Magnavox MWC13D6 Owner's Manual
13 inch COLOR TV/DVD
Owner's Manual
Owner's Manual
MWC13D6
FEATURES
• Auto Channel Programming
• Screen Saver
• Auto Power Off
• Parental Lock
• Resume Play
• Closed Caption Decoder
SUPPLIED ACCESSORIES
This unit comes with the following accessories. Please confirm that
all the accessories are included.
P Remote Control
(NF102UD)
*Batteries for remote control not included.
Tw o “AA” batteries required.
INSTRUCCIONES EN ESPAÑOL INCLUDAS
PLEASE READ BEFORE USING THIS EQUIPMENT
P Owner's Manual
(1EMN21370)
IF YOU NEED ADDITIONAL ASSISTANCE FOR SET-UP OR OPERATING
AFTER READING OWNER'S MANUAL,
PLEASE CALL
TOLL FREE 1-800-605-8610 OR VISIT OUR WEB SITE AT
http://www.funai-corp.com
RECAUTIONS
P
WARNING: TO REDUCE THE RISK OF FIRE OR ELECTRIC SHOCK, DO NOT EXPOSE THIS
APPLIANCE TO RAIN OR MOISTURE.
CAUTION
RISK OF ELECTRIC SHOCK
DO NOT OPEN
CAUTION:TO REDUCE THE RISK OF
ELECTRIC SHOCK, DO NOT REMOVE COVER (OR
BACK). NO USER SERVICEABLE PARTS INSIDE.
REFER SERVICING TO QUALIFIED SERVICE
PERSONNEL.
The caution marking is located on the rear of the cabinet.
MPORTANT SAFEGUARDS
I
1. Read instructions - All the safety and operating instructions
should be read before the appliance is operated.
2. Retain Instructions - The safety and operating instructions
should be retained for future reference.
3. Heed Warnings - All warnings on the appliance and in the
operating instructions should be adhered to.
4. Follow Instructions - All operating and use instructions
should be followed.
5.
Cleaning - Unplug the unit from the wall outlet before
cleaning. Do not use liquid cleaners or aerosol cleaners.
Use a damp cloth for cleaning.
EXCEPTION: A product that is meant for uninterrupted service and, that for some specific reason, such as the possibility of the loss of an authorization code for a CATV converter,
is not intended to be unplugged by the user for cleaning or
any other purpose, may exclude the reference to unplugging
the appliance in the cleaning description otherwise required
in item 5.
6. Attachments - Do not use attachments not recommended
by the unit manufacturer as they may cause hazards.
7. Water and Moisture - Do not use this unit near water - for
example, near a bath tub, wash bowl, kitchen sink, or laundry tub, in a wet basement, or near a swimming pool, and
the like.
8. Accessories - Do not place this unit on an
PORTABLE CART WARNING
unstable cart, stand, tripod, bracket, or table.
The unit may fall, causing serious injury to
someone, and serious damage to the appliance. Use only with a cart, stand, tripod,
bracket, or table recommended by the manu-
S3126A
facturer, or sold with the unit. Any mounting of the appliance
should follow the manufacturer’s instructions and should use
a mounting accessory recommended by the manufacturer.
An appliance and cart combination should be moved with
care. Quick stops, excessive force, and uneven surfaces may
cause the appliance and cart combination
to overturn.
Ameubles - Cet appareil ne doit être placé
SYMBOLE D'AVERTISSEMENT POUR
LES COMPOSANTES
APPAREIL ET MEUBLE A ROULETTES
que sur un meuble (avec ou sans roulettes)
recommandé par le fabricant. Si vous l’installez sur un meuble à roulettes, déplacez
les deux ensembles avec précaution. Un
S3126A
arrêt brusque, l’utilisation d’une force excessive et des surfaces irrégulières risquent de déstabiliser l’ensemble et de le
renverser.
9. Ventilation - Slots and openings in the cabinet and the back
or bottom are provided for ventilation and to ensure reliable
operation of the unit and to protect it from overheating, and
10. Power Sources - This unit should be operated only from the
11. Grounding or Polarization - This unit is equipped with a
12. Power-Cord Protection - Power-supply cords should be
13. Outdoor Antenna grounding - If an outside antenna or
THIS SYMBOL INDICATES THAT
DANGEROUS VOLTAGE CONSTITUTING
A RISK OF ELECTRIC SHOCK IS
PRESENT WITHIN THIS UNIT.
