Magnavox MRD130 User Manual

Download

User Manual

SMART. VERY SMART.

MRD130

DVD VIDEO HOME THEATER SYSTEM

Thank you for choosing

Magnavox.

Need help fast?

Read your Quick Use Guide and/or Owner's Manual first for quick tips

that make using your Magnavox product

more enjoyable.

If you have read your instructions

and still need assistance,

you may access our online help at

www.magnavox.com

or call

1-800-705-2000

while with your product.

Magnavox vous remercie de

votre confiance.

Besoin d'une aide

rapide?

Les Guide d'utilisation rapide et Manuel de l'utilisateur regorgent d'astuces destinées à

simplifier l'utilisation de votre produit Magnavox.

Toutefois, si vous ne parvenez pas à résoudre

votre probléme, vous pouvez accéder à

notre aide en ligne à l'adresse

www.magnavox.com

ou formez le

1-800-661-6162 (Francophone)

1-800-705-2000 (English speaking)

Veillez à avoir votre produit à

portée de main.

Gracias por escoger

Magnavox

Necesita ayuda

inmediata?

Lea primero la GuÌa de uso rápido o el

Manual del usuario, en donde encontrar·

consejos que le ayudarán a disfrutar

plenamente de su producto Magnavox.

Si después de leerlo aún necesita ayuda,

consulte nuestro servicio de

asistencia en lÌnea en

www.magnavox.com

o llame al teléfono

1-800-705-2000

y tenga a mano el producto.

Return your Product Registration Card today

to get the very most from your purchase.

Registering your model with MAGNAVOX makes you eligible for all of the valuable benefits listed below, so don't miss out. Complete and return your Product Registration Card at once to ensure:

*Proof of Purchase

Returning the enclosed card guarantees that your date of purchase will be on file, so no additional paperwork will be required from you to obtain warranty service.

*Product Safety Notification

By registering your product, you'll receive notification directly from the manufacturer in the rare case of a product recall or safety defect.

Congratulations on your purchase, and welcome to the “family!”

Dear MAGNAVOX product owner:

Thank you for your confidence in MAGNAVOX. You’ve selected one of the best-built, best-backed products available today.We’ll do everything in our power to keep you happy with your purchase for many years to come.

As a member of the MAGNAVOX “family,” you’re entitled to protection by one of the most comprehensive warranties and outstanding service networks in the industry.What’s more, your purchase guarantees you’ll receive all the information and special offers for which you qualify, plus easy access to accessories from our convenient home shopping network.

Most importantly, you can count on our uncompromising commitment to your total satisfaction.

All of this is our way of saying welcome - and thanks for investing in a MAGNAVOX product.

P.S. To get the most from your MAGNAVOX purchase, be sure to complete and return your Product Registration Card at once.

*Additional Benefits of Product Ownership

Registering your product guarantees that you'll receive all of the privileges to which you're entitled, including special money-saving offers.

Know these

safety symbols

This “bolt of lightning” indicates uninsulated material within your

unit may cause an electrical shock. For the safety of everyone in your household, please do not remove product covering.

The “exclamation point” calls attention to features for which

you should read the enclosed literature closely to prevent operating and maintenance problems.

WARNING:To reduce the risk of fire or electric shock, this apparatus should not be exposed to rain or moisture, and objects filled with liquids, such as vases, should not be placed on this apparatus.

CAUTION: To prevent electric shock, match wide blade of plug to wide slot, fully insert.

ATTENTION: Pour éviter les choc électriques, introduire la lame la plus large de la fiche dans la borne correspondante de la prise et pousser jusqu’au fond.

For Customer Use

Enter below the Serial No. which is located on the rear of the cabinet. Retain this information for future reference.

Model No. ____________________ Serial No. ____________________

Visit our World Wide Web Site at http://www.magnavox.com

IMPORTANT SAFETY INSTRUCTIONS

Read these instructions.

Keep these instructions.

Heed all warnings.

Follow all instructions.

Do not use this apparatus near water.

Clean only with dry cloth.

Do not block any ventilation openings. Install in accordance with the manufacturer´s instructions.

Do not install near any heat sources

such as radiators, heat registers, stoves, or other apparatus (including ampliﬁers) that

produce heat.

Do not defeat the safety purpose of the

polarized or grounding-type plug. A polarized plug has two blades with one wider than the other.A grounding type plug has two blades and a third grounding prong. The wide blade or the third prong are provided for your safety. If the provided plug does not ﬁt into your outlet, consult an electrician for replacement of the obsolete outlet.

10.

Protect the power cord from being

walked on or pinched, particularly at plugs, convenience receptacles, and the point where they exit from the apparatus.

11.

Only use attachments/accessories

speciﬁed by the manufacturer.

AC Polarized

Plug

12 .

13 .

Unplug this apparatus during lightning

storms or when unused for long periods of time.

14 .

Refer all servicing to qualiﬁed service

personnel. Servicing is required when the apparatus has been damaged in any way, such as power-supply cord or plug is damaged, liquid has been spilled or objects have fallen into the apparatus, the apparatus has been exposed to rain or moisture, does not operate normally, or has been dropped.

15.

Battery usage

prevent battery leakage which may result in bodily injury, proper ty damage, or damage to the unit:

●

Install all batteries correctly, + and - as marked on the unit.

●

Do not mix batteries (old and new or carbon and alkaline, etc.).

●

Remove batteries when the unit is not used for a long time.

16.

Apparatus shall not be exposed to

dripping or splashing.

17.

Do not place any sources of danger

on the apparatus (e.g. liquid filled

objects, lighted candles).

Use only with the cart, stand, tripod, bracket, or table speciﬁed by the manufacturer or sold with the apparatus.When a cart is used, use caution when moving the cart/apparatus combination to avoid injury from tip-over.

CAUTION

– To

18.

This product may contain lead and mercury. Disposal of these materials may be regulated due to environmental considerations.

For disposal or recycling information, please contact your local authorities or the Electronic Industries Alliance : www.eiae.org.

EL 6475-E005: 04/01

E L

Canada

English:

This digital apparatus does not exceed the Class B limits for radio noise emissions from digital apparatus as set out in the Radio Interference Regulations of the Canadian Department of Communications.

Français:

Cet appareil numérique n'emet pas de bruits radioélectriques dépassant les limites applicables aux appareils numériques de Class B prescrites dans le Règlement sur le Brouillage Radioélectrique édicté par le Ministère des Communications du Canada.

CAUTION

Use of controls or adjustments or performance of procedures other than herein may result in hazardous radiation exposure or other unsafe operation.

ATTENTION

L'utilisation des commandes ou réglages ou le non-respect des procédures ciincluses peuvent se traduire par une exposition dangereuse à l'irradiation.

ATENCIÓN

El uso de mando o ajustes o la ejecucción de métodos que no sean los aquí descritos puede ocasionar peligro de exposición a radiación.

This warning label is located on the rearside

and inside this laser product.

INVISIBLE

CAUTION

LASER RADIATION

WHEN OPEN. DO NOT STARE INTO BEAM.

INVISIBLE LASER RADIATION WHEN OPEN.

DANGER

AVOID DIRECT EXPOSURE TO BEAM.

AVATTAESSA JA SUOJALUKITUS OHITETTAESSA OL

VARO !

ALTTIINANAKYMATTOMAALLE LASERSATEILYLLE. A KATSO SATEESEEN.

OSYNLIG LASERSTRÅLNING NÄR DENNA DEL ÄR ÖPPNA

VARNING!

OCH SPARREN AR URKOPPLAD.BETRAKTA EJ STRÅLEN.

DANGER - Invisible laser radiation when ope

AVOID DIRECT EXPOSURE TO BEAM.

‘CONSUMERS SHOULD NOTE THAT NOT ALL HIGH DEFINITION TELEVISION SETS ARE FULLY COMPATIBLE WITH THIS PRODUCT AND MAY CAUSE ARTIFACTS TO BE DISPLAYED IN THE PICTURE. IN CASE OF 525 OR 625 PROGRESSIVE SCAN PICTURE PROBLEMS, IT IS RECOMMENDED THAT THE USER SWITCH THE CONNECTION TO THE ‘STANDARD DEFINITION’ OUTPUT. IF THERE ARE QUESTIONS REGARDING OUR TV SET COMPATIBILITY WITH THIS MODEL 525p AND 625p DVD PLAYER, PLEASE CONTACT OUR CUSTOMER SERVICE CENTER.’

Class II equipment symbol

This symbol indicates that the unit has

a double insulation system

IMPORTANT NOTE

Due to the numerous versions of new CD-Audio copy protection or enhanced CD-Audio protection recently available on certain discs, Philips is unable to guarantee that this DVD system is fully compatible with such new discs. Should you have difficulty playing such CDAudio discs, kindly refer them to your CD-Audio disc retailer.

This system complies with the FCC rules, Part 15 and with 21 CFR 1040.10. Operation is subject to the following two conditions:

– This device may not cause harmful interference, and – This device must accept any interference received, including interference that may cause undesired operation.

