1.0 cu.ft Microwave Oven
Convection
MCMY10SCC
Instruction Manual
and Cooking Guide
Before operating this oven, please read these instructions completely.
DEAN-MCMY10SCC-C-926T9A(영) 2005.7.5 5:22 PM 페이지2
1
TABLE OF CONTENTS
PRECAUTIONS TO AVOID POSSIBLE EXPOSURE TO EXCESSIVE MICROWAVE ENERGY.....1
IMPORTANT SAFETY INSTRUCTIONS............................................................................................2
FEDERAL COMMUNICATIONS COMMISSION
RADIO FREQUENCY INTERFERENCE STATEMENT.....................................................................3
GROUNDING INSTRUCTIONS .........................................................................................................3
INSTALLATION..................................................................................................................................4
SPECIFICATIONS..............................................................................................................................5
FEATURES DIAGRAM.......................................................................................................................6
FEATURES DIAGRAM (CONTINUED).............................................................................................7
ACCESSORIES..................................................................................................................................8
BEFORE OPERATION.......................................................................................................................9
OPERATION.....................................................................................................................................11
COOKING INSTRUCTIONS.............................................................................................................21
COOKING UTENSILS......................................................................................................................21
MICROWAVING PRINCIPLES.........................................................................................................22
HOW MICROWAVES COOK FOOD................................................................................................22
COOKING TECHNIQUES................................................................................................................23
DEFROSTING GUIDE......................................................................................................................24
DEFROSTING CHART.....................................................................................................................25
COOKING CHART ...........................................................................................................................26
REHEATING CHART .......................................................................................................................30
CARE OF YOUR MICROWAVE OVEN............................................................................................31
USE YOUR MICROWAVE OVEN SAFELY .....................................................................................32
BEFORE YOU CALL FOR SERVICE...............................................................................................33
QUESTIONS AND ANSWERS.........................................................................................................33
PRECAUTIONS TO AVOID POSSIBLE
EXPOSURE TO EXCESSIVE
MICROWAVE ENERGY
(a) Do not attempt to operate this oven with the door open since open-door operation can result
in harmful exposure to microwave energy. It is important not to defeat or tamper with the safety
interlocks.
(b) Do not place any object between the oven front face and the door or allow soil or cleaner
residue to accumulate on sealing surfaces.
(c) Do not operate the oven if it is damaged. It is particularly important that the oven door close
properly and that there is no damage to the: (1) door (bent), (2) hinges and latches (broken or
loosened), (3) door seals and sealing surfaces.
(d) The oven should not be adjusted or repaired by anyone except properly qualified service
personnel.
DEAN-MCMY10SCC-C-926T9A(영) 2005.7.5 5:22 PM 페이지1
2
IMPORTANT SAFETY INSTRUCTIONS
When using electrical appliances, basic safety precautions should be followed, including the following:
WARNING - To reduce the risk of burns, electric shock, fire, injury to persons or exposure to excessive
microwave energy:
SAVE THESE INSTRUCTIONS
11. Read all instructions before using the appliance.
12. Read and follow the specific “PRECAUTIONS TO
AVOID POSSIBLE EXPOSURE TO EXCESSIVE
MICROWAVE ENERGY” found on page 1.
13. This appliance must be grounded. Connect only to
properly grounded outlet.
See “GROUNDING INSTRUCTIONS” found on page 3.
14. Install or locate this appliance only in accordance with
the provided installation instructions.
15. Some products such as whole eggs and sealed
containers - for example, closed glass jars-are able to
explode and should not be heated in this oven.
16. Use this appliance only for its intended use as described
in this manual. Do not use corrosive chemicals or vapors
in this appliance. This type of oven is specifically
designed to heat, cook, or dry food. It is not designed for
industrial or laboratory use.
17. As with any appliance, close supervision is necessary
when used by children.
18. Do not operate this appliance if it has a damaged cord
or plug, if it is not working properly, or if it has been
damaged or dropped.
19. This appliance should be serviced only by qualified
service personnel.
Contact nearest authorized service facility for
examination, repair or adjustment.
10. Do not cover or block any openings on the appliance.
11. Do not store this appliance outdoors. Do not use this
product near water — for example, near a kitchen sink,
in a wet basement, or near a swimming pool, or similar
locations.
12. Do not immerse cord or plug in water.
13. Keep cord away from heated surfaces.
14. Do not let cord hang over edge of table or counter.
15. Either:
a) When cleaning surfaces of door and oven that
comes together on closing the door, use only mild,
non-abrasive soaps or detergents applied with a
sponge or soft cloth , or
b) When separate cleaning instructions are provided,
See door surface cleaning instructions on.