THIS SYMBOL INDICATES THAT THERE
ARE IMPORTANT OPERATING AND
MAINTENANCE INSTRUCTIONS IN THE
LITERATURE ACCOMPANYING THE
APPLIANCE.
these openings must not be blocked or covered. The openings should never be blocked by placing the unit on a bed,
sofa, rug, or other similar surface.This unit should never be
placed near or over a radiator or heat register. This unit
should not be placed in a built-in installation such as a bookcase or rack unless proper ventilation is provided or the
manufacturer’s instructions have been adhered to.
type of power source indicated on the marking label. If you
are not sure of the type of power supply to your home, consult your appliance dealer or local power company. For the
units intended to operate from battery power, or other
sources, refer to the operating instructions.
polarized alternating-current line plug (a plug having one
blade wider than the other). This plug will fit into the power
outlet only one way. This is a safety feature. If you are
unable to insert the plug fully into the outlet, try reversing
the plug. If the plug should still fail to fit, contact your electrician to replace your obsolete outlet. Do not defeat the
safety purpose of the polarized plug.
routed so that they are not likely to be walked on or pinched
by items placed upon or against them, paying particular
attention to cords at plugs, convenience receptacles, and the
point where they exit from the appliance.
cable system is connected to the unit, be sure the antenna
or cable system is grounded so as to provide some protection against voltage surges and built-up static charges.
Article 810 of the National Electrical Code, ANSI/NFPA No.
70, provides information with respect to proper grounding of
the mast and supporting structure, grounding of the lead-in
wire to an antenna discharge unit, size of grounding conductors, location of antenna-discharge unit, connection to
grounding electrodes, and requirements for the grounding
electrode. (Fig. A)
FIGURE A
EXAMPLE OF ANTENNA GROUNDING AS PER
NATIONAL ELECTRICAL CODE
GROUND
CLAMP
ELECTRIC
SERVICE
EQUIPMENT
NEC - NATIONAL ELECTRICAL CODE POWER SERVICE GROUNDING
S2898A
GROUNDING CONDUCTORS
(NEC SECTION 810-21)
GROUND CLAMPS
ELECTRODE SYSTEM
(NEC ART 250, PART H)
ANTENNA
LEAD IN
WIRE
ANTENNA
DISCHARGE UNIT
(NEC SECTION 810-20)
2
EN
14. Lightning - For added protection for this unit receiver during
a lightning storm, or when it is left unattended and unused
for long periods of time, unplug it from the wall outlet and
disconnect the antenna or cable system. This will prevent
damage to the unit due to lightning and power-line surges.
15. Power Lines - An outside antenna system should not be
located in the vicinity of overhead power lines or other electric light or power circuits, or where it can fall into such power
lines or circuits. When installing an outside antenna system,
extreme care should be taken to keep from touching such
power lines or circuits as contact with them might be fatal.
16. Overloading - Do not overload wall outlets and extension
cords as this can result in a risk of fire or electric shock.
17. Object and Liquid Entry - Never push objects of any kind
into this unit through openings as they may touch dangerous
voltage points or short out parts that could result in a fire or
electric shock. Never spill liquid of any kind on the unit.
18. Servicing - Do not attempt to service this unit yourself as
opening or removing covers may expose you to dangerous
voltage or other hazards. Refer all servicing to qualified service personnel.
19. Damage Requiring Service - Unplug this unit from the wall
outlet and refer servicing to qualified service personnel
under the following conditions:
a. When the power-supply cord or plug is damaged or frayed.
b. If liquid has been spilled, or objects have fallen into the unit.
c. If the unit has been exposed to rain or water.
d. If the unit does not operate normally by following the operat-
ing instructions. Adjust only those controls that are covered
by the operating instructions, as improper adjustment of
other controls may result in damage and will often require
extensive work by a qualified technician to restore the unit to
its normal operation.
e. If the unit has been dropped or damaged in any way.
f. When the unit exhibits a distinct change in performance, this
indicates a need for service.
20. Replacement Parts - When replacement parts are required,
be sure the service technician has used replacement parts
specified by the manufacturer that have the same characteristics as the original part. Unauthorized substitutions may
result in fire, electric shock, injury to persons or other hazards.
21. Safety Check - Upon completion of any service or repairs to
this unit, ask the service technician to perform routine safety
checks to determine that the unit is in proper operating condition.
