1.6 Cu. Ft.

Countertop Microwave Oven

User's Manual

Model MCM1611ST

PLEASE READ THIS MANUAL CAREFULLY BEFORE USING YOUR MICROWAVE OVEN AND KEEP IT FOR FUTURE REFERENCE.

Product Registration

Thank you for purchasing a Magic Chef product. The first step to protect your new product is to complete the product registration on our website: www.mcappliance.com/register. The benefits of registering your product include the following:

1. Registering your product will allow us to contact you regarding a safety notification or product update.

2. Registering your product will allow for more efficient warranty service processing when warranty service is required.

3. Registering your product could act as your proof of purchase in the event of insurance loss.

Once again, thank you for purchasing a Magic Chef product.

PRECAUTIONS TO AVOID POSSIBLE

EN-1

EXPOSURE TO EXCESSIVE MICROWAVE ENERGY

TABLE OF CONTENTS

EN-2

z PRECAUTIONS TO AVOID POSSIBLE EXPOSURE TO EXCESSIVE MICROWAVE ENERGY………………………..

z IMPORTANT SAFETY INSTRUCTIONS…………………………………………………………………..…………….…......

z FEDERAL COMMUNICATIONS COMMISSION

RADIO FREQUENCY INTERFERENCE STATEMENT………………………………………………….….……………..… 4

z GROUNDING INSTRUCTIONS………………………………………………………………………………........………….... 4

z INSTALLATION………………………………………………………………………………………………………...………..… 5

z SPECIFICATIONS………………………………………………………………………………………………………………….6

z PARTS AND FEATURES……………………………………………………………………………………………...………..…7

TURNTABLE…………………………………………………………………………………………………………….…..….….7

z MICROWAVE OVEN CONTROL…………………………………………………………………………..……….….……..….7

DISPLAY………………………………………………………………………………………………………………….……..….7

START……………………………………………………………………………………………………………………………....8

ADD 30 SECONDS………..…………………………………………………………………………………….….……….........8

EXPRESS COOK……………………………………………………………………………………………………………...…..8

STOP/C ………………………………………………………………………………………………….………...…..….8

ANCEL.

CLOCK….………………………………………………………………………………………………………………..……..…..8

TONES.……………………………………………………………………………………………………………………...….…..8

KITCHEN TIMER…………………………………………………………………………………………………….….……..…..8

CONTROL LOCK ……….………………………………………………………………………………………….....……….….8

z MICROWAVE OVEN USE……………………………………………………………………………………..………..…..…….9

FOOD CHARACTERISTICS………………………………………………………………………………..………….….….….9

COOKING GUIDELINES………………………………………………………………………………………………...…….….9

COOKWARE AND DINNERWARE………………………………………………………………………………..……….…….9

ALUMINUM FOIL AND METAL………………………………………………………………………….……………..….……

MICROWAVE COOKING POWER…………………………………………………………………………….……….…....… 10

MANUAL COOKING………………………………………………………………………………………………………..….… 11

COOKING IN STAGES……………………………………………………………………………………………….…….….…11

DEFROST………………………………………………………………………………………………………...………….….…11

MEMORY…………………………………………………………………………………………………………………….….…

POPCORN…………………………………………………………………………………………………………..……...….….

POTATO……………………………………………………………………………………………………………….……...…… 12

PIZZA……………………………………………………………………………………………………….………………...…… 13

BEVERAGE…………………………………………………………………………………………………………………..……

DINNER PLATE…………………………………………………………………………………………………………..…….…

FROZEN VEGETABLE

z CARE OF YOUR MICROWAVE OVEN……………………………………………………………………….…….…….……. 14

z BEFORE YOU CALL FOR SERVICE…………………………………………………………………………….……….…….

z CARE AND CLEANING…………………………………………………………………………………………………………. 15

z QUESTIONS AND ANSWERS………………………………………………………………………………….…….…………

z USE YOUR MICROWAVE OVEN SAFELY……………………………………………………………………...…………….

z ARCING…………………………………………………………………………………………………………………………… 17

z MICROWAVE OVEN WARRANTY…………………………………………………………………………………..…….…... 18

………………………………………………………………………………………………………….

13 13

…

….

…

IMPORTANT SAFETY INSTRUCTIONS

EN-3

When using electrical appliances, basic safety precautions should be followed, including

following: WARNING-To reduce the risk of burns, electric shock, fire, injury to

the

persons or

1.Read all instructions before using the appliance.

2.Read and follow the specific “PRECAUTIONS TO AVOID POSSIBLE EXPOSURE TO EXCESSIVE MICROWAVE ENERGY” found on page 1.

3.This appliance must be grounded. Connect only

to properly grounded outlet. See “GROUNDING

INSTRUCTIONS” found on page 4.

4.Install or locate this appliance only in accordance with the provided installation instructions.

5.Some products such as whole eggs and sealed containers - for example, closed glass jars are

able

this oven.

Use this appliance only for its intended use as described in this manual. Do not use corrosive chemicals or vapors in this appliance. This type

of oven is specifically designed to heat, cook, or dry food. It is not designed for industrial or laboratory use.

7.As with any appliance, close supervision is necessary when used by children.

8.Do not operate this appliance if it has a

damaged cord or plug, if it is not working properly, or if it has been damaged or dropped.

9.This appliance should be serviced only by

qualified service personnel.

Contact nearest authorized service facility for

examination, repair or adjustment.

10.

Do not cover or block any openings on the

appliance.

11.Do not store this appliance outdoors. Do not use

this product near water — for example, near a kitchen sink, in a wet basement, near a swimming pool, or similar locations.

