- 1 -
Magnum Dynalab MD 209
HYBRID AUDIO RECEIVER
INSTRUCTION MANUAL
- 2 -
TABLE OF CONTENTS
DEAR VALUED CUSTOMER .............................................................................................. 3
UNPACKING YOUR MD 209 HYBRID AUDIO RECEIVER ............................................... 4
SETTING UP THE MD 209 HYBRID AUDIO RECEIVER ................................................... 5
SET UP OF THE INTEGRATED AMPLIFIER SECTION OF THE MD 209 HYBRID AUDIO
RECEIVER ...................................................................................................................................................................... 6
SET UP OF THE TUNER SECTION OF THE MD 209 HYBRID AUDIO RECEIVER ............... 6
CONNECTING ADDITIONAL SOURCES TO THE MD 209 HYBRID AUDIO RECEIVER ......................................................... 7
SET UP THE MD 209 HYRBID AUDIO RECEIVER WITH AN EXTERNAL HOME THEATER PROCESSOR ...................... 8
HOOKING UP A SUBWOOFER TO YOUR SYSTEM ..................................................................................................................... 9
DIGITAL AUDIO CONVERTER (D.A.C) OPTION ............................................................................................................................. 9
RC4 REMOTE CONTROL ................................................................................................. 10
FUNCTIONS OF THE RC4 REMOTE .............................................................................................................................................. 10
IMAGE OF RC4 REMOTE ................................................................................................................................................................. 11
CONTROL FUNCTIONS .................................................................................................... 12
DISPLAY FUNCTIONS ...................................................................................................... 12
DIAGRAM OF MD 209 .................................................................................................... 13
TROUBLE SHOOTING ....................................................................................................... 14
RECEPTION TECHNIQUES ............................................................................................... 15
FM RECEPTION AIDS AND ACCESSORIES ..................................................................... 16
SPECIFICATIONS .............................................................................................................. 17
SAFETY SHEET ................................................................................................................. 19
LIMITED WARRANTY ...................................................................................................... 20
- 3 -
Dear Valued Customer
Thank you for choosing the Magnum Dynalab
care has been given to the design, manufacturing and selection of components for
the
MD 209
listening enjoyment for many years.
The FM Section is a special design completely researched and manufacturer in
house. In fact, we are the only company in the world that does their own R.F. front
end, choosing this practice due to the fact that no other manufacturer can produce
one that meets our very rigid performance specifications. These rigid specifications
insure that you can enjoy excellent FM reception regardless of signal conditions.
The Integrated Amplifier section of the
characterized by the simplicity of the circuit. We use only high grade components,
ensuring that accuracy and realism of the music is the end result. The power supply
with its specially designed transformer is at the heart of the stability and dynamics
that the
When using these high grade components, a considerable length of time is required
for the
quality break-in disc or white noise from a FM tuner will help ensure optimum
performance as quickly as possible.
Once again, thank you for including a MAGNUM DYNALAB product in your
entertainment system. We are sure that you will have years of listening pleasure
from your
at www.magnumdynalab.com, and if there is anything else we can do, please call us
on our toll free number, 1-800-551-4130, or contact us via email:
info@magnumdynalab.com
Respectfully yours,
Larry Zurowski
President
MD 209
Hybrid Audio Receiver. This complete process insures optimum
MD 209
MD 209
MD 209
Hybrid Audio Receiver exhibits.
Hybrid Audio Receiver to reach its full potential. Using either a high
Hybrid Audio Receiver. Please be sure to register your product
.
MD 209
Hybrid Audio Receiver is
Hybrid Audio Receiver. Great
- 4 -
UNPACKING YOUR MD 209 HYBRID AUDIO RECEIVER
Carefully inspect all sides of the shipping carton for damage. If there are marks or
holes in the carton make note of the location in relation to the unit inside. Any
obvious dents or scuff marks should alert you to the possibility of damage. Carefully
remove the MD 209 Hybrid Audio Receiver from the end caps and wrapping,
inspect all sides. Pay special attention to the corresponding areas on the unit where
damage was found to the shipping carton. If damage is evident, document the type
and extent of the damage, then repack the unit and call the dealer.