Index

English ----------------------------------------- 8

Français-------------------------------------- 41

Español -------------------------------------- 77

English

Français

Español

8239 300 30551

This product incorporates copyright protection technology that is protected by method claims of certain U.S. patents and other intellectual property rights owned by Macrovision Corporation and other rights owners. Use of this copyright protection technology must be authorized by Macrovision Corporation, and is intended for home and other limited viewing uses only unless otherwise authorized by Macrovision Corporation. Reverse engineering or disassembly is prohibited.

Manufactured under license from Dolby Laboratories. “Dolby”, “Pro Logic” and the double-D symbol are trademarks of Dolby Laboratories.

“DTS” and “DTS Digital Surround” are registered trademarks of Digital Theater Systems, Inc.

Environmental information

All unnecessary packaging has been omitted. We have tried to make the packaging easy to separate into three materials: cardboard (box), polystyrene foam (buffer) and polyethylene (bags, protective foam sheet).

Your system consists of materials which can be recycled and reused if disassembled by a specialized company. Please observe the local regulations regarding the disposal of packaging materials, exhausted batteries and old equipment.

Contents

General Information

Supplied accessories ............................................ 8

Care and safety information .............................. 8

Connections

Step 1: Placing the speakers and subwoofer .. 9

Step 2: Connecting TV ....................................... 10

Using Composite Video jack ...................... 10

Using Component Video jack (Y Pb Pr) .. 10

Using S-Video jack ........................................ 11

Using an accessory RF modulator ............ 11

Step 3: Connecting speakers and subwoofer 12

Step 4: Connecting FM/AM antennas ............. 13

Step 5: Connecting the power cord............... 13

Connections (optional)

Connecting a VCR or Cable/Satellite Box .... 14

Viewing and listening to the playback ...... 14

Using the VCR for recording DVD

playback........................................................... 14

Connecting digital audio equipment .............. 14

Digital Recording .......................................... 14

Functional Overview

Main unit and remote control ......................... 15

Control buttons available on the

remote only ................................................... 16

Getting Started

Step 1: Inserting batteries into the

remote control ................................................... 17

Using the remote control to operate

the system ...................................................... 17

Step 2: Setting the TV ........................................ 17

Selecting the color system that

corresponds to your TV .............................. 18

Setting the TV shape .................................... 18

Step 3: Setting the speakers ............................. 19

Test Tone - turning on/off ........................... 19

Adjusting the delay time.............................. 19

Adjusting the speaker output levels ......... 19

Step 4: Setting language preferences .............. 20

On-screen display (OSD) language........... 20

Audio, Subtitle and Disc Menu language .. 20

Progressive Scan ................................................. 21

Activate Progressive Scan manually .......... 21

Deactivate Progressive Scan manually ..... 21

Disc Operations

Playable discs ....................................................... 22

Playing discs ......................................................... 22

Using the Disc Menu ......................................... 23

Basic playback controls ..................................... 23

Resuming playback from the last

stopped point (DVD/VCD/CD) ................ 23

Display function ............................................ 24

Selecting a subtitle language ....................... 24

Selecting an audio language ........................ 24

Selecting various repeat functions .................. 24

Repeat play mode ......................................... 24

Repeating a section within a

title/track ........................................................ 24

Program favorite tracks

(audio CDs and VCDs) ..................................... 25

Clearing the program .................................. 25

Using the menu bar to program ..................... 25

Playing MP3/Picture disc (Kodak, JPEG) ........ 26

MP3/JPEG picture disc ................................. 26

Kodak picture CD ........................................ 26

JPEG and MP3 simultaneously playback... 26

DVD Setup Menu Options

Using the menu bar ........................................... 27

Using the Setup Menu ....................................... 28

Setting the video output ............................. 28

Screen saver - turning on/off...................... 29

Smart Power - turning on/off..................... 29

Night mode - turning on/off ....................... 30

Restoring the original settings ................... 30

Restricting playback by parental control . 31

Changing the password ............................... 32

Tuner Operations

Tuning to radio stations .................................... 33

Presetting radio stations ................................... 33

Automatic presetting ................................... 33

Manual presetting ......................................... 33

Selecting a preset radio station ....................... 33

Deleting a preset radio station .................. 33

Other Functions

Sound Control .................................................... 34

Selecting surround sound ........................... 34

Selecting digital sound effects .................... 34

Volume Control .................................................. 34

Dimming system’s display screen .................... 34

Using the remote to operate ‘Philips’

television ............................................................... 35

Setting the Sleep timer ..................................... 35

Troubleshooting ........................................... 36–37

Specifications .......................................................... 38

Glossary ......................................................................... 39

English

Limited Warranty.............................................. 40

General Information

10 cm

(4 inches)

10 cm

(4 inches)

10 cm

(4 inches)

DVD Home Cinema System

PHILIPS

English

Supplied accessories Care and safety information

Avoid high temperatures, moisture,

Composite video cable (yellow)

Audio cable (white, red)

FM wire antenna

AM loop antenna

Remote Control and two AA batteries

water and dust

– Do not expose the system, batteries or discs to humidity, rain, sand or excessive heat (caused by heating equipment or direct sunlight.) Always keep the disc tray closed to avoid getting dust on the lens.

Avoid condensation problem

– The lens may cloud over when the player is suddenly moved from cold to warm surroundings, making it impossible to play a disc. Leave the player in the warm environment until the moisture evaporates.

Do not block the vents

– Do not operate the DVD system in an enclosed cabinet and allow about 10 cm (4 inches) of free space all around the player for adequate ventilation.

Care of disc

– To clean a CD, wipe it in a straight line from the center toward the edge using a soft, lint-free cloth. Do not use cleaning agents, as they may damage the disc. – Write only on the printed side of a CD-R/CD-RW and only with a soft felttipped pen. – Handle the disc by its edge, do not touch the surface.

Care of the cabinet

– Use a soft cloth slightly moistened with a mild detergent solution. Do not use a solution containing alcohol, spirits, ammonia or abrasives.

Finding a suitable location

– Place the player on a flat, hard, stable surface.

Step 1: Placing the speakers

and subwoofer

Center speaker

Front Speaker

(Left)

Connections

English

Front Speaker

(Right)

Rear Speaker

(Left)

Subwoofer

For best possible surround sound, all the speakers (except subwoofer) should be placed at the same distance from the listening position.

1 Place the front left and right speakers at

equal distances from the TV and at an angle of approximately 45 degrees from the listening position.

2 Place the center speaker above the TV or

the DVD system so that the center channel’s sound is localized.

3 Place the rear speakers at normal

listening ear level facing each other or hang on the wall.

4 Place the subwoofer on the floor near

the TV.

Rear Speaker

(Right)

Helpful Hints: – To avoid magnetic interference, do not position the front speakers too close to your TV. – Allow adequate ventilation around the DVD system.

Connections

English

Step 2: Connecting TV

Option 1

IMPORTANT! – You only need to make connection from the following options, depending on the capabilities of your TV. – Connect the DVD system directly to the TV.

Using Composite Video jack

1 Use the supplied composite video cable

(yellow) to connect the DVD system’s VIDEO OUT jack to the video input jack (or labeled as A / V In, CVBS, Composite or Baseband) on the TV.

2 To hear the TV channels through this

DVD system, use the supplied audio cables (white/red) to connect AUDIO IN-TV jacks to the corresponding AUDIO OUT jacks on the TV.

one video

Option 2

IMPORTANT! The progressive scan video quality is only possible when using Y Pb Pr, and a progressive scan TV is required.

Using Component Video jacks (Y Pb Pr)

1 Use a component video cables (red/blue/

green - not supplied) to connect the DVD system’s Y Pb Pr jacks to the corresponding Component video input jacks (or labeled as Y Pb/Cb Pr/Cr or YUV) on the TV.

2 To hear the TV channels through this

DVD system, use the supplied audio cables (white/red) to connect AUDIO IN-TV jacks to the corresponding AUDIO OUT jacks on the TV.

3 If you are using a Progressive Scan TV

(TV must indicate Progressive Scan or ProScan capability), to activate TV Progressive Scan, please refer to your TV user manual. For DVD system Progressive Scan function, see page 21.

Helpful Hint: – If your TV does not support Progressive Scan, you will not be ab le to view the picture. Press and hold OPEN/CLOSE button and press ‘1’ to deactivate progressive scan.

Option 3 Option 4

ANT IN

Connections

English

RF coaxial cable to TV

IMPORTANT! If S-Video is used for DVD playback connection, the system’s VIDEO OUT setting will need to be changed accordingly.

Using S-Video jack

1 Use an S-video cable (not supplied) to

connect the DVD system’s S-VIDEO OUT jack to the S-Video input jack

(or labeled as Y / C or S-VHS) on the TV.

2 To hear the TV channels through this

DVD system, use the supplied audio cables (white/red) to connect AUDIO IN-TV) jacks to the corresponding AUDIO OUT jacks on the TV.

