Magnavox MSD1005 Owner's Manual

• Remote
control
(NB070UD)
with two AA
batteries

•

Audio/Video
cables

(

WPZ0102TM015/
WPZ0102LTE01/
WPZ0102CAB01)

•

HDMI cable

(WPZ0202NB001)

• Owner’s
Manual
(1VMN21386)

Precautions

Functions

SetupInformation

Supplied Accessory

Owner's Manual

If you need additional operating assistance after

reading this owner’s manual, please call

TOLL FREE : 1-800-605-8610

or visit our web site at http://www.funai-corp.com

Precautions

Laser Safety . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2

■ Important Safeguards . . . . . . . . . . . . . . . . . . . . . . . . . 3

Installation Location. . . . . . . . . . . . . . . . . . . . . . . . . . . . 4

Avoid the Hazards of Electrical Shock and Fire . . . . . . . 4

Moisture Condensation Warning . . . . . . . . . . . . . . . . . . 4

About Copyright. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4

Notice for Progressive Scan Outputs . . . . . . . . . . . . . . . 4

Symbols Used in This Manual . . . . . . . . . . . . . . . . . . . . 4

Maintenance . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4

■ About the Discs . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5

Playable Discs. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5

Unplayable Discs. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5

Setup

■ Connections . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6

Connection to a TV . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6

Connection to a TV with an HDMI Compatible Port . . . . 7

Connection to an Audio System. . . . . . . . . . . . . . . . . . . 8

Rear Terminals . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8

Front Panel Display . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9

HDMI Setup. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9

■ About the Remote Control . . . . . . . . . . . . . . . . . . . . 10

Remote Control . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10

Installing the Batteries for the Remote Control . . . . . . . 10

Functions

■ Playback. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11

■ MP3/WMA Playback . . . . . . . . . . . . . . . . . . . . . . . . . . 12

■ On-Screen Display. . . . . . . . . . . . . . . . . . . . . . . . . . . 12

■ Search Function . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14

Tr ack Search . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14

Title / Chapter Search . . . . . . . . . . . . . . . . . . . . . . . . . 14

Time Search . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14

■ Marker Setup . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14

■ Repeat / Random / Programmed Playback . . . . . . . . 15

Repeat Playback . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15

Repeat A-B Playback. . . . . . . . . . . . . . . . . . . . . . . . . . 15

Random Playback . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15

Programmed Playback. . . . . . . . . . . . . . . . . . . . . . . . . 15

■ Special Settings. . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16

Subtitle Language . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16

Audio Language . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16

Camera Angles . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16

Black Level Setting . . . . . . . . . . . . . . . . . . . . . . . . . . . 16

Stereo Sound Mode. . . . . . . . . . . . . . . . . . . . . . . . . . . 16

Virtual Surround . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16

■ DVD Setup . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17

LANGUAGE Setting. . . . . . . . . . . . . . . . . . . . . . . . . . . 17

DISPLAY Setting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18

AUDIO Setting. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19

PARENTAL Setting . . . . . . . . . . . . . . . . . . . . . . . . . . . 19

OTHERS Setting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20

Reset to the Default Setting

(Except for PARENTAL Setting) . . . . . . . . . . . . . . . . . . 20

Information

■ Troubleshooting Guide . . . . . . . . . . . . . . . . . . . . . . . 21

■ Specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22

■ Language Code List . . . . . . . . . . . . . . . . . . . . . . . . . 22

■ Limited Warranty . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22

Español . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .23

Quick Use Guide . . . . . . . . . . . . . . . . . . . . . .Back Cover

Table of Contents

Before Using Your Unit

If your TV has AUDIO/VIDEO input jacks, see the section
“Connections” on page 6. If not, it is still possible to connect this
unit to your TV by using a STEREO AUDIO/VIDEO RF Modulator
(commercially available.) In this case, follow the instructions below.

1) Connect the AUDIO/VIDEO output jacks of this unit to the
AUDIO/VIDEO input jacks of your RF Modulator by audio and
video cables.

2) The antenna input jack of your TV may have been already occu­pied. If so, disconnect the RF cable from your TV, and then con­nect the RF cable to your RF Modulator (usually marked “ANT
IN”.)

3) Connect your RF modulator to your TV by another RF cable.

4) Set your RF modulator’s channel 3/4 switch to either 3 or 4,
whichever the TV channel is least used in your area. If your RF
modulator has a Modulator/Antenna switch, set it according to
your RF modulator’s manual.

5) Turn on your TV and choose the same channel as you set the
RF modulator’s channel 3/4 switch to.
For more details, follow the instructions supplied with the RF
Modulator.

Hint

Hint

• The quality of picture may become poor if the unit is connected

to an RF Modulator.

T

Español

Owner’s Manual

Please read before using this unit.

DVD/CD Player

MSD1005

INSTRUCCIONES EN ESPAÑOL INCLUIDAS.

Cable
Signal

Antenna

Stereo Audio/Video RF Modulator

(commercially available)

ANT IN

AC 120V

TO TVCHANNEL VIDEO AUDIO

2

(Back of DVD player)

DIGITAL OUT

(PCM/BITSTREAM)

OPTICAL

RL34

RF Cable (Not supplied)

HDMI OUT

COAXIAL

1

Audio/Video

Cables

(Supplied)

2CH AUDIO

COMPONENT

OUT

VIDEO OUT

L

YC

CB/P

R

VIDEO

OUT

3

S-VIDEO

OUT

R/PR

B

(Back of

Antenna in jack

–2–

EN

Precautions

This unit employs a laser. Only a qualified service person should remove the cover or attempt to service this device, due to possible
eye injury.

CAUTION: USE OF CONTROLS OR ADJUSTMENTS OR PERFORMANCE OF PROCEDURES OTHER THAN THOSE SPECI-

FIED HEREIN MAY RESULT IN HAZARDOUS RADIATION EXPOSURE.

CAUTION: VISIBLE AND INVISIBLE LASER RADIATION WHEN OPEN AND INTERLOCK DEFEATED. DO NOT STARE INTO

BEAM.

LOCATION: INSIDE, NEAR THE DECK MECHANISM.

WARNING

: TO REDUCE THE RISK OF FIRE OR ELECTRIC SHOCK, DO NOT EXPOSE THIS

APPLIANCE TO RAIN OR MOISTURE.

RADIO-TV INTERFERENCE

This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part
15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in
a residential installation. This equipment generates, uses, and can radiate radio frequency energy and, if not
installed and used in accordance with the instructions, may cause harmful interference to radio communications.
However, there is no guarantee that interference will not occur in a particular installation. If this equipment does
cause harmful interference to radio or television reception, which can be determined by turning the equipment off
and on, the user is encouraged to try to correct the interference by one or more of the following measures:

1) Reorient or relocate the receiving antenna.

2) Increase the separation between the equipment and receiver.

3) Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.

4) Consult the dealer or an experienced radio/TV technician for help.

This Class B digital apparatus complies with Canadian ICES-003.
Cet appareil numérique de la classe B est conforme à la norme NMB-003 du Canada.

FCC WARNING-This equipment may generate or use radio frequency energy. Changes or modifications to

this equipment may cause harmful interference unless the modifications are expressly approved in the man­ual. The user could lose the authority to operate this equipment if an unauthorized change or modification
is made.

CAUTION:TO PREVENT ELECTRIC SHOCK, MATCH WIDE BLADE OF PLUG TO WIDE SLOT, FULLY INSERT.

ATTENTION: POUR ÉVITER LES CHOC ÉLECTRIQUES, INTRODUIRE LA LAME LA PLUS LARGE DE LA

FICHE DANS LA BORNE CORRESPONDANTE DE LA PRISE ET POUSSER JUSQU’AU FOND.

A NOTE ABOUT RECYCLING

This product’s packaging materials are recyclable and can be reused. Please dispose of any materials in accordance with your
local recycling regulations.

Batteries should never be thrown away or incinerated but disposed of in accordance with your local regulations concerning
chemical wastes.

Precautions

Laser Safety

For Customer Use:
Read carefully the information located at the bottom of this unit and enter below the Serial No. Retain this information for
future reference.

Model No.

_____________________

Serial No. _____________________

Make your contribution to the environment!!!

• Used up batteries do not belong in the dust bin.

• You can dispose of them at a collection point for used up batteries or special waste.
Contact your council for details.

The lightning flash with arrowhead symbol, within an
equilateral triangle, is intended to alert the user to the
presence of uninsulated “dangerous voltage” within the
product’s enclosure that may be of sufficient magnitude
to constitute a risk of electric shock to persons.

The exclamation point within an equilateral triangle is
intended to alert the user to the presence of important
operating and maintenance (servicing) instructions in
the literature accompanying the appliance.

CAUTION

:

TO REDUCE THE RISK OF ELECTRIC SHOCK, DO NOT REMOVE
COVER (OR BACK). NO USER SERVICEABLE PARTS INSIDE. REFER
SERVICING TO QUALIFIED SERVICE PERSONNEL.

CAUTION

RISK OF ELECTRIC SHOCK

DO NOT OPEN

–3–

EN

Precautions

IMPORTANT SAFEGUARDS

1) Read Instructions - All the safety and operating instruc­tions should be read before the product is operated.

2) Retain Instructions - The safety and operating instruc­tions should be retained for future reference.

3) Heed Warnings - All warnings on the product and in
the operating instructions should be adhered to.

4) Follow Instructions - All operating and use instructions
should be followed.

5) Cleaning - Unplug this product from the wall outlet
before cleaning. Do not use liquid cleaners or aerosol
cleaners. Use a damp cloth for cleaning.

6) Attachments - Do not use attachments not recom­mended by the product manufacturer as they may
cause hazards.

7) Water and Moisture - Do not use this product near
water - for example, near a bath tub, wash bowl,
kitchen sink, or laundry tub; in a wet basement; or near
a swimming pool; and the like.

8) Accessories - Do not place this product on an unstable
cart, stand, tripod, bracket, or table. The product may
fall, causing serious injury to a child or adult, and seri­ous damage to the product. Use only with a cart,
stand, tripod, bracket, or table recom­mended by the manufacturer, or sold
with the product. Any mounting of the
product should follow the manufac­turer’s instructions, and should use a
mounting accessory recommended
by the manufacturer.

9) A product and cart combination should be moved with
care. Quick stops, excessive force, and uneven sur­faces may cause the product and cart combination to
overturn.

10) Ventilation - Slots and openings in the cabinet are pro­vided for ventilation and to ensure reliable operation of
the product and to protect it from overheating, and
these openings must not be blocked or covered. The
openings should never be blocked by placing the prod­uct on a bed, sofa, rug, or other similar surface. This
product should not be placed in a built-in installation
such as a bookcase or rack unless proper ventilation is
provided or the manufacturer's instructions have been
adhered to.

11) Power Sources - This product should be operated only
from the type of power source indicated on the mark­ing label. If you are not sure of the type of power sup­ply to your home, consult your product dealer or local
power company. For products intended to operate from
battery power, or other sources, refer to the operating
instructions.

12) Grounding or Polarization - This product may be
equipped with a polarized alternating-current line plug
(a plug having one blade wider than the other). This
plug will fit into the power outlet only one way. This is a
safety feature. If you are unable to insert the plug fully
into the outlet, try reversing the plug. If the plug should
still fail to fit, contact your electrician to replace your
obsolete outlet. Do not defeat the safety purpose of the
polarized plug.

13) Power-Cord Protection - Power-supply cords should be
routed so that they are not likely to be walked on or
pinched by items placed upon or against them, paying
particular attention to cords at plugs, convenience
receptacles, and the point where they exit from the
product.

14) Lightning - For added protection for this product during
a lightning storm, or when it is left unattended and
unused for long periods of time, unplug it from the wall
outlet. This will prevent damage to the product due to
lightning and power-line surges.

15) Power lines - An outside antenna system should not be
located in the vicinity of overhead power lines or other
electric light or power circuits, or where it can fall into
such power lines or circuits.When installing an outside
antenna system, extreme care should be taken to keep
from touching such power lines or circuits as contact
with them might be fatal.