KINDLY DO NOT SEND THE UNIT BACK TO THE SHIPPER UNTIL YOU HAVE BEEN
ASKED TO DO SO.
DO NOT DISCARD THE PACKING MATERIALS AND CARTONS. Should there be a
necessity to return the unit for any reason, it must arrive safely and suitably
packaged in order for our receiver to accept it from the carrier. Also, if the unit has
incurred damage as a result of improper packaging, it is not likely that a claim for
the damage against the carrier will be successful.
Likewise, we will ship your unit back to you only in factory-approved packaging.
However, if the unit were to arrive at the factory on anything other than factory
approved packaging, we reserve the right to return the unit in factory-approved
packaging and charge the cost of the packaging to the shipper. This is the only way
we can assure you of a safe return (damage by carrier excepted).
- 5 -
SETTING UP THE MD 209 HYBRID AUDIO RECEIVER
1. Position the receiver away from any spot which may have extremes in
temperatures.
2. Place the receiver on a very rigid surface capable of holding 50 pounds (22 KG).
3. The heat sinks located inside the unit are used to keep the unit at a safe
operating temperature. It is important that they are not covered and that the unit
is not installed in a closed area where there is little air circulation. Ensure at
least 2” of clearance on the left and right of the device, and 5” of clearance
above the unit to allow for proper ventilation.
4. Allow the unit to sit for 2 hours at room temperature before connecting the
power.
5. Connect your FM antenna cable to the ANTENNA IN terminal on the rear panel
of the MD 209 Hybrid Audio Receiver. The connector on the rear of the unit is
an “F” type (75 ohms) connector. Should your antenna cable be the 300 ohm
twin lead you may convert to 75 ohm using a 300 to 75 ohm
balum/transformer. Make sure that the center connector of the 75 ohm cable
is properly inserted into the connector. If you do not have an antenna now,
prepare the temporary straight wire antenna that is enclosed with the receiver.
Connect one end into the center of the antenna input connector on the rear of
the receiver.
Please note that the piece of wire provided should only be used as a device to
test the receiver. To obtain optimum benefit from this fine tuner a better
antenna may be required. Magnum Dynalab offers a number of different
antennas. The antennas are discussed in the
of the manual. If you have any questions please call your dealer or Magnum
Dynalab.
6. Unwrap the EIA AC cord and plug the EIA end into the rear socket marked
Input
. Plug the other end of the AC cord into a 120/220/230/240 volt
continuous AC power supply. Be sure that the voltage marked on the rear of the
unit is the same as the AC source that you are using.
Note: Many countries that use 220/230/240 have a special FM transmitter,
deemphasis for these countries may be different. Please consult Magnum
Dynalab for the correct one.
Reception Techniques
in the back
Power
- 6 -
SET UP OF THE INTEGRATED AMPLIFIER SECTION OF THE MD 209
HYBRID AUDIO RECEIVER
(All numbers correspond to the product diagram on Page 13)
CAUTION
As standard practice, you should always unplug the main power to the MD 209
Hybrid Audio Receiver whenever any source component, interconnect or
loudspeaker is being installed in your system.
Now that you have positioned the MD 209 Hybrid Audio Receiver correctly and
plugged it into the appropriate AC power supply, you are ready to hook it up to the
speakers.
1. Hook up your speakers to the receiver insuring that the positive (+) terminal on
the speaker is hooked up to the positive (+) output terminal on the receiver,
likewise that the negative (-) is correctly hooked up. Be sure that all the
connections are tightly affixed.
2. Turn the power switch on the front panel (1 on diagram) to the ON position. The
LED above the power switch will turn on, and center display will light up indicating
the selected source (i.e. Tuner, CD etc.).
SET UP OF THE TUNER SECTION OF THE MD 209 HYBRID AUDIO
RECEIVER
1. Set input (2 on diagram) to Tuner. The input display will show “TU”, the meters
will light up.
2. Press the
3. Press the bandwidth button “
illuminate.
