Magnavox MRD733B Owner Manual

Download

Owner’s Manual

MRD733B

Blu-ray™ Home Cinema with Built-in WiFi

CONTENTS

INTRODUCTION ............................................. 4

Safety Instructions.................................................................4

Supplied Accessories............................................................4

FEATURES......................................................... 5

Features...................................................................................5

Product Info ...........................................................................6

Symbols Used in this Owner’s Manual.............................6

FUNCTIONAL OVERVIEW ............................7

Front Panel .............................................................................7

Rear Panel...............................................................................7

Remote Control....................................................................8

Guide to On-Screen Display........................................... 10

CONNECTIONS............................................. 12

Placing the Speakers.......................................................... 12

Connection to a TV .......................................................... 12

Connecting Speakers and Subwoofer ........................... 13

Connecting Audio from Cable Box / Recorder /

Game Console or TV ....................................................... 14

HDMI Audio¬Output......................................................... 15

Connection to the Network........................................... 17

BEFORE YOU START.................................... 19

Finding a Viewing Video Source Input on Your TV ... 19

Initial Setup..........................................................................19

INFORMATION ON PLAYBACK................. 21

Information on Playback...................................................21

Guide to File List................................................................ 25

How to Insert a Disc ........................................................ 25

Switching Subtitles..............................................................34

Switching Audio Soundtrack............................................35

Switching Camera Angles .................................................36

Black Level............................................................................36

Noise Reduction.................................................................36

CLEAR+................................................................................37

NETWORK FEATURES................................. 38

Before Using Network Features.....................................38

Information on Network Services..................................38

PANDORA® OPERATION ............................ 39

Activating Pandora .............................................................39

Adding Pandora User Accounts......................................39

Creating a New Pandora Station....................................40

Guide to the Player Screen ..............................................40

LIST OF SETTINGS ....................................... 41

SETUPS............................................................ 44

Network Connection........................................................44

fun-Link (HDMI CEC)........................................................49

Audio Input Mapping ........................................................50

HDMI Video Resolution....................................................50

Parental .................................................................................51

Software Update.................................................................52

Restore Default Settings...................................................54

SOUND SETTINGS........................................ 55

Volume Control..................................................................55

Selecting Surround Mode .................................................55

Selecting Sound Effect Mode............................................56

Audio Sync ...........................................................................56

Speaker Setup......................................................................56

BASIC PLAYBACK .........................................26

Playing Back a Disc ............................................................ 26

Playing Back Contents from a USB Memory Stick..... 27

Playing Back Video / Music / Photo from DLNA

Certified Home Media Servers....................................... 28

Using the Title / Disc / Pop Menu.................................. 29

SPECIAL PLAYBACK..................................... 30

Fast Forward / Fast Reverse............................................ 30

Slow Forward Playback..................................................... 30

Step by Step Playback........................................................ 30

Repeat Playback.................................................................. 31

Slide Show............................................................................ 31

PiP (BONUSVIEW™) Setting ......................................... 32

Enjoying BD-Live™ Discs Using Internet..................... 32

Title / Chapter Search ...................................................... 33

Track / File Search............................................................. 33

Time Search......................................................................... 34

EN - 2

OTHER SETTINGS ........................................ 57

Switching Active Source Mode........................................57

Sleep Timer..........................................................................57

TROUBLESHOOTING .................................. 58

LANGUAGE CODE LIST .............................. 62

SPECIFICATIONS.......................................... 63

NETWORK SERVICE DISCLAIMER............ 64

MAINTENANCE............................................. 65

TRADEMARK INFORMATION .................... 66

GLOSSARY ...................................................... 68

LIMITED WARRANTY ....................back cover

ESPAÑOL ........................................................ 70

Mando a Distancia.............................................................. 70

Encontrar el Canal de Video en su Televisor.............. 71

Instalacion Inicial................................................................. 72

EN - 3

1. INTRODUCTION

www.magnavox.com

1.1. Safety Instructions

To Avoid the Hazards of Electrical Shock and Fire

• Do not handle the AC power cord with wet hands.

• Do not pull on the AC power cord when disconnecting it from an AC outlet. Grasp it by the plug.

• Do not put your fingers or objects into the unit.

Location and Handling

• Do not install the unit in direct sunlight, near strong magnetic fields, or in a place subject to dust or strong vibration.

• Avoid a place with drastic temperature changes.

• Install the unit in a horizontal and stable position. Do not place anything directly on top or bottom of the unit. Depending on your external devices, noise or disturbance in the picture and/or sound may be generated if the unit is placed too close to them. In this case, please ensure enough space between the external devices and the unit.

• Depending on the environment, the temperature of this unit may increase slightly. This is not a malfunction.

• Be sure to remove the disc and unplug the AC power cord from the outlet before moving the unit.

Dew Condensation Warning

• Dew condensation may form inside the unit in the following conditions. If so, do not use this unit at least for a few hours until its inside gets dry.

- The unit is moved from a cold place to a warm place.

- Under conditions of high humidity.

- After heating a cold room.

Note about Recycling

• This unit’s packaging materials are recyclable and can be reused. Please dispose of any materials in accordance with your local recycling regulations.

• Batteries should never be thrown away or incinerated but disposed of in accordance with your local regulations concerning chemical wastes.

• For product recycling information, please visit Click on

Notice for Progressive Scan Output

• Consumers should note that not all high definition television sets are fully compatible with this product and may cause artifacts to be displayed in the picture. In case of picture problems with 480 progressive scan output, it is recommended that the user switch the connection to the ‘standard definition’ output. If there are questions regarding your TV set compatibility with this 480p Blu-ray Disc™/DVD player, please contact our customer service center.

1.2. Supplied Accessories

• Remote Control (NB993UD)

• Batteries (AAA, 1.5V × 2)

• SETUP MANUAL

• 1 center, 2 front, 2 rear speakers and 1 subwoofer

MAGNAVOX is a registered trademark of Philips Electronics North America Corporation and is used by Funai Electric Ltd. and Funai Corporation, Inc. under license from Philips Electronics North America. © 2012 Funai Electric Co., Ltd. All rights reserved. No part of this manual may be reproduced, copied, transmitted, disseminated, transcribed, downloaded or stored in any storage medium, in any form or for any purpose without the express prior written consent of Funai. Furthermore, any unauthorized commercial distribution of this manual or any revision hereto is strictly prohibited. Information in this document is subject to change without notice. Funai reserves the right to change the content herein without the obligation to notify any person or organization of such changes.

Co.,

EN - 4

2. FEATURES

www.netflix.com/Magnavox

2.1. Features

Blu-ray Disc™

You can enjoy Blu-ray Disc™ which is capable of storing five times more data than a conventional DVD.

BD-Java

With some Blu-ray discs which contain Java applications, you can enjoy interactive functions such as games or interactive menus.

DVD upscaling for enhanced picture quality

Your current DVD will look even better than before thanks to video upscaling. Upscaling will increase the resolution of standard definition DVD to high definition up to 1080p over an HDMI connection. The picture will be less jagged and more realistic for a near high definition experience.

Enjoy your content on different kinds of media

Full backwards compatibility with DVD, CD and USB Memory Stick ensures that you can continue to enjoy your current audio-video collection. Additionally, you can enjoy AVCHD (for DVD-RW/-R only) / MP3 / JPEG files.

Listen to rich multi-channel surround sound

Multi-channel surround sound, which realizes real-to-life sound and makes you feel that you are really there.

Easy and simple connection to your HDTV via HDMI

Connect this unit to your HDTV with one single HDMI (HighDefinition Multimedia Interface) cable. It is recommended to use a High Speed HDMI cable for better compatibility. The high definition video output signal will be transferred to your HDTV without conversion to analog signals, so you will get excellent picture and sound quality, completely free from noise. Thanks to other multiple outputs, you can also easily connect to your Home Cinema or amplifier.

fun-Link (HDMI CEC) (Consumer Electronics Control)

This unit supports fun-Link (HDMI CEC), which allows integrated system control over an HDMI cable and is part of the HDMI standard. This function may not work properly on some devices.

PiP (BONUSVIEW™)

Some BD-videos have the PiP function which enables you to display the Secondary Video in the Primary Video. You can call up the Secondary Video by pressing [MODE] whenever the scene contains a Secondary Video.

BD-Live™

BD-Live™ (BD-ROM version 2 Profile 2.0) that allows interactive functions to be used when this unit is connected to the Internet in addition to the BONUSVIEW™ function. The various functions differ depending on the disc.

Pop Menu

Some BD-videos have a Pop Menu which is a navigation menu that can be called up and be operated on the TV screen without interrupting playback. You can call up the Pop Menu by pressing [POP MENU/MENU]. Contents in the Pop Menu vary depending on the disc.

HDMI Deep Color

Deep Color reduces posterization (color banding) effect of the playback image.

HDMI 1080p/24 output (Blu-ray Disc™ only)

This unit is equipped with the feature which can provide smooth movement during playback of film originated material with the frame rate of 24 frames per second with progressive. (Available only when the display device is connected with an HDMI cable.) Refer to “HDMI Video Resolution” on page 50.

Playing back contents from a USB Memory Stick

You can play back MP3 / JPEG files stored on a USB Memory Stick. BD-ROM Profile 2.0 (BD-Live™) and Profile 1.1 discs sometimes store picture-in-picture commentary, subtitles or other extras on a USB Memory Stick for use during playback with the BD-video.

Playing back AVCHD files

This unit supports playback of AVCHD format files (new format for high definition video camcorders) recorded on a disc / SD Memory Card using USB card reader / USB hub (not supplied). Your high definition personal archive is playable in HD quality.

x.v.Color

This unit supports playback of video contents on discs recorded with “x.v.Color” technology. To watch this video content with the “x.v.Color” space, a TV or other display device supporting both video image reproduction using “x.v.Color” standard and capability of manual switching of its color space setting is required. Please refer to the user manual of your display device for further information.

Enjoy contents stored on DLNA certified home media servers

This unit is a DLNA certified media player that can play video, music and photo files stored on DLNA certified home media servers connected to your home network. (not warranted for wireless environment)

Netflix

With this unit, you can enjoy movies and TV episodes streamed instantly from Netflix via the Internet. In order to use this feature, you must visit on your PC and become a Netflix member. (This feature is only available in the United States.)

continued on next page

EN - 5

VUDU

www.vudu.com/product_overview.html

www.vudu.com

www.pandora.com/magnavox

This unit supports VUDU which is the leading HD ondemand video service. With VUDU, you can also enjoy various kinds of Internet applications. In order to use this feature, you must connect this unit to the Internet

(This feature is only

available in the United States.)

YouTube™

This unit enables you to access YouTube™. On your TV screen, you can enjoy a large number of video clips streamed from YouTube™.

Pandora

This unit supports Pandora internet radio service. You can instantly listen to free personalized radio stations streamed over the internet from Pandora. In order to use this feature, you must visit the below website on your PC and become a Pandora member. (This feature is only available in the United States.)

Digital Rights Management

This product contains technology subject to certain intellectual property rights of Microsoft.

Use or distribution of this technology outside of this product is prohibited without the appropriate license(s) from Microsoft.

internet radio

2.2. Product Info

“Product Info” screen provides information about this unit’s software version. You can also download the latest software from the Magnavox website and update it yourself if it is newer than the version currently on your unit. The current version of software on your unit can be seen on the “Product Info” screen. To access “Product Info”, follow the procedure below.

1. Press [HOME].

2. Use [] to select “Settings”, then press [OK].

3. Use [] to select “Others”, then press [OK].

4. Use [] to select “Product Info”, then press [OK].

2.3. Symbols Used in this Owner’s Manual

To specify which media type each function is applicable to, the following symbols that are at the beginning of each Symbol type.

Symbol Description

Description refers to BD-video

Description refers to DVD-video

Description refers to audio CD / DTS-CD

Description refers to DVD-RW/-R with AVCHD files

Description refers to BD-RE/-R, DVD-RW/-R, CD-RW/-R and USB Memory Stick with MP3 files

Description refers to BD-RE/-R, DVD-RW/-R, CD-RW/-R and USB Memory Stick with JPEG files

Description refers to video files in the DLNA Media Server

Description refers to music files in the DLNA Media Server

Description refers to photo files in the DLNA Media Server

If you do not find any of the symbols listed above under the function heading, the operation is applicable to all media.

EN - 6

3. FUNCTIONAL OVERVIEW

3.1. Front Panel

2* 3 4 5

* The unit can also be turned on by pressing this button.

1. Disc tray

2. (OPEN/CLOSE) button*

3. VOLUME button

4. Power-On indicator

• Flashes while unit is starting up.

• Dims and flickers when IR remote signal is received.

C Caution

• Do not connect any device other than USB Memory Stick or USB card reader into the USB Input. (e.g. PC, external HDD, MP3 player, digital camera, keyboard, mouse, etc.)

• When connecting a USB Memory Stick, connect it directly to the USB Input. Do not use a USB extension cable.

3.2. Rear Panel

)

SPEAKERS (3Ω

REAR FRONT

SUB

FRONT

R L RL

WOOFER

CENTER

LAN HDMI OUT

5. (POWER-ON) button

6. Infrared sensor window

7. USB Input

VIDEO

AUDIO IN

OUT

AUX

DIGITAL AUDIO IN

COAXIAL

1. AC power cord

2. 5.1ch Audio Out (SPEAKERS (3))

3. LAN terminal

5. VIDEO OUT jack

6. DIGITAL AUDIO IN (COAXIAL) jack

7. AUDIO IN (AUX) jacks

4. HDMI OUT jack

C Caution

• Do not touch the inner pins of the jacks on the rear panel. Electrostatic discharge may cause permanent damage to the unit.

• This unit does not have a TV RF modulator.

EN - 7

3.3. Remote Control

6 7*

8 9

The unit can also be turned on by pressing these buttons.

1. (POWER-ON) button

• Press to Turn On the unit, or to switch the unit into

Standby mode. (To completely Turn Off the unit, you must unplug the AC power cord.)

2. TOP MENU button Blu-ray Disc™: Press to display the Top Menu.

DVD: Press to display the Title Menu.

3. buttons

• Press to select items or settings.

4. MODE button

• During playback, press to display the Play Menu.

5. RED / GREEN / BLUE / YELLOW buttons

• Press to activate shortcut keys on some BD-video

functions. When a file list is shown, press to switch between pages.

6. (REVERSE) button

• During playback, press to Fast Reverse the playback.

13* 14

15 16

19 20

23 24

7. (PLAY) button*

• Press to start playback or resume playback.

8. (SKIP) button

• During playback, press once to return to the beginning of the current Title, Chapter, Track or File.

• During playback, press twice to return to the previous Title, Chapter, Track or File.

• During the JPEG playback, press to return to the previous File.

9. (STOP) button

• Press to Stop playback.

10. NUMBER buttons

• Press to select a Chapter during playback.

• Press to enter Numbers or letters in the input field.

11. NET APP button

• Press to display the network application menu.

12. NETFLIX button

• Press to launch Netflix.

13. (OPEN/CLOSE) button*

• Press to Open or Close the disc tray.

14. HOME button

• Press to display the Home Menu.

15. POP MENU/MENU button Blu-ray Disc™: Press to display the Pop Menu.

DVD: Press to display the Disc Menu.

16. OK button

• Press to confirm or select menu items.

17. RETURN button

• Press to Return to the previously displayed menu or

screen function.

18. (FORWARD) button

• During playback, press to Fast Forward the playback.

• When playback is in pause, press to Slow Forward

the playback.

19. (SKIP) button

• During playback, press to Skip to the next Chapter,

Track or File.

• When playback is in pause mode, press to Forward

the playback picture by picture.

20. (PAUSE) button

• Press to Pause playback.

21. VOL / button

• Press to adjust the volume.

22. MUTE button

• Press to Mute the volume.

EN - 8

23. SOURCE button

30˚ 30˚

• Press to switch the active Source mode; Home Menu (Disc / USB Memory Stick / Network), “Aux” and “Coaxial” .

24. DISPLAY button

• Press to Display the on-screen display menu.

25. VUDU button

• Press to launch VUDU.

D Note

• The Power-On indicator on the front panel dims and flickers when it receives the IR signal from the remote control.

• Use the supplied remote control. Remote-control operation on any other remote control, such as a universal remote control, is not guaranteed.

 Installing the Batteries in the Remote Control

Install 2 AAA (1.5V) batteries matching the polarity indicated inside battery compartment of the remote control.

 Using the Remote Control

Remote Control Usage Guidelines:

• Make sure that there are no obstacles between the remote control and the infrared sensor window on the unit.

• Remote operation may become unreliable if strong sunlight or fluorescent light is shining on the infrared sensor window of the unit.

• Remote controls of different devices can interfere with each other. Avoid using a remote control from another device which is located close to the unit.

• Replace the batteries when you notice a fall-off in the operating range of the remote control.

• The maximum operable ranges from the unit are as follows.

- Line of sight:

approx. 23 feet (7 m)

- Either side of the center:

approx. 16 feet (5 m) within 30°

-Above:

approx. 16 feet (5 m) within 15°

-Below:

approx. 10 feet (3 m) within 30°

C Caution

Incorrect use of batteries can result in hazards such as leakage and bursting. Please observe the following:

• Lithium or ni-cad and ni-mh rechargeable batteries are not recommended to use for remote control.

• Do not mix different types of batteries such as alkaline and standard (carbon-zinc).

• Do not mix new and old batteries together.

• Do not use different kinds of batteries together. Although they may look similar, different batteries may have different voltages.

• Make sure that the + and - ends of each battery match the indications in the battery compartment.

• Remove batteries from battery compartment, when the remote is not going to be used for a month or more.

• When disposing of used batteries, please comply with governmental regulations or environmental public rules that apply in your country or area.

• Do not recharge, short-circuit, heat, burn or disassemble batteries.

16 feet (5 m) 16 feet (5 m)23 feet (7 m)

EN - 9

3.4. Guide to On-Screen Display

 Home Menu When you Turn On the unit, Home Menu will appear automatically. Otherwise, press [HOME].

Disc

4 5 6

1. “Disc”: Initiates playback of inserted disc, displays a list of Tracks / Files or the Media Filter Menu.

2. “NET APP”: To access the menu of network services.

3. “USB Memory Stick”: Displays a list of Tracks / Files on the connected USB Memory Stick or the Media Filter

4. “Home Network”: To access the home network server (DLNA).

5. “Settings”: To access the Setup Menu.

6. “Network Setup”: To set up network settings.

 Network Status Icons

: The unit is connected to a wireless network.

The white bars indicate the wireless signal strength.

: The unit is not connected to a wireless network.