22. Heat - This unit product should be situated away from heat
sources such as radiators, heat registers, stoves, or other
products (including amplifiers) that produce heat.
IMPORTANT COPYRIGHT INFORMATION
Unauthorized copying, broadcasting, public performance and lending of discs are prohibited.
This product incorporates copyright protection technology that is protected by U.S. patents and other intellectual property rights. Use of this copyright protection technology must be authorized by Macrovision, and is
intended for home and other limited viewing uses only unless otherwise authorized by Macrovision. Reverse
engineering or disassembly is prohibited.
PRECAUTIONS / IMPORTANT SAFEGUARDS
RADIO-TV INTERFERENCE
This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to
Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses, and can radiate radio frequency energy and,
if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the
equipment off and on, the user is encouraged to try to correct the interference by one or more of the following
measures:
1) Reorient or relocate the receiving antenna.
2) Increase the separation between the equipment and receiver.
3) Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.
4) Consult the dealer or an experienced radio/TV technician for help.
This Class B digital apparatus complies with Canadian ICES-003.
Cet appareil numérique de la classe B est conforme à la norme NMB-003 du Canada.
FCC WARNING-
This equipment may generate or use radio frequency energy. Changes or modifications to
this equipment may cause harmful interference unless the modifications are expressly approved in the
owner’s manual. The user could lose the authority to operate this equipment if an unauthorized change or
modification is made.
EN
3
LASER SAFETY
This unit employs a laser. Only a qualified service person should remove the cover or attempt to service
this device, due to possible eye injury.
CAUTION: USE OF CONTROLS OR ADJUSTMENTS OR PERFORMANCE OF PROCEDURES OTHER
THAN THOSE SPECIFIED HEREIN MAY RESULT IN HAZARDOUS RADIATION EXPOSURE.
CAUTION: VISIBLE AND INVISIBLE LASER RADIATION WHEN OPEN AND INTERLOCK DEFEATED.
DO NOT STARE INTO BEAM.
LOCATION: INSIDE, NEAR THE DECK MECHANISM.
CAUTION: TO PREVENT ELECTRIC SHOCK, MATCH WIDE BLADE OF PLUG TO WIDE SLOT, FULLY
INSERT.
ATTENTION: POUR ÉVITER LES CHOC ÉLECTRIQUES, INTRODUIRE LA LAME LA PLUS LARGE DE
LA FICHE DANS LA BORNE CORRESPONDANTE DE LA PRISE ET POUSSER
JUSQU'AU FOND.
Note to CATV system installer:
This reminder is provided to call the CATV system installer's attention to Article 820-40 of the NEC that provides guidelines for proper grounding and in particular, specifies that the cable ground shall be connected to the grounding system
of the building as close to the point of cable entry as practical.
LOCATION
For safe operation and satisfactory performance of the unit, keep the following in mind when selecting a place
for its installation:
• Shield it from direct sunlight and keep it away from sources of intense heat.
• Avoid dusty or humid places.
• Avoid places with insufficient ventilation for proper heat dissipation. Do not block the ventilation holes at the
top and bottom of the unit. Do not place the unit on a carpet because this will block the ventilation holes.
• Install unit in a horizontal position.
• Avoid locations subject to strong vibration.
• Do not place the unit near strong magnetic fields.
• Avoid moving unit to locations where temperature differences are extreme.
• Be sure to remove disc and unplug the AC power cord from the outlet before carrying the unit.
TO AVOID THE HAZARDS OF ELECTRICAL SHOCK AND FIRE
• Do not handle the power cord with wet hands.
• Do not pull on the power cord when disconnecting it from an AC wall outlet. Grasp it by the plug.
• If, by accident, water is spilled on your unit, unplug the power cord immediately and take the unit to our
Authorized Service Center for servicing.
• Do not put your fingers or objects into the unit disc loading tray.
• Do not place anything directly on top of the unit.
MOISTURE WARNING
• Moisture condensation may occur inside the unit when it is moved from a cold place to a warm place, or
after heating a cold room or under conditions of high humidity. If you play a videotape or DVD in a moist
unit, it may damage the tape or DVD and the unit. When the condensation occurs inside the unit, turn the
unit on and leave it at least 2 hours to dry out.
NOTE ABOUT RECYCLING
Batteries should never be thrown away or incinerated but disposed of in accordance with your local regulations concerning chemical wastes.
