SECTION 1. SECURITY

The iDynamo is a secure card reader authenticator (SCRA) designed to work with the Apple devices that use a 30 pin connector; including iPhone 4, iPhone 3GS, iPhone 3G, iPod touch and iPad. The iDynamo 5 is an iDynamo SCRA that uses the Lightning connector for use with the iPhone 5, iPad mini, iPad with Retina display, and iPod touch 5th gen devices. Securit y featur es include:

• Supplies 54 byte MagnePrint value

• Includes Device Serial Number

• Encrypts all track data and the MagnePrint value

• Provides clear text confirmation data including card holder’s name, expiration date, and a

portion of the PAN as part of the Masked Track Data

• Supports Mutual Authentication Mode for use with Magensa

This reader only supports Security Level 3.

SECURITY LEVEL 3

Security Level 3 enables encryption of track data, MagnePrint data, and the Session ID. MagnePrint data is always included and it is always encrypted. The format for the data is detailed later in this document. At Security Level 3, many commands require security—most notably, the Set Property command.

Commands that require security must be sent with a four byte Message Authentication Code (MAC) appended to the end. The MAC is calculated as specified in ANSI X9.24 Part 1 – 2004, Annex A. Note that data supplied to the MAC algorithm should NOT be converted to the ASCII-Hex, rather it should be supplied in its raw binary form. The MAC key to be used is as specified in the same document (“Request PIN Entry 2” bullet 2). Calculating the MAC requires knowledge of the current DUKPT KSN, which can be retrieved using the Get DUKPT KSN and Counter command. For each command processed successfully, the DUKPT Key is advanced.

1

iDynamo MagneSafe V5 Communication Manual

Command

Level 3

Get Property

Y

Set Property

S

Reset

X*

Get DUKPT KSN and Counter

Y

Set Session ID

Y

Activate Authenticated Mode

Y

Activation Challenge Reply

Y

Deactivate Authenticated Mode

Y

Get Reader State

Y

Get Encryption Counter

Y

Bulk Encrypt

Y

COMMANDS AND SECURITY LEVELS

The following table shows how security levels affect the various commands. “Y” means the command can run. “N” means the command is prohibited. “S” means the command is protected (requires MACing). “X” means other (notes to follow).

* The Reset command has special behavior. When an Authentication sequence has failed, only a

correctly MACed Reset command can be used to reset the reader. This is to prevent a dictionary

attack on the keys and to minimize a denial of service attack.

2

SECTION 2. COMMUNICATIONS

CARD DATA

The details about how the card data and commands are structured follow later in this section.

The reader will send only one swipe message per card swipe. When a card is swiped, the swipe message will be sent even if the data is not decodable. If no data is detected on a track then nothing will be transmitted for that track. If an error is detected on a track, the ASCII character “E” will be sent in place of the track data to indicate an error.

The reader will always send data in blocks of 500 bytes. If card data is more than 500 bytes, the reader will send this using 2 blocks of 500 bytes. If card data is less than or equal to 500 bytes, the reader will only send 1 block with 500 bytes. If data is less than 500 bytes in a block, the reader will use a lower case ‘x’ (0x78) as padding characters. Note: The longest message always fits within 2 blocks.

A Swipe Message is composed of readable ASCII characters. It includes:

• Structural ASCII characters intended to give clues to the structure of the rest of the data.

• Simple ASCII fields that convey the ASCII representation of:

Masked Track Data Device Serial Number Format Code

• Binary fields that use sets of two ASCII characters representing hexadecimal digits to

convey the binary value of each byte in the field. The ASCII characters

0123456789ABCDEF convey the hexadecimal values of 0123456789ABCDEF

respectively. The Binary fields are:

Reader Encryption Status Encrypted Track Data MagnePrint Status Encrypted MagnePrint Data Encrypted Session ID DUKPT Key Serial Number Clear Text CRC Encrypted CRC

For the encrypted fields, the original binary bytes are encrypted using the DES CBC mode with an Initialization Vector starting at all binary zeroes and the PIN Encryption Key associated with the current DUKPT KSN. This is done in segments of 8 bytes. If the last segment of the original data is less than eight bytes long (track data only), the last bytes of the block will be set to binary zeroes before encrypting. When decrypting track data, the End Sentinel can be used to find the actual end of the data (ignoring the final zeroes). Each byte of encrypted data is then converted to two bytes of ASCII data representing the Hexadecimal value of the encrypted byte (many of the encrypted bytes will have values outside of the printable ASCII character range).

3

iDynamo MagneSafe V5 Communication Manual

Label

Property

ID

P-

Value

Description

Default

0x1E

P30

Pre card string

0 (0x00)

0x1F

P31

Post card string

0 (0x00)

0x20

P32

Pre track string

0 (0x00)

0x21

P33

Post track string

0 (0x00)

0x22

P34

Terminating string

C/R (0x0D)

0x23

P35

Programmable field separator

“|” (0x7C)

Tk1 SS

0x24

P36

ISO/ABA start sentinel

“%” (0x25)

Tk2-SS

0x25

P37

ISO/ABA 5-bit start sentinel

“;” (0x3B)

Tk3-SS

0x26

P38

ISO/ABA start sentinel

“+” (0x2B)

Tk3-SS

AAMVA

P39

AAMVA start sentinel

“#” (0x23)

Tk2-SS 7 bit

0x28

P40

7 bit start sentinel (ISO/ABA Track 1 start sentinel)

“@”(0x40)

Tk3-SS 7 bit

0x29

P41

7 bit start sentinel (ISO/ABA Track 1 start sentinel)

“&”(0x26)

0x2B

0x2F

P43

P47

End Sentinel

Track 3 Specific End Sentinel

“?” (0x3F)

The card data format for all programmable configuration options is as follows:

[P30] [P32] [Tk1 SS] [Tk1 Masked Data] [ES ] [P3 3 ] [P32] [Tk2 SS] [Tk2 Masked Data] [ES ] [P3 3 ] [P32] [Tk3 SS] [Tk3 Masked Data] [ES ] [P3 3 ] [P31] [P35] [Reader Encryption Status] [P35] [Tk1 Encrypted Data (including TK1 SS and ES)] [P35] [Tk2 Encrypted Data (including TK1 SS and ES)] [P35] [Tk3 Encrypted Data (including TK1 SS and ES)] [P35] [MagnePrint Status] [P35] [Encrypted MagnePrint data] [P35] [Device serial number] [P35] [Encrypted Session ID] [P35] [DUKPT serial number/counter] [P35] [Encryption Counter] (optional, off by default) [P35] [Clear Text CRC] [P35] [Encrypted CRC] [P35] [Format Code] [P34]

The characters and fields are described in the list below. The Property ID (e.g., P31) is the decimal value of the property ID in the command list (see Pre Card String).

0x27

ES

0x2D 0x2E

P45 P46

Track 1, Track 2 and Track 3 Encrypted Data includes the Start and End Sentinel that were decoded from the card.

All fields with the format P# are programmable configuration property numbers. They are described in detail later in this document.

4

Track 1 Specific End Sentinel Track 2 Specific End Sentinel

“?” (0x3F) “?” (0x3F)

Section 2. Communications

Masked Track Data

If decodable track data exists for a given track, it is located in the Masked Track Data field that corresponds to the track number.

The Masked Track Data is decoded and converted to ASCII and then it is “masked”. The Masked Track Data includes all data starting with the start sentinel and ending with the end sentinel. Much of the data is “masked”; a specified mask character is sent instead of the actual character read from the track. The characters that are masked depend on the format of the card. Only ISO/ABA (Financial Cards with Format Code B) and AAMVA cards are selectively masked; all other card types are either entirely masked or sent totally in the clear. There is a separate masking property for ISO/ABA cards and AAMVA cards. See the ISO Track Masking property and the AAMVA Track Masking property for more information. (Refer to Appendix C for a description of how ISO/ABA and AAMVA cards are identified.)

Each of these properties allows the application to specify masking details for the Primary Account Number and Driver’s License / ID Number (DL/ID#), the masking character to be used, and whether or not to apply an adjustment to force the Mod 10 9 (Luhn algorithm) digit at the end of the number to be correct.

Track 1 Masked Data

This Simple ASCII field contains the Masked Track Data for track 1. The device transmits all characters.

For an ISO/ABA card, the PAN is masked as follows:

• The specified number of initial characters is sent unmasked. The specified

number of trailing characters is sent unmasked. If Mod 10 correction is specified, all but one of the intermediate characters of the PAN are set to zero; one of them will be set such that last digit of the PAN calculates an accurate Mod 10 check of the rest of the PAN as transmitted. If the Mod 10 correction is not specified, all of the intermediate characters of the PAN are set to the specified mask character.

• The Card Holder’s name and the Expiration Date are transmitted unmasked.

• All Field Separators are sent unmasked.

• All other characters are set to the specified mask character.

For an AAMVA card, the specified mask character is substituted for each of the characters read from the card.

Track 2 Masked Data

This Simple ASCII field contains the Masked Track Data for track 2.

For an ISO/ABA card, the PAN is masked as follows:

• The specified number of initial characters are sent unmasked. The specified

number of trailing characters are sent unmasked. If Mod 10 correction is specified, all but one of the intermediate characters of the PAN are set to zero; one of them will be set such that last digit of the PAN calculates an accurate Mod 10 check of the rest of the PAN as transmitted. If the Mod 10 correction is not specified, all of the intermediate characters of the PAN are set to the specified mask character.

5

iDynamo MagneSafe V5 Communication Manual

• The Expiration Date is transmitted unmasked.

• All Field Separators are sent unmasked.

• All other characters are set to the specified mask character.

For an AAMVA card, the DL/ID# is masked as follows:

• The specified number of initial characters are sent unmasked. The specified

number of trailing characters are sent unmasked. If Mod 10 correction is specified, all but one of the intermediate characters of the DL/ID#PAN are set to zero; one of them will be set such that last digit of the DL/ID# calculates an accurate Mod 10 check of the rest of the DL/ID# as transmitted. If the Mod 10 correction is not specified, all of the intermediate characters of the DL/ID# are set to the specified mask character.

• The Expiration Date and Birth Date are transmitted unmasked.

• All other characters are set to the specified mask character.

Track 3 Masked Data

This Simple ASCII field contains the Masked Track Data for track 3.

For an ISO/ABA card, the PAN is masked as follows:

• The specified number of initial characters are sent unmasked. The specified

number of trailing characters are sent unmasked. If Mod 10 correction is specified, all but one of the intermediate characters of the PAN are set to zero; one of them will be set such that last digit of the PAN calculates an accurate Mod 10 check of the rest of the PAN as transmitted. If the Mod 10 correction is not specified, all of the intermediate characters of the PAN are set to the specified mask character.

• All Field Separators are sent unmasked.

• All other characters are set to the specified mask character.

For an AAMVA card, the specified mask character is substituted for each of the characters read from the card.

Reader Encryption Status

This two byte Binary field contains the Encryption Status. The Reader Encryption Status is sent in big endian byte order. Byte 1 is the least significant byte. Byte 1 LSB is status bit 0. Byte 2 MSB is status bit 15. The Reader Encryption Status is defined as follows:

Bit 0 = DUKPT Keys exhausted

Bit 1 = Initial DUKPT key Injected, always set to One

Bit 2 = Encryption Enabled, always set to One

Bit 3 = Always set to Zero

Bit 4 = Timed Out waiting for user to swipe card

Bit 5 = Always set to Zero

Bit 6 = Always set to Zero

Bit 7 = Always set to Zero

Bit 8 = Encryption Counter Expired

Bits 9–10 = Unassigned (always set to Zero)

Bit 11 = DUKPT Key Variant used to encrypt track data, 0=PIN Variant,

1=DATA Variant/Bidirectional.