16) Overloading - Do not overload wall outlets, extension
cords, or integral convenience receptacles as this can
result in a risk of fire or electric shock.

17) Object and Liquid Entry - Never push objects of any
kind into this product through openings as they may
touch dangerous voltage points or short-out parts that
could result in a fire or electric shock. Never spill liquid
of any kind on the product.

18) Servicing - Do not attempt to service this product your­self as opening or removing covers may expose you to
dangerous voltage or other hazards. Refer all servicing
to qualified service personnel.

19) Damage Requiring Service - Unplug this product from
the wall outlet and refer servicing to qualified service
personnel under the following conditions:
a) When the power-supply cord or plug is damaged,
b) If liquid has been spilled, or objects have fallen into

the product,
c) If the product has been exposed to rain or water,
d) If the product does not operate normally by follow-

ing the operating instructions. Adjust only those con-

trols that are covered by the operating instructions

as an improper adjustment of other controls may

result in damage and will often require extensive

work by a qualified technician to restore the product

to its normal operation,
e) If the product has been dropped or damaged in any

way.

f) When the product exhibits a distinct change in per-

formance - this indicates a need for service.

20) Replacement Parts - When replacement parts are
required, be sure the service technician has used
replacement parts specified by the manufacturer or
have the same characteristics as the original part.
Unauthorized substitutions may result in fire, electric
shock, or other hazards.

21) Safety Check - Upon completion of any service or
repairs to this product, ask the service technician to
perform safety checks to determine that the product is
in proper operating condition.

22) Heat - The product should be situated away from heat
sources such as radiators, heat registers, stoves, or
other products (including amplifiers) that produce heat.

–4–

EN

Precautions

Unauthorized copying, broadcasting, public
performance and lending of discs are prohibited.
This product incorporates copyright protection
technology that is protected by U.S. patents and other
intellectual property rights. Use of this copyright
protection technology must be authorized by
Macrovision, and is intended for home and other
limited viewing uses only unless otherwise authorized
by Macrovision. Reverse engineering or disassembly
is prohibited.

The following symbols appear in some head­ings in this manual.

: Description refers to playback of DVD-Video discs.

: Description refers to playback of Audio CDs.

: Description refers to playback of MP3 files.

: Description refers to playback of discs formatted

with WMA.

WMAWMA

WMA

MP3MP3

MP3

CDCD

CD

DVD-V

DVD-V

For safety and optimum performance of this unit:

• Do not stand the unit up vertically. Install the unit in
a horizontal and stable position. Do not place any­thing directly on top of the unit. Do not place the unit
directly on top of the TV.

• Shield it from direct sunlight and keep it away from
sources of intense heat. Avoid dusty or humid
places. Avoid places with insufficient ventilation for
proper heat dissipation. Do not block the ventilation
holes on the sides of the unit. Avoid locations sub­ject to strong vibration or strong magnetic fields.

• Be sure to remove the disc and unplug the AC
power cord from the outlet before carrying the unit.

• Do not handle the power cord with wet hands.

• Do not pull on the power cord when disconnecting it
from AC wall outlet. Grasp it by the plug.

• If, by accident, water is spilled on this unit, unplug
the power cord immediately and take the unit to our
Authorized Service Center for servicing.

Moisture condensation may occur inside the unit
when it is moved from a cold place to a warm place,
or after heating a cold room or under conditions of
high humidity. Do not use this unit at least for 2 hours
until its inside gets dry.

Installation Location

About Copyright

Symbols Used in This Manual

Manufactured under license from Dolby Laboratories. “Dolby” and the double-D symbol are trade­marks of Dolby Laboratories.

SERVICING

¡Please refer to relevant topics on the “Troubleshooting

Guide” on page 21 before returning the product.

¡If this unit becomes inoperative, do not try to correct

the problem by yourself. There are no user-service­able parts inside. Turn off, unplug the power plug,
and please call our help line mentioned on the front
page to locate an Authorized Service Center.

CLEANING THE CABINET

¡Use a soft cloth slightly moistened with a mild deter-

gent solution. Do not use a solution containing alco­hol, spirits, ammonia or abrasive.

CLEANING DISCS

¡When a disc becomes dirty, clean it with a cleaning

cloth. Wipe the disc from the center out. Do not wipe
in a circular motion.

¡Do not use solvents such as benzine, thinner, com-

mercially available cleaners, detergent, abrasive
cleaning agents or antistatic spray intended for ana­log records.

CLEANING THE DISC LENS

¡If this unit still does not perform properly although you

refer to the relevant sections and to “Troubleshooting
Guide” in this Owner’s Manual, the laser optical pickup
unit may be dirty. Consult your dealer or an Authorized
Service Center for inspection and cleaning of the laser
optical pickup unit.

DISC HANDLING

¡When you handle a disc, hold it by its edge and try

not to touch the surface of the disc.

¡Always store a disc in its protective case when it is

not used.

Maintenance

Moisture Condensation Warning

Avoid the Hazards of Electrical Shock and Fire

Notice for Progressive Scan Outputs

Consumers should note that not all high definition televi­sion sets are fully compatible with this product and may
cause artifacts to be displayed in the picture. In case of
picture problems with 525 progressive scan output, it is
recommended that the user switch the connection to the
‘standard definition’ output. If there are questions regard­ing your TV set compatibility with this 525p DVD player,
please contact our customer service center.

“WMA” (Windows Media Audio) is a new audio codec developed by Microsoft®in the United States of
America.

–5–

EN

Precautions

About the Discs

Unplayable Discs

¡

NEVER play back the following discs. Otherwise, malfunction may result!

DVD-RAM / CD-I/Photo CD / Video CD / DVD with region codes other than 1 or ALL
DTS-CD / DVD-ROM for personal computers / CD-ROM for personal computers

¡

On the following disc, the sound MAY NOT be heard.

Super Audio CD
NOTE: Only the sound recorded on the normal CD layer can be delivered.

The sound recorded on the high density Super Audio CD layer cannot be delivered.

¡

Any other discs without compatibility indications

Playable Discs

If you cannot play back a disc which bears one of the marks above, check the following notes.

*1: This unit conforms to the NTSC color system. Discs recorded in other color systems such as PAL may not be played

back or the picture may be distorted.
*2: Certain DVD-Video discs do not operate as described in this manual due to the intentions of the disc’s producers.
*3: Discs recorded in the VR (Video Recording) format cannot be played back.
*4: Scratched or stained discs may not be played back.
*5: Some discs cannot be played back because of incompatible recording conditions, characteristics of the recorder or spe-

cial properties of discs.
*6: You can play back discs which bear the marks above. If you use nonstandardized discs, this unit may not play them back.

Even if they are played back, the sound or video quality will be compromised.
*7: You may play back the unfinalized DVD-R/RW disc recorded in the video format on our brand’s DVD recorder. However,

depending on the recording status of a disc, the disc may not be played back at all or normally (the picture or sound may

not be smooth, etc.). In this case, you need to finalize the disc with the DVD recorder. Refer to the manual accompanying

the DVD recorder.
*8: Only the discs recorded in the video format and finalized can be played back.

Unfinalized discs cannot be played back. Depending on the recording status of a disc, the disc may not be played back at

all or normally (the picture or sound may not be smooth, etc.).
*9:

If there is too much recording space left on a disc (the used portion is less than 55 mm across), it may not play back properly.

*10: Do not glue paper or put stickers on to the disc. These may damage the disc, and the unit may not read it correctly.
*11: This DVD/CD player cannot playback the disc contents protected by Windows Media Digital Rights Management (DRM).

Windows Media and the Windows logo are trademarks or registered trademarks of Microsoft
Corporation in the United States and/or other countries.

DVD-Video

* 1, 2, 4, 6, 10

* 1, 3, 4, 5,

6, 8, 9, 10

* 1, 3, 4, 5,

6, 7, 9, 10

* 4, 6, 10

* 4, 5, 6,

9, 10

or

DVD-RW

DVD-R

DVD+RW

DVD+R

Audio CD

CD-RW

CD-R

Digital video

(MPEG2)

-

-

-

Region code

Mark (logo)

Playable

discs

Recorded

signals

Disc size

Disc types

12 cm

or

8cm

Example

Title 1 Title 2

Chapter 1 Chapter 2 Chapter 1

Chapter 2

Chapter 3 Chapter 4

Digital audio

or

MP3/

WMA

*11

12 cm

or

8cm

Example

Group 1 Group 2

Tra c k 1

Tra c k 2 Track 5

Tra c k 6

Tra c k 3

Tra c k 4

Example

Tra c k 1

Tra c k 2

Tra c k 5

Tra c k 6

Tra c k 3

Tra c k 4

Audio CD

MP3/WMA

Digital audio

-

is a trademark of DVD Format/Logo Licensing Corporation.

Hint

Hint

• Connect this unit directly to the TV. If the Audio/Video cables are connected to a VCR, pictures may be distorted due to the
copy protection system.

• When progressive scanning mode is selected, no video signal will be output from the VIDEO OUT or S-VIDEO OUT jack.

–6–

EN

Setup

Connections

If your TV has AUDIO/VIDEO input jacks, see the following instructions. If not, see the section “Before Using
Your Unit” on the front page.

Setup

Connection to a TV

DIGITAL OUT

(PCM/BITSTREAM)

HDMI OUT

2CH AUDIO
OUT

L

YC

R/PR

CB/PBR

COMPONENT
VIDEO OUT

S-VIDEO

OUT

R

OPTICAL

COAXIAL

2CH AUDIO

OUT

L

R

LR

AUDIO IN

VIDEO IN

VIDEO

OUT

S-VIDEO IN

S-VIDEO

OUT

2CH AUDIO OUT (Analog) VIDEO OUT

TV

Method 1

Good pictureBasic Audio

Method 2

Better picture

S-VIDEO OUT

Video

cable

(supplied)

Audio cable

(supplied)

S-Video

cable

(commercially

available)

This unit

C

B

Y

C

R

COMPONENT

VIDEO IN

or

P

B

Y

P

R

YCR/P

R

CB/P

B

COMPONENT

VIDEO OUT

VIDEO

OUT

Method 3

Best picture

COMPONENT VIDEO OUT

Component Video cables
(commercially available)

(INPUT)

(OUTPUT)

If your TV is compatible with 525p (480p) progressive scanning and you want to enjoy the high quality
picture;

Set “PROGRESSIVE” to “ON” in the Display setting. Details are on pages 17-18.You also need to set your TV to progressive
scanning mode.

If your TV is not compatible with progressive scanning;

Use this unit in interlace mode. Set “PROGRESSIVE” to “OFF” in the Display setting. Holding [PLAY BB] on the front panel or the
remote control for more than 5 seconds will also switch from progressive scanning mode to interlace mode.

After you have completed connections

• Press the input selector button (usually TV/VIDEO, INPUT or AUX) on your TV to switch an appropriate external input

channel (usually near channel 0) for viewing the picture from this unit. If the picture does not appear, also refer to the
manual accompanying your TV.

INPUT MODES FOR COMMON TV BRANDS (Example)

• Listed below are inputs for common brand name TV’s.

Admiral: AUX
Curtis Mathis: LINE1, LINE2, 00, 90, 91, 92, 93
GE: INPUT, TV/VCR, 00, 90, 91, 92, 93
Hitachi: INPUT, AUX
JVC: VIDEO, VIDEO1, VIDEO2, VIDEO3
Kenwood: AUX
LXI-Series: 00
Magnavox: AUX CHANNEL
Panasonic: TV/VIDEO
RCA: INPUT, TV/VCR, 00, 90, 91, 92, 93
Samsung: TV/VIDEO

Sanyo: VIDEO
Sharp: 00
Sony: VIDEO1, VIDEO2, VIDEO3
Toshiba: TV/GAME
Zenith: 00

The DCDi (Directional Correlational Deinterlacing) system of this DVD player produces smooth and
natural video images, even if really dynamic, by eliminating the jagged edges. *“DCDi” is a trademark
of Faroudja, a division of Genesis Microchip Inc.