When the unit has successfully been connected to an access point, appears in the upper left corner of the Home Menu screen.

Menu.

D Note

• The network status icon does not necessarily mean that this unit is connected to the Internet.

• When “Network Setup” is set to “Wired”, the network status icon does not appear.

EN - 10

continued on next page

 Setup Menu

Video Out

Audio Out

Network

HDMI

Playback

Others

TV Aspect

Progressive Mode

Still Mode

16:9 Wide

Auto

1. Category

2. Menus / Options: Displays options for the highlighted item on the left whenever available

 Play Menu

During playback, press [MODE] to display the Play Menu.

e.g.) Blu-ray Disc™

Audio

Subtitle

Repeat

Black Level

Noise Reduction

EN - 11

4. CONNECTIONS

HDMI cable

(not supplied)

Your TV

4.1. Placing the Speakers

Make the following connection to ensure an optimum sound experience.

REAR

LEFT

FRONT LEFT

CENTER

FRONT RIGHT

REAR

SUBWOOFER

RIGHT

1. Place the main unit near to the TV.

2. Place the speakers system at normal listening ear-level and directly parallel to the listening area.

3. Place the subwoofer at the corner of the room or at least 3.3 feet (1 meter) away from the TV.

D Note

• The placement diagram shown here is only a guideline that provides great system performance. You may find other placement choices that are more suitable for your room layout that provide the sound experience you enjoy.

• To avoid magnetic interference, never position the front speakers too close to your CRT Picture Tube TV.

• The rear speakers are labeled as REAR LEFT or REAR RIGHT.

• The front speakers are labeled as FRONT LEFT or FRONT RIGHT.

• For speaker setup, refer to “Speaker Setup” on page 41.

4.2. Connection to a TV

 HDMI Connection (Supports up to 1080i

(*1)

, 1080p

(*2)

, 1080p/24

(*3)

resolution.)

)

SPEAKERS (3Ω

REAR FRONT

SUB

FRONT

R L RL

CENTER

WOOFER

HDMI OUT HDMI IN

VIDEO

AUDIO IN

OUT

AUX

DIGITAL AUDIO IN

COAXIAL

LAN

HDMI OUT

No Analog Audio connection is required as Digital Audio is included with HDMI cable signal.

(*1)

1080i:

(*2)

1080p:

(*3)

1080p/24:

Outputs video data with a frame rate of 30 frames per second.

Outputs video data with a frame rate of 60 frames per second.

Outputs video data with a frame rate of 24 frames per second.

• Do not tilt the connector when inserting it into the HDMI jack, and make sure the shapes of the jack and the connector are matched.

• When connected to an HDCP incompatible display device, the picture will not be displayed properly.

• Use an HDMI cable with the HDMI logo (a certified HDMI cable) for this connection. High Speed HDMI cable (also known as HDMI category 2 cable) is recommended for better compatibility.

D Note

• If the TV receives no Audio / Video signal after properly connecting the unit and the TV with an HDMI cable, it may be the TV. Please refer to the TV’s user’s manual.

• If the TV receives no Audio signal after properly connecting the unit and the TV with an HDMI cable, make sure the TV input is not an HDMI-DVI Input terminal.

continued on next page

EN - 12

 Standard Composite Video Connection (Supports only 480i resolution.)

SUBWOOFER FRONT

CENTER

REAR

RIGHT

REAR

LEFT

FRONT

RIGHT

FRONT

LEFT

1. Press the clamper and insert the wire.

2. Release the clamper.

Video cable

VIDEO

OUT

)

SPEAKERS (3Ω

REAR FRONT

SUB

FRONT

R L RL

CENTER

WOOFER

VIDEO

AUDIO IN

OUT

AUX

DIGITAL

AUDIO IN

COAXIAL

LAN

HDMI OUT

(not supplied)

VIDEO IN

Your TV

• Connect this unit directly to the TV. If a video cable is connected to a VCR then the pictures may be distorted due to the copyright protection system.

4.3. Connecting Speakers and Subwoofer

)

SPEAKERS (3Ω

REAR FRONT

SUB

FRONT

R L RL

CENTER

WOOFER

SUB

WOOFER

FRONT

CENTER

REAR FRONT

R L RL

LAN

HDMI OUT

VIDEO

AUDIO IN

OUT

AUX

DIGITAL AUDIO IN

COAXIAL

1. Connect the bare speaker cable wire ends to the matching color terminals on the speakers.

2. Connect all the speakers and subwoofer to the matching terminals at the rear of the main unit. Make sure that the colors of the cable wires and terminals match.

3. Confirm that the solid colored wire goes to its matching “+” colored terminal and the black wire goes to the “-” black colored terminal.

4. Press a colored clamper and insert the solid colored wires to their respective colored terminal. Then release the clamper when the bare wire end is located so the clamper will clamp the bare wire making a positive connection.

5. Repeat step 4.

D Note

• To prevent unwanted noise, never place the speakers too close to the main unit, subwoofer, AC power adapter, TV or any other radiation sources.

• When a disc has 7.1 multi-channel surround sound output then this Home Cinema unit will convert it to 5.1 multichannel surround sound output using the Home Cinema speakers.

EN - 13

4.4. Connecting Audio from Cable Box / Recorder / Game Console or TV

AUDIO IN

AUX

AUDIO OUT

DVD Recorder / VCR

Cable / Satellite Box

Your TV

Digital audio coaxial cable

(not supplied)

Audio cable

(not supplied)

Digital audio connection

Analog audio connection

DVD Recorder / VCR

Your TV

• This unit provides analog and digital audio connection. You can connect the Audio output from an Audio / Video device (e.g. DVD Recorder, VCR, Cable / Satellite Box, game console or TV) to this Blu-ray™ Home Cinema in order to enjoy the Multi-channel Surround Sound capabilities.

)

SPEAKERS (3Ω

REAR FRONT

SUB

FRONT

R L RL

CENTER

WOOFER

VIDEO

AUDIO IN

OUT

AUX

DIGITAL AUDIO IN

COAXIAL

LAN

HDMI OUT

DIGITAL OUT

DIGITAL

AUDIO IN

COAXIAL

• Use an audio cable (not supplied) to connect the AUDIO IN (AUX) jacks on the main unit to the audio output jacks on the connected device.

• Use a digital audio coaxial cable (not supplied) to connect the DIGITAL AUDIO IN (COAXIAL) jack on the main unit to the digital audio coaxial output jack on the connected device.

D Note

• To listen to the audio output from these connections, select “Speakers” in “Audio Output” (refer to page 41) and change the active Source mode to the connected Input. (Refer to “Switching Active Source Mode” on page 57.)

EN - 14

4.5. HDMI Audio Output

HOME A “Settings” A “Audio¬Out” A “Audio Output”

If you set to “Speakers”:

The audio output from the 5.1ch speakers differs depending on the audio source and the setting of surround mode. (Refer to “Selecting Surround Mode” on page 55.)

If you set to “HDMI Normal” or “HDMI LPCM”:

Refer to the table below for the audio output from HDMI OUT jack.

“Audio Output”

setting A

Media

“BD Audio Mode”

setting A

Audio SourceªWhich audio format can be output depends on the compatibility of the connected

“HD Audio Output” “Mix Audio Output” “HD Audio Output” “Mix Audio Output”

device.

Dolby Digital Dolby Digital Multi LPCM

Dolby Digital Plus Dolby Digital Plus Dolby Digital Multi LPCM

BD-video

Dolby TrueHD Dolby TrueHD Dolby Digital Multi LPCM*3 Multi LPCM

DTS

DTS-HD

DTS

DTS-HD

LPCM Multi LPCM Multi LPCM

Dolby Digital Dolby Digital Multi LPCM

DVD-video

DTS

LPCM 2ch LPCM 2ch LPCM

Audio CD LPCM 2ch LPCM 2ch LPCM

DTS-CD DTS® DTS

AVCHD

Dolby Digital Dolby Digital Multi LPCM

LPCM Multi LPCM Multi LPCM

MP3 MP3 2ch LPCM 2ch LPCM

Dolby Digital Dolby Digital Multi LPCM

DLNA

Video

MP2 2ch LPCM 2ch LPCM

LPCM Multi LPCM Multi LPCM

DLNA

Music

Netflix

MP3 / LPCM 2ch LPCM 2ch LPCM

Dolby Digital Plus Dolby Digital Plus Multi LPCM

HE-AAC 2ch AAC 2ch LPCM

Dolby Digital Dolby Digital Multi LPCM

VUDU

Dolby Digital Plus Dolby Digital Plus Multi LPCM

HE-AAC 2ch AAC 2ch LPCM

MP3 2ch LPCM 2ch LPCM

Pandora

MP3 2ch LPCM 2ch LPCM

YouTube™ HE-AAC 2ch AAC 2ch LPCM

) Fully decoded.

) Only the independent substream is decoded.

) Dolby TrueHD stream is decoded.

) Only the Dolby Digital substream is decoded.

) Only the core substream is decoded.

“HDMI Normal” “HDMI LPCM”

DTS

Multi LPCM

continued on next page

EN - 15

D Note

• If the connected device is not compatible with HDMI BITSTREAM, audio will be output as multi LPCM or 2-channel down-mixed LPCM depending on the capability of the connected device even if you select “HDMI Normal” in “Audio Output” setting.

• If the connected device is not compatible with AAC, audio will be output as LPCM depending on the capability of the connected device.

• When playing back a BD-video which only contains the primary audio, the audio output will be the same case as “HD Audio Output” even if “BD Audio Mode” is set to “Mix Audio Output”.

• HD Audio will not be output when “BD Audio Mode” is set to “Mix Audio Output” and the Button Sound feature in the content is enabled. (Button Sound setting may be found in Pop Menu.)

EN - 16

4.6. Connection to the Network

Internet

LAN cable

(not supplied)

LAN cable

(not supplied)

Networking equipment

(modem, etc.)

Broadband router or hub

By connecting this unit to the Internet, you can update the software via the Internet, play contents stored on DLNA home media servers or access BD-Live™ and other network services, such as Netflix, VUDU, Pandora

and YouTube™.

- Software Update: For more information, refer to “Network Update” on page 53.

- DLNA home media server: For more information, refer to “Playing Back Video / Music / Photo from DLNA Certified

Home Media Servers” on page 28.

- BD-Live™: For more information, refer to “Enjoying BD-Live™ Discs Using Internet” on page 32.

- Netflix / VUDU / Pandora

/ YouTube™: For more information, refer to “Information on Network Services” on

page 38.

D Note

• Wired connection is recommended when using the following features. (Using the following features with a wireless connection can be affected by other devices using radio frequencies.)

- Play contents from DLNA certified home media servers

- Video streaming services (Netflix / VUDU / YouTube™)

- Listening to Internet radio (Pandora)

- Network update

 Wired Connection

LAN

WAN LAN

12345

LAN

)

SPEAKERS (3Ω

REAR FRONT

FRONT

SUB

R L RL

WOOFER

CENTER

VIDEO

AUDIO IN

OUT

AUX

DIGITAL

AUDIO IN

COAXIAL

HDMI OUT

LAN

C Caution

• Do not insert any cable other than a LAN cable to the LAN terminal to avoid damaging the unit.

• Do not connect your PC directly to the LAN terminal of this unit.

D Note

• After you make a wired connection, set up necessary network settings. (For network setting of wired connection, refer to “Wired Connection” on page 44.)

• If your modem does not have router functions, connect a wired router.

• If your modem has router functions but there is no vacant port, add a Switch / Hub.

• Please purchase shielded LAN cables at your local store and use them when you connect to network equipment.

continued on next page

EN - 17

 Wireless Connection

LAN cable

(not supplied)

Internet

Networking equipment

(modem, etc.)

Wireless router

LAN WAN

D Note

• If using the wireless connection, refer to page 46 for “Wireless Connection” to configure the network setting.

• For a wireless router, use a router that supports the following IEEE 802.11 b/g/n specifications. (“n” is preferred type for a faster stable operation of the wireless network.)

• Our player supports infrastructure mode when using a wireless router. This unit does not support ad-hoc mode.

• Other radio devices or obstacles may cause interference to the wireless network connection.

• If you are experiencing signal issues with your wireless connection, please confirm that your wireless router is placed close enough to the unit.

EN - 18

5. BEFORE YOU START

Please Wait...

Please select your language for on-screen display.

English

Español

Français

Return

5.1. Finding a Viewing Video Source Input on Your TV

After you have completed all of the connections to your TV, review the steps below.

1. Press [(POWER-ON)] to Turn On the unit.

2. Turn On your TV.

3. Please locate the Source / Input / AUX / Video button on TV's remote control. The button may vary on the TV brand and model. Once you have located the button, press until you see “Please Wait...” or the Initial Setup Menu on the Screen.

This is the correct viewing of the video Source Input.

• If the TV is connected by an HDMI cable, it may take a few moments for the opening picture to appear.

• If a certain amount of time has passed since you Turned On the unit, welcome screen only appears the first time you

Turn On the unit.

5.2. Initial Setup

Please follow the instructions below to complete the initial setup.

1. While welcome screen is displayed, use [] to select “Next”, then press [OK].

2. Language setup screen will appear. Use [] to select your language, then press [OK].

Language

3. “Quick Start Mode” screen will appear. Use [] to select the desired mode, then press [OK].

4. “Automatically check for latest software” screen will appear. Use [] to select the desired mode, then press [OK].

5. Network setup screen will appear. Use [] to select the desired mode, then press [OK].

• If you select “Wired”, refer to “Wired Connection” on page 44 for further operation.

• If you select “Wireless”, refer to “Wireless Connection” on page 46 for further operation.

continued on next page

EN - 19

 How to Reset the OSD Language

You can reset the OSD language if you selected the wrong language.

1. Press [HOME] to display the Home Menu.

2. Use [] to select “ ”, then press [OK].

• This item is “Settings” (English) / “Configuaraciones” (Spanish) / “Paramètres” (French).

• From here on, please select one of the following items you can find on screen:

3. Use [] to select “Playback” (English) / “Reproducción” (Spanish) / “Lecture” (French), then press [OK].

4. Use [] to select “Language” (English) / “Idioma” (Spanish) / “Langue” (French), then press [OK].

5. Use [] to select your desired language, then press [OK].

6. If the items that were set are displayed in your desired language, then press [HOME] to exit.

EN - 20

6. INFORMATION ON PLAYBACK

6.1. Information on Playback

 Playable Discs and Files

Playable discs Logos

Blu-ray Disc™

- BD-video

- BD-RE* (ver. 2.1) (Recorded in BDMV format)

- BD-R* (ver. 1.1 / 1.2 / 1.3) (Recorded in BDMV format) (Unfinalized disc may not be played back.)

DVD-video

DVD-RW (finalized video mode discs only)

DVD-R (finalized video mode discs only)

CD-DA (audio CD)

CD-RW

CD-R

KODAK Picture CD

DTS-CD

(*) Due to the intentional progression of the Blu-ray Disc™ format by its standard setting authority, the company cannot

guarantee or warrant the playability of future extensions of the Blu-ray Disc™ format with this product.

Playable files Media

AVCHD

MP3 JPEG

SD Memory Card using USB card reader / USB hub (not supplied)

DVD-RW/-R

BD-RE/-R

DVD-RW/-R

CD-RW/-R

USB Memory Stick

Readable device Playable files / data

USB Memory Stick

MP3, JPEG, picture-in-picture commentary, Subtitles or other extras for BD-ROM ver. 2 (Profile 2.0 / Profile 1.1)

D Note

• This unit may not be able to play back discs recorded on PC's or other recorders.

continued on next page

EN - 21

 Recommended Specifications AVCHD

This unit cannot play back stand-alone AVCHD files (*.m2ts, *.mts or *.m2t) written to a DVD or copied to an SD Memory Card. The DVD or SD Memory Card containing AVCHD files must have a proper file and folder structure meeting AVCHD format specifications. Please use AVCHD compliant device / software to burn or copy AVCHD files to DVD or SD Memory Card. (Please refer to user manuals of your device / software for more information.)

MP3

• Sampling frequency: 32 kHz, 44.1 kHz or 48 kHz

• Constant bit rate: 112 kbps - 320 kbps

JPEG

Resolution

• Upper limit: 2,560 x 1,900 dots (sub sampling is 4:4:4) 5,120 x 3,840 dots (sub sampling is up to 4:2:2)

• Lower limit: 32 x 32 dots

• Maximum file size of a picture: 12MB

 Folder / File Number Limitations

Blu-ray Disc™, DVD and USB Memory Stick

• 999 folders (groups) and 9,999 files

• 255 folders (groups) and 999 Tracks / Files

Caution / Note for USB Memory Stick

C Caution

• Do not try to open or modify the USB Memory Stick.

• Do not touch the terminal surface with your fingers or any metals.

D Note

• This unit supports USB Memory Stick with FAT16 / FAT32 file system.

• This unit does not support NTFS file system.

• This unit may not read USB Memory Sticks formatted on a computer. If that is the case, please reformat the USB Memory Sticks on this unit and try again. Please not that all files stored on the USB Memory Stick will be erased upon format.

• Please keep the USB Memory Sticks in their cases when you are not using them.

• Some USB Memory Sticks may not work with this unit.

• This unit can read SD Memory Cards using a USB card reader (not supplied).

- Readable cards: SD Memory Card (8 MB - 2 GB)

miniSD Memory Card (16 MB - 2 GB) microSD Memory Card (256 MB - 2 GB) SDHC Memory Card (4 GB - 32 GB) miniSDHC Memory Card(4 GB - 8 GB) microSDHC Memory Card (4 GB - 16 GB)

- Readable files: AVCHD / MP3 / JPEG

• Depending on a USB card reader or USB hub, connected card or device may not be recognized.

EN - 22

continued on next page



Unplayable Media and Files

The following discs will not be played back on this unit.

• CD-ROM • CD-I (compact disc-interactive)

•DVD-RAM •VSD (video single disc)

•DVD-audio •video CD

• HD DVD • SVCD

• SDXC Memory Card • microSDXC Memory Card

• unfinalized disc • BD-RE (ver. 1.0)

• BD-RE (ver. 2.1) (Recorded in BDAV format) • BD-R (ver. 1.1 / 1.2 / 1.3) (Recorded in BDAV format)

•BDXL™

• Blu-ray Disc™ / DVD / CD / USB Memory Stick / SD Memory Card containing DivX

files

• Blu-ray Disc™ / USB Memory Stick that contains AVCHD files

• Blu-ray Disc™ / DVD hybrid disc (played back as a BD-video only)

• DVD-RW/-R recorded in non compatible recording format

• Super Audio CD - Only the sound on the CD layer can be heard. The sound on the high-density Super Audio CD layer cannot be heard.

