indicates the status of decoding track 2. Bit position zero indicates if there was an error decoding track 2 if this bit is set to one. If it is zero, then no error occurred. If a track has data on it that is not noise, and it is not decodable, then a decode error is indicated. If a decode error is indicated, the corresponding track data length value for the track that has the error will be set to zero and no valid track data will be supplied.

Track 3 Decode Status

Bits 7-1 0 Value Reserved Error

This is a one-byte value, which indicates the status of decoding track 3. Bit position zero indicates if there was an error decoding track 3 if this bit is set to one. If it is zero, then no error occurred. If a track has data on it that is not noise, and it is not decodable, then a decode error is indicated. If a decode error is indicated, the corresponding track data length value for the track that has the error will be set to zero and no valid track data will be supplied.

Track 1 Data Length

This one-byte value indicates how many bytes of decoded card data are in the track 1 data field. This value will be zero if there was no data on the track or if there was an error decoding the track.

Track 2 Data Length

This one-byte value indicates how many bytes of decoded card data are in the track 2 data field. This value will be zero if there was no data on the track or if there was an error decoding the track.

Track 3 Data Length

This one-byte value indicates how many bytes of decoded card data are in the track 3 data field. This value will be zero if there was no data on the track or if there was an error decoding the track.

Card Encode Type

This one-byte value indicates the type of encoding that was found on the card. The following table defines the possible values.

USB MagnePrint Swipe Reader with Encryption

Value Encode Type Description

0 ISO/ABA ISO/ABA encode format 1 AAMVA AAMVA encode format 2 CADL CADL encode format. Note that this reader can only read track 2 for this

format. It cannot read tracks 1 and 3. However, this format is obsolete. There should no longer be any cards in circulation that use this format.

California is now using the AAMVA format. 3 Blank The card is blank. 4 Other The card has a non-stan dard encode format. For example, ISO/ABA

track 1 format on track 2. 5 Undetermined The card encode type could not be determined because no tracks could

be decoded. 6 None No decode has occurred. This type occurs if no magnetic stripe data has

been acquired since the data has been cleared or since the device was

powered on. This device only sends an Input report when a card has

been swiped so this value will never occur.

Track Data

If decodable track data exists for a given track, it is located in the track data field that corresponds to the track number. The length of each track data field is fixed at 112 bytes, but the length of valid data in each field is determined by the track data length field that corresponds to the track number. Track data located in positions greater than the track data length field indicates are undefined and should be ignored. The HID specification requires that reports be fixed in size, but the number of bytes encoded on a card may vary. Therefore, the Input Report always contains the maximum amount of bytes that can be encoded on the card and the number of valid bytes in each track is indicated by the track data length field. The track data is decoded and converted to ASCII. The track data includes all data starting with the start sentinel and ending with the end sentinel.

Track 1 Data

This field contains the decoded track data for track 1.

Track 2 Data

This field contains the decoded track data for track 2.

Track 3 Data

This field contains the decoded track data for track 3.

Card Status

This one byte field is reserved for future use. It is currently not used on this reader.

Section 4. USB Communications

MagnePrint Status

This Binary field represents 32 bits of MagnePrint status information. Each character represents 4 bits (hexadecimal notation). For example, suppose the characters are: “A1050000”

Nibble 1 2 3 4 5 6 7 8 Value A 1 0 5 0 0 0 0 Bit 7 6 5 4 3 2 1 0 15 1413121110 9 8 232221201918171631 30 29 28 27 262524 Value 1 0 1 0 0 0 0 1 0 0 0 0 0 1 0 1 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 Usage R R R R R R R M R R R R R R R R X X D X F L N S X X X X X X X X

Meaning

R Revision M MagnePrint D Direction F Fast L Low N Noisy S Status X Not Used

This four-byte field contains the MagnePrint status. The MagnePrint status is in little endian byte order. Byte 1 is the least significant byte. Byte 1 LSB is status bit 0. Byte 4 MSB is status bit 31. MagnePrint status is defined as follows:

Bit 0 = This is a MagnePrint-capable product (usage M) Bits 1-15 = Product revision & mode (usage R) Bit 16* = STATUS-only state (usage S) Bit 17* = Noise too high or “move me” away from the noise source (used only in

STATUS) (usage N) Bit 18 = Swipe too slow (usage L) Bit 19 = Swipe too fast (usage F) Bit 20 = Unassigned (always set to Zero) Bit 21 = Actual Card Swipe Direction (0 = Forward, 1 = Reverse) (usage D) Bits 22-31 = Unassigned (always set to Zero)

If the Enable/Disable MagnePrint property is set to disable MagnePrint, this field will not be sent.

*Bit 16 & 17 are reserved and should not be used on readers with MagneSafe V5 or later, such as these firmware versions: 21042840, 21042841, 21042846, 21042847, 21042863

MagnePrint Data Length

This one byte field indicates how many bytes of MagnePrint data are in the MagnePrint data field. This field currently only contains a value of 54.

MagnePrint Data

This 128 byte field contains the MagnePrint data. Only the number of bytes specified in the MagnePrint data length field are valid. The least significant bit of the first byte of data in this field corresponds to the first bit of MagnePrint data.