TO TVINT IN

VIDEO

Back of RF Modulator

(example only)

AUDIO IN R L

CH3 CH4

Antenna or

Cable TV signal

IMPORTANT! If your TV only has a single Antenna In jack (labeled as 75 ohm or RF In), you will need an RF modulator in order to view DVD playback on the TV. See your electronics retailer or contact Philips for details on RF modulator availability and operations.

Using an accessory RF modulator

1 Use the supplied composite video cable

(yellow) to connect the DVD system’s VIDEO OUT jack to the video input jack on the RF modulator.

2 Use an RF coaxial cable (not supplied) to

connect ANTENNA OUT or TO TV jack on the RF modulator to the ANTENNA IN jack on the TV.

3 Connect the Antenna or Cable TV

service signal to the ANTENNA IN or RF IN jack on the RF modulator. (It may have been connected to your TV previously. Disconnect it from the TV.)

Connections

English

Step 3: Connecting speakers

and subwoofer

Front Speaker

(Right)

FRONT R

REAR R

Rear Speaker

(Right)

Connect the supplied speaker systems using the fixed speaker cables by matching the colors of the jacks and speaker cables.

Front Speaker

(Left)

FRONT L

REAR L

Rear Speaker

(Left)

Center

Speaker

CENTER

SUBWOOFER

Passive

Subwoofer

Helpful Hint: – Ensure that the speaker cables are correctly connected. Improper connections may damage the system due to short-circuit.

Connections

Step 4: Connecting FM/AM

antennas

fix the claw into

the slot

➠

antenna

1 Connect the supplied AM loop antenna

to the AM jack. Place the AM loop antenna on a shelf or attach it to a stand or wall.

2 Connect the supplied FM antenna to the

FM (75Ω) jack. Extend the FM antenna and fix its ends to the wall.

For better FM stereo reception, connect an external FM antenna (not supplied.)

Step 5: Connecting the

power cord

English

~ AC MAINS

Power Outlet

After everything is connected properly,

1 Plug the AC power cord into the power

outlet.

2 Never make or change any connections

with the power switched on.

Helpful Hint: – Refer to the type plate on the rear or bottom of the system for identification and supply ratings.

Helpful Hints: – Adjust the position of the antennas for optimal reception. – Position the antennas as far as possible from your TV, VCR or other radiation source to prevent unwanted interference.

Connections (optional)

FRONT RIGHT

FRONT

LEFT

REAR

RIGHT

REAR LEFT

SUBWOOFER

FRONT CENTER

DIGITAL IN

English

Connecting a VCR or Cable/Satellite Box

VCR or Cable/ Satellite Box

214

Viewing and listening to the playback

~ AC MAINS

1 Connect the VCR or Cable/Satellite Box

to the TV as shown.

2 Connect the DVD system’s AUDIO IN-

AUX jacks to the AUDIO OUT jacks on

the VCR or cable/satellite box.

Before starting operation, press AUX on the remote to select “AUX” in order to activate the input source.

Using the VCR for recording DVD playback

3 Connect the DVD system’s VIDEO OUT

jack to the VIDEO IN jack on the VCR.

4 Connect the DVD system’s LINE OUT

jacks to the AUDIO IN jacks on the VCR. This will allow you to make analog stereo (two channel, right and left) recordings.

To view DVD playback while recording, you must connect the DVD

system to your TV using S-VIDEO (as shown above) or Component (Y Pb Pr) connection.

Connecting digital audio equipment

(for example) CD Recorder

Digital Recording

● Connect the DVD system’s DIGITAL

OUT-COAXIAL jack to the DIGITAL

COAXIAL IN jack on a digital recording device (such as Dolby Digital decoder, CD recorder.)

Helpful Hints: – Some DVDs are copy-protected. You cannot record the disc through a VCR or digital recording device. – Always refer to the owner’s manual of the other equipment for complete connection and usage details.

Functional Overview

Main unit and remote control

1 2 3 4 5 6 7 9 10 118

English

1 STANDBY ON

– Switches to standby mode or turns on

the system.

2 Disc tray

3 OPEN /CLOSE 0 (DISC mode only)

– Opens / Closes the disc tray.

4 System display panel

5 ÉÅ PLAY/PAUSE

– DISC: starts/pauses playback.

6 S PREV / T NEXT

– DISC: *searches backward/forward or

selects a track.

– TUNER: tunes the radio frequency

up/down.

– TV: selects previous/next channel on

Philips TV (on remote only.)

7 Ç STOP

– Exits an operation. – DISC: stops playback or clears a program. – TUNER: *erases a preset radio station.

8 SOURCE

– Selects the relevant active mode : TV,

DISC, TUNER (FM/AM) or AUX.

9 PROG

– DISC: starts programming. – TUNER: starts manual preset programming.

0 VOLUME (VOL +-)

– Adjusts the volume level.

! PHONES

– For plugging in the headphones jack.

The speakers output will be cancelled.

* = Press and hold the button for more than two seconds.

Functional Overview

English

Control buttons available on the remote only

@ Numeric Keypad (0-9)

– Enters a track/title number of the disc. – Enters a number of a preset radio station.

# SOUND

– Selects a sound effect.

$ SURROUND

– Selects multichannel surround (Dolby

Digital, Dolby Pro Logic or Dolby Pro Logic II) or stereo mode.

% AUDIO

– Selects an audio language.

^ DISPLAY

– Displays the current status or disc

information on TV screen during playback.

& RESUME

– Continues disc playback after an interruption.

* 1 2 3 4

– Selects movement direction in the menu.

– Use 1 2 to select a preset radio station.

( DISC MENU

– Enters disc contents menu.

) SUBW +-

– Adjusts subwoofer’s sound level.

REAR +-

– Adjusts rear speakers’ sound level.

CENTER +-

– Adjusts center speaker’s sound level.

TV VOL +-

– Adjusts TV volume (Philips TV only.)

¡ SLEEP

– Sets the sleep timer function.

™ NIGHT (DVD mode only)

– Toggles between night mode on and off.

Selects night mode on to level out the volume output.

£ SYSTEM MENU (DISC mode only) – Enters or exits system setup menu.

≤ OK

– Confirms a selection.

∞ REPEAT

– Selects various repeat modes.

§ REPEAT A-B

– Repeats a specific section on a disc.

≥ SUBTITLE

– Selects a subtitle language.

• DIM

– Selects different levels of brightness for

display panel.

ª MUTE

– Mutes or restores the volume.

º B

– Switches to standby mode. – In TV mode, switches Philips TV on/off.

* = Press and hold the button for more than two seconds.

Getting Started

Step 1: Inserting batteries

into the remote control

1 Open the battery compartment. 2 Insert two batteries type R06 or AA,

following the indications (+-) inside the compartment.

3 Close the cover.

Using the remote control to operate the system

1 Aim the remote control

directly at the remote sensor (iR) on the front panel.

2 Select the source you

wish to control by pressing one of the source select buttons on the remote control (for example TV, TUNER.)

3 Then select the desired

function (for example

ÉÅ,

S, T .)

Step 2: Setting the TV

IMPORTANT! Make sure you have completed all the necessary connections. (See pages

10–11 “Connecting TV”.)

1 Press SOURCE control until “DISC”

appears on the display panel (or press DISC on the remote.)

2 Turn on the TV and set to the correct

video-in channel. You should see the blue DVD background screen on the TV.

➜ Usually this channel is between the

lowest and highest channels and may be called FRONT, A/V IN, or VIDEO. See your TV manual for more details.

➜ Or, you may go to channel 1 on your

TV, then press the Channel down button repeatedly until you see the Video In channel.

➜ Or, the TV remote control may have a

button or switch that chooses different video modes.

➜ Or, set the TV to channel 3 or 4 if you

are using an RF modulator.

English

CAUTION! – Remove batteries if they are exhausted or if the remote is not to be used for a long time. – Do not use old and new or different types of batteries in combination. – Batteries contain chemical substances, so they should be disposed of properly.

Getting Started

English

Selecting the color system that corresponds to your TV

In order for a DVD to play on this DVD system, the color system of the DVD, the TV and the DVD player should match. Before changing the TV system, ensure that your TV supports the selected color system.

1 In disc mode, press SYSTEM MENU.

➜ Use the 1 2 3 4 keys on the remote

to navigate in the menu.

2 Highlight icon and press 4.

Move to Move to {TV SYSTEM} and press 2.

AUTO – Select this if the connected TV is compatible with both NTSC and PAL (multi-system.) The output format will be in accordance with the video signal of the disc.

NTSC – Select this if the connected TV has the NTSC system. It will change the video signal of a PAL disc (VCD only) and output it to NTSC format.

PAL – Select this if the connected TV has the PAL system. It will change the video signal of an NTSC disc and output it to PAL format.

and press 2.

TV SHAPE

TV SYSTEM

VIDEO OUT

SCR SAVER

SMART POWER

SET TO NTSC

AUTO

NTSC

PAL

3 Press 34 to select a setting and press

OK to confirm.

