Magikitchn LPG, LPAGA Operation Manual

White and Red Label on Top of Fill Valve

"NOTICE - This is a new cylinder that should be purged by an authorized LP Gas Filler before it is filled
for the first time. The filler will remove this label after purging and filler. DO NOT OVERFILL !"

vvnlte ana tj:laCK LaDel on I op t(lm OT lanK

"WARNING - THIS CYLINDER IS EQUIPPED WITH AN OVERFILL PREVENTION DEVICE

- Only qualified persons are permitted to fill this cylinder.

- Read and understand the cylinder warning label before attempting to fill.

- This cylinder may only be filled in the VERTICAL POSITION.

- The Overfill Prevention Device (OPD) will only operate if the cylinder is overfilled (greater than 80%

level). Do not attempt to calibrate or tamper with the Overfill Protection Device (OPD).

- Before filling, inspect the cylinder in accordance with CGA C-6 or CGA c-6.3.

- This cylinder must be filled in accordance with U.S. DOT, NFPA-58. State and Local Regulations.

- Fill the cylinder through the fill valve only.

- Do not attempt to fill the cylinder through the service valve! The service valve contains a check valve

for vapor withdrawal only.

- Failure to properly fill the cylinder can result in injury or death.
DO NOT REMOVE, DEFACE OR OBLITERATE THIS LABEL.
Danger tag at OPD

DANGER - TOTAL WEIGHT OF TANK WHEN FILLED MUST NOT EXCEED 68 LBS.
OVERFILLING OF TANK WILL RESULT IN A FIRE HAZARD.

White Tag on Body of unit (1st from top - bottom)

HORIZONTAL CYLINDER - THIS SIDE MUST FACE UP

WARNING! DANGER! EXTREMELY FLAMMABLE GAS "FOR OUTDOOR USE ONLY"

DO NOT STORE OR USE THIS CYLINDER IN A BUILIDING, GARGAGE OR ENCLOSED AREA

1) EXTREMELY FLAMMABLE PRODUCT (LP GAS) UNDER PRESSURE is meant to be stored in the

cylinder. A SERIOUS FIRE OR EXPLOSION could result from misuse, leaks, mishandling, overfilling,

or tampering with valve or cylinder.

2) AVOID SERIOUS INJURY AND PROPERTY DAMAGE, IF YOU SEE, SMELL, OR HEAR THE HISS

OF ESCAPING GAS IMMEDIATELY GET AWAY FROM THIS CYLINDER! CALL YOUR FIRE

DEPT!

3) KEEP OUT OF REACH OF CHILDREN.

4) DO NOT expose to fire or heat above 120' F. (49'C). Doing so could cause the Pressure Relief Valve

to function, thus expelling a large volume of flammable gas.

5) DO NOT TAMPER with or attempt repairs on the valve or cylinder. Allow only QUALIFIED LP GAS

DEALERS to fill or repair.

6) ALWAYS transport and store this cylinder in an UPRIGHT position.

7) THIS CYLINDER MUST BE FILLED IN THE VERTICAL POSITION. horizontal filling may cause

overfill which may lead to dangerous or explosive conditions.

8)This cylinder must be installed to manufacturers specifications. INCORRECT INSTALLATION MAY

RESULT IN s:ERIOUS INJURY, PROPERTY DAMAGE OR OTHER DANGEROUS CONDITIONS.

9) All gas connections must be checked for leaks with a liquid soapy solution, once pressure is on the

system.

10) CLOSE cylinder valve when NOT IN USE.

11) When cylinder is stored, moved or transported by vehicle, install dust dap to protect valve from

foreign material. DO NOT USE P.O.L. PLUG. Installation of a P.O.L. plug could cause a flow of

flammable gas.

12) Do not use without reading the OWNER'S MANUAL and warning information for the specific

Appliance with which the cylinder will be used.

13) BE CERT AI N that this cylinder is purged of trapped air prior to first filling.

, THIS CYLINDER MUST BE PERIODICALLY REQUALIFEDBY. YOUR GAS SUPPLIER.