USB MagnePrint Swipe Reader with Encryption

Device Serial Number

This sixteen byte field contains the device serial number. The device serial number is a NUL (zero) terminated string. So the maximum length of the device serial number, not including the null terminator, is 15 bytes. This device serial number can also be retrieved and set with the device serial number property explained in the property section of this document. This field is stored in non-volatile memory, so it will persist when the unit is power cycled.

Sequence Counter

This 8 byte field contains the sequence counter. The sequence counter is in big endian byte order. Byte 1 is the most significant byte. The first four bytes is the counter value, the last four is padding for encryption. The sequence counter is incremented by one every time a card is swiped. The sequence number cannot be reset. This sequence counter can also be retrieved with the sequence number property explained in the property section of this document. This field is stored in non-volatile memory, so it will persist when the unit is power cycled.

CARD DATA (KB)

The card data is converted to ASCII and transmitted to the host as if it had been typed on a keyboard. Any data with ASCII values 0 – 31 or 127 will be transmitted as their equivalent control code combination. For example a carriage return value 13 (0x0D) will be sent as (^M) where ^ represents the Ctrl key on the keyboard.

Caution

If another keyboard is connected to the same host as this device and a key is pressed on the other keyboard while this device is transmitting, then the data transmitted by this device may get corrupted.

The device’s programmable configuration options affect the format of the card data. During normal device operation, the device acts like a USB HID keyboard so the host operating system takes care of all low level communications with the device so that the application developer is not burdened with these low level details.

All data will be sent in upper case regardless of the state of the caps lock key on the keyboard. If no data is detected on a track then nothing will be transmitted for that track. If an error is detected on a track, the ASCII character “E” will be sent in place of the track data to indicate an error.

The card data format for all programmable configuration options is as follows:

[P18] [P11] [P13][Reader Encryption Status] [Tk1 SS] [Tk1 Encrypted Data] [ES] [LRC] [P14] [P5] [P13] [Tk2 SS] [Tk2 Encrypted Data] [ES] [LRC] [P14] [P5] [P13] [Tk3 SS] [Tk3 Encrypted Data] [ES] [LRC] [P14] [P23] [MagnePrint status] [P35] [Encrypted MagnePrint data] [P35] [Device serial number] [P35] [Encrypted Sequence counter] [P35] [Masked PAN] [P35] [Cardholder Name] [P35] [Expiration date] [P35] [DUKPT serial number/counter] [P5] [P12] [P19]

Section 4. USB Communications

where:

ES = P22 (end sentinel) LRC = Longitudinal redundancy check character P5 = Terminating character P11 = Pre card character P12 = Post card character P13 = Pre track character P14 = Post track character P18 = Pre card string P19 = Post card string P35 = Programmable field separator; this defaults to the “|” key (0x7C). Note that this

key is never found in track data or the default programmable field separators. Tk1 SS = P20 (ISO/ABA start sentinel) Tk2 SS = P21 (ISO/ABA 5-bit start sentinel) P6 (7-bit start sentinel) Tk3 SS = P8 (ISO/ABA start sentinel) P9 (AAMVA start sentinel) P10 (7-bit start sentinel)

Track 1, Track 2 and Track 3 Encrypted Data includes the Start and End Sentinel that were decoded from the card.

All fields with the format P# are programmable configuration property numbers. They are described in detail later in this document.

Reader Encryption Status

This two byte field contains the Encryption Status. The Reader Encryption Status is sent in big endian byte order. Byte 1 is the least significant byte. Byte 1 LSB is status bit 0. Byte 2 MSB is status bit 15. The Reader Encryption status is defined as follows:

Bit 0 = Encryption Enabled (currently always set) Bit 1 = Initial DUKPT key Injected Bit 2 = DUKPT Keys exhausted Bits 3- 15 = Unassigned (always set to Zero)

Notes:

(1) Encryption will only be performed when Encryption Enabled and Initial DUKPT key

Injected are set. Otherwise, data that are normally encrypted are sent in the clear in ASCII HEX format; the DUKPT Serial Number/counter will not be sent.

(2) When DUKPT Keys Exhausted is set, the reader will no longer read cards and after a

card swipe, the reader response will be sent as follows: [P18] [P11] [P13] [Reader Encryption Status] [P5] [P12] [P19]

USB MagnePrint Swipe Reader with Encryption

PROGRAMMABLE CONFIGURATION OPTIONS

This device has a number of programmable configuration properties. Most of the programmable properties deal with the Keyboard Emulation mode but some of the properties deal with the reader regardless of the mode. These properties are stored in non-volatile memory. These properties can be configured at the factory or by the end user using a program supplied by MagTek. Programming these parameters requires low level communications with the device. Details on how to communicate with the device to change programmable configuration properties follows in the next few sections. These details are included as a reference only. Most users will not need to know these details because the device will be configured at the factory or by a program supplied by MagTek. Most users may want to skip over the next few sections on low level communications and continue with the details of the configuration properties.