Bit 12 = Unassigned (always set to Zero)

6

Section 2. Communications

Bit 13 = DUKPT Key Variant used to encrypt MagnePrint data.

0 = PIN Variant, 1 = Data Variant/Bidirectional

Bits 14-15 = Unassigned (always set to Zero)

Notes:

(1) Encryption will only be performed when Encryption Enabled (bit 2) and Initial DUKPT

key Injected (bit 1) are set. Otherwise, data that are normally encrypted are sent in the

clear in ASCII HEX format; the DUKPT Serial Number/counter will not be sent.

(2) When DUKPT Keys Exhausted (bit 0) is set, the reader will no longer read cards and

after a card swipe, the reader response will be sent as follows:

[P30]

[P31]

[P35] [Reader Encryption Status]

[P35]

[P35] [Device serial number]

[P35] [Encrypted Session ID]

[P35] [DUKPT serial number/counter]

[P35] [Encryption Counter] (optional, OFF by default)

[P35] [Clear Text CRC]

[P35] [Encrypted CRC]

[P35] [Format Code]

[P34]

Encrypted Track Data

If decodable track data exists for a given track, both the Masked Track Data field and the Encrypted Track Data field for that track will contain data.

The encrypted data from each track is decoded and converted to ASCII, then is encrypted. The encrypted track data includes all data starting with the start sentinel and ending with the end sentinel. The encryption begins with the first 8 bytes of the clear text track data. The 8-byte result of this encryption is placed in the Encrypted Data buffer for the corresponding track. The process continues using the CBC (Cipher Block Chaining) method with the encrypted 8 bytes XORed with the next 8 bytes of clear text. That result is placed in next 8 bytes of the Encrypted Data buffer and the process continues until all clear text bytes have been encrypted. If the final block of clear text contains fewer than 8 bytes, it is padded with binary zeros to fill up the 8 bytes. After this final clear text block is XORed with the prior 8 bytes of encrypted data, it is encrypted and placed in the Encrypted Data buffer. No Initial Vector is used in the process.

Decrypting the data must be done in 8 byte blocks, ignoring any final unused bytes in the last block. See Appendix A for more information.

Track 1 Encrypted Data

This Binary field contains the encrypted track data for track 1.

7

iDynamo MagneSafe V5 Communication Manual

Nibble 1 2 3 4 5 6 7 8

Value A 1 0 5 0 0 0 0

Bit 7 6 5 4 3 2 1 0

15

14

13

12

11

10 9 8

23

22

21

20

19

18

17

16

31

30

29

28

27

26

25

24

Value

1 0 1 0 0 0 0 1 0 0 0 0 0 1 0 1 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0

0

Usage*

R R R R R R R M R R R R R R R R 0 0 D 0 F L N S 0 0 0 0 0 0 0

0

Track 2 Encrypted Data

This Binary field contains the encrypted track data for track 2.

Track 3 Encrypted Data

This Binary field contains the encrypted track data for track 3.

MagnePrint Status

This Binary field represents 32 bits of MagnePrint status information. Each character represents 4 bits (hexadecimal notation). For example, suppose the characters are: “A1050000”:

* Usage Legend:

• D = Direction

• F = Too Fast

• L = Too Slow

• M = MagnePrint capable

• N = Too Noisy

• R = Revision

This four byte field contains the MagnePrint status. The MagnePrint status is in little endian byte order. Byte 1 is the least significant byte. Byte 1 LSB is status bit 0. Byte 4 MSB is status bit 31. MagnePrint status is defined as follows:

Bit 0 = This is a MagnePrint-capable product (usage M)

Bits 1-15 = Product revision & mode (usage R)

Bit 16 = STATUS-only state (usage S)

Bit 17 = Noise too high or “move me” away from the noise source (used only in

STATUS) (usage N) Bit 18 = Swipe too slow (us age L) Bit 19 = Swipe too fast (u s age F) Bit 20 = Unassigned (always set to Zero) Bit 21 = Actual Card Swipe Direction (0 = Forward, 1 = Reverse) (usage D) Bits 22-31 = Unassigned (always set to Zero)

If the Enable/Disable MagnePrint property is set to disable MagnePrint, this field will not be sent.

Encrypted MagnePrint Data

This 56 byte Binary field contains the MagnePrint data. After decryption, the final two bytes should be discarded leaving the 54 byte MagnePrint data. The least significant bit of the first byte of data in this field corresponds to the first bit of MagnePrint data. If the Enable/Disable MagnePrint property is set to disable MagnePrint, this field will not be sent.

Device Serial Number

This Simple ASCII field contains the device serial number. The device serial number is a NUL (zero) terminated string. So the maximum length of the device serial number, not including the

8

Section 2. Communications

null terminator, is 15 bytes. This device serial number can also be retrieved and set with the device serial number property explained in the property section of this document. This field is stored in non-volatile memory, so it will persist when the unit is power cycled.

Encrypted Session ID

This eight byte Binary field contains the encrypted version of the current Session ID. Its primary purpose is to prevent replays. After a card is read, this value will be encrypted, along with the card data, and supplied as part of the transaction message. The clear text version of this will never be transmitted. To avoid replay, the application sets the Session ID property before a transaction and verifies that the Encrypted Session ID returned with card data decrypts to the value set.

DUKPT Key Serial Number

This 10 byte Binary field contains the DUKPT Key Serial Number used to encrypt the encrypted fields in this message. This 80-bit field includes the Initial Key Serial Number in the leftmost 59 bits and a value for the Encryption Counter in the rightmost 21 bits. If no keys are loaded, all bytes will have the value 0xFF.

Encryption Counter

This three byte field contains the value of the Encryption Counter at the end of this transaction. See the Get Encryption Counter command for more information.

Clear Text CRC

This 2-byte Binary field contains a clear text version of a Cyclical Redundancy Check (CRC-16 CCITT, polynomial 0x1021) (least significant byte sent first). It provides a CRC of all characters sent prior to this CRC. The CRC is converted to four characters of ASCII before being sent. The application may calculate a CRC from the data received prior to this CRC and compare it to the CRC received. If they are the same, the application can have high confidence that all the data was received correctly. The CRC Flag property controls whether this field is sent. If the property is True, the CRC is sent, if it is False, the CRC is not sent. The default state for this property is True.

Encrypted CRC

This 8-byte Binary field contains an encrypted version of a Cyclical Redundancy Check (CRC). It provides a CRC of all characters sent prior to this CRC. The CRC is converted to 16 characters of ASCII before being sent. After the receiver decrypts the message, the CRC is contained in the first 2 bytes of the message, all other bytes are meaningless. The application may calculate a CRC from the data received prior to this CRC and compare it to the CRC received. If they are the same, the application can have high confidence that all the data was received correctly. The CRC FLAG property controls whether this field is sent.

Format Code

This 4-character ASCII field contains the Format Code. The purpose of the Format Code is to allow the receiver of this message to know how to find the different fields in the message. The default Format Code for this reader is “0001”. If any of the properties that affect the format of the message are changed, the first character of the Format Code will automatically change to a

9

iDynamo MagneSafe V5 Communication Manual

Byte

Usage

0

Command Number

1

Data Length

2 – 23

Data

Byte

Usage

0

Result Code

1

Data Length

2 – 23

Data

“1”. The application may change the final three characters, but making such a change will automatically cause the first character to a “1”.

PROGRAMMABLE CONFIGURATION OPTIONS

This reader has a number of programmable configuration properties. These properties are stored in non-volatile memory. These properties can be configured at the factory or by the end user using a program supplied by MagTek. Programming these parameters requires low level communications with the reader. Details on how to communicate with the reader to change programmable configuration properties follows in the next few sections. These details are included as a reference only. Most users will not need to know these details because the reader will be configured at the factory or by a program supplied by MagTek. Most users may want to skip over the next few sections on low level communications and continue with the details of the configuration properties.

COMMANDS

Most host applications do not need to send commands to the reader. Most host applications only need to obtain card data from the reader as described previously in this section. This section of the manual can be ignored by anyone who does not need to send commands to the reader.

Command requests and responses are sent to and received from the reader using command strings. Command requests are sent to the reader via a serial port. The response to a command is retrieved from the corresponding serial port.

Each command and response is composed of a series of readable ASCII characters followed by the ASCII character CR. The ASCII characters preceding the CR are the message; there should always be an even number of them and they should contain only the characters 0123456789ABCDEF. The receiver will combine two successive ASCII characters from the message to form one “byte” (see the descriptions of the commands) which may have any value from 0x00 to 0xFF.

The following table shows the structure of a command message:

The following table shows the structure of a response to a command.

Privileged Commands

Some commands are, for security purposes, privileged. These commands are:

10

(1) Set Property (2) Reset Device*

* The Reset Device command is usually not Privileged. The exception occurs when sending

a sequence to Activate the Authenticated Mode, during which time the Reset Device

Section 2. Communications

Value

Command Number

Description

0x00

Get Property

Gets a property from the reader

0x01

Set Property

Sets a property in the reader

0x02

Reset Device

Resets the reader

0x09

Get DUKPT KSN

Reports DUKPT KSN and Counter

0x0A

Set Session ID

Sets the current Session ID

Starts Activation of Authenticated Mode of secure operation

of secure operation

Deactivates the Authenticated Mode of secure operation

0x14

Get Reader State

Gets the current state of the reader

0x1C

Get Encryption Counter

Gets the encryption counter

0x30

Bulk Encrypt

Encrypts Bulk Data

0xA0

Read ASIC Control

Enables / disables the Read ASIC

command is Privileged to prevent a hacker from using this sequence to exhaust DUKPT keys, thereby rendering the reader unusable.

The privileged commands must be MACed in order to be accepted. If a MAC is required but not present or incorrect, RC = 07 will be returned.

Command Number

This one-byte field contains the value of the requested command number. The following table lists all the existing commands.

0x10 Activate Authenticated Mode 0x11 Activation Challenge Reply 0x12 Deactivate Authenticated Mode

Completes the Activation of Authenticated Mode

Data Length

This one-byte field contains the length of the valid data contained in the Data field. For example, a command with one byte of data would send 01 for this byte; a command with 18 bytes of data would send 12 for this byte.

Data

This multi-byte field contains command data if any. Note that the maximum length of this field is fixed at 120 bytes. Valid data should be placed in the field starting at offset 2.

11

iDynamo MagneSafe V5 Communication Manual

Value

(Hex)

00

Success

The command completed successfully.

01

Failure

The command failed.

The command failed due to a bad parameter or command syntax error.

mode

07

Invalid Operation

Depends on context of command

Data Offset

Value

0

Property ID

Data Offset

Value

0 – n

Property Value

Data Offset

Value

0

Property ID

1 – n

Property Value

Result Code

This one-byte field contains the value of the result code. There are two types of result codes: generic result codes and com man d-specific result codes. Generic result codes always have the most significant bit set to zero. Generic result codes have the same meaning for all commands and can be used by any command. Command-specific result codes always have the most significant bit set to one. Command-specific result codes are defined by the command that uses them. The same code can have different meanings for different commands. Command-specific result codes are defined in the documentation for the command that uses them. Generic result codes are defined in the following table.