–7–

EN

Connection to a TV with an HDMI Compatible Port

A simple 1-cable connection with a device having an HDMI (High-Definition Multimedia Interface) connector
allows digital transfer of the digital images of DVD-Video and other sources, DVD-Video, and the multi-channel
sound of DVD-Audio.

DIGITAL OUT

(PCM/BITSTREAM)

HDMI OUT

2CH AUDIO

OUT

L

YC

R/PR

CB/PBR

COMPONENT

VIDEO OUT

S-VIDEO

OUT

VIDEO

OUT

OPTICAL

COAXIAL

To HDMI Input
Connector

A display equipment with an HDMI compatible port

HDMI cable
(supplied)

NOTES:

• When using an HDMI-incompatible or HDCP-incompatible display equipment, the image will not be viewed properly.

• Among the devices that support HDMI, some devices can control other devices via the HDMI connector; however, this play-

er cannot be controlled by another device via the HDMI connector.

• The audio signals from the HDMI connector (including the sampling frequency and bit length) may be limited by the equip-

ment that is connected.

• Among the monitors that support HDMI, some do not support audio output (for example, projectors). In connections with

equipment such as this, audio signals are not output from the HDMI output connector.

• When the set’s HDMI connector is connected to a DVI-D compatible monitor (HDCP compatible) with an HDMI-DVI convert-

er cable (commercially available), the signals are output in digital RGB.

*HDMI: High Definition Multimedia Interface

Copyright protection system

To play back the digital video images of a DVD via an HDMI connection, it is necessary that both the player and the display
equipment (or an AV amplifier) support a copyright protection system called HDCP (High-bandwidth Digital Content
Protection System). HDCP is copy protection technology that comprises data encryption and authentication of the connect­ed AV equipment.
This player supports HDCP. Please read the operating instructions of your display equipment (or AV amplifier) for more
information.

DOLBY DIGITAL Setting

Audio Recording Format

BITSTREAM *1 PCM

Dolby Digital Dolby Digital

2channel PCM

DVD-Video

LPCM 2channel PCM 2channel PCM
Audio CD 2channel PCM 2channel PCM
MP3/WMA 2channel PCM 2channel PCM

*1 If the connected equipment is not compatible with HDMI BITSTREAM, signals are output on PCM.

C Actual output modes by media

“HDMI, the HDMI logo and High-Definition Multimedia Interface are trademarks or registered
trademarks of HDMI Licensing LLC.”

Setup

–8–

EN

Setup

Stereo system

Method 1

Rear Terminals

Connection to an Audio System

LR

2CH AUDIO

OUT

L

R

COAXIALOPTICAL

DIGITAL OUT

(PCM/BITSTREAM)

OPTICAL

COAXIAL

AUDIO

This unit

Analog audio
input jacks

Digital
audio input
jack

2CH AUDIO OUT
(Analog)

DIGITAL
AUDIO OUT

Audio cable

(supplied)

Audio Coaxial

Digital cable

(commercially

available)

Optical cable

(commercially

available)

Dolby Digital

decoder, MD deck

or DAT deck

PCM

SETUP > QUICK >

DOLBY DIGITAL

Connecting to Stereo System.

Setting

Connection

* To complete these settings, refer to pages 17-19.

Hint

Hint

•

Playing a DVD using incorrect settings may generate noise
distortion and may also damage the speakers.

BITSTREAM

PCM

SETUP > QUICK >

Setting

Connection

DOLBY DIGITAL

Connecting to a Dolby Digital decoder for
Dolby Digital audio output.

Connecting to the other equipment (an MD deck
or DAT deck etc.) without Dolby Digital decoder.

* To complete these settings, refer to pages 17-19.

Hint

Hint

•

The audio source on a disc in a Dolby Digital 5.1 channel surround
format cannot be recorded as digital sound by an MD or DAT deck.

•

By hooking this unit up to a Multi-channel Dolby Digital decoder, you
can enjoy high-quality Dolby Digital 5.1 channel surround sound as
heard in the movie theaters.

•

Playing a DVD using incorrect settings may generate noise distortion
and may also damage the speakers.

S-VIDEO OUT jack

Connect an optional
S-Video cable here
through the S-video in
jack of a television.

HDMI OUT jack

Use a HDMI connection cable (supplied)
to connect to a display with an HDMI
compatible port.

COMPONENT VIDEO OUT jacks

Connect optional component video
cables here through the component
video in jacks of a television.

OPTICAL jack

Connect an optional digital audio cable
here through the optional digital audio in
jack of a decoder or audio receiver.

2CH AUDIO OUT jacks

Connect the supplied
audio cables here
through the audio in
jacks of a television or
other audio equipment.

COAXIAL jack

Connect an optional coaxial digital
audio cable here through the coaxial
digital audio in jack of a decoder or
audio receiver.

VIDEO OUT jack

Connect the supplied yellow
video cable here through the
TV’s video in jack.

Hint

Hint

•

When there is video out­put from the HDMI OUT
jack, no signal is output
from the COMPONENT
VIDEO OUT jacks.

Optical cable (commercially available)

• Optical cable (commercially available) may be damaged when bent at sharp angles. Ensure cables are coiled in loops with
a diameter of 6 inches (15 cm) or more when storing them.

• Use a cable which is 9.8 feet (3 m) or shorter.

• Insert cable plugs firmly into the connectors when making connections.

• If a plug has dust or is dirty, clean it with a soft cloth before inserting it into a connector.

Method 2

DIGITAL OUT

(PCM/BITSTREAM)

OPTICAL

2CH AUDIO

HDMI OUT

COAXIAL

COMPONENT

OUT

VIDEO OUT

L

YC

R

VIDEO

OUT

CB/P

R/PR

B

S-VIDEO

OUT

–9–

EN

Setup

Front Panel Display

Power on

No disc inserted or
cannot read

Tr ay open

Tr ay closed

Loading the Disc

HDMI output mode
(480p) is selected

Power off

HDMI output mode
(720p) is selected

HDMI output mode
(1080i) is selected

HDMI output mode
(OFF) is selected

Lights up when the inserted
disc is being played back.

Displays a type of the disc
which is inserted on the tray.

• DVD: DVD disc

• CD: Audio CD, MP3, WMA

Lights up when the
inserted disc comes
to a pause.

Lights up when the
A-B repeat function
is on.

Lights up when the
repeat function is on.

Lights up when playing back
in slow mode. (DVD)

Displays how long the current title or track
has been played back. When a chapter or track is
switched, the number of a new title,
chapter or track is displayed.
Selected HDMI output mode is displayed.

Lights up when
the ALL repeat
function is on.

GROUP P.SCAN

DVD

CD

Lights up when the
progressive scan
system is activated.

HDMI Setup

H / E D/ G

HDMI Button

Press to set the HDMI connectors
video signal output.

Hint

Hint

•

Video and audio signals may distorted temporarily when
switching to/from the HDMI output mode.

• Use a display equipment with an HDMI-compatible
port.

• Progressive video signal will not be output from the
COMPONENT VIDEO OUT jacks during the HDMI out­put mode.

• If the HDMI cable is not connected correctly or the
other equipment is not turned on, the HDMI indicator
on the front panel will not light up even you select the
HDMI mode.

•You can check the HDMI connection status by pressing
[DISPLAY] during playback with the HDMI output mode
(refer to page 7).

• If the TV is not compatible with newly selected HDMI
output mode, the actual output mode will be kept the
one before changing the selection. When this occurs,
the newly selected mode will appear on the front panel
display while the actual output resolution will be indicat­ed by performing the on-screen display as described
above.

HDMI indicator

Lights up when there is video signal
output from the HDMI OUT jack.

Press [HDMI] on the front panel to select the HDMI output mode.

The output mode changes as follows every time [HDMI] is
pressed.

• The HDMI indicator on the front panel lights up when HDMI out­put mode is on.

480P (Default): Video output from the HDMI OUT jack at 480p.
720P: Video output from the HDMI OUT jack at 720p.
1080i: Video output from the HDMI OUT jack at 1080i.
hdOFF:

No video output from the HDMI OUT connector.

1080i hdOFF480P

720P

–10–

EN

Setup

About the Remote Control

• To turn the unit on or off. • To turn the unit on or off.

• To display the current disc

or HDMI mode.

• To display the current disc
or HDMI mode.

• To open or close the disc
tray.

• To open or close the disc
tray.

• To select chapter or title
directly.

• To select track directly.

• To select camera angles on

a disc.

• To select subtitles on a disc.

• To select audio languages on

a disc.

• To select STEREO,
L-ch or R-ch.(CD)

• To repeat between your
chosen point A and B.

• To repeat between your
chosen point A and B.(CD)

• To play a chapter or title
repeatedly.

• To play a track or disc
repeatedly.(CD)

• To play a track, group or disc
repeatedly. (MP3/WMA)

• To return to the previous
operation in menu.

• To set black level on/off.

• To set virtual surround on/off.

• To arrange the playing

order or play randomly.

• To set virtual surround on/off.

• To call up the Menu

on a disc.

• To call up the Top Menu
on a disc.

• To magnify part of a picture.
(x2/x4)

• To return to the previous
operation in menu.

• To search chapter, title or time.

• To set or search the

markers.

• To search track.

• To search time. (CD)

• To set or search the

markers. (CD)

• To clear the markers.

• To clear the numbers

entered incorrectly.

• To cancel the point for A-B
repeat.

• To clear the markers.(CD)

• To remove status number

in program input.

• To clear the numbers
entered incorrectly.

• To cancel the point for A-B
repeat.(CD)

• To pause disc playback.

• To advance playback

one frame at a time.

• To pause disc playback.

• To stop playback. • To stop playback.

• To skip chapters. • To skip tracks.

• To begin disc playback. • To begin disc playback.

• To call up the DVD setup

menu.

• Only used to call up the
DVD setup menu.

• To move the cursor and
determine its position.

• To move the cursor and
determine its position.

STANDBY-ON

DISPLAY

MENU

TOP MENU

ZOOM

SUBTITLE

MODE

ANGLE

SEARCH

MODE

REPEAT

A-B

AUDIO

CLEAR

123

456

789

0

+1 0

PAUSE

PLAY

STOP

SETUP

DVD-V

DVD-V

Button

(Alphabetical order)

Disc

ENTER

RETURN

• To search forward/backward
through a disc.

• To begin slow forward
/reverse playback during
the pause mode.

• To search forward/backward
through a disc.

REV FWD

OPEN/CLOSE

SKIP

• To call up the file list.
(MP3/WMA)

•

To return to the top file of the
highest hierarchy in the program
and

file list

. (MP3/WMA)

CDCD

CD

MP3MP3

MP3

WMAWMA

WMA

STANDBY-ON

AUDIO

SUBTITLE

ANGLE

REPEAT

CLEAR

A-B

PAUSE

SETUP

TOP MENU

MENU

ENTER

MODE

ZOOM RETURN

SLOW

SKIP

OPEN/ CLOSE

DISPLAY

SEARCH

MODE

123

456

789

0 +10

PLAY

REV FWD

STOP

2

1

3

Installing the Batteries
for the Remote Control

Install two AA batteries (supplied)
matching the polarity indicated inside
battery compartment of the remote
control.

Remote Control

Keep in mind the following when
using the remote control:

•

Make sure that there is no obstacle
between the remote control and the
remote sensor on the unit.

• The maximum operable ranges
from the unit are as follows.

- Beeline: approx. 23 feet (7m)

- Either side of the center:

approx. 16 feet (5m) within 30°

- Above: approx. 16 feet (5m)

within 15°

- Below: approx. 10 feet (3m)

within 30°

D/ G

H / E

STANDBY-ON

–11–

EN

Functions

Paused and Step-by-Step Playback

Press [PAUSE FF] during playback.
To continue playback, press [PLAY B].

The disc goes forward by one frame each time [PAUSE FF]
is pressed during the pause mode.
To continue playback, press [PLAY B].