• Playability of dual discs is not guaranteed.

• This unit cannot play back the disc contents protected by Windows Media™ Digital Rights Management (DRM).

Region Codes

This unit has been designed to play back BD-video with region “A” and DVD-video with region “1” or “ALL”. You cannot play back BD-video or DVD-video that is labeled for other regions. Look for the symbols on your BD-video or DVD-video. If these region symbols do not appear on your BD-video or DVD-video, you cannot play back the disc on this unit. The letter or number inside the globe refers to region of the world. BD-video or DVD-video discs labeled for a specific region can only be played back on players with the same region code.

Hint for Disc Playback

The contents of a disc are generally divided into sections or folders (group of titles / files) as shown below.

BD-video, DVD-video, AVCHD

Title 1 Title 2

Chapter 1 Chapter 2 Chapter 1 Chapter 2 Chapter 3

Audio CD

Track 1 Track 2 Track 3 Track 4 Track 5

BD-video

DVD-video

MP3, JPEG

folder (group) 1 folder (group) 2

File 1 File 2 File 3 File 4 File 5

continued on next page

EN - 23

 Description for Icons [] : group (folder) icon

[] : music file icon

[] : movie file icon

[] : photo file icon

- “Folders” refers to the group of files.

- “Tracks” refers to the contents recorded on the audio CD.

- “Files” refers to the contents on a disc which are recorded in AVCHD, MP3, JPEG (including KODAK Picture CD) file format.

D Note

• Unrecognizable characters will be replaced with asterisks.

EN - 24

6.2. Guide to File List

Align the Disc to the disc tray guide.

 Music File List

e.g.) MP3 mode

File List

--- / 999 -- : -- : --

DATAxxxxxxx

Music1

Song2.mp3

Song3.mp3

Song4.mp3

Song5.mp3

Song6.mp3

Song7.mp3

Page Up Page Down

1. Name of disc / USB Memory Stick

2. Current Track (File) number / Total number of Tracks (Files)

3. Elapsed playing time of the current Track

 Picture File List

Thumbnail

--- / 999

06051_1140

DATA

4. Playback status symbol

5. Media type

6. Group (folder) / File list

Folder_001 Folder_002

Page Up Page Down Media Mode

1. Current File number / Total number of Files

2. Playback status symbol

3. Media type

4. Group (folder) / File list (thumbnails)

 How to Navigate through the Track / File List

•Use [] to move the highlight up and down in the list.

• To access the files in a Group (folder), select the desired Group (folder), then press [OK].

•Press [] or [RETURN] to go back to the previous hierarchy.

•Press [RED] or [GREEN] to change the page list up or down.

•Press [YELLOW] to go back to the “Media Mode” screen.

•Press [HOME] to Exit.

6.3. How to Insert a Disc

1. Press [(OPEN/CLOSE)] to Open the disc tray.

2. Place the Disc on the disc tray with its label side facing up.

3. Press [(OPEN/CLOSE)] to Close the disc tray.

• It may take a while to load the disc.

EN - 25

7. BASIC PLAYBACK

a b c

7.1. Playing Back a Disc

1. Insert a disc (refer to “How to Insert a Disc” on page 25).

• For Blu-ray Disc™ / DVD / audio CD or a disc containing only one type of file, playback will start automatically. If

not, press [(PLAY)].

• Some discs may show a Title or a Disc Menu. In this case, refer to “Using the Title / Disc / Pop Menu” on page 29.

2. Select the type of the file you want to play back, then press [OK].

Music

a. For “Music”, Track / File list will be displayed. Select a Group (folder) or Track / File you want to play back then press

[(PLAY)] or [OK] to start playback.

• Refer to “Music File List” on page 25 and “How to Navigate through the Track / File List” on page 25.

b. For “Photo”, thumbnail screen will appear.

• Refer to “Picture File List” on page 25 and “How to Navigate through the Track / File List” on page 25.

c. For “AVCHD”, playback will start automatically.

To Skip to the next Track / File: To Skip to the previous Track / File: To Pause playback: To Return to Normal playback: To Stop playback:

Playback will be in Resume-On-Stop mode.

 Resume-On-Stop Mode

Blu-ray Disc™ / DVD / AVCHD When you press [(PLAY)] next time, the playback will start from the point where it has been stopped.

Audio CD Playback will start from the point where it is stopped next time you press [(PLAY)]. If you press [OK] instead of

[(PLAY)], playback will start from the beginning of the Track / File instead of resuming from the stop point. MP3 / JPEG / KODAK Picture CD

Playback will start from the beginning of the current file next time you press [(PLAY)] or [OK].

Press [(SKIP)]. Press [(SKIP)]. Press [(PAUSE)]. Press [(PLAY)].

Press [(STOP)].

D Note

• Playback will also Stop and the Home Menu will appear when you press [HOME].

• For BD-Java application, the Resume-On-Stop may not be available.

• If you press [OK] instead of [(PLAY)], playback can be started from the beginning of the disc even if it was in the Resume-On-Stop mode.

• Resume-On-Stop mode remains in effect even after Power is Turned Off, but will be cancelled once the disc is ejected.

• With regard to the multi-border BD-RE/-R, additionally recorded sections cannot be recognized.

• With regard to the multi-border DVD-RW/-R, additionally recorded sections may not be recognized.

continued on next page

EN - 26

Note for JPEG / KODAK Picture CD Playback

• Every press of [] will turn the image by 90 degrees when an image is displayed.

• During playback, press [TOP MENU] to display thumbnail screen.

• This unit conforms to ver. 7.0 of KODAK Picture CD. For details of KODAK Picture CD, contact a shop that provides developing service for Kodak Inc.

• Some unplayable folders or files may be listed due to the recording status.

• High-resolution JPEG files take longer to be displayed.

• Progressive JPEG files (JPEG files saved in progressive format) cannot be played back on this unit.

7.2. Playing Back Contents from a USB Memory Stick

You can play back MP3 / JPEG files stored on a USB Memory Stick. With the USB Memory Stick, you can also enjoy the following functions.

- Special additional contents for BD-ROM Profile 1 ver. 1.0. (For more information about the special additional contents, refer to the instruction book that came with the disc.)

- BD-Live™ function (BD-ROM ver. 2 Profile 2.0). (For more information about BD-Live™, refer to page 32.)

1. Connect a USB Memory Stick.

2. Press [HOME].

3. Use [] to select “USB Memory Stick”, then press [OK].

4. Follow step 2 in “Playing Back a Disc” on page 26.

Caution

• Do not disconnect the USB Memory Stick or switch the unit to Standby mode while a content on the USB Memory Stick is being accessed. It may result in malfunction or loss of the stick's data.

• If you connect a USB Memory Stick or SD Memory Card via a USB card reader or USB hub, BD-ROM data will be written onto the first connected card or device. Connecting a USB Memory Stick directly to this unit is recommended.

• Occasionally, SD Memory Cards / Micro SD Memory Cards will not be recognized when using certain Adapters. In such cases, try a different USB Adapter.

Note

• When connecting more than two USB Memory Sticks to a USB Hub, this unit may fail to recognize them. In such cases, disconnect the USB Hub from the unit then reconnect it, or use less USB Memory Sticks at a time.

• The resume information will be cleared when;

- [(STOP)] is pressed while in the Resume-On-Stop mode.

- the USB Memory Stick is disconnected.

- the unit is switched to Standby mode.

• Do not delete the folders or files on the USB Memory Stick with your computer. This unit may not read USB Memory Sticks formatted on a computer.

• If a folder or file name includes one of the following unrecognizable characters, the folder or file name may not be displayed correctly.

- Unrecognizable characters:

• This unit can read MP3 / JPEG files and AVCHD in an SD Memory Card by using USB card reader / USB hub (not supplied).

. , " = + [ ] ; / \ : | ¥

EN - 27

7.3. Playing Back Video / Music / Photo from DLNA Certified Home Media Servers

On this unit, you can play video, music and photo files stored on DLNA certified media servers connected to your home network. In order to use this feature, you must connect this unit to your local network. (not guaranteed to work with a wireless environment)

• For details, refer to the user manual of the DLNA certified device.

1. Follow steps 1 and 2 in “Before Using Network Features” on page 38.

2. Start DLNA home media servers in your home network.

3. Press [HOME].

4. Use [] to select “Home Network” then press [OK].

• This unit will start loading the Media Server list.

• To cancel loading, press [(STOP)].

• To reload the Media Server list, press [YELLOW].

5. After loading, Media Server list will appear. Select a Media Server you want to access, then press [OK].

6. File list of the selected Media Server will appear. Select a file you want to play back, then press [(PLAY)] or [OK] to start playback.

• If you select a folder, select a file in the folder and then press [(PLAY)] or [OK] to start playback.

Home Network

---- / 1234

DATAxxxxxxx


Song1.mp3

Song2.mp3

Song3.mp3

Song4.mp3





Page Up Page Down Server List

• Refer to “Guide to File List” on page 25.

To control playback, use following buttons.

Button Action

(SKIP)

Skip to next song, file, etc. (For video files, playback will be step by step each time the button is pressed in pause mode.)

(FORWARD)

During playback, press to Fast Reverse or Fast Forward the playback.

(REVERSE) (PAUSE) (PLAY)

(STOP)

Pause the playback. Start or return to Normal playback.

Stop the playback. (For video files, playback will be in Resume-On-Stop mode.)

Resume-On-Stop mode for video files

Playback will start from the point where it is stopped next time you press [(PLAY)]. If you press [OK] instead of [(PLAY)] playback will start from the beginning of the file instead of resuming from the last stop point.

TOP MENU Goes to the root directory of the file list.

EN - 28

continued on next page

D Note

• For the Media Server list, maximum of 10 servers can be displayed.

• The system can recognize up to 2,000 files (including folders).

• The 10th and deeper hierarchies cannot be displayed.

• This unit supports the following formats. (Formats other than listed below cannot be recognized.)

- Video : MPEG 1, MPEG 2 PS, MPEG 2 TS / TTS

- Music : LPCM, MP3

- Photo : JPEG (Images over 1024 x 768 pixel are not included in the warranty specification.)

• Unplayable files in the Media Server will not be displayed in the file list.

• For some files, playback is not available even if displayed in the file list.

• In order to play back the contents from Media Servers, the player and the Media Servers must be connected to the same local area network.

• Compatibility and available playback function may differ depending on the Media Server.

• If you select a photo file in step 6 on page 28, the selected photo will display and go to the next photo within 10 seconds.

• For a folder that only contains photo files, thumbnails may be displayed.

• For photo files, every press of [] will turn the image by 90 degrees when an image is displayed.

• The quality of the playback picture or sound depends on the speed/signal strength condition of your network.

• It may take a few moments while loading a file when the unit is going to a new folder / file location during playback.

7.4. Using the Title / Disc / Pop Menu

Some BD-videos, DVD-videos or AVCHD files may contain a Title Menu which describes the contents of the disc, or a Disc Menu which guides you through the available functions on the disc. With such discs, a Title Menu or a Disc Menu may appear automatically when you insert the disc. Otherwise, press [TOP MENU] or [POP MENU/MENU] to call up the menu. Refer to the disc’s manual on how to navigate through the menu.

D Note

• Menus vary among discs. Refer to the information accompanying the disc for details.

• [TOP MENU] or [POP MENU/MENU] may not work with some discs.

EN - 29

8. SPECIAL PLAYBACK

8.1. Fast Forward / Fast Reverse

1. During playback, press [(FORWARD)] repeatedly for Fast Forward. During playback, press [(REVERSE)] repeatedly for Fast Reverse.

2. Press [(PLAY)] to return to Normal playback.

D Note

• For Blu-ray Disc™, DVD and AVCHD, speed changes at 5 different levels.

• For audio CD, MP3 and Video / Audio files on DLNA Media Server, speed changes at 3 different levels.

• For some video / music files on a DLNA Media Server, Fast Forward / Fast Reverse may not function.

• For audio CD, MP3 and Fast Forward / Fast Reverse search between different files are not available.

8.2. Slow Forward Playback

1. During playback, press [(PAUSE)]. Then press [(FORWARD)]. Every time you press [(FORWARD)], the playback speed changes at 3 different levels.

2. Press [(PLAY)] to return to Normal playback.

D Note

• Only Slow Forward is available.

• For some video files on a DLNA Media Server, Slow Forward may not function.

• Set “Still Mode” to “Field” in “Video Out” menu if pictures in the Slow Forward playback mode are blurred.

8.3. Step by Step Playback

1. In pause mode, press [(SKIP)] repeatedly. Every time you press [(SKIP)], playback will advance one step at a time.

2. Press [(PLAY)] or [(PAUSE)] to return to Normal playback.

D Note

• Only step by step forward is available.

• Set “Still Mode” to “Field” in “Video Out” menu if pictures in the Slow Forward playback mode are blurred.

EN - 30

8.4. Repeat Playback

Available repeat function varies depending on the disc.

1. During playback, press [MODE] to display the Play Menu.

2. Use [] to select “Repeat”, then press [OK].

3. Use [] to select the desired repeat mode.

REPEAT MODE AVAILABLE MEDIA

Chapter Repeat

The current Chapter will be played back repeatedly.

Title Repeat

The current Title will be played back repeatedly.

Track Repeat

The current Track or File will be played back repeatedly.

All Repeat

All Tracks in the media will be played back repeatedly.

Group Repeat

The current Group (folder) will be played back repeatedly.

Random Repeat (Audio CD)

Repeats the random playback.

Random Repeat (MP3 / JPEG)

Repeats the random playback in a folder.

4. Press [RETURN] to Exit.

D Note

• The repeat setting will be cancelled when you stop playback.

• When the repeat setting is set for an MP3 or JPEG folder (file), the repeat setting will be cancelled if you select another MP3 or JPEG folder (file) to playback.

• For some video / music / photo files on a DLNA Media Server, repeat playback may not function.

8.5. Slide Show

1. Follow steps 1 and 2 in “Playing Back a Disc” on page 26.

2. Open the folder which contains the desired JPEG files.

3. Use [] to select a desired file to be played back, then press [(PLAY)] or [OK].

• An image will be played back from the selected file and go to the next one in turn every 10 seconds.

4. Press [(STOP)] to Stop playback.

To return to the first item: Press [TOP MENU] To return to the file played last: Press [POP MENU/MENU]

D Note

• Large-size JPEG files take a few moments to be displayed.

EN - 31

8.6. PiP (BONUSVIEW™) Setting

Some BD-videos have the PiP function which enables you to display the Secondary Video in the Primary Video.

PiP 1 / 8

Primary Video

Secondary Video

1. During playback, press [MODE] to display the Play Menu.

2. Use [] to select “PiP” then press [OK].

• PiP information will appear.

3. Use [] to select the Secondary Video you want to show.

• The Secondary Video will be displayed with the Secondary Audio.

•Use [] to switch between current setting and “Off”.

4. Press [RETURN] to Exit.

• How to select the Secondary Audio output, refer to “Switching Audio Soundtrack” on page 35.

D Note

• Not that the secondary video will be displayed at any time during playback. Depending on the scene, the secondary video may not be available.

8.7. Enjoying BD-Live™ Discs Using Internet

You can enjoy BD-Live™ which enables you to use interactive features when the unit is connected to the Internet.

Examples of BD-Live™ features:

• Online access to additional content such as movie trailers, subtitles, BD-Java applications, etc.

• While downloading, special video data may be played back.

- Service and functions differ depending on the disc. Follow the instructions given by the disc when using

the BD-Live™ function.

- Connect a USB Memory Stick with at least 1 GB of available memory before using BD-Live™ features on a

Blu-ray Disc™.

- Do not disconnect the USB Memory Stick while using BD-Live™ features.

D Note

• You must connect the unit to the Internet and set up necessary settings in order to use BD-Live™.

• For the network connection, refer to “Connection to the Network” on page 17.

• For the network setup, refer to “Network Connection” on page 44.

• For certain discs, “BD-Live¬Setting” under “Network” in “Settings” may need to be changed.

• Depending on your connection environment, it may take a few moments to connect to the Internet or the Internet may not be connected. Refer to “TROUBLESHOOTING” on page 58.

• Some discs with BD-Live™ function require memory when playing back the content. If you cannot play back a disc with BD-Live™ function, connect a USB Memory Stick (1GB or more of available memory) which is formatted on this unit.

• Not all BD-video discs have a BD-Live™ content. To enjoy the BD-Live™ features, please use discs with a BD-Live™ content.

D Note for AACS Online

• The player or disc ID may be sent to the content provider when playing back a disc with BD-Live™ function.

• If you save your viewing history on the server by using these ID’s, you will be introduced to other similar movies.

• You can save game score histories.

EN - 32

8.8. Title / Chapter Search

CHP

Search 1 / 999

 Using [(SKIP)] / [(SKIP)]

1. During playback, press [(SKIP)] to Skip the current Title or Chapter and move to the next.

The Title or Chapter will move forward one at a time.

• If there is no Chapter in one Title, the current Title may be Skipped. To go back to the beginning of the current Title or Chapter, press [(SKIP)].

Press [(SKIP)] repeatedly to go to the previous Title or Chapter. The Title or Chapter may move backward one at a time.

 Using [MODE]

1. During playback, press [MODE] to display the Play Menu.

2. Use [] to select “Search”, then press [OK].

3. Use [] to select “ ” or “ ”, then press [OK].

e.g.) Blu-ray Disc™

4. Use [] to select the Title / Chapter number, then press [OK].

Playback will start from the beginning of the Title / Chapter.

5. Press [RETURN] to Exit.

 Using [the NUMBER buttons] (Direct Search)

Chapter Search

During playback of a Title, enter the Chapter number you want to search using [the NUMBER buttons]. Playback of the Chapter will start in a few seconds.

D Note

• As for the BD-video, how it performs will be strongly determined by the disc, and may not perform as described.

8.9. Track / File Search

 Using [(SKIP)] / [(SKIP)]

1. During playback, press [(SKIP)] to Skip the current Track or File and move to the next. The Track / File will move forward one at a time. To go back to the beginning of the current Track / File, press

[(SKIP)]. Press it repeatedly to go to the previous Track / File. The Track / File will move backward one at a time.

 Using [MODE]

1. During playback, press [MODE] to display the Play Menu.

2. Use [] to select “Search” then press [OK]. For MP3 / JPEG files, skip to step 4.

3. Use [] to select “ ”, then press [OK].

4. Use [] to select the Track number, then press [OK]. Playback will start from the beginning of the Track.

5. Press [RETURN] to Exit.

EN - 33

8.10. Time Search

Search 00:12:44 / 11:13:14

1. During playback, press [MODE] to display the Play Menu.

2. Use [] to select “Search”, then press [OK].

• For video files on DLNA server, skip to step 4.