Low Level Communications

It is strongly recommended that application software developers become familiar with the HID specification the USB specification before attempting to communicate directly with this device. This document assumes that the reader is familiar with these specifications. These specifications can be downloaded free from www.usb.org.

COMMANDS

Most host applications do not need to send commands to the device. Most host applications only need to obtain card data from the device as described previously in this section. This section of the manual can be ignored by anyone who does not need to send commands to the device.

Command requests and responses are sent to and received from the device using feature reports. Command requests are sent to the device using the HID class specific request Set_Report. The response to a command is retrieved from the device using the HID class specific request Get_Report. These requests are sent over the default control pipe. When a command request is sent, the device will NAK the Status stage of the Set_Report request until the command is completed. This insures that, as soon as the Set_Report request is completed, the Get_Report request can be sent to get the command response. The usage ID for the command message was shown previously in the Usage Table.

The following table shows how the feature report is structured for command requests:

Offset Field Name

0 Command Number 1 Data Length 2 – 23 Data

The following table shows how the feature report is structured for command responses.

Offset Field Name

0 Result Code 1 Data Length 2 – 23 Data

COMMAND NUMBER

This one-byte field contains the value of the requested command number. The following table lists all the existing commands.

Section 4. USB Communications

Value Command Number Description

0 GET_PROPERTY Gets a property from the device 1 SET_PROPERTY Sets a property in the device 2 RESET_DEVICE Resets the device 3 GET_KEYMAP_ITEM Gets a key map item (KB only) 4 SET_KEYMAP_ITEM Sets a key map item (KB only) 5 SAVE_CUSTOM_KEYMAP Saves the custom key map (KB only) 7 LOAD DUKPT INITIAL KEY Loads the initial DUKPT Key scheme 8 REINITIALIZE DUKPT KEY Reinitializes the DUKPT Key scheme 9 GET_DUKPT_KSN Reports DUKKPT KSN and Counter

DATA LENGTH

This one-byte field contains the length of the valid data contained in the Data field.

DATA

This multi-byte field contains command data if any. Note that the length of this field is fixed at 22 bytes. Valid data should be placed in the field starting at offset 2. Any remaining data after the valid data should be set to zero. This entire field must always be set even if there is no valid data. The HID specification requires that Reports be fixed in length. Command data may vary in length. Therefore, the Report should be filled with zeros after the valid data.

RESULT CODE

This one-byte field contains the value of the result code. There are two types of result codes: generic result codes and command-specific result codes. Generic result codes always have the most significant bit set to zero. Generic result codes have the same meaning for all commands and can be used by any command. Command-specific result codes always have the most significant bit set to one. Command-specific result codes are defined by the command that uses them. The same code can have different meanings for different commands. Command-specific result codes are defined in the documentation for the command that uses them. Generic result codes are defined in the following table.

Value Result Code Description

0 SUCCESS The command completed successfully. 1 FAILURE The command failed. 2 BAD_PARAMETER The command failed due to a bad

parameter or command syntax error.

GET AND SET PROPERTY COMMANDS

The Get Property command gets a property from the device. The Get Property command number is 0.

The Set Property command sets a property in the device. The Set Property command number is 1.

The Get and Set Property command data fields for the requests and responses are structured as follows:

USB MagnePrint Swipe Reader with Encryption

Get Property Request Data:

Data Offset Value

0 Property ID

Get Property Response Data:

Data Offset Value

0 – n Property Value

Set Property Request Data:

Data Offset Value

0 Property ID 1 – n Property Value

Set Property Response Data: None

The result codes for the Get and Set Property commands can be any of the codes list in the generic result code table.

Property ID is a one-byte field that contains a value that identifies the property. The following table lists all the current property ID values:

Value

HID

mode

16 16 INTERFACE_TYPE Type of USB interface

Value

mode

0 0 SOFTWARE_ID The device’s software identifier 1 1 SERIAL_NUM The device’s serial number 2 2 POLLING_INTERVAL The interrupt pipe’s polling interval 3 - MAX_PACKET_SIZE The interrupt pipe’s packet size 4 3 TRACK_ID_ENABLE Track enable / ID enable

- 4 TRACK_DATA_SEND_FLAGS Track data send flags

- 5 TERMINATION_CHAR Terminating char / per track or card flag

- 6 SS_TK2_7BITS Start sentinel char for track 2 – 7 bit data

- 7 Reserved for future use

- 8 SS_TK3_ISO_ABA Start sentinel char for track 3 – ISO/ABA

- 9 SS_TK3_AAMVA Start sentinel char for track 3 - AAMVA

- 10 SS_TK3_7BITS Start sentinel char for track 3 – 7 bit data

- 11 PRE_CARD_CHAR Pre card char

- 12 POST_CARD_CHAR Post card char

- 13 PRE_TK_CHAR Pre track char

- 14 POST_TK_CHAR Post track char

- 15 ASCII_TO_KEYPRESS_CONV

- 17 ACTIVE_KEYMAP Selects which key map to uses

- 18 PRE_CARD_STRING Pre card string

- 19 POST_CARD_STRING Post card string

- 20 SS_TK1_ISO_ABA Start sentinel char for track 1 – ISO/ABA

- 21 SS_TK2_ISO_ABA Start sentinel char for track 2 – ISO/ABA

- 22 ES End sentinel char for all tracks/formats

- 35 FS Field Separator for additional data

Property ID Des cription

Type of conversion performed when

ERSION_TYPE

converting ASCII data to key strokes

Section 4. USB Communications

The Property Value is a multiple-byte field that contains the value of the property. The number of bytes in this field depends on the type of property and the length of the property. The following table lists all of the property types and describes them.

