OMTD

OPOS FOR MAGTEK DEVICES

PROGRAMMING REFERENCE MANUAL

Manual Part Number: 99875144 Rev 3

JUNE 2003

REGISTERED TO ISO 9001:2000

1710 Apollo Court

Seal Beach, CA 90740

Phone: (562) 546-6400

FAX: (562) 546-6301

Technical Support: (651) 415-6800

www.magtek.com

MagTek®, Inc.

Printed in the United States of America

Information in this document is subject to change without notice. No part of this document may be reproduced or transmitted in any form or by any means, electronic or mechanical, for any purpose, without the express written permission of MagTek, Inc.

MagTek is a registered trademark of MagTek, Inc.

REVISIONS

Rev Number Date Notes

1 5 Oct 99 Initial Release 2 17 Feb 00 Section 2: Added "Registering an OLE

Programmatic ID Alias for OPOS Control Object." Added Figure 2-1; Section 3: Added "Registering an OLE Programmatic ID Alias for OPOS Control Object."

3 13 Jun 03 Engineering Update for MTD Software Release

1.12. Front Matter: Added ISO line to logo, changed Tech Support phone number, and replaced Limited Warranty with generic software license

REGISTERED TO ISO 9001:2000

1710 Apollo Court, Seal Beach, CA 90740 MagTek Part Number 99875144-2 Voice: 562-546-6400 Fax: 562-546-6301 13 June 2003

SOFTWARE LICENSE AGREEMENT

IMPORTANT: YOU SHOULD CAREFULLY READ ALL THE TERMS, CONDITIONS AND RESTRICTIONS OF THIS LICENSE AGREEMENT BEFORE INSTALLING THE SOFTWARE PACKAGE. YOUR INSTALLATION OF THE SOFTWARE PACKAGE PRESUMES YOUR ACCEPTANCE OF THE TERMS, CONDITIONS, AND RESTRICTIONS CONTAINED IN THIS AGREEMENT. IF YOU DO NOT AGREE WITH THESE TERMS, CONDITIONS, AND RESTRICTIONS, PROMPTLY RETURN THE SOFTWARE PACKAGE AND ASSOCIATED DOCUMENTATION TO ABOVE ADDRESS ATTENTION: CUSTOMER SUPPORT.

TERMS, CONDITIONS AND RESTRICTIONS

MagTek, Incorporated (the "Licensor") owns and has the right to distribute the described software and documentation, collectively referred to as the "Software".

LICENSE: Licensor grants you (the "Licensee") the right to use the Software in conjunction with MagTek products.

LICENSEE MAY NOT COPY, MODIFY OR TRANSFER THE SOFTWARE IN WHOLE OR IN PART EXCEPT AS EXPRESSLY PROVIDED IN THIS AGREEMENT. Licensee may not decompile, disassemble or in any other manner attempt to reverse engineer the Software. Licensee shall not tamper with, bypass or alter any security features of the software or attempt to do so.

TRANSFER: Licensee may not transfer the Software or license to the Software to another party without prior written authorization of the

Licensor. If Licensee transfers the Software without authorization, all rights granted under this Agreement are automatically terminated.

purposes. All other copies of the Software are in violation of this Agreement.

TERM:

this Agreement if Licensee fails to comply with any of the terms, conditions or restrictions contained herein. Should Licensor terminate this Agreement due to Licensee's failure to comply, Licensee agrees to return the Software to Licensor. Receipt of returned Software by the Licensor shall mark the termination.

This Agreement is in effect as long as Licensee continues the use of the Software. The Licensor also reserves the right to terminate

LIMITED WARRANTY:

from defects in material or workmanship under normal use. THE SOFTWARE IS PROVIDED AS IS WITHOUT WARRANTY OF ANY KIND, EITHER EXPRESS OR IMPLIED, INCLUDING, BUT NOT LIMITED TO, THE IMPLIED WARRANTIES OF MERCHANTABILITY AND FITNESS FOR A PARTICULAR PURPOSE. Because of the diversity of conditions and PC hardware under which the Software may be used, Licensor does not warrant that the Software will meet Licensee specifications or that the operation of the Software will be uninterrupted or free of errors.

IN NO EVENT WILL LICENSOR BE LIABLE FOR ANY DAMAGES, INCLUDING ANY LOST PROFITS, LOST SAVINGS OR OTHER INCIDENTAL OR CONSEQUENTIAL DAMAGES ARISING OUT OF THE USE OR INABILITY TO USE THE SOFTWARE. Licensee's sole remedy in the event of a defect in material or workmanship is expressly limited to replacement of the Software disk(s) if applicable.

GOVERNING LAW: If any provision of this Agreement is found to be unlawful, void or unenforceable, that provision shall be removed

from consideration under this Agreement and will not affect the enforceability of any of the remaining provisions. This Agreement shall be governed by the laws of the State of California and shall insure to the benefit of MagTek, Incorporated, its successors or assigns.

The Software is copyrighted. Licensee may not copy the Software except for archival purposes or to load for execution

Licensor warrants to the Licensee that the disk(s) or other media on which the Software is recorded to be free

ACKNOWLEDGMENT:

ITS TERMS, CONDITIONS AND RESTRICTIONS AND AGREES TO BE BOUND BY THEM. LICENSEE ALSO AGREES THAT THIS AGREEMENT SUPERSEDES ANY AND ALL, VERBAL AND WRITTEN, COMMUNICATIONS BETWEEN LICENSOR AND LICENSEE OR THEIR ASSIGNS RELATING TO THE SUBJECT MATTER OF THIS AGREEMENT.

LICENSEE ACKNOWLEDGES THAT HE HAS READ THIS AGREEMENT, UNDERSTANDS ALL OF

QUESTIONS REGARDING THIS AGREEMENT SHOULD BE ADDRESSED IN WRITING TO MAGTEK, INCORPORATED, ATTENTION: CUSTOMER SUPPORT, AT THE ABOVE ADDRESS OR E-MAILED TO support@magtek.com.

iii

TABLE OF CONTENTS

SECTION 1. FEATURES AND REQUIREMENTS...................................................................................... 1

FEATURES...............................................................................................................................................1

REQUIREMENTS.....................................................................................................................................1

Interfacing to Applications ....................................................................................................................2

Interfacing to the Device.......................................................................................................................2

Supported Device Classes....................................................................................................... ............2

Operation..............................................................................................................................................3

COMPATIBILITY ......................................................................................................................................3

CONFIGURATION....................................................................................................................................4

REFERENCE DOCUMENTS...................................................................................................................4

SECTION 2. INSTALLATION...................................................................................................................... 5

OMTD INSTALLATION NOTES...............................................................................................................5

REGISTERING OLE PROGRAMMATIC ID ALIAS FOR OPOS CONTROL OBJECT............................6

MODIFYING AND REMOVING DEVICES...............................................................................................6

SECTION 3. IMPLEMENTATION NOTES.................................................................................................. 9

SINGLE SERVICE OBJECT .................................................................................................................... 9

POTENTIAL PROBLEMS IN WINDOWS 95/98....................................................................................... 9

MODIFYING OMTD DEVICE CONFIGURATION....................................................................................9

OPENING THE DEVICE.........................................................................................................................10

