Low Temperature
Cofired Ceramics Series
LTCC 低温共烧陶瓷
CUTTUNG-EDGE TECHNOLOGY OF RF SOLUTION
■ Feature 特点
Compact Size 体积小
Miniaturized SMD packaged in low profile and lightweight.
Low Loss
Low insertion loss, high attenuation.
High Soldering Heat Resistance 耐高温表面焊接
High quality termination allows both flow and re-flow soldering methods to be applied.
High Performance 特性优良
Eliminate noise over a wide frequency range. Idea for high frequency and space limited
designs.
Available in tape and reel packaging for automatic mounting 卷轴包装适用於
特点
特点特点
体积小
体积小体积小
低插
低插入入入入损耗
低插低插
损耗
损耗损耗
特性优良
特性优良特性优良
耐高温表面焊接
耐高温表面焊接耐高温表面焊接
卷轴包装适用於表面贴片技术
卷轴包装适用於卷轴包装适用於
■ Product Identification 产品型号
□ □ □
□ □ □ – □ □ □ □
□ □ □□ □ □
产品型号
产品型号产品型号
□ □ □ □ – □
□ □ □ □□ □ □ □
□ □ □ □ □
□□
□ □ □ □ – □ □
□ □ □ □□ □ □ □
□ □ - □ □
□ □□ □
□ □
□ □□ □
表面贴片技术
表面贴片技术表面贴片技术
Product Code
Dimension Code
Series Type (center frequency and material type)
Design Code
Pattern Code
1
MAG.LAYERS
Low Temperature
, GND
Cofired Ceramics Series
CUTTUNG-EDGE TECHNOLOGY OF RF SOLUTION
Balun 平衡-不平衡变压器
■ Application 用途
Cell Phone, PHS, WLAN, Bluetooth, Home RF, WiMAX, etc.
■ Dimensions 外观尺寸
Figure A
Figure B
W
Figure L W T a b c p/d
A 1.0±0.10
B 1.60±0.15
B 2.00±0.15
0.5±0.10 0.5±0.10 0.1±0.10 0.3±0.1 0.20±0.1 0.15±0.1
0.8±0.10 0.60±0.10 0.30±0.10 0.30±0.20 0.10±0.10 0.55±0.10
1.25±0.15 0.95±0.10
■ Termination Configuration 脚位图
L T
a p
0.30±0.20
b
c
Unit: mm
0.25±0.20 0.20±0.20 0.65±0.20
Unbalanced Port
Balanced Port
Balanced Port
GND
N. C. (Balance Port for 1608-2G4S1-A3/A4)
GND (N.C. for 1608-2G4S1-A3/A4)
Balanced Port
Balanced Port (GND for 1608-2G4S1-A3/A4)
GND or DC (N.C. for 1608-2G4S1-A3/A4
for 1608-2G4S1-B1/B2 and 16085G5S1-D1)
Unbalanced Port
2
MAG.LAYERS
Low Temperature
Cofired Ceramics Series
■ Electrical Specification 电气规格
Part No.
型号
Pass Band
带宽
(MHz)
Insertion
Loss
插入损耗
VSWR
电压
驻波比
CUTTUNG-EDGE TECHNOLOGY OF RF SOLUTION
Phase
Difference
相位差
Amplitude
Balance
振幅平衡
Unbalance/Balance
Impedance
非平衡/平衡阻抗
LTU-1608-0G8S1-A1 824~849 1.0dB max. 2.0 max.
LTU-1608-1G8S1-A1 1710~1910 1.0dB max. 2.0 max.
LTU-1608-1G9S1-A1 1920~1990 1.0dB max. 2.0 max.
LTU-2012-1G9S1-A1 1892~1920 1.2dB max. 2.0 max.
LTU-1005-2G4S1-A1 2400~2500 1.2dB max. 2.0 max.
LTU-1005-2G4S1-A2 2400~2500 1.2dB max. 2.0 max.
LTU-1608-2G4S1-A1 2400~2500 1.2dB max. 2.0 max.