Property Type Description

Byte This is a one-byte value. The valid values depend on the property. String This is a multiple byte ASCII string. Its length can be zero to a

maximum length that depends on the property. The value and length of the string does not include a terminating NUL character.

SOFTWARE_ID PROPERTY

Property ID: 0 Property Type: String Length: Fixed at 11 bytes Get Property: Yes Set Property: No Description: This is an 11 byte read only property that identifies the software part number

and version for the device. The first 8 bytes represent the part number and the last 3 bytes represent the version. For example this string might be “21042812D01”. Examples follow:

Example Get SOFTWARE_ID property Request (Hex):

Cmd Num Data Len Prp ID

00 01 00

Example Get SOFTWARE_ID property Response (Hex):

Result Code Data Len Prp Value

00 01 32 31 30 34 32 38 31 32 44 30 31

USB_SERIAL_NUM PROPERTY

Property ID: 1 Property Type: String Length: 0 – 15 bytes Get Property: Yes Set Property: Yes Default Value: The default value is no string with a length of zero. Description: The value is an ASCII string that represents the USB serial number. This

string can be 0 – 15 bytes long. The value of this property, if any, will be sent to the host when the host requests the USB string descriptor.

This property is stored in non-volatile memory, so it will persist when the unit is power cycled. When this property is changed, the unit must be reset (see Command Number 2) or power cycled to have these changes take effect. This device must be unplugged for at least 30 seconds to properly power cycle it.

Example Set USB_SERIAL_NUM property Request (Hex):

Cmd Num Data Len Prp ID Prp Value

01 04 01 31 32 33

USB MagnePrint Swipe Reader with Encryption

Example Set USB_SERIAL_NUM property Response (Hex):

Result Code Data Len Data

00 00

Example Get USB_SERIAL_NUM property Request (Hex):

Cmd Num Data Len Prp ID

00 01 01

Example Get USB_SERIAL_NUM property Response (Hex):

Result Code Data Len Prp Value

00 03 31 32 33

POLLING_INTERVAL PROPERTY

Property ID: 2 Property Type: Byte Length: 1 byte Get Property: Yes Set Property: Yes Default Value: 1 for Keyboard Emulation interface type or 10 (0A hex) for HID interface type Description: The value is a byte that represents the devices polling interval for the Interrupt

In Endpoint. The value can be set in the range of 1 – 255 and has units of milliseconds. The polling interval tells the host how often to poll the device for card data packets. For example, if the polling interval is set to 10, the host will poll the device for card data packets every 10ms. This property can be used to speed up or slow down the time it takes to send card data to the host. The trade-off is that speeding up the card data transfer rate increases the USB bus bandwidth used by the device, and slowing down the card data transfer rate decreases the USB bus bandwidth used by the device. The value of this property will be sent to the host when the host requests the device’s USB endpoint descriptor.

Example Set POLLING_INTERVAL property Request (Hex):

Cmd Num Data Len Prp ID Prp Value

01 02 02 0A

Example Set POLLING_INTERVAL property Response (Hex):

Result Code Data Len Data

00 00

Example Get POLLING_INTERVAL property Request (Hex):

Cmd Num Data Len Prp ID

00 01 02

Section 4. USB Communications

Example Get POLLING_INTERVAL property Response (Hex):

Result Code Data Len Prp Value

00 01 0A

MAX_PACKET_SIZE PROPERTY (HID)

Property ID: 3 Property Type: Byte Length: 1 byte Get Property: Yes Set Property: Yes Default Value: 8 Description: The value is a byte that represents the devices maximum packet size for the

Interrupt In Endpoint. The value can be set in the range of 1 – 64 and has units of bytes. The maximum packet size tells the host the maximum size of the Interrupt In Endpoint packets. For example, if the maximum packet size is set to 8, the device will send HID reports in multiple packets of 8 bytes each or less for the last packet of the report. This property can be used to speed up or slow down the time it takes to send card data to the host. Larger packet sizes speed up communications and smaller packet sizes slow down communications. The trade-off is that speeding up the card data transfer rate increases the USB bus bandwidth used by the device, and slowing down the card data transfer rate decreases the USB bus bandwidth used by the device. The value of this property will be sent to the host when the host requests the device’s USB endpoint descriptor.