DVD-V

DVD-V

WMAWMA

WMA

MP3MP3

MP3

CDCDCDDVD-V

DVD-V

Hint

Hint

• Slow forward or reverse speed is different depending on the disc.
Approximate speed is 1(1/16), 2(1/8) and 3(1/2).

• Set “STILL MODE” to “FIELD” in the Display menu if pictures in the
slow playback mode are blurred. (Refer to pages 17-18.)

Functions

Fast Forward/Reverse Search

Press [REV hh] or [FWD gg] repeatedly dur­ing playback to select the required forward or
reverse speed.
To continue playback, press [PLAY B].

Slow Forward/Slow Reverse

Press [REV hh] or [FWD gg] repeatedly dur­ing the pause mode to select the required for­ward or reverse speed.
To continue playback, press [PLAY B].

DVD-V

DVD-V

WMAWMA

WMA

MP3MP3

MP3

CDCDCDDVD-V

DVD-V

STANDBY-ON

AUDIO

SUBTITLE

ANGLE

REPEAT

CLEAR

A-B

PAUSE

SETUP

TOP MENU

MENU

SLOW

SKIP

OPEN/CLOSE

DISPLAY

SEARCH

MODE

123

456

789

0 +10

PLAY

REV FWD

STOP

Before: Turn on the TV, amplifier and any
other equipment which are connected to
this unit. Make sure the TV and audio
receiver (commercially available) are set
to the correct channel.

1

1

2

2

3

3

1

1

PLAY

4

4

3

3

Functions

4

4

STOP

STANDBY-ON

OPEN/CLOSE

DVD menu

Some discs contain menus which allow you to customize
DVD playback. Use [KK/ LL/ ss/ BB] to select an item, then
press [ENTER] (or [PLAY BB]), to select.

Calling Up a Menu Screen during Playback

• Press [MENU] to call up the DVD menu.

• Press [TOP MENU] to call up the title menu.

Hint

Hint

•When you play an MP3/WMA file, details on pages 12-13.

•

A “prohibited icon” may appear at the top-right on the TV
screen when the operation is prohibited by the disc or this unit.

• Some DVDs may start playback from title 2 or 3 due to specif­ic programs.

•

During the playback of a two-layered disc, pictures may stop for a
moment.This happens while the 1st layer is being switched to the
2nd layer. This is not a malfunction.

Operations described in this section are mainly based on the remote control use. Some operations can be carried out on main unit.

1

1

Playback

Hint

Hint

• On DVDs, set “STILL MODE” to “FIELD” in the Display menu if pic­tures in the pause mode are blurred. (Refer to pages 17-18.)

H / E D/ G

1

1

334

4

1

1

TIP:

You can change the on-screen language in “PLAYER MENU”
setting. (Refer to page 17.)

Hint

Hint

• Menu operations may vary depending on the disc. Refer to the
manual accompanying the disc for more details.

Resume

Press [STOP CC]. Resume mes­sage will appear on the TV
screen.

Press

[PLAY BB], playback will

resume from the point at which
playback was stopped.

Resume information stays on even when unit is in standby mode.

WMAWMA

WMA

MP3MP3

MP3

CDCDCDDVD-V

DVD-V

Hint

Hint

•

To cancel resume, press [STOP CC] one more time during the stop mode.

•For MP3

/WMA

, playback will resume from the beginning of the track

at which playback was stopped.

• The resume information will be kept even when unit is in standby mode.

Zoom

Press [ZOOM] repeatedly during playback to select the
required zoom factor: x2, x4 or OFF.

Use [KK/ LL/ ss/ BB] to slide the zoomed picture across the
screen.
To exit zoom function, press [ZOOM] repeatedly to select
OFF.

DVD-V

DVD-V

Hint

Hint

•

For DVDs, fast forward or reverse search speed is different depending on
the disc. Approximate speed is 1(x2), 2(x8), 3(x20), 4(x50) and 5(x100).

•For Audio CDs, approximate speed is 1(x2), 2(x8) and 3(x30).

•For MP3

/WMA

, approximate speed is 1(x2), 2(x8), 3(x30).

Lights up when power is on.

Insert a disc with
label facing up.

Hint

Hint

• Zooming function does not work while the disc menu is showing up.

• x4 zoom is not available on some discs.

• The picture may be distorted when you press

[PAUSEkk] or

[REV hh] repeatedly in the zoom mode.

• It may take several seconds to slide the zoomed picture.

To start
playback

To stop
playback

<Example : DVD>

(

⇒Pages 12-13

)

WMAWMA

WMA

MP3MP3

MP3

CDCDCDDVD-V

DVD-V

2

2

Resume ON

Press 'PLAY' to play from here.
To play the beginning,
press 'STOP' first and then 'PLAY'.

E

x2 x4

1

1

–12–

EN

Functions

Functions

On-Screen Display

You can check the information about the current disc by pressing [DISPLAY] on the remote control.

DVD-V

DVD-V

CDCD

CD

4/12 0:03:21 - 0:02:15

T

4/12 0:13:45 - 0:45:40

T

CH(Chapter):
Current chapter number / Total chapters

TT(Title):
Current title number / Total titles

Current repeat setting appears only
when the repeat setting is active

C: Chapter repeat / T: Title repeat /

AB:A-B repeat

TR(Track):
Current track number / Total tracks

Current repeat setting appears only
when the repeat setting is active

T: Track repeat
A: All Tracks repeat

AB:A-B repeat

11/16 0:00:00 - 0:03:30

1/3 0:00:00 - 1:23:45

TL1

BIT RATE: The amount of audio and
video data currently being read

ALL:
Current track number / Total tracks

Elapsed time of the current chapter

Remaining time of the current chapter

Elapsed time of the current title

Remaining time of the current title

Layer numbers, appears only when
playing a two-layered Disc
L0: Layer 0 is playing
L1: Layer 1 is playing

Elapsed time of the current track

Remaining time of the current track

Elapsed time of the entire disc

Remaining time of the entire disc

Current playback status

Current playback status

DISPLAY

DISPLAY

DISPLAY

DISPLAY

DISPLAY

DISPLAY

DISPLAY

1

1

2

2

4

4

3

3

1

1

2

2

4

4

Hint

Hint

• When you are playing a disc in PROGRAM or RANDOM mode,
PROGRAM (or RANDOM) will be displayed instead of .

2

2

2

2

STOP

MP3/WMA Playback

Insert an MP3-format disc, then press [MENU]
to call up the file list on the TV screen.

WMAWMA

WMA

MP3MP3

MP3

1

1

folder name 4

folder name 1

folder name 3

folder name 2

folder name 1

DISC NAME

FILE LIST

FOLDER

WMA

MP3

ENTER

PLAY

file name 3

file name 2

file name 1

1/ 2

3

3

3

ENTERENTERENTER

When selecting the folder:

• Press

[BB]

when you want

to go to the next hierarchy.

• Press

[ss] when you

want to go back to the
previous hierarchy
(except for the top
hierarchy).

MENU

MP3/WMA is a method of compressing files.You can copy MP3/WMA files on CD-R/RWs from the computer and play the files on this unit.

Hint

Hint

• Some selections may take a while to be recognized.

• Press

[TOP MENU] to return to the first item.

• Folders are known as Groups; files are known as Tracks.

• MP3 files are accompanied by icon. • WMA files are accompanied by icon.

• Folders are accompanied by icon.

• A maximum of 255 folders can be recognized.

• A maximum of 999 files can be recognized.

• Up to 8 hierarchies can be created.
This player recommends the files recorded under the following circumstances:

• Sampling frequency: 44.1kHz or 48kHz (MP3/WMA)

• Constant bit rate: 32kbps ~ 320kbps (MP3), 48kbps ~ 192kbps (WMA)

• For MP3/WMA file recorded in Variable Bit Rate(VBR), the unit may not display the actual elapsed time.

• Copyright protected WMA files will not play on this DVD/CD player.

3

Refer to “Resume” on page 11.

PLAY

or

Angle icon, appears only when avail­able on the DVD

DISPLAY

Current HDMI status

• Image output / Resolution of image

• Sound output format

• Maximum number of audio channels

5

5

3

3

Current HDMI status

• Image output / Resolution of image

• Sound output format

• Maximum number of audio channels

DISPLAY

VIDEO INFO. :
AUDIO INFO. :
MAX CHANNEL

YCbCr/1080i
BITSTREAM

: 2ch

VIDEO INFO. :
AUDIO INFO. :
MAX CHANNEL

YCbCr/1080i
BITSTREAM

: 2ch

WMAWMA

WMA

–13–

EN

Functions

MP3MP3

MP3

DISPLAY

DISPLAY

DISPLAY

DISPLAY

TRACK 01

3

1/36 0:01:15

T

The name of the file currently in
play will be displayed.

Current repeat setting, if active

T: Track repeat
G: Group (folder) repeat
A: Disc repeat

Elapsed playing time of the current
track

PROGRAM

RANDOM

or

TR(Track):
Current track number / Total tracks

Current playback status

1

1

2

2

3

3

5

5

(Only when you are playing a disc in PROGRAM or RANDOM mode.)

4

4

Current HDMI status

• Image output / Resolution of image

• Sound output format

• Maximum number of audio channels

DISPLAY

DISPLAY

DISPLAY

DISPLAY

TRACK 01

3

1/36 0:01:15

T

The name of the file currently in
play will be displayed.

Current repeat setting, if active

T: Track repeat
G: Group (folder) repeat
A: Disc repeat

Elapsed playing time of the current
track

PROGRAM

RANDOM

or

TR(Track):
Current track number / Total tracks

Current playback status

1

1

4

4

5

5

7

7

(Only when you are playing a disc in PROGRAM or RANDOM mode.)

6

6

Current HDMI status

• Image output / Resolution of image

• Sound output format

• Maximum number of audio channels

ARTIST NAME
TITLE NAME

Title name based on tag
information currently in play will
be displayed.

Artist name based on tag
information currently in play will
be displayed.

DISPLAY

DISPLAY

2

2

3

3

DISPLAY

VIDEO INFO. :
AUDIO INFO. :
MAX CHANNEL

YCbCr/1080i
BITSTREAM

: 2ch

DISPLAY

VIDEO INFO. :
AUDIO INFO. :
MAX CHANNEL

YCbCr/1080i
BITSTREAM

: 2ch

–14–

EN

Functions

1

1

1

1

1

1

2

2

1

1

Search Function

Time Search

CDCDCDDVD-V

DVD-V

2

2

within 30 seconds

1:29:00

TOTAL

1:29:00

TOTAL

SEARCH

MODE

PLAY

Marker Setup

This feature allows you to assign a specific
point on a disc to be called back later.

TTo set a marker

o set a marker

CDCDCDDVD-V

DVD-V

1

1

SEARCH

MODE

Press repeatedly until
the marker display
appears.

2

2

3

3

ENTERENTERENTER

TTo return to the marker

o return to the marker

later

later

SEARCH

MODE

PLAY

Press repeatedly until
the marker display
appears.

2

2

3

3

ENTERENTERENTER

at the desired marker

• Playback will restart from the specific point
which you set.

TTo e

o e

xit the marker displa

xit the marker displayy

1

1

RETURN

PLAY

or

or

Press repeatedly until
the Time Search display
appears.

Track Search

Using [SEARCH

Using [SEARCH

MODE]

MODE]

WMAWMA

WMA

MP3MP3

MP3

CDCD

CD

within 30 seconds

/29

/29

Title / Chapter Search

Using [SEARCH

Using [SEARCH

MODE]

MODE]

DVD-V

DVD-V

1

1

2

2

within 30 seconds

/12

/12

Press once for the
Chapter Search.
Press twice for the
Title Search.

123

456

789

0

+1 0

SEARCH

MODE

SEARCH

MODE

1

1

PLAY

TR 1 TR 2 TR 3 TR 4

Current Track

(TR)

SKIP

SKIP

Using [SKIP

Using [SKIP

HH

HH

,

,

GG

GG

]

]

Using [SKIP

Using [SKIP

HH

HH

,

,

GG

GG

]

]

SKIP

SKIP

Hint

Hint

• When there is no need to enter a number,
“0” appears automatically.
For example, “0: 0-:--” appears in the Time
Search display if the total time of the title
or track is less than 10 minutes.