3. Use [] to select “ ”, then press [OK].

e.g.) Blu-ray Disc™

4. Use [] or [the NUMBER buttons] to enter the time count you want to jump to, then press [OK].

e.g.) Entering 1 hour 45 minutes and 15 seconds.

Press

Playback will start from the desired time entered.

5. Press [RETURN] to Exit.

D Note

• For some video files on DLNA Media Server, time search may not function.

8.11. Switching Subtitles

Some video materials may have subtitles in one or more languages. For commercially available discs, the supported languages can be found on the disc case. Follow the steps below to switch the Subtitle language during playback.

1. During playback, press [MODE] to display the Play Menu.

2. Use [] to select “Subtitle”, then press [OK].

3. Use [] to select “Primary”, “Secondary” or “Style”, then press [OK].

“Primary”: Sets the Subtitle for the Primary Video. “Secondary”: Sets the Subtitle for the Secondary Video. “Style”: Sets Style of the Subtitle.

4. Use [] to select your desired Subtitle or Style.

Subtitle Primary

Secondary

Style

1 ENG / 3

Off

•Use [] to switch between current Subtitle setting and “Off”.

5. Press [RETURN] to Exit.

1. During playback, press [MODE] to display the Play Menu.

2. Use [] to select “Subtitle”, then press [OK].

3. Use [] to select your desired Subtitle.

Subtitle 1 ENG / 32

•Use [] to switch between current Subtitle setting and “Off”.

4. Press [RETURN] to Exit.

EN - 34

continued on next page

D Note

• Some discs will only allow you to change the subtitles from the Disc Menu or Pop Menu. Press [TOP MENU] or [POP MENU/MENU] to display the Disc Menu or Pop Menu.

• If the disc has no Subtitle language or Subtitle Style, “Not Available” will be displayed on the TV screen.

• During playback of the Secondary Video, the Primary Subtitle setting is not available except when there is no Subtitle for the Secondary Video.

8.12. Switching Audio Soundtrack

When playing back video material recorded with two or more soundtracks (these are often in different audio languages or audio formats), you can switch them during playback. For Blu-ray Disc™, available audio varies depending on “BD Audio Mode” setting. Refer to page 41.

1. During playback, press [MODE] to display the Play Menu.

2. Use [] to select “Audio”, then press [OK].

3. Use [] to select “Primary” or “Secondary”, then press [OK].

“Primary”: Sets the audio for the Primary Video. “Secondary”: Sets the audio for the Secondary Video.

4. Use [] to select your desired audio stream channel.

Audio Primary

Secondary

1 ENG Dolby D Multi-ch /3

1 ENG DTS Multi-ch /3

[Decoding Format] : Dolby D

• For “Secondary”, use [] to switch between current audio setting and “Off”.

5. Press [RETURN] to Exit.

1. During playback, press [MODE] to display the Play Menu.

2. Use [] to select “Audio”, then press [OK].

3. Use [] to select your desired audio stream channel.

Audio 1 ENG Dolby D Multi-ch /3

[Decoding Format] : Dolby D

• For audio CD, you can select following options.

“Stereo”: Both right and left channels are active (stereo). “L-ch”: Only left channel is active. “R-ch”: Only right channel is active.

4. Press [RETURN] to Exit.

D Note

• The Secondary Audio will not be output when the Secondary Video is not displayed or when “BD Audio Mode” is set to “HD Audio Output”. (For some Blu-ray discs, Secondary Audio will be output even when Secondary Video is Off.)

• The sound mode cannot be changed during playback of discs not recorded in multiple audio mode.

• Some discs allow changing the audio language setting from Disc Menu. (Operation varies depending on the discs. Refer to the manual accompanying the disc.)

• If the disc has no audio language, “Not Available” will be displayed on the TV screen.

• For DTS-CD (5.1 music disc), selecting audio streams or channels is not available.

EN - 35

8.13. Switching Camera Angles

Black Level On

Noise Reduction Off

Some BD-videos and DVD-videos contain scenes which have been shot simultaneously from various angles. You can change the Camera Angle when appears on the TV screen.

1. During playback, press [MODE].

2. Use [] to select ”Angle”, then press [OK].

3. Use [] to select your desired angle.

• The selected Angle will be displayed on the display bar at the top of the TV screen.

4. Press [RETURN] to Exit.

D Note

• If “Angle Icon” setting is set to “Off”, will not appear on the TV screen.

8.14. Black Level

You can adjust the Back Level setting to make the black parts of the pictures as bright as you prefer. You can select “On” or “Off”.

1. During playback, press [MODE] to display the Play Menu.

2. Use [] to select “Black Level”, then press [OK].

3. Use [] to select your desired setting.

e.g.) Blu-ray Disc™

“On”: Makes the dark parts blacker with additional contrast and brightness. “Off”: Shows the original picture as recorded.

4. Press [RETURN] to Exit.

D Note

• This function can also be set during Netflix / VUDU / YouTube™ playback.

• The setting will remain the same even if the unit is switched to Standby mode.

• “Black Level” is not effective under the following conditions.

- When the picture is output from HDMI OUT jack.

8.15. Noise Reduction

Reduces the noise of the playback picture.

1. During playback, press [MODE] to display the Play Menu.

2. Use [] to select “Noise Reduction”, then press [OK].

3. Use [] to select your desired setting.

e.g.) Blu-ray Disc™

“On”: Activates noise reduction. “Off”: Deactivates noise reduction.

4. Press [RETURN] to Exit.

D Note

• This function can also be set during Netflix / VUDU / YouTube™ playback.

• The setting will remain the same even if the unit is switched to Standby mode.

EN - 36

8.16. CLEAR+

CLEAR+ Off

CLEAR+ enhances the contrast of the picture and makes edges crisp. It is effective especially for DVD's.

1. During playback, press [MODE] to display the Play Menu.

2. Use [] to select “CLEAR+”, then press [OK].

3. Use [] to select your desired setting.

e.g.) Blu-ray Disc™

“On”: Gives low-definition videos high-definition like picture quality. “Off”: Shows the original picture as recorded.

4. Press [RETURN] to Exit.

D Note

• This function can also be set during Netflix / VUDU / YouTube™ playback.

• This operation is prohibited during Fast Forward, Fast Reverse, Slow Forward playback and pause mode.

• Pictures may appear whiter depending on the material and the connected TV. In this case, turn “CLEAR+” Off.

• “CLEAR+” is not effective under the following conditions.

- When the material is in 1080p24 which is commonly used in Blu-ray discs.

EN - 37

9. NETWORK FEATURES

http://www.netflix.com/HowItWorks

www.netflix.com/support

http://www.vudu.com/product_overview.html

support@vudu.com

http://www.pandora.com

Pandora-support@Pandora.com

http://www.youtube.com/device_support

9.1. Before Using Network Features

Please follow the instructions below before using network features.

1. Connect this unit to the Internet.

• Refer to “Connection to the Network” on page 17.

2. Set up the necessary network connection settings.

• Refer to “Network Connection” on page 44.

3. Press [NET APP] to display the network application menu.

4. Use [] to select the desired application, then press [OK].

• For the first time only, “Network Service Disclaimer” screen will appear. After confirming the content, use []

to select “Agree” then press [OK].

5. Press [HOME] to Exit.

D Note

• The Network Service Disclaimer is displayed when first using a network service and its acceptance is applied to all network services.

9.2. Information on Network Services

For detailed information on the third-party Internet services, please visit each service provider’s website:

Netflix :

VUDU :

Pandora :

YouTube™ :

To activate Netflix, this unit requires a PC connected to the Internet. On your PC, please visit their activation website (see above) then enter the activation code displayed on the TV screen.

• Support website : Support number : 1-866-716-0414

• Support number : 1-888-554-VUDU (8838) E-mail support :

• E-mail support :

EN - 38

10. PANDORA® OPERATION

www.pandora.com/magnavox

With this unit, you can instantly listen to free personalized radio stations streamed over the internet from Pandora. To learn more about Pandora, please visit on your PC.

10.1. Activating Pandora

In order to listen to Internet radio streamed from Pandora via the Internet, you must create a Pandora account and activate this unit.

1. Follow steps 1 to 3 in “Before Using Network Features” on page 38.

2. Use [] to select “PANDORA”, then press [OK].

3. Use [] to select “Create new account”, then press [OK].

4. Use [] to select “No, I am new to Pandora.”, then press [OK].

5. Note the activation code and website address displayed on the TV screen.

6. On your PC, visit the website address noted in step 5.

7. Follow directions on the website to create your account.

8. On this unit, select “Continue” and press [OK] to complete activation.

10.2. Adding Pandora User Accounts

You can add multiple Pandora user accounts on this unit.

1. Follow steps 1 to 3 in “Activating Pandora” on page 39.

2. Use [] to select “Yes, I have a Pandora account.”, then press [OK].

3. Enter your e-mail address, then press [OK] while “OK” is selected.

4. Enter a password, then press [OK] while “OK” is selected.

5. Use [] to select “Sign In”, then press [OK].

• Your account is added to the user list and player screen appears on the TV screen.

D Note

• Pandora is only available in the United States.

• You can add up to 5 accounts. After adding 5 accounts, “Create new account” is not displayed anymore.

• If you forget your password, please enter the e-mail address which is associated with your Pandora account, then select

“Password Recovery”, then press [OK]. After a while, a password recovery e-mail will be sent to the e-mail address. Follow the instruction in the e-mail.

EN - 39

10.3. Creating a New Pandora Station

By entering your favorite artists or songs, Pandora selects music and creates a new station for you on the basis of the entered information.

1. On the player screen, press [GREEN] to go to “Create Station” screen.

2. Enter a name of your favorite artist or song, then press [OK] while “OK” is selected.

• Search result will appear on the right side of the TV screen.

• If the selection screen of result type appears, use [] to select the desired type, then press [OK].

3. Use [] to select the desired station, then press [OK] to start the playback.

Button Action

[(PAUSE)] [(PLAY)] [(STOP)] [(SKIP)]

Pauses the playback.

Starts or Resumes the playback.

Stops the playback and the station list will appear. Skips to the next song.

D Note

• On the “Tool Menu”, you can delete or rename the currently selected station.

• To call up the “Tool Menu”, press [BLUE] on the player screen to display Station List, then press [YELLOW].

10.4. Guide to the Player Screen

On the player screen, you can set various options to the currently playing song.

1 2 3 4

ABC

By: XXXXX On: XXXXX

4:52 0:00

American Oldies Radio

Station ListExit Create Station Why this song?

1. : Gives thumbs up to the currently playing song. Pandora will play songs similar to the song.

2. :Gives thumbs down to the currently playing song. Pandora will skip and will not play the song.

3. : Bookmarks the currently playing song. You can view your bookmarked song's list by accessing Pandora website and log into your account.

4. : Tells Pandora that you do not like the currently playing song. Pandora will not play the song for about a month.

EN - 40

11. LIST OF SETTINGS

In “Settings”, you can customize various kinds of settings as you prefer. Refer to the following instructions to navigate through the Setup Menu.

1. Press [HOME] to access the Home Menu.

2. Use [] to select “Settings”, then press [OK].

3. Use [] to select the desired Category, then press [OK].

4. Use [] to move up and down the list to select Menus / Options.

5. To make a selection or to access options of an item, select the desired item, then press [OK].

• To go back to the previous screen, press [RETURN].

6. Press [HOME] to Exit.

Refer to the following table for the types of settings you can customize. The item highlighted in gray is the default setting.

Category Menus / Options

Video Out TV Aspect 4:3 Letter Box

4:3 Pan & Scan 16:9 Wide 16:9 Squeeze

Progressive Mode

Still Mode

Audio¬Out DRC

Audio Output

BD Audio Mode

Audio Sync 0 ~ 300ms Speaker Setup Speaker layout

Auto Video Auto Field Frame Auto On Off Speakers HDMI Normal HDMI LPCM Mix Audio Output HD Audio Output

Surround Effects

Speaker Distance

Speaker Volume

Test Tone Center Width 0 ~ 7 Dimension -3 ~ 3 Panorama On

Front Feet: 0 ~ 15

Center Feet: 0 ~ 3

Surround Feet: 0 ~ 3

Default Front Lch -10 ~ +10dB Center Subwoofer Front Rch Surround Rch Surround Lch Default

Off

Meters: 0 ~ 4.5

Meters: 0 ~ 0.9

continued on next page

EN - 41

Category Menus / Options

Network Network Connection Start

Connection Test

Network Status Wireless Status Disclaimer Digital Rights Mgmt Netflix ESN Deactivation Netflix

VUDU YouTube

BD-Live¬Setting

HDMI fun-Link (HDMI CEC) On

System Audio Control On

Audio Input Mapping

Video Resolution

Deep Color

Playback Language Auto

Audio

Allow Limited Allow

Prohibit

Off

Auto

480p Auto

Off

English

Español

Français

Original

Bulgarian Italian

Chinese Japanese

Czech Korean

Danish Norwegian

Dutch Polish

English Portuguese

Finnish Romanian

French Russian

German Slovak

Greek Spanish

Hungarian Swedish

Icelandic Turkish

Irish Other

EN - 42

continued on next page

Category Menus / Options

Playback Subtitle Off

Bulgarian Italian

Chinese Japanese

Czech Korean

Danish Norwegian

Dutch Polish

English Portuguese

Finnish Romanian

French Russian

German Slovak

Greek Spanish

Hungarian Swedish

Icelandic Turkish

Irish Other

Disc Menu Bulgarian Italian

Chinese Japanese

Czech Korean

Danish Norwegian

Dutch Polish English Portuguese

Finnish Romanian

French Russian

German Slovak

Greek Spanish

Hungarian Swedish

Icelandic Turkish

Irish Other

BD Rating Level

DVD Rating Level

Password Change

Angle Icon

Others Software Update Disc

Automatically check for latest software

Quick Start Mode* On

Product Info

Initialize Reset Settings

Off

Age Setting

Off

8 [Adult] 4 [PG-13]

7 [NC-17] 3 [PG]

6 [R] 2 [G]

5 [PGR] 1 [Kid Safe]

Off

Network

USB Memory Stick

Off

Format USB Memory Stick

(Unit) Erase Saved BD-ROM Data

(USB Memory Stick) Erase Saved BD-ROM Data Reset Network Settings

OSS

* When “Quick Start Mode” is set to “On”, power consumption during Standby mode will increase.

EN - 43

12. SETUPS

12.1. Network Connection

HOME A “Settings” A “Network” A “Network Connection”

Perform the network connection setup in order to use the network features, such as BD-Live™, DLNA home media server, Netflix, VUDU, Pandora, YouTube™ and the network update function.

 Connection Test

After you enable a network connection or change the network settings, always perform the connection test to check to see if the connection is correctly made.

1. Use [] to select “Settings” in the Home Menu, then press [OK].

2. Use [] to select “Network”, then press [OK].

3. Use [] to select “Network Connection”, then press [OK].

4. Use [] to select “Connection Test”, then press [OK].

• Connection test will automatically start. The test result will appear right after the test finishes.

- “Connecting...”: The test is in progress.

- “Pass”: Connection test is successfully completed.

- “Failed”: Connection test failed. Check the connection settings.

5. If the connection test passes, press [OK].

D Note

• If the connection test passes, you are ready to use BD-Live™, DLNA home media server, Netflix, VUDU, Pandora,

YouTube™ and network update function, using the Internet without making any additional settings.

• If the connection test fails, you may need to check your router settings and make sure the physical connection is

secure. If you need the MAC address of this unit to complete your router settings, you can view it on the “Network Status” / “Wireless Status” screen (refer to page 48).

• When connecting this unit directly to a modem for the first time or connecting it to a modem which was previously

connected to any other network device (e.g. a router, PC, etc.), you may have to power cycle the modem (unplug the modem’s and/or router’s AC plug from its AC outlet for 30 seconds and then plug it back in), this may reset the settings in the modem. If you have a telephone/Internet modem with your cable service then you may have to use its reset button or remove the backup battery to reset this type of modem.

• If “Home Network” failed on the connection test, this unit is not connected to the router / local network. In this case,

you cannot use your DLNA home media server(s).

• If “Internet” failed on the connection test, this unit is not connected to the Internet. In this case, you cannot use the

BD-Live™ function or access the network services, such as Netflix. (You can use your DLNA home server(s) as long as “Home Network” passed.) Please confirm the router settings or contact your ISP (Internet Service Provider) for troubleshooting assistance.

 Wired Connection

Select “Wired” if you made a wired connection and set the setting to “Auto” or “Manual”, in accordance with your network environment.

Auto (Wired)

Select “Auto” to set the network setting automatically.

1. Use [] to select “Network Setup” in the Home Menu, then press [OK].

2. Use [] to select “Wired”, then press [OK].

3. Use [] to select “Auto”, then press [OK].

• The unit will automatically start the connection test. The test result will appear right after the test finishes.

4. “Network connection succeeds.” will be displayed. Select “End” then press [OK] to complete the settings.

continued on next page

EN - 44

Manual (Wired)

Please input the IP Address.

Return Clear OK

0 . 0 . 0 . 0

Network Settings

Please enter your network settings.

IP Address

Subnet Mask

Default Gateway

Primary DNS

Secondary DNS

255

Return

Cancel

Please input the Proxy Address with software keyboard.

http://xxxxx.xxx

In the following cases, select “Manual” to set each setting as necessary.

- When connection test failed with the setting of “Auto”.

- When instructed by your Internet service provider to make specific settings in accordance with your network

environment.

1. Follow steps 1 and 2 in “Auto (Wired)” on page 44.

2. Use [] to select “Manual”, then press [OK].

3. Use [] to select “IP Address”, then press [OK].

4. “IP Address” setting screen will appear. Enter an IP address using the cursor buttons and the NUMBER buttons.

IP Address

• Enter an IP address after checking the specifications of your router.

• If an IP address is unknown, check the IP address of other devices (e.g. PC connected with a LAN cable). Then, in the furthest cell to the right, assign a different number from those other devices.

5. Use [] to select “OK”, then press [OK].

6. Configure “Subnet Mask”, “Default Gateway”, “Primary DNS” and “Secondary DNS” in the same manner.

• Enter the DNS addresses provided by your Internet service provider.

• If the DNS address is unknown, check the DNS address of other devices (e.g. PC connected via LAN cable) and assign the same DNS address.