Manufactured under license from Dolby Laboratories.
"Dolby" and the double-D symbol are trademarks of Dolby Laboratories.
The serial number of this product may be found on the back of the unit. No other unit has the same serial
number as yours.You should record the number and other vital information here and retain this book as a
permanent record of your purchase to aid identification in case of theft. Serial numbers are not kept on file.
Date of Purchase
Dealer Purchase from
Dealer Address
Dealer Phone No.
Model No.
Serial No.
4
EN
ABLE OF CONTENTS
T
PRECAUTIONS . . . . . . . . . . . . . . . . . . . . . . . . . .2
IMPORTANT SAFEGUARDS . . . . . . . . . . . . . . . .2
TABLE OF CONTENTS . . . . . . . . . . . . . . . . . . . .5
SYMBOLS USED IN THIS MANUAL . . . . . . . . . . . .5
PREPARATION FOR USE . . . . . . . . . . . . . . . . . .6
ANTENNA/CABLE CONNECTIONS . . . . . . . . . . . .6
CONNECTING TO AN EXTERNAL DEVICE (FRONT)
INSTALLING THE BATTERIES IN REMOTE CONTROL
OPERATING CONTROLS AND FUNCTIONS . . .8
. .7
.7
TV SECTION
TV OPERATION AND SETTINGS . . . . . . . . . . . .9
INITIAL SET UP . . . . . . . . . . . . . . . . . . . . . . . . . . .9
WATCHING A TV PROGRAM . . . . . . . . . . . . . . . . .9
SLEEP TIMER / PICTURE CONTROL . . . . . . . . . .10
CLOSED CAPTION SYSTEM . . . . . . . . . . . . . . . .10
CHANNEL SET UP . . . . . . . . . . . . . . . . . . . . . . . .11
ON-SCREEN MENU LANGUAGE . . . . . . . . . . . . .11
V-CHIP SET UP . . . . . . . . . . . . . . . . . . . . . . . . . .12
DVD SECTION
ABOUT THE DISCS . . . . . . . . . . . . . . . . . . . . .14
PLAYABLE DISCS . . . . . . . . . . . . . . . . . . . . . . . . .14
UNPLAYABLE DISCS . . . . . . . . . . . . . . . . . . . . . .14
PLAYING A DISC . . . . . . . . . . . . . . . . . . . . . . .15
BASIC PLAYBACK . . . . . . . . . . . . . . . . . . . . . . . .15
DISC MENU / TITLE MENU . . . . . . . . . . . . . . . . . .15
SPECIAL PLAYBACK FUNCTIONS & SETTINGS . . .
FUNCTION TABLE . . . . . . . . . . . . . . . . . . . . . . . .16
AUDIO MENU . . . . . . . . . . . . . . . . . . . . . . . . . . . .17
SUBTITLE LANGUAGE . . . . . . . . . . . . . . . . . . . . .17
ANGLE MENU . . . . . . . . . . . . . . . . . . . . . . . . . . . .17
ZOOM . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .17
BLACK LEVEL MENU . . . . . . . . . . . . . . . . . . . . . .18
SEARCH MENU . . . . . . . . . . . . . . . . . . . . . . . . . .18
REPEAT PLAYBACK . . . . . . . . . . . . . . . . . . . . . . .19
PROGRAMMED PLAYBACK . . . . . . . . . . . . . . . . .20
RANDOM PLAYBACK . . . . . . . . . . . . . . . . . . . . . .20
ON-SCREEN INFORMATION . . . . . . . . . . . . . .20
CHANGING THE DVD SET UP ITEMS . . . . . . .21
CUSTOM MENU . . . . . . . . . . . . . . . . . . . . . . . . . .21
INITIALIZE . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .23
TROUBLESHOOTING GUIDE . . . . . . . . . . . . . .24
MAINTENANCE . . . . . . . . . . . . . . . . . . . . . . . .26
APPENDIX . . . . . . . . . . . . . . . . . . . . . . . . . . . .27
CABLE CHANNEL DESIGNATIONS . . . . . . . . . . .27
LANGUAGE CODE LIST . . . . . . . . . . . . . . . . . . . .27
SPECIFICATIONS . . . . . . . . . . . . . . . . . . . . . . .28
16
ESPAÑOL . . . . . . . . . . . . . . . . . . . . . . .29
WARRANTY . . . . . . . . . . . . . . . . . .BACK COVER
SYMBOLS USED IN THIS MANUAL
The following symbols below appear in some headings and notes in this manual, with the following meanings.