12.Do not immerse cord or plug in water.

13.Keep cord away from heated surfaces.

14.Do not let cord hang over edge of table or counter.

15. When cleaning surfaces of door and oven

that comes together on closing the door, use only mild, non-abrasive soaps or detergents applied with a sponge or soft cloth.

16.To reduce the risk of fire in the oven cavity: a) Do not overcook food. Carefully attend

exposure

to explode and should not be heated in

appliance when paper, plastic, or other combustible materials are placed inside the oven to facilitate cooking.

to excessive microwave energy:

b) Remove wire twist-ties from paper or plastic

bags before placing bag in oven.

c) If materials inside the oven ignite, keep oven

door closed, turn oven off, and disconnect the power cord, or shut off power at the fuse or

circuit breaker panel.

d) Do not use the cavity for storage purposes. Do

not leave paper products, cooking utensils, or food in the cavity when not in use.

17. Liquids, such as water, coffee, or tea are able to

be overheated beyond the boiling point without

appearing to be boiling due to surface tension of

the liquid. Visible bubbling or boiling when the container is removed from the microwave oven is not always present. THIS COULD RESULT IN VERY HOT LIQUIDS SUDDENLY BOILING OVER WHEN SPOON OR OTHER UTENSIL IS INSERTED INTO THE LIQUID.

To reduce the risk of injury to persons:

a) Do not overheat the liquid. b) Stir the liquid both before and halfway through

heating it.

c) Do not use straight-sided containers with

narrow necks.

d) After heating, allow the container to stand in

the microwave oven for a short time before

removing the container.

e) Use extreme care when inserting a spoon or

other utensil into the container.

18.Do not use this microwave oven to heat corrosive chemicals (for example, sulfides and chlorides). Vapors from such corrosive chemicals may

interact with the contact and springs of the safety interlock switches thereby rendering them inoperable.

19.Keep the waveguide cover clean at all times. Wipe the oven interior with a soft damp cloth after each use. If you leave grease or fat anywhere in

the cavity it may overheat, smoke or even catch fire when next using the oven.

20. Never heat oil or fat for deep frying as you cannot control the temperature and doing so may lead to overheating and fire.

21.

Do not operate the oven without the glass tray

in place. Be sure it is properly sitting on the rotating base.

SAVE THESE INSTRUCTIONS

261800317767

FEDERAL COMMUNICATIONS

EN-4

COMMISSION RADIO FREQUENCY INTERFERENCE STATEMENT

WARNING:

This equipment generates and uses ISM frequency energy and if not installed and used

properly, that is in strict accordance with the manufacturer's instructions, may cause interference to radio and television reception.

It has been type-tested and found to comply with limits for an ISM Equipment pursuant to

part 18 of FCC Rules, which are designed to provide reasonable protection against such interference in a residential installation.

However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause interference to radio or television reception,which can be

determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or

• Reorient the receiving antenna of radio or television.

• Relocate the Microwave oven with respect to the receiver.

• Move the microwave oven away from the receiver.

• Plug the microwave oven into a different outlet so that microwave oven and

receiver are on different branch circuits.

THE MANUFACTURER is not responsible for any radio or TV interference caused by UNAUTHORIZED MODIFICATION to this microwave oven. It is the responsibility of the user

to correct such interference.

more of the followings.

GROUNDING INSTRUCTIONS

This appliance must be grounded. In the event of an electrical short circuit, the grounding plug reduces

the risk of electric shock by providing an escape wire for electric current. This appliance is equipped

with a cord having a grounding wire with a grounding plug. The plug must be plugged into an

outlet that is

WARNING:

Improper use of the grounding can result in a risk of electric shock. Consult a qualified electrician or serviceman if the grounding instructions are not completely

understood, or if doubt exists as to whether the appliance is properly grounded, and either :

If it is necessary to use an extension cord, use only a 3-wire extension cord that has a 3-blade

grounding plug, and a 3-slot receptacle that will accept the plug on the appliance. The marked

rating of the extension cord shall be equal to or greater than the electrical rating of the appliance.

WARNING:

Do not cut or remove the third (ground) prong from the power cord under any circumstances.

properly installed and grounded.

INSTALLATION

EN-5

1. Examine the oven after unpacking. Check for damage such as a misaligned door, broken door or dent in the cavity.

If any damage is visible, DO NOT INSTALL, and notify your dealer immediately.

2. Level, flat location. Install the microwave oven on a level, flat surface.

3. Ventilation. Do not block air vents. If they are blocked during operation, the oven may overheat and eventually cause a failure. For proper ventilation, allow 4 inches (10.16 cm) of space between oven top, sides, rear and adjacent surfaces.

4. Away from radio and TV sets. Poor television reception and radio interference may result if the oven is located close to a TV, radio, antenna, feeder, etc. Place the oven as far from them as possible.

5. Away from heating appliances and water taps. Keep the oven away from heat, steam or splashing liquids. These things can adversely affect oven wiring and contacts.

6. Power supply.

• Check your local power source.

This microwave oven requires a current of approximately 15 amperes, 120Volts, 60Hz grounded outlet.

1. A short power-supply cord is provided to reduce the risks resulting from becoming entangled in or tripping over a longer cord.

2. Longer cord sets or extension cords are available and may be used if care is exercised in their use.

3. If a long cord or extension cord is used:

• The marked electrical rating of the cord set or extension cord should be at least as great as the electrical

rating of the appliance.

• The extension cord must be a grounding type 3-wire cord.