4. Press the
operation of the tuner, the mute switch should be on.
5. Press the
6. Turn the
using the center tune meter (12 on diagram) and the signal strength meter (11
on diagram) as indicators. Check that the
properly tuned to a strong frequency (as indicated by the signal strength meter).
stereo/mono
mute
button (3 on diagram), and LED will illuminate. For normal
button (4 on diagram) to S
Signal Meter button
Tuning Knob
(8 on diagram) until sound is heard, fine tune the station
tere
o.
BW 1”
(7 on diagram), and LED will illuminate.
button (5 on diagram), and LED will
Stereo
button’s LED is on when
- 7 -
Press the
should go out.
7. If you hear a crackling sound push the
switch the signal strength meter to indicate if the noise is a result of multi-path
(a difference in timing between the RF signal received by the tuner’s antenna and
the tuner itself). If the meter showcases even a moderate level of multi-path,
adjust the orientation of your antenna until the multi-path signal reads zero. If the
needle on the tuner continually reads more than zero, move the antenna to a
different location or rotate the antenna. If this does not correct the problem, a
better or different antenna may be required. Please see
the back of the manual.
8. You are now ready to listen and search for your favorite stations across the
frequency. If you encounter difficult reception situations, please read the
Reception Techniques
Approximately 48 hours of “burn in” should eliminate any measure of drifting that
you may encounter with the tuner section of the MD 209 Hybrid Audio Receiver.
Please note that when your receiver is turned off for more than a couple of hours,
upon powering “ON”, you may encounter a slight amount of drift on the station you
were last tuned to (the center tune meter is not perfectly aligned). Please do not
touch the dial; when the receiver warms back up, it will return to where it was last
center tuned.
Stereo
button again and this will switch to
Multi-path
section at the back of the manual.
button (7 on diagram). This will
Mono
– the stereo light
Reception Techniques
at
CONNECTING ADDITIONAL SOURCES TO THE MD 209 HYBRID AUDIO
RECEIVER
1. Using your RCA cables, or balanced XLR cables, plug the source into one of the
inputs marked in the back of the receiver.
2. Set the input on the receiver to match the input on the rear of the unit that the
source is plugged into.
3. With volume set to zero, power up the new source, initialize the playback, and
slowly adjust volume to desired level.
- 8 -
SET UP THE MD 209 HYRBID AUDIO RECEIVER WITH AN EXTERNAL
HOME THEATER PROCESSOR
The MD 209 Hybrid Audio Receiver is equipped with a unity gain input (A3/SSP
mode Input on the Pre-Amplifier section). This is a switchable input, meaning the
input can be used as a normal pre-amplifier input or in unity gain mode.
To Connect to a Home Theater Processor
1. Turn off all the power to the receiver. Unplug the power cord to the MD 209
Hybrid Audio Receiver.
2. Connect your theater processor Main Left and Right interconnects into the MD
209 Hybrid Audio Receiver through the A3 input.
3. Connect your Main Left and Right speakers to the MD 209 Hybrid Audio
Receiver speaker connections.
4. Re-connect the power to the MD 209 Hybrid Audio Receiver. Push the power
button to the “ON” position.
5. Switch the input to A3. On the remote, select “input” and “00”. You will see the
display switch to P1 and then the volume display will go dark, indicating there is
no volume being provided by the MD 209.
6. Input P1 is now the dedicated input for you to listen and control volume with your
home theater processor (meaning that when you listen to regular music you use
the preamplifier found in the MD 209 Hybrid Audio Receiver). Once input P1 has
been activated into
controlled via your external processor preamp.
Home Theater
mode, volume on input P1 will now be
- 9 -
HOOKING UP A SUBWOOFER TO YOUR SYSTEM
1. Unplug the power to the MD 209 Hybrid Audio Receiver.
2. Using RCA cables, connect one end to the
the Receiver, the other corresponding end to your subwoofer.
3. Turn the subwoofer “ON”.
4. Re-connect the power to the MD 209 Hybrid Audio Receiver and adjust the
volume level to suit you.