REGISTERING OLE PROGRAMMATIC ID ALIAS FOR OPOS CONTROL OBJECT..........................10

DEVICE POWER REPORTING.............................................................................................................11

SAVING DEVICE SETTINGS ACROSS CLAIM/RELEASE...................................................................11

ERROR PROCESSING..........................................................................................................................11

Reporting............................................................................................................................................11

Incompatibility Issues .........................................................................................................................12

SECTION 4. CONTROL OBJECTS.......................................................................................................... 13

COMMON INTERFACES.......................................................................................................................13

OLE Interfaces....................................................................................................................................13

Event Methods....................................................................................................................................13

Common Properties............................................................................................................................14

MAGNETIC STRIPE READER (MSR) DEVICE CLASS........................................................................17

MSR Properties..................................................................................................................................17

MSR Methods.....................................................................................................................................18

MICR Device Class ............................................................................................................................18

MICR Properties................................................................................................................................. 18

MICR Methods....................................................................................................................................19

PINPAD DEVICE CLASS.......................................................................................................................19

PINPad Properties..............................................................................................................................20

PINPad Methods ................................................................................................................................21

LINE DISPLAY DEVICE CLASS............................................................................................................ 21

LDSP Properties.................................................................................................................................22

LDSP Methods ...................................................................................................................................23

USE CASES...........................................................................................................................................24

Using an OMTD Control.....................................................................................................................24

SUPPORTED DEVICE FEATURES.......................................................................................................25

Common Features..............................................................................................................................25

MSR Device Class..............................................................................................................................26

MICR Device Class ............................................................................................................................26

PINPad Device Class.........................................................................................................................27

Line Display Device Class..................................................................................................................28

APPENDIX A. GLOSSARY....................................................................................................................... 31

INDEX .........................................................................................................................................................33

FIGURE

OMTD Program Controlled Devices -----------------------------------------------------------------------------------------vi

OMTD

Control Objects (CO)

for

MICR, MSR, PINPad,

and Line Display

MTD

MagTek Device Drivers

Windows 95/98/NT

for

OMTD

Service Object (SO)

OMTD Program Controlled Devices

User-Supplied

Control Objects

(CO)

SECTION 1. FEATURES AND REQUIREMENTS

The OMTD program is an extension of the MagTek Device Driver Program (MTD). The OMTD Program provides an OPOS-compliant application interface to MagTek products and works on Windows 95, 98, ME, NT, 2000, and XP. OMTD is in the form of a set of ActiveX controls (COs) and a Service Object (SO).

OMTD is the OPOS (OLE for Retail POS) Support for MagTek Devices. It contains the Control Objects for the MICR, MSR, PINPad, and Line Display device classes, and a Service Object.

The OMTD extensions are installed as part of the MTD installation package. When installing the MTD drivers, you have the option to include OPOS support. Refer to the MTD Programming Manual (99875125) for complete installation information.

Part Number Medium

30037385 MTD/OMTD Installation Package for Windows 95/98/ME/NT/2000/XP (CD) 99510030 MTD/OMTD Installation Package for Windows 95/98/ME/NT/2000/XP (WEB)

FEATURES

• OMTD is a set of COM objects that act as an extension to the MTD driver and provide an

OPOS-compliant application interface to MagTek products.

• Each control consists of a control object (CO) and a service object (SO). The CO is an

ActiveX control that exposes to applications a set of properties, methods and events defined by OPOS for a specific device class (e.g., MICR devices, PINPads, line displays, Magnetic Stripe Readers (MSR), etc.).

• The SO is a local in-process OLE Automation server (in a DLL) that is used by a CO to

implement the OPOS-prescribed functionality for a specific device. The SO performs this functionality by sending one or more commands to the MTD driver using the Win32 File IO.

• In addition to the OPOS-specific functionality, each object exposes the OLE-specific

interfaces that make the control Microsoft compliant.

REQUIREMENTS

Each control provides the following functionality, to the degree supported by the particular device class.

• Each CO and SO provides self-registration functionality.

OMTD OPOS for MagTek Devices

• Each CO implements the following standard OLE control interfaces thereby making the

control Microsoft OLE compliant: IDispatch, IViewObject2, IOleInPlaceObject, IOleObject, IPersistStorage, IDataObject, and IProvideClassInfo.

• Exposes OPOS-specific device class methods and properties through the IDispatch interface.

• Each CO implements all OPOS-specific functionality for a specific device class as defined

by the OPOS Specification.

• A CO will only support MagTek SO(s).

• The SO implements the following standard OLE interfaces: IUnknown, IClassFactory, and

IDispatch.

• The SO implements a union of all supported OPOS device class interfaces.

• The SO implements the OPOS functionality by sending commands to the MTD driver using

the Win32 File IO API.

Interfacing to Applications

The OPOS Specification defines a common architecture for interfacing Windows applications with a variety of POS devices. The CO is loaded and created by the host application or container class whenever it needs to interact with the supported device. If an application needs to access a combo device (one that supports multiple device classes), the application is required to create and open several different control objects, one for each base class functionality that the device supports.

Interfacing to the Device

The CO loads and creates a SO in response to an application requesting a device to be opened. The CO invokes methods on the SO to request implementation of OPOS-specific functionality. In response, the SO sends one or more commands to the MTD driver using the Win32 File IO API to access the device functionality.

Supported Device Classes

The following OPOS device classes are supported by the SO:

• MSR (Magnetic Stripe Reader, e.g., Port Powered Swipe Reader, MiniWedge Swipe Reader)

Section 1. Features and Requirements

• MICR (Magnetic Ink Character Recognition Check Reader, e.g., MICR Plus, Mini MICR)

• PINPad (e.g., IntelliPIN)

• Line Display (e.g., IntelliPIN)

Operation

The requirements for operation are as follows:

• Computer system: Intel Pentium-based PC or better

• Operating system: Microsoft Windows 95/98/ME/NT/2000/XP

• Environment: Win32

• Packaging: ActiveX control (.OCX) for OMTD CO, COM in-process server (.DLL) for

OMTD SO

• Device access: OMTD accesses the device through existing MTD drivers.

COMPATIBILITY

Each of the OMTD controls is designed to be compatible with release 1.04 of the OPOS Specification and work with any containing application or container that implements the standard OLE mechanisms of creation and binding.

The common service object is designed to be compatible with the 1.05 version of the MTD driver or later. The SO will function with earlier versions of MTD, but not all functionality may be supported (e.g., data parsing).

It must be noted that the MTD driver itself does not have any knowledge about OPOS. This gives the ability to modify the OMTD controls without having to modify the MTD drivers and visa versa.

MTD will auto-configure OPOS parameters when it is installed and when any changes are made to the device (e.g., add, remove, friendly name change, etc.).

OMTD OPOS for MagTek Devices

CONFIGURATION

The OPOS specification does not provide support for or prescribe mechanisms for configuration of OPOS controls. To provide a service to the user, the configuration of the OMTD controls will be integrated with the MTD class installer.

The OPOS configuration for MagTek devices is provided in a separate DLL that is invoked by both the OMTD setup application and the MTD class installer when they want to modify the OPOS configuration for a device.