LTU-1608-2G4S1-B1 2400~2500 1.2dB max. 2.0 max.
LTU-1608-2G4S1-A2 2400~2500 1.2dB max. 2.0 max.
180°±10°
180°±10°
180°±10°
180°±10°
180°±10°
180°±10°
180°±10°
180°±10°
180°±10°
2dB max. 50 / 100 ohm
2dB max. 50 / 100 ohm
2dB max. 50 / 100 ohm
2dB max. 50 / 100 ohm
2dB max. 50 / 100 ohm
2dB max. 50 / 50 ohm
2dB max. 50 / 100 ohm
2dB max. 50 / 100 ohm
2dB max. 50 / 50 ohm
LTU-1608-2G4S1-A3 2400~2500 1.2dB max. 2.0 max.
LTU-1608-2G4S1-A4 2400~2500 1.2dB max. 2.0 max.
LTU-2012-2G4S1-A1 2400~2500 1.0dB max. 2.0 max.
LTU-2012-2G4S1-A2 2400~2500 1.0dB max. 2.0 max.
LTU-2012-2G4S1-A5 2400~2500 1.0dB max. 2.0 max.
LTU-1005-2G5S1-A1 2300~2700 1.5dB max. 2.0 max.
LTU-1005-2G5S1-A2 2300~2700 1.5dB max. 2.0 max.
LTU-1608-2G5S1-A1 2300~2700 1.2dB max. 2.0 max.
LTU-1608-2G5S1-A2 2300~2700 1.2dB max. 2.0 max.
180°±10°
180°±10°
180°±10°
180°±10°
180°±10°
180°±15°
180°±15°
180°±10°
180°±10°
2dB max. 50 / 50 ohm
2dB max. 50 / 100 ohm
2dB max. 50 / 100 ohm
2dB max. 50 / 50 ohm
2dB max. 50 / 50 ohm
2dB max. 50 / 100 ohm
2dB max. 50 / 50 ohm
2dB max. 50 / 100 ohm
2dB max. 50 / 50 ohm
3
MAG.LAYERS
Low Temperature
Cofired Ceramics Series
Part No.
型号
Pass Band
带宽
(MHz)
Insertion
Loss
插入损耗
VSWR
电压
驻波比
Phase
Difference
相位差
CUTTUNG-EDGE TECHNOLOGY OF RF SOLUTION
Amplitude
Balance
振幅平衡
Unbalance/Balance
Impedance
非平衡/平衡阻抗
LTU-1608-3G5S1-A1 3300~3800 1.2dB max. 2.0 max.
LTU-1608-3G5S1-A2 3300~3800 1.2dB max. 2.0 max.
LTU-1005-5G5S1-A1 4900~5950 1.5dB max. 2.0 max.
LTU-1005-5G5S1-A2 4900~5950 1.5dB max. 2.0 max.
LTU-1608-5G5S1-A1 4900~5900 1.2dB max. 2.0 max.
LTU-1608-5G5S1-D1 4900~5900 1.2dB max. 2.0 max.
LTU-1608-5G5S1-A2 4900~5900 1.2dB max. 2.0 max.
LTU-1608-5G5S1-B2 4900~5900 1.2dB max. 2.0 max.
LTU-1608-5G5S1-A3 4900~5900 1.2dB max. 2.0 max.
180°±10°
180°±10°
180°±15°
180°±15°
180°±10°
180°±10°
180°±10°
180°±10°
180°±10°
2dB max. 50 / 100 ohm
2dB max. 50 / 50 ohm
2dB max. 50 / 100 ohm
2dB max. 50 / 50 ohm
2dB max. 50 / 100 ohm
2dB max. 50 / 100 ohm
2dB max. 50 / 50 ohm
2dB max. 50 / 50 ohm
2dB max. 50 / 200 ohm
LTU-2012-5G5S1-A1 4900~5900 1.0dB max. 2.0 max.
◎Please contact us for detail information.
180°±10°
2dB max. 50 / 100 ohm