Result Code Description

02 Bad Parameter 05 Delayed

The request is refused due to anti-hacking

GET AND SET PROPERTY COMMANDS

The Get Property command gets a property from the reader. The Get Property command number is 00.

The Set Property command sets a property in the reader. The Set Property command number is 01. For security purposes, this command is privileged. This commands must be MACed in order to be accepted.

The Get and Set Property command data fields for the requests and responses are structured as follows:

Get Property Request Data:

Get Property Respons e Data:

Set Property Request Data:

Set Property Respo ns e Dat a:

None

Result Codes

The result codes for the Get and Set Property commands can be any of the codes listed in the generic result code table.

12

Section 2. Communications

Property

ID

P-

Value

0x00

Software ID

The reader’s software identifier

0x03

Device Serial Num

The reader’s serial number

0x04

MagneSafe Version Number

Version number of MagneSafe feature set

0x05

Track ID Enable

Track enable / ID enable

0x07

ISO Track Mask

Specifies Masking factors for ISO cards

0x08

AAMVA Track Mask

Specifies Masking factors for AAMVA cards

0x10

Interface Type

Type of interface

0x14

Track Data Send Flags

Track data send flags

0x15

MP Flags

Enables sending of MagnePrint data

0x19

CRC Flag

Enables/disables sending CRC

0x1B

Decode Enable

Enables decoding for certain formats

0x1C

SS JIS TYPE 2

Start sentinel character for JIS type 2

0x1D

ES JIS TYPE 2

End Sentinel Character for JIS type 2

0x1E

P30

Pre-Card String

Pre card string

0x1F

P31

Post-Card String

Post card string

0x20

P32

Pre-Track String

Pre track string

0x21

P33

Post-Track String

Post track string

0x22

P34

Termination String

Terminating string

0x23

P35

FS

Field Separator for additional data

0x24

P36

SS Track 1 ISO ABA

Start sentinel char for track 1 – ISO/ABA

0x25

P37

SS Track 2 ISO ABA

Start sentinel char for track 2 – ISO/ABA

0x26

P38

SS Track 3 ISO ABA

Start sentinel char for track 3 – ISO/ABA

0x27

P39

SS Track 3 AAMVA

Start sentinel char for track 3 – AAMVA

0x28

P40

SS Track 2 7BITS

Start sentinel char for track 2 – 7 bit data

0x29

P41

SS Track 3 7BITS

Start sentinel char for track 3 – 7 bit data

End sentinel char for all tracks/formats except JIS type 2

Defines the Format Code to be sent with the message

0x2D

P45

ES Track 1

End sentinel char for track 1

0x2E

P46

ES Track 2

End sentinel char for track 2 except JIS type 2

0x2F

P47

ES Track 3

End sentinel char for track 3

0x30

Send Encryption Counter

Enables/disables sending Encryption Counter

Enables/disables masking of cards that don’t meet the ISO Financial or the AAMVA formats

Enables/disables sending of clear AAMVA card data

0x50

Bundle Seed ID String

Shows Bundle Seed ID

0x51

SDK Protocol Token String

Shows SDK Protocol String

Property ID

Property ID is a one-byte field that contains a hex value that identifies the property. The following table lists all the current property ID values:

Property Description

0x2B P43 ES 0x2C Format Code

0x31 Mask Other Cards 0x34 Send clear AAMVA card data

The Property Value is a multiple-byte field that contains the value of the property. The number of bytes in this field depends on the type of property and the length of the property. The following table lists all of the property types and describes them.

13

iDynamo MagneSafe V5 Communication Manual

Property Type

Description

Byte

This is a one-byte value. The valid values depend on the property.

This is a multiple byte ASCII string. Its length can be zero to a length of the string does not include a terminating NUL character.

Cmd Num

Data Len

Prp ID

00

01

00

Result Code

Data Len

Prp Value

00

0B

32 31 30 34 32 38 37 35 41 30 31

Cmd Num

Data Len

Prp ID

Prp Value

01

04

03

31 32 33

String

maximum length that depends on the property. The value and

Property Default Values

Each property specifies a default value. This is the firmware default value and may be changed during the manufacturing or order fulfillment process to support the needs of specific clients.

PROPERTIES

All of the properties available in this reader are shown below.

Software ID Property

Property ID: 0x00 Property Type: String Length: Fixed at 11 bytes Get Property: Yes Set Property: No Description: This is an 11-byte read-only property that identifies the software part number

and version for the reader. The first 8 bytes represent the part number and the last 3 bytes represent the version. For example this string might be “21042875A01”.

Example Get Software ID property Request (Hex):

Example Get Software ID property Response (Hex):

Device Serial Number property

Property ID: 0x03 Property Type: String Length: 0 – 15 bytes Get Property: Yes Set Property: Yes (Once only) Default Value: The default value is no string with a length of zero. Description: The value is an ASCII string that represents the reader serial number. This

string can be 0 – 15 bytes long. This property may be Set once only. Attempts to Set the property again will fail with RC = 0x07 (Sequence Error).

This property is stored in non-volatile memory, so it will persist when the unit is power cycled. When this property is changed, the unit must be reset (see Command Number 2) or power cycled for these changes to take effect.

Example Set Device Serial Number property Request (Hex):

14

Section 2. Communications

Result Code

Data Len

Data

00

Cmd Num

Data Len

Prp ID

00

01

03

Result Code

Data Len

Prp Value

00

03

31 32 33

Cmd Num

Data Len

Prp ID

00

01

04

Result Code

Data Len

Prp Value

00

02

56 30 35

Example Set Device Serial Number property Response (Hex):

Example Get Device Serial Number property Request (Hex):

Example Get Device Serial Number property Response (Hex):

MagneSafe Version Number Property

Property ID: 0x04 Property Type: String Length: 0 – 7 bytes Get Property: Yes Set Property: No Default Value: “V05” (may change later) Description: This is a maximum 7-byte read-only property that identifies the MagneSafe

Feature Level supported on this reader. Attempts to set this property will fail with RC=01.

Example Get MagneSafe Version Number property Request (Hex):

Example Get MagneSafe Version Number property Response (Hex):

Track ID Enable Property

Property ID: 0x05 Property Type: Byte Length: 1 byte Get Property: Yes Set Property: Yes Default Value: 0x95 Description: This property is defined as follows:

id 0 T3 T3 T2 T2 T1 T1

Id 0 – Decodes standard ISO/ABA cards only 1 – Decodes AAMV and 7-bit cards also

If this flag is set to 0, only tracks that conform to the ISO format allowed for that track will be decoded. If the track cannot be decoded by the ISO method it will be considered to be in error.

T# 00 – Track Disabled

15

iDynamo MagneSafe V5 Communication Manual

Cmd Num

Data Len

Prp ID

Prp Value

01

02

05

95

Result Code

Data Len

Data

00

Cmd Num

Data Len

Prp ID

00

01

05

Result Code

Data Len

Prp Value

00

01

95

01 – Track Enabled 10 – Track Enabled/Required (Error if blank)

This property is stored in non-volatile memory, so it will persist when the unit is power cycled. When this property is changed, the unit must be reset (see Command Number 2) or power cycled for these changes to take effect.

Example Set Track ID Enable property Request (Hex):

Example Set Track ID Enable property Response (Hex):

Example Get Track ID Enable property Request (Hex):

Example Get Track ID Enable property Response (Hex):

ISO Track Mask Property

Property ID: 0x07 Property Type: String Length: 6 bytes Get Property: Yes Set Property: Yes Default Value: ”04040Y” Description: This property specifies the factors for masking data on ISO/ABA type cards:

• The first two bytes specify how many of the leading characters of the PAN

should be sent unmasked. The range of masking is from “00” to “99.”

• The next two bytes specify how many of the trailing characters of the PAN

should be sent unmasked. The range of masking is from “00” to “99.”

• The fifth byte specifies which character should be used for masking. If this

byte contains the uppercase letter ‘V’, the following rules apply:

o The character used for masking the PAN will be ‘0’ o All data after the PAN will be sent without masking

• The sixth byte specifies whether the Mod 10 Correction should be applied to

the PAN. “Y” means Yes, the Mod 10 Correction will be applied. “N” means No, the Mod 10 will not be applied. (This option is only effective if the masking character is “0”.)

This property is stored in non-volatile memory, so it will persist when the unit is power cycled. When this property is changed, the unit must be reset (see Command Number 2) or power cycled for these changes to take effect.

16

Section 2. Communications

Cmd Num

Data Len

Prp ID

00

01

10

Result Code

Data Len

Prp Value

00

01

02

AAMVA Track Mask Property

Property ID: 0x08 Property Type: String Length: 6 bytes Get Property: Yes Set Property: Yes Default Value: ”04040Y” Description: This property specifies the factors for masking data on AAMVA type cards:

• The first two bytes specify how many of the leading characters of the Driver’s

License/ID Number (DL/ID#) should be sent unmasked. The range of masking is from “00” to “99.”

• The next two bytes specify how many of the trailing characters of the DL/ID#

should be sent unmasked. The range of masking is from “00” to “99.”

• The fifth byte specifies which character should be used for masking. If this

byte contains the uppercase letter ‘V’, the following rules apply:

o The DL/ID# will be masked according to the rules of this property

(the Send Clear AAMVA Card Data property is ignored)

o The character used for masking the DL/ID# will be ‘0’ o All data after the DL/ID# will be sent without masking

• The sixth byte specifies whether the Mod 10 Correction should be applied to

the DL/ID#. “Y” means Yes, the Mod 10 Correction will be applied. “N” means No, the Mod 10 will not be applied. (This option is only effective if the masking character is “0”.)

This property is stored in non-volatile memory, so it will persist when the unit is power cycled. When this property is changed, the unit must be reset (see Command Number 2) or power cycled for these changes to take effect.

Interface Type Property

Property ID: 0x10 Property Type: Byte Length: 1 byte Get Property: Yes Set Property: No Default Value: 0x02 (Indicates UART interface) Description: The value is a 1-byte read-only property that represents the reader’s interface

type. It is always set to 0x02 indicating this is an UART/RS232 reader.

Example Get Interface Type property Request (Hex):

Example Get Interface Type property Response (Hex):

17

iDynamo MagneSafe V5 Communication Manual

Track Data Send Flags Property

Property ID: 0x14 Property Type: Byte Length: 1 byte Get Property: Yes Set Property: Yes Default Value: 0x63 Description: This property is defined as follows:

ICL SS ES 0 0 LC Er Er

ICL 0 – Changing the state of the caps lock key will not affect the case of the data 1 – Changing the state of the caps lock key will affect the case of the data

SS 0 – Don’t send Start Sentinel for each track 1 – Send Start Sentinel for each track

ES 0 – Don’t send End Sentinel for each track 1 – Send End Sentinel for each track

LC 0 – Send card data as upper case 1 – Send card data as lower case

Er 00 – Don’t send any card data if error – NOT CURRENTLY IMPLEMENTED 01 – Don’t send track data if error 11 – Send ‘E’ for each track error

This property is stored in non-volatile memory, so it will persist when the unit is power cycled. When this property is changed, the unit must be reset (see Command Number 2) or power cycled for these changes to take effect.