➜ Follow the instructions shown on the

TV to confirm the selection (if any.)

➜ If a blank/distorted TV screen appears,

wait for 15 seconds for auto recovery.

Setting the TV shape

Set the aspect ratio of the DVD Player according to the TV you have connected. The format you select must be available on the disc. If it is not, the setting for TV display will not affect the picture during playback.

1 In disc mode, press SYSTEM MENU.

➜ Use the 1 2 3 4 keys on the remote

to navigate in the menu.

2 Highlight icon and press 4.

Move to Move to {TV SHAPE} and press 2.

4:3 PS (PanScan) –

Select this if you have a conventional TV and want both sides of the picture to be trimmed or formatted to fit your TV screen.

4:3 LB (letterbox) –

Select this if you have a conventional TV. In this case, a wide picture with black bands on the upper and lower portions of the TV screen will be displayed.

16:9 – Select this if you have a widescreen TV.

and press 2.

TV SHAPE

TV SYSTEM

VIDEO OUT

SCR SAVER

SMART POWER

SET TO LETTER BOX

4:3 PS

4:3 LB

16:9

3 Press 34 to select a setting and press

OK to confirm.

TIPS:

To return to the previous menu, press 1. To exit the menu, press SYSTEM MENU.

Getting Started

Step 3: Setting the speakers

You can adjust the delay time (center and rear speakers only) and volume level for individual speakers. These adjustments let you optimize the sound according to your surroundings and setup.

Test Tone - Turning on/off

If you have turned on the test tone, the test signal will be automatically generated to help you judge the sound level of each speaker.

1 In disc mode, press SYSTEM MENU.

➜ Use the 1 2 3 4 keys on the remote

to navigate in the menu.

2 Highlight icon and press 4.

Move to and press 2. Move to {TEST TONE} and press 2.

NIGHT MODE

CNTR DELAY

REAR DELAY

TEST TONE

OFF

{CNTR DELAY} – Select this to set the delay time in relation to the listening position/distance from the center speaker (5ms, 3ms, 2ms, 1ms or OFF.)

{REAR DELAY} – Select this to set the delay time in relation to the listening position/distance from the rear speakers (15ms, 12ms, 9ms, 6ms, 3ms or OFF.)

5 Press 1 2 to adjust the settings that

best suit your surround sound needs.

6 Press OK to confirm.

Helpful Hint: – Use longer delay time settings when the rear speakers are closer to the listener than the front speakers.

Adjusting the speaker output levels

You can adjust the rear speakers, center speaker and subwoofer output levels by comparing the sound from the front speakers.

English

3 Press 34 to select a setting.

Adjusting the delay time

4 Press 34 to highlight one of the options

below at a time, then press 2.

NIGHT MODE

CNTR DELAY

REAR DELAY

TEST TONE

CENTER DELAY SET TO 1 MS

TIPS:

To return to the previous menu, press 1. To exit the menu, press SYSTEM MENU.

● Press the respective buttons on the

remote (REAR +-, CENTER +- and SUBW +-) to adjust the output level between -15dB ~ +10dB.

Helpful Hint: – If you have selected Stereo mode, adjusting the center and rear speakers’ volume level will have no effect.

AUDIO

SUBTITLE

DISC MENU

ENGLISH

GOTO LANGUAGE SETUP PAGE

Getting Started

English

Step 4: Setting language

preferences

You can select your preferred language settings so that this DVD system will automatically switch to the language for you whenever you load a disc. If the language selected is not available on the disc, the disc’s default setting language will be used instead. The OSD (on-screen display) language for the system menu will remain as you set it, regardless of various disc languages.

On-screen display (OSD) language

1 In disc mode, press SYSTEM MENU.

➜ Use the 1 2 3 4 keys on the remote

to navigate in the menu.

2 Highlight icon and press 4.

Move to and press 2. Move to {MENU LANG} and press 2.

PARENTAL

PASSWORD

MENU LANG

DEFAULTS

ENGLISH

FRENCH SPANISH

Audio, Subtitle and Disc menu language

1 In disc stop mode, stop playback and

press SYSTEM MENU.

➜ Use the 1 2 3 4 keys on the remote

to navigate in the menu.

2 Highlight icon and press 4.

Move to Move to highlight one of the options below at a time, then press 2.

– {AUDIO} (disc’s soundtrack) – {SUBTITLE} (disc’s subtitles) – {DISC MENU} (disc’s menu)

and press 2.

3 Press 34 to select a language and press

OK to confirm.

4 Repeat steps 2~3 for other settings.

3 Press 34 to select a language and press

OK to confirm.

TIPS:

OSD LANGUAGE SET TO ENGLISH

To return to the previous menu, press 1. To exit the menu, press SYSTEM MENU.

Getting Started

Progressive Scan

The progressive scan produces 60 complete frames per second, rather than 30 frames per second of interlaced scanning (normal TV system). With nearly double the number of lines, progressive scan offers higher picture resolution, eliminates bothersome motion artifacts and jaggier edges on moving objects.

To enjoy the quality offered by progressive scan, a progressive scan TV is required.

Activate Progressive Scan manually

You can activate Progressive Scan as below.

1 Press STANDBY ON on the front

panel to switch on the DVD system.

2 Press and hold OPEN/CLOSE 0 on the

front panel, while pressing down the OPEN /CLOSE 0 , press the numerical keypad “2” on the remote control.

● To activate the Progressive Scan, you

must set the “Video Output” to Y PR PB (see page 28.)

Deactivate Progressive Scan manually

When the progressive scan function is activated, the TV screen may be blank because of the following reasons:

1) Your TV supports progressive scan, but

it is not activated. To activate it, please refer to your TV user manual.

2) The cables are not connected

accordingly. Refer to page 10 for proper connections.

3) Your TV does not support progressive

scan function. In that case, you can deactivate progressive scan as below.

1 Press STANDBY ON on the front

panel to switch on the DVD system.

2 Press and hold OPEN/CLOSE 0 on the

front panel, while pressing down the OPEN /CLOSE 0 press the numerical keypad “1” on the remote control.

➜ The blue DVD background appears on

the TV.

English

TIPS:

To return to the previous menu, press 1. To eixt the menu, press SYSTEM MENU.

Disc Operations

English

IMPORTANT!

– If the inhibit icon (or X)

appears on the TV screen

when a button is pressed, it means the function is not available on the current disc or at the current time. – DVD discs and players are designed with regional restrictions. Before playing a disc, make sure the disc is for the same zone as your player. – Do not push on the disc tray or put any objects other than discs on the disc tray. Doing so may cause the disc player to malfunction.

Playable discs

Your DVD home cinema system will play:

– Digital Versatile Discs (DVDs) – Video CDs (VCDs) – Super Video CDs (SVCDs) – Audio Compact Discs (CDs) – MP3 discs, picture (Kodak, JPEG) files

on CD-R(W)

– JPEG/ISO 9660 format – Maximum 12 characters display – Supported sampling frequencies :

32 kHz, 44.1 kHz, 48 kHz

– Supported Bit-rates : 32~256 (kbps),

variable bit rates

Region Codes

DVDs must be labeled for ALL regions or for Region 1 in order to play on this DVD system. You cannot play discs that are labeled for other regions.

Helpful Hints: – It may not be possible to play CD-R/RW in all cases due to the type of disc or condition of the recording. – If you are having trouble playing a certain disc, remove the disc and try a different one. Improperly formatted discs will not play on this DVD system.

ALL

Playing discs

Press SOURCE control until “DISC” appears on the display panel (or press DISC on the remote.)

2 Turn on the TV power and set to the

correct Video In channel. (See page 17 “Setting the TV”.)

➜ You should see the blue DVD

background screen on the TV.

3 Press the OPEN/CLOSE 0 to open the

disc tray and load a disc, then press the button again to close the disc tray.

➜ Make sure the disc label is facing up.

For double-sided discs, load the side you want to play face up.

4 Press ÉÅ to start playback.

➜ If a disc menu shows on the TV, see

next page on “Using the Disc Menu.”

➜ If the disc is locked by parental control,

you must enter your four-digit password (see page 31.)

The operating features described here might not be possible for certain discs. Always refer

TIPS:

to the instructions supplied with the discs.

Disc Operations

Using the Disc Menu

Depending on the disc, a menu may appear on the TV screen once you load in the disc.

To select a playback feature or item

● Use the 1 2 3 4 keys or numeric

keypad (0-9) on the remote, then press OK to start playback.

To access the menu

● Press DISC MENU on the remote.

For VCDs with Playback Control (PBC) feature (version 2.0 only)

● During playback, pressing DISC MENU

will return to the menu screen (if PBC is on.)

➜ Use S / T to select a play

option and press OK to confirm or use the numeric keypad (0-9).

Basic playback controls

Pausing playback

● Press ÉÅ.

➜ To resume normal playback, press

ÉÅ again.

Selecting another track/chapter

● Press S / T or use the numeric

keypad (0-9) to key in a track/chapter

number.

➜ If repeat mode is active, pressing

S / T will replay the same track/ chapter.