• Press

[CLEAR] to erase the incorrect

input at step 2.

Hint

Hint

• Depending on the disc being played, this
function can also be performed by directly
entering the desired chapter number with
the Number buttons. Refer to the manual
accompanying the disc.

•For CDs and MP3/WMA, Track Search is
not available for Programmed or Random
Playback.

PLAY

123

456

789

0

123

456

789

0

+1 0

CH 1 CH 2 CH 3 CH 4

Current Chapter

(CH)

or

SKIP

TT 1 TT2 TT3 TT4

Current Title

(TT)

SKIP

SKIP

SKIP

(If the disc has no chapters)

• For the disc with less than 10 tracks, press

the track number directly.

• For discs with more than 10 but less than

99 tracks, to play a single-digit track, press

[0] first, then the track number (e.g. for
track 3, press [0],[3]). To play a double­digit track, press the track number.

• For discs with more than 100 tracks, to

play a single or a double-digit track, press
[0] first, then the track number (e.g. for
track 3, press [0], [0],[3], and for track 26,
press [0], [2], [6]). To play a triple-digit
track,press the track number.

Hint

Hint

• The Marker display will disappear in about
30 seconds when there is no output.

•To clear a marker, select the marker to be
cleared at step 2 in the section “To set a
marker” or “To return to the marker later”
and then press

[CLEAR].

•

Opening the disc tray or putting unit in
standby mode will erase all markers.

• Selecting “AC” at step 2 in the section “To
set a marker” or “To return to the marker
later” will also erase all markers.

Hint

Hint

• [+10] button can also bring the Track Search

display, except for the disc with less than 10
tracks. For such a disc, track search can be
done by just pressing the track number.

–15–

EN

Functions

2

2

1

1

1

1

Repeat / Random / Programmed Playback

CHAPTER

TITLE

OFF

(current chapter repeat)

(current title repeat)

(repeat

off)

Each time you press [REPEAT], repeat
function changes as example below.

DVD-V

DVD-V

Repeat function is available only during
playback.

WMAWMA

WMA

MP3MP3

MP3

CDCDCDDVD-V

DVD-V

at your desired starting point (A)

CDCDCDDVD-V

DVD-V

You may determine the order in which
tracks will play.

WMAWMA

WMA

MP3MP3

MP3

CDCD

CD

1

1

REPEAT

TRACK

ALL

OFF

(current track repeat)

(

entire disc repeat)

(repeat

off)

CDCD

CD

Repeat Playback Programmed PlaybackRepeat A-B Playback

1

1

A-B

A-B

Random Playback

A-

at your desired end point (B)

2

2

A-B

2

2

or

3

3

This function shuffles the playing order of
tracks instead of playback in the sequence.

WMAWMA

WMA

MP3MP3

MP3

CDCD

CD

MODE

Press twice

.

Press once.

CD-DA TOTAL 0:00:00

ENTER

• Point B should be in the same title or

track as point A.

Hint

Hint

• In the track or group repeat setting will be
cleared when moving to another title,
chapter, track or group.

• Repeat playback may not function with
some discs or during repeat A-B playback.

Hint

Hint

•To repeat the current track in the random
selections, press

[REPEAT] repeatedly

until “ TRACK” appears during playback.

•To repeat the entire random selections,
press

[REPEAT] repeatedly until “ ALL”

appears during playback.

Hint

Hint

• Press [CLEAR] at step 2 to erase the most

recently entered track.

•To erase all programmed tracks at once,
select “ALL CLEAR’’ and press

[ENTER] at

step 2.

• While a program is being played back,
[STOP CC] works as follows;

⇒

Press [STOPCC] and [PLAY BB] next, so
that the programmed playback restarts.

(CD playback restarts from the current
point. MP3/WMA playback restarts from
the beginning of the current track.)

⇒

Press [STOP CC] twice and [PLAY BB]
next, so that playback restarts from the
first track in the original order. However,
your programmed playback can be
restarted when you follow above steps.
(Your programs are still stored until either
the disc is removed or unit is put in
standby mode.)

•To repeat the current track in the program,
press

[REPEAT] repeatedly until

“ TRACK’’ appears during playback.

•To repeat the entire program, press
[REPEAT] repeatedly until “ ALL’’
appears during playback.

Hint

Hint

•To exit the sequence, press [A-B] so that

OFF appears.

•To cancel Point A, press

[CLEAR].

• This function does not work in the other
repeat modes.

PLAY

PLAY

PLAY

STOP

MODE

STOP

ENTER

• Up to 99 tracks can be
ordered.

•

If eight or more tracks were in a
program, use

[SKIP HH,GG]

to see all the tracks.

• While an MP3/WMA folder
is open:

–

Press [BB] when you want
to go to the next hierar­chy.

–

Press [

ss

]

when you want
to go back to the previous
hierarchy (except for the
top hierarchy).

TRACK

GROUP

ALL

OFF

(current track repeat)

(

current group repeat)

(

entire disc repeat)

(repeat

off)

WMAWMA

WMA

MP3MP3

MP3

<Example: CD>

<Example: CD>

RANDOM

CD-DA TOTAL 0:45:55

PLAY

RANDOM PROGRAM

--no indication--

ENTER

ENTER

PLAY

CD-DA TOTAL 1:03:30

1 3:30
5 5:10
10 4:20
11 3:00
12 3:20
17 4:10
22 2:50

2/3

–16–

EN

Functions

1

1

1

1

Special Settings

Audio Language

This unit allows you to select an audio
language (if multiple languages are
available) during DVD playback.

DVD-V

DVD-V

1

1

1.ENG Dolby D 3/2.1ch 48k/ 3

AUDIO

ENG

SPA

FRE

(English audio)

(Spanish audio)

(French audio)

Each time you press [

AUDIO]

, audio

language changes as example below.

This unit allows you to select a subtitle
language (if available) during DVD play­back.

DVD-V

DVD-V

1.ENG/6

ENG

FRE

OFF

(English subtitles)

(French subtitles)

(no subtitles)

Each time you press [SUBTITLE], subtitle
language changes as example below.

Subtitle Language

SUB TITLE

...

...

To set subtitle ON/OFF

1.ENG/6

2

2

OFF

Hint

Hint

• If your language is not shown after press­ing

[AUDIO] or [SUBTITLE] several times,

the disc may not have that language.
However, some discs allow audio language
or subtitle language setting on the disc
menu. (Operation varies depending on the
disc, so refer to the manual along with the
disc.)

•When “NOT AVAILABLE” appears on the
TV screen, it means no subtitle is recorded
on the scene.

•If you choose a language that has a three­letter-language code, the code will be dis­played every time you change the subtitle
language setting. If you choose any other
languages, ‘---’ will be displayed instead.
(Refer to page 22.)

• Some discs will only allow you to change
the subtitle from the disc menu. Refer to the
manual accompanying the discs for details.

PLAY

PLAY

SUB TITLE

PLAY

1

1

Camera Angles

Some DVD discs may con­tain scenes which have been
shot simultaneously from var­ious angles.You can change the cam­era angle if the ( ) icon appears on
the screen. If the “ANGLE ICON” set­ting is “OFF” in the OTHERS menu, the
() icon will not appear. (Refer to
pages 17-20.)

DVD-V

DVD-V

1

1

1 / 8

ANGLE

ON

Black Level Setting

Adjust the Black Level Setting to make
the dark areas of the TV picture brighter.

DVD-V

DVD-V

1

1

STEREO

L-ch

R-ch

(right and left channels
are active)

(left channel is active)

(right channel is active)

This unit allows you to select a sound
mode during CD playback.

CDCD

CD

1

1

STEREO

Each time you press [

AUDIO]

, sound

mode changes as example below.

Stereo Sound Mode

OFF

Virtual Surround

You can enjoy stereophonic virtual
world on your existing 2 channel stereo
system.

WMAWMA

WMA

MP3MP3

MP3

CDCDCDDVD-V

DVD-V

2

2

1

1: Natural effect.
2: Emphasized effect.
OFF: No effects (original sound).

3

3

MODE

Press twice (once for CD and MP3/WMA).

Hint

Hint

For CD playback only

• Virtual Surround will not be effective if the
sound mode is set to something other than
STEREO. Refer to “Stereo Sound Mode”.

PLAY

RETURN

ENTERENTERENTER

PLAY

AUDIO

2

2

OFF

ON: Makes the dark areas brighter.
OFF: Shows the original picture as recorded.

3

3

RETURN

ENTERENTERENTER

Hint

Hint

• Some discs will only allow you to change
the audio setting from the disc menu. Refer
to the manual accompanying the discs for
details.

PLAY

PLAY

MODE

–17–

EN

Functions

–17–

EN

–17–

EN

ENTERENTERENTER

Hint

Hint

∗1

• Language options are not available
with some discs.

• If “OTHER” is selected in the “AUDIO,
SUBTITLE” or “DISC MENU” screen,
press four-digit number to enter the
code for the desired language. (Refer
to the language code list on page 22.)

• Only the languages supported by the
disc can be selected.

∗2

• Language setting for Audio and
Subtitle are not available with some
discs. Then press

[AUDIO] and

[SUBTITLE]. Details are on page 16.

LANGUAGE Setting

Follow steps 1 to 3 in the “CUSTOM Menu” section above.

4

4

Select the desired item.

6

6 To exit the menu

5

5

AUDIO ∗∗1 ∗∗2
(Default: ORIGINAL)

Sets the audio language.

SUBTITLE:∗∗1 ∗∗2
(Default: OFF)

Sets the subtitle language.

DISC MENU:∗∗1
(Default: ENGLISH)

Sets the language in DVD
menu.

PLAYER MENU:
(Default: ENGLISH)

Sets the language for the
On-Screen Display.

QUICK

ENTERENTERENTER

SETUP

QQUICK SETUP Men

UICK SETUP Menuu

Select the desired language.

A

<

LANGUAGE” menu

>

DVD Setup

ENTER

AUDIO ORIGINAL
SUBTITLE OFF
DISC MENU ENGLISH
PLAYER MENU ENGLISH

LANGUAGE

or

or

2

2

Select the desired item.

1

1

QUICK SETUP

PLAYER MENU ENGLISH
TV ASPECT

4:3 LETTER BOX
PROGRESSIVE OFF
DOLBY DIGITAL BITSTREAM

ENTER

SETUP

STOP

QUICK SETUP

PLAYER MENU ENGLISH
TV ASPECT

4:3 LETTER BOX
PROGRESSIVE OFF
DOLBY DIGITAL BITSTREAM

•

Refer to the sections “PLAYER MENU”, “TV ASPECT”,
“PROGRESSIVE or “DOLBY DIGITAL” on pages 17-19.

<SETUP MENU>

Confirm that “QUICK” is selected.

You can select the “PLAYER MENU”, “TV ASPECT”, “PROGRESSIVE” or “DOLBY DIGITAL” from the QUICK SETUP menu quickly.

ENTERENTERENTER

P17 Step 5
P18 Step 5
P18 Step 5
P19 Step 5

A

B
B

ENTERENTERENTER

or

C

3

3

2

2

ENTER

AUDIO ORIGINAL
SUBTITLE OFF
DISC MENU ENGLISH
PLAYER MENU ENGLISH

LANGUAGE

Select “CUSTOM”.

QUICK SETUP

PLAYER MENU ENGLISH
TV ASPECT

4:3 LETTER BOX
PROGRESSIVE OFF
DOLBY DIGITAL BITSTREAM

Select the desired item.