TV
TV
Description refers to TV operation
(in the TV mode).
Description refers to playback of
DVD video discs (in the DVD mode).
QUICK
Description refers to playback of
audio CDs (in the DVD mode).
Description refers to the items
to be set by the QUICK mode
(in the DVD mode).
IMPORTANT SAFEGUARDS / TABLE OF CONTENTS
EN
5
REPARATION FOR USE
ANT.
Cable
TV signal
Antenna
or
ANT.
IN
O
U
T
P
ANTENNA/CABLE CONNECTIONS
Plug the incoming cable into the ANT. jack on the rear of the unit.
If your cable service supplies you with a converter box or if you use a satellite system, connect the box with
this unit as shown below.
Incoming cable from home
Antenna / Cable Company
(No Cable Box)
Rear of the unit
OR
Cable Box or Satellite Box*
Incoming cable from Cable Company
or Satellite Antenna
NOTE:
Before plugging the antenna into
the ANT. jack of the unit, check
that the pin is not bent. If it is bent,
straighten the pin as illustrated,
then plug the pin into the ANT. jack
of the unit.
*NOTE
(DO NOT DISCONNECT FROM BOX)
Some cable TV systems use scrambled
signals and require a special converter to
receive these channels. Consult your local
cable company.
Bent pin
For your safety and to
avoid damages to the unit,
Cable
Plug
(Needs to be
straightened)
(Straight pin)
unplug the antenna cable
from the ANT. jack before
moving the unit.
6
EN
CONNECTING TO AN EXTERNAL DEVICE (FRONT)
21 3
PLAYSTOPCH.
SELECT
STANDBY-ON
VOLUME
VIDEO AUDIO
OPEN/CLOSE
VIDEO
AUDIO
OPEN/CLOSE
ex.
VCR or video camera
, etc.
When you watch a program recorded on another source (VCR or video camera), use the
AUDIO/VIDEO input jacks on the front of the unit.
Connect the Audio/Video output jacks of another source to the AUDIO and VIDEO jacks of
this unit.
Then use [SELECT] or [CH.KK/ LL] until "AUX" appears on the screen.
To the Audio output jack
(OUT)
Audio Cable
(IN)
(commercially available)
(IN)
(OUT)
To the Video output jack
Video Cable
(commercially available)
AUX
[Front of the unit]
PREPARATION FOR USE
INSTALLING THE BATTERIES IN REMOTE CONTROL
1) Open the battery compartment cover by pressing
the cover on the remote unit in the direction of
the arrow.
2) Insert 2 “AA” penlight batteries into the battery
compartment in the direction indicated by the
polarity (+/-) markings.
3) Replace the cover.
[BATTERY PRECAUTIONS]
Be sure to follow the correct polarity as indicat-
•
ed in the battery compartment. Reversed batteries may cause damage to the device.
Do not mix different types of batteries together
•
(e.g. Alkaline and Carbon-Zinc) or old batteries
with fresh ones.
If the device is not to be used for a long period
•
of time, remove the batteries to prevent damage
or injury from possible battery leakage.
Do not try to recharge batteries not intended to
•
be recharged; they can overheat and rupture.
EN
7
PERATING CONTROLS AND FUNCTIONS
PLAYSTOPCH.
SELECT
STANDBY-ON
VOLUME
VIDEO AUDIO
OPEN/CLOSE
12 456 107983
O
- FRONT PANEL -
- REMOTE CONTROL -
[REMOTE CONTROL]
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
11
12
13
14
15
16
17
18
19
20
21
STANDBY-ON
PICTURE/
SELECT
SLEEP
1
2
5
789
DISPLAY
0
NEXT
PREV
REW
SLOW
PAUSE TITLE
CLEAR
MODE
SET-UP MUTE
PLAY
STOP
3
64
+100
+10
ENTER
OPEN/
CLOSE
CH.
VOL.