Example Set MAX_PACKET_SIZE property Request (Hex):

Cmd Num Data Len Prp ID Prp Value

01 02 03 08

Example Set MAX_PACKET_SIZE property Response (Hex):

Result Code Data Len Data

00 00

Example Get MAX_PACKET_SIZE property Request (Hex):

Cmd Num Data Len Prp ID

00 01 03

Example Get MAX_PACKET_SIZE property Response (Hex):

Result Code Data Len Prp Value

00 01 08

USB MagnePrint Swipe Reader with Encryption

TRACK_ID_ENABLE PROPERTY

Property ID: 3 (KB mode) or 4 (HID mode) Property Type: Byte Length: 1 byte Get Property: Yes Set Property: Yes Default Value: 95 (hex) Description: This property is defined as follows:

id 0 T3 T3 T2 T2 T1 T1

Id 0 – Decodes standard ISO/ABA cards only 1 – Decodes AAMV and 7-bit cards also

00 – Track Disabled

01 – Track Enabled 10 – Track Enabled/Required (Error if blank)

Example Set TRACK_ID_ENABLE property Request (Hex):

Cmd Num Data Len Prp ID Prp Value

01 02 04 95

Example Set TRACK_ID_ENABLE property Response (Hex):

Result Code Data Len Data

00 00

Example Get TRACK_ID_ENABLE property Request (Hex):

Cmd Num Data Len Prp ID

00 01 04

Example Get TRACK_ID_ENABLE property Response (Hex):

Result Code Data Len Prp Value

00 01 95

Section 4. USB Communications

TRACK_DATA_SEND_FLAGS PROPERTY (KB)

Property ID: 4 Property Type: Byte Length: 1 byte Get Property: Yes Set Property: Yes Default Value: 63 (hex) Description: This property is defined as follows:

ICL SS ES LRC 0 LC Er Er

ICL 0 – Changing the state of the caps lock key will not affect the case of the data 1 – Changing the state of the caps lock key will affect the case of the data

SS 0 – Don’t send Start Sentinel for each track 1 – Send Start Sentinel for each track

ES 0 – Don’t send End Sentinel for each track 1 – Send End Sentinel for each track

LRC 0 – Don’t send LRC for each track 1 – Send LRC for each track

Note that the LRC is the unmodified LRC from the track data. To verify the LRC the track data needs to be converted back from ASCII to card data format and the start sentinels that were modified to indicate the card encode type need to be converted back to their original values.

LC 0 – Send card data as upper case 1 – Send card data as lower case

Note that the state of the Caps Lock key on the host keyboard has no affect on what case the card data is transmitted in unless the ICL bit in this property is set to 1.

Er 00 – Don’t send any card data if error 01 – Don’t send track data if error 11 – Send ‘E’ for each track error

USB MagnePrint Swipe Reader with Encryption

TERMINATION_CHAR PROPERTY (KB)

Property ID: 5 Property Type: Byte Length: 1 byte Get Property: Yes Set Property: Yes Default Value: 0D (hex) (carriage return) Description: This property is defined as follows:

mod c c c c c C c

mod 0 – Send c after card data 1 – Send c after each track

c 1-127 – 7 bit ASCII char code 0 – send nothing

SS_TK2_7BITS PROPERTY (KB)

Property ID: 6 Property Type: Byte Length: 1 byte Get Property: Yes Set Property: Yes Default Value: 40 (hex) ‘@’ Description: This character is sent as the track 2 start sentinel for cards that have track 2

encoded in 7 bits per character format. If the value is 0 no character is sent. If the value is in the range 1 – 127 then the equivalent ASCII character will be sent.

Section 4. USB Communications

SS_TK3_ISO_ABA PROPERTY (KB)

Property ID: 8 Property Type: Byte Length: 1 byte Get Property: Yes Set Property: Yes Default Value: 2B (hex) ‘+’ Description: This character is sent as the track 3 start sentinel for cards that have track 3

encoded in ISO/ABA format. If the value is 0 no character is sent. If the value is in the range 1 – 127 then the equivalent ASCII character will be sent.

SS_TK3_AAMVA PROPERTY (KB)

Property ID: 9 Property Type: Byte Length: 1 byte Get Property: Yes Set Property: Yes Default Value: 23 (hex) ‘#’ Description: This character is sent as the track 3 start sentinel for cards that have track 3

encoded in AAMVA format. If the value is 0 no character is sent. If the value is in the range 1 – 127 then the equivalent ASCII character will be sent.

SS_TK3_7BITS PROPERTY (KB)

Property ID: 10 (0x0A) Property Type: Byte Length: 1 byte Get Property: Yes Set Property: Yes Default Value: 26 (hex) ‘&’ Description: This character is sent as the track 3 start sentinel for cards that have track 3

encoded in 7 bits per character format. If the value is 0 no character is sent. If the value is in the range 1 – 127 then the equivalent ASCII character will be sent.

USB MagnePrint Swipe Reader with Encryption

PRE_CARD_CHAR PROPERTY (KB)

Property ID: 11 (0x0B) Property Type: Byte Length: 1 byte Get Property: Yes Set Property: Yes Default Value: 0 Description: This character is sent prior to all other card data. If the value is 0 no character

is sent. If the value is in the range 1 – 127 then the equivalent ASCII character will be sent.

POST_CARD_CHAR PROPERTY (KB)

Property ID: 12 (0x0C) Property Type: Byte Length: 1 byte Get Property: Yes Set Property: Yes Default Value: 0 Description: This character is sent after all other card data. If the value is 0 no character is

sent. If the value is in the range 1 – 127 then the equivalent ASCII character will be sent.