16. To reduce the risk of fire in the oven cavity:
a) Do not overcook food. Carefully attend appliance
when paper, plastic, or other com-bustible materials
are placed inside the oven to facilitate cooking.
b) Remove wire twist-ties from paper or plastic bags
before placing bag in oven.
c) If materials inside the oven ignite, keep oven door
closed, turn oven off, and disconnect the power cord,
or shut off power at the fuse or circuit breaker panel.
d) Do not use the cavity for storage purposes. Do not
leave paper products, cooking utensils, or food in the
cavity when not in use.
17. Do not use this microwave oven to heat corrosive
chemicals (for example, sulfides and chlorides). Vapours
from such corrosive chemicals may interact with the
contact and springs of the safety interlock switches
thereby rendering them inoperable.
18. Keep the waveguide cover clean at all times.
Wipe the oven interior with a soft damp cloth after each
use. If you leave grease or fat anywhere in the cavity it
may overheat, smoke or even catch fire when next using
the oven.
19. Never heat oil or fat for deep frying as you cannot
control the temperature and doing so may lead to
overheating and fire.
20. Liquids, such as water, coffee, or tea are able to be
overheated beyond the boiling point without appearing
to be boiling due to surface tension of the liquid. Visible
bubbling or boiling when the container is removed from
the microwave oven is not always present. THIS
COULD RESULT IN VERY HOT LIQUIDS SUDDENLY
BOILING OVER WHEN A SPOON OR OTHER
UTENSIL IS INSERTED INTO THE LIQUID. To reduce
the risk of injury to persons:
1 Do not overheat the liquid.
2 Stir the liquid both before and halfway through
heating it
3 Do not use straight-sided containers with narrow
necks.
4 After heating, allow the container to stand in the
microwave oven for a short time before removing the
container.
5 Use extreme care when inserting a spoon or other
utensil into the container.
Prior to use(If your oven has a grill element)
In order to protect your oven during transportation and storage, the grill element is covered with a
protective coating. To remove this coating the grill element must be heated for 5 minutes.
This procedure will produce some bad odors as the protective coating on the element disappears.
DEAN-MCMY10SCC-C-926T9A(영) 2005.7.5 5:22 PM 페이지2
3
FEDERAL COMMUNICATIONS COMMISSION
RADIO FREQUENCY INTERFERENCE
STATEMENT
GROUNDING INSTRUCTIONS
This appliance must be grounded. In the event of an electrical short circuit, the grounding plug reduces the risk
of electric shock by providing an escape wire for electric current. This appliance is equipped with a cord having
a grounding wire with a grounding plug. The plug must be plugged into an outlet that is properly installed and
grounded.
WARNING:
This equipment generates and uses ISM frequency energy and if not installed and used properly, that is in
strict accordance with the manufacturer's instructions, may cause interference to radio and television
reception.
It has been type-tested and found to comply with limits for an ISM Equipment pursuant to part 18 of FCC
Rules, which are designed to provide reasonable protection against such interference in a residential
installation.
However, there is no guarantee that interference will not occur in a particular installation.
If this equipment does cause interference to radio or television reception, which can be determined by
turning the equipment off and on, the user is encouraged to try to correct the interference by one or more
of the followings.
• Reorient the receiving antenna of radio or television.
• Relocate the Microwave oven with respect to the receiver.
• Move the microwave oven away from the receiver.
• Plug the microwave oven into a different outlet so that microwave oven and receiver are on
different branch circuits.
THE MANUFACTURER is not responsible for any radio or TV interference caused by
UNAUTHORIZED MODIFICATION to this microwave oven. It is the responsibility of
the user to correct such interference.
WARNING:
Improper use of the grounding can result in a risk of electric shock.
Consult a qualified electrician or serviceman if the grounding instructions are not completely understood,
or if doubt exists as to whether the appliance is properly grounded, and either :
(1) If it is necessary to use an extension cord, use only a 3-wire extension cord that has a 3-blade
grounding plug, and a 3-slot receptacle that will accept the plug on the appliance. The marked
rating of the extension cord shall be equal to or greater than the electrical rating of the appliance.
or
(2) Do not use an extension cord, if the power supply cord is too short, have a qualified electrician or
serviceman install an outlet near the appliance.
WARNING:
Do not cut or remove the third (ground) prong from the power cord under any circumstances.
DEAN-MCMY10SCC-C-926T9A(영) 2005.7.5 5:22 PM 페이지3
4
INSTALLATION
1
Examine the oven after unpacking.