MP Flags Property

Property ID: 0x15 Property Type: Byte Length: 1 byte Get Property: Yes Set Property: Yes Default Value: 0x00 Description: This property is defined as follows:

0 0 0 0 0 0 0 S

S 0 – MagnePrint Data will NOT be sent 1 – MagnePrint Data will be sent.

This property is used to designate whether or not the MagnePrint data is sent as part of a card swipe message. Setting S to 1 causes the MagnePrint Status and Unencrypted MagnePrint Data to be sent with each swipe. Setting S to 0 causes these fields to be omitted from the data. When these fields are omitted, the Programmable Field Separator that precedes each of these fields will also be omitted.

18

Section 2. Communications

Bit

Position

Type

This property is stored in non-volatile memory, so it will persist when the unit is power cycled. When this property is changed, the unit must be reset (see Command Number 2) or power cycled for these changes to take eff ect.

CRC Flag Property

Property ID: 0x19 Property Type: Byte Length: 1 byte Get Property: Yes Set Property: Yes Default Value: 0x01 Description: This property is defined as follows:

0 0 0 0 0 0 E S

E 0 – The Encrypted CRC will NOT be sent 1 – The Encrypted CRC will be sent

S 0 – The Clear Text CRC will NOT be sent 1 – The Clear Text CRC will be sent.

This property is used to designate whether or not the Encrypted and/or the Clear Text CRC will be sent as part of a card swipe message. In the default state of this property, the device will send only the Clear Text CRC. When these fields are omitted, the Programmable Field Separator that precedes each of these fields will be sent anyhow.

This property is stored in non-volatile memory, so it will persist when the unit is power cycled. When this property is changed, the unit must be reset (see Command Number 2) or power cycled for these changes to take effect.

Decode Enable Property

Property ID: 0x1B Property Type: Byte Length: 1 byte Get Property: Yes Set Property: Yes Default Value: 0x00 Description: This property is defined as follows:

7 6 5 4 3 2 1 0

Decode

Reserved Reserved Reserved Reserved Reserved Reserved Reserved JIS Type 2

When a decode type bit is set to 1 (true), the decode type represented by that bit is enabled. When a decode type bit is set to 0 (false), the decode type represented by that bit is disabled. The reserved decode type bits should always be set to zero.

19

iDynamo MagneSafe V5 Communication Manual

Cmd Num

Data Len

Prp ID

Prp Value

decode type)

Result Code

Data Len

Data

00

Cmd Num

Data Len

Prp ID

00

01

1B

Result Code

Data Len

Prp Value

00

01

This property is stored in non-volatile memory, so it will persist when the unit is power cycled. When this property is changed, the unit must be reset (see Command Number 2) or power cycled for these changes to take effect.

Example Set property Request (Hex):

01 02 1B 01 (enable JIS Type 2

Example Set property Response (Hex):

Example Get property Request (Hex):

Example Get property Response (Hex):

SS JIS TYPE 2 Property

Property ID: 0x1C Property Type: Byte Length: 1 byte Get Property: Yes Set Property: Yes Default Value: 0x7F ‘DEL’ Description: This character is sent as the start sentinel for cards that are encoded in the JIS

type 2 format. If the value is in the range 0 – 127 then the equivalent ASCII character will be sent.

This property is stored in non-volatile memory, so it will persist when the unit is power cycled. When this property is changed, the unit must be reset (see Command Number 2) or power cycled for these changes to take effect.

ES JIS TYPE 2 Property

Property ID: 0x1D Property Type: Byte Length: 1 byte Get Property: Yes Set Property: Yes Default Value: 0x7F ‘DEL’ Description: This character is sent as the end sentinel for cards that are encoded in the JIS

type 2 format. If the value is in the range 0 – 127 then the equivalent ASCII character will be sent.

20

Section 2. Communications

Cmd Num

Data Len

Prp ID

Prp Value

01

04

1E

31 32 33

Result Code

Data Len

Data

00

Cmd Num

Data Len

Prp ID

00

01

1E

Result Code

Data Len

Prp Value

00

03

31 32 33

This property is stored in non-volatile memory, so it will persist when the unit is power cycled. When this property is changed, the unit must be reset (see Command Number 2) or power cycled for these changes to take effect.

Pre Card String Property

Property ID: 0x1E Property Type: String Length: 0 – 7 bytes Get Property: Yes Set Property: Yes Default Value: The default value is no string with a length of zero. Description: The value is an ASCII string that represents the reader’s pre card string. This

string can be 0 – 7 bytes long. This string is sent prior to all other card data.

This property is stored in non-volatile memory, so it will persist when the unit is power cycled. When this property is changed, the unit must be reset (see Command Number 2) or power cycled for these changes to take effect.

Example Set Pre-Card String property Request (Hex):

Example Set Pre-Card String property Response (Hex):

Example Get Pre-Card String property Request (Hex):

Example Get Pre-Card String property Response (Hex):

Post Card String Property

Property ID: 0x1F Property Type: String Length: 0 – 7 bytes Get Property: Yes Set Property: Yes Default Value: The default value is no string with a length of zero. Description: The value is an ASCII string that represents the reader’s post card string. This

string can be 0 – 7 bytes long. This string is sent after all other card data.

This property is stored in non-volatile memory, so it will persist when the unit is power cycled. When this property is changed, the unit must be reset (see Command Number 2) or power cycled for these changes to take effect.

Example Set Post-Card String property Request (Hex):

21

iDynamo MagneSafe V5 Communication Manual

Cmd Num

Data Len

Prp ID

Prp Value

01

04

1F

31 32 33

Result Code

Data Len

Data

00

Cmd Num

Data Len

Prp ID

00

01

1F

Result Code

Data Len

Prp Value

00

03

31 32 33

Cmd Num

Data Len

Prp ID

Prp Value

01

04

20

31 32 33

Result Code

Data Len

Data

00

Cmd Num

Data Len

Prp ID

00

01

20

Result Code

Data Len

Prp Value

00

03

31 32 33

Example Set Post-Card String property Response (Hex):

Example Get Post-Card String property Request (Hex):

Example Get Post-Card String property Response (Hex):

Pre-Track String Property

Property ID: 0x20 Property Type: String Length: 0-7 bytes Get Property: Yes Set Property: Yes Default Value: No string with a length of zero. Description: This string is sent prior to the data for each track. The string can be 0 – 7

bytes long. If the value is 0 no character is sent.

This property is stored in non-volatile memory, so it will persist when the unit is power cycled. When this property is changed, the unit must be reset (see Command Number 2) or power cycled for these changes to take effect.

Example Set Pre-Track String property Request (Hex):

Example Set Pre-Track S tri ng property Response (Hex):

Example Get Pre-Track String property Request (Hex):

Example Get Pre-Track String property Response (Hex):

22

Section 2. Communications

Cmd Num

Data Len

Prp ID

Prp Value

01

04

21

31 32 33

Result Code

Data Len

Data

00

Cmd Num

Data Len

Prp ID

00

01

21

Result Code

Data Len

Prp Value

00

03

31 32 33

Post Track String Property

Property ID: 0x21 Property Type: String Length: 0-7 bytes Get Property: Yes Set Property: Yes Default Value: No string with a length of zero Description: This string is sent after the data for each track. The string can be 0 – 7 bytes

long. If the value is 0 no character is sent.

This property is stored in non-volatile memory, so it will persist when the unit is power cycled. When this property is changed, the unit must be reset (see Command Number 2) or power cycled for these changes to take effect.

Example Set Post-Track String property Request (Hex):

Example Set Post-Track String property Response (Hex):

Example Get Post-Track String property Request (Hex):

Example Get Post-Track String property Response (Hex):

Termination String Property

Property ID: 0x22 Property Type: String Length: 0-7 bytes Get Property: Yes Set Property: Yes Default Value: 0x0D (carriage return) Description: This string is sent after the all the data for a transaction. The string can be 0 –

7 bytes long. If the value is 0 no character is sent.

This property is stored in non-volatile memory, so it will persist when the unit is power cycled. When this property is changed, the unit must be reset (see Command Number 2) or power cycled for these changes to take effect.

23

iDynamo MagneSafe V5 Communication Manual

FS Property

Property ID: 0x23 Property Type: Byte Length: 1 byte Get Property: Yes Set Property: Yes Default Value: 0x7C ‘|’ Description: This character is sent as the field separator to delimit additional data

(MagnePrint info, Device info, DUKPT info, etc.). If the value is 0 no character is sent. If the value is in the range 1 – 127 then the equivalent ASCII character will be sent.

This property is stored in non-volatile memory, so it will persist when the unit is power cycled. When this property is changed, the unit must be reset (see Command Number 2) or power cycled for these changes to take effect.

SS Track 1 ISO AB A Property

Property ID: 0x24 Property Type: Byte Length: 1 byte Get Property: Yes Set Property: Yes Default Value: 0x25 ‘%’ Description: This character is sent as the track 1 start sentinel for cards that have track 1

encoded in ISO/ABA format. If the value is 0 no character is sent. If the value is in the range 1 – 127 then the equivalent ASCII character will be sent.

This property is stored in non-volatile memory, so it will persist when the unit is power cycled. When this property is changed, the unit must be reset (see Command Number 2) or power cycled for these changes to take effect.

SS Track 2 ISO AB A Property

Property ID: 0x25 Property Type: Byte Length: 1 byte Get Property: Yes Set Property: Yes Default Value: 0x3B ‘;’ Description: This character is sent as the track 2 start sentinel for cards that have track 2

encoded in ISO/ABA format. If the value is 0 no character is sent. If the value is in the range 1 – 127 then the equivalent ASCII character will be sent.

This property is stored in non-volatile memory, so it will persist when the unit is power cycled. When this property is changed, the unit must be reset (see Command Number 2) or power cycled for these changes to take effect.

24

Section 2. Communications

SS Track 3 ISO AB A Property

Property ID: 0x26 Property Type: Byte Length: 1 byte Get Property: Yes Set Property: Yes Default Value: 0x2B (‘+’) Description: This character is sent as the track 3 start sentinel for cards that have track 3

encoded in ISO/ABA format. If the value is 0 no character is sent. If the value is in the range 1 – 127 then the equivalent ASCII character will be sent.

This property is stored in non-volatile memory, so it will persist when the unit is power cycled. When this property is changed, the unit must be reset (see Command Number 2) or power cycled for these changes to take effect.

SS Track 3 AAMVA Property

Property ID: 0x27 Property Type: Byte Length: 1 byte Get Property: Yes Set Property: Yes Default Value: 0x23 (‘#’) Description: This character is sent as the track 3 start sentinel for cards that have track 3

encoded in AAMVA format. If the value is 0 no character is sent. If the value is in the range 1 – 127 then the equivalent ASCII character will be sent.

This property is stored in non-volatile memory, so it will persist when the unit is power cycled. When this property is changed, the unit must be reset (see Command Number 2) or power cycled for these changes to take effect.

SS Track 2 7bits Property

Property ID: 0x28 Property Type: Byte Length: 1 byte Get Property: Yes Set Property: Yes Default Value: 0x40 (‘@’) Description: This character is sent as the track 2 start sentinel for cards that have track 2

encoded in 7 bits per character format. If the value is 0 no character is sent. If the value is in the range 1 – 127 then the equivalent ASCII character will be sent.