Searching backward/forward

● Press and hold S / T, then press

ÉÅ to resume normal playback.

➜ While searching, pressing and holding

S / T again will increase the search speed.

Stopping playback

● Press Ç.

Resuming playback from the last stopped point (DVD/VCD/CD)

● When play is stopped and the disc has

not been ejected, press RESUME.

English

To cancel the resume mode

● When play is stopped, press Ç again.

Helpful Hint: – Opening the disc tray or disconnecting the DVD system from the power supply will cancel the resume option.

The operating features described here might not be possible for certain discs. Always refer

TIPS:

to the instructions supplied with the discs.

Disc Operations

English

Display function

● While playing a disc, press DISPLAY to

view the information of the playing disc.

DVD

TITLE ELAPSED ™ TITLE REMAIN ™ CHAPTER ELAPSED ™ TOTAL REMAIN ™ OFF

VCD (PBC off)/SVCD/CD

SINGLE ELAPSED ™ SINGLE REMAIN ™ TOTAL ELAPSED ™ OFF

MP3

CHAPTER ELAPSED ™ CHAPTER REMAIN ™ OFF

Selecting a subtitle language

● While playing a DVD disc with multi

subtitle languages, press SUBTITLE to select different subtitle language.

Helpful Hints: – This function is not available if the disc is not recorded with multi subtitle languages. – The maximum number of subtitle languages stipulated by the manufacturers is 32/32.

Selecting an audio language

● While playing a DVD disc with different

channels recorded, press AUDIO to select an audio language.

● While playing a SVCD, VCD or CD disc

with different channels recorded, press AUDIO to select the available audio channels:

LEFT VOCAL ™ RIGHT VOCAL

™ MONO LEFT ™ MONO RIGHT ™ STEREO

Selecting various repeat functions

Repeat play mode

● While playing a disc, press REPEAT to

select various repeat mode.

➜ "REPEAT” icon will appear on the

display, except REPEAT OFF mode.

DVD

REPEAT CHAPTER ™ REPEAT TITLE ™ REPEAT OFF

VCD/SVCD/CD

REPEAT ONE (repeat the current track) ™ REPEAT DISC ™ REPEAT OFF

MP3

REPEAT ONE ™ REPEAT ALBUM ™ REPEAT DISC ™ REPEAT OFF

Helpful Hint: – For VCD, repeat playback is not possible if the PBC mode is switched on.

Repeating a section within a title/ track

1 While playing a disc, press REPEAT A-B

at the starting point.

2 Press REPEAT A-B again to end the

section.

➜ The section A and B can be set only

within the same title/track.

➜ The section will now repeat

continuously.

3 Press REPEAT A-B again to resume

normal playback.

Disc Operations

Program favorite tracks (audio CDs and VCDs)

You can play the contents of the disc in the order you want by programming the order of the tracks to be played. Up to tracks can be stored.

1 Stop playback, then press PROG on the

front panel to enter program mode.

2 Use the numeric keypad (0-9) to enter

a valid track number.

➜ "FULL" will appear if you have

programmed 99 tracks.

3 Press OK to store the track. 4 Repeat steps 2~3 to select other

tracks.

5 Press ÉÅ to start program playback.

Clearing the program

● Stop playback, then press the Ç again.

➜ "PROG CLR" appears.

Helpful Hints: – If the DVD system is discoonected from the power supply, it will erase the program. – For VCD, the program option is only possible if the PBC mode is turned off.

Using the menu bar to program

IMPORTANT! You have to turn on your TV and set to the correct Video In channel. (See

page 17 “Setting the TV”.)

1 Stop playback, then press SYSTEM

MENU.

➜ The menu bar will appear across the

top of the TV screen.

2 Press 1 2 to select and press 4 to

enter the program menu.

PROGRAM P 00 : 00

3 Use the numeric keypad (0-9) to enter

the track number to be programmed.

➜ "FULL" will appear if you have

programmed 99 tracks.

4 Press ÉÅ to start program playback.

To clear the program

● Stop playback, then press Çagain.

English

The operating features described here might not be possible for certain discs. Always refer

TIPS:

to the instructions supplied with the discs.

Disc Operations

English

Playing MP3/Picture disc (Kodak, JPEG)

IMPORTANT! You have to turn on your TV and set to the correct Video In channel. (See

page 17 “Setting the TV”.)

MP3/ JPEG picture disc

1 Load an MP3/JPEG picture disc.

➜ The disc reading time may exceed

30 seconds due to the complexity of the directory/file configuration.

2 Playback will start automatically.

➜ The album/picture menu appears on

the TV screen. If not, press DISC MENU on the remote.

3 Use 1 2 3 4 keys to select a desired

album, then press OK to open the folder (for MP3 disc only.)

➜ The title menu appears on the TV

screen.

4 Use 1 2 3 4 keys to select a desired

title, then press OK to start playback.

● You can also use the numeric keypad

(0-9) to enter your choice.

5 To stop playback, press Ç.

Kodak picture CD

1 Load a Kodak picture disc.

➜ The disc reading time may exceed

30 seconds due to the complexity of the directory/file configuration.

2 Playback will start automatically. 3 To stop playback, press Ç.

➜ 9 thumbnail pictures will appear on the

TV.

➜ Use S / T keys to view the

previous/next page (if available.)

4 Use 1 2 3 4 keys to navigate within the

menu and press OK to start playback.

During playback, you can;

● Press S / T to select another title/

picture in the current folder.

● Use 1 2 3 4 keys to rotate/ flip the

picture files.

● Select “ZOOM ON”, then press and hold

the S / T (or select Q R on the system menu, then press S / T ) to zoom the picture in or out.

● Press ÉÅ to pause/resume playback.

5 To stop playback, press Ç.

Helpful Hints: – Due to the recording nature of Digital Audio MP3 (DAM), only digital audio music will play.

– It is normal to experience an occasional “skip” while listening to your MP3 discs. – It may not be possible to play certain MP3

or JPEG disc due to the configuration and characteristics of the disc or condition of the recording. – For multi-session discs with different formats, only the first session will be available.

JPEG and MP3 simultaneously playback

1 Select a MP3 track and press NIGHT.

➜ ‘MP3 is selected’ appears on the TV.

2 Press 3 4 to select a picture file, then

press OK.

3 To quit simultaneous playback, pressÇ.

➜ The picture and MP3 music playback

will stop.

Helpful Hint: – If the disc menu doesn’t appear on the TV screen, press DISC MENU to turn on the disc menu.

The operating features described here might not be possible for certain discs. Always refer

TIPS:

to the instructions supplied with the discs.

Using the menu bar

SUBTITLE

Select a subtitle language that is available on the DVD.

LANGUAGE

DVD : Select an audio soundtrack language that is available on the DVD. VCD : Select audio channels : LEFT VOCAL, RIGHT VOCAL, MONO LEFT, MONO RIGHT or STEREO.

SLOW MOTION

Select a slow playback speed. The volume will be muted. To resume normal playback, press ÉÅ. DVD : SF x1/2, SF x1/4, SF x1/8. SR x1/2, SR x1/4, SR x1/8, PLAY. VCD : SF x1/1, SF x1/2, SF x1/3, PLAY.

(SF - Slow Forward, SR- Slow Rerverse)

FAST REVERSE (FR)

DVD / MP3 : FR x2, FR x4, FR x6, FR x8, PLAY. VCD / CD : FR x1, FR x2, FR x3, FR x4, PLAY.

FAST FORWARD (FF)

DVD / MP3 : FF x2, FF x4, FF x6, FF x8, PLAY. VCD / CD : FF x1, FF x2, FF x3, FF x4, PLAY.

Select a search speed (FR - backward, FF - forward). The volume will be muted. To resume normal playback, press ÉÅ.

STATUS

Allows viewing of the current status of the disc

The information will vary depending on the disc format.

Available on DVD only TITLE SEARCH (TITLE XX:YY") Select a Title for playback to begin.

CHAPTER SEARCH (CHAPTER XX:YY) Select a Chapter for playback to begin.

"XX" - current title/chapter number. "YY" - total number of title/chapter. Use the numeric keypad (0-9) to change the "XX" number, then press OK.

TIME SEARCH (TIME __:__:__) Use the numeric keypad (0-9) to enter the time (hours, minutes and seconds) at which you want playback to begin (for DVD and VCD with PBC-OFF only)

ZOOM

Select an enlarge picture ratio : x1.5, x2 or x4. You can use 1 2 3 4 keys to move within the enlarged picture on the TV. To resume normal playback, select 'ZOOM OFF' from the menu.

ANGLE (for DVD only) Select to view the same scene from different angles if the DVD is recorded with multiple angles.

STEP FORWARD

Select to advance the still picture one frame forward. To resume normal playback, press ÉÅ.

PBC ON/OFF (for VCD 2.0 with PBC feature) Select between PBC On and Off. 'PBC OFF' - the playback will start automatically.

PROGRAM

Stop playback, then select this to enter the program menu (see page 25 "Using the menu bar to program".)