• The longer cord should be arranged so that it will not drape over the counter top or tabletop where it can be

pulled on by children or tripped over unintentionally.

7. The minimum height of free space necessary above the top surface of the oven is about 4 inches (10.16 cm).

When use 3-pronged plug

3-prong Receptacle

Receptacle Box cover

3-prong plug

When use grounding adaptor, make sure the receptacle box is fully grounded.

Grounding Lead

Grounding Adaptor

Receptacle Box Cover

Receptacle

“THE CANADIAN ELECTRICAL CODE DOES NOT ALLOW THE USE OF THE GROUNDING ADAPTOR”

SPECIFICATIONS

EN-6

POWER SUPPLY

INPUT POWER 1 W

MICROWAVE ENERGY OUTPUT 0W

FREQUENCY 2,450MHz OUTSIDE DIMENSIONS (W H CAVITY DIMENSIONS (W H CAVITY VOLUME NET WEIGHT APPROX. TIMER 99 min. 99 sec. POWER LEVELS 11 Levels

* Specifications are subject to change without notice.

x x

D) 3

120V AC, 60Hz SINGLE PHASE WITH GROUNDING

550

110

5 x x

326.1

94 x 260 x 433 mm (15.5 x 10.2 x 17.0 in)

1.6 cu.ft

21.8

12.

487 mm (2

6.8

lbs.

x 12. x

1.8 8

19.2

in)

PARTS AND FEATURES

EN-7

This manual may cover several different models.

The model you

or all of the features shown here. of your particular model may differ slightly from

the illustrations in this manual.

have purchased may have some

The appearance

MICROWA VE OVEN CONTROL

A B C D E

A.Door lock system B.Metal shielded window C.Glass turntable

D.Microwave inlet cover E.Microwave oven light F.Display G.Control panel

F G

Tur ntable

A.Turntable B.Hub C.Roller Guide

The turntable can rotate in either direction to help cook do not

the turntable

to reorder any of

T o Install:

1. Install the hub into the hole in the center of the

microwave

2. Place the support on the microwave oven cavity

Fit the raised, curved mounds in the center of the turntable hub.

more evenly. For best cooking results,

food

operate the

bottom. Place the turntable on the support.

microwave oven without having

in place. See

the parts.

oven cavity bottom

bottom between the three spokes of the

“Assistance or Service”

When power is first supplied to the microwave oven,

“0:00” will

in the display at any occurred. Reset the clock if When the microwave oven is in use, the display shows cook time

in use, the display

set)

appear in the display. If the “0:00” appears

remaining. When the microwave oven is not

or Timer countdown.

Display

other time, a power failure has

needed. See “Clock” section.

shows the time of day (if the clock is

The START control (START/+30SEC pad) begins

EN-8

any function.

STOP/CANCEL or by opening

START/+30SEC will resume the cycle.

If cooking is interrupted by touching

the door, touching

Add 30 Seconds

The +30SEC control (ST ART/+30SEC) automatically

Start

starts the seconds, and adds each additional touch of the

microwave oven at 100% power for 30

30 seconds of cook time with

control.

Tones are audible signals that indicate the following:

Tones

One tone

Valid entry (short tone)

End of stage in multistage cooking

Control lock activated or deactivated (long tone)

Five tones

End of cycle

End of Kitchen Timer countdown

Each of the EXPRESS COOK controls (number pads

automatically starts the microwave oven at 100%

1-6)

power for

5 minutes or

touched.

1 minute, 2 minutes, 3minutes, 4 minutes,

6 minutes, depending on which pad is

Stop/Cancel

Express Cook

The STOP/CANCEL control clears any incorrect

command, and during cooking. It will not

A cooking program may be paused by touching

STOP/CANCEL

cycle may be resumed by A cooking program may be canceled by touching

STOP/CANCEL

then touching STOP/CANCEL.

The STOP/CANCEL

unlock the

pauses and/or cancels any program

erase the time of day.

once or by opening the door. The

touching START/+30SEC.

twice, or by opening the door and

control is also used to lock and

control panel. See “Control Lock” section.

Clock

This is a standard 12-hour clock (1:00-12:59). If

the clock is not When the clock is set, the “:” the clock may be seen for 3 seconds CLOCK.

To Set:

The microwave oven must be in standby mode (no

functions

Touch CLOCK control

“00:00” will appear in the display, with the first “0”

flashing.

2. Enter current time, filling all four digits from left to right. The

3. Touch

set, “0:00” will remain in the display.

operating).

first digit can be only “1” or “0.”

CLOCK.

will flash. During cooking,

by touching

Kitchen Timer

The Kitchen Timer can be set in minutes and seconds,

up to

99 minutes, 99 seconds, and counts down the

set time. The

any other function is

NOTE: The Kitchen Timer does not start or stop the

microwav

To Set:

1. TouchKITCHEN TIMER control . “00:00” will appear in the display, with the first “0” flashing.

2. Enter desired time in minutes and seconds, filling all

four

minutes, or

3. Touch START/+30SEC. When the set time ends, end-of-timer tones will sound, and

Touch STOP/CANCEL at any time during the countdown

Kitchen Timer may not be used while

operating.

oven.

digits from left to right. Example: 1-0-0-0 for 10

0-5-0-0 for 5 minutes.

the display will return to the time of day.

cancel the Kitchen Timer.

Control Lock

The Control Lock shuts down the control panel pads

to avoid be in

for 3 seconds until

display clears to show an outline of Repeat to unlock control, and return the display the time of day. control is locked, there will be no microwave oven.

unintended use of the microwave oven.