1

1

ENTERENTERENTER

CUST

CUST

OM Men

OM Menuu

ENTERENTERENTER

SETUP

STOP

OTHERS

ENTER

ANGLE ICON ON
AUTO POWER OFF

ON

PANEL DISPLAY BRIGHT

AUDIO

DRC

ON

DOWN SAMPLING

ON

DOLBY DIGITAL

BITSTREAM

ENTER

DISPLAY

TV ASPECT 4:3 LETTER BOX
STILL MODE AUTO
PROGRESSIVE OFF
PROGRESSIVE MODE

AUTO 1
FORMAT RGB
RGB RANGE NORMAL

ENTER

ENTER

AUDIO ORIGINAL
SUBTITLE OFF
DISC MENU ENGLISH
PLAYER MENU ENGLISH

LANGUAGE

You can change the settings of the DVD/CD player.

•

on pages 17-20 indicates DVD Setup menus also accessible from the QUICK SETUP menu.

QUICK

<SETUP MENU>

LANGUAGE menu

AUDIO menu

DISPLAY menu

OTHERS menu

page 17

A

page 18

B

page 19

C

page 20

E

ENTER

PARENTAL LEVEL ALL

PARENTAL menu

page 19

D

QUICK SETUP

PLAYER MENU ENGLISH
TV ASPECT

4:3 LETTER BOX
PROGRESSIVE OFF
DOLBY DIGITAL BITSTREAM

or or

AUDIO

ORIGINAL
ENGLISH
FRENCH

SUBTITLE

OFF
ENGLISH
FRENCH

DISC MENU

ENGLISH
FRENCH
SPANISH

PLAYER MENU

ENGLISH
FRANÇAIS
ESPAÑOL

4

4

DISPLAY

TV ASPECT 4:3 LETTER BOX
STILL MODE AUTO
PROGRESSIVE OFF
PROGRESSIVE MODE

AUTO1
FORMAT RGB
RGB RANGE NORMAL

ENTER

–18–

EN

Functions

DISPLAY Setting

You can change the display functions. Follow steps 1 to 3 in the “CUSTOM Menu” section on page 17.

Select the desired item.

B

DISPLAY menu

5

5

TV ASPECT:
(Default: 4:3 LETTER BOX)

See Hint to the right.

QUICK

TV ASPECT

4:3

LETTER BOX

4:3

PAN & SCAN

16:9

WIDE

16:9

SQUEEZE

TV ASPECT

4:3 LETTERBOX

STILL MODE

AUTO

PROGRESSIVE

OFF

PROGRESSIVE MODE

AUTO 1
FORMAT RGB
RGB RANGE NORMAL

Select the
desired
setting.

or

ENTERENTERENTER

ENTERENTERENTER

or

6

6 To confirm the

PROGRESSIVE
scanning mode

5

5

PROGRESSIVE:
(Default: OFF)

See Hint to the right.

QUICK

TV ASPECT

4:3 LETTERBOX

STILL MODE

AUTO

PROGRESSIVE OFF

PROGRESSIVE MODE

AUTO 1
FORMAT RGB
RGB RANGE NORMAL

4:3 LETTERBOX
AUTO
ON

AUTO 1
RGB
NORMAL

ENTERENTERENTER

SETUP

Select
YES.

or

ENTERENTERENTER

Select
YES.

or

If you do not press any buttons
for 15 seconds, Progressive
Scan will switch to “OFF”.

If “PROGRESSIVE” is “ON”,
this message appears:

ENTERENTERENTER

ENTERENTERENTER

STILL MODE:
(Default: AUTO)

See Hint to the right.

TV ASPECT

4:3 LETTERBOX

STILL MODE

AUTO

PROGRESSIVE

OFF

PROGRESSIVE MODE

AUTO 1
FORMAT RGB
RGB RANGE NORMAL

STILL MODE

AUTO
FIELD
FRAME

Select the
desired
setting.

or

ENTERENTERENTER

PROGRESSIVE MODE:
(Default: AUTO1)

See Hint to the right.

TV ASPECT

4:3 LETTERBOX

STILL MODE

AUTO

PROGRESSIVE

OFF

PROGRESSIVE MODE

AUTO 1
FORMAT RGB
RGB RANGE NORMAL

PROGRESSIVE MODE

AUTO1
AUTO2
VIDEO1
VIDEO2
VIDEO3

Select the
desired
setting.

or

ENTERENTERENTER

ENTERENTERENTER

FORMAT

:

(Default: RGB)

See Hint to the right.

4:3 LETTERBOX
AUTO

OFF
AUTO1
YCbCr
NORMAL

TV ASPECT

4:3 LETTERBOX

STILL MODE

AUTO

PROGRESSIVE

OFF

PROGRESSIVE MODE

AUTO 1
FORMAT RGB
RGB RANGE NORMAL

RGB RANGE

:

(Default: NORMAL)

See Hint to the right.

4:3 LETTERBOX
AUTO

OFF
AUTO1
RGB
ENHANCED

TV ASPECT

4:3 LETTERBOX

STILL MODE

AUTO

PROGRESSIVE

OFF

PROGRESSIVE MODE

AUTO 1
FORMAT RGB
RGB RANGE NORMAL

ENTERENTERENTER

ENTERENTERENTER

Hint

Hint

TV ASPECT:

• Select “4:3 LETTER BOX”,
so that black bars may
appear on the top and bot­tom of the screen.

• Select “4:3 PAN & SCAN”
for a full height picture with
both sides adjusted.

• Select “16:9 WIDE” if a
wide-screen TV is connect­ed to this unit.

•

Select “16:9 SQUEEZE” when
the TV screen is too large
horizontally at “16:9 WIDE”
setting and when it is possible
to adjust the screen size
using the TV’s controls.

STILL MODE:

• Select “AUTO” usually.

•

If you select AUTO, automati­cally select the best resolution
setting (FRAME or FIELD)
based on the data characteris­tics of the pictures. (default)

• If you select “FIELD”, the
picture in the still mode will
be stabilized.

• If you select “FRAME”, the
picture in the still mode will
be highly defined.

•

An individual picture on TV
screen is called a “frame”, which
consists of two separate images
called as “field”.
Some pictures may be blurred at
the AUTO setting in the still mode
due to their data characteristics.

PROGRESSIVE MODE:

•

You can select a mode below
for the progressive scan output.

•

AUTO1: mode suitable for

images on the film
material.

•

AUTO2: mode for images on

the material of 30­frame film.

•

VIDEO1: mode for normal video

material.

•

VIDEO2: mode for video

material with less
movements.

•

VIDEO3: mode for video

material with many
movements.

FORMAT:

•

Select an HDMI output mode
between YCbCr and RGB.

•

When the connected equipment
is not compatible with YCbCr,
HDMI signal is output as RGB
regardless of the setting.

•

This setting is effective only when
you use the HDMI connection.

RGB RANGE:

•

Select a HDMI picture mode
between NORMAL and
ENHANCED.

•

Select ENHANCED if the black­white contrast is not clear.

•

This setting is effective only for
HDMI RGB output.

PROGRESSIVE:

•

You can set “PROGRESSIVE”
to “OFF” either in the Display
menu or by pressing and hold­ing [PLAY BB] on the front of the
unit for more than 5 seconds.

•

When “PROGRESSIVE” is “ON”,
video signals from VIDEO OUT
and S-VIDEO OUT jacks will be
distorted or not be output at all.

6

6 To exit

the menu

SETUP

Confirm again to use progressive scan.

If Picture is good, Select “YES”.

SET:ENTER

SELECT: K / L

NO
YESNOYES

Before proceeding…

1. Make sure your TV has progressive scan.

2. Connect with component video cable

NOTE: If there is no picture or picture is

distorted after selecting “YES”,
wait about 15 seconds for auto recovery.

Activate Progressive?

SELECT: K / L SET:ENTER

NO
YES

5

5

–19–

EN

Functions

4

4

AUDIO

DRC

ON

DOWN SAMPLING

ON

DOLBY DIGITAL

BITSTREAM

ENTER

AUDIO Setting

Choose the appropriate audio settings for your equipment. It only affects during the playback of DVD discs. Follow steps 1 to
3 in the “CUSTOM Menu” section on page 17.

Select the desired item.

C

<

AUDIO menu

>

Hint

Hint

DRC:

• This function is available
only on the discs which
are recorded in the Dolby
Digital format.

DOWN SAMPLING:

• When playing disc with
copyright protection, the
sound will be down sam­pled at 48kHz, even if
you set to “OFF”.

• This function is available
only on digital outputting
of a disc recorded in
96kHz.

6

6

To exit the menu

SETUP

DRC (Dynamic Range Control):
(Default: ON)

Set to “ON” to compress the range between soft and loud sounds.

DOLBY DIGITAL:
(Default: BITSTREAM)

Set to “BITSTREAM” when the unit is connected to a Dolby Digital receiver.

• BITSTREAM: Outputs a Dolby Digital Signals.

• PCM: Convert the Dolby Digital into PCM (2 channel).

QUICK

DRC ON
DOWN SAMPLING

ON

DOLBY DIGITAL BITSTREAM

OFF
ON
BITSTREAM

DOWN SAMPLING:
(Default: ON)

Set to “ON” when outputting in 48kHz.
Set to “OFF” when outputting the original sound.

DRC ON
DOWN SAMPLING

ON

DOLBY DIGITAL BITSTREAM

ON
ON

PCM

DRC ON
DOWN SAMPLING

ON

DOLBY DIGITAL BITSTREAM

ON
OFF
BITSTREAM

ENTERENTERENTER

ENTERENTERENTER

ENTERENTERENTER

or

ENTER

4

4

PASSWORD

ENTER

5

5

PARENTAL Setting

Parental Control limits the disc viewing that exceed your settings. (An incorrect password will be not acceptable.)
This feature prevents your children from viewing inappropriate materials.

PParental

arentalLeLe

vels

vels

Parental Level allows you to set the rating levels of your DVD discs. Playback will stop if the ratings exceed the levels you set.
Follow steps 1 to 3 in the “CUSTOM Menu” section on page 17.

ENTERENTERENTER

ENTERENTERENTER

Select “PARENTAL
LEVEL”.

Enter your desired four­digit password (except
for 4737).

D

<

PARENTAL menu

>

PASSWORD CHANGE

PARENTAL LEVEL ALL

7

7

SETUP

6

6

Select the
desired level.

PARENTAL LEVEL
ALL

8
7 [NC-17]
6 [R]

To exit
the menu

If you have set a password already,

enter the current four-digit
password.

or

or

ENTERENTERENTER

123

456

789

0

CONTROL LEVELS

• ALL: All parental locks are cancelled.

• Level 8: DVD softwares of any grades (adult/general/children) can be played back.

• Levels 7 to 2:

Only DVD softwares intended for general use and children can be played back.

• Level 1: Only DVD softwares intended for children can be played back, with those
intended for adult and general use prohibited.

TIPS FOR LEVELS

• 7 [NC-17]: No one under 17 admitted

• 6 [R]: Restricted; under 17 requires accompanying parent or adult guardian

• 4 [PG13]: Unsuitable for children under 13

• 3 [PG]: Parental Guidance suggested

• 1 [G]: General Audience

Hint

Hint

• DVD-Video discs may not respond to the parental lock settings. Make sure this function

works with your DVD-Video discs.

or

Instructions continue on the next page.

2

2

4

4

PASSWORD

ENTER

QUICK SETUP

PLAYER MENU ENGLISH
TV ASPECT

4:3 LETTER BOX
PROGRESSIVE OFF
DOLBY DIGITAL BITSTREAM

OK

QUICK SETUP

PLAYER MENU ENGLISH
TV ASPECT

4:3 LETTER BOX
PROGRESSIVE OFF
DOLBY DIGITAL BITSTREAM

OK

–20–

EN

Functions

OTHERS Setting

E

6

6

4

4

Hint

Hint

•

Record the password in case
you forget it.

•

If you forget the password,
press

[4], [7], [3], [7] at step 4,

then enter your new password.

•

Password will be cleared and
parental levels will be set to “ALL”.

ENTER

TTo Chang

o Chang

e the P

e the P

ass

asswworor

d f

d f

or P

or P

arental Contr

arental Contr

ols

ols

You can change your password for parental controls. Follow steps 1 to 3 in the “CUSTOM Menu” section on page 17.