Please note the volume of the subwoofer is controlled by the volume control on the
receiver.
Pre Out
output marked on the rear of
DIGITAL AUDIO CONVERTER (D.A.C) OPTION
If you chose the Digital Audio Converter (D.A.C.) option, additional inputs have been
installed in the back of the MD 209 Hybrid Audio Receiver with corresponding “D1”,
“D2” & “USB” displays on the front of the unit. The D.A.C. is outfitted with two (2)
coaxial inputs, and one (1) USB input.
1. Connect an external source to the USB or either coaxial inputs.
2. Adjust the input on the MD 209 Hybrid Audio Receiver by using the input button
on the front of the unit or by using the RC4 remote as outlined on page 10.
- 10 -
RC4 REMOTE CONTROL
Unpacking the Remote:
• Remove the remote from its plastic bag, and install the 2 “AA” batteries provided
• Test the remote to make sure that all functions are operating correctly.
FUNCTIONS OF THE RC4 REMOTE
1. POWER MAIN: Power ON & OFF
2. TUNER REMOTE ON/OFF: This will power up the IR remote stage of the analog
tuner section. If this is ON, the tuner can only be adjusted using the remote, and
not manually. Similarly, if this feature is OFF, the tuner can only be adjusted
manually (using the tuning dial on the faceplate), and not with the remote.
3. TUNE UP/TUNE DOWN: Changes the FM frequency when using the FM tuner as
a source. Hold either the “TUNE UP” or “TUNE DOWN” button until you reach the
desired station. The longer you hold the button the faster the frequency changes.
To FINE TUNE, press either button shortly until your center tune meter is
centered.
4. PRESETS: Your precision remote gives you the ability to store up to 20 preset
stations. To program a preset station, first tune to the desired station and then
push “STORE”. Then select the preset memory position you want to store this
station in by selecting two digits. For Presets 1-9 you must select 01-09 and for
10+ directly enter the number. To recall these presets you must push “PRESET”
and then enter the two-digit preset you wish to recall.
5. VOLUME UP/VOLUME DOWN: Increase or reduces the volume level of the
preamplifier section of the MD 209 Hybrid Audio Receiver.
6. INPUT: Adjusts the selected source received by the preamplifier section of the
receiver (i.e. Tuner, CD, Aux 1). Push “Input” and then the corresponding
number key for the input you want. The TUNER input is input “9”, while the USB
input is input “8”. Note: There is a 10 second delay when switching inputs.
7. AUDIO MUTE: Mutes the amplifier section of the receiver.
- 11 -
IMAGE OF RC4 REMOTE
- 12 -
CONTROL FUNCTIONS
(Numbers correspond with product diagram on page 13)
1. POWER – Switches the power (AC) on and off to the receiver.
2. INPUT SELECTOR – Changes the input source sequentially.
3. MUTE – When on, inter-station noises are muted while tuning the tuner.
4. STEREO – Switches the tuner from Mono to Stereo.
5. BW1 BANDWIDTH SETTING – When BW 1 is selected the tuner is in the “Wide”
IF Bandwidth setting. This setting produces the best sound where adjacent
channel interference is not a factor.
6. BW2 BANDWIDTH SETTING – When BW 2 is selected the tuner is in the
“Narrow Bandwidth” setting. This setting produces the best results where
adjacent channel interference is a factor.
7. SIGNAL STRENGTH/MULTIPATH METER – When the LED above the button is lit,
meter #11 will read the signal strength of the incoming signal, the higher the
better. The signal meter is calibrated so that it will never reach 10, this is done
to protect the meter mechanism. When the switch is set up to multi-path, meter
#11 will indicate the presence of multi-path. The unit should be tuned so that this
meter reads zero.
8. TUNING KNOB - Rotating this knob allows you to precisely tune to the frequency
of your choice. Slight detuning of the tuner may help eliminate multi-path or some
unusual atmospheric conditions that are affecting the sound of the tuner.