To Lock/Unlock Control: The microwave oven must

standby mode. Touch and hold STOP/CANCEL

one long tone sounds and the

the display area.

If any pad is touched while the

response from the

MICROWAVE OVEN USE

EN-9

A magnetron in the microwave oven produces micro

waves ceiling and pass cookware to the food. and absorbed by fat, sugar and

the food, causing them to move,

and heat

To avoid damage to the microwave oven, do not

lean on or

oven door.

To avoid damage to the microwave oven, do not

operate

Baby bottles and baby food jars should not be

heated in

Clothes, flowers, fruit, herbs, wood, gourds, paper,

including not be dried in

Paraffin wax will not melt in the microwave oven

because it

Use oven mitts or pot holders when removing

tainers from

Do not overcook potatoes. At the end of the reco

mmended firm. Let potatoes finish cooking while standing.

Do not cook or reheat whole eggs inside the shell.

Steam

burst, requiring

oven cavity. Cover poached

standing time.

When microwave cooking, the amount, size and shape, starting food affect cooking

Amount of Food

The more food heated at once, the longer the cook time needed. of time if

Size and Shape

Smaller pieces of food will cook more quickly than larger

pieces,

than irregularly

Starting Temperature

Room temperature foods will heat faster than refrigerated foods, foods.

Composition and Density

Foods high in fat and sugar will reach a higher temper

ature, and

dense foods, such as longer cook time than the same size food, such as cake.

reflect off the metal floor, walls and

which

through the

turntable and appropriate

Microwaves are

attracted to

water molecules in

producing

friction

which cooks the food.

allow children to swing on the microwave

when it is empty.

microwave oven.

brown paper bags and newspaper, should

microwave oven.

does not absorb microwaves.

microwave oven.

con

cook time, potatoes should be slightly

stand for 5 minutes. They will

buildup in whole eggs may cause them to

significant cleanup of microwave

eggs and allow a

Food Characteristics

temperature, composition and density of the

Check for doneness and add small increments

necessary.

and uniformly shaped foods cook more evenly

and refrigerated foods will heat faster than frozen

results.

shaped food.

will heat faster than other foods. Heavy,

meat and potatoes, require a

of a light, porous

Cooking Guidelines

Covering

Covering food helps retain moisture, shorten cook time and reduce spattering. Use the lid supplied with cookware. If a

not available, wax paper, paper towels or plastic wrap

lid is

approved

should be turned to vent steam.

is normal during

for microwave ovens may be used. Plastic wrap

back at one corner to provide an opening

Condensation on the door and cavity surfaces

heavy cooking.

Stirring and Turning

Stirring and turning redistribute heat evenly to avoid over

cooking

the outer edges of food. Stir from outside to

center. If possible,

turn food over from bottom to top.

Arranging

If heating irregularly shaped or different sized foods, arrange

the

thinner parts and smaller sized items toward the center. If

cooking several items of the same size and shape, place them

a ring pattern, leaving the center of the ring empty.

Piercing

Before heating, use a fork or small knife to pierce or prick

foods

that have a skin or membrane, such as potatoes, egg chicken livers, hot dogs, and sausage. Prick in several

yolks, places to

allow steam to vent.

Shielding

Use small, flat pieces of aluminum foil to shield the thin

pieces of

as chicken

irregularly shaped foods, bones and foods such

and Metal” first.

wings, leg tips and fish tail. See “Aluminum Foil

Standing Time

Food will continue to cook by the natural conduction of heat

after the microwave cooking cycle ends. The length of

even

time depends on the volume and density of the food.

standing

Cookware and Dinnerware

Cookware and dinnerware must fit on the turntable.

Always use

because any dish may

erred dinnerware with gold or silver trim. Use the chart as a guide, then test before using.

MATERIAL RECOMMENDATIONS

Aluminum Foil, Metal

Browning Dish Bottom must be at least 3/16" (5 mm)

Ceramic Glass, Glass

oven mitts or pot holders when handling

from the food. Do not use

become hot from heat transf

cookware and

See “Aluminum Foil and Metal” section.

above the turntable. Follow manufacturer’s recommendations.

Acceptable for use

following

MATERIAL

EN-10

China, Earthenware

Melamine Follow manufacturer’s recommendations. Paper: Towels,

Dinnerware, Napkins

Plastic: Wraps, Bags, Covers, Dinnerware, Containers

Pottery and ClayFollow manufacturer’s r ecommendations. Silicone

Bakeware Straw, Wicker,

Wooden Containers

Wax Paper Acceptable for use.

To Test Cookware or Dinnerware for Microwave Use:

1. Place cookware or dinnerware in microwave oven with

1 cup (250 mL) of water beside it.

2. Cook at 100% cooking power for 1 minute.

Do not use cookware or dinnerware if it becomes hot and the water stays cool.

RECOMMENDATIONS

Follow manufacturer’s r ecommendations.

Use nonrecycled and those approved by the manufacturer for microwave oven us

Use those approved by the manufacturer for microwave oven use.

Follow manufacturer’s r ecommendations.

Do not use in microwave oven.

Aluminum Foil and Metal

Always use oven mitts or pot holders when removing

dishes from

Aluminum foil and some metal can be used in the microwave oven. If not used properly, ar cing (a blue flash of light) can

occur

OK for Use

Racks and bakeware supplied with the microwave oven

(on some

meat

guidelines:

T o avoid damage to the micr owave oven, do not allow aluminum foil or metal to touch the inside cavity walls, ceiling or floor.

Always use the turntable.