5

5

Select “PASSWORD
CHANGE”.

PASSWORD CHANGE

PARENTAL LEVEL ALL

7

7

Enter your new
four-digit password
(except for 4737).

To exit
the menu

Enter your desired four­digit password (except
for 4737).

<

PARENTAL menu

>

or

ENTERENTERENTER

ENTERENTERENTER

SETUP

123

456

789

0

123

456

789

0

5

5

You can change the other functions. Follow steps 1 to 3 in the “CUSTOM Menu” section on page 17.

4

4

Select the desired item

<

OTHERS menu

>

6

6 To exit the menu

ANGLE ICON:

(Default: ON)

Set to “ON” to show the angle icon when multiple camera angles are
available during DVD playback.

AUTO POWER OFF:

(Default: ON)

Set to “ON” to turn this unit off automatically after 30 minutes of no use.

ANGLE ICON ON
AUTO POWER OFF

ON

PANEL DISPLAY BRIGHT

ON
OFF

ANGLE ICON ON
AUTO POWER OFF

ON

PANEL DISPLAY BRIGHT

OFF
ON

OTHERS

ENTER

ANGLE ICON ON
AUTO POWER OFF

ON

PANEL DISPLAY BRIGHT

SETUP

or

Select the
desired
setting

or

ENTERENTERENTER

ANGLE ICON ON
AUTO POWER OFF

ON

PANEL DISPLAY BRIGHT

PANEL DISPLAY
BRIGHT
DIMMER
AUTO

ENTERENTERENTER

Hint

Hint

PANEL DISPLAY:

• When AUTO is selected,
the display dims only during
playback.

PANEL DISPLAY:

(Default: BRIGHT)

This adjusts the brightness of the panel display.
See Hint to the right.

Hint

Hint

•

When you cancel
to initialize at step
3, select “NO”.

Reset to the Default Setting (Except for PARENTAL Setting)

Select “INITIALIZE”.

Select “YES”.

INITIALIZE

Initialize?

NO
YES

ENTER

<SETUP MENU>

SETUP

To exit
the menu

Press
twice.

SETUP

STOP

ENTERENTERENTER

ENTERENTERENTER

or

or

ENTER

ENTER

1

1

3

3

ENTER

ENTER

ENTER

ENTER

–21–

EN

Information

Troubleshooting Guide

Problem Solution

No power –Check if the AC power cord is properly connected.

–Unplug the outlet once, and wait for 5-10seconds and then plug it in again.

No sound or picture – Check if the TV is switched on.

–Check the video connection and HDMI.
–

Check the VIDEO/AUDIO cable connections to the TV. (See Connection to a TV.)

– When signals are output from the HDMI OUT jack, signals (interlace/pro-

gressive) are not output from the COMPONENT VIDEO OUT jacks. Press
the HDMI button on the front panel to set the HDMI output mode to “OFF”.

–

Set PROGRESSIVE correctly. Turn it on only if your TV has Progressive
Scan and you are using the Component Video connections between the unit
and the TV. Disable Progressive Scan for all other connections. (See page 6.)

Distorted picture –Sometimes a small amount of picture distortion may appear.

This is not a malfunction.

–Connect the unit directly to the TV.

Completely distorted picture or –Connect the unit directly to the TV.
black/white picture with DVD – Make sure the disc is compatible with the unit.

–

Check if the INTERLACE/PROGRESSIVE mode is set correctly. (See pages 17-18.)

No sound or distorted sound –Adjust the volume.

– Check that the speakers are connected correctly.

No audio at digital output – Check the digital connections.

–Check if the audio format of the selected audio language matches your

receiver capabilities.

No DTS audio is output –This unit does not support DTS audio.

This is not a malfunction.

No image from HDMI connection –

Check the HDMI connection. (Check the status of the HDMI related indications.)

–Check whether the connected monitor equipment or other equipment

supports HDCP. (This player will not output a video signal unless the other

equipment supports HDCP.)
– Check the setting of HDMI.
– Check whether the output format of this player (HDMI FORMAT) matches the

supported input format of other connected equipment.

Picture freezes momentarily – Check the disc for fingerprints/scratches and clean with a soft cloth wiping
during playback from center to edge.

–Clean the disc.

Disc can’t be played –Clean the disc.

– Ensure the disc label is facing up.
– Check if the disc is defective by trying another disc.
– Cancel the parental lock or change the control level.
– Insert a correct disc that plays on this unit.
–Handle a disc with special care so that it does not have fingerprints,

scratches, or dusts on its surface.

No return to start-up screen when disc is removed

– Reset the unit by switching the unit off, then on again.

The unit does not respond to –

Aim the remote control directly at the sensor on the front of the unit.

the remote control – Reduce the distance to the unit.

– Replace the batteries in the remote control.
– Re-insert the batteries with their polarities (+/– signs) as indicated.
–Tune your radio to an empty AM station so that you hear a lot of noises.

Then, turn the volume up. If you hear some signal sound from the radio by

pressing buttons on the remote control, the remote control is working.

Buttons do not work or the unit stops –To completely reset the unit, unplug the AC
responding cord from the AC outlet for 5-10 seconds.
The unit does not respond to some – Operations may not be permitted by the disc.
operating commands during playback Refer to the instructions of the disc.
The unit cannot read CDs/DVDs –Use a commonly available cleaning CD/DVD to clean the lens before send-

ing the unit for repair.

Angle does not switch –

The angle cannot be switched for DVDs which do not contain multiple

angles. In some cases multiple angles are only recorded for specific scenes.

Playback does not start when the title is selected

– Check the “PARENTAL” setting.

The password for rating level has been forgotten–Enter the default password “4737”, then your forgotten password will be cleared.

If the unit does not perform properly when operated as instructed in this Owner’s Manual, check the unit consulting the following checklist.

NOTES:

• Some functions are not available in specific modes, but this is not a malfunction.Read the description in this Owner’s Manual
for more details on correct operations.

• Playback from a desired track and random playback are not available during program playback.

• Some functions are prohibited on some discs.

Information

–22–

EN

Information

Language Code List

Output signal format:

NTSC color

Power source:

120 V AC +/- 10%, 60 Hz +/- 0.5%

Power consumption:

14 W (standby: 0.8 W)

Operating temperature:

41°F (5°C) to 104°F (40°C)

Dimensions:

W : 17 1/16" (433 mm)

H : 2 3/8” (61 mm)

D : 11 13/16"(300 mm)

Weight :

Approx 5.1 lbs (2.3 kg)

• Designs and specifications are subject
to change without notice.

• If there is a discrepancy between lan­guages, the default language will be
English.

Specifications

A-B

Abkhazian 4748
Afar 4747
Afrikaans 4752
Albanian 6563
Amharic 4759
Arabic 4764
Armenian 5471
Assamese 4765
Aymara 4771
Azerbaijani 4772
Bashkir 4847
Basque 5167
Bengali;Bangla 4860
Bhutani 5072
Bihari 4854
Bislama 4855
Breton 4864
Bulgarian 4853
Burmese 5971
Byelorussian 4851

C-E

Cambodian 5759
Catalan 4947
Chinese [CHI] 7254
Corsican 4961
Croatian 5464
Czech 4965
Danish [DAN] 5047
Dutch [DUT] 6058
English [ENG] 5160
Esperanto 5161
Estonian 5166

F-H

Faroese 5261
Fiji 5256
Finnish [FIN] 5255

French [FRE] 5264
Frisian 5271
Galician 5358
Georgian 5747
German [GER] 5051
Greek [GRE] 5158
Greenlandic 5758
Guarani 5360
Gujarati 5367
Hausa 5447
Hebrew 5569
Hindi 5455
Hungarian [HUN] 5467

I-K

Icelandic [ICE] 5565
Indonesian 5560
Interlingua 5547
Interlingue 5551
Inupiak 5557
Irish [IRI] 5347
Italian [ITA] 5566
Japanese [JPN] 5647
Javanese 5669
Kannada 5760
Kashmiri 5765
Kazakh 5757
Kinyarwanda 6469
Kirghiz 5771
Kirundi 6460
Korean [KOR] 5761
Kurdish 5767

L-N

Laothian 5861
Latin 5847
Latvian;Lettish 5868
Lingala 5860
Lithuanian 5866

Macedonian 5957
Malagasy 5953
Malay 5965
Malayalam 5958
Maltese 5966
Maori 5955
Marathi 5964
Moldavian 5961
Mongolian 5960
Nauru 6047
Nepali 6051
Norwegian [NOR] 6061

O-R

Occitan 6149
Oriya 6164
Oromo(Afan) 6159
Panjabi 6247
Pashto;Pushto 6265
Persian 5247
Polish 6258
Por tuguese [POR] 6266
Quechua 6367
Rhaeto-Romance 6459
Romanian [RUM] 6461
Russian [RUS] 6467

S

Samoan 6559
Sangho 6553
Sanskrit 6547
Scots Gaelic 5350
Serbian 6564
Serbo-Croatian 6554
Sesotho 6566
Setswana 6660
Shona 6560
Sindhi 6550
Singhalese 6555

Siswat 6565
Slovak 6557
Slovenian 6558
Somali 6561
Spanish [SPA] 5165
Sundanese 6567
Swahili 6569
Swedish [SWE] 6568

T

Tagalog 6658
Tajik 6653
Tamil 6647
Tatar 6666
Telugu 6651
Thai 6654
Tibetan 4861
Tigrinya 6655
Tonga 6661
Tsonga 6665
Tu rkish [TUR] 6664
Tu rkmen 6657
Tw i 6669

U-Z

Ukrainian 6757
Urdu 6764
Uzbek 6772
Vietnamese 6855
Volapuk 6861
Welsh 4971
Wolof 6961
Xhosa 7054
Yiddish 5655
Yo r uba 7161
Zulu 7267

Language Code Language Code Language Code Language Code

If you choose a Language that has a 3 letter language code, the code will be displayed every time you change the Audio or Subtitle language
setting on page 16. If you choose any other languages, ‘---’ will be displayed instead. (3 letter language code is written in bracket.)

✄

Limited Warranty

FUNAI CORP. will repair this MAGNAVOX product, free of charge in
the USA in the event of defect in materials or workmanship as follows:

DURATION:
PA RTS:

FUNAI CORP. will provide parts to replace defective
parts without charge for one (1) year from the date of
original retail purchase. Certain parts are excluded
from this warranty.

LABOR: FUNAI CORP. will provide the labor without charge for

a period of ninety (90) days from the date of original
retail purchase.

LIMITS AND EXCLUSIONS:

This warranty is extended only to the original retail purchaser. A pur­chase receipt or other proof of original retail purchase will be required
together with the product to obtain service under this warranty.

This warranty shall not be extended to any other person or transferee.
This warranty is void and of no effect if any serial numbers on the

product are altered, replaced, defaced, missing or if service was
attempted by an unauthorized service center. This MAGNAVOX
Limited warranty does not apply to any product not purchased and
used in the United States.

This product is produced for home use and this warranty only covers
failures due to defects in material or workmanship which occurs dur­ing normal use. It does not cover damage which occurs in shipment,
or failures which are caused by repairs, alterations or product not
supplied by FUNAI CORP., or damage which results from accident,
misuse, abuse, mishandling, misapplication, alteration, faulty installa­tion, improper maintenance, commercial use such as hotel, rental or
office use of this product or damage which results from fire, flood,
lightning or other acts of God.

THIS WARRANTY DOES NOT COVER PACKING MATERIALS, ANY
ACCESSORIES (EXCEPT REMOTE CONTROL), ANY COSMETIC
PA RTS, COMPLETE ASSEMBLY PARTS, DEMO OR FLOOR MODELS.