FWD
DISC MENU
RETURN
22
23
24
25
26
27
28
29
30
31
32
33
30
[FRONT PANEL]
01
y STANDBY-ON Button
02
Disc loading tray
03
VOLUME X/YButtons
04
CHANNEL SELECT KButton
05
STOP C Button
06
PLAY B Button
07
Remote sensor window
08
OPEN/CLOSE A Button
09
VIDEO input Jack
10
AUDIO input Jack
[DVD P.15]
[TV P.9 / DVD P.15]
[P.7]
[P.7]
[TV P.9 / DVD P.15]
[P.9]
[TV P.9]
[DVD P.15]
31
32
33
NOTES:
• We do not recommend the use of universal remote controls as it may not control all the functions. Note that the
code number given by universal remote controls may
not program to this unit. For more details, contact the
manufacturer of the universal remote control.
• Unless stated, all operations described are based on
remote control use. Some operations can be carried
out using the menu bar on the TV screen.
STANDBY-ON y Button
PICTURE/SLEEP Button
Number Buttons
DISPLAY Button
PREV H Buttons
NEXT G Buttons
PLAY B Button
PAUSE F Button
TITLE Button
CLEAR Button
MODE Button
[TV P.9 / DVD P.18]
[DVD P.20]
[DVD P.18]
[DVD P.18]
[TV P.9 / DVD P.15]
[DVD P.15]
[DVD P.15]
[TV P.10 / DVD P.18]
[DVD P.16]
OPEN/CLOSE A Button
SELECT Button
CH.K/ LButtons
VOL.X/YButtons
MUTE Button
SET-UP Button
REW E Button
FWD D Button
STOP C Button
DISC MENU Button
ENTER Button
K /L
/{ / B Buttons
RETURN Button
[TV P.9]
[TV P.9]
[TV P.9]
[TV P.9]
[TV P.10 / DVD P.21]
[DVD P.15]
[DVD P.15]
[DVD P.15]
[DVD P.15]
[TV P.10 / DVD P.15]
[TV P.10 / DVD P.15]
[DVD P.17]
[TV P.9 / DVD P.15]
[TV P.10]
[DVD P.15]
8
EN
TV SECTION
TV
TV
TV
TV
V OPERATION AND SETTINGS
T
INITIAL SET UP
When you turn on the power for the first time,
the INITIAL LANGUAGE screen is displayed.
Select the language for screen display and perform
auto programming of the channels.
1 After antenna or cable connection is
completed, connect the power cord into
a standard AC outlet.
2 Press [STANDBY-ON y] to turn on the unit.
3 Press one of the keys listed
below to select the language
of on-screen menu.
• ENGLISH:
[VOL.Y]
• ESPAÑOL: [VOL.X]
• FRANÇAIS: [CH. K]
4 Confirm the antenna (or cable)
connection and press
• The tuner scans and
memorizes all active
channels in your area.
[PLAY BB].
5 When the scanning is completed,
the tuner stops on the lowest
memorized channel.
NOTES:
•You can exit the INITIAL SETUP menu by pressing
[SET-UP]. If the button is pressed during channel
scanning, the tuner stops scanning and the lowest
memorized channel is displayed.
The INITIAL SETUP menu is displayed every time
•
you turn on the unit unless the scanning is completed.
• In case no channel can be
received by the channel scanning,
"NO TV SIGNALS" is displayed on
the screen. Turn off the unit and
check the antenna connection,
then follow steps 1 to 5 again.
You can change the setting after completing INI-
•
TIAL SETUP by LANGUAGE menu or CHANNEL
SET UP menu. (Refer to "ON-SCREEN MENU LANGUAGE" or "CHANNEL SET UP" on page 11).
SELECT LANGUAGE
ENGLISH
NEXT:PRESS VOLYH
ESPAÑOL
DESPUÉS:PRESIONE VOLXH
FRANÇAIS
APRÈS:PRESSEZ CH.KH
– INITIAL SETUP –
PLEASE CONNECT ANTENNA
OR CABLE OR SATELLITE
TO THIS UNIT.
THEN PRESS PLAY,
IN ORDER TO PERFORM
“AUTO CH PROGRAMMING”
CH 15
(Example)
NO TV SIGNALS
WATCHING A TV PROGRAM
1 Press [STANDBY-ONy] to turn on the unit.
NOTES:
If the TV screen shows snow
noise and there is no operation
for more than 10 seconds,
“HELPFUL HINTS” appears.
• Make sure if the antenna or cable is connected
properly. (Refer to “ANTENNA/CABLE CONNECTIONS on page 6.)
• Set the“AUTO CH PROGRAMMING” in the
CHANNEL SET UP. (Refer to “CHANNEL SET UP”
on page 11.)