PRE_TK_CHAR PROPERTY (KB)

Property ID: 13 (0x0D) Property Type: Byte Length: 1 byte Get Property: Yes Set Property: Yes Default Value: 0 Description: This character is sent prior to the data for each track. If the value is 0 no

character is sent. If the value is in the range 1 – 127 then the equivalent ASCII character will be sent.

Section 4. USB Communications

POST_TK_CHAR PROPERTY (KB)

Property ID: 14 (0x0E) Property Type: Byte Length: 1 byte Get Property: Yes Set Property: Yes Default Value: 0 Description: This character is sent after the data for each track. If the value is 0 no

character is sent. If the value is in the range 1 – 127 then the equivalent ASCII character be sent.

ASCII_TO_KEYPRESS_CONVERSION_TYPE PROPERTY (KB)

Property ID: 15 (0x0F) Property Type: Byte Length: 1 byte Get Property: Yes Set Property: Yes Default Value: 0 (keymap) Description: The value is a byte that represents the devices ASCII to keypress conversion

type. The value can be set to 0 for keymap (the active keymap is set with the ACTIVE_KEYMAP property) or to 1 for ALT ASCII code (international keyboard emulation). When the value is set to 0 (keymap), data will be transmitted to the host according to the active keymap which defaults to the United States keyboard keymap. For example, to transmit the ASCII character ‘?’ (063 decimal), the character is looked up in a keymap. For a United States keyboard keymap, the ‘/’ (forward slash) key combined with the left shift key modifier are stored in the keymap to represent the key press combination that is used to represent the ASCII character ‘?’ (063 decimal). When the value is set to 1 (ALT ASCII code), instead of using the key map, a international keyboard key press combination consisting of the decimal value of the ASCII character combined with the ALT key modifier is used. For example, to transmit the ASCII character ‘?’ (063 decimal), keypad ‘0’ is sent combined with left ALT key modifier, next keypad ‘6’ is sent combined with the left ALT key modifier, last keypad ‘3’ is sent combined with the left ALT key modifier. In general, if this device only needs to emulate United States keyboards then this property should be set to 0 (keymap). If this device needs to be able to emulate all country’s keyboards then this property should be set to 1 (ALT ASCII code). The tradeoff is that the ALT ASCII code mode is slightly slower than keymap mode because more key presses need to be transmitted. Some applications are not compatible with ALT ASCII code mode.

USB MagnePrint Swipe Reader with Encryption

Example Set ASCII_TO_KEYPRESS_CONVERSION_TYPE property Request (Hex):

Cmd Num Data Len Prp ID Prp Value

01 02 0F 00

Example Set ASCII_TO_KEYPRESS_CONVERSION_TYPE property Response (Hex):

Result Code Data Len Data

00 00

Example Get ASCII_TO_KEYPRESS_CONVERSION_TYPE property Request (Hex):

Cmd Num Data Len Prp ID

00 01 0F

Example Get ASCII_TO_KEYPRESS_CONVERSION_TYPE property Response (Hex):

Result Code Data Len Prp Value

00 01 00

INTERFACE_TYPE PROPERTY

Property ID: 16 (0x10) Property Type: Byte Length: 1 byte Get Property: Yes Set Property: Yes Default Value: 1 (keyboard emulation) Description: The value is a byte that represents the devices interface type. The value can

be set to 0 for the HID interface or to 1 for the Keyboard Emulation interface. When the value is set to 0 (HID) the device will behave as described in the HID manual. When the value is set to 1 (keyboard emulation) the device will behave as described in the keyboard emulation manual. This property should be the first property changed because it affects which other properties are available. After this property is changed, the device should be power cycled before changing any other properties.

Example “Set INTERFACE_TYPE property to HID” Request (Hex):

Cmd Num Data Len Prp ID Prp Value

01 02 10 00

Example Set INTERFACE_TYPE property Response (Hex):

Result Code Data Len Data

00 00

Section 4. USB Communications

Example Get INTERFACE_TYPE property Request (Hex):

Cmd Num Data Len Prp ID

00 01 10

Example Get INTERFACE_TYPE property Response (Hex):

Result Code Data Len Prp Value

00 01 00

ACTIVE_KEYMAP PROPERTY (KB)

Property ID: 17 (0x11) Property Type: Byte Length: 1 byte Get Property: Yes Set Property: Yes Default Value: 0 (United States) Description: The value is a byte that represents the device’s active key map. The value can

be set to 0 for the United States key map or to 1 for the custom key map. The active key map will be used by the device to convert ASCII data into key strokes. The United States key map should be used will all hosts that are configured to use United States keyboards. The custom key map can be used to set up the device to work with hosts that are configured to use other countries keyboards. The default custom key map is the same as the United States key map. The key map can be modified to another countries key map by using commands “Get Key Map”, “Set Key Map” and “Save Custom Key Map”. See the command section of this manual for a complete description of these commands. To set up a device to use a custom key map, select the appropriate key map to be modified using the active key map property, reset the device to make this change take affect, use the “Get Key Map” and “Set Key Map” commands to modify the active key map, use the “Save Custom Key Map” command to save the active key map as the custom key map, set the active key map property to custom to use the custom key map, reset the device to make these changes take affect.