FUNAI CORP. AND ITS REPRESENTATIVES OR AGENTS SHALL
IN NO EVENT BE LIABLE FOR ANY GENERAL, INDIRECT OR
CONSEQUENTIAL DAMAGES ARISING OUT OF OR OCCA­SIONED BY THE USE OF OR THE INABILITY TO USE THIS PROD­UCT. THIS WARRANTY IS MADE IN LIEU OF ALL OTHER WAR­RANTIES, EXPRESS OR IMPLIED, AND OF ALL OTHER LIABILI­TIES ON THE PART OF FUNAI, ALL OTHER WARRANTIES
INCLUDING THE WARRANTY OF MERCHANTABILITY, AND FIT­NESS FOR A PARTICULAR PURPOSE, ARE HEREBY DIS­CLAIMED BY FUNAI AND ITS REPRESENTATIVES IN THE UNIT­ED STATES. ALL WARRANTY INSPECTIONS AND REPAIRS MUST
BE PERFORMED BY A FUNAI AUTHORIZED SERVICE CENTER.
THIS WARRANTY IS VALID WHEN THE UNIT IS CARRIED-IN TO A
FUNAI AUTHORIZED SERVICE CENTER.

IMPORTANT:

THIS LIMITED WARRANTY GIVES YOU SPECIFIC LEGAL RIGHTS.
YOU MAY HAVE OTHER RIGHTS THAT VARY FROM STATE TO
STATE. IF, AT ANY TIME DURING THE WARRANTY PERIOD, YOU
ARE UNABLE TO OBTAIN SATISFACTION WITH THE REPAIR OF
THIS PRODUCT, PLEASE CONTACT FUNAI CORP.

ATTE NTION:

FUNAI CORP. RESERVES THE RIGHT TO MODIFY ANY DESIGN
OF THIS PRODUCT WITHOUT PRIOR NOTICE.

To locate your nearest AUTHORIZED SERVICE CENTER or for general
service inquiries, please contact us at:

FUNAI CORPORATION

Customer Service

Tel :[phone]

http://www.funai-corp.com

19900 Van Ness Avenue, Torrance, CA 90501

4

4 Para salir del menú.

3

3

2

2

–23–

EN

Español

✄

1

3

2

1

1

1

Ponga un
disco con
la
etiqueta
hacia
arriba.

Si su televisor tiene entradas
de AUDIO/VIDEO vea la sec­ción “Connection to a TV” en la
página 6 en el Manual de
Manejo. En caso contrario, vea
la sección “Before Using Your
Unit” en la página del frente en
el Manual de Manejo.

STANDBY-ON

AUDIO

SUBTITLE

ANGLE

REPEAT

CLEAR

A-B

PAUSE

SLOW

SKIP

OPEN/CLOSE

DISPLAY

SEARCH

MODE

123

456

789

0 +10

PLAY

REV FWD

STOP

Español

WMAWMA

WMA

MP3MP3

MP3

CDCDCDDVD-V

DVD-V

Conexiones

SETUP

Seleccione el idioma deseado para las
indicaciones en la pantalla.

Para cambiar el idioma
en la pantalla

Reproducción

4

Confirme que ha seleccionado
“PLAYER MENU”.

QUICK SETUP

PLAYER MENU ENGLISH
TV ASPECT

4:3 LETTER BOX
PROGRESSIVE OFF
DOLBY DIGITAL BITSTREAM

OK

ENTERENTERENTER

ENTERENTERENTER

ENTERENTERENTER

1

1

4

4

3

3

Antes:

¡

Encienda el televisor, amplificador y
otros equipos conectados a esta
unidad. Asegúrese que el televisor y el
sintonizador de audio (de venta en los
comercios) están en el canal correcto.

• Para encender o apagar la
unidad.

• Para encender o apagar la
unidad.

•

Para indicar el modo de
disco actual o modo de HDMI.

•

Para indicar el modo de
disco actual o modo de HDMI.

• Para abrir o cerrar la bandeja
del disco.

• Para abrir o cerrar la bandeja
del disco.

• Para hacer una pausa en la
reproducción del disco.

• Para empezar la
reproducción del disco.

• Para empezar la
reproducción del disco.

• Para seleccionar
directamente el capítulo o
título.

• Para seleccionar
directamente la canción.

• Para seleccionar los ángulos
de cámara en un disco.

• Para seleccionar subtítulos
en un disco.

• Para seleccionar idiomas de
audio en un disco.

•

Para seleccionar ESTÉREO
L-ch o R-ch.

(CD)

• Para repetir entre su punto A
y B seleccionado.

•

Para repetir entre su punto A y B
seleccionado.(CD)

• Para reproducir
repetidamente un capítulo o
título.

• Para reproducir repetidamente
una canción o disco.(CD)

•

Para reproducir repetidamente una
canción, grupo o disco. (MP3/WMA)

• Para activar/desactivar el
nivel del negro.

• Para activar/desactivar el
ambiental virtual.

•

Para disponer el orden de reproducción
o la reproducción aleatoria.

• Para activar/desactivar el
ambiental virtual.

• Para llamar el Menú en un
disco.

• Para llamar el menú inicial
en un disco.

• Para ampliar parte de la
imagen. (x2/x4)

• Para volver a la operación
anterior en el menú.

• Para volver a la operación
anterior en el menú.

• Para buscar un capítulo, título
o tiempo.

• Para colocar o buscar los
marcadores.

• Para buscar una canción.

• Para buscar el tiempo.

(CD)

•

Para colocar o buscar los
marcadores.

(CD)

• Para borrar los marcadores.

• Para borrar los números mal

entrados.

• Para borrar el punto para la
repetición A-B.

• Para borrar los marcadores.
(CD)

•

Para eliminar el Nº de estado
en la entrada de programa.

• Para borrar los números mal
entrados.

• Para borrar el punto para la
repetición A-B.

(CD)

•

Para buscar en avance/
retroceso por un disco.

•

Para empezar la reproducción
en avance lento/retroceso
durante el modo de pausa.

• Para buscar en avance/
retroceso por un disco.

•

Para hacer una pausa en la reproducción.

•

Para avanzar la reproducción un cuadro
cada vez.

• Para parar la reproducción. • Para parar la reproducción.

• Para saltar capítulos. • Para saltar canciones.

• Para llamar el menú de

ajustes de DVD.

• Para llamar el menú de
ajustes de DVD.

• Para mover el cursor y
determinar la posición.

• Para mover el cursor y
determinar la posición.

STANDBY-ON

DISPLAY

MENU

TOP MENU

ZOOM

SUBTITLE

MODE

ANGLE

SEARCH

MODE

REPEAT

A-B

AUDIO

CLEAR

123

456

789

0

+1 0

PAUSE

PLAY

STOP

SETUP

DVD-V

DVD-V

Botón

(Orden alfabético)

Disco

ENTER

RETURN

REV FWD

OPEN/CLOSE

SKIP

• Para llamar la lista de archivo
(MP3

/WMA

)

•

Para volver al archivo superior de la
j

erarquía más alta en el programa

y en la lista de archivo. (MP3/WMA)

CD

CD

MP3

MP3

WMA

WMA

Control remoto

5

QUICK SETUP

PLAYER MENU ENGLISH
TV ASPECT

4:3 LETTER BOX
PROGRESSIVE OFF
DOLBY DIGITAL BITSTREAM

OK

SETUP

STOP

Confirme que ha selec­cionado “QUICK”.

Instalación de las pilas
en el control remoto

1

1

2

3

STANDBY-ON

o

1

1

3

3

4

4

2

2

STOP

STANDBY-ON

OPEN/CLOSE

PLAY

Para empezar
la reproducción

Para parar
la reproducción

PLAYER MENU

ENGLISH
FRANÇAIS
ESPAÑOL

1VMN21386 / E61J2UD ★★★★★

✄

Printed in China

STOP

Insert a
disc with
label
facing up.

If your TV has AUDIO/VIDEO
input jacks, see the section
“Connection to a TV” on page
6 of the Owner’s Manual. If not,
see the section “Before using
your Unit” on the front page of
the Owner’s Manual.

STANDBY-ON

AUDIO

SUBTITLE

ANGLE

REPEAT

CLEAR

A-B

PAUSE

SLOW

SKIP

OPEN/CLOSE

DISPLAY

SEARCH

MODE

123

456

789

0 +10

PLAY

REV FWD

STOP

Quick Use Guide

Connections

3

3

Select the desired language for the On­Screen Display.

1

To Change the On­Screen Language

3

Playback

4

2

2

Confirm that “PLAYER MENU”
is selected.

QUICK SETUP

PLAYER MENU ENGLISH
TV ASPECT

4:3 LETTER BOX
PROGRESSIVE OFF
DOLBY DIGITAL BITSTREAM

OK

1

1

4

4

3

3

Before:

¡

Tu rn on the TV, amplifier and any other equip­ment which are connected to this unit. Make
sure the TV and audio receiver (commercially
available) are set to the correct channel.

• To turn the unit on or off. • To turn the unit on or off.

• To display the current disc

or HDMI mode.

• To display the current disc
or HDMI mode.

• To open or close the disc
tray.

• To open or close the disc
tray.

• To select chapter or title
directly.

• To select track directly.

• To select camera angles on

a disc.

• To select subtitles on a disc.

• To select audio languages on

a disc.

• To select STEREO,
L-ch or R-ch.(CD)

• To repeat between your
chosen point A and B.

• To repeat between your
chosen point A and B.(CD)

• To play a chapter or title
repeatedly.

• To play a track or disc
repeatedly.(CD)

• To play a track, group or disc
repeatedly. (MP3/WMA)

• To return to the previous
operation in menu.

• To set black level on/off.

• To set virtual surround on/off.

• To arrange the playing

order or play randomly.

• To set virtual surround on/off.

• To call up the Menu

on a disc.

• To call up the Top Menu
on a disc.

• To magnify part of a picture.
(x2/x4)

• To return to the previous
operation in menu.

• To search chapter, title or time.

• To set or search the

markers.

• To search track.

• To search time. (CD)

• To set or search the

markers. (CD)

• To clear the markers.

• To clear the numbers

entered incorrectly.

• To cancel the point for A-B
repeat.

• To clear the markers.(CD)

• To remove status number

in program input.

• To clear the numbers
entered incorrectly.

• To cancel the point for A-B
repeat.(CD)

• To pause disc playback.

• To advance playback

one frame at a time.

• To pause disc playback.

• To stop playback. • To stop playback.

• To skip chapters. • To skip tracks.

• To begin disc playback. • To begin disc playback.

• To call up the DVD setup

menu.

• Only used to call up the
DVD setup menu.

• To move the cursor and
determine its position.

• To move the cursor and
determine its position.

STANDBY-ON

DISPLAY

MENU

TOP MENU

ZOOM

SUBTITLE

MODE

ANGLE

SEARCH

MODE

REPEAT

A-B

AUDIO

CLEAR

123

456

789

0

+1 0

PAUSE

PLAY

STOP

SETUP

DVD-V

DVD-V

Button

(Alphabetical order)

Disc

ENTER

RETURN

• To search forward/backward
through a disc.

• To begin slow forward
/reverse playback during
the pause mode.

• To search forward/backward
through a disc.

REV FWD

OPEN/CLOSE

SKIP

• To call up the file list.
(MP3/WMA)

•

To return to the top file of the
highest hierarchy in the program
and

file list

. (MP3/WMA)

CD

CD

MP3

MP3

WMA

WMA

Remote Control

5

1

1

QUICK SETUP

PLAYER MENU ENGLISH
TV ASPECT

4:3 LETTER BOX
PROGRESSIVE OFF
DOLBY DIGITAL BITSTREAM

OK

Confirm that “QUICK” is
selected.

Installing the Batteries
for the Remote Control

2

1

1

2

3

1

ENTERENTERENTER

ENTERENTERENTER

ENTERENTERENTER

SETUP

STOP

STANDBY-ON

or

WMAWMA

WMA

MP3MP3

MP3

CDCDCDDVD-V

DVD-V

1

1

3

3

4

4

2

2

STANDBY-ON

OPEN/CLOSE

PLAY

To start
playback

To stop
playback

4

4 To exit the menu.

SETUP

PLAYER MENU

ENGLISH
FRANÇAIS
ESPAÑOL