5 / 7

7. Use [] to select “Next”, then press [OK].

8. Use [] to select “Yes” or “No” for proxy server, then press [OK].

• If you use a proxy server, select “Yes” then press [OK] to go to the next step.

• If you do not use a proxy server, select “No” then press [OK] to go to step 12.

9. “Proxy Address” setting screen will appear. Enter a proxy address using the cursor buttons, the NUMBER buttons and the color keys.

Access Point Setting

[]: [the NUMBER buttons] [OK]: [RED]*:

Used to move through the menu.

: Enter number (remote control).

Enter the selected setting. Confirm and set the network setting.

[GREEN]: Exit / Cancel network setting.

Done Return Clear a/A/@

[BLUE]*:

5 / 7

[YELLOW]:

* These buttons can be used in other network settings.

Clear the enter number or letters. Switch between different characters abc

(lower case), ABC (uppercase),and @!? (special characters).

continued on next page

EN - 45

10. Press [RED] to go to the “Proxy Port” setting screen.

Please input the Proxy Port.

Return Clear OK

65525

11. Enter the proxy port number using the NUMBER buttons, then select “OK”, then press [OK].

Proxy Port

12. Connection test confirmation screen will appear. Select “Yes”, then press [OK] to start the connection test. The test result will appear right after the connection test finishes.

13. “Network connection succeeds.” will be displayed. Select “End” then press [OK] to complete the settings.

D Note for “IP Address”, “Subnet Mask”, “Default Gateway”, “Primary DNS” and “Secondary DNS”

• The range of input numbers is between 0 and 255.

• If you enter a number larger than 255, the number will automatically be reset to 255.

• When you enter a wrong number, select “Clear” to clear the incorrect number. (The number will be set to “0”)

• If you want to enter a 1 or 2-digit number in one cell, press [] to move on to the next cell.

D Note for “Proxy Address” and “Proxy Port”

• The range of input numbers for the port number is between 0 and 65535. (If you enter a number larger than 65535, it will be regarded as 65535.)

• For proxy port, certain ports might be closed, blocked or unusable depending on your network environment.

• When the settings are changed, the network connection may be disabled depending on the device.

 Wireless Connection

If you connect this unit to a wireless network, select “Wireless” and set up necessary settings. Please make a note of your SSID (Service Set Identifier ȥ wireless network name) and its WEP* / WPA / WPA2 key before proceeding with the setup. * “Easy Connect (WPS)” cannot be used when the Security protocol is set to “WEP”.

Easy Connect (WPS)

Push Button Method

You can set up a Wireless connection quickly. (“Push Button Method” is only available when your router supports it. For details, please refer to the user manual of your wireless router.) Please confirm your wireless router has a PBC* (Push Button Configuration) button.

1. Use [] to select “Network Setup” in the Home Menu, then press [OK].

2. Use [] to select “Wireless”, then press [OK].

3. Use [] to select “Easy Connect (WPS)”, then press [OK].

4. Use [] to select “Push Button Method”, then press [OK]. Then within 2 minutes push the PBC* (Push Button Configuration) button on your wireless router. * PBC button may be called WPS (Wi-Fi Protection System) button on your wireless router.

• The unit will automatically start the Connection test. The test result will appear right after the test finishes.

Access Point Setting

Push Button Method

Please push the PBC (push button configuration) on the wireless router and select ‘Push Button Method’ button on screen.

PIN Code Method

Please input the PIN number into the wireless router and select ‘PIN Code Method’ button on screen.

Return

PIN Code is: xxxxxxxx

Cancel

5. “Network connection succeeds.” will be displayed. Select “End” then press [OK] to complete the settings.

EN - 46

2 / 7

continued on next page

PIN Code Method

1. Follow steps 1 and 2 in “Push Button Method” on page 46.

2. Set up your wireless router with the PIN code shown on the TV screen.

• For details about setting method of your wireless router, please refer to the user manual of the router.

3. Use [] to select “PIN Code Method”, then press [OK].

• The unit will automatically start the connection test. The test result will appear right after the test finishes.

4. “Network connection succeeds.” will be displayed. Select “End” then press [OK] to complete the settings.

Note

“Easy Connect (WPS)” cannot be used when the Security mode of your Access Point is set to “WEP”. Please try either method below.

• Connect the unit to the Access Point using “Auto Scan” or “Manual” mode.

• Change the Access Point's security mode from “WEP*” to “WPA” or “WPA2”.

* “WEP” is not recommended to be used due to its “Major security flaws”. Change the Security protocol on the wireless

router to “WPA” or “WPA2 (recommended)” mode. (For Access Point configuration, please consult the user manual of your wireless router or manufacturer.)

Auto Scan (Wireless)

1. Follow steps 1 and 2 in “Push Button Method” on page 46.

2. Use [] to select “Auto Scan”, then press [OK].

• This unit will automatically start searching for nearby wireless networks.

3. The search result will be displayed. Use [] to select an appropriate SSID, then press [OK].

• If you select an SSID with “ ” (no password is required), please go to step 5.

Access Point Setting

Please select the access point.

Wireless Access Point A

Wireless Access Point B

Wireless Access Point C

Retry

Return

Cancel

Wireless Access Point D

Wireless Access Point E

Wireless Access Point F

Wireless Access Point G

3 / 7

4. “WEP / WPA / WPA2 Key” entry screen will appear. Enter the WEP / WPA / WPA2 password of the selected wireless network using Cursor buttons, Number buttons and Color keys, then press [RED] to confirm the password.

• If you do not know the WEP / WPA / WPA2 key for your wireless network, please confirm the sticker on the router.

• The WEP / WPA / WPA2 key entries are case-sensitive.

Access Point Setting

Please input the WEP / WPA key with software keyboard.

Done Return Clear a/A/@

3 / 7

5. Use [] to select “Next”, then press [OK].

Access Point Setting

Retry

Return

Cancel

Please confirm the setting.

SSID

Security

WEP/WPA Key

: Wireless Access Point A

: WPA-PSK (AES)

: xxxxxxxxxxxxxxxxxxxxxxxx xxxxxxxxxx

3 / 7

6. Use [] to select “Auto” or “Manual”, then press [OK].

• If you select “Auto”, follow step 4 in “Auto (Wired)” on page 44.

• If you select “Manual”, follow steps 3 to 13 in “Manual (Wired)” on page 45.

continued on next page

EN - 47



Access Point Setting

Please select the security mode.

None

WEP

WPA-PSK (TKIP)

WPA-PSK (AES)

WPA2-PSK (AES)

WPA2-PSK (TKIP)

Return

Cancel

Note

• The internal wireless LAN supports following specifications.

- Wireless standards: IEEE 802.11 b/g/n

- Frequency: 2.4 GHz

- Security protocol: WEP* / WPA / WPA2

* “WEP” is not recommended to be used due to its “Major security flaws”. Change the Security protocol on the wireless

router to “WPA” or “WPA2 (recommended)” mode. (For Access Point configuration, please consult the user manual of your wireless router or manufacturer.)

Manual (Wireless)

Set up the connection to the wireless router manually by entering the SSID. In the following cases, select “Manual” to set each setting as necessary.

- When connection test failed with the setting of “Auto Scan”.

1. Follow steps 1 and 2 in “Push Button Method” on page 46.

2. Use [] to select “Manual”, then press [OK].

3. SSID entry screen will appear. Enter the SSID using the Cursor buttons, the Number buttons and the Color keys, then press [RED].

4. Security mode selection screen will appear. Use [] to select the desired Security mode, then press [OK].

• If you select “None”, please go to step 6.

3 / 7

5. “WEP / WPA / WPA2 Key” entry screen will appear. Enter the WEP / WPA / WPA2 password of the selected wireless

[

network using Cursor buttons, Number buttons and Color keys, then press

RED] to confirm the password.

• If you do not know the WEP / WPA / WPA2 key for your wireless network, please confirm the sticker on the

router.

• The WEP / WPA / WPA2 key entries are case-sensitive.

6. Use [] to select “Next”, then press [OK].

7. Use [] to select “Auto” or “Manual”, then press [OK].

• If you select “Auto”, follow step 4 in “Auto (Wired)” on page 44.

• If you select “Manual”, follow steps 3 to 13 in “Manual (Wired)” on page 45.

Network Status / Wireless Status

You can check the current status of network status and wireless status.

1. Follow steps 1 and 2 in “Connection Test” on page 44.

2. Use [] to select “Network Status” or “Wireless Status”, then press [OK].

• The current network settings or wireless router setting will be displayed.

3. Press [HOME] to return to the Home Menu.

Netflix ESN

You can view the ESN (Electronic Serial Number, which Netflix uses to identify your device). Netflix customer service might ask you for this number during troubleshooting.

1. Follow steps 1 and 2 in “Connection Test” on page 44.

2. Use [] to select “Netflix ESN”, then press [OK].

3. Press [HOME] to return to the Home Menu.

EN - 48

12.2. fun-Link (HDMI CEC)

HOME A “Settings” A “HDMI” A “fun-Link (HDMI CEC)”

fun-Link (HDMI CEC) allows integrated system control over HDMI and is part of the HDMI standard. This function may not work properly depending on the device connected to the unit. When “fun-Link (HDMI CEC)” setting is set to “On” the functions listed below will be available.

 One Touch Play

When the buttons below on the remote control are pressed then operations are performed on this unit, the TV will automatically be Turned On and switched to the appropriate video Source Input.

Buttons for one touch play:

- [(PLAY)], [(SKIP)], [(SKIP)], [the NUMBER buttons], [HOME]

- [TOP MENU], or [POP MENU/MENU] (when a disc is inserted in the unit)

 One Touch Standby

When you press and hold [(POWER-ON)] for 2 seconds, it Turns Off the power on the TV first and then Turns Off the power on this unit. When the connected fun-Link (HDMI CEC) compatible display device is Turned Off first, it then Turns Off the power to this unit.

 System Information Get & Set Menu Language

The unit recognizes the OSD language set on the TV and automatically sets the same language as the Player Menu Language (OSD menu language) for this unit. “Language” under “Playback” on page 42 for available languages.

• Feature is available only when “Auto” is selected in the Setup Menu “Language” section in “Settings” while connected via an HDMI cable.

System Audio Control

When you set your TV to output the audio from the 5.1ch speakers through this unit, you can control the volume level or mute the audio using TV’s remote control. (For more details, refer to the owner’s manual of your TV.)

D Note

• For external input mode, “One Touch Play” is not available.

• Volume level will be displayed on the TV screen.

• If you change the speaker setting on your TV to output the audio from TV's speaker, 5.1ch speakers will be muted. (To restore the volume, use the remote control of this unit.) Only when connected via HDMI cable to TV.

• When you switch this unit into Standby mode, TV’s speaker will be activated automatically. Only when connected via HDMI cable to TV.

• Depending on the connected TV, two device names (“MAGNAVOX BD” and “Audio System”) may be displayed in the device list on the TV’s menu screen. To select this unit, please select “MAGNAVOX BD”. Only when connected via HDMI cable to TV.

• If the system audio control does not work properly, please restart the unit.

EN - 49

12.3. Audio Input Mapping

Use to map a connected HDMI device to the correct Audio Input for automatic Audio Source switching. If your TV is compatible with HDMI-CEC System Audio Control, this unit will automatically switch to the selected audio Input to output sound from your TV. “Audio Input Mapping ” is only available when “System Audio Control” is set to “On”.

1. Use [] to select “Settings” in the Home Menu, then press [OK].

2. Use [] to select “HDMI”, then press [OK].

3. Use [] to select “Audio Input Mapping ”, then press [OK].

Video Out

Audio Out

Network

HDMI

Playback

Others

fun-Link (HDMI CEC)

System Audio Control

Audio Input Mapping

Video Resolution

Deep Color

> On

> Auto

4. Press [HOME] to Exit.

12.4. HDMI Video Resolution

HOME A “Settings” A “HDMI” A “Video Resolution”

Set the resolution of the video signal being output from the HDMI OUT jack. You can select the desired “Video Resolution” among the settings listed below: “Auto”,“480p”. Actual Output Resolution:

Setting in the

“

Video Resolution”

Auto

480i/60 720p/60 1080i/60 720p/24 1080p/24

The highest resolution supported by your display device will automatically be in effect.

480p

Composite video output (VIDEO OUT) jack can only output 480i/60.

• For AVCHD, outputting the video in 24 frames per second (1080p/24) is not available.

D Note

• The selected resolution must also be supported by your display device.

• If your TV and the unit are connected by a DVI cable and if “Auto” is selected, “480p” will be automatically in effect.

• Refer also to your TV’s manual.

• When connected to an HDCP incompatible display device, the picture will not be displayed properly.

• The audio signals from the HDMI OUT jack (including the sampling frequency, the number of channels and bit length) may be limited by the connected device.

• Among the display devices that support HDMI, some do not support audio output (for example, projectors). While connected to a device such as a projector, audio will not be output from the HDMI OUT jack.

• When this unit’s HDMI OUT jack is connected to a DVI-D compatible display device(s) (HDCP compatible) with an HDMI-DVI converter cable, the signals are output in digital RGB.

• HDMI video resolution does not work during the playback of a BD-video.

Source

480p/60

To play back the digital video images of a BD-video or DVD-video via an HDMI connection, it is necessary that both the player and the display device (or an AV receiver / amplifier) support a copyright protection system called HDCP (high-bandwidth digital content protection system). HDCP is copy protection technology that comprises data encryption and authentication of the connected AV device. This unit supports HDCP. Please read the operating instructions of your display device (or an AV receiver / amplifier) for more information.

EN - 50

12.5. Parental

Some BD-videos or DVD-videos feature parental lock levels. Playback will stop if the ratings exceed the levels you set, it will require you to enter a password before the disc will play back. This feature prevents your children from viewing inappropriate material.

1. Use [the NUMBER buttons] to enter your 4-digit password.

For the first time use:

Use [the NUMBER buttons] to enter any 4-digit number (except for 4737). That number will be used as the password. Record your password, in case you forget it.

• If you forget the password, enter [4], [7], [3], [7]. The password will be cleared and rating level will be set to “Off”.

• When you input the password, select “Clear” to clear the number, then re-enter the password.

 BD Rating Level

HOME A “Settings” A “Playback” A “BD Rating Level”

1. Use [] to select “Settings” in the Home Menu, then press [OK].

2. Use [] to select “Playback”, then press [OK].

3. Use [] to select “BD Rating Level”, then press [OK].

4. Use [the NUMBER buttons] to enter your 4-digit password.

5. Use [] to select your desired option, then press [OK].

“Off”: To release the limitation. “Age Setting”: To set the age limitation.

• After selecting “Age Setting”, use [the NUMBER buttons] to enter the age.

(e.g., For age 6, enter [6] + [OK]. For age 15, enter [1] + [5] + [OK].)

6. Press [HOME] to Exit.

 DVD Rating Level

HOME A “Settings” A “Playback” A “DVD Rating Level”

1. Use [] to select “Settings” in the Home Menu, then press [OK].

2. Use [] to select “Playback”, then press [OK].

3. Use [] to select “DVD Rating Level”, then press [OK].

4. Use [the NUMBER buttons] to enter your 4-digit password.

5. Use [] to select your desired level, then press [OK].

6. Press [HOME] to Exit.

RATING EXPLANATIONS

Off • Parental is inactive; all discs can be played back. 8 [Adult] • DVD software of any grades (adult / general / children) can be played back. 7 [NC-17] • No one under 17. 6 [R] • Restricted; under 17. 5 [PGR] • Parental Guidance Recommended. 4 [PG-13] • Unsuitable for children under 13. 3 [PG] • Parental Guidance suggested. 2 [G] • General Audience. 1 [Kid Safe] • Suitable for children.

continued on next page

EN - 51

 Password Change

www.magnavox.com

HOME A “Settings” A “Playback” A “Password Change”

1. Use [] to select “Settings” in the Home Menu, then press [OK].

2. Use [] to select “Playback”, then press [OK].

3. Use [] to select “Password Change”, then press [OK].

4. Use [the NUMBER buttons] to enter your 4-digit password.

5. Use [the NUMBER buttons] to enter a new 4-digit password.

6. Use [the NUMBER buttons] to retype the same new 4-digit password.

7. Use [] to select “OK”, then press [OK].

8. Press [HOME] to Exit.

To temporarily disable parental lock:

Some discs allow you to temporarily disable parental lock. With these discs, the message below will appear when you try to play them back. “Enter current password.” Follow the instruction which appears on the TV screen to disable parental lock.

12.6. Software Update

HOME A “Settings” A “Others” A “Software Update”

This unit lets you update the software yourself using a software update disc or USB Memory Stick or via the Internet. The available discs are below:

- BD-RE/-R

- DVD-RW/-R

- CD-RW/-R

 Disc / USB Memory Stick Update

You can update the software by using a disc or USB Memory Stick. Prepare a blank disc or USB Memory Stick for software update: Access , and download the latest version software to a blank disc or USB Memory Stick using a PC by following the directions described on the website.

• Use a blank disc or USB Memory Stick, download one software per disc or USB Memory Stick. Write the software in the root directory of the disc or USB Memory Stick.

• For more details on how to download the software, please refer to the website.

1. Use [] to select “Settings” in the Home Menu, then press [OK].

2. Use [] to select “Others”, then press [OK].

3. Use [] to select “Software Update”, then press [OK].

4. Use [] to select “Disc” or “USB Memory Stick”, then press [OK].

5. Use [] to select “Yes”, then press [OK].

6. Insert the disc or connect the USB Memory Stick for software update.

7. After loading disc or USB Memory Stick, confirmation message will appear. Select “Yes” and press [OK].

8. The unit will restart automatically, then software update will start.

• It may take a while to complete the updating.

9. After the update finishes, this unit will restart. Remove the disc or the USB Memory Stick from the unit.

C Caution

• Please do not unplug the AC power cord, eject the disc or disconnect the USB Memory Stick or press

[(POWER-ON)] to turn the unit to Standby mode while performing a “Disc / USB Memory Stick Update”.

EN - 52

continued on next page

D Note

• Software update will not change any of the current settings.

 Network Update

You can update the software by connecting the unit to the Internet.

1. Follow steps 1 to 3 in “Disc / USB Memory Stick Update” on page 52.

2. Use [] to select “Network”, then press [OK].

3. Use [] to select “Yes”, then press [OK].

• The unit will connect to the server, then check for the latest software version.

4. Confirmation message will appear. Select “Yes”, then press [OK].

5. The unit will restart automatically, then software update will start.

• The unit will start downloading the latest software version.

6. When the download completes, confirmation message will appear. Press [OK].

• The unit will start updating the software to the newer version.