REFERENCE DOCUMENTS

1. MagTek Device Drivers for Windows, Technical Reference Manual (P/N 99875125)

2. OLE for Retail POS, Application Programmer’s Guide, Release 1.4, September 23, 1998,

International Standard, other OLE/ActiveX compliant 32-bit operating system

3. OLE for Retail POS, Control Programmer’s Guide, Release 1.4, International Standard,

September 24, 1998, Windows 95/98, Windows NT, or other OLE/ActiveX compliant 32-bit operating system

4. Header files for VC++ and VB

5. OLE Controls Inside Out, Adam Denning, Microsoft Press, 1995

SECTION 2. INSTALLATION

MagTek Device Drivers (MTD) must be installed before installing the OMTD. Refer to MagTek Device Drivers for Windows, Technical Reference Manual, P/N 99875125.

OMTD INSTALLATION NOTES

The OMTD extensions to the MTD Drivers are installed as part of the MTD installation package. When installing the MTD drivers, check the OPOS Support option at the top of the list.

Selecting the OPOS Support option triggers the installation of all of the OMTD controls. It also copies all CO and SO packages, and adds registry entries under the OPOS service provider key. Additionally, all of the installed MTD devices will be configured for OPOS operation. Each MTD driver will be mapped to the service object for all device classes supported by th e particular device.

Note

When installing the OPOS Support on Windows 2000 and XP, you will need to manually configure the devices by using the OMTDCFG configuration utility. See Modifying and Removing Devices below for more information.

OMTD OPOS for MagTek Devices

REGISTERING OLE PROGRAMMATIC ID ALIAS FOR OPOS CONTROL OBJECT

The OPOS specification states that the OLE Programmatic IDs for OPOS control objects should be OPOS.xxx where xxx specifies the device class of the control object (e.g., MSR, MICR, PINPad, etc). The result of this requirement is that only one control object of a specific device class can be registered at a single time.

By default, the OMTD installation registers aliases for the control objects’ OLE programmatic ID, as required by the OPOS specification. The registered aliases are:

• MSR Control Object = OPOS.MSR

• MICR Control Object = OPOS.MICR

• PINPad Control Object = OPOS.PINPad

• Line Display Control Object = OPOS.LineDisplay

If it is desired to use more than one control object of a specific device class at a time, the alias registration can be bypassed by typing a:\setup c in step #4 below.

When the alias registration is bypassed, the control objects are registered under the following OLE programmatic IDs:

• MSR Control Object = MAGTEK.OPOS.MSR

• MICR Control Object = MAGTEK.OPOS.MICR

• PINPad Control Object = MAGTEK.OPOS.PPAD

• Line Display Control Object = MAGTEK.OPOS.LDSP

MODIFYING AND REMOVING DEVICES

After the OMTD Controls are installed, the configuration utility (OMTDCFG.EXE) can be used to update/remove OPOS configuration for installed MagTek devices. It is copied to the C:\ProgramFiles\MagTek\MTDInstall Folder when the OMTD controls are installed. OMTDCFG.EXE is a Win32 console application that has the following usage:

omtdcfg [/|-][option] [class flag]

The [option] parameter can be one of the following:

• c , C = Configure OPOS support for installed MagTek devices

• d , D = Remove OPOS support for configured MagTek devices

• l , L = List currently configured MagTek devices

• ? = Display usage help

Section 2. Installation

The [class flag] parameter gives the option to select specific device classes to configure, remove, or list. It is a bit flag that can be one or more of the following:

• <empty> = Perform operation for all device classes listed below

• 0x01 = Perform operation for MSR device class

• 0x02 = Perform operation for MICR device class

• 0x04 = Perform operation for PIN Pad device class

• 0x08 = Perform operation for Line Display device class

The configuration utility should be run after MagTek devices are installed, removed, or modified in Windows NT/2000/XP.

The configuration utility should be run from the DOS command line so that its output may be seen.

Examples:

omtdcfg -C 0x02 [configure MICR devices] omtdcfg -L 0x03 [list MICR & MSR devices]

After this, a window listing all of the configured devices will be shown, as indicated below.

OMTD OPOS for MagTek Devices

SECTION 3. IMPLEMENTATION NOTES

The following sections define specifics of the OMTD implementation of the OPOS controls.

SINGLE SERVICE OBJECT

The OMTD product implements a slight deviation from the OPOS Specification. The OPOS Specification specifies that there is a separate control object for each device class and separate service object for each device model. OMTD conforms to the idea of a separate control object per device class, but it diverges from the specification in that OMTD contains a single service object that is used for all device models.

The reasoning behind the separate service object idea is that each device has its own interface (i.e., set of commands) and communication channel (e.g., RS-232 or keyboard) which requires different implementations of the OPOS functionality.

The OMTD product contains only one service object, the common service object, because the MTD driver handles the data medium and the transport protocol to the device, providing uniform access to the device regardless of the type of connection and device model.

POTENTIAL PROBLEMS IN WINDOWS 95/98

The MTD property sheet (settings) in Windows 95/98 has an additional check box that is used to enable or disable OMTD for that device. When a new device is installed, the box is checked by default if OMTD is installed.

When the box is checked, the class installer creates and maintains a registry entry that maps the device name to the SO for each device class supported by the device. The registry entry is made up of the friendly name for the device (e.g., "micr+") and the device class (e.g., msr) separated by a period. An example is: "Micr+.msr".

When the state of the box is changed from checked to unchecked or the device is removed from the system, the class installer removes the device’s registry entries for each supported device class.

MODIFYING OMTD DEVICE CONFIGURATION

The OMTD Service Object accepts per-device parameterization from the registry under the following path:

HKLM\Software\OLEForRetail\ServiceInfo\MagTek\Devices\<device friendly name>

The following value is currently supported for each device:

OMTD OPOS for MagTek Devices

Name Type Description

msr.enable_sentinels

REG_DWORD When set to 1, the OMTD MSR Control includes start

and end sentinels with the TrackXData properties. The default value is 0 (disabled).

When OMTD is installed or reconfigured, the device configuration, as described above, is reset to the default values for each device.

OPENING THE DEVICE

The device name that should be provided on the Open method for the control is made up of the friendly name for the device and the device class for which the open method is being called. It has the following format:

The table below shows the legal combinations of <device friendly names> and <device class>.

Default Friendly Name Msr Micr Pinp Ldsp IntelliPIN RS-232

IntelliPIN Wedge IntelliPIN MICR+ Aux Mag-Wedge MiniWedge MICR+ Mini MICR RS-232 Mini MICR Wedge MT-85 MT-95 Port-Powered Swipe reader Port-Powered Insert reader

Device Classes

X X X X X X X X X X X X X X X X X X X X X

For example, the OPOS device names for MICR+ with an MSR is "micr+.micr" and "micr+.msr".