This property is stored in non-volatile memory, so it will persist when the unit is power cycled. When this property is changed, the unit must be reset (see Command Number 2) or power cycled for these changes to take effect.

25

iDynamo MagneSafe V5 Communication Manual

SS Track 3 7bits Property

Property ID: 0x29 Property Type: Byte Length: 1 byte Get Property: Yes Set Property: Yes Default Value: 0x26 (‘&’) Description: This character is sent as the track 3 start sentinel for cards that have track 3

encoded in 7 bits per character format. If the value is 0 no character is sent. If the value is in the range 1 – 127 then the equivalent ASCII character will be sent.

This property is stored in non-volatile memory, so it will persist when the unit is power cycled. When this property is changed, the unit must be reset (see Command Number 2) or power cycled for these changes to take effect.

ES Property

Property ID: 0x2B Property Type: Byte Length: 1 byte Get Property: Yes Set Property: Yes Default Value: 0x3F (‘?’) Description: This character is sent as the end sentinel for all tracks with any format except

JIS type 2. If the value is 0 no character is sent. If the value is in the range 1 – 127 then the equivalent ASCII character will be sent.

This property is stored in non-volatile memory, so it will persist when the unit is power cycled. When this property is changed, the unit must be reset (see Command Number 2) or power cycled for these changes to take effect.

Format Code Property

Property ID: 0x2C Property Type: String Length: 4 bytes Get Property: Yes Set Property: Yes Default Value: “0000” Description: This property specifies the Format Code that will be returned at the end of a

transmitted card swipe. The application sends four characters, but only the last three will be set. The first character is reserved for MagTek use. A value of ‘0’ in the first character means the Format Code is defined by MagTek; a value of ‘1’ means the Format Code is application defined.

This property is stored in non-volatile memory, so it will persist when the unit is power cycled. When this property is changed, the unit must be reset (see Command Number 2) or power cycled for these changes to take effect.

26

Section 2. Communications

ES Track 1 Property

Property ID: 0x2D Property Type: Byte Length: 1 byte Get Property: Yes Set Property: Yes Default Value: 0xFF (use ES property) Description: This character is sent as the end sentinel for track 1 with any format. If the

value is 0 no character is sent. If the value is in the range 1 – 127 then the equivalent ASCII character will be sent. If the value is 0xFF then the value of the ES property will be used instead of this property.

This property is stored in non-volatile memory, so it will persist when the unit is power cycled. When this property is changed, the unit must be reset (see Command Number 2) or power cycled for these changes to take effect.

ES Track 2 Property

Property ID: 0x2E Property Type: Byte Length: 1 byte Get Property: Yes Set Property: Yes Default Value: 0xFF (use ES property) Description: This character is sent as the end sentinel for track 2 with any format except

JIS type 2. If the value is 0 no character is sent. If the value is in the range 1 – 127 then the equivalent ASCII character will be sent. If the value is 0xFF then the value of the ES property will be used instead of this property.

This property is stored in non-volatile memory, so it will persist when the unit is power cycled. When this property is changed, the unit must be reset (see Command Number 2) or power cycled for these changes to take effect.

ES Track 3 Property

Property ID: 0x2F Property Type: Byte Length: 1 byte Get Property: Yes Set Property: Yes Default Value: 0xFF (use ES property) Description: This character is sent as the end sentinel for track 3 with any format. If the

value is 0 no character is sent. If the value is in the range 1 – 127 then the equivalent ASCII character will be sent. If the value is 0xFF then the value of the ES property will be used instead of this property.

This property is stored in non-volatile memory, so it will persist when the unit is power cycled. When this property is changed, the unit must be reset (see Command Number 2) or power cycled for these changes to take effect.

27

iDynamo MagneSafe V5 Communication Manual

Send Encryption Counter Property

Property ID: 0x30 Property Type: Byte Length: 1 byte Get Property: Yes Set Property: Yes Default Value: 0x00 (don’t send Encryption Counter) Description: This property is used to designate whether or not the Encryption Counter is

sent as part of a keyboard message. If the property is set to 0x00, neither the Encryption Counter nor the field separator will be sent. If the property is set to 0x01, the Encryption Counter is sent as the field immediately following the DUKPT Serial Number in a swipe message.

NOTE: If this property is set to 0x01 and the Format Code is currently

“0000”, the Format Code will be changed to “0001”.

This property is stored in non-volatile memory, so it will persist when the unit is power cycled. When this property is changed, the unit must be reset (see Command Number 2) or power cycled for these changes to take effect.

Mask Other Cards Property

Property ID: 0x31 Property Type: Byte Length: 1 byte Get Property: Yes Set Property: Yes Default Value: 0x00 (Don’t Mask Other cards) Description: This property is used to designate whether or not the cards which do not

decode as ISO/ABA (Financial) or AAMVA (Driver License) cards should be sent with their data masked or in the clear. The default state is to send the data in the clear (0x00). If this property is set to 0x01, the track(s) will be sent with a ‘0’ for each byte of encoded data read.

This property is stored in non-volatile memory, so it will persist when the unit is power cycled. When this property is changed, the unit must be reset (see Command Number 2) or power cycled for these changes to take effect.

Send Clear AAMVA Card Data Property

Property ID: 0x34 Property Type: Byte Length: 1 byte Get Property: Yes Set Property: Yes Default Value: 0x00 Description: This property is used to control how to send out AAMVA card data.

28

Section 2. Communications

Cmd Num

Data Len

Prp ID

Data

01

06

34

01 xx xx xx xx *

Result Code

Data Len

Data

00

Cmd Num

Data Len

Prp ID

00

01

34

Result Code

Data Len

Data

00

01

Cmd Num

Data Len

Prp ID

Prp Value

01

0B

50

57 39 34 32 51 46 4E 56 4D

Result Code

Data Len

Data

00

Cmd Num

Data Len

Prp ID

00

01

50

This property is stored in non-volatile memory, so it will persist when the unit

is power cycled. When this property is changed, the unit must be reset (see Command Number 2) or power cycled for these changes to take effect.

0 – send out masked AAMVA card data 1 – send out clear AAMVA card data

Example Set Send Clear AAMVA Card Data property Request (Hex):

* where “xx xx xx xx” is the MAC.

Example Set Send Clear AAMVA Card Data property Response (Hex):

Example Get Send Clear AAMVA Card Data property Request (Hex):

Example Get Send Clear AAMVA Card Data property Response (Hex):

Bundle Seed ID String Property

Property ID: 0x50 Property Type: String Length: 10 bytes Get Property: Yes Set Property: Yes Default Value: The default value W9342QFNVM. Description: The value is an ASCII string that represents the reader BundleSeedID string.

This string is always 10 bytes long.

This property is stored in non-volatile memory, so it will persist when the unit is power cycled. When this property is changed, the unit must be reset (see Command Number 2) or power cycled for these changes to take effect.

Example Set BundeSeedID String property Request (Hex):

Example Set BundeSeedID String property Response (Hex):

Example Get BundeSeedID String property Request (Hex):

29

iDynamo MagneSafe V5 Communication Manual

Result Code

Data Len

Prp Value

00

0A

57 39 34 32 51 46 4E 56 4D

Cmd Num

Data Len

Prp ID

Prp Value

01

13

51

63 6F 6D 2E 6D 61 67 74 65 6B 2E 69 64 79 6E 61 6D 6F

Result Code

Data Len

Data

00

Cmd Num

Data Len

Prp ID

00

01

51

Result Code

Data Len

Prp Value

00

12

63 6F 6D 2E 6D 61 67 74 65 6B 2E 69 64 79 6E 61 6D 6F

Example Get Device Serial Number property Response (Hex):

SDK Protocol Token String Property

Property ID: 0x51 Property Type: String Length: 50 bytes Get Property: Yes Set Property: Yes Default Value: The default value is com.magtek.idynamo Description: The value is an ASCII string that represents the reader SDK Protocol Token

string, sometimes referred to as the Reverse DNS string. This string can be a maximum of 50 bytes long.

This property is stored in non-volatile memory, so it will persist when the unit is power cycled. When this property is changed, the unit must be reset (see Command Number 2) or power cycled for these changes to take effect.

Example Set SDK Protocol Token String property Request (Hex):

Example Set SDK Protocol Token String property Response (Hex):

Example Get SDK Protocol Token String property Request (Hex):

Example Get SDK Protocol Token String property Response (Hex):

Card Data Encryption Variant Property

Property ID: 0x54 Property Type: Byte Length: 1 byte Get Property: Yes Set Property: Yes Default Value: 0x00 (PIN Variant) Description: This property is used to indicate which Variant of the current DUKPT key is

used to encrypt swipe data for Track 1, Track 2, Track 3, and the Session ID.

• A value of 0x00 indicates the PIN Variant will be used,

• A value of 0x01 indicates the Data Encryption both ways Variant will be

used.

These variants are fully specified in the ANSI-X9.24-1 2009 standard.

30

Section 2. Communications

Cmd Num

Data Len

Prp ID

Data

01

06

54

01

Result Code

Data Len

Data

00

Cmd Num

Data Len

Prp ID

00

01

54

Result Code

Data Len

Data

00

01

This property is stored in non-volatile memory, so it will persist when the unit is power cycled. When this property is changed, the unit must be reset (see Command Number 2) or power cycled to have these changes take effect.

Example Configure to use Card Data Encryption Variant – Data Encryption both ways:

Example Configure to use Card Data Encryption Variant – Data Encryption both ways Response (Hex):

Example Get Card Data Encryption Variant property:

Example Get Card Data Encryption Variant Response (Hex):

31

iDynamo MagneSafe V5 Communication Manual

Cmd Num

Data Len

Data

02

00

Result Code

Data Len

Data

00

Offset

Field Name

Description

0

Current Key

This eighty-bit field includes the Initial Key Serial Encryption Counter in the rightmost 21 bits.

Cmd Num

Data Len

Data

09

00

none

COMMAND LIST

The following commands are used with this reader.

Reset Device Command

Command number: 0x02 Description: This command resets the reader. It can be used to make previously

changed properties take effect without power cycling the reader.

Note

When the reader begins an Authentication Sequence, the Reset command will not be honored until after the Authentication Sequence has successfully completed, the user swipes a card, or the unit is power cycled.

Data structure: No data is sent with this command Result codes: 0x00 Success 0x01 Failure

Example Reset Device Request (Hex):

Example Reset Device Response (Hex):

DUKPT Operation

Since key loading is proprietary and performed at MagTek, there are no user commands to support key injection.

Get DUKPT KSN and Counter Command

Command number: 0x09 Description: This command is used to report the Key Serial Number and Encryption

Counter.

Data structure: No data is sent with this command.

Response Data:

Serial Number

Number in the leftmost 59 bits and a value for the

Result codes: 0x00 Success

0x02 Bad Parameter – The Request Data is not the correct length. The

request command contains no data, so the Data Length must be 0.

Example Request (Hex):

32

Section 2. Communications

Result Code

Data Len

Data

00

0A

FFFF 9876 5432 10E0 0001

Offset

Field Name

Description

0

New Session ID

This eight byte field may contain any value the application wishes.