• It may take a while to complete the updating.

7. After updating finishes, this unit will restart automatically.

C Caution

• Please do not unplug the AC power cord, LAN cable, wireless modem / router or press the unit to Standby mode while using “Network Update”.

D Note

• In order to update the software via the Internet, you must connect the unit to the Internet and set up necessary settings.

• For the network connection, refer to “Connection to the Network” on page 17.

• For the network setup, refer to “Network Connection” on page 44.

• Software update will not change any of the current settings.

[ (POWER-ON)]

to turn

EN - 53

12.7. Restore Default Settings

HOME A “Settings” A “Others” A “Initialize”

Menus to reset player settings, format a USB Memory Stick and clear network settings.

1. Use [] to select “Settings” in the Home Menu, then press [OK].

2. Use [] to select “Others”, then press [OK].

3. Use [] to select “Initialize”, then press [OK].

4. Use [] to select the desired setting, then press [OK].

“Reset Settings”:

All the settings except for the “Parental” and “Network Connection” settings will be reset to default.

“Format USB Memory Stick” (Only available when a USB Memory Stick is connected):

Initialize the USB Memory Stick.

“(Unit) Erase Saved BD-ROM Data”:

Clears the data saved for the BD-ROM contents, such as BD-ROM game scores, on this player.

“(USB Memory Stick) Erase Saved BD-ROM Data” (Only available when a USB Memory Stick is connected):

Clears the supplemental data for the BD-ROM playback, such as Subtitle data, from the USB Memory Stick.

“Reset Network Settings”:

Reset the network setting to the default.

5. Use [] to select “Yes”, then press [OK].

6. Confirmation message will appear. Press [OK] to complete the setting.

7. Press [HOME] to Exit.

C Caution

• Do not remove the USB Memory Stick while executing “Format USB Memory Stick” or “(USB Memory Stick) Erase Saved BD-ROM Data”. It will damage the USB Memory Stick.

D Note

• “Format USB Memory Stick” and “(USB Memory Stick) Erase Saved BD-ROM Data” are not available when a Blu-ray Disc™ is in the unit.

EN - 54

13. SOUND SETTINGS

13.1. Volume Control

You can control the volume level of the audio output from 5.1ch speakers.

To increase or decrease the volume level:

Press [VOL / ].

• The volume level will increase or decrease, every time you press [VOL ] or [VOL ].

• The volume level will be displayed on the TV screen. (When connected via an HDMI cable.)

To Turn Off the volume temporarily:

Press [MUTE].

• To restore the volume, press [MUTE] again or press [VOL / ].

• will be displayed on the TV screen. (When connected via an HDMI cable.)

D Note

• This function is only available for the audio output from 5.1ch speakers.

• Pressing [VOL / ] does not work while the Setup Menu is displayed.

• If you turn up the volume too much, the audio may get distorted. To enjoy clear sounds, please turn down the volume.

13.2. Selecting Surround Mode

Select the Surround mode for the audio output from 5.1ch speakers.

1. Press [MODE] to display the Play Menu.

2. Use [] to select “Surround”, then press [OK].

3. Use [] to select the desired Surround mode.

“Multi ch Stereo”: Set the Surround mode to “Multi ch Stereo”.

(5.1ch stereo sound from 5.1ch speakers.)

“Dolby Pro Logic II Movie”: Set the Surround mode to “Dolby Pro Logic II Movie”.

(Dolby Pro Logic II 5.1ch surround sound.)

“Dolby Pro Logic II Music”: Set the Surround mode to “Dolby Pro Logic II Music”.

(Dolby Pro Logic II 5.1ch surround sound.)

“Direct”:

“2.1ch Stereo”: Set the Surround mode to “2.1ch Stereo”.

D Note

• This function is effective only for the audio output from 5.1ch speakers.

• Mute will be deactivated when selecting “Surround” in the Play Menu while the audio is muted.

• For multi-channel and mono-channel audio, “ not effective.

Selects the appropriate audio decoder (stereo / multi-channel Dolby, DTS PCM) based on the input audio stream.

(2.1ch Stereo sound from front left/right speakers.)

Multi ch Stereo

”, “

Dolby Pro Logic II Movie

” or “

Dolby Pro Logic II Music

” is

EN - 55

13.3. Selecting Sound Effect Mode

Select the Sound effect mode for the audio output from 5.1ch speakers to suit your video or music.

1. Press [MODE] to display the Play Menu.

2. Use [] to select “Sound Mode”, then press [OK].

3. Use [] to select the desired Sound effect mode.

Video Music Description

Off Off Turns Off the sound effect mode. Action Rock Enhanced low and high-range. Ideal for action movies and rock or pop music. Drama Jazz Clear mid and high-range. Ideal for drama movies and jazz music. Concert Classic Neutral sound. Ideal for live concerts and classical music. Sports Sports Moderate mid-range and Surround effects for clear vocals and the atmosphere of a live

sport venue.

D Note

• This function is effective only for the audio output from 5.1ch speakers.

• Mute will be deactivated when selecting “Sound Mode” in the Play Menu while the audio is muted.

13.4. Audio Sync

HOME A “Settings” A “Audio¬Out” A “Audio Sync”

You can select delay between 5.1ch speaker sound and picture (range from 0 - 300 ms, by 50 ms steps).

1. Use [] to select “Settings” in the Home Menu, then press [OK].

2. Use [] to select “Audio¬Out”, then press [OK].

3. Use [] to select “Audio Sync”, then press [OK].

4. Use [] to select the desired setting, then press [OK].

D Note

• This function is effective only for the audio output from 5.1ch speakers.

• When “Audio Output” is set to “HDMI Normal” or “HDMI PCM”, this function can not be set.

13.5. Speaker Setup

HOME A “Settings” A “Audio¬Out” A “Speaker Setup”

1. Use [] to select “Settings” in the Home Menu, then press [OK].

2. Use [] to select “Audio¬Out”, then press [OK].

3. Use [] to select “Speaker Setup”, then press [OK].

4. Use [] to select the desired setting, then press [OK].

You can adjust the following:

“Surround Effects” “Speaker Distance” “Speaker Volume”

D Note

• This function is effective only for the audio output from 5.1ch speakers.

• When “Audio Output” is set to “HDMI Normal” or “HDMI PCM”, this function can not be used.

• The volume level will automatically increase to “30” in “Speaker Setup” if the current volume is lower than “30” (You also can manually adjust it using

EN - 56

[VOL / ]

). The volume level will be recovered to the original level when exiting “Settings”.

14. OTHER SETTINGS

14.1. Switching Active Source Mode

You can change the active Source mode to the desired external audio Inputs and enjoy audio from the connected device with the multi-channel surround sound capabilities. Press [SOURCE] repeatedly to select the desired Source mode.

“Aux”: Set the active Source mode to the AUDIO IN (AUX). “Coaxial”: Set the active Source mode to the DIGITAL AUDIO IN (COAXIAL).

14.2. Sleep Timer

The sleep timer enables the unit to switch to Standby mode automatically after the selected preset time.

To set the sleep timer:

1. Press [MODE] to display the Play Menu.

2. Use [] to select “Sleep Timer”, then press [OK].

3. Use [] to select the desired preset time.

“Off”: Turns Off the sleep timer. “15min.” : Sets the preset turn-off time to 15 minutes. “30min.”: Sets the preset turn-off time to 30 minutes. “60min.”: Sets the preset turn-off time to 60 minutes. “90min.”: Sets the preset turn-off time to 90 minutes. “120min.”: Sets the preset turn-off time to 120 minutes. “150min.”: Sets the preset turn-off time to 150 minutes.

To check the setting:

1. Press [MODE] to display the Play Menu.

2. Use [] to select “Sleep Timer”, then press [OK].

• The remaining time will be displayed.

To change the setting:

1. Press [MODE] to display the Play Menu.

2. Use [] to select “Sleep Timer”, then press [OK].

3. Use [] to toggle up/down the preset time until your desired preset time is displayed.

To cancel sleep timer:

1. Press [MODE] to display the Play Menu.

2. Use [] to select “Sleep Timer”, then press [OK].

3. Use [] to toggle up/down the preset time until “Off” is displayed.

D Note

• The sleep timer will be activated even if the unit is in operation.

• Sleep timer can only be set in the Play Menu.

EN - 57

15. TROUBLESHOOTING

Problem Tip

No power. Check the AC power cord, if it is properly connected.

Try another power outlet. Unplug the AC power cord, and wait for about 5-10 seconds. Plug it back

in and attempt to power On the unit.

No sound or picture. Make sure both the TV and Blu-ray™ Home Cinema are Turned On.

Confirm the connections to the TV are made properly as shown in the “CONNECTIONS” on page 12.

Check to see whether the connected TV or another device supports HDCP. (This unit will not output a video signal unless the other device supports HDCP.)

No reaction to the remote control. Reduce the distance to infrared sensor window.

Confirm that the player’s AC power cord is plugged into a powered outlet. Check the batteries in the remote control and make sure they are inserted

properly by + or - symbols. Aim the remote at the unit’s remote receiver. Then press any arrow key

and confirm the Power-On indicator dims and blinks when a remote button is pushed. Please check IR signal. Refer to “IR Signal Check” on page 65.

No Audio / Video signal on the display device via HDMI cable.

No high-definition video signal on the TV screen.

Distorted picture. Sometimes a small amount of picture distortion may appear. This is not a

Completely distorted picture or black / white picture with Blu-ray Disc™ / DVD.

No sound or distorted sound. Adjust the volume.

Picture freezes momentarily during disc playback.

If the unit is connected to a non-certified HDMI device, the Audio / Video signal will not output to that device.

Make sure the display device is on the correct Input / Video source. Perform the HDMI hotplug: Disconnecting the HDMI cable from the display

device, Turn On both devices, and replug the HDMI cable back in. Check with the TV manufacturer, if there are any software updates

available for the TV. Check to see if the HDMI cable is a certified version. Does the disc contain high-definition video? High-definition video is only

available when the disc contains it. Does the TV support high-definition video? High-definition video is only

available when the TV supports it.

malfunction. Connect this unit directly to the TV. If Audio / Video cables are connected

to a VCR, pictures may be distorted due to the VCR copyright protection system.

Make sure the disc is compatible with this unit.

Check to see if the speakers are connected correctly. Check the HDMI, COAXIAL and AUX connections as necessary. Make sure the HDMI cable is not plugged into an HDMI-DVI adapter or

Projector which does not handle Digital sound. Check the settings in “Audio¬Out” menu. Check the disc for fingerprints / scratches and clean with a soft cloth wiping

from the center to the outer edge.

EN - 58

continued on next page

Problem Tip

Cannot play back a disc. Make sure that the disc is playable on this unit.

Check the region code of the disc. This unit supports the following region codes.

- Blu-ray Disc™: “A”

- DVD: “ALL” or “1” For DVD-RW/-R, make sure that the disc is finalized. Clean the disc. Is the disc a newer title? This problem may be solved by software update.

Refer to “Software Update” on page 52.

No return to start-up screen when disc is removed.

Soft reset this unit by turning it Off for 30 seconds, then On again. To completely reset the unit, press and hold [(POWER-ON)] on the

front panel for 10 seconds to shut down the unit or unplug the AC power cord from the AC outlet for 5-10 seconds.

in the upper right hand corner of the TV

The operation is not possible.

screen. Buttons do not work or the unit stops

responding.

To soft reset the unit, press and hold [(POWER-ON)] on the front panel for 10 seconds to shut down the unit or to hard reset the unit by unplugging the AC power cord from the AC outlet for 5-10 seconds.

The unit does not respond to some operating commands during playback.

The unit cannot read Blu-ray Disc™ / DVD/ CD.

The operations may be prohibited by the disc. Refer to the instructions for the disc.

Condensation? (Let sit 1 or 2 hours) Check to see if the disc is compatible with this unit. (Refer to page 21.) Wipe dirt off the disc from the center to the outside or replace the disc.

Refer to “Cleaning Discs” on page 65.

Scene shooting Angle does not switch. Angles cannot be switched for Blu-ray Disc™ / DVD which do not contain

multiple Angles. In some cases multiple Angles are only recorded for specific scenes.

Playback does not start when a Title is

Check the settings in “Parental” menu.

selected. The password for rating level has been

forgotten. Error message appears when I select “Auto”

in the “Language”.

Enter the default password “4737”, then your forgotten password will be cleared. Then to change password go to “Password Change” on page 52.

Make sure that the unit is connected to a MAGNAVOX brand fun-Link (HDMI CEC) TV and the “fun-Link (HDMI CEC)” is set to “On”.

This error message may appear when your TV's OSD language is not supported by this unit.

Cannot play back AVCHD file. This unit cannot play back stand-alone AVCHD files (*.m2ts, *.mts or

*.m2t) written to a DVD. The DVD containing AVCHD files must have a proper file and folder structure meeting AVCHD format specifications. Please use AVCHD compliant device / software to burn or copy AVCHD files to DVD. (Please refer to user manuals of the device / software for more information.)

The capacity of the USB Memory Stick decreased.

Cannot play back a MPEG-2 video and audio

Data may be written on the USB Memory Stick when a BD-video uses the Virtual Package feature while a USB Memory Stick is connected to the unit.

MPEG-2 is not compatible with this unit.

from the USB Memory Stick. Cannot read the contents on the USB

Memory Stick.

The USB Memory Stick is not compatible with this unit or the contents may be damaged.

Try and Turn Off the unit, then turn it back On. To soft reset the unit, press and hold [(POWER-ON)] on the front

panel for 10 seconds to shut down the unit or to hard reset the unit by unplugging the AC power cord from the AC outlet for 5-10 seconds.

continued on next page

EN - 59

Problem Tip

Cannot play back BD-video (BD-ROM Profile

2.0).

Connect a USB Memory Stick (1GB or more of available memory) which is formatted on this unit. Some discs with BD-Live™ function require memory when playing back the content.

Do not disconnect the USB Memory Stick during playback.

Cannot load a Blu-ray Disc™ (stuck in “Loading…” mode) and cannot Open the disc

Unplug unit from AC outlet for 20 seconds. Plug unit back in and press the [ (OPEN/CLOSE)] on the unit to eject the disc.

tray to eject the disc. The software update screen appears after

turning On the unit.

Please complete the software update. When the software update has failed, the software update screen will keep

appearing after turning the unit on. If the software update continues failing, please try it by using a USB Memory Stick with the update software installed in its root directory. In this case, please change the file name as below. “E****UD10000FA1.bin” Ȼ “UPDATE10000FA1.BIN” Do not change the numbers. The file name is case sensitive.

Cannot read a USB Memory Stick. The format of the USB Memory Stick is not compatible with this unit.

Please try and format it on this unit (All data will be deleted).

Cannot play back JPEG files from a disc. Cannot play back JPEG files from a disc. Make sure that the disc was

recorded in the UDF, ISO9660 or JOLIET format.

Cannot find a JPEG file. Make sure that the selected Group (folder) does not contain more than

9,999 files for Blu-ray Disc™ / DVD / USB Memory Stick and 999 files for CD.

Make sure that the file extension is .jpg / .JPG / .jpeg / or .JPEG.

Cannot play back MP3 files from a disc. Make sure that the disc was recorded in the UDF, ISO9660 or JOLIET

format. Make sure that the bit rate of the MP3 files is between 112 and 320 kbps Make sure that the sample rate of the MP3 files is 32 kHz, 44.1 kHz or 48 kHz.

Cannot find an MP3 file. Make sure that the selected folder does not contain more than 9,999 files

for Blu-ray Disc™ / DVD / USB Memory Stick and 999 files for CD. Make sure that the file extension is .mp3 or .MP3 for MP3 files.

No 5.1-channel audio from the speaker system.

Does the disc contain 5.1-channel audio? The 5.1-channel audio is only available when the disc contains it.

Set “Audio Output” to “Speakers” in “Settings”. Press

Video and Audio from the supplied speakers are not synchronized.

[MODE]

Set the audio delay time (0 - 300 ms) in “Audio Sync” under “Audio¬Out” in “Settings”. “Audio Sync” only functions when the supplied speakers are

then check to see if the surround mode is not set to “2.1ch Stereo”.

connected to the unit using 5.1ch sound audio output.

No Audio from the speaker system. Increase the volume level of the speaker system.

Set “Audio Output” to “Speakers” in “Settings”. Make sure that audio is not muted. Make sure you have selected the correct active Source for external audio Input.

Cannot connect to the network. Check to see if the modem / router has Power turned On.

Confirm if the Internet light is showing activity (light blinking) on the modem / router.

Check network settings on the unit. Power cycle the modem’s and/or router’s AC plug from its AC outlet for

30 seconds, and then plug it back in. Then, try reconnecting cords. If you have a telephone / Internet modem with your cable service, then you may have to use its reset button or remove the backup battery to reset this type of modem. Now wait for the lights to show activity and try reconnecting.

Check the cable connection to the router. Turn On the DHCP function on the router.

EN - 60

continued on next page

Problem Tip

netflix.com/magnavox

netflix.com

http://my.vudu.com

www.vudu.com

Cannot use “Easy Connect (WPS)” to connect to the Access Point.

If the Access Point's security mode is set to “WEP”, change the setting to “WPA” or “WPA2 (recommended)”, then try “Easy Connect (WPS)” again. Refer to “

Note” on page 47. (For Access Point configuration, please

consult its user manual or manufacturer.) Connect the unit to the Access Point using “Auto Scan” or “Manual” mode.

Cannot use the wireless connection. Once you have activated the wireless connection please wait 30 seconds

for the connection to be established after Turning On the unit, before trying to access network features such as BD-Live™, DLNA home network

server and the third-party network services. If appears in the upper left corner of the Home Menu screen, this unit is connected to an Access Point.

Please contact your ISP for further assistance when you cannot access BD-Live™ or network services.

Cannot connect to the network while my PC is connected to the network.

Cannot use the BD-Live™ function or download of data does not perform properly.

Check the content of your Internet service contract to see if your Internet Service Provider prevents multiple terminals connecting at the same time.

Connect a USB Memory Stick before inserting the disc. Connect a USB Memory Stick with enough capacity (1GB or more of available memory). Check to see if the USB Memory Stick is properly connected.

Folder or files stored on DLNA home media server are not displayed in the file list or files do not play back.

Check the settings on your home media server. (Refer to the user manual of the home media server.)

Check the network connection and settings.

Cannot use Netflix feature. Netflix is only available in the United States.

Check to see if the network connection is properly made.

Visit on your PC and become a Netflix member.

Cannot add Movies or TV episodes to the instant Queue.