REGISTERING OLE PROGRAMMATIC ID ALIAS FOR OPOS CONTROL OBJECT

Section 3. Implementation Notes

By default, the OMTD installation registers aliases for the control objects’ OLE programmatic ID, as required by the OPOS specification. The registered aliases are:

• MSR Control Object = OPOS.MSR

• MICR Control Object = OPOS.MICR

• PINPad Control Object = OPOS.PINPad

• Line Display Control Object = OPOS.LineDisplay

When the alias registration is bypassed, the control objects are registered under the following OLE programmatic IDs:

• MSR Control Object = MAGTEK.OPOS.MSR

• MICR Control Object = MAGTEK.OPOS.MICR

• PINPad Control Object = MAGTEK.OPOS.PPAD

• Line Display Control Object = MAGTEK.OPOS.LDSP

When the OMTD controls are uninstalled, the registered aliases are removed only if they still refer to an OMTD control object meaning that another OPOS control has not been installed after the OMTD controls were installed.

DEVICE POWER REPORTING

The OMTD controls do not support the optional power reporting capability described in the OPOS Specification. This is due to the fact that MagTek devices and MTD do not report power events.

SAVING DEVICE SETTINGS ACROSS CLAIM/RELEASE

The OPOS Specification defines that settable device characteristics are saved and restored for each application that accesses the device. The complexity of supporting this functionality does not justify the marginal benefit provided to applications. If MagTek foresees frequent simultaneous access of a device from multiple applications, this feature may be added later.

ERROR PROCESSING

Reporting

The SO will display a message box if it receives a property request containing an invalid PropIndex. These types of errors should be found during development, testing, or staging of the containing application prior to rollout to a customer. This type of error reporting is recommended by the OPOS Specification.

OMTD OPOS for MagTek Devices

Incompatibility Issues

If the control object determines that the specified service object is not supplied by MagTek or does not implement the required device class methods, it will fail the Open method. The CO determines if the SO is supplied by MagTek by querying a private property on the SO. However, the SO should work with other COs by specification.

The minimally required device class methods are those methods that are common to all device classes. Based on the service object version, one or more device class-specific methods may also be required.

The PINPad CO will fail the Open method if the OPOS version of the SO is less than 1.3. This is because the PINPad device class did not exist with prior versions of OPOS.

The SO will fail its OpenService method if it fails to bind to the SOxxx event handlers of the CO.

SECTION 4. CONTROL OBJECTS

This section defines the interfaces, properties, and methods exposed or used by the OMTD control objects. In the tables that follow, in the “Access” column, “R” indicates that the property is Read Only, “R/W” indicates that the property can be modified.

COMMON INTERFACES

The following sections describe the interfaces, methods, and properties that are common to all OMTD control objects.

OLE Interfaces

Each OMTD control object implements the following standard OLE interfaces: IUnknown,

IClassFactory, IDispatch, IViewObjectEx, IViewObject2, IViewObject, IOleInPlaceObjectWindowless, IOleInPlaceObject, IOleWindow, IOleInPlaceActiveObject, IOleControl, IOleObject, IPersistStreamInit, IPersist, IConnectionPointContainer, ISpecifyPropertyPages, IQuickActivate, IPersistStorage, IDataObject, IProvideClassInfo, and IProvideClassInfo2. See the OLE documentation for detailed descriptions of these interfaces.

(See Section 1, Reference Documents, numbers 2, 3, and 4.)

Event Methods

The following event methods are implemented by the containing application via its IDispatch interface. These event methods are also implemented by the CO to receive event notifications from the SO except they are preceded with SO and do not have Event in their name (e.g., DataEvent = SOData)

void DataEvent (LONG Status)

Fired to present input data from the device to the application. The actual input data is placed in one or more device-specific properties.

The Status parameter contains the input status. Its value is device class-dependent, and may describe the type or qualities of the input.

void DirectIOEvent (LONG EventNumber, LONG *pData, BSTR *pString)

Fired by a Service Object to communicate directly with the application. This event provides a means for a Service Object to provide events to the application that are not otherwise supported by the Control Object.

OMTD OPOS for MagTek Devices

void ErrorEvent (LONG ResultCode, LONG ResultCodeExtended,

LONG ErrorLocus, LONG *pErrorResponse)

Fired when an error is detected and the Control’s State transitions into the error state.

void OutputCompleteEvent (LONG OutputID)

Fired when a previously started asynchronous output request completes successfully. The OutputID parameter indicates the ID number of the asynchronous output request that is complete.

void StatusUpdateEvent (LONG Status)

Fired when a Control needs to alert the application of a device status change. The Status parameter is for device class-specific data, describing the type of status change. When a device is enabled, the Control may fire initial StatusUpdateEvents to inform the application of the device state.

Common Properties

The following properties are common to all OMTD control objects. Most properties are initialized to their default values after a successful call to the Open method. If a property has not been initialized, its default value will be “[Error]” for BSTR properties, 0 for numeric properties and FALSE for Boolean properties. See the OPOS Specification for more information. It is the application’s responsibility to determine what properties the CO supports by querying the corresponding capability (e.g. CapXXX) property. If an unsupported property is accessed that does not have a corresponding capability property, the return status will be OPOS_E_ILLEGAL.

Property Name Access Type Description

AutoDisable R/W BOOL Set to TRUE if application wants to receive and process

only one input at a time. The default is FALSE.

BinaryConversion R/W LONG Format in which characters are placed into BString

arguments. The default is OPOS_BC_NONE. CapPowerReporting R LONG Identifies the reporting capabilities of the device. CheckHealthText R BSTR Holds the results of the most recent call to the

CheckHealth method. Claimed R BOOL If TRUE, the device is claimed for exclusive access.

The device must be claimed before accessing the

device methods and properties and before events are

fired to the application. The default is FALSE. ControlObjectDescription R BSTR String identifying the CO and the company that

Inc.”). ControlObjectVersion R LONG Control object version number.

Section 4. Control Objects

Property Name Access Type Description

DataCount R LONG Numb er of enqueued data events at the control. The

default is 0. DataEventEnabled R/W BOOL When TRUE, a DataEvent is delivered as soon as input

data is enqueued. The default is FALSE. DeviceDescription R BSTR String identifying the device (e.g., MICR Plus). DeviceEnabled R/W BOOL When TRUE, the device is placed in an operational

state. When FALSE, any input is discarded and output

operations are disallowed. The default is FALSE. DeviceName R BSTR Identifies the device (e.g., friendly name of the device). FreezeEvents R/W BOOL When TRUE, the control will not deliver events. The

default is FALSE. OutputID R LONG Holds the identifier of the most rece ntly started

asynchronous output. PowerNotify R/W LONG Contains the type power notification selection made by

the application. The default is OPOS_PN_DISABLED. PowerState R LONG Contains the current power condition, if it can be

determined. The default is OPOS_PS_UNKNOWN. ResultCode R LONG Re sult code of the most recently invoked method. ResultCodeExtended R LONG Contains extended result information when ResultCode

is set to OPOS_S_EXTENDED. ServiceObjectDescription R BSTR String identifying the service object supporting the

device and the company that produced it (e.g., “OPOS

Common Methods

The following methods are common to all OMTD control objects.

LONG Open (BSTR DeviceName)

Call to open a device for subsequent I/O.

When the Open method is successful, it sets the properties Claimed, DeviceEnabled, and FreezeEvents, as well as descriptions and version numbers of the OPOS software layers (i.e. CO and SO). Additional class-specific properties may also be initialized.