'PBC ON' - the disc menu (if available) will appear on the TV. Use the numeric keypad (0-9) to enter your choice.

You can continue a number of operations directly via the multiple menu bars on the TV screen without interrupting the disc playback. The exception is when you enter

(SETUP MENU), after which the

playback will pause.

1 In disc mode, press SYSTEM MENU.

➜ The menu bar will appear across the

top of the TV screen.

2 Use 1 2 3 4 keys on the remote to

navigate in the menu.

➜ Press 1 2 to move through the menu bar. ➜ Press 4 to enter the selection. If there

are multiple choices available, press 4 repeatedly to select.

3 Press SYSTEM MENU again to exit the

menu.

IMPORTANT! – Some operations may be different or restricted, depending on the disc format. Refer to the jacket or case of the disc you are playing. – Changing the Subtitle Language and Audio Language from the menu bar will only apply to the current disc, it will not change the default preset.

DVD Setup Menu Options

English

DVD Setup Menu Options

S-VIDEO

YPRPB

S-VIDEO

TV SHAPE

TV SYSTEM

VIDEO OUT

SCR SAVER

SMART POWER

English

Using the Setup Menu

This DVD setup is carried out via the TV, enabling you to customize the DVD system to suit your particular requirements.

1 In disc mode, press SYSTEM MENU.

➜ Playback will pause.

2 Highlight icon and press 4 to enter

the setup menu. Then press 3 4 to select one of the setup menu options and press 2 to enter the menu.

SETUP MENU

Picture Setup

Sound Setup

Language Setup

Feature Setup

3 Use 1 2 3 4 keys on the remote to

navigate in the menu.

4 Press OK to confirm your selection.

Setting the video output

Choose the type of video output that matches the video connection between the DVD system and your TV.

Stop playback, then follow the steps of “Using the Setup Menu” and select :

> VIDEO OUT

S-VIDEO

Select this if you have connected the DVD system to your TV using the S-Video jack.

Y PR PB

Select this if you have connected the DVD system to your TV using component video jacks.

Helpful Hints: – You do not need to adjust the video output setting if you are using CVBS jack (yellow) to connect the DVD system to your TV. – If the Progressive Scan is set to ON, this item will not be available.

NOTE: Some of the features in the Setup Menu are described in “Getting Started.”

TIPS:

To return to the previous menu, press 1. To exit the menu, press SYSTEM MENU.

OFF

TV SHAPE

TV SYSTEM

VIDEO OUT

SCR SAVER

SMART POWER

DVD Setup Menu Options

Screen Saver - turning on/off

The screen saver will help to prevent your TV display device from getting damaged.

Follow the steps of “Using the Setup Menu” and select :

> SCR SAVER

TV SHAPE

TV SYSTEM

VIDEO OUT

SCR SAVER

SMART POWER

SCREEN SAVER NOW OFF

OFF

Select this to disable the screen saver function.

Select this if you wish to turn off the TV screen when play is stopped or paused for more than five (5) minutes.

Smart power – turning on/off

When in “Stop” or “No Disc” mode, the DVD system will switch to standby mode, after 15 minutes of inactivity for energy saving.

Follow the steps of “Using the Setup Menu” and select :

> SMART POWER

OFF

Smart Power is disabled.

In STOP or NO DISC mode, if no actions are performed for 15 minutes, the smart power will be activated.

English

TIPS:

To return to the previous menu, press 1. To exit the menu, press SYSTEM MENU.

DVD Setup Menu Options

RESET

LOAD FACTORY SETTINGS

PARENTAL

PASSWORD

MENU LANG

DEFAULTS

English

Night mode – turning on/off

When the night mode is activated, the high volume outputs will be softened and low volume outputs will be brought upward to an audible level. It is useful for watching your favorite action movie without disturbing others at night. This function can also be accessed via the NIGHT button on the remote.

Follow the steps of “Using the Setup Menu” and select :

> NIGHT MODE

NIGHT MODE

CNTR DELAY

REAR DELAY

TEST TONE

NIGHT MODE SET TO OFF

OFF

Select this when you want to enjoy the full dynamic of surround sound.

Select this to level out the volume. This feature is only available for movies with Dolby Digital mode.

Restoring the original settings

Setting the DEFAULT function will reset all options and your personal settings to the factory defaults, except your password for Parental Control and Video Output.

Follow the steps of “Using the Setup Menu” and select :

> DEFAULTS

RESET

Pressing 2 to select {RESET}, all settings will now reset to factory defaults.

TIPS:

To return to the previous menu, press 1. To exit the menu, press SYSTEM MENU.

DVD Setup Menu Options

Restricting playback by Parental Control

Some DVDs may have a parental level assigned to the complete disc or to certain scenes on the disc. This feature lets you set a playback limitation level. The rating levels are from 1 to 8 and are country dependent. You can prohibit the playback of certain discs that are not suitable for your children or have certain discs played with alternative scenes.

1 In disc mode, press SYSTEM MENU.

➜ Use the 1 2 3 4 keys on the remote

to navigate in the menu.

2 Select icon and press 4.

Move to and press 2. Move to {PARENTAL} and press 2.

PARENTAL

PASSWORD

MENU LANG

DEFAULTS

PLEASE ENTER PASSWORD

__ __ __ __

Enter code

3 Use the numeric keypad (0-9) to enter

‘1234’ (default password) when you are asked to enter the four-digit password. You will have to enter the same code, exactly, twice.

➜ To change the password, see page 32

“Changing the password.”

4 Select a rating level and press OK.

➜ DVDs that are rated above the level

you selected will not play unless you enter your four-digit password and choose a higher level rating. To disable Parental Controls and have all discs play, choose ‘NO PARENTAL.’

PARENTAL

PASSWORD

MENU LANG

DEFAULTS

KID SAFE

1 KID SAFE

2 G 3 PG 4 PG 13 5 PG-R 6 R 7 NC-17 8 ADULT

5 Press SYSTEM MENU again to exit the

menu.

Rating explanations

NO PARENTAL – It will play all discs.

8 ADULT – Mature material; should be viewed

7 NC-17 – No children under age 17; not

5-6 PG-R – Parental Guidance - Restricted;

4 PG13 – Material is unsuitable for children

3 PG – Parental Guidance suggested. 2 G – General Audience; recommended as

1 KID SAFE – Kids material; recommended

only by adults due to graphic sexual material, violence, or language.

recommended viewing for children under age 17.

recommended that parents restrict children under 17 from viewing or allow to view only when supervised by a parent or adult guardian.

under age 13.

acceptable for viewers of all ages.

especially for children and viewers of all ages.

English

TIPS:

Helpful Hints: – VCD, SVCD, CD have no level indication, so parental control has no effect on these type of discs. This also applies to most illegal DVDs. – Some DVDs are not encoded with a rating though the movie rating may be printed on the Disc cover. The rating level feature does not prohibit playback of such Discs.

To return to the previous menu, press 1. To exit the menu, press SYSTEM MENU.

DVD Setup Menu Options

__ __ __ __

Confirm code

Confirm :

PARENTAL

PASSWORD

MENU LANG

DEFAULTS

English

Changing the password

You can change the four-digit password used for Parental Control. Enter your four-digit password to play a prohibited disc or if prompted for a password. The default password is ‘1234.’

1 In disc mode, press SYSTEM MENU.

➜ Use the 1 2 3 4 keys on the remote

to navigate in the menu.

2 Select icon and press 4.

Move to and press 2. Move to {PASSWORD} and press 2.

PARENTAL

PASSWORD

MENU LANG

DEFAULTS

PLEASE ENTER OLD PASSWORD

__ __ __ __

Enter old code

3 Use the numeric keypad (0-9) to enter

your original four-digit password at “Enter old code.”

➜ If you are asked to enter the code for

the first time, key in ‘1234.’

➜ If you forget your password, press Ç

four times to restore to the default password (1234.)

4 Enter your new four-digit password.

5 Enter the same new four-digit password

again.

6 Press SYSTEM MENU again to remove

the menu.

TIPS:

PARENTAL

PASSWORD

MENU LANG

DEFAULTS

PLEASE ENTER NEW PASSWORD

__ __ __ __ Enter new code

To return to the previous menu, press 1. To exit the menu, press SYSTEM MENU.

Tuner Operations

IMPORTANT! Make sure the FM and AM antennas are connected.

Tuning to radio stations

Press TUNER on the remote (or press SOURCE control on front panel) to

select “FM” or “AM.”

2 Press and hold S / T on the

remote until the frequency indication starts to change, then release.

➜ The next radio station will tune

automatically.

3 To tune a weak station, press S / T

briefly and repeatedly until an optimal reception is found.

Presetting radio stations

You can store up to 40 preset radio stations in the memory, starting from FM and followed by AM bands.

Automatic presetting

You can store all available radio stations automatically.

● In tuner mode, press and hold PROG

until "AUTO PROG" appears.

Manual presetting

You can choose to store only your favourite radio stations.