The picture quality of a Netflix streaming movie does not improve even though my Internet connection speed improved during playback.

The picture quality of Netflix streaming movie is poor.

Netflix streaming movie often stops or starts

Visit on your PC.

You may add from the player or visit and login to your account by web.

The picture quality does not change during playback. The picture quality differs based on the Internet connection speed at the

time the streaming movie is loading. Check your Internet connection speed. Contact your Internet service provider. (You may need to improve the broadband speed.) Contact your Internet service provider. (You may need to improve the broadband speed.)

buffering during playback. Cannot use the VUDU service. VUDU is only available in the United States.

Check to see if the network connection is properly made.

Cannot rent or buy Movies / TV shows on VUDU.

You need to activate the VUDU account.

Log into your account at and check your payment information.

The picture quality of VUDU movie is poor. Check your Internet connection speed. You need speeds of at least 9 Mbps

to this player for high quality uninterrupted playback.

VUDU movie often stops or starts buffering during playback.

Check your Internet speed. The following are the required connection speeds for picture quality for uninterrupted streaming. SD quality (1 Mbps - 2 Mbps), HD quality (2.25 Mbps - 4.5 Mbps), HDX quality (4.5 Mbps - 9 Mbps) Please

confirm your Internet environment on

Cannot use the Pandora® feature.

Pandora is only available in the United States. Check to see if the network connection is made properly.

You must create a Pandora account and activate this unit. Cannot use the YouTube™ service. Check to see if the network connection is properly made. The picture quality of the YouTube™ video

is poor.

You may experience frequent buffering, distorted pictures or no picture at

all depending on your network environment and Internet traffic.

The picture and sound quality differ depending on the Internet service provider.

Note

• Do not attempt to repair the Blu-ray™ Home Cinema yourself. This may cause severe injury, irreparable damage to your Blu-ray™ Home Cinema and void your warranty.

• Please have available your Blu-ray™ Home Cinema model and serial number before contacting us. These numbers are available on the cabinet, as well as on the packaging.

EN - 61

16. LANGUAGE CODE LIST

Language Code Language Code Language Code Language Code

A-B

Abkhazian 4748 Frisian 5271 Malagasy 5953 Slovak [SLO] 6557

Afar 4747 Galician 5358 Malay 5965 Slovenian 6558

Afrikaans 4752 Georgian 5747 Malayalam 5958 Somali 6561

Albanian 6563 German [GER] 5051 Maltese 5966 Spanish [SPA] 5165

Amharic 4759 Greek [GRE] 5158 Maori 5955 Sundanese 6567

Arabic 4764 Greenlandic 5758 Marathi 5964 Swahili 6569

Armenian 5471 Guarani 5360 Moldavian 5961 Swedish [SWE] 6568

Assamese 4765 Gujarati 5367 Mongolian 5960

Aymara 4771 Hausa 5447 Nauru 6047 Tagalog 6658

Azerbaijani 4772 Hebrew 5569 Nepali 6051 Tajik 6653

Bashkir 4847 Hindi 5455 Norwegian [NOR] 6061 Tamil 6647

Basque 5167 Hungarian [HUN] 5467

Bengali;Bangla 4860

Bhutani 5072 Icelandic [ICE] 5565 Oriya 6164 Thai 6654

Bihari 4854 Indonesian 5550 Oromo (Afan) 6159 Tibetan 4861

Bislama 4855 Interlingua 5547 Panjabi 6247 Tigrinya 6655

Breton 4864 Interlingue 5551 Pashto;Pushto 6265 Tonga 6661

Bulgarian [BUL] 4853 Inupiak 5557 Persian 5247 Tsonga 6665

Burmese 5971 Irish [GLE] 5347 Polish [POL] 6258 Turkish [TUR] 6664

Byelorussian 4851 Italian [ITA] 5566 Portuguese [POR] 6266 Turkmen 6657

C-E

Cambodian 5759 Javanese 5668 Rhaeto-Romance 6459

Catalan 4947 Kannada 5760 Romanian [RUM] 6461 Ukrainian 6757

Chinese [CHI] 7254 Kashmiri 5765 Russian [RUS] 6467 Urdu 6764

Corsican 4961 Kazakh 5757

Croatian 5464 Kinyarwanda 6469 Samoan 6559 Vietnamese 6855

Czech [CZE] 4965 Kirghiz 5771 Sangho 6553 Volapuk 6861

Danish [DAN] 5047 Kirundi 6460 Sanskrit 6547 Welsh 4971

Dutch [DUT] 6058 Korean [KOR] 5761 Scots Gaelic 5350 Wolof 6961

English [ENG] 5160 Kurdish 5767 Serbian 6564 Xhosa 7054

Esperanto 5161

Estonian 5166 Laothian 5861 Sesotho 6566 Yoruba 7161

F-H

Faroese 5261 Latvian;Lettish 5868 Shona 6560

Fiji 5256 Lingala 5860 Sindhi 6550

Finnish [FIN] 5255 Lithuanian 5866 Singhalese 6555

French [FRE] 5264 Macedonian 5957 Siswat 6565

I-K

O-R

Occitan 6149 Telugu 6651

Tatar 6666

Japanese [JPN] 5647 Quechua 6367 Twi 6669

U-Z

L-N

Serbo-Croatian 6554 Yiddish 7155

Uzbek 6772

Latin 5847 Setswana 6660 Zulu 7267

D Note

• If you choose a language that has a 3-letter-language code (written in bracket), the code will be displayed every time you change the Subtitle language setting on page 34 or audio language setting on page 35. If you choose any other languages, “---” will be displayed instead.

EN - 62

17. SPECIFICATIONS

General

Signal system NTSC Color Power requirements 120 V AC, 60 Hz Power consumption 30 W (standby: 0.45 W) Total Output Power (Amplifier) Home Cinema mode: 300 W

FTC* output power: 160 W

* (Main Ch @ 1 kHz within 1 % THD, Sub Ch 60 Hz within 1 % THD)

Dimensions (width x height x depth) 17.2 x 2.4 x 9.9 inches (435.0 x 59.0 x 250.0 mm) Weight Total weight: 17.64 lbs. (8.00 kg)

Main unit: 5.52 lbs. (2.50 kg) Operating temperature 41°F (5°C) to 104°F (40°C) Operating humidity Less than 80 % (no condensation)

Terminals

USB input

TYPE A

Analog audio output (SPEAKERS (3Ω))

Front and rear speakers System: Full range satellite

Impedance: 3Ω

Frequency response: 200 Hz ~ 20 kHz

Dimensions: 3.1 x 4.7 x 2.8 inches (76.9 x 118.9 x 70.0 mm)

Speaker cable length: front - 98.5 inches (2500.0 mm)

rear - 295.3 inches (7500.0 mm)

Weight: front - 0.71 lbs. (0.32 kg)

rear - 0.80 lbs. (0.36 kg)

Center speaker System: Full range satellite

Impedance: 3Ω

Frequency response: 200 Hz ~ 20 kHz

Dimensions: 5.6 x 3.4 x 2.8 inches (141.9 x 84.9 x 70.0 mm)

Speaker cable length: 78.8 inches (2000.0 mm)

Weight: 0.95 lbs. (0.43 kg)

Subwoofer Impedance: 3Ω

Speaker drivers: 5.2 inches Full Range (130.0 mm) woofer

Frequency response: 73 Hz ~ 8 kHz

Dimensions: 5.8 x 11.5 x 10.4 inches (145.7 x 291.5 x 264.0 mm)

Speaker cable length: 98.5 inches (2500.0 mm)

Weight: 5.54 lbs. (2.51 kg)

Video output

RCA jack x 1 1 Vp-p (75Ω)

Analog audio input (AUX)

RCA jacks(L / R) x 1 L/R: 2 Vrms (47kΩ)

Digital audio input (COAXIAL)

RCA jack x 1 500 mVp-p (75Ω)

HDMI output

HDMI jack x 1 Digital Video: 480p, 720p, 1080i, 1080p, 1080p24 / Digital Audio

LAN terminal 10BASE-T / 100BASE-TX Wireless LAN (Internal) IEEE 802.11 b/g/n

D Note

• The specifications and design of this product are subject to change without notice.

EN - 63

18. NETWORK SERVICE DISCLAIMER

Content and services made available through this product are transmitted by third parties by means of networks and transmission facilities over which Company has no control and third party services may be terminated or interrupted at any time, and Company makes no representation or warranty that any content or service will remain available for any period of time. Without limiting the generality of this disclaimer, Company expressly disclaims any responsibility for any interruption or suspension of any content or service made available through this product. Company is not responsible for customer service related to the content and services. Any question or request for service relating to the content or services should be made directly to the respective content and service providers.

THIRD PARTY CONTENT AND SERVICES MADE AVAILABLE THROUGH THIS PRODUCT ARE PROVIDED “AS IS.” COMPANY DOES NOT WARRANT CONTENT OR SERVICES SO PROVIDED, FOR ANY PURPOSE WHATSOEVER. COMPANY EXPRESSLY DISCLAIMS ANY WARRANTIES, EXPRESS OR IMPLIED INCLUDING WITHOUT LIMITATION, WARRANTIES OF MERCHANTABILITY OR FITNESS FOR A PARTICULAR PURPOSE, ACCURACY, VALIDITY, TIMELINESS, LEGALITY, SUITABILITY, OR QUALITY OF ANY CONTENT OR SERVICE MADE AVAILABLE THROUGH THIS PRODUCT.

IN NO EVENT SHALL COMPANY BE LIABLE FOR, ANY DAMAGES, WHETHER ARISING IN CONTRACT OR TORT, INCLUDING WITHOUT LIMITATION, ANY DIRECT, INDIRECT, INCIDENTAL, SPECIAL OR CONSEQUENTIAL DAMAGES, LOST PROFITS, ATTORNEY FEES, EXPENSES, OR ANY OTHER DAMAGES ARISING OUT OF, OR IN CONNECTION WITH, ANY CONTENT (OR ANY INFORMATION CONTAINED THEREIN) OR SERVICE PROVIDED TO THE USER OR ANY THIRD PARTY, EVEN IF ADVISED OF THE POSSIBILITY OF SUCH DAMAGES.

All content and services accessible through this product belong to third parties and are protected by copyright, patent, trademark and/or other intellectual property rights. Such content and services are provided solely for the User’s personal noncommercial use. User may not use any content or services in a manner that has not been authorized by the content owner or service provider. Without limiting the foregoing, unless expressly authorized by the applicable content owner or service provider, you may not modify, copy, republish, upload, post, transmit, translate, sell, create derivative works, exploit, or distribute in any manner or medium any content or services made available through this product.

EN - 64

19. MAINTENANCE

www.magnavox.com/support

 Servicing

• Please refer to relevant topics on “TROUBLESHOOTING” on page 58 before returning the product.

• If this unit becomes inoperative, do not try to correct the problem by yourself. There are no user-serviceable parts inside. Eject the disc (if possible), disconnect the USB Memory Stick (if connected to the unit), place the unit into

Standby mode, unplug the AC power plug, and please contact: 1-800-605-8610 or visit :

 Cleaning the Cabinet

• Wipe the front panel and other exterior surfaces of the unit with a soft cloth.

• Never use a solvent, thinner, benzene or alcohol to clean the unit. Do not spray insecticide liquid near the unit. Such chemicals may discolor the surface or damage the unit.

 Cleaning Discs

• When a disc becomes dirty, clean it with a cleaning cloth. Wipe the disc from the center to outside. Do not wipe in a circular motion.

• Do not use solvents such as benzine, thinner, commercially available cleaners, detergent, abrasive cleaning agents or antistatic spray intended for analog records.

 Cleaning the Disc Lens

• If this unit still does not perform properly although you refer to the relevant sections and to “TROUBLESHOOTING” in this user manual, the laser optical pickup unit may be dirty. Consult your dealer or an Authorized Service Center for inspection and cleaning of the laser optical pickup unit.

 Disc Handling

• Handle the discs so that fingerprints and dust do not adhere to the surfaces of the discs.

• Always store the disc in its protective case when it is not used.

• Note that discs with special shapes (heart-shaped discs, octagonal discs, etc.) cannot be played back on this unit. Do not attempt to play such discs, as they may damage the unit.

 IR Signal Check

If the remote control does not work properly, you can test IR signal using a digital camera (including a cellphone with a built-in camera) to see if the remote control sends out the infrared signal.

1. Turn On the digital camera.

2. Direct a digital camera to the remote control, then press and hold any button on the remote control.

• If infrared light appears on the digital camera display, the remote control is working.

EN - 65

20. TRADEMARK INFORMATION

http://www.netflix.com/HowItWorks

http://www.pandora.com

http://www.vudu.com/product_overview.html

Manufactured under license from Dolby Laboratories. Dolby, Pro Logic, and the double-D symbol are trademarks of Dolby Laboratories.

Manufactured under license under U.S. Patent Nos: 5,956,674; 5,974,380; 6,226,616; 6,487,535; 7,392,195; 7,272,567; 7,333,929; 7,212,872 & other U.S. and worldwide patents issued & pending. DTS-HD, the Symbol, & DTS-HD and the Symbol together are registered trademarks & DTS-HD Master Audio | Essential is a trademark of DTS, Inc. Product includes software. © DTS, Inc. All Rights Reserved.

The terms HDMI and HDMI High-Definition Multimedia Interface, and the HDMI Logo are trademarks or registered trademarks of HDMI Licensing LLC in the United States and other countries.

Netflix and the Netflix logo are trademarks or registered trademarks of Netflix, Inc.

PANDORA, the PANDORA logo, and the Pandora trade dress are trademarks or registered trademarks of Pandora Media, Inc. Used with permission.

VUDU™ is a trademark of VUDU, Inc.

YouTube and the YouTube logo are trademarks of Google Inc.

“x.v.Color” and “x.v.Color” logo are trademarks of Sony Corporation.

Java and all Java based trademarks and logos are trademarks or registered trademarks of Oracle and/or its affiliates.

EN - 66

DLNA

, the DLNA Logo and DLNA CERTIFIED® are trademarks, service marks, or certification marks of the Digital Living Network Alliance.

The Wi-Fi CERTIFIED Logo is a certification mark of the Wi-Fi Alliance.

continued on next page

Kodak and KODAK Picture CD Compatible are trademarks of Kodak used under license.

“AVCHD” and the “AVCHD” logo are trademarks of Panasonic Corporation and Sony Corporation.

“Blu-ray Disc™”, “Blu-ray™” and “Blu-ray Disc™” logo are trademarks of the Blu-ray Disc Association.

is a trademark of DVD Format/Logo Licensing Corporation.

“BD-Live™” and “BD-Live™” logo are trademarks of the Blu-ray Disc Association.

THIS PRODUCT IS LICENSED UNDER THE AVC PATENT PORTFOLIO LICENSE FOR THE PERSONAL AND NON-COMMERCIAL USE OF A CONSUMER TO (i) ENCODE VIDEO IN COMPLIANCE WITH THE AVC STANDARD (“AVC VIDEO”) AND/OR (ii) DECODE AVC VIDEO THAT WAS ENCODED BY A CONSUMER ENGAGED IN A PERSONAL AND NON-COMMERCIAL ACTIVITY AND/OR WAS OBTAINED FROM A VIDEO PROVIDER LICENSED TO PROVIDE AVC VIDEO. NO LICENSE IS GRANTED OR SHALL BE IMPLIED FOR ANY OTHER USE. ADDITIONAL INFORMATION MAY BE OBTAINED FROM MPEG LA, L. L. C. SEE HTTP://WWW.MPEGLA.COM

THIS PRODUCT IS LICENSED UNDER THE VC-1 PATENT PORTFOLIO LICENSE FOR THE PERSONAL AND NON-COMMERCIAL USE OF A CONSUMER TO (i) ENCODE VIDEO IN COMPLIANCE WITH THE VC-1 STANDARD ("VC-1 VIDEO") AND/OR (ii) DECODE VC-1 VIDEO THAT WAS ENCODED BY A CONSUMER ENGAGED IN A PERSONAL AND NONCOMMERCIAL ACTIVITY AND/OR WAS OBTAINED FROM A VIDEO PROVIDER LICENSED TO PROVIDE VC-1 VIDEO. NO LICENSE IS GRANTED OR SHALL BE IMPLIED FOR ANY OTHER USE. ADDITIONAL INFORMATION MAY BE OBTAINED FROM MPEG LA, L.L.C. SEE HTTP://WWW.MPEGLA.COM

MPEG Layer-3 audio coding technology licensed from Fraunhofer IIS and Thomson.

“BONUSVIEW™” and “BONUSVIEW™” logo are trademarks of the Blu-ray Disc Association.

EN - 67

21. GLOSSARY

http://www.cinavia.com

AACS

Advanced Access Content System (AACS) is the content protection scheme used with Blu-ray discs.

Analog Audio

An electrical signal that directly represents sound. Compare this to digital audio which can be an electrical signal, but is an indirect representation of sound. See also “Digital Audio”.

Aspect Ratio

The width of a TV screen relative to its height. Conventional TVs are 4:3 (in other words, the TV screen is almost square); widescreen models are 16:9 (the TV screen is almost twice as wide as its height).

AVCHD

AVCHD is a new format for high definition video camcorders which can record and play high-resolution HD images.

BD-Live™

BD-Live™ is a BD-video (BD-ROM version 2 Profile 2.0) which contains new functions (e.g. Internet connection), in addition to the BONUSVIEW™ function.

Blu-ray Disc™

Blu-ray Disc™ is a next generation optical video disc which is capable of storing much more data than a conventional DVD. The large capacity makes it possible to benefit from the features such as high-definition videos, multi-channel surround sounds, interactive menus and so on.

Chapter

Just as a book is split up into several chapters, a Title on a BD-video or DVD-video is usually divided into chapters. See also “Title”.

Cinavia™

Cinavia Notice This product uses Cinavia technology to limit the use of unauthorized copies of some commercially-produced film and videos and their soundtracks. When a prohibited use of an unauthorized copy is detected, a message will be displayed and playback or copying will be interrupted. More information about Cinavia technology is provided at the Cinavia Online Consumer Information Center at

To request additional information about Cinavia by mail, send a postcard with your mailing address to: Cinavia Consumer Information Center, P.O. Box 86851, San Diego, CA, 92138, USA. This product incorporates proprietary technology under license from Verance Corporation and is protected by U.S. Patent 7,369,677 and other U.S. and worldwide patents issued and pending as well as copyright and trade secret protection for certain aspects of such technology. Cinavia is a trademark of Verance Corporation. Copyright 2004-2010 Verance Corporation. All rights reserved by Verance. Reverse engineering or disassembly is prohibited.