Check for damage such as a misaligned door, broken door or dent in the cavity.
If any damage is visible, DO NOT INSTALL, and notify your dealer immediately.
2
Level, flat location.
Install the microwave oven on a level, flat surface and more than 3ft(916mm) above the floor.
3
Ventilation.
Do not block air vents. If they are blocked during operation, the oven may overheat and eventually cause a
failure. For proper ventilation, allow 4 inches of space between oven top, sides, rear and adjacent
surfaces.
4
Away from radio and TV sets.
Poor television reception and radio interference may result if the oven is located close to a TV, radio,
antenna, feeder, etc. Place the oven as far from them as possible.
5
Away from heating appliances and water taps.
Keep the oven away from heat, steam or splashing liquids. These things can adversely affect oven wiring
and contacts.
6
Power supply.
This microwave oven requires a power supply of approximately 13 Amperes, 120 Volts, 60Hz and a
grounded outlet. A short power cord is provided to reduce the risk of the user becoming entangled in or
tripping over a longer cord. Longer cord sets or extension cords are available and may be used if care is
exercised in their use.
If an extension cord is used, the marked electrical rating of the cord should be at least as great as the
electrical rating of the oven.
The extension cord must be a grounding-type 3-wire cord. The longer cord should be arranged so that it
will not drape over the table top or counter where it can be pulled on by children or tripped over
unintentionally.
7
The minimum height of free space necessary above the top surface of the oven is 4inches.
When use 3-pronged plug
When use grounding adaptor, make sure
the receptacle box is fully grounded.
3-prong Receptacle
Receptacle
Box cover
3-prong plug
Grounding
Lead
Grounding
Adapter
Receptacle
“THE CANADIAN ELECTRICAL CORD DOES NOT ALLOW THE USE OF THE GROUNDING ADAPTOR”
Receptacle
Box Cover
DEAN-MCMY10SCC-C-926T9A(영) 2005.7.5 5:22 PM 페이지4
5
SPECIFICATIONS
POWER SUPPLY
120V AC 60 Hz SINGLE PHASE WITH GROUNDING
POWER CONSUMPTION 1500W
MICROWAVE OUTPUT POWER 1000W
FREQUENCY 2450 MHZ
GRILL POWER CONSUMPTION 850W
CONVECTION POWR CONSUMPTION 1450W
COMBINATION HEATING POWER CONSUMPTION 1500W
OUTSIDE DIMENSIONS (WXHXD) 542 x 329 x 515 mm ( 21.3 x 13.0 x 20.3 in. )
CAVITY DIMENSIONS (WXHXD) 350 x 230 x 355 mm ( 13.8 x 9.1 x 14.0 in. )
NET WEIGHT APPROX. 20 Kg ( 44.1 lbs. )
TIMER 60 min.
POWER SELECTIONS 10 LEVELS
* Specifications are subject to change without notice.
DEAN-MCMY10SCC-C-926T9A(영) 2005.7.5 5:22 PM 페이지5
6
FEATURES DIAGRAM
1 DOOR HOOK - When the door is closed, it will automatically lock shut. If door is opened while oven
is operating, the magnetron will immediately stop operating.
2 DOOR VIEWING SCREEN - Allows viewing of food. The screen is designed so that light can pass
through, but not the microwave.
3 METAL RACK
4 TOP HEATER - Turns on when convection, grill and combi cooking is selected.
5 OVEN LAMP - Automatically turns on during oven operating.
6 SAFETY INTERLOCK SYSTEM
7 CONTROL PANEL
8 TURNTABLE TRAY - Rotates during cooking and ensure even distribution of Microwaves.
It can also be used as a cooking utensil.
9 ROLLER GUIDE - This must always be used for cooking together with the turntable tray.
0 COUPLER - This fits over the shaft in the center of the ovens cavity floor. This is to remain in the
oven for all cooking.
q CONVECTION OUTLET & FAN
w OVEN FRONT PLATE
e DOOR SEAL - Door seal maintains the microwave energy within the oven cavity and prevents
microwave leakage.
DEAN-MCMY10SCC-C-926T9A(영) 2005.7.5 5:22 PM 페이지6
7
FEATURES DIAGRAM
(continued)
11
Display : Cooking time, power level,
indicators and present time are displayed.
MW : When blinking, the oven is operating in
MICROWAVE COOK.
Grill : When blinking, the oven is operating in
GRILL.
Combi : When blinking, the oven is operating
in COMBI.
Defrost Weight : When blinking, the oven is
operating in WEIGHT DEFROST.