LONG Close 0

Called to release the device and its resources. If the DeviceEnabled property is TRUE, then the device is first disabled. If the Claimed property is TRUE, then exclusive access to the device is first released.

OMTD OPOS for MagTek Devices

LONG Claim (LONG Timeout)

Called to acquire exclusive access to the device. The Timeout parameter gives the maximum number of milliseconds to wait for exclusive access to be satisfied. If zero, the method attempts to claim the device, then returns the appropriate status immediately. If OPOS_FOREVER (-1), the method waits as long as needed until exclusive access is satisfied.

LONG Release () Call this method to release exclusive access to the device. If the DeviceEnabled property is

TRUE and the device is an exclusive-use device, then the device is first disabled.

LONG CheckHealth (LONG Level)

Called to test the state of a device. A text description of the results of this method is placed in the CheckHealthText property. The CheckHealth method is always synchronous.

LONG ClearInput ()

Called to clear all device input that has been buffered. Any data events or input error events that were enqueued – usually waiting for DataEventEnabled to be set to TRUE and FreezeEvents to be set to FALSE – are also cleared.

LONG ClearOutput ();

Called to clear all device output that has been buffered. Also, when possible, halts outputs that are in progress. Any output error events that were enqueued – usually waiting for FreezeEvents to be set to FALSE – are also cleared.

LONG DirectIO (LONG Command, LONG* pData, BSTR* pString)

Call to communicate directly with the Service Object.

This method provides a means for a Service Object to provide functionality to the application that is not otherwise supported by the standard Control Object for its device class. Depending upon the Service Object’s definition of the command, this method may be asynchronous or synchronous. Use of DirectIO will make an application non-portable (e.g., it will not work with service objects developed by other companies). The application may, however, maintain portability by performing DirectIO calls within conditional code. This code may be based upon the value of the ServiceObjectDescription, DeviceDescription, or DeviceName property.

Section 4. Control Objects

MAGNETIC STRIPE READER (MSR) DEVICE CLASS

The following sections describe those properties and methods that are specific to the MSR device class.

MSR Properties

Property Name Access Type Description

AccountNumber R BSTR Account number obtained from the most recently

swiped card. CapISO R BOOL If TRUE, the device supports ISO cards. CapJISOne R BOOL If TRUE, the device supports JIS Type-I cards. CapJISTwo R BOOL If TRUE, the device supports JIS Type-II cards. DecodeData R/W BOOL If TRUE, each byte of track data contained within the

Track1Data, Track2Data, and Track3Data

properties is mapped from its raw format to its

corresponding decoded ASCII bit sequence. The

default is TRUE. ErrorReportingType R/W LONG Specifies when an error is reported by an

ErrorEvent when a card is swiped and one or more

of the tracks specified by the TracksToRead

property contains data with errors. The default is

MSR_ERT_CARD – report errors at a card level. ExpirationDate R BSTR Expiration date as retrieved from the most recently

swiped card, as four ASCII decimal characters in the

form YYMM. FirstName R BSTR First name obtained from the most recently swiped

card. MiddleInitial R BSTR Middle initial obtained from the most recently swiped

card. ParseDecodedData R/W BOOL If TRUE, the decoded data contained within the

Track1Data and Track2Data properties is further

separated into fields for access via various other

properties. The default is TRUE. ServiceCode R BSTR Service code obtained from the most recently swiped

card. Suffix R BSTR Suffix obtained from the most recently swiped card. Surname R BSTR Surname obtained from the most recently swiped

card. Title R BSTR Title obtained from the most recently swiped card. Track1Data R BSTR Contains either the track 1 data from the previous

card swipe or an empty string. This property

contains the track data between but not including the

start and end sentinel characters (refer to

msr.enable_sentinels). Track1DiscretionaryData R BSTR Track 1 discretionary data obtained from the most

recently swiped card. Track2Data R BSTR Contains either the track 2 data from the previous

card swipe or an empty string.

OMTD OPOS for MagTek Devices

Property Name Access Type Description

Track2DiscretionaryData R BSTR Track 2 discretionary data obtained from the most

recently swiped card. Track3Data R BSTR Contains either the track 3 data from the previous

card swipe or an empty string. TracksToRead R/W LONG Indicates the track data that the applicati on wishes to

have placed into the Track1Data, Track2Data and

Track3Data properties following a card swipe. The

default is MSR_TR_1_2_3.

MSR Methods

The MSR device class does not define any additional methods.

MICR Device Class

The following sections describe those properties and methods that are specific to the MICR device class.

MICR Properties

Property Name Access Type Description

AccountNumber R BSTR A string containing the account number parsed from

the most recently read MICR data.

Amount R BSTR A string containing the amount field parsed from the

most recently read MICR data.

BankNumber R BSTR A string containing the bank number portion of the

transit field parsed from the most recently read MICR data.

CapValidationDevice R BOOL Indicates if this device also performs validation printing

via the POS Printer Control’s slip station.

CheckType R LONG A number that represents the type of check parsed

from the most recently read MICR data.

CountryCode R LONG A number that represents the country of origin of the

check parsed from the most recently read MICR data.

EPC R BSTR A string containing the Extended Processing Code

(“EPC”) field parsed from the most recently read MICR data. The string will contain a single character 0 though 9 if the field is present. If not, the string will be empty (“”).

RawData R BSTR A string containing the MICR data from the most recent

MICR read.

SerialNumber R BSTR A string containing the serial number of the check

parsed from the most recently read MICR data.

TransitNumber R BSTR A string containing the transit field of the check parsed

from the most recently read MICR data.

Section 4. Control Objects

MICR Methods

The MagTek MICR devices do not require processing of the following methods, so they will always return OPOS_SUCCESS.

BeginInsertion(LONG Timeout)

Called to initiate check insertion processing.

EndInsertion()

Called to end check insertion processing.

BeginRemoval(LONG Timeout)

Called to initiate check removal processing.

EndRemoval()

Called to end check removal processing.

PINPAD DEVICE CLASS

The following sections describe those properties and methods that are specific to the PINPad device class.

OMTD OPOS for MagTek Devices

PINPad Properties

Property Name Access Type Description

AccountNumber R/W BSTR The account number to be used for the current EFT

transaction. AdditionalSecurity Information

Amount R/W CURRENCY The amount of the current EFT transaction. AvailableLanguagesList R BSTR This property is a comma-separated string of the

AvailablePromptsList R BSTR This property is a comma-separated string of CapDisplay R LONG Defines the operations that the Application may CapKeyboard R BOOL Defines whether the application can obtain input CapLanguage R LONG Defines the capabilities that the application has to

CapMACCalculation R BOOL If TRUE, the PINPad supports MAC calculation. CapTone R BOOL If TRUE, the PINPad has a Tone Indicator. EncryptedPIN R BSTR This property will contain the value of the Encrypted

MaximumPINLength R/W LONG The application should set this property to the MerchantID R/W BSTR The Merchant ID, as it is known to the EFT MinimumPINLength R/W LONG The application should set this property to the PINEntryEnabled R BOOL The PINPad Control object sets this property to

Prompt R/W LONG This property identifies a pre-defined message to be PromptLanguage R/W LONG This property specifies the language of the

TerminalID R/W BSTR The terminal ID, as it is known to the EFT Track1Data R/W BSTR Contains either the track 1 data from the previous Track2Data R/W BSTR Contains either the track 2 data from the previous Track3Data R/W BSTR Contains either the track 3 data from the previous TransactionType R/W BSTR The type of the current EFT transaction.