Example Set ACTIVE_KEYMAP property Request (Hex):

Cmd Num Data Len Prp ID Prp Value

01 02 11 00

Example Set ACTIVE_KEYMAP property Response (Hex):

Result Code Data Len Data

00 00

Example Get ACTIVE_KEYMAP property Request (Hex):

Cmd Num Data Len Prp ID

00 01 11

USB MagnePrint Swipe Reader with Encryption

Example Get ACTIVE_KEYMAP property Response (Hex):

Result Code Data Len Prp Value

00 01 00

PRE_CARD_STRING PROPERTY (KB)

Property ID: 18 (0x12) Property Type: String Length: 0 – 7 bytes Get Property: Yes Set Property: Yes Default Value: The default value is no string with a length of zero. Description: The value is an ASCII string that represents the device’s pre card string. This

string can be 0 – 7 bytes long. This string is sent prior to all other card data.

Example Set PRE_CARD_STRING property Request (Hex):

Cmd Num Data Len Prp ID Prp Value

01 04 12 31 32 33

Example Set PRE_CARD_STRING property Response (Hex):

Result Code Data Len Data

00 00

Example Get PRE_CARD_STRING property Request (Hex):

Cmd Num Data Len Prp ID

00 01 12

Example Get PRE_CARD_STRING property Response (Hex):

Result Code Data Len Prp Value

00 03 31 32 33

POST_CARD_STRING PROPERTY (KB)

Property ID: 19 (0x13) Property Type: String Length: 0 – 7 bytes Get Property: Yes Set Property: Yes Default Value: The default value is no string with a length of zero. Description: The value is an ASCII string that represents the device’s post card string.

This string can be 0 – 7 bytes long. This string is sent after all other card data.

Section 4. USB Communications

Example Set POST_CARD_STRING property Request (Hex):

Cmd Num Data Len Prp ID Prp Value

01 04 12 31 32 33

Example Set POST_CARD_STRING property Response (Hex):

Result Code Data Len Data

00 00

Example Get POST_CARD_STRING property Request (Hex):

Cmd Num Data Len Prp ID

00 01 12

Example Get POST_CARD_STRING property Response (Hex):

Result Code Data Len Prp Value

00 03 31 32 33

SS_TK1_ISO_ABA PROPERTY (KB)

Property ID: 20 (0x14) Property Type: Byte Length: 1 byte Get Property: Yes Set Property: Yes Default Value: 0x25 ‘%’ Description: This character is sent as the track 1 start sentinel for cards that have track 1

encoded in ISO/ABA format. If the value is 0 no character is sent. If the value is in the range 1 – 127 then the equivalent ASCII character will be sent.

SS_TK2_ISO_ABA PROPERTY (KB)

Property ID: 21 (0x15) Property Type: Byte Length: 1 byte Get Property: Yes Set Property: Yes Default Value: 0x3B ‘;’ Description: This character is sent as the track 2 start sentinel for cards that have track 2

encoded in ISO/ABA format. If the value is 0 no character is sent. If the value is in the range 1 – 127 then the equivalent ASCII character will be sent.

USB MagnePrint Swipe Reader with Encryption

ES PROPERTY (KB)

Property ID: 22 (0x16) Property Type: Byte Length: 1 byte Get Property: Yes Set Property: Yes Default Value: 0x3F ‘?’ Description: This character is sent as the end sentinel for all tracks with any format. If the

value is 0 no character is sent. If the value is in the range 1 – 127 then the equivalent ASCII character will be sent.

FS PROPERTY (KB)

Property ID: 35 (0x23) Property Type: Byte Length: 1 byte Get Property: Yes Set Property: Yes Default Value: 0x7C ‘|’ Description: This character is sent as the field separator to delimit additional data

(MagnePrint info, device info, DUKPT info, etc.). If the value is 0 no character is sent. If the value is in the range 1 – 127 then the equivalent ASCII character will be sent.

Section 4. USB Communications

DEVICE_SERIAL_NUM PROPERTY

Property ID: 32 (0x20) Property Type: String Length: 0 – 15 bytes Get Property: Yes Set Property: Yes Default Value: The default value is no string with a length of zero. Description: The value is an ASCII string that represents the device serial number. This

string can be 0 – 15 bytes long. The value of this property, if any, will be sent to the host in the device serial number field of the USB input report when a card is swiped. This is explained in the card data section of this document.

Example Set DEVICE_SERIAL_NUM property Request (Hex):

Cmd Num Data Len Prp ID Prp Value

01 04 20 31 32 33

Example Set DEVICE_SERIAL_NUM property Response (Hex):

Result Code Data Len Data

00 00

Example Get DEVICE_SERIAL_NUM property Request (Hex):

Cmd Num Data Len Prp ID

00 01 20

Example Get DEVICE_SERIAL_NUM property Response (Hex):

Result Code Data Len Prp Value

00 03 31 32 33

SEQUENCE_COUNTER PROPERTY

Property ID: 33 (0x21) Property Type: Double Word Length: 4 bytes Get Property: Yes Set Property: No Default Value: 0 Description: This 4 byte field contains the sequence counter. The sequence counter is in

little endian byte order. Byte 1 is the least significant byte. The sequence counter is incremented by one every time a card is swiped. The sequence number can not be reset.