EN - 68

Default Gateway

IP address of the electronic devices (such as router) which provide Internet access.

Digital Audio

An indirect representation of sound by numbers. During recording, the sound is measured at discrete intervals (44,100 times a second for CD audio) by an analog-to-digital converter, generating a stream of numbers. On playback, a digital-to-analog converter generates an analog signal based on these numbers. See also “Sampling Frequency” and “Analog Audio”.

DLNA (Digital Living Network Alliance)

DLNA is a cross-industry organization of consumer electronics that formulates DLNA Interoperability Guidelines for sharing digital contents within a home network.

DNS Server

A server which translates Internet domain names into IP addresses.

Dolby Digital

The system to compress digital sound developed by Dolby Laboratories. It offers you sound of stereo (2ch) or multi-channel audio.

Dolby Digital Plus

Dolby Digital Plus is the next generation digital audio compression technology developed as an extension to Dolby Digital. Blu-ray Disc™ supports 7.1 multi-channel surround sound output.

Dolby Pro Logic II

Dolby Pro Logic II technology processes any high quality stereo (two-channel) movie and music audio into five playback channels of full-bandwidth surround sound. A matrix surround decoding technology, Dolby Pro Logic II detects the directional cues that occur naturally in stereo content and uses these elements to create a five-channel surround sound playback experience.

Dolby TrueHD

Dolby TrueHD is a lossless coding technology developed for next generation optical discs. Blu-ray Disc™ supports

7.1 multi-channel surround sound output.

DTS® (Digital Theater System)

DTS® is a multi channel surround sound system. You can enjoy movie dynamic and realistic sound like movie theater. DTS surround sound technologies were developed by DTS, Inc.

DTS-HD

DTS-HD® is a lossless coding technology developed as an extension of the original DTS Coherent Acoustics format. Blu-ray Disc™ supports 7.1 multi-channel surround sound output.

continued on next page

HDMI (High-Definition Multimedia Interface)

A digital interface between an audio and video Source. It can transmit component video, audio, and control signal with one cable connection.

IP Address

A set of numbers which are assigned to devices participating in a computer network.

JPEG (Joint Photographic Experts Group)

JPEG is a method of compressing still picture files. You can copy JPEG files on BD-RE/-R, DVD-RW/-R, CD-RW/-R, or USB Memory Stick from a computer and play back the files on this unit.

LAN (Local Area Network)

A group of computer networks covering a small area like a company, school or home.

Local Storage

A storage area of sub contents for playing virtual packages on BD-video.

MP3 (MPEG audio layer 3)

MP3 is a method of compressing files. You can copy MP3 files on BD-RE/-R, DVD-RW/-R, CD-RW/-R, or USB Memory Stick from the computer and play back the files on this unit.

Netflix

Netflix is online movie rental service, offering online streaming to customers in the United States.

Pandora

Pandora is a popular personalized internet radio service. You can instantly listen to free personalized radio stations streamed over the internet from Pandora. Pandora is only available in the United States.

PCM (Pulse Code Modulation)

The most common system of encoding digital audio, found on CD and DAT. Excellent quality, but requires a lot of data compared to formats such as Dolby Digital and MPEG audio. For compatibility with digital audio recorders (CD, MD and DAT) and AV amplifiers with digital Inputs, this unit can convert Dolby Digital, DTS, and MPEG audio to PCM. See also “Digital Audio”.

Proxy Server

Proxy server is a server which acts as an intermediary between a workstation user and the Internet to ensure security.

Region Code

Regions associate discs and players with particular areas of the world. This unit will only play back discs that have compatible region codes. You can find the region code of your unit by looking on the rear panel. Some discs are compatible with more than one region (or all regions).

Router

A networking device which distinguishes the IP address assigned to each device and routing and forwarding information in the computer network.

Sampling Frequency

The rate which sound is measured by a specified interval to turn into digital audio data. The numbers of sampling in one second defines as sampling frequency. The higher the rate, the better the sound quality.

Subnet Mask

A mask which is used to determine what subnet an IP address belongs to.

Switch / Hub

A device used for connecting multiple devices to the network.

Title

A collection of chapters on BD-video or DVD-video. See also “Chapter”.

Track

Audio CD uses Tracks to divide up the content of a disc. The BD-video or DVD-video equivalent is called a Chapter. See also “Chapter”.

Virtual Package

The function which copies data to other media (local storage) from the Internet and plays Secondary Video, Secondary Audio and subtitles at the same time. The method of the playback varies depending on the disc.

VUDU

VUDU is a leading HD on-demand video service which utilizes the Internet connection to deliver the highest quality on-demand video and Internet applications.

x.v.Color

“x.v.Color” is a promotion name given to the products that have the capability to realize a wide color space based on the xvYCC specifications and is a trademark of Sony Corporation.

YouTube™

YouTube™ is one of the video-sharing web sites which you can view a large number of videos posted on the web site for free. Not only can you view videos on YouTube™, you can upload your original video clips and share them with your friends all over the world.

EN - 69

13* 14

19 20

6 7*

8 9

22. ESPAÑOL

22.1. Mando a Distancia

* La unidad también se puede encender pulsando estos

botones.

1. Botón (ENCENDIDO)

• Pulse el botón para encender la unidad, o para pasar la unidad al modo de espera. (Para apagar completamente la unidad, debe desconectar el cable de alimentación de CA.)

2. Botón TOP MENU Blu-ray Disc™:

DVD: Púlselo para mostrar el menú de títulos.

3. Botones de

• Púlselos para seleccionar elementos o configuraciones.

4. Botón MODE

• Durante la reproducción, púlselo para visualizar el

menú de reproducción.

ES - 70

Púlselo para mostrar el menú superior.

5. Botones de ROJO / VERDE / AZUL / AMARILLO

• Púlselo para activar las teclas de atajo en algunas funciones de BD-vídeo. Cuando se despliega la lista de archivos, presione para cambiar las páginas.

6. Botón (REVERSO)

• Durante la reproducción, púlselo para invertir rápido la reproducción.

7. Botón (REPRODUCIR)*

• Púlselo para iniciar o reanudar la reproducción.

8. Botón (SALTAR)

• Durante la reproducción, púlselo una vez para volver al comienzo del título, capítulo, pista o archivo actual.

• Durante la reproducción, pulse dos veces sobre la tecla para volver al título, capítulo, pista o archivo anterior.

• Durante la reproducción de archivos JPEG, púlselo para volver al archivo anterior.

9. Botón (DETENER)

• Púlselo para detener la reproducción.

10. Botones NUMÉRICOS

• Púlselos para seleccionar un capítulo durante la reproducción.

• Púlselos para introducir números en el campo de entrada.

11. Botón NET APP

• Púlselo para visualizar el menú de aplicación de la red.

12. Botón NETFLIX

• Pulse para abrir Netflix.

13. Botón (ABRIR/CERRAR)*

• Púlselo para cerrar o abrir la bandeja para discos.

14. Botón HOME

• Púlselo para mostrar el menú de inicio.

15. Botón POP MENU/MENU Blu-ray Disc™:

DVD: Púlselo para mostrar el menú del disco.

16. Botón OK

• Púlselo para confirmar o seleccionar elementos de menú.

17. Botón RETURN

• Púlselo para volver a la pantalla de funciones o menú

mostrado anteriormente.

18. Botón (ADELANTAR)

• Durante la reproducción, púlselo para avanzar rápido

la reproducción.

• Cuando la reproducción esté en pausa, púlselo para

avanzar lentamente la reproducción.

Púlselo para mostrar el menú emergente.

Continua en la página siguiente

19. Botón (SALTAR)

• Durante la reproducción, púlselo para saltar al siguiente capítulo, pista o archivo.

• Cuando la reproducción esté en modo de pausa, púlselo para avanzar la reproducción imagen a imagen.

20. Botón (PAUSAR)

• Púlselo para pausar la reproducción.

21. Botón VOL /

• Púlselo para ajustar el volumen.

22. Botón MUTE

• Púlselo para silenciar el volumen.

23. Botón SOURCE

• Púlselo para cambiar el modo de fuente activa; menú de inicio (Disco / dispositivo de memoria USB / Red), “Aux” o “Coaxial” .

24. Botón DISPLAY

• Púlselo para visualizar el menú desplegable en pantalla.

25. Botón VUDU

• Pulse para abrir VUDU.

D Nota

• El indicador ENCENDIDO en el panel frontal se atenúa y parpadea cuando se recibe la señal IR del control remoto.

• Use el control remoto suministrado. No se garantiza la operación de control remoto en cualquier otro control remoto, tal como un control remoto universal.

22.2. Encontrar el Canal de Video en su Televisor

Revise los siguientes pasos después de haber completado todas las conexiones a su TV.

1. Presione [(ENCENDIDO)] para Encender la unidad.

2. Encienda su televisor.

3. Busque el botón Source / Input / AUX / Video en el control remoto del televisor. El boton puede variar en funcion de la marca y el modelo del televisor. Una vez localizado el boton presione hasta ver “Espere un...” o el menu de Configuracion Inicial en la pantalla.

Please Wait...

Esta es la visualización correcta de la entrada de la fuente de video.

• Si la TV está conectada por medio de un cable HDMI, puede tomar algunos minutos para que aparezca la imagen de

abertura.

• Cuando pase cierto tiempo sin que haya conectado la unidad aparecera la solo pantalla de bienvenida la primera vez

que conecte la unidad.

ES - 71

22.3. Instalacion Inicial

Idioma

Por favor, siga las instrucciones que se exponen a continuacion para completar la configuracion inicial.

1. Utilice [] mientras se presenta la pantalla de bienvenida para seleccionar “Next” y pulse luego [OK].

2. Aparece la pantalla de configuracion del idioma. Utilice [] para seleccionar su idioma y pulse luego [OK].

Por favor, seleccione su idioma para el menú en pantalla.

English

Español

Français

Retorno

3. Aparece la pantalla de “Modo de Inicio Rápido”. Utilice [] para seleccionar el modo deseado y pulse luego [

4. Aparece la pantalla de “Comprueba automaticamente si hay un software mas reciente”. Utilice [] para

seleccionar el modo deseado y pulse luego [

5. Aparece la pantalla de configuracion de la red. Utilice [] para seleccionar el modo deseado y pulse luego [OK].

• Si selecciona “Por cable” vea informaciones mas detalladas en el punto “Wired Connection” de la página 44.

• Si selecciona “Inalambrico” vea informaciones mas detalladas en el punto “Wireless Connection” de la página 46.

 Cómo restablecer el Idioma OSD

Puede restablecer el idioma OSD si seleccionó el ajuste de idioma equivocado.

1. Presione [HOME] para desplegar el Menú de Inicio.

2. Utilice [] para seleccionar “ ”, despés presione [OK].

• Esta partida es “Settings” (inglés) / “Configuaraciones” (español) / “Paramètres” (francés).

• A partir de aquí, por favor seleccione una de las siguientes partidas que puede encontrar en la pantalla:

3. Utilice [] para seleccionar “Playback” (inglés) / “Reproducción” (español) / “Lecture” (francés), y después presione [OK].

4. Utilice [] para seleccionar “Language” (inglés) / “Idioma” (español) / “Langue” (francés), y después presione [OK].

5. Utilice [] para seleccionar el idioma que desee, después presione [OK].

6. Si las partidas de ajuste se despliegan en el idioma que seleccionó, presione [HOME] para salir.

ES - 72

LIMITED WARRANTY

FUNAI CORP. will repair this product, free of charge in the USA in the event of defect in materials or workmanship as follows:

DURATION: PARTS: FUNAI CORP. will provide parts to replace defective parts without charge for one (1) year from the

date of original retail purchase. Certain parts are excluded from this warranty.

LABOR: FUNAI CORP. will provide the labor without charge for a period of ninety (90) days from the date of

original retail purchase.

Note: Any product sold and identified as refurbished or renewed carries a ninety (90) days labor

and parts limited warranty.

LIMITS AND EXCLUSIONS:

THIS WARRANTY IS EXTENDED ONLY TO THE ORIGINAL RETAIL PURCHASER. A PURCHASE RECEIPT OR OTHER PROOF OF ORIGINAL RETAIL PURCHASE WILL BE REQUIRED TOGETHER WITH THE PRODUCT TO OBTAIN SERVICE UNDER THIS WARRANTY. This warranty shall not be extended to any other person or transferee. This warranty is void and of no effect if any serial numbers on the product are altered, replaced, defaced, missing or if service was attempted by an unauthorized service center. This limited warranty does not apply to any product not purchased and used in the United States. This warranty only covers failures due to defects in material or workmanship which occur during normal use. It does not cover damage which occurs in shipment, or failures which are caused by repairs, alterations or products not supplied by FUNAI CORP., or damage, which results from accident, misuse, abuse, mishandling, misapplication, alteration, faulty installation, improper maintenance, commercial use such as hotel, rental or office use of this product, or damage which results from fire, flood, lightning or other acts of God. THIS WARRANTY DOES NOT COVER PACKING MATERIALS, ANY ACCESSORIES (EXCEPT REMOTE CONTROL), ANY COSMETIC PARTS, COMPLETE ASSEMBLY PARTS, DEMO OR FLOOR MODELS. FUNAI CORP. AND ITS REPRESENTATIVES OR AGENTS SHALL IN NO EVENT BE LIABLE FOR ANY GENERAL, INDIRECT OR CONSEQUENTIAL DAMAGES ARISING OUT OF OR OCCASIONED BY THE USE OF OR THE INABILITY TO USE THIS PRODUCT. THIS WARRANTY IS MADE IN LIEU OF ALL OTHER WARRANTIES, EXPRESS OR IMPLIED, AND OF ALL OTHER LIABILITIES ON THE PART OF FUNAI, ALL OTHER WARRANTIES INCLUDING THE WARRANTY OF MERCHANTABILITY AND FITNESS FOR A PARTICULAR PURPOSE, ARE HEREBY DISCLAIMED BY FUNAI AND ITS REPRESENTATIVES IN THE UNITED STATES. ALL WARRANTY INSPECTIONS AND REPAIRS MUST BE PERFORMED BY AN AUTHORIZED SERVICE CENTER. THIS WARRANTY IS ONLY VALID WHEN THE UNIT IS CARRIED-IN TO AN AUTHORIZED SERVICE CENTER.

THE PRODUCT MUST BE ACCOMPANIED BY A COPY OF THE ORIGINAL RETAIL PURCHASE RECEIPT.

IF NO PROOF OF PURCHASE IS ATTACHED, THE WARRANTY WILL NOT BE HONORED AND REPAIR COSTS WILL BE CHARGED.

IMPORTANT:

THIS LIMITED WARRANTY GIVES YOU SPECIFIC LEGAL RIGHTS. YOU MAY HAVE OTHER RIGHTS THAT VARY FROM STATE TO STATE. IF, AT ANY TIME DURING THE WARRANTY PERIOD, YOU ARE UNABLE TO OBTAIN SATISFACTION WITH THE REPAIR OF THIS PRODUCT, PLEASE CONTACT FUNAI CORP.

ATTENTION:

FUNAI CORP. RESERVES THE RIGHT TO MODIFY ANY DESIGN OF THIS PRODUCT WITHOUT PRIOR NOTICE.

WARRANTY STATEMENT REGARDING NON AUTHORIZED REPAIRS:

To obtain warranty service, you must take the product, or deliver the product freight prepaid, in either its original packaging or packaging affording an equal degree of protection, to any AUTHORIZED SERVICE CENTER. FUNAI CORP. will not reimburse you for any service done by unauthorized service providers without prior written approval.

To locate your nearest AUTHORIZED SERVICE CENTER or for general service inquiries, please contact us at:

FUNAI SERVICE CORPORATION

Tel: 1-800-605-8610

www.magnavox.com/support

2200 Spiegel Drive, Groveport, OH 43125

★★★★★

EDC11UD

Magnavox MRD733B Owner Manual

Specifications and Main Features

Frequently Asked Questions

User Manual

1. INTRODUCTION

1.1. Safety Instructions

1.2. Supplied Accessories

2. FEATURES

2.1. Features

2.2. Product Info

2.3. Symbols Used in this Owner’s Manual

3. FUNCTIONAL OVERVIEW

3.1. Front Panel

3.2. Rear Panel

3.3. Remote Control

3.4. Guide to On-Screen Display

4. CONNECTIONS

4.1. Placing the Speakers

4.2. Connection to a TV

4.3. Connecting Speakers and Subwoofer

4.4. Connecting Audio from Cable Box / Recorder / Game Console or TV

4.5. HDMI Audio Output

4.6. Connection to the Network

5. BEFORE YOU START

5.1. Finding a Viewing Video Source Input on Your TV

5.2. Initial Setup

6. INFORMATION ON PLAYBACK

6.1. Information on Playback

6.2. Guide to File List

6.3. How to Insert a Disc

7. BASIC PLAYBACK

7.1. Playing Back a Disc

7.2. Playing Back Contents from a USB Memory Stick

7.3. Playing Back Video / Music / Photo from DLNA Certified Home Media Servers

7.4. Using the Title / Disc / Pop Menu

8. SPECIAL PLAYBACK

8.1. Fast Forward / Fast Reverse

8.2. Slow Forward Playback

8.3. Step by Step Playback

8.4. Repeat Playback

8.5. Slide Show

8.6. PiP (BONUSVIEW™) Setting

8.7. Enjoying BD-Live™ Discs Using Internet

8.8. Title / Chapter Search

8.9. Track / File Search

8.10. Time Search

8.11. Switching Subtitles

8.12. Switching Audio Soundtrack

8.13. Switching Camera Angles

8.14. Black Level

8.15. Noise Reduction

8.16. CLEAR+

9. NETWORK FEATURES

9.1. Before Using Network Features

9.2. Information on Network Services

10. PANDORA® OPERATION

10.1. Activating Pandora

10.2. Adding Pandora User Accounts

10.3. Creating a New Pandora Station

10.4. Guide to the Player Screen

11. LIST OF SETTINGS

12. SETUPS

12.1. Network Connection

12.2. fun-Link (HDMI CEC)

12.3. Audio Input Mapping

12.4. HDMI Video Resolution

12.5. Parental

12.6. Software Update

12.7. Restore Default Settings

13. SOUND SETTINGS

13.1. Volume Control

13.2. Selecting Surround Mode

13.3. Selecting Sound Effect Mode

13.4. Audio Sync

13.5. Speaker Setup

14. OTHER SETTINGS

14.1. Switching Active Source Mode

14.2. Sleep Timer

15. TROUBLESHOOTING

16. LANGUAGE CODE LIST