9. VOLUME CONTROL – The digitally controlled precision volume control allows you
to vary the volume from 0-99. Normal operating range is 40-85. Note that it is
not a linear volume control – therefore volume changes will vary more as you turn
the control at higher levels than at lower levels. The volume control has been
calibrated so that the volume level can not exceed the safe operating parameters
of the system
DISPLAY FUNCTIONS
10. FREQUENCY/VOLUME DISPLAY – Shows the tuned frequency from 87.5 MHz
thru to 108.5 MHz. This readout is controlled by the tuning control. Volume
control is between 0 – 99 controlled by the volume knob.
- 13 -
11. SIGNAL STRENGTH/MULTI-PATH DISPLAY – The readout of this meter is
controlled by button 7, showcasing either incoming RF Signal Strength or the
presence of Multi-path.
12. CENTER TUNE METER – Indicates the setting of the tuners front end, in normal
situations the tuner should be tuned so that the needle is in the center.
DIAGRAM OF MD 209
- 14 -
PROBLEM POSSIBLE CAUSE
No sound, meter
lights are not on
No sound, meter
lights on
Signal strength is
low
Reception is poor Antenna not connected
Intermittent sound Mute switch is “ON”
Power cord disconnected
Power off at source
Fuse blown
Interconnect not properly
installed
Preamp set to wrong
source
Power amp off
Antenna not connected
Wrong type of antenna
Station too far away
Antenna pointed the
wrong way
Wrong type of antenna
Cross talk from
neighboring stations
Multi-path is occurring
TROUBLE SHOOTING
POSSIBLE SOLUTION
Connect power cord
Check AC source
Check rear fuse panel
Check installation of
interconnects
Turn preamp to tuner
Turn on amp
Check antenna hookup
See page 15
Change your antenna
Rotate the antenna to
point at the station
Check antenna hookup
See page 15
Switch to BW 2 (switch
# 6)
Rotate your antenna,
read Reception
Techniques
Turn mute switch “OFF”
- 15 -
RECEPTION TECHNIQUES
Antenna Cabling:
The lead-in cable from the antenna is often the weakest link in the FM system. Some
time spent on selection and matching will yield dramatic results when it comes to
noise reduction in weak signals.
A good grade of 75 ohm coaxial cable will provide very sufficient signal passage,
along with effective shielding against interference. Without effective shielding your
coaxial cable can in fact become an antenna in itself. There are different grades of
75 ohm cable, there is RG 59/U (Suitable for 50 feet and less) and RG 6. RG 6 is
the better of the two and should be used in runs of 50 feet or more. The RG 6 has
quad shielding and 50 % less losses than RG 59/U.
The key to maximizing the efficiency of the system is insuring that all connections are
clean and tight, silicon grease on outdoor connections will insure good performance
over a long period of time. If you splice either cable, make sure that exactly the
same type of cable is used.
Types of Antennas:
Multi-element Yagi - This is a unidirectional antenna capable of pulling in very distant
stations due to its high gain, the higher the gain the better. These types of antennas
are very directional and should be used with a rotor to get the maximum benefit of
the antenna. The directional feature helps eliminate multi-path problems by allowing
only the signal from the direction that the antenna is facing to be picked up by the
antenna and not the signals that come from a different direction.
Magnum Dynalab offers two Yagi antennae, the MD 6 FM or MD 10 FM
Vertical ½ Wave - This design offers ease of installation and operation. This type of
antenna is omni-directional, which means that it picks up stations coming from all
directions. No rotor is required to pull in stations from behind or the side. This
design also gathers more of the FM signal from the air, offering superior fidelity over
that of a standard bi-directional antenna. It also gives 2.5 dB gain to the signal
strength over that of a standard dipole.
If multi-path is a reception problem try laying the antenna down in the horizontal
plane rather than the vertical plane. This type of antenna can be used indoors or
outdoors, but regardless of whether it is installed indoors or outdoors the higher
that you can put it the better it will perform.
Magnum Dynalab offers the MD ST-2, an excellent vertical ½ wave antenna
Folded Di-Pole - This is the most common and simplest of all antennas, most people
are familiar with the 79 cent piece of wire you received with most electronics gear
- 16 -
(generally provided with a tuner or receiver). This piece of wire is bi-directional and
the performance of it is affected by the angle that the signal hits the piece of wire.