This property is stored in non-volatile memory, so it will persist when the unit is power cycled.

USB MagnePrint Swipe Reader with Encryption

Example Get SEQUENCE_COUNTER property Request (Hex):

Cmd Num Data Len Prp ID

00 01 21

Example Get SEQUENCE_COUNTER property Response (Hex):

Result Code Data Len Prp Value

00 04 02 01 00 00 (counter is 258 decimal)

RESET_DEVICE COMMAND

Command number: 2 Description: This command is used to reset the device. This command can be used to

make previously changed properties take affect without having to unplug and then plug in the device. When the device resets, it automatically does a USB detach followed by an attach. After the host sends this command to the device it should close the USB port, wait a few seconds for the operating system to handle the device detach followed by the attach and then re-open the USB port before trying to communicate further with the

device. Data structure: No data is sent with this command Result codes: 0 (success)

Example Request (Hex):

Cmd Num Data Len Data

02 00

Example Response (Hex):

Result Code Data Len Data

00 00

GET_KEYMAP_ITEM COMMAND (KB)

Command number: 3 Description: This command is used to get a key map item from the active key map.

The active key map is determined by the active key map property. Data

from a magnetic stripe card is a sequence of ASCII characters. These

ASCII characters are mapped to key strokes and these key strokes are sent

to the host to represent the ASCII character. The key map maps a single

ASCII character to a single USB key usage ID and USB key modifier

byte. The key usage ID and the key modifier byte are transmitted to the

host via USB to represent the ASCII character. The ASCII value is the

value of the ASCII character to be transmitted to the host. See an ASCII

table for the values of the ASCII character set. The USB key usage ID is a

unique value assigned to every keyboard key. For a list of all key usage

IDs see Appendix A. The key modifier byte modifies the meaning of the

key usage ID. The modifier byte indicates if any combination of the right

or left Ctrl, Shift, Alt or GUI keys are pressed at the same time as the key

usage ID. For a list and description of the key modifier byte see Appendix

Section 4. USB Communications

Starting with the firmware release with software ID 21042812F01, when

both the key usage ID and the key modifier byte are set to 0xFF for a

given ASCII value, the ALT ASCII code is sent instead of the key map

values. The ALT ASCII code is a key press combination consisting of the

decimal value of the ASCII character combined with the ALT key

modifier. For example, to transmit the ASCII character ‘?’ (063 decimal),

keypad ‘0’ is sent combined with left ALT key modifier, next keypad ‘6’

is sent combined with the left ALT key modifier, last keypad ‘3’ is sent

combined with the left ALT key modifier. Data structure:

Request Data:

Offset Field Name Description

0 ASCII value Value of the ASCII character to be

retrieved from the key map. This can be any value between 0 and 127 (0x7F). For example, to retrieve the key map item for ASCII character ‘?’ (card data end sentinel) use the ASCII value of ‘?’ which is 63 (0x3F).

Response Data:

Offset Field Name Description

0 Key Usage ID The value of the USB key usage ID that is

mapped to the given ASCII value. For example, for the United States keyboard map, usage ID 56 (0x38) (keyboard / and ?) is mapped to ASCII character ‘?’.

1 Key Modifier Byte The value of the USB key modifier byte

that is mapped to the given ASCII value. For example, for the United States keyboard map, modifier byte 0x02 (left shift key) is mapped to ASCII character ‘?’.

Result codes: 0 (success)

Example Request (Hex):

Cmd Num Data Len Data

03 01 3F

Example Response (Hex):

Result Code Data Len Data

00 02 38 02

SET_KEYMAP_ITEM COMMAND (KB)

Command number: 4 Description: This command is used to set a key map item of the active key map. The

active key map is determined by the active key map property. Data from a

magnetic stripe card is a sequence of ASCII characters. These ASCII

characters are mapped to key strokes and these key strokes are sent to the

USB MagnePrint Swipe Reader with Encryption

host to represent the ASCII character. The key map maps a single ASCII

character to a single USB key usage ID and USB key modifier byte. The

key usage ID and the key modifier byte are transmitted to the host via

USB to represent the ASCII character. The ASCII value is the value of

the ASCII character to be transmitted to the host. See an ASCII table for

the values of the ASCII character set. The USB key usage ID is a unique

value assigned to every keyboard key. For a list of all key usage IDs see

Appendix A. The key modifier byte modifies the meaning of the key

usage ID. The modifier byte indicates if any combination of the right or

left Ctrl, Shift, Alt or GUI keys are pressed at the same time as the key

usage ID. For a list and description of the key modifier byte see Appendix

B. Once a key map item is modified, the changes take affect immediately.

However, the changes will be lost if the device is reset or power cycled.

To make the changes permanent, the save custom key map command must

be issued. To use the new custom key map after a reset or power cycle,

the active key map property must be set to custom.