• If those setting do not work properly, please
call our help line on the front page of this owner’s
manual.
2 Use [CH.
K/ L
] or the Number buttons to
select your desired channel number.
To use the number buttons
•Single digit channels: (Ex. 02, 03, 04 and so on)
Press [0] first to select a single digit channel.
•Two digit channels: (Ex. 12, 38, 95 ...)
Press two digits directly.
•Tree digit channels: (Ex. 115, 125 ...)
Press
[+100] first, then press the last two digits.
3 Use [VOL.
Press
X/ Y
] to adjust the volume.
[MUTE] to instantly
mute the sound. Press it again
to restore the previous sound
level.
NOTE:
•Even if you turn off the unit in the DVD mode, the unit
will be in the TV mode when you turn it on again.
TO WATCH CABLE OR SATELLITE CHANNEL
If the unit is connected to a cable box or satellite
box, use
[CH. K / L] to select CH3 or CH4 according to the output channel setting of the device and
select desired channel on that device.
TO WATCH EXTERNAL INPUT
When an external equipment is
connected to the front AUDIO/
VIDEO input jacks, press
[SELECT] or [CH. K / L] repeat-
edly until "AUX" appears on the
screen.
- HELPFUL HINTS -
1.PLEASE CHECK TO SEE IF
THE ANTENNA/CABLE/
SATELLITE IS
PROPERLY CONNECTED.
2.DID YOU PERFORM
“AUTO CH PROGRAMMING”?
3.PLEASE REFER TO FRONT
PAGE OF THE OWNER’S
MANUAL OR REAR PANEL
FOR SUPPORT LINE
INFORMATION.
VOLUME 20
C C C C C C C C C C C C C C C C
AUX
TV SECTION
TV OPERATION AND SETTINGS
9
EN
TV SECTION
TV OPERATION AND SETTINGS
SLEEP TIMER / PICTURE CONTROL
You can set Sleep Timer and picture
adjustment with
[PICTURE / SLEEP].
• The menu changes as described below every time
you press
Sleep Timer
[PICTURE / SLEEP].
BRIGHT
TINTSHARPNESS
CONTRAST
COLOR
SLEEP TIMER SETTING
The Sleep Timer function is used to turn off the
unit without pressing
desired time.
1 Press [PICTURE / SLEEP] to
display the Sleep Timer menu.
[STANDBY-ON y] after a
SLEEP 0 MINUTE
C C C C C C C C C C C C
TV
TV
2 Within 10 seconds, set your desired sleep time
using
[s / B].
• [B]...Increase by 10 min. (Up to 120 min.)
[s]...Decrease by 10 min.
•
NOTE:
•To cancel the Sleep Timer, use [CLEAR] or [s / B]
to set the time to "0".
3 To confirm the remainder time to shutdown,
press
[PICTURE / SLEEP].
PICTURE CONTROL
The picture controls are preset to factory defaults,
but you can change them to your desired setting.
1 Press [PICTURE / SLEEP]
repeatedly until desired control
is displayed.
BRIGHT
PP PP PP PP PP PP PP CC PPPP PP PP PP PPPP
–
2 Use [s / B] to adjust to your desired level within
5 seconds.
CLOSED CAPTION SYSTEM
You can view specially labeled (cc) TV programs, movies, news and pre-recorded tapes with
either a dialogue caption or text display.
1 Press [SET-UP].
Use
[KK/ LL] to point to
"CAPTION".
2 Press [ENTER] repeatedly to
select your desired caption
mode.
•
CAPTION mode: You can watch dramas, movies and
news while captioning the dialogues and the contents
of news.
• TEXT mode: You can watch half screen text informa-
tion if you want.
*"CAPTION2" is usually used for a second language (if
available).
Press [SET-UP] to exit the menu.
3
NOTES:
•Even if any power failure, the unit will retain its memory for this feature.
• Some programs are not broadcasted with closed
captions. The unit is designed to provide error-free
closed captions with high quality antenna, cable and
VCR signals. Conversely, poor quality signals are
likely to result in caption errors or no captions at all.
• Common signal conditions which may cause caption
errors are listed below:
- Weak snowy reception on TV screen
- Multiplex signal reception displaying picture
+
ghosts or airplane flutter
• If the unit displays a black box on
the TV screen, this means that
the unit is set to the TEXT mode.
To clear screen, select "CAPTION1", "CAPTION2" or "OFF".