There are quite a number of di-pole antenna designs; they work well in areas of
strong signal strength, such as local stations.
Magnum Dynalab offers the SR-100 as a good folded di-pole.
There are many styles of antennas but all of them are based on one of these types.
FM RECEPTION AIDS AND ACCESSORIES
We have already alluded to the importance of a good quality antenna which has
been designed and built with the reception of the FM bandwidth exclusively.
Should you encounter a situation in which you require more gain to the FM signal or
situations where you may need less gain AND better selectivity then the Magnum
Dynalab 205 “Signal Sleuth” may be of benefit to you.
The 205 is a FM signal processor/amplifier designed specifically for FM. If you
would like more information on this item or any other magnum dynalab product,
please feel free to contact us at any time. Call us TOLL FREE 1-800-551-4130,
email us at INFO@MAGNUMDYNALAB.COM or visit us at
www.magnumdynalab.com.
Power
Audio Frequency Response (+/-
0.1dB)
Class of Operation
Harmonic Distortion
Gain Control
Signal to Noise Ratio
Total Harmonic Distortion
Gain
Output Devices
Input Sensitivity
Input Impedance
Output Impedance
Inputs
Outputs
Dimensions (W.D.H.)
Weight
Fuse Replacement
Tube Specifications
Warranty
RF Specifications
Usable Sensitivity
50 dB Quieting (mono)
50 dB Quieting (stereo)
Capture Ratio
Image Rejection
Alternate Channel (wide)
Alternate Channel (narrow)
Adjacent Channel (wide)
Adjacent Channel (narrow)
THD (mono)
THD (stereo)
Stereo Separation
AM Suppression
SCA Rejection
IF Rejection
19 KHz & 38 KHz Component
Rejection
- 17 -
SPECIFICATIONS
125 watts in 8 ohms, 250 watts into 4
ohms
2Hz - 100KHz
50 % of gain class A, 50 % of gain class
AB
< 0.05 % (2hz-100KHz)
Burr Brown
> -115dB
<0.1
28 dB
Sanken (bi-polar)
1.2 Volts at full power
10k
2k
5 Analog (2 balanced XLR, 3 single ended
including Surround Sound Processor
input)
1 line level pre-out, 3 digital (2 Coaxial, 1
USB)
19" x 19.5" X 6.5"
51 lbs
120V, 6.3amp slow blow OR 240V, 4
amp slow blow
2 x 6922
2 years
(mono) 0.7 u V 9.0 dBf
2.0 u V 9.9 dBf
2.3 u V 20.0 dBf
1.5 dB
125.0 dB
>46.0 dB
>80.0 dB
3.0 dB
30.0 dB
0.10%
0.10%
50.0 dB
70.0 dB
80.0 dB
80.0 dB
75.0 dB
- 18 -
- 19 -
SAFETY SHEET
IMPORTANT SAFETY INSTRUCTIONS
1. KEEP THESE INSTRUCTIONS
2. HEED ALL WARNINGS
3. FOLLOW ALL INSTRUCTIONS
4. DO NOT USE THIS APPARATUS IN WATER
5. CLEAN ONLY WITH DRY CLOTH
6. DO NOT BLOCK ANY VENTILATION OPENINGS, INSTALL IN ACCORDANCE
WITH THE MANUFACTURER’S INSTRUCTIONS.
7. DO NOT INSTALL NEAR ANY HEAT SOURCES SUCH AS RADIATORS, HEAT
REGISTERS, STOVES, OR OTHER APPARATUS (INCLUDING AMPLIFIERS) THAT
PRODUCE HEAT.
8. DO NOT DEFEAT THE SAFETY PURPOSE OF THE GROUNDING TYPE PLUG.
THE GROUNDING PLUG HAS TWO BLADES AND A THIRD GROUNDING
PRONG. THE THIRD PRONG IS PROVIDED FOR YOUR SAFETY. IF THE
PROVIDED PLUG DOES NOT FIT INTO YOUR OUTLET, CONSULT AN
ELECTRICIAN FOR REPLACEMENT OF THE OBSOLETE OUTLET.