Cmd Num

Data Len

Data

0A

08

54 45 53 54 54 45 53 54

Result Code

Data Len

Data

00

Example Response (Hex):

Set Session ID Command

Command number: 0x0A Description: This command is used to set the current Session ID. The new Session ID

stays in effect until one of the following occurs:

1. Another Set Session ID command is received.

2. The reader is powered down.

3. The reader is put into Suspend mode.

The Session ID is used by the host to uniquely identify the present transaction. Its primary purpose is to prevent replays. After a card is read, the Session ID will be encrypted, along with the card data, and supplied as part of the transaction message. The clear text version of this will never be transmitted.

Data structure:

Request Data:

Response Data: None

Result codes: 0x00 Success

0x02 Bad Parameter – The Request Data is not the correct length. The

Session ID is an 8-byte field, so the Data Length must be 8.

Example Set Session ID Request (Hex):

Example Set Session ID Response (Hex):

Activate Authenticated Mode Command

Command number: 0x10 Description: This command is used to Activate the Authenticated Mode. Note that this

command provides the only means by which to enter this Mode.

The application specifies a PreAuthentication Time Limit. This is the maximum number of seconds the reader will wait for the Activation Challenge Reply Command before timing out. If the supplied value is less than 120 seconds, the reader will use 120 seconds. If the reader times out waiting for the Activation Challenge Reply Command, the Authentication attempt fails and anti-hacking behavior may be invoked.

33

iDynamo MagneSafe V5 Communication Manual

Offset

Field Name

Description

0

PreAuthentication Time Limit (msb)

Most significant byte of the PreAuthentication Time Limit.

Time Limit (lsb)

Limit.

Offset

Field Name

Description

0

Current Key

This eighty-bit field includes the Initial Key Serial Number

10

Challenge 1

This eight byte challenge may be used later in an to authenticate the reader as mentioned above.

18

Challenge 2

This eight byte challenge may be used later in a Deactivate Authenticated Mode command shown belo w.

Cmd Num

Data Len

Data

10

00

The reader responds with two challenges (Challenge 1 and Challenge 2) encrypted using a variant of the current DUKPT PIN Encryption Key (Key XOR F0F0 F0F0 F0F0 F0F0 F0F0 F0F0 F0F0 F0F0). When decrypted, Challenge 1 contains 6 bytes of random number (used in the Activation Challenge Reply command) followed by the last two bytes of the KSN. These last two bytes of the KSN may be compared with the last two bytes of the clear text KSN sent in the message to authenticate the reader. The application should complete the Activate Authentication sequence using the Activation Challenge Reply command (see below).

The first two Activate Authenticated Mode commands may proceed without any delay (one error is allowed with no anti-hacking consequences). If a second Activate Authenticated Mode in a row fails, the reader goes into anti-hacking behavior. This consists of an increasing delay being enforced between Activate Authenticated Mode commands. The first delay is 10 seconds, increasing by 10 seconds until a maximum delay of 10 minutes is reached. The application may remove the reader from the anti-hacking mode at any time by swiping any encoded magstripe card. When the reader is in this anti-hacking mode it is NOT receptive to the Reset Device command.

Data structure:

Request Data:

1 PreAuthentication

Least significant byte of the PreAuthentication Time

Response Data:

Serial Number

in the leftmost 59 bits and a value for the Encryption Counter in the rightmost 21 bits.

Activation Challenge Reply command shown below, and

Result codes: 0x00 Success

0x03 Redundant – the reader is already in this mode 0x05 Delayed – the request is refused due to anti-hacking mode 0x07 Sequence Error – the current Security Level is too low 0x80 Encryption Counter Expired

Example Activate Authenticated Mode Request (Hex):

34

Section 2. Communications

Result Code

Data Len

Data

00

20

FFFF 0123 4567 8000 0003 9845 A48B 7ED3 C294 7987 5FD4 03FA 8543

Offset

Field Name

Description

0

Response to

Six bytes of Challenge 1 plus two bytes of time as the current DUKPT Key

8

Session ID

Optional eight byte Session ID encrypted by the specified variant of the current DUKPT Key.

Example Activate Authenticated Mode Response (Hex):

Activation Challenge Reply Command

Command number: 0x11 Description: This command is used as the second part of an Activate Authentication

sequence. In this command the application sends the first 6 bytes of Challenge 1 (received in response to the Activate Authenticated Mode command), two bytes of time information, and (optionally) an eight byte Session ID encrypted with a variant of the current DUKPT PIN Encryption Key (Key XOR 3C3C 3C3C 3C3C 3C3C 3C3C 3C3C 3C3C 3C3C).

The time information contains a count of the maximum number of seconds the reader should remain in the Authenticated Mode. Regardless of the value of this timer, a user card swipe in the Authenticated Mode ends the Authenticated Mode. The maximum time allowed is 3600 seconds (one hour). To get the full hour, use the value 0x0E10. To get the value of 3 minutes, use the value 0x012C. A value of zero forces the reader to stay in the Authenticated Mode until a card swipe or power down occurs (no timeout).

If the Session ID information is included and the command is successful, it will change the Session ID in the reader.

If the reader decrypts the CR response correctly the Activate Authenticated Mode has succeeded. If the reader can not decrypt the CR command correctly the Activate Authenticated Mode has failed, the DUKPT KSN advances.

Data structure:

Request Data: None

Challenge 1

Response Data: None

Result codes: 0x00 Success 0x02 Bad Parameters – the Request Data is not a correct length 0x04 Bad Data – the encrypted reply data could not be verified 0x07 Sequence – not expecting this command

outlined above, encrypted by the specified variant of

35

iDynamo MagneSafe V5 Communication Manual

Cmd Num

Data Len

Data

11

08

8579 8275 2157 3495

Result Code

Data Len

Data

00

Offset

Field Name

Description

0

Response to

Seven bytes of Challenge 2 plus one byte of specified variant of the current DUKPT Key

Cmd Num

Data Len

Data

12

08

8579827521573495

Result Code

Data Len

Data

Example Activation Challenge Reply Request (Hex):

Example Activation Challenge Reply Response (Hex):

Deactivate Authenticated Mode Command

Command number: 0x12 Description: This command is used to exit the Authenticated Mode command. It can

be used to exit the mode with or without incrementing the DUKPT transaction counter (lower 21 bits of the KSN). The application must send the first 7 bytes of Challenge 2 (from the response to the Activate Authenticated Mode command) and the Increment flag (0x00 indicates no increment, 0x01 indicates increment of the KSN) encrypted with a variant of the current DUKPT PIN Encryption Key (Key XOR 3C3C 3C3C 3C3C 3C3C 3C3C 3C3C 3C3C 3C3C).

If the reader decrypts Challenge 2 successfully it will exit the Authenticated Mode and, depending on the Increment flag, may increment the KSN.

If the reader cannot decrypt Challenge 2 successfully, it will stay in the Authenticated Mode until either the time specified in the Activate Authenticated Mode command passes or the user swipes a card. This behavior is intended to discourage denial of service attacks. Exiting the Authenticated Mode by timeout or card swipe always increments the KSN, exiting Authenticated Mode by the Deactivate Authenticated Mode command may increment the KSN.

Data structure:

Request Data:

Challenge 2

Response Data: None

Result codes: 0x00 Success 0x02 Bad Parameters – the Request Data is not a correct length 0x03 Bad Data – the encrypted reply data could not be verified 0x07 Sequence – not expecting this command

Example Deactivate Authenticated Mode Request (Hex):

Example Deactivate Authenticated Mode Response (Hex):

36

Increment flag as outlined above, encrypted by the

Section 2. Communications

00

Current Reader State

Value

Name

Meaning

0x00

WaitActAuth

Waiting for Activate Authenticated Mode. The reader requires Authentication before swipes are accepted.

reader is waiting for the Activation Challenge Reply command.

0x02

WaitSwipe

Waiting for Swipe. The reader is waiting for the user to Swipe a card.

0x03

WaitDelay

Waiting for Anti-Hacking Timer. Two or more previous attempts to before it accepts further Activate Authenticated Mode commands.

Current State Antecedent

Value

Name

Meaning

0x00

PU

Just Powered Up. The reader has had no swipes and has not been Authenticated since it was powered up.

0x02

GoodSwipe

Good Swipe. The user swiped a valid card correctly.

0x03

BadSwipe

Bad Swipe. The user swiped a card incorrectly or the card is not valid.

0x04

FailAuth

Authentication Activation Failed. The most recent Activation Challenge Reply command failed.

0x05

FailDeact

Authentication Deactiv ation Failed. A recent Deactivate Authenticated Mode command failed.

0x06

TOAuth

Authentication Activation Timed Out. The Host failed to send an Activation Authentication Mode command.

0x07

TOSwipe

Swipe Timed Out. The user failed to swipe a card in the time period specified in the Activation Challenge Repl y command.

Cmd Num

Data Len

Data

14

00

Get Reader State Command

Command Number: 0x14 Description: This command is used to get the current state of the reader. The state is

returned as two bytes that represent the Current State of the reader and how it got to that state (Antecedent). For more information see Reader

States.

Data Structure:

Request Data: None

Response Data:

The first byte specifies the current state as follows:

0x01 WaitActRply Waiting for Activation Challenge Reply. Activation has been started, the

Authenticate failed, the reader is waiting for the Anti-Hacking timer to expire

The second byte specifies how the reader got to its current state as follows:

0x01 GoodAuth Authentication Activation Successful. The reader processed a valid Activation

Challenge Reply command.

Challenge Reply command in the time period specified in the Activate

0x08 KeySyncError The keys between the MagneSafe processor and the Encrypting IntelliHead

are not the same and must be re-loaded before correct operation can resume.

Result codes: 0x00 Success

Example Request (Hex):

Example Response (Hex):

37

iDynamo MagneSafe V5 Communication Manual

Result Code

Data Len

Data

00

02

00 00

Offset

Field Name

Description

0

Device Serial #

16 bytes, if DSN is shorter than 15 bytes, left justify the last one) must contain binary zero.

16

Actual Encryption Counter

This three byte field returns the current value of the Encryption Counter.

Cmd Num

Data Len

Data

1C

00

Result Code

Data Len

Data

00

13

54455354205345545550203030303100 0007F1

Get Encryption Counter Command

Command number: 0x1C Description: This command is used to Get the Encryption Counter. The Encryption

Counter gives the maximum number of transactions that can be performed by the reader. A transaction is either an encrypted card swipe or a correctly completed Activation Sequence (Activate Authenticated Mode followed by correct Activation Challenge Reply).

The Encryption Counter has three possible states:

1. Disabled – value 0xFFFFFF – In this state there is no limit to the number of

transactions that can be performed.

2. Expired – value 0x000000 – This state indicates that all transactions are prohibited

3. Active – value 1 to 1,000,000 (0x000001 to 0x0F4240) – In this state, each

transaction causes the Encryption Counter to be decremented and allows transactions to be processed. If an Activation Sequence decrements the Encryption Counter to 0, a last encrypted card swipe will be permitted.

Request Data: None Response Data:

Result codes: 0x00 Success

0x02 Invalid length

Example Get Encryption Counter Request (Hex):

Example Get Encryption Counter Response (Hex) - Encryption Counter is 2033:

Encrypt Bulk Data Command

Command number: 0x30 Description: This command will encrypt up to a maximum of 120 bytes. The Data-

Response variant of the DUKPT key will be used to encrypt data. It will also compute a MAC for the S/N, Num Bytes Encrypted, KSN and Cryptogram. Data to be encrypted that are not a multiple of 8 bytes will be padded with NULLs to be a multiple of 8.