- TV SETUP -
CHANNEL SET UP
V-CHIP SET UP
LANGUAGE [ENGLISH]
B CAPTION [OFF]
- TV SETUP -
CHANNEL SET UP
V-CHIP SET UP
LANGUAGE [ENGLISH]
B CAPTION [CAPTION1]
TV
TV
BRIGHT
CONTRAST
COLOR
TINT
SHARPNESS
to decrease brightness
to decrease contrast
to pale
to purple
to soft
to increase brightness
to increase contrast
to brilliant
to green
to clear
• Even if any power failure occurs, the unit will
retain its memory for this feature.
10
EN
TO CANCEL THE CLOSED CAPTION SYSTEM
1 Press [SET-UP]. Use [
"CAPTION".
KK/ LL
] to point to
2 Press [ENTER] repeatedly to select "OFF".
3 Press [SET-UP] to exit the menu.
TV
TV
CHANNEL SET UP
TV
TV
Channel presetting is necessary at the start
or in case you moved the TV to a different area.
AUTO CHANNEL PROGRAMMING
1 Press [SET-UP].
[KK/ LL] to point to
Use
"CHANNEL SET UP", then
press
[ENTER].
2 Use [
KK / LL
] to point to "AUTO
CH PROGRAMMING", then
press
[ENTER].
The tuner scans and memorizes all the active
channels in your area.
3 When the scanning is comple-
ted, the lowest memorized
channel is displayed.
If "NO TV SIGNALS" appears
on the TV screen, check the
antenna connection and try
again.
NOTES:
• The unit may recognize CATV channels to be TV
channels if reception condition is poor. In this case,
check the antenna connection and try "AUTO CH
PROGRAMMING" again.
Auto channel programming is NOT necessary
•
when connected to a cable box or satellite box.
Just select the channel for cable box or satellite
input (ex. CH3 or CH4) on the unit, then select
your desired channel on the cable box or satellite
box.
ADDING/DELETING CHANNELS
You can add channels that was not memorized due
to the bad reception status and also delete channels you no longer receive or seldom watch.
- TV SETUP -
B CHANNEL SET UP
V-CHIP SET UP
LANGUAGE [ENGLISH]
CAPTION [OFF]
– CHANNEL SET UP –
ADD/DELETE CH (CATV)
B AUTO CH PROGRAMMING
CH 15
(Example)
NO TV SIGNALS
• Refer to page 9 on how to use
the Number buttons.
4 Press [ENTER] repeatedly.The channel number
changes to
time you press the button.
•To delete or add another channel, repeat steps
to 4.
red (deleted) or blue (added) every
3
5 Press [SET-UP] to exit the menu.
NOTE:
•To confirm that channel(s) has (have) been deleted
or added, select it (them) using [CH.KK/ LL].
ON-SCREEN MENU LANGUAGE
You can select the language of on-screen
menu among English, Spanish and French.
1 Press [SET-UP].
Use
[KK/ LL] to point to
"LANGUAGE".
- TV SETUP -
CHANNEL SET UP
V-CHIP SET UP
B LANGUAGE [ENGLISH]
CAPTION [OFF]
2 Press [ENTER] repeatedly to select "ENGLISH",
"ESPAÑOL" or "FRANÇAIS".
3 Press [SET-UP] to exit the menu.
NOTES:
• This function effects only the language on the screen
menu and not the audio source.
• If for some reason the menu is already in Spanish or
French, press [SET-UP], using [KK/ LL] point to
"IDIOMA [ESPAÑOL]" or "LANGAGE [FRANÇAIS]",
then press [ENTER] repeatedly to select desired language, then press [SET-UP].
TV SECTION
TV OPERATION AND SETTINGS
1 Press [SET-UP].
Use
[KK/ LL] to point to
"CHANNEL SET UP", then
press
[ENTER].
2 Use [
KK/ LL
] to point to
"ADD/DELETE CH", then
press
[ENTER].
3 Use the Number buttons or
[CH.KK/ LL] to select your
desired channel number.
(You can also use
enter it.)
[KK/ LL] to
- TV SETUP -
B CHANNEL SET UP
V-CHIP SET UP
LANGUAGE [ENGLISH]
CAPTION [OFF]
– CHANNEL SET UP –
B ADD/DELETE CH (CATV)
AUTO CH PROGRAMMING
08
ADD / DELETE
(Example: CH8)
11
EN
Loading...