R BSTR This property may contain additional

security/encryption information after a DataEvent

event.

languages supported by the pre-defined prompts in

the PINPad.

supported values for the Prompt property.

perform on the PINPad display.

from the PINPad keyboard.

select the language of pre-defined messages (e.g.,

English, French, and Arabic).

PIN after a DataEvent event.

maximum acceptable number of digits in a PIN.

Transaction Host.

minimum acceptable number of digits in a PIN.

TRUE when an EnablePINEntry method is

executed.

displayed on the PINPad.

message to be displayed (as specified by the

Prompt property).

Transaction Host.

card swipe or an empty string.

Section 4. Control Objects

PINPad Methods

BeginEFTTransaction(BSTR PINPadSystem, LONG TransactionHost)

This method must be called by the application to inform the PINPad Control of the beginning of an EFT Transaction. The PINPad Control will perform initialization functions (such as computing session keys). No other PINPad functions can be performed until this method is called. Set the PINPadSystem to “MDK” or “DUKPT”.

EndEFTTransaction ()

This method must be called by the application to inform the PINPad Control of the end of an EFT Transaction.

EnablePINEntry ()

This method is called by the application to enable PIN Entry at the PINPad device. When the user has completed the PIN entry operation (either by entering their PIN or by hitting Cancel), a DataEvent event will be fired to provide the encrypted PIN to the application.

ComputeMAC(BSTR InMsg, BSTR* pOutMsg)

This method is called by the application to have the PINPad compute a MAC value and append it to the designated message. Depending on the selected PINPad Management System, the PINPad may also insert other fields into the message. Note that the ComputeMAC method cannot be used while PINPad input (PIN Entry) is enabled.

VerifyMAC(BSTR Message)

This method is called by the application to have the PINPad verify the MAC value in a message received from an EFT Transaction Host.

UpdateKey(LONG KeyNum, BSTR Key)

This method is used to provide a new encryption key to the PINPad. It is used only for those PINPad Management Systems in which new key values are sent to the terminal as a field in standard messages from the EFT Transaction Host.

LINE DISPLAY DEVICE CLASS

The following sections describe those properties and methods that are specific to the Line Display LDSP device class.

OMTD OPOS for MagTek Devices

LDSP Properties

Property Name Access Type Description

CapBlink R LONG Holds the character blink capability of the device. CapBrightness R BOOL If TRUE, the brightness control is supported; otherwise it is

FALSE. CapCharacterSet R LONG Holds the default character set capability. CapDescriptors R BOOL If TRUE, then the display supports descriptors; otherwise it is

FALSE. CapHMarquee R BOOL If TRUE, the display supports horizontal marquee windows;

otherwise it is FALSE. CapICharWait R BOOL If TRUE, the display supports intercharacter wait; otherwise it

is FALSE. CapVMarquee R BOOL If TRUE, the display supports vertical marquee windows;

otherwise it is FALSE. CharacterSet R/W LONG Contains the character set for displaying characters. CharacterSetList R BSTR A string of character set numbers. Columns R LONG Holds the number of columns for this window. CurrentWindow R/W LONG Holds the current window to which text is displayed. CursorColumn R/W LONG Holds the column in the current window to which the next

displayed character will be output. CursorRow R/W LONG Holds the row in the current window to which the next

displayed character will be output. CursorUpdate R/W BOOL If TRUE when characters are displayed by the DisplayText

or DisplayTextAt method, then CursorRow and

CursorColumn will be updated to point to the character

beyond the last character output. If FALSE when characters

are displayed, then the cursor properties will not be updated. DeviceBrightness R/W LONG Holds the device brightness value, expressed as a

percentage between 0 and 100. DeviceColumns R LONG Holds the number of columns on this device. DeviceDescriptors R LONG Holds the number of descriptors on this device. If the

capability CapDescriptors is TRUE, then

DeviceDescriptors is non-zero; otherwise it is zero. DeviceRows R LONG Holds the number of rows on this device. DeviceWindows R LONG Holds the maximum window number supported by this

device. A value of zero indicates that only the device window

is supported, and that no windows may be created. InterCharacterWait R/W LONG Holds the wait time between displaying each character with

the DisplayText and DisplayTextAt methods. This timer

gives a “teletype” appearance when displaying the text. MarqueeFormat R/W LONG Holds the marquee format for the current window. MarqueeRepeatWait R/W LONG Holds the wait time between scrolling the final character or

row of the window into its viewport and restarting the

marquee with the first or last character or row. The wait time

is the specified number of milliseconds. (Note that the timer

resolution may reduce the precision of the wait time.) MarqueeType R/W LONG Holds the marquee type for the current window. When not

DISP_MT_NONE, the window is in Marquee Mode.

Section 4. Control Objects

Property Name Access Type Description

MarqueeUnitWait R/W LONG Holds the wait time between marquee scrolling of each

column or row in the window. The wait time is the specified

number of milliseconds. (Note that the timer resolution may

reduce the precision of the wait time.) Rows R LONG Holds the number of rows for this window.

LDSP Methods

DisplayText(BSTR Data, LONG Attribute)

The characters in Data are processed beginning at the location specified by CursorRow and CursorColumn, and continue in succeeding columns.

DisplayTextAt(LONG Row, LONG Column, BSTR Data, LONG Attribute)

The characters in Data are processed beginning at the window location specified by the Row and Column parameters, and continuing in succeeding columns. This method has the same effect as

setting the CursorRow to Row, setting CursorColumn to Column, and calling the DisplayText method.

ClearText()

Clears the current window to blanks, sets CursorRow and CursorColumn to zero, and resynchronizes the beginning of the window with the start of the viewport.

ScrollText(LONG Direction, LONG Units)

Scrolls the current window.

SetDescriptor(LONG Descriptor, LONG Attribute)

Sets the state of one of the descriptors, which are small indicators with a fixed label.

ClearDescriptors()

Turns off all descriptors.

CreateWindow (LONG ViewportRow, LONG ViewportColumn, LONG ViewportHeight, LONG ViewportWidth, LONG WindowHeight, LONG WindowWidth)

OMTD OPOS for MagTek Devices

Creates a viewport over the portion of the display given by the first four parameters. The window size is given by the last two parameters. Valid window row values range from (0) to (WindowHeight-1) and column values range from (0) to (WindowWidth-1).

DestroyWindow()

Destroys the current window. The characters displayed in its viewport are not changed. CurrentWindow is set to window 0. The device window and the associated window properties are updated.

RefreshWindow(LONG Window)

Changes the current window to Window, then redisplays its viewport. Neither the mapping of the window to its viewport nor the window’s cursor position is changed.

USE CASES Using an OMTD Control

Once an OMTD control has been installed and an application has created and linked to it, the first action an application must take on the CO is to call its Open method passing it a device name that is associated with the control object. The CO locates the corresponding SO and using the system registry and calls CoCreateInstance passing the SO’s Programmatic GUID to create the object. The CO then binds to the SO’s interfaces and invokes its OpenService method.