1 Tune to your desired radio station (see

“Tuning to a radio station”.)

2 Press PROG.

➜ “

PROGRAM” icon appears.

3 Use the numeric keypad (0-9) to

select a preset number.

➜ If “

PROGRAM” icon goes off before you

select the desired preset number, press PROG again.

4 Press PROG again to store. 5 Repeat steps 1~4 to store other radio

stations.

Helpful Hints: – If you attempt to program more than 40 preset radio stations, “PROG FULL” appears. – The system will exit presetting mode if no button is pressed within five seconds.

Selecting a preset radio station

English

AUTO PROG

➜ All the available radio stations with

strong transmission signal will be stored.

➜ Automatic preset will begin from

preset (1) and all your former presets will be overridden.

➜ If it reaches 40 presets, “PROG FULL”

appears.

➜ Once complete, “PROG END” appears.

● Press 1 2 or use the numeric keypad

(0-9) to select a preset number.

➜ The preset number, radio frequency,

and waveband will appear.

Deleting a preset radio station

● Press and hold Ç until “PXX CLR”

appears.

➜ The current preset radio station will

be deleted.

Other Functions

English

Sound Control

IMPORTANT! For proper surround sound, make sure the speakers and subwoofer are connected (see page 12.)

Selecting surround sound

● Press SURROUND to select surround

or stereo mode.

➜ The availability of the various surround

sound modes depends on the number of speakers used and the sound available on the disc.

➜ The center and surround speakers

operate only in Multi-channel surround mode.

➜ The available output modes for multi-

channel include: Dolby Digital, Dolby Pro Logic or Dolby Pro Logic II surround sound.

➜ Stereo broadcasts or recordings will

produce some surround channel effects when played in a surround mode. However, monaural (single channel sound) sources will not produce any sound from the rear speakers.

Volume control

● Adjust VOLUME control (or press

VOL +/-on the remote) to increase

or decrease the volume level.

➜ "VOL XX" appears. “XX” denotes the

volume level.

To listen through the headphones

● Plug in the headphones plug to the

PHONES socket at the front of the DVD system.

➜ The speakers will be muted.

To turn off the volume temporarily

● Press MUTE. ➜ Playback will continue without sound

and "MUTE" appears.

➜ To restore the volume, press MUTE

again or increase the volume level.

Dimming system’s display screen

● In any active mode, press DIM to select

desired brightness : HIGH, MID or LOW.

Selecting digital sound effects

Select a preset digital sound effects that matches your disc’s content or that optimizes the sound of the musical style you are playing.

● Press SOUND to select the available

sound effect.

When playing movie discs, you can select: CONCERT, ACTION, DRAMA, or SCI-FI.

When playing music discs or while in TV, TUNER or AUX mode, you can select: DIGITAL, CLASSIC, ROCK, or JAZZ.

Helpful Hint: – For flat sound output, select CONCERT or CLASSIC.

Other Functions

Using the remote to operate ‘Philips’ television

Press TV.

2 Press S / T or use the numeric

keypad (0-9) to select the TV’s channel.

3 Press TV VOL +/- to adjust the TV’s

volume level.

4 Press B to turn off your TV.

Helpful Hint: – When listening to TV or AUX programs, press the respective TV or AUX button on the remote in order for the sound to be heard.

Setting the Sleep Timer

The sleep timer enables the system to switch to standby mode automatically at a preset time.

● Press SLEEP repeatedly until it reaches

the desired preset turn-off time.

➜ The selections are as follows (time in

minutes):

15 ™ 30 ™ 45 ™ 60 ™ 90 ™ 120 ™ OFF ™ 15 …

➜ “

SLEEP” icon will be shown on the

display, except if "OFF" is selected.

To check or change the setting

● Press SLEEP once to show the

remaining time before switching off. If you continue pressing the SLEEP button, the next Sleep Timer option will appear.

To cancel the sleep timer

● Press SLEEP repeatedly until "OFF"

appears or press the STANDBY ON button.

English

Troubleshooting

English

WARNING Under no circumstances should you try to repair the system yourself, as this will invalidate the warranty. Do not open the system as there is a risk of electric shock.

If a fault occurs, first check the points listed below before taking the system for repair. If you are unable to remedy a problem by following these hints, please consult your dealer for help.

Problem

No power.

No picture.

Completely distorted picture or black/ white picture.

The aspect ratio of the screen cannot be changed even though you have set the TV display.

No sound or distorted sound.

The DVD system does not work.

The disc tray cannot open and “TRAY LOCKED” is displayed.

The display panel is dark.

Low hum or buzz sound.

Cannot activate some features, such as Angles, Subtitles, or multi-language Audio.

– Check if the AC power cord is properly

connected.

– Press the STANDBY ON on the front of the

DVD system to turn on the power.

– Refer to your TV’s manual for correct Video In

channel selection. Change the TV channel until you see the DVD screen.

– Press DISC on the remote. – Refer to description “Progressive Scan” in next

page.

– If this happens when you changing the setting

of the ‘TV SYSTEM’, wait for 15 seconds for auto recovery.

– Check the video connection. – Sometimes a small amount of picture distortion

may appear. This is not a malfunction.

– Clean the disc.

– The aspect ratio is fixed on the DVD disc. – Depending on the TV, it may not be possible to

change the aspect ratio.

– Adjust the volume. – Check the speaker connections and settings. – Disconnect the headphones. – Press the correct source button on the

remote (TV or AUX, for example) to choose the equipment that you want to hear through the DVD system.

– Disconnect the power cord from the power

outlet for a few minutes. Reconnect the power cord and try to operate again as usual.

– Press and hold SOURCE button on the front

panel for more than two seconds, then press PLAY button.

– Press DIM again.

– Place the DVD system as far away as possible

from electrical devices that may be causing interference.

– The features may not be available on the DVD. – Changing the language for the sound or

subtitle is prohibited on the DVD.

Solution

Troubleshooting

Problem

The DVD player does not start playback.

There is no sound from the center and rear speakers.

Radio reception is poor.

The remote control does not function properly.

Progressive Scan.

Solution

– Insert a readable disc with the playback side

facing down. The DVD+R/CD-R must be finalized.

– Check the disc type, color system and region

code.

– Check for any scratches or smudges on the disc. – Press SYSTEM SETUP to turn off the setup

menu screen.

– You may need to enter the password in order

to change the parental control rating level or to unlock the disc for playback.

– Moisture has condensed inside the system.

Remove the disc and leave the system turned on for about an hour.

– Press CENTER +- or REAR +- to

adjust the volume level.

– Make sure the center and rear speakers are

connected correctly.

– Press SURROUND button to select a correct

surround sound setting.

– Make sure the source you are playing is

recorded or broadcast in surround sound (DPL II, Dolby Digital, etc.)

– If the signal is too weak, adjust the antenna or

connect an external antenna for better reception.

– Increase the distance between the system and

your TV or VCR.

– Tune in to the correct frequency. – Place the antenna farther away from any

equipment that may be causing the noise.

– Select the source (DISC or TUNER, for

example) before pressing the function button (ÉÅ , S, T.)

– Reduce the distance between the remote

control and the system.

– Replace the batteries with new ones. – Point the remote control directly toward the

IR sensor.

– Check that the batteries are loaded correctly.

– If the progressive function is activated but your

TV does not support progressive scan or the cables are not connected accordingly, the TV screen will be blank. You can deactivate progressive scan as below.

1) Press STANDBY ON on the front panel to switch on the DVD system.

2) Press OPEN/CLOSE 0 on the front panel, while pressing down OPEN/CLOSE 0, press numerical keypad “1” on the remote control. The blue DVD background appears on the TV screen.

English

Specifications

English

AMPLIFIER SECTION

Total output power

- Home Theater mode 200 W

- FTC 120 W Front 20 W FTC1 x 2 Rear 20 W FTC1 x 2 Center 20 W FTC Subwoofer 20 W FTC Frequency Response 180 Hz – 14 kHz / ±3 dB Signal-to-Noise Ratio > 60 dB (A-weighted) Input Sensitivity

- AUX In 450 mV

- TV In 450 mV

1 4ohm, 1 kHz, 1% THD

TUNER SECTION

Tuning Range FM 87.5 – 108 MHz

26 dB Quieting Sensitivity FM 22 dBf 26 dB Quieting Sensitivity AM 5000 µV/m IF Rejection Ratio FM 60 dB

Signal-to-Noise Ratio FM 50 dB

AM Suppression Ratio FM 30 dB Harmonic Distortion FM Mono 3%

Frequency Response FM 180 Hz – 10 kHz /

Stereo Separation FM 26 dB (1 kHz) Stereo Threshold FM 23.5 dB

AM 530 – 1710 kHz

AM 24 dB

AM 30 dB

FM Stereo 3% AM 5%

±6 dB

MAIN UNIT

Power Supply Rating 120 V / 60 Hz Power Consumption 110 W Dimensions (w x h x d) 435 x 53 x 359 (mm) Weight 5.58 kg

