PV-7451M
Owner’s
Manual
Photo Tripod
Thank you for choosing Magnus.
The Magnus PV-7451M Tripod employs an adjustable
center column that converts to a four-section
monopod for enhanced flexibility. Telescoping legs
with flip-locks offer fast and easy adjustments, with
enclosed spiked feet for all-terrain shooting. The three-
way pan and tilt head offers total control over camera
positioning, and the quick-release plate is equipped
with a 1/4”-20 male thread for universal camera
mounting.
Please read and follow these instructions and keep this
manual in a safe place.
Overview
Video register pin1/4-20 mounting screw
Quick-release lever
Quick-release
mounting plate
Platform orientation
locking knob
Pan handle
Pan handle
twist-lock
Pan locking
knob
Center column/
monopod
Monopod leg
sections
Friction control knob
Panning marks
Bubble levels (×2)
Center-column
locking knob
Mid-level spreader
Leg flip-locks (×6)
Spreader lock
Image is for illustration purposes only.
Features varies by model
Enclosed
spiked feet (×3)
Opening the Tripod
1
Loosen the pan handle
and position it at an
approximate 90° angle
to the center column.
2
Pull out each flip-lock,
extend the legs to the
desired height, and
relock each leg.
Note: Always
extend the legs from the top flip-locks first.
3
Rotate the spreader
lock counterclockwise to
release the center brace.
Gently pull the legs out
to the open position and
rotate the spreader lock clockwise until secure.
Using the Enclosed Spiked Feet
When setting up on soft ground, the spiked feet can
provide more stability.
To expose the spikes,
rotate the tripod feet
clockwise. To enclose the
spikes, rotate the tripod
feet counterclockwise.
Mounting Your Camera
1
Pull and hold the quick-release plate locking lever
to release the plate. Lift
the plate up and out.
2
Align the quick-release
plate lengthwise with the
bottom of your camera.
If you’re using a video
camera, make sure the
video register pin is
aligned with your video
camera’s pin socket.
3
Insert the plate’s
mounting screw into
your camera’s tripod
socket and fasten
the screw using the
screwhead handle until fully tightened.
Note: Make sure the screwhead handle is
flat against the bottom of the quick-release
plate before placing it back on the tripod.
4
Pull and hold on to
the quick-release
plate locking lever and
insert the camera/
quick-release assembly
into the tripod head.
Using the Pan and Tilt Head
Tip: Use the bubble levels to make sure
your shot is parallel to the horizon.
Tilting
To use the tilt feature,
rotate the pan handle
counterclockwise. Tilt
the tripod head to
the desired angle, and rotate the pan handle
clockwise to secure the new position.
Panning
To pan, rotate the
pan locking knob
counterclockwise. When
panning, the tripod
head will rotate, but the
panning marks will remain stationary. To secure the
position, rotate the pan locking knob clockwise.
Horizontal/Vertical
Orientation
To change the camera
orientation from
horizontal to vertical,
rotate the platform
locking knob counterclockwise to loosen. Adjust
the platform as desired, and rotate the platform
locking knob clockwise to secure the new position.
Extending the Pan Handle
To adjust the length of the
telescoping pan handle,
rotate the pan handle
twist-lock clockwise.
Adjust the pan handle
to the desired length,
and rotate the twist-lock
counterclockwise to secure the new position.
Friction Control
Friction control
regulates the stiffness
of the tilt feature. For
less friction, rotate
the knob counterclockwise. For more
friction, rotate the knob clockwise.
Adjusting the Center-Column Height
1
Rotate the center-
column locking knob
counterclockwise
to loosen.
2
Adjust the center
column to the desired
height, and rotate the
center-column locking
knob clockwise to secure
the new position.
Note: To ensure the stability of the center column, do
not extend it beyond the marker labeled “STOP HERE.”
Using the Monopod
When the center column is removed from the
tripod legs, it functions as a four-section monopod.
1
Rotate the center-
column locking knob
counterclockwise to
loosen, and then pull the
center column all the
way out of the tripod.
2
Looking down at the
monopod, rotate the
monopod sections
clockwise to loosen,
extend fully, and rotate
counterclockwise
to secure.
Note: Always extend the monopod
from the top section first.
Precautions
• Safe operation of this product is the user’s
responsibility.
• Keep this product away from children.
• The camera should be securely fastened to the quickrelease mounting plate before mounting onto the
tripod.
• Never mount a camera to the tripod until all tripod
legs are locked and stabilized.
• Make sure that this product is intact and that there
are no missing parts.
• To avoid damage to this product, be careful not to
overtighten or improperly thread any of the threaded
fittings.
• Do not exceed the maximum load capacity.
• Do not set up, pull down, move a tripod, or adjust its
legs while a camera is mounted.
• Never leave a camera unattended on the tripod.
• Do not stand or rest on, hang anything from, or
attempt to remove the mid-level spreader.
• Do not lift or move the tripod by the head.
• To avoid trapping fingers, keep hands clear of the
inside of the legs.
• All photos are for illustrative purposes only.
ONE (1) YEAR LIMITED WARRANTY
This Magnus product is warranted to the original purchaser to be free
from defects in materials and workmanship under normal consumer use
for a period of one (1) year from the original purchase date or thirty (30)
days after replacement, whichever occurs later. The warranty provider’s
responsibility with respect to this limited warranty shall be limited solely to
repair or replacement, at the provider’s discretion, of any product that fails
during normal use of this product in its intended manner and in its intended
environment. Inoperability of the product or part(s) shall be determined by the
warranty provider. If the product has been discontinued, the warranty provider
reserves the right to replace it with a model of equivalent quality and function.
This warranty does not cover damage or defect caused by misuse, neglect,
accident, alteration, abuse, improper installation or maintenance. EXCEPT
AS PROVIDED HEREIN, THE WARRANTY PROVIDER MAKES NEITHER ANY
EXPRESS WARRANTIES NOR ANY IMPLIED WARRANTIES, INCLUDING BUT
NOT LIMITED TO ANY IMPLIED WARRANTY OF MERCHANTABILITY OR
FITNESS FOR A PARTICULAR PURPOSE. This warranty provides you with specific
legal rights, and you may also have additional rights that vary from state to state.
To obtain warranty coverage, contact the Magnus Customer Service
Department to obtain a return merchandise authorization (“RMA”) number,
and return the defective product to Magnus along with the RMA number and
proof of purchase. Shipment of the defective product is at the purchaser’s
own risk and expense.
For more information or to arrange service, visit www.magnustripods.com or
call Customer Service at 212-594-2353.
Product warranty provided by the Gradus Group. www.gradusgroup.com»
MAGNUS is a registered trademark of the Gradus Group. © 2015 Gradus
Group LLC. All Rights Reserved.