9. PROTECT THE POWER CORD FROM BEING WALKED ON OR PINCHED
PARTICULARLY AT PLUGS, CONVENIENCE RECEPTACLES, AND THE POINT
WHERE THEY EXIT FROM THE APPARATUS.
10. ONLY USE ATTACHMENTS/ACCESSORIES SPECIFIED BY THE
MANUFACTURER.
11. UNPLUG THIS APPARATUS DURING LIGHTNING STORMS OR WHEN
UNUSED FOR LONG PERIODS OF TIME.
12. REFER ALL SERVICING TO QUALIFIED PERSONNEL. SERVICING IS
REQUIRED WHEN THE APPARATUS HAS BEEN DAMAGED IN ANY WAY,
SUCH AS THE POWER SUPPLY CORD OR PLUG IS DAMAGED, LIQUID HAS
BEEN SPILLED OR OBJECTS HAVE FALLEN INTO THE APPARATUS, THE
APPARATUS HAS BEEN EXPOSED TO RAIN OR MOISTURE, DOES NOT
OPERATE NORMALLY, OR HAS BEEN DROPPED.
13. THE EQUIPMENT REQUIRES A GROUNDED POWER OUTLET TO
OPERATE SAFELY.
14. THE POWER SUPPLY CORD IS THE MAIN DISCONNECT AND SHALL BE
READILY OPERABLE.
“WARNING” TO REDUCE THE RISK OF FIRE OR ELECTRIC SHOCK, DO
NOT EXPOSE THIS APPARATUS TO RAIN OR MOISTURE.
- 20 -
Y
LIMITED WARRANTY
Register your product at www.magnumdynalab.com
Magnum Dynalab Ltd. herein referred to as the “manufacturer” guarantees this
product to be free of defect in both material and workmanship and agrees to
remedy any such defect or replace any defective component at no charge for a
period of two years from date of sale to the first end user. This warranty is void if
the product has been found to be subjected to misuse, abuse, lightning strike,
unauthorized service, damaged in transit or has been altered or repaired in such a
way as to detract from its performance, reliability or its safe operation.
Should such defect be discovered and it falls within the terms of this guarantee,
the manufacturer will correct the defect in workmanship and/or replace any
defective component with a new one of same or better capability and value. This
warranty does not apply to the cabinet or appearance items such as the faceplate,
control knobs or meter lenses nor does it cover any expenses in shipping the unit to
the appropriate service depot.
The foregoing is in lieu of any other warranties expressed, implied or statutory
and the manufacturer neither assumes nor authorizes any person to assume for it
any other obligation or liability in the connection with the sale of this product. This
warranty is not transferable except by written authorization from the manufacturer.
In order to qualify under the terms of the above warranty, all items must be
returned to the appropriate factory service depot with all shipping charges prepaid
in lieu of having previously registered the purchase of the unit by completing and
returning the attached Registration Card, the unit must be accompanied by proof of
purchase from an authorized Magnum Dynalab Ltd. dealer.
* All tubes are covered for 12 months.
OUR LOCATION RETURN SHIPPING ADDRESS
Within the USA Magnum Dynalab c/o Trans American
2775 Broadway
Buffalo, NY
14227-1043
1-800-551-4130
Within Canada Magnum Dynalab Ltd.
8 Strathearn Avenue, Unit # 9
Brampton, ON, Canada
L6T 4L9
PHONE: 1-800-551-4130
Other Countries Contact selling dealer
TO PREVENT FIRE SHOCK OR HAZARD, DO NOT EXPOSE THIS APPLIANCE TO RAIN
OR MOISTURE. TO REDUCE THE RISK OF ELECTRIC SHOCK, DO NOT REMOVE
- 21 -
COVER OR FACEPLATE, NO USER SERVICEABLE PARTS INSIDE. REFER SERVICING
TO QUALIFIED SERVICE PERSONNEL.
Loading...