38

and fill with binary zeroes. At least one byte (usua ll y

Section 2. Communications

Cmd Num

Data Len

Data

30

05

01 02 03 04 05

Offset

Field Name

Description

0

ASIC Control

This 1-byte field controls the state of the Read ASIC:

Num Bytes (1 byte)

32 31 30 34 32 38

31 00

31 32 33

35

The DUKPT key counter/pointer will be incremented before processing

this command.

Example Request (Encrypt Bulk Data) (Hex):

Example Encrypt Bulk Data Response (Hex):

Result Code

00 0x27

Data Len

DSN (16 bytes)

31 32 44 30 31 31 31 31

Encrypted

05

KSN (10 bytes)

34 35 31 32 33 34

Cryptogram (8 bytes)

01 02 03 04 05 06 07 08

MAC (4 bytes)

01 02 03 04

DSN – Device Serial Number, this data field will always be fixed at 16 bytes. If the serial number is less than 15 bytes, it will be left justified. The 16th byte will always be set to NULL.

Cryptogram – Encrypted data, the length of which is always a multiple of 8, this field can be maximum of 120 characters.

Result codes: 0x00 Success

0x02 Bad Parameters, the Data Len is not supported 0x07 Security Level < 2, MSCI CMUT was incorrect

READ ASIC Control Command

Command number: 0xA0 Description: This command is used to enable or disable the Read ASIC. Setting S to 0

causes the read ASIC to be in the disabled and low power state. In this state, the ASIC will not read cards. The S bit must be set to 1 to enable cards to be read.

Data structure:

Request Data:

0 0 0 0 0 0 0 S

S 0 – Read ASIC disabled. 1 – Read ASIC enabled.

Response Data: None

Result codes: 0x00 Success 0x02 Bad Parameters – the Request Data is not a correct length

Example Read ASIC Control Request (Hex), Enable ASIC:

39

iDynamo MagneSafe V5 Communication Manual

Cmd Num

Data Len

Data

A0

01

Result Code

Data Len

Data

00

Example Read ASIC Control Response (Hex):

40

APPENDIX A. GUIDE ON DECRYPTING DATA

The key that was used to encrypt each data block can be determined by using the Key Serial Number field along with the Base Derivation Key associated with this reader. The resulting DUKPT key, as described in ANS X9.24 Part 1, is the key which was used to encrypt the data. (The key is described as the PIN key in the standard but since there are no PINs being used in this application, the derived key is used.)

These sequences are based on the following data:

• Derivation Key: 0123 4567 89AB CDEF FEDC BA98 7654 3210

• Initially Loaded Key Serial Number (KSN): FFFF 9876 5432 10E0 0000

• Initially Loaded PIN Entry Device Key: 6AC2 92FA A131 5B4D 858A B3A3 D7D5 933A

When a data field consists of more than one block, Cipher Block Chaining (CBC) method is used by the encrypting algorithm.

To decrypt this group of data, follow these steps:

• Start decryption on the last block.

• The result of the decryption is then XORed with the previous block.

• Continue until reaching the first block.

• The first block can skip the XOR operation.

41

iDynamo MagneSafe V5 Communication Manual

42

APPENDIX B. COMMAND EXAMPLE

This Appendix gives an example of command sequences and cryptographic operations. The intent is to clarify any ambiguities the user might find in the body of the document. The example shows a sequence as it actually runs, thus the user can check algorithms against the example to assure they are computing correctly.

Example 1: Swipe decryption, iDynamo MagneSafe V5 Reader:

This example shows the data received in a Card Swipe for a reader at Security Level 3, KSN Count = 8. It will go on to show the steps to decrypt ALL the data received.

Raw Card Swipe Data: Byte Content 0 %B5452000000007189^HOGAN/PAUL ^08040000000000 50 000000000?;5452000000007189=080400000000000000?+51 100 63000050000445=000000000000?|0600|C25C1D1197D31CAA 150 87285D59A892047426D9182EC11353C051ADD6D0F072A6CB34 200 36560B3071FC1FD11D9F7E74886742D9BEE0CFD1EA1064C213 250 BB55278B2F12|724C5DB7D6F901C7F0FEAE7908801093B3DBF 300 E51CCF6D483E789D7D2C007D539499BAADCC8D16CA2|E31234 350 A91059A0FBFE627954EE21868AEE3979540B67FCC40F61CECA 400 54152D1E|A1050000|8628E664C59BBAA232BA90BFB3E6B41D 450 6F4B691E633C311CBE6EE7466B81196EC07B12648DCAC4FD7F 500 D0E212B479C60BAD8C74F82F327667||21685F158B5C6BE0|F 550 FFF9876543210E00008|B78F||0000

According to the iDynamo MagneSafe V5 Communications Reference Manual, the Card Swipe Data is broken down like this:

[P30] [P32] [Tk1 SS] [Tk1 Masked Data] [ES] [P33] [P32] [Tk2 SS] [Tk2 Masked Data] [ES] [P33] [P32] [Tk3 SS] [Tk3 Masked Data] [ES] [P33] [P31] [P35] [Reader Encryption Status] [P35] [Tk1 Encrypted Data (including TK1 SS and ES)] [P35] [Tk2 Encrypted Data (including TK1 SS and ES)] [P35] [Tk3 Encrypted Data (including TK1 SS and ES)] [P35] [MagnePrint Status] [P35] [Encrypted MagnePrint data] [P35] [Device serial number] [P35] [Encrypted Session ID] [P35] [DUKPT serial number/counter] [P35] [Clear Text CRC] [P35] [Encrypted CRC] [P35] [Format Code] [P34]

Each of the Pxx elements has the default value in this configuration, thus we can reinterpret the format as:

%[Tk1 Masked Data]? ;[Tk2 Masked Data]? +[Tk3 Masked Data]? |[Reader Encryption Status] |[Tk1 Encrypted Data (including TK1 SS and ES)] |[Tk2 Encrypted Data (including TK1 SS and ES)] |[Tk3 Encrypted Data (including TK1 SS and ES)]

43

iDynamo MagneSafe V5 Communication Manual

Using this information, we can put the respective data from the Raw Data into the structure:

%B5452000000007189^HOGAN/PAUL ^08040000000000000000000? ;5452000000007189=080400000000000000? +5163000050000445=000000000000? |0600 |C25C1D1197D31CAA87285D59A892047426D9182EC11353C051ADD6D0F072A6CB3436560B3071FC1FD11D9F7 E74886742D9BEE0CFD1EA1064C213BB55278B2F12 |724C5DB7D6F901C7F0FEAE7908801093B3DBFE51CCF6D483E789D7D2C007D539499BAADCC8D16CA2 |E31234A91059A0FBFE627954EE21868AEE3979540B67FCC40F61CECA54152D1E |A1050000 |8628E664C59BBAA232BA90BFB3E6B41D6F4B691E633C311CBE6EE7466B81196EC07B12648DCAC4FD7FD0E21 2B479C60BAD8C74F82F327667 | |21685F158B5C6BE0 |FFFF9876543210E00008 |B78F | |0000

Note: The Device Serial Number field is empty because the DSN has not been set.

Note: The Encrypted CRC field is empty because the default configuration is to send it empty.

Note: at Security Level 3 the following fields are represented as ASCII characters: Masked Track data Format Code

Note that all other fields are represented as Hexadecimal data, that is, two ASCII characters together give the value of a single byte.

The data is coherent structurally; let's work on decryption.

First, we note that the KSN = FFFF9876543210E00008 and the counter = 8. For the standard ANSI key example, counter 8 gets us the following Encryption Key: 27F66D5244FF621E AA6F6120EDEB427F

There are five encrypted fields:

1. Track 1 encrypted data

2. Track 2 encrypted data

3. Track 3 encrypted data

4. Encrypted MagnePrint data

5. Encrypted Session ID

We will show the decryption of each of these fields in detail. For convenience, each will be grouped as blocks of eight bytes.

Track 1 encrypted data Block # 1 C25C1D1197D31CAA

44

Appendix B – Command Examples

2 87285D59A8920474 3 26D9182EC11353C0 4 51ADD6D0F072A6CB 5 3436560B3071FC1F 6 D11D9F7E74886742 7 D9BEE0CFD1EA1064 8 C213BB55278B2F12

Appendix A tells us to decrypt the last block: C213BB55278B2F12 TDES Dec with 27F66D5244FF621E AA6F6120EDEB427F gets E98ED0F0D1EA1064 XOR D9BEE0CFD1EA1064 gets 3030303F00000000 (decrypted last block)

Continue on in reverse block order: D9BEE0CFD1EA1064 TDES Dec with 27F66D5244FF621E AA6F6120EDEB427F gets E12DA84C41B85772 XOR D11D9F7E74886742 gets 3030373235303030 (decrypted block 7)

Continue on in reverse block order: D11D9F7E74886742 TDES Dec with 27F66D5244FF621E AA6F6120EDEB427F gets 0704673B0041CC2F XOR 3436560B3071FC1F gets 3332313030303030 (decrypted block 6)

Continue on in reverse block order: 3436560B3071FC1F TDES Dec with 27F66D5244FF621E AA6F6120EDEB427F gets 718DF68EC04A96FF XOR 51ADD6D0F072A6CB gets 2020205E30383034 (decrypted block 5)

Continue on in reverse block order: 51ADD6D0F072A6CB TDES Dec with 27F66D5244FF621E AA6F6120EDEB427F gets 0989597B8D3373E0 XOR 26D9182EC11353C0 gets 2F5041554C202020 (decrypted block 4)

Continue on in reverse block order: 26D9182EC11353C0 TDES Dec with 27F66D5244FF621E AA6F6120EDEB427F gets BF110311E7D5453A XOR 87285D59A8920474 gets 38395E484F47414E (decrypted block 3)

Continue on in reverse block order: 87285D59A8920474 TDES Dec with 27F66D5244FF621E AA6F6120EDEB427F gets F2692820A5E12B9B XOR C25C1D1197D31CAA gets 3035353132323731 (decrypted block 2)

Continue on in reverse block order: C25C1D1197D31CAA TDES Dec with 27F66D5244FF621E AA6F6120EDEB427F gets 2542353435323330 (decrypted block 1)

Ordering the decrypted blocks 1st to last we get: HEX ASCII 2542353435323330 %B545230 3035353132323731 05512271 38395E484F47414E 89^HOGAN

45

iDynamo MagneSafe V5 Communication Manual

2F5041554C202020 /PAUL 2020205E30383034 ^0804 3332313030303030 32100000 3030373235303030 00725000 3030303F00000000 000?

We can ignore the last four bytes because they are all hex 00 and fall after the End Sentinel.

ASCII string "%B5452300551227189^HOGAN/PAUL ^08043210000000725000000?"

This is an accurate decryption of the track.