T o avoid damage to the micr owave oven, do not allow contact with another metal object during microwave cooking.

Do Not Use

Metal cookware and bakeware, gold, silver , pew ter , nonapproved meat thermometers, skewers, twist ties, foil liners such as sandwich wrappers, staples and objects with gold or silver trim or a metallic glaze should not be used in the microwave oven.

the microwave oven.

and cause damage to the microwave oven.

models), aluminum foil for shielding, and appr oved

thermometers may be used with the following

Many recipes for microwave cooking specify which cooking

Microwave Cooking Power

power to use by percent, name or number . For example,

70% =

7=Medium-High

Use the following chart as a general guide for the suggested cooking power of specific foods.

PERCENT NUMBER USE NAME

100%, High (default setting)

90%

80%

70%, Medium-High

60%

50%, Medium

40%

30%, MediumLow, Defrost

20%

10%, Low

10 Quick heating convenience

foods and foods with high water content, such as soups, beverages and most vegetables.

9 Cooking small, tender pieces

of meat, ground meat, poultry pieces and fish fillets.

Heating cream soups.

8 Heating rice, pasta or stirrable

casseroles. Cooking and heating foods

that need a cook power lower than high. For example, whole fish and meat loaf.

7 Reheating a single serving of

food.

6 Cooking sensitive foods such

as cheese and egg dishes, pudding and custards.

Cooking non-stirrable casseroles, such as lasagna.

5 Cooking ham, whole poultry

and pot roasts. Simmering stews.

4 Melting chocolate.

Heating bread, rolls and pastries.

3 Defrosting bread, fish, meats,

poultry and precooked foods.

2 Softening butter, cheese, and

ice cream.

1 T aking chill out of fruit. 0 Work with fan for no power.

To U s e :

EN-11

1. Place food on the turntable and close the door.

2. Touch TIME COOK.

3. Enter length of time to cook.

4. Touch POWER. “PL10” will appear briefly in the display.

If cooking with a power other than 100%, touch number keys

to select the power levels from highest

lowest. See “Microwave Cooking Power” chart.

5. Touch START/+30SEC. The display will count down the set cook time.

When the cycle ends, the end-of-cycle tones will sound,

and

the display will return to the time of day.

6. T ouch STOP/CANCEL at any time during the countdown

pause or cancel cooking.

Cooking in Stages

The microwave oven can be set to cook at different cooking powers for various lengths of time, up to 2 stages. One of the stages may be an automatic Defrost function (see “Defrost” section), which will be the first stage.

To Cook in Stages:

Place food on the turntable and close the door.

2. Touch TIME COOK.

3. Enter length of time to cook.

4. Touch POWER. “PL10” will appear briefly in the display.

If cooking with a power other than 100%, touch number keys

to select the power levels from highest

lowest. See “Microwave Cooking Power” chart.

5. Touch TIME COOK.

Enter length of time to cook for second stage.

7. Touch POWER. “PL10” will appear briefly in the display. If cooking with a power other than 100%, touch number

keys

Manual Cooking

to select the power levels from highest

T ouch START/+30SEC. The display will count down the set cook time for each

and a short tone will sound at the end of the first

stage,

stage. The power level may be seen for 3 seconds by touching POWER during the cycling stage. When the cycle ends, the end-of-cycle tones will sound,

and

the display will return to the time of day.

Touch STOP/CANCEL at any time during the countdown

pause or cancel cooking.

Cook time may be added in 30-second increments during

second

the To Use Defrost As First Stage: Touch Weight Defrost,

"dEF1" appears in the display. Enter the number of ounces

between 4a

The Defrost feature has two functions: dEF1, which is an

automatic defrost by weight, and dEF2, which is a manual defrost be adjusted.

stage by touching START/+30SEC contr ol.

nd 100 ounces (see “Defrost” section), then

above for second stage programming.follow steps 5-8

Defrost

by time. The default power level is 30%, and can

Unwrap foods and remove lids (for example, from fruit juice containers) before defrosting.

lowest.

Shallow packages will defrost more quickly than deep blocks.

Separate food pieces as soon as possible during or at the

end of the cycle for more even defrosting. Use small pieces of aluminum foil to shield parts of food

as chicken wings, leg tips and fish tails. See

such “Aluminum

The Defrost feature should not be used for food that has been

outside the freezer for more than 20 minutes, or for

left

frozen r eady-

MEAT

Beef: ground, steaks, roast,

stew Lamb: stew and chops Pork: chops, ribs, roasts,

sausage

POULTRY

Chicken: whole and cut up

Cornish hens

Turkey: breast

FISH

Fillets, Steaks, Whole Shellfish Place in microwave-safe

To Defrost by Weight:

1. Place food, uncovered, on the turntable and close

the door.

2. Touch WEIGHT DEFROST. “dEF1” will appear.

3. Enter the weight in ounces, from 4 to 100.

If an invalid value is entered, the microwave oven will not

4. Touch START/+30SEC. The display will count down the defrost time.

When the cycle ends, the end-of-cycle tones will sound, and

5. Touch STOP/CANCEL at any time during the countdown pause or cancel cooking.

To Defrost by Time:

1. Place food, uncovered, on the turntable and close

the door. Touch TIME DEFROST. “dEF2” will appear in the

display.

3. Enter the desired time for defrosting.

The default microwave power is power level 3. If you want to change the power level,

the LED will display "PL 3", then press the number pad

of the power level

4. Touch START/+30SEC.

The display will count down the defrost time. When the cycle ends, the end-of-cycle tones will

sound, and

Touch STOP/CANCEL at any time during the coun

down to

and Metal” first.