Time : When blinking, the oven is operating
in TIME DEFROST.
Auto-cook : When blinking, the oven is
operating AUTO COOK.
Lock : When lighting, the oven is CHILD
LOCK.
Con-vection : When blinking, the oven is
operating in CONVECTION.
g : When blinking, the oven is operating in
weight input mode.
22
Auto cook : Used to cook or reheat.
33
MICROWAVE : Used to set power level of
microwave.
44
Convection : Used to select convection and
selected temp.
55
Grill : Used to select grill.
66
Combi : Used to select combi.
77
Time Defrost : Used to defrost foods.
88
Weight Defrost : Used to defrost foods.
99
Clock : Used to set clock.
00
Time set pad : Used to set time, weight and
quantity.
qq
START/SPEEDY COOK : Used to start a
programmed, also for speedy start(each
press adds 30 seconds microwave cooking
time).
ww
STOP/CLEAR : Used to stop the oven
operation or to delete the cooking data.
DEAN-MCMY10SCC-C-926T9A(영) 2005.7.5 5:22 PM 페이지7
8
ACCESSORIES
This oven comes equipped with several accessories.
They can be used in various ways to facilitate cooking.
■ Rotating base
This fits over the shaft in the center of the oven’s cavity
floor.
This to remain in the oven for all cooking. It should only be
removed for cleaning.
■ Turntable tray or turntable
This metal tray fits over the rotating base and locks into
place.
This is to be used in the oven for all cooking. It rotates
clockwise or counterclockwise during cooking. It is easily
removable for cooking and cleaning needs.
■ Metal rack
This metal rack is used with the turntable tray.
■ HOW TO USE THE ACCESSORIES OF COOKING
Important:
The rotating base must be placed in the center of
the oven’s cavity and fitted in the rotating shaft
exactly.
In case the rotating base does not fit in the
rotating shaft, the rotating base might become as
tray and sparks can occur.
■ Turntable
• Microwave cooking
• Convection cooking
• Combination cooking
• Auto cooking
■ Metal rack
• Grill cooking
• Auto cooking(1, 2, 3, 4)
• No convection cooking
DEAN-MCMY10SCC-C-926T9A(영) 2005.7.5 5:22 PM 페이지8
9
BEFORE OPERATION
SETTING THE CLOCK
When the oven is first plugged in, the display will show “:0” and a tone will sound. If the AC power ever goes off,
the display show “ : 0” when the power comes back on.
1. Touch CLOCK pad.
This is a 12 hour clock system.
2. Touch CLOCK pad once more.
This is a 24 hour clock system.
3. Enter the correct time of day by
touching the numbers in
sequence.
4. Touch CLOCK pad.
NOTE: If you attempt to enter an incorrect time, the time will not be set and a error signal tone will sound.
Touch the CLOCK pad and re-enter the time.
The display stops blinking, and the
colon starts blinking. If you selected
12 hour clock system, this digital
clock allows you to set from 1:00 to
12:59. If you selected 24 hour clock
system, this digital clock allows you to
set from 0:00 to 23:59.
NOTE : This oven has multiple
clock systems.
If you want 12 hour clock
system, omit this step.
DEAN-MCMY10SCC-C-926T9A(영) 2005.7.5 5:22 PM 페이지9
10
Child lock : The child lock prevents the oven from being used. For example because children could hurt
themselves on hot liquids etc.
Power save mode : This function is used for saving energy.
To set child lock
1. Touch STOP/CLEAR pad.
" : 0" or clock appears in the
display.
2. Touch and then hold
STOP/CLEAR pad for 3 seconds.
3. To cancel child lock simply repeat
procedure 2.
To set power save mode
1. Touch STOP/CLEAR pad.
" : 0" or clock appears in the
display.
2. Touch and then hold Clock pad
for 3 seconds.
3. To cancel power save simply repeat setting procedure.
The oven will Lock indicator lights.
Now the oven cannot be operated.
The oven will beep and lock indicator
disappears. The oven is again
available for normal use.
The display will turn off and a beep
sounds.
To operate the oven in power save
mode, touch any key.
Then " :0" or clock will be shown and
the operation of all function key will
be same as in the normal mode. But
if there is no operation within 10
seconds in clear mode or while
manipulating the key, all the contents
of display will disappear.
The power save mode will be
canceled and a beep sounds.
The oven is again available for
normal use.
CHILD LOCK AND POWER SAVE MODE
DEAN-MCMY10SCC-C-926T9A(영) 2005.7.5 5:22 PM 페이지10
Loading...