Track 2 encrypted data Block # 1 724C5DB7D6F901C7 2 F0FEAE7908801093 3 B3DBFE51CCF6D483 4 E789D7D2C007D539 5 499BAADCC8D16CA2

Appendix A tells us to decrypt the last block: 499BAADCC8D16CA2 TDES Dec with 27F66D5244FF621E AA6F6120EDEB427F gets D0BBE2E2FF07D539 XOR E789D7D2C007D539 gets 373235303F000000 (decrypted last block)

Continue on in reverse block order: E789D7D2C007D539 TDES Dec with 27F66D5244FF621E AA6F6120EDEB427F gets 82EBCE61FCC6E4B3 XOR B3DBFE51CCF6D483 gets 3130303030303030 (decrypted block 4)

Continue on in reverse block order: B3DBFE51CCF6D483 TDES Dec with 27F66D5244FF621E AA6F6120EDEB427F gets C9C39E4138B423A1 XOR F0FEAE7908801093 gets 393D303830343332 (decrypted block 3)

Continue on in reverse block order: F0FEAE7908801093 TDES Dec with 27F66D5244FF621E AA6F6120EDEB427F gets 47796C85E4CE30FF XOR 724C5DB7D6F901C7 gets 3535313232373138 (decrypted block 2)

Continue on in reverse block order: 724C5DB7D6F901C7 TDES Dec with 27F66D5244FF621E AA6F6120EDEB427F gets 3B35343532333030 (decrypted block 1)

Ordering the decrypted blocks 1st to last we get: HEX ASCII 3B35343532333030 ;5452300 3535313232373138 55122718 393D303830343332 9=080432 3130303030303030 10000000 373235303F000000 7250?

We can ignore the last three bytes because they are all hex 00 and fall after the End Sentinel.

46

Appendix B – Command Examples

ASCII string ";5452300551227189=080432100000007250?"

This is an accurate decryption of the track.

Track 3 encrypted data Block # 1 E31234A91059A0FB 2 FE627954EE21868A 3 EE3979540B67FCC4 4 0F61CECA54152D1E

Appendix A tells us to decrypt the last block: 0F61CECA54152D1E TDES Dec with 27F66D5244FF621E AA6F6120EDEB427F gets DE0949643B57C3C4 XOR EE3979540B67FCC4 gets 3030303030303F00 (decrypted last block)

Continue on in reverse block order: EE3979540B67FCC4 TDES Dec with 27F66D5244FF621E AA6F6120EDEB427F gets CB5F4964DE11B6BA XOR FE627954EE21868A gets 353D303030303030 (decrypted block 3)

Continue on in reverse block order: FE627954EE21868A TDES Dec with 27F66D5244FF621E AA6F6120EDEB427F gets D32A0499226994CF XOR E31234A91059A0FB gets 3038303032303434 (decrypted block 2)

Continue on in reverse block order: E31234A91059A0FB TDES Dec with 27F66D5244FF621E AA6F6120EDEB427F gets 2B35313633343939 (decrypted block 1)

Ordering the decrypted blocks 1st to last we get: HEX ASCII 2B35313633343939 +5163499 3038303032303434 08002044 353D303030303030 3=000000 3030303030303F00 000000?

We can ignore the last byte because it is hex 00 and falls after the End Sentinel.

ASCII string "+5163499080020443=000000000000? "

This is an accurate decryption of the track.

MagnePrint data Block # 1 8628E664C59BBAA2 2 32BA90BFB3E6B41D 3 6F4B691E633C311C 4 BE6EE7466B81196E 5 C07B12648DCAC4FD 6 7FD0E212B479C60B 7 AD8C74F82F327667

Appendix A tells us to decrypt the last block: AD8C74F82F327667 TDES Dec with 27F66D5244FF621E AA6F6120EDEB427F gets 09162DCA11E5C60B XOR 7FD0E212B479C60B

47

iDynamo MagneSafe V5 Communication Manual

gets 76C6CFD8A59C0000 (decrypted last block)

Continue on in reverse block order: 7FD0E212B479C60B TDES Dec with 27F66D5244FF621E AA6F6120EDEB427F gets AE81BFA4A2C80006 XOR C07B12648DCAC4FD gets 6EFAADC02F02C4FB (decrypted block 6)

Continue on in reverse block order: C07B12648DCAC4FD TDES Dec with 27F66D5244FF621E AA6F6120EDEB427F gets AAC8D06ACCF27E6D XOR BE6EE7466B81196E gets 14A6372CA7736703 (decrypted block 5)

Continue on in reverse block order: BE6EE7466B81196E TDES Dec with 27F66D5244FF621E AA6F6120EDEB427F gets 01D78CB7D1DAEA95 XOR 6F4B691E633C311C gets 6E9CE5A9B2E6DB89 (decrypted block 4)

Continue on in reverse block order: 6F4B691E633C311C TDES Dec with 27F66D5244FF621E AA6F6120EDEB427F gets 0D2620B051231748 XOR 32BA90BFB3E6B41D gets 3F9CB00FE2C5A355 (decrypted block 3)

Continue on in reverse block order: 32BA90BFB3E6B41D TDES Dec with 27F66D5244FF621E AA6F6120EDEB427F gets 41499B60A6AAD427 XOR 8628E664C59BBAA2 gets C7617D0463316E85 (decrypted block 2)

Continue on in reverse block order: 8628E664C59BBAA2 TDES Dec with 27F66D5244FF621E AA6F6120EDEB427F gets 010002D4B69CD2C0 (decrypted block 1)

Ordering the decrypted blocks 1st to last we get: HEX 010002D4B69CD2C0 C7617D0463316E85 3F9CB00FE2C5A355 6E9CE5A9B2E6DB89 14A6372CA7736703 6EFAADC02F02C4FB 76C6CFD8A59C0000

We can ignore the last two bytes because we know the MagnePrint data is actually 54

bytes long.

010002D4B69CD2C0C7617D0463316E853F9CB00FE2C5A3556E9CE5A9B2E6DB8914A6372C A77367036EFAADC02F02C4FB76C6CFD8A59C0000

This is an accurate decryption of the MagnePrint data.

Encrypted Session ID (application didn't load, all zeroes) 21685F158B5C6BE0

As this is a simple eight byte block, we only need decrypt it with the appropriate key: 21685F158B5C6BE0 TDES Dec with 27F66D5244FF621E AA6F6120EDEB427F

48

Appendix B – Command Examples

gets 0000000000000000

This is an accurate decryption of the Encrypted Session ID, which was not loaded by the application and thus was all zeroes.

49

iDynamo MagneSafe V5 Communication Manual

50

APPENDIX C. IDENTIFYING ISO/ABA AND AAM VA CARDS

ISO/ABA FINANC IAL CARD S

1. If a low-level decoding algorithm finds data for available tracks to be in the ISO format

particular to each track, the card is classified as ISO. In order to be considered for ISO Financial masking, the card must first be classed as ISO.

2. In order for any track on a card to be considered for ISO/ABA masking, the card must be

classified as ISO by the low-level decoding algorithm.

3. ISO/ABA masking is considered for each track independently. One track may qualify for

masking and another track may not.

4. Track 1 a. The goal is to send the Format Code in the clear, the PAN partially masked, the

Name and Expiration Date in the clear, and the rest of the track masked.

b. If Format Code, PAN, Name, or Expiration Date are not correctly structured, the

rest of the track (from the point of discrepancy) will be sent in the clear.

c. If the Format Code, PAN, Name, or Expiration Date contain the ‘?’ character

(End Sentinel), the field is not correctly structured.

d. A correctly structured Format Code is the first character on the card and contains

the character ‘B’.

e. A correctly structured PAN has a maximum of 19 digits terminated by the

character ‘^’ (Field Separator).

f. A correctly structured Name has a maximum of 26 characters terminated by the

character ‘^’ (Field Separator).

g. A correctly structured Expiration Date has 4 characters.

5. Tracks 2 & 3 a. The goal is to send the PAN partially masked, the Expiration Date in the clear,

and the rest of the track masked.

b. If the PAN or the Expiration Date is incorrectly structured, the rest of the track

(from the point of discrepancy) will be sent in the clear.

c. If the PAN or the Expiration Date contains the ‘?’ character (End Sentinel), the

field is not correctly structured.

d. A correctly structured PAN has a maximum of 19 digits and is terminated by the

character ‘=’ (Field Sepa rat or).

e. A correctly structured Expiration Date has 4 characters.

51

iDynamo MagneSafe V5 Communication Manual

AAMVA DRIVER LICENSES

1. If the card reader reads three tracks of data and Track 1 is formatted per ISO Track 1

rules, Track 2 is formatted per ISO Track 2 rules, and Track 3 is formatted per ISO Track 1 rules, the card is considered to be an AAMVA card. Some MagTek readers do not support the reading of Track 3, so this rule will not apply to such readers.

2. If a low-level decoding algorithm finds data for the available tracks to be in the ISO

format particular to each track, and Track 2 contains a correctly structured PAN field whose first 6 digits is “604425” or contains values in the range “636000” to “636062” inclusive, then the card is considered to be an AAMVA card.

3. AAMVA card masking, when enabled, works as follows: a. Tracks 1 & 3 are sent entirely masked (i.e., zeros are supplied in all character

positions).

b. Track 2:

• The goal is to send the Driver License ID (DLID) partially masked, the

Expiration Date in the clear, the Birth Date in the clear, and the rest of the track masked.

• If the DLID, Expiration Date, or Birth Date are not correctly structured, the

rest of the track (from the point of discrepancy) will be sent in the clear.

• If the DLID, Expiration Date, or Birth Date contains the ‘?’ character (End

Sentinel), the field is not correctly structured.

• A correctly structured DLID has a maximum of 19 digits and is terminated by

the character ‘=’ (Field Separator).

• A correctly structured Expiration Date has 4 characters.

• A correctly structured Birth Date has 8 characters.

52

MagTek iDynamo MagneSafe V5 User Manual

Specifications and Main Features

Frequently Asked Questions

User Manual

TABLE OF CONTENTS

SECTION 1. SECURITY

SECURITY LEVEL 3

COMMANDS AND SECURITY LEVELS

SECTION 2. COMMUNICATIONS

CARD DATA

Masked Track Data

Track 1 Masked Data

Track 2 Masked Data

Track 3 Masked Data

Reader Encryption Status

Encrypted Track Data

Track 1 Encrypted Data

Track 2 Encrypted Data

Track 3 Encrypted Data

MagnePrint Status

Encrypted MagnePrint Data

Device Serial Number

Encrypted Session ID

DUKPT Key Serial Number

Encryption Counter

Clear Text CRC

Encrypted CRC

Format Code

PROGRAMMABLE CONFIGURATION OPTIONS

COMMANDS

Privileged Commands

Command Number

Data Length

Data

Result Code

GET AND SET PROPERTY COMMANDS

Result Codes

Property ID

Property Default Values

PROPERTIES

Software ID Property

Device Serial Number property

MagneSafe Version Number Property

Track ID Enable Property

ISO Track Mask Property

AAMVA Track Mask Property

Interface Type Property

Track Data Send Flags Property

MP Flags Property

CRC Flag Property

Decode Enable Property

SS JIS TYPE 2 Property

ES JIS TYPE 2 Property

Pre Card String Property

Post Card String Property

Pre-Track String Property

Post Track String Property

Termination String Property

FS Property

SS Track 1 ISO AB A Property

SS Track 2 ISO AB A Property

SS Track 3 ISO AB A Property

SS Track 3 AAMVA Property

SS Track 2 7bits Property

SS Track 3 7bits Property

ES Property

Format Code Property

ES Track 1 Property

ES Track 2 Property

ES Track 3 Property

Send Encryption Counter Property

Mask Other Cards Property

Send Clear AAMVA Card Data Property

Bundle Seed ID String Property

SDK Protocol Token String Property

Card Data Encryption Variant Property

COMMAND LIST

Reset Device Command

DUKPT Operation

Get DUKPT KSN and Counter Command