Foil

made food. Use the following chart as a guide.

The narrow or fatty areas of irregular shaped cuts should be shielded with foil before defrosting.

Do not defrost less than 1/4 lb (113 g) or two 4 oz (113 g) patties.

Place all meats in microwavesafe baking dish. Do not cover.

Place in microwave-safe

baking dish, chicken breast side up. Do not cover.

baking dish. Do not cover.

start.

the display will return to the time of day.

press " POWER " once, and

you wanted.

the display will return to the time of day.

pause or cancel cooking.

The Memory feature can store up to 3 unique cooking programs.

EN-12

The Auto Menu functions cannot be programmed as a memory

function.

To Set Memory :

T ouch MEMORY control. “1” will appear in the display

first memory program.

for the

2. Set the program, following the instructions in “Manual Cooking” or “Cooking in Stages.”

3. Touch . A valid entry tone will sound,

T o Set Second and Third Memory Programs: Touch MEMORY twice or three times, then follow steps 2 and 3 above.

To U se Me mory:

2. Touch MEMOR Y repeatedly until the desired program

3. Touch START/+30SEC.

STAR T/+30SEC.

indicating

Touch START/+30SEC. again. The program will

immediately start,

Place food on the turntable and close the door. number The display will count down the program cook time.

When the cycle ends, the end-of-cycle tones will sound,

the display will return to the time of day.

and

Touch STOP/C at any time during the countdown to

pause or cancel cooking.

the program has been accepted to memory .

that

and it will be saved to memory

is displayed.

ANCEL

Popcorn

PAD TOUCH DISPLAY SERVING SIZE

Memory

POPCORN Once

NOTE: During Popcorn function, as with all microwave cooking functions, the microwave oven should be attended at all times. Listen for popping to slow to 1 pop every 1 or 2 seconds, then stop the cycle.

T o avoid damage to the microwave oven, do not use

regular

Pop only one package of popcorn at a time. Follow manufacturer’s instructions when using a microwave

popcorn popper. For best cooking results, do not try to pop unpopped kern

Use fresh bags of popcorn for optimal results.

Cooking results may vary by brand and fat content. For

bag

on the

2 times 3 times

paper bags or glassware.

sizes not listed in this section, follow directions

package.

1.75

3.0

3.5

1.75 oz (50 g)

3.0 oz (85 g)

3.5 oz (99 g)

T o Use POPCORN:

1. Place popcorn bag on the turntable, and close the door.

2. Touch POPCORN to select size (see chart).

3. Touch ST ART/+30SEC.

The display will count down the popping time. When the cycle ends, the end-of-cycle tones will sound,

the display will return to the time of day.

and

4. To uc h STOP/CANCEL at any time during the countdown to pause or cancel popping.

Pota to

PAD TOUCH DISPLAY SERVING SIZE

POTATO Once

the

To U s e PO TAT O :

1. Place potato(es) on the turntable and close the door.

2. T ouch POT ATO to select number of potatoes (see chart).

3. T ouch ST ART/+30SEC.

The display will count down the cook time. When the cycle ends, the end-of-cycle tones will sound,

and

4. Touch STOP/CANCEL at any time during the countdown to

pause or cancel cooking.

2 times 3 times

Pierce each potato several times with a fork before baking. Place a single potato on the turntable, off to the side (not

centered). Place 2 or 3 potatoes on the turntable around

edges, at least 1" (2.5 cm) apart.

Let potato(es) stand for 5 minutes after baking.

the display will return to the time of day.

1, 8-oz (230 g) potato

2, 16-oz (460 g) potatoes

3, 24-oz (690 g) potatoes

Pizza

EN-13

PAD TOUCH DISPLAY SERVING SIZE

PIZZA Once

o Use PIZZA:

1. Place pizza on the turntable, and close the door.

2. Touch PIZZA to select number of slices (see chart).

3. Touch START/+30SEC.

2 times 3 times

Place pizza slice(s) on a paper towel or paper plate.

The display will count down the reheat time. When the cycle ends, the end-of- cycle tones will sound,

the display will return to the time of day.

and

Tou c h STOP/CANCEL at any time during the countdown to pause or cancel heating.

4.0

8.0

14.0

1, 4-oz (113 g) slice 2, 8-oz (230 g) slices 3, 14-oz (400 g) slices

Dinner Plate

PAD TOUCH DISPLAY SERVING SIZE

DINNER PLATE

Place food on plate(s), cover with plastic wrap and vent.

To Use DINNER PLATE:

1. Place dinner plate on the turntable and close the door.

Once 2 times 3 times

2. Touch DINNER PLATE to select size (see chart).

3. Touch START/+30SEC.

The display will count down the cook time. When the cycle ends, the end-of-cycle tones will sound,

the display will return to the time of day.

4. Touch STOP/CANCEL at an y time during the countdown

pause or cancel heating.

9.0

12.0 18

9.0 oz (255 g)

12.0 oz (340 g)

18.0 oz (510 g)

Beverage

PAD TOUCH DISPLAY SERVING SIZE

BEVERAGE Once

Do not cover.

The diameter of the cup’s opening will affect how the liquid may heat

To Use BEVERAGE:

1. Place cup(s) on the turntable, and close the door.

2. Touch BEVERAGE to select amount (see chart).

3. Touch ST AR T/+30SEC.

The display will count down the heat time.

When the cycle ends, the end-of-cycle tones will sound, and

4. Touch STOP/CANCEL at any time during the countdown

2 times 3 times

heats. Beverages in cups with smaller openings

faster.

the display will return to the time of day.

pause or cancel heating.