SPEAKERS

Front/Rear speakers System 1-way Impedance 4 Ω Speaker drivers 3” full range woofer Frequency response 160 Hz – 20 kHz Dimensions (w x h x d) 90 x 92 x 90 (mm) Weight 0.53 kg each

CENTER SPEAKER

System 1-way, magnetically

Impedance 4 Ω Speaker drivers 3” full range woofer Frequency response 160 Hz – 20 kHz Dimensions (w x h x d) 90 x 92 x 90 (mm) Weight 0.53 kg

shielded

PASSIVE SUBWOOFER

Impedance 4 Ω Speaker drivers 6.5” woofer Frequency response 45 Hz – 2 kHz Dimensions (w x h x d) 220 x 212 x 350 (mm) Weight 3.57 kg

DISC SECTION

Laser Type Semiconductor Disc Diameter 12cm / 8cm Video Decoding MPEG-2 / MPEG-1 Video DAC 10 Bits Signal System PAL / NTSC Video Format 4:3 / 16:9 Video S/N 56 dB (minimum) Composite Video Output 1.0 Vp-p, 75 Ω S-Video Output Y - 1.0 Vp-p, 75 Ω

C - 0.286 Vp-p, 75 Ω Audio DAC 24 Bits / 96 kHz Frequency Response 4 Hz – 20 kHz (44.1 kHz)

4 Hz – 22 kHz (48 kHz) Digital Output SPDIF (Sony Philips

digital interface) Coaxial

- Dolby Digital IEC 60958, IEC 61937

Specifications subject to change without prior notice

Glossary

Analog: Sound that has not been turned into

numbers. Analog sound varies, while digital sound has specific numerical values. These jacks send audio through two channels, the left and right. Aspect ratio: The ratio of vertical and horizontal sizes of a displayed image. The horizontal vs. vertical ratio of conventional TVs. is 4:3, and that of wide-screens is 16:9. AUDIO OUT Jacks: Jacks on the back of the DVD System that send audio to another system (TV, Stereo, etc.) Bit Rate: The amount of data used to hold a given length of music; measured in kilobits per second, or kbps. Or, the speed at which you record. Generally, the higher the bit rate, or the higher the recording speed, the better the sound quality. However, higher bit rates use more space on a Disc. Chapter: Sections of a picture or a music piece on a DVD that are smaller than titles. A title is composed of several chapters. Each chapter is assigned a chapter number enabling you to locate the chapter you want. Component Video Out Jacks: Jacks on the back of the DVD System that send high-quality video to a TV that has Component Video In jacks (R/G/B, Y/Pb/Pr, etc.) Disc menu: A screen display prepared for allowing selection of images, sounds, subtitles, multi-angles, etc recorded on a DVD. Digital: Sound that has been converted into numerical values. Digital sound is available when you use the DIGITAL AUDIO OUT COAXIAL or OPTICAL jacks. These jacks send audio through multiple channels, instead of just two channels as analog does.

Dolby Digital: A surround sound system

developed by Dolby Laboratories containing up to six channels of digital audio (front left and right, surround left and right, center and subwoofer.)

Dolby Pro Logic II: It creates five full-

bandwidth output channels from two-channel sources. Decode only systems that derive 5.1 channels instead of the conventional 4 channels of Dolby Pro Logic surround sound. JPEG: A very common digital still picture format. A still-picture data compression system proposed by the Joint Photographic Expert Group, which features small decrease in image quality in spite of its high compression ratio.

MP3: A file format with a sound data compression system. “MP3” is the abbreviation of Motion Picture Experts Group 1 (or MPEG-

1) Audio Layer 3. By using the MP3 format. One CD-R or CD-RW can contain about 10 times more data then a regular CD. Parental control: Limits Disc play according to the age of the users or the limitation level in each country. The limitation varies from disc to disc; when it is activated, playback will be prohibited if the software’s level is higher than the user-set level. Playback control (PBC): Refers to the signal recorded on video CDs or SVCDs for controlling playback. By using menu screens recorded on a Video CD or SVCD that supports PBC, you can enjoy interactive playback and searching. Progressive Scan: It displays all the horizontal lines of a picture at one time, as a single frame. This system can convert the interlaced video from DVD into progressive format when the DVD Player is connected to a Progressive Scan TV. It dramatically increases the vertical resolution and provides the best picture. Region code: A system allowing discs to be played only in the region designated. This unit will only play discs that have compatible region codes. You can find the region code of your unit by looking on the product label. Some discs are compatible with more than one region (or ALL regions.) S-Video: Produces a clear picture by sending separate signals for the luminance and the color. You can use S-Video only if your TV has an S-Video In jack. Sampling Frequency: Frequency of sampling data when analog data is converted to digital data Sampling frequency numerically represents how many time the original analog signal is sampled per second. Surround: A system for creating realistic three-dimensional sound fields full of realism by arranging multiple speakers around the listener. Title: The longest section of a movie or music feature on DVD. Each title is assigned a title number, enabling you to locate the title you want. VIDEO OUT jack: Yellow jack on the back of the DVD system that sends the DVD picture video to a TV.

English

MAGNAVOX LIMITED WARRANTY

One (1) Year Free Product Exchange

MAGNAVOX warrants this product against defect in material

or workmanship, subject to any conditions set forth as follows:

PROOF OF PURCHASE:

You must have proof of the date of purchase to exchange the product. A sales receipt or other document showing the product and the date that you purchased the product as well as the authorized retailer included, is considered such proof.

COVERAGE:

Warranty coverage begins the day you buy your product. For a period of one (1) year from the date of purchase, if the product is determined to be defective, Magnavox will exchange the defective product with a new or renewed product, at its option, at no charge. The replacement product is covered only for the warranty period of the original product. When the warranty on the original product expires, the warranty on all replaced products also expires. When it is necessary for you to ship the product to Magnavox for exchange, you will pay the shipping cost for shipment to Magnavox. Magnavox will pay the shipping costs when returning a product to you.

Note: The exchange model supplied will be the most comparable one in Magnavox current inventory. Shipping of your product to Magnavox implies intent to follow the specified requirements of the warranty and exchange program. Product received by Magnavox cannot be returned. Replacement product can only be sent if all warranty requirements are met. Failure to follow all requirements can result in delay of exchange process.

EXCLUDED FROM WARRANTY COVERAGE

Your warranty does not cover:

• Shipping charges to return defective product.

• Labor charges for installation or setup of the product, adjustment of customer controls on the product, and installation or repair of antenna systems outside of the product.

• Product repair and/or part replacement because of improper installation, connections to improper voltage supply, abuse, neglect, misuse, accident, unauthorized repair or other cause not within the control of Magnavox.

• A product that requires modification or adaptation to enable it to operate in any country other than the country for which it was designed, manufactured, approved and/or authorized, or repair of products damaged by these modifications.

• Damage occurring to product during shipping when improperly packaged or costs associated with packaging.

• Product lost in shipment and no signature verification receipt can be obtained.

• A product used for commercial or institutional purposes (including but not limited to rental purposes).

• Products sold AS IS or RENEWED.

WHERE WARRANTY EXCHANGE IS AVAILABLE:

Exchange is available in all countries where Magnavox officially distributes the product. In countries where Magnavox does not distribute the product, the local Magnavox organization will attempt to exchange the product, although there may be a delay if the appropriate product is not readily available or special customs processes are implied.

FOR EXCHANGE IN THE U.S.A., PUERTO RICO, OR U.S.VIRGIN ISLANDS…

Contact Magnavox Customer Care Center at:

1-800-705-2000

FOR EXCHANGE IN CANADA…

1-800-661-6162 (French Speaking) 1-800-705-2000 (English or Spanish Speaking)

REPLACEMENT AS PROVIDED UNDER THIS WARRANTY IS THE EXCLUSIVE REMEDY FOR THE CONSUMER. MAGNAVOX SHALL NOT BE LIABLE FOR ANY INCIDENTAL OR CONSEQUENTIAL DAMAGES FOR BREACH OF ANY EXPRESS OR IMPLIED WARRANTY ON THIS PRODUCT. EXCEPT TO THE EXTENT PROHIBITED BY APPLICABLE LAW, ANY IMPLIED WARRANTY OF MERCHANTABILITY OR FITNESS FOR A PARTICULAR PURPOSE ON THIS PRODUCT IS LIMITED IN DURATION TO THE DURATION OF THIS WARRANTY.

Some states do not allow the exclusions or limitation of incidental or consequential damages, or allow limitations on how long an implied warranty lasts, so the above limitations or exclusions may not apply to you. In addition, if you enter into a service contract agreement with the MAGNAVOX partnership within ninety (90) days of the date of sale, the limitation on how long an implied warranty lasts does not apply.

This warranty gives you specific legal rights. You may have other rights which vary from state/province to state/province.

Magnavox,P.O. Box 671539, Marietta, GA.30006-0026

(Warranty: 4835 710 27825)

Magnavox MRD130 User Manual

Specifications and Main Features

Frequently Asked Questions

User Manual