The CO initializes its properties as well as descriptions and version numbers of the OPOS control layers. Additional class-specific properties may also be initialized.

Since several applications may have the same device open at the same time, an application must gain exclusive access to the device by calling the Claim method. This method must be called before some methods and properties may be accessed.

Before the application can use the device, it must set the DeviceEnabled property to TRUE. This value brings the device to an operational state, while FALSE disabled the device. When a device is disabled, any physical input from the device will be discarded until the device is enabled.

An application uses the device by invoking various methods on the CO via the IDispatch interface.

When an application has finished using the device, the Close method should be called to release the device and associated resources. If the DeviceEnabled property is TRUE, then Close disables the device. If the Claimed property is TRUE, the Close releases the lock.

Before exiting, an application should close all open OMTD Controls. 24

Section 4. Control Objects

SUPPORTED DEVICE FEATURES

The following sections describe the OPOS features that are not supported or partially supported for each device class. The restrictions are based on the functionality of the supported MagTek devices. In some cases, features not supported by the device (e.g., multiple windows in the Line Display) can be implemented by OMTD in software at a later time.

Common Features

Common Properties

Property Name Comments

CapPowerReporting This property returns OPOS_PR_NONE for all devices because

no MagTek devices have power reporting capabilities.

Claimed All devices must be claimed before access will be granted by the

control.

PowerNotify This property is initialized to OPOS_PN_DISABLED and the

control will fail any attempts to enable this property because it is not supported by any devices.

PowerState This property will always return OPOS_PS_UNKNOWN because

CapPowerReporting is OPOS_PR_NONE.

Common Methods

Method Name Comments

CheckHealth Only OPOS_CH_INTERNAL is supported by the SO. All other

levels are mapped to OPOS_CH_INTERNAL.

DirectIO At this time, no commands have been defined for this method.

See the Discretionary Features section later in this document for more details.

Common Events

Event Name Comments

DirectIOEvent Used only if asynchronous DirectIO method is supported. OutputCompleteEvent This event is not used because all output is performed

synchronously for the device classes supported by OMTD.

StatusUpdateEvent This event is not used because the power state reporting

capability is not supported and no status update events are defined for the device classes supported by OMTD.

OMTD OPOS for MagTek Devices

MSR Device Class

MSR Properties

Property Name Comments

TracksToRead This property modifies the “trk_enable” property of the MTD driver. DecodeData This property cannot be set to FALSE because the devices send

all track data in decoded format.

MSR Methods

There are no device class-specific methods defined for the MSR class.

MICR Device Class

MICR Properties

Property Name Comments

CapValidationDevice This property will always be FALSE because the MICR devices do

not support validation printing.

RawData This property will contain the check data as returned by the MTD

driver (e.g., 6500 format).

The CheckType and CountryCode properties are set based upon the MICR check status that is returned by the device and provided in the response of the /read command. The following table describes the values that are stored in the CheckType and CountryCode properties based on the MICR status. The MICR status values are listed in order of priority that they are returned by the device.

MICR

Status

00 No error, check OK MICR_CT_PERSONAL MICR_CC_USA 01 No MICR Data MICR_CT_UNKNOWN MICR_CC_UNKNOWN 03 Low MICR signal,

04 Check # Error, Bad

05 Transit Error MICR_CT_PERSONAL MICR_CC_USA 07 Account Error MICR_CT_PERSONAL MICR_CC_USA 08 Canadian Check MICR_CT_PERSONAL MICR_CC_CANADA 09 Mexican Check MICR_CT_PERSONAL MICR_CC_MEXICO 10 Business Check MICR_CT_BUSINESS MICR_CC_USA 11 Amount field present MICR_CT_PERSONAL MICR_CC_USA

Description CheckType Value CountryCode Value

MICR_CT_PERSONAL MICR_CC_USA

good read

MICR_CT_PERSONAL MICR_CC_USA character in check #, or no check #.

Section 4. Control Objects

MICR Methods

Method Name Comments BeginInsertion This method either always returns success or causes a /read

check command to be sent to the MTD driver.

EndInsertion This method always returns success. Optionally, it may wait until

/read check command completes or the specified timeout expires.

BeginRemoval This method always returns success because the MICR devices

do not support its functionality.

EndRemoval This method always returns success.

PINPad Device Class

PINPad Properties

Property Name Comments

AvailableLanguagesList This property is not supported because CapDisplay is

PPAD_DSP_UNRESTRICTED.

AvailablePromptsList This property is not supported because CapDisplay is

PPAD_DSP_UNRESTRICTED.

CapDisplay This property is initialized to PPAD_DSP_UNRESTRICTED,

which specifies that the Line Display CO is the interface to the PINPad display.

CapLanguage This property is initialized to PPAD_LANG_NONE because

CapDisplay is PPAD_DSP_UNRESTRICTED.

CapMACCalculation This property is always FALSE. MAC calculation is not supported

due to security concerns.

CapKeyboard This property is always FALSE. At a later time, access to the

keyboard functionality may be added through a POS Keyboard control.

CapTone This property is always FALSE because the IntelliPIN does not

have a Tone Indicator.

MerchantID This property is supported, but has no effect on the operation of

the device (i.e., no commands are sent to the device).

MinimumPINLength This property is supported, but cannot be modified. The minimum

PIN length is based on the current encode mode (M/S or DUKPT).

Prompt This property is not supported because CapDisplay is

PPAD_DSP_UNRESTRICTED.

PromptLanguage This property is not supported because CapDisplay is

PPAD_DSP_UNRESTRICTED.

TerminalID This property is supported, but has no effect on the operation of

the device.

TransactionType Only PPAD_TRANS_DEBIT and PPAD_TRANS_CREDIT

options are supported because these are the transaction types supported by IntelliPIN.

OMTD OPOS for MagTek Devices

PINPad Methods

Method Name Comments

BeginEFTTransaction The only supported PINPad Management Systems are “M/S” and

“DUKPT” – the ones supported by IntelliPIN. ComputeMAC This function is not supported due to security concerns. VerifyMAC This function is not supported due to security concerns.

Line Display Device Class

LDSP Properties

The following table lists those properties that are supported by the Line Display CO. All other properties are not supported.

Property Name Comments

CapBlink CAP_CB_NOBLINK CapBrightness FALSE CapCharacterSet DISP_CCS_ASCII CapDescriptors FALSE CapHMarquee FALSE CapICharWait FALSE CapVMarquee FALSE DeviceWindows 0 (only device window supported) DeviceRows 2 DeviceColumns 16 DeviceDescriptors 0 DeviceBrightness 100 only CharacterSet DISP_CS_ASCII only CharacterSetList 998 CurrentWindow 0 only Rows 2 Columns 16 CursorRow 0..1 CursorColumn 0..16 CursorUpdate TRUE, FALSE MarqueeType DISP_MT_NONE only MarqueeFormat DISP_MF_WALK (not used) MarqueeUnitWait 0 (not used) MarqueeRepeatWait 0 (not used) InterCharacterWait 0 (not used)

Section 4. Control Objects

LDSP Methods

Based on the device features and the capabilities defined above, only the following methods are supported:

Method Name Comments

ClearText Supported DisplayText Supported DisplayTextAt Supported

OMTD OPOS for MagTek Devices

APPENDIX A. GLOSSARY

CO OPOS Control Object – ActiveX Control that exposes a

set of properties, methods, and events to an application for its device class

COM Component Object Module

Device Physical MagTek device (e.g., Port Powered Swipe

Reader, MICR+, IntelliPIN, etc.)