1 2 3

1, 4-oz (120 mL) cup 2, 8-oz (240 mL) cups 3, 12-oz (360 mL) cups

Frozen Vegetable

PAD TOUCH DISPLAY SERVING SIZE

FROZEN VEGETABLE

Remove frozen vegetables from package.

Place in microwave-safe container.

Add water:

2tbs (30mL) to 4.0 oz (113 g) vegetables; 4tbs (60 mL) to 8.0 oz (230 g) vegetables;

1/3 cup (80 mL) to 16.0 oz( 460 g) vegetables.

Cover with plastic wrap and vent.

Stir and let stand 2-3minutes after cooking.

To Use FROZEN VEGETABLE:

1. Place food on the turntable and close the door.

2. Touch FROZEN VEGETABLE

(see chart).

3. Touch START/+30SEC. The display will count down the cook time. When the cycle ends, the end-of-cycle tones will sound,

and

4. Tou ch STOP/CANCEL at a ny time during the countdown

Once 2 times 3 times

4.0

8.0

16.0

4.0 oz (113 g)

8.0 oz (230 g)

16.0 oz (460g)

to select

the display will return to the time of day.

pause or cancel cooking.

amount

CARE OF YOUR MICROWAVE OVEN

EN-14

The oven should be cleaned regularly and any food deposits removed. Failure to maintain the oven in a clean condition could lead to deterioration of the surface that could adversely affect the life of the appliance and possibly result in a hazardous situation.

Unplug the power cord before cleaning any

part of this oven. Keep the inside of the oven clean. When food

spatters or spilled liquids adhere to oven walls, wipe with a damp cloth. Mild detergent may be used if the oven gets very dirty. The use of harsh detergent or abrasives is not recommended.

The outside oven surface should be cleaned

with soap and water, rinsed and dried with a soft cloth. To prevent damage to the operating parts inside the oven, water should not be allowed to seep into the ventilation openings.

If the Control Panel becomes wet, clean with a

soft, dry cloth. Do not use harsh detergents or abrasives on Control Panel.

If steam accumulates inside or around the

outside of the oven door, wipe with a soft cloth. This may occur when the microwave oven is operated under high humidity conditions and in

ROLLER GUIDE

The ROLLER GUIDE and oven floor should be

cleaned frequently to prevent excessive noise. The ROLLER GUIDE MUST ALWAYS be used

for cooking together with the Glass Tray.

no way indicates malfunction of the unit. It is occasionally necessary to remove the glass

tray for cleaning. Wash the tray in warm sudsy water or in a dishwasher.

The roller guide and oven cavity floor should be

cleaned regularly to avoid excessive noise. Simply wipe the bottom surface of the oven with mild detergent water or window cleaner and dry.

Glass Tray

Roller Guide

GLASS TRAY

DO NOT operate the oven without the Glass Tray

in place. DO NOT use any other Glass Tray with this oven.

If Glass Tray is hot, ALLOW TO COOL before

cleaning or placing it in water. DO NOT cook directly on the Glass Tray.

BEFORE YOU CALL FOR SERVICE

EN-15

Refer to following checklist, you may prevent an unnecessary service call.

* The oven doesn’t work :

1. Check that the power cord is securely plugged in.

2. Check that the door is firmly closed.

3. Check that the cooking time is set.

4. Check for a blown circuit fuse or tripped main circuit breaker in your house.

* Sparking in the cavity;

1. Check utensils. Metal containers or dishes with metal trim should not be used.

2. Check that metal skewers or foil does not touch the interior walls.

If there is still a problem, contact the service station. A list of these stations is included in the oven.

CARE AND CLEANING

Although your oven is provided with safety features, it is important to observe the following:

1. It is important not to defeat or tamper with safety interlocks.

2. Do not place any object between the oven front face and the door or allow residue to accumulate on sealing surfaces. Wipe the sealing area frequently with a mild detergent, rinse and dry. Never use abrasive powders or pads.

3. When opened, the door must not be subjected to strain, for example, a child hanging on an opened door or any load could cause the oven to fall forward to cause injury and also damage to the door. Do not operate the oven if it is damaged, until it has been repaired by a competent service technician. It is particularly important that the oven closes properly and that there is no damage to the:

i) Door(bent) ii) Hinges and Hookes(broken or loosened) iii) Door seals and sealing surfaces.

4. The oven should not be adjusted or repaired by anyone except a properly competent service technician.

5. The oven should be cleaned regularly and any food deposits removed;

6. Failure to maintain the oven in a clean condition could lead to deterioration of the surface that could adversely affect the life of the appliance and possibly result in a hazardous situation.

QUESTIONS AND ANSWERS

EN-16

* Q : Can the oven be used with the glass tray or

roller guide removed?

* A : No. Both the glass tray and roller guide must

always be used in the oven before cooking.

* Q : Can I open the door when the oven is

operating?

* A : The door can be opened anytime during the

cooking operation. Then microwave energy will be instantly switched off and the time setting will maintain until the door is closed.

* Q : Why do I have moisture in my microwave

oven after cooking?

* A : The moisture on the side of your microwave

oven is normal. It is caused by steam from cooking food hitting the cool oven surface.

* Q : Does microwave energy pass through the

viewing screen in the door?

* A : No. The metal screen bounces back the energy

to the oven cavity. The holes are made to allow light to pass through. They do not let microwave energy pass through.

* Q : Why do eggs sometimes pop?