Device class Category of POS devices that share a consistent set of

properties, methods, and events (e.g., MSR, MICR, PINPad, etc.)

DLL Dynamic-Link Library

LDSP Line Display Device (e.g., LCD on IntelliPIN)

MICR Magnetic Ink Character Recognition (Check Reader)

MSR Magnetic Stripe Reader

MTD MagTek Device Driver

OLE Object Linking and Embedding

OPOS OLE for Retail Point of Sale

PINPad PINPad Device Class (PIN Entry Device)

SO OPOS Service Object – COM in-process server that

provides the device-specific OPOS functionality

OMTD OPOS for MagTek Devices

INDEX

ActiveX .....................................................................1

Auto-configure ..........................................................3

BeginEFTTransaction..............................................21

BeginInsertion .........................................................19

BeginRemoval.........................................................19

CheckHealth............................................................16

Claim.......................................................................16

Claim/Release..........................................................11

Class Flag ..................................................................7

ClearDescriptors......................................................23

ClearInput................................................................16

ClearOutput ............................................................. 16

ClearText.................................................................23

Close........................................................................15

CO ...........................................................................31

COM........................................................................31

COM objects..............................................................1

Combo Device...........................................................2

Common Events ......................................................25

Common Features....................................................25

Common Interfaces..................................................13

Common Methods.............................................15, 25

Common Properties...........................................14, 25

ComputeMAC .........................................................21

Configuration.............................................................4

Control Objects..................................................13–30

CreateWindow.........................................................23

DataEvent................................................................13

DestroyWindow.......................................................24

Device......................................................................31

Device class............................................................. 31

Device Classes...........................................................2

Device Features, Supported

Common Features...............................................25

Device Power Reporting..........................................11

DirectIO...................................................................16

DirectIOEvent..........................................................13

Discretionary Features.............................................25

DisplayText .............................................................23

DisplayTextAt .........................................................23

DLL.........................................................................31

EnablePINEntry.......................................................21

EndEFTTransaction.................................................21

EndInsertion ............................................................19

EndRemoval............................................................19

Error Processing ......................................................11

ErrorEvent...............................................................14

Event Methods.........................................................13

Features .....................................................................1

Features and Specifications...................................1–4

Friendly Name.....................................................9, 10

Glossary...................................................................31

Implementation Notes..........................................9–12

Incompatibility Issues..............................................12

Installation.................................................................5

KeyNum ..................................................................21

LDSP.......................................................................31

LDSP Methods ..................................................23, 29

LDSP Properties................................................22, 28

License..................................................................... iii

Line Display Control Object......................................6

Line Display Device Class.................................21, 28

Line Displays.............................................................1

LONG Release.........................................................16

Magnetic Stripe Reader Device Class .....................17

Methods...................................................................15

MICR...................................................................1, 31

MICR Control Object................................................6

MICR Device Class...........................................18, 26

MICR Methods..................................................19, 27

MICR Properties................................................18, 26

Modifying and Removing Devices............................6

Modifying OMTD Device Configuration..................9

MSR.....................................................................1, 31

MSR Control Object..................................................6

MSR Device Class...................................................26

MSR Methods....................................................18, 26

OMTD OPOS for MagTek Devices

MSR Properties .................................................17, 26

msr.enable_sentinels................................................10

MTD....................................................................3, 31

OLE.........................................................................31

OLE Interfaces.........................................................13

OMTD Control, Using.............................................24

OMTDCFG............................................................6, 7

Open ........................................................................15

Open Method...........................................................10

OPOS.......................................................................31

OPOS Specification...................................................3

OutputCompleteEvent.............................................14

PINPad.....................................................................31

PINPad Control Object..............................................6

PINPad Device Class.........................................19, 27

PINPad Methods................................................21, 28

PINPad Properties..............................................20, 27

PINPads.....................................................................1

Potential Problems.....................................................9

Power Reporting......................................................11

Properties.................................................................14

Reference Documents................................................4

RefreshWindow.......................................................24

Registering OLE Programmatic ID Alias for OPOS

Control Object ................................................6, 10

Release.....................................................................16

Requirements.............................................................1

Saving Device Settings............................................11

ScrollText................................................................23

Sentinels ..................................................................10

Service Object ...........................................................9

SetDescriptor...........................................................23

Single Service Object ................................................9

SO............................................................................31

StatusUpdateEvent...................................................14

Supported Device Features......................................25

UpdateKey...............................................................21

Use Cases.................................................................24

Using an OMTD Control.........................................24

VerifyMAC..............................................................21

MagTek OMTD 99875144 User Manual

Specifications and Main Features

Frequently Asked Questions

User Manual

REGISTERED TO ISO 9001:2000

SOFTWARE LICENSE AGREEMENT

TERMS, CONDITIONS AND RESTRICTIONS

SECTION 1. FEATURES AND REQUIREMENTS

FEATURES

REQUIREMENTS

Interfacing to Applications

Interfacing to the Device

Supported Device Classes

Operation

COMPATIBILITY

CONFIGURATION

REFERENCE DOCUMENTS

SECTION 2. INSTALLATION

OMTD INSTALLATION NOTES

Note

REGISTERING OLE PROGRAMMATIC ID ALIAS FOR OPOS CONTROL OBJECT

MODIFYING AND REMOVING DEVICES

SECTION 3. IMPLEMENTATION NOTES

SINGLE SERVICE OBJECT

POTENTIAL PROBLEMS IN WINDOWS 95/98

MODIFYING OMTD DEVICE CONFIGURATION

OPENING THE DEVICE

REGISTERING OLE PROGRAMMATIC ID ALIAS FOR OPOS CONTROL OBJECT

DEVICE POWER REPORTING

SAVING DEVICE SETTINGS ACROSS CLAIM/RELEASE

ERROR PROCESSING

Reporting

Incompatibility Issues

SECTION 4. CONTROL OBJECTS

COMMON INTERFACES

OLE Interfaces

Event Methods

Common Properties

MAGNETIC STRIPE READER (MSR) DEVICE CLASS

MSR Properties

MSR Methods

MICR Device Class

MICR Properties

MICR Methods

PINPAD DEVICE CLASS

PINPad Properties

PINPad Methods

LINE DISPLAY DEVICE CLASS

LDSP Properties

LDSP Methods

SUPPORTED DEVICE FEATURES

Common Features

Common Properties

Common Methods

Common Events

MSR Device Class

MSR Properties

MSR Methods

MICR Device Class

MICR Properties

MICR Methods

PINPad Device Class

PINPad Properties

PINPad Methods

Line Display Device Class

LDSP Properties

LDSP Methods

APPENDIX A. GLOSSARY

INDEX