* A : When baking or poaching eggs, the yolk may

pop due to steam build-up inside the yolk membrane. To prevent this, simply pierce the yolk with a toothpick before cooking. Never cook eggs without piercing their shells.

* Q : Why this standing time recommended after

the cooking operation has been completed?

* A : Standing time is very important.

With microwave cooking, the heat is in the food, not in the oven. Many foods build up enough internal heat to allow the cooking process to continue, even after the food is removed from the oven. Standing time for joints of meat, large vegetables and cakes is to allow the inside to cook completely, without overcooking the outside.

* Q : What does “standing time” mean?

* A : “Standing time” means that food should be

removed from the oven and covered for additional time to allow it to finish cooking. This frees the oven for other cooking.

Q : Why does my oven not always cook as fast

as the microwave cooking guide says?

* A : Check your cooking guide again, to make sure

you’ve followed directions exactly ; and to see what might cause variations in cooking time. Cooking guide times and heat settings are suggestions, to help prevent over-cooking... the most common problem in getting used to a microwave oven. Variations in the size, shape and weights and dimensions could require longer cooking time. Use your own judgement along with the cooking guide suggestions to check whether the food has been properly cooked just as you would do with a conventional cooker.

* Q : Will the microwave oven be damaged if it

operates while empty?

* A : Yes. Never run it empty.

* Q : Can I operate my microwave oven without

the turntable or turn the turntable over to hold a large dish?

* A : No. If you remove or turn over the turntable,

you will get poor cooking results. Dishes used in your oven must fit on the turntable.

* Q : Is it normal for the turntable to turn in either

direction?

* A : Yes. The turntable rotates clockwise or

counterclockwise, depending on the rotation of the motor when the cooking cycle begins.

* Q : Can I pop popcorn in my microwave oven?

How do I get the best results?

* A : Yes. Pop packaged microwave popcorn

following manufacture’s guidelines. Do not use regular paper bags. Use the “listening test” by stopping the oven as soon as the popping slows to a “pop” every 1 or 2 seconds. Do not repop unpopped kernels. Do not pop popcorn in glass cookware.

USE YOUR MICROWAVE OVEN SAFELY

EN-17

General Use

Do not attempt to defeat or tamper with safety interlocks. Do not place any object between the oven front frame and the door or allow residue to build up on sealing surfaces. Wipe with a mild detergent, rinse and dry. Never use abrasive powders or pads. Do not subject the oven door to strain or weight such as a child hanging on an open door. This could cause the oven to fall forward resulting in injury to you and damage to the oven.

Food

Never use your microwave oven for home canning. The oven is not designed for proper home canning. Improperly canned food may spoil and be dangerous to consume. Always use the minimum recipe cooking time. It is better to undercook rather than overcook foods. Undercooked foods can be returned to the oven for more cooking. If food is overcooked, nothing can be done. Heat small quantities of food or foods with low moisture carefully. These can quickly dry out, burn or catch on fire. Do not heat eggs in the shell. Pressure may build up and eggs can explode. Potatoes, apples, egg yolks and sausages are examples of food with non-porous skins. These must be pierced before cooking to prevent bursting. Do not attempt to deep fat fry in your microwave oven. Always allow a standing time of at least 20 seconds after the oven has been switched off to allow the

Do not operate the oven if door seals or sealing surfaces are damaged; or if door is bent; or if hinges are loose or broken. Do not operate the oven empty. This will damage the oven. Do not attempt to dry clothes, newspapers or other materials in the oven. They may catch on fire. Do not use recycled paper products as they may contain impurities which may cause sparks or fires. Do not hit or strike the control panel with hard objects. This can damage the oven.

temperature to even out, stir during heating, if necessary, and ALWAYS stir after heating. To prevent eruptive boiling and possible scalding, you should put a spoon or glass stick into the beverages and stir before, during and after heating. Do not leave the oven unattended while popping corn. Do not pop corn in a paper bag unless it is the commercially prepared Microwave Popcorn product. The kernels can overheat and ignite a brown paper bag. Do not put packaged Microwave Popcorn bags directly on the oven tray. Place the package on a microwave safe glass or ceramic plate to avoid overheating and cracking the oven tray. Do not exceed the Microwave Popcorn manufacturers suggested popping time. Longer popping does not yield more popcorn but it can result in buring the popcorn or risk of fire. Remember, the Popcorn bag and tray can be too hot to handle. Remove with caution and use pot holders.

ARCING

If you see arcing, touch the pad and correct the problem.

Arcing is the microwave term for sparks in the oven. Arcing is caused by:

• Metal or foil touching the side of the oven.

• Foil not molded to food (upturned edges act like antennas).

STOP/CANCEL

• Metal, such as twist-ties, poultry pins, or gold rimmed dishes, in the microwave.

• Recycled paper towels containing small metal pieces being used in the microwave.

Limited Warranty

EN-18

MC Appliance Corporation warrants each new Counvertop Microwave Oven to be free from defects in material and workmanship, and agrees to remedy any such defect or to furnish a new part(s), at the company’s option, for any part(s) of the unit that have failed during the warranty period. Parts and labor expenses are covered on this unit for a period of one year from the date of purchase. A copy of the dated sales receipt or invoice is required to receive warranty service by an authorized service agent.

In addition, MC Appliance Corporation warrants the magnetron (parts only) to be free from defects in material and workmanship for a period of eight years. The consumer is responsible for all labor and transportation expenses related to the diagnosis and replacement of the magnetron after the initial one-year warranty expires. In the event the unit requires replacement or refund under the terms of this warranty, the consumer is responsible for all transportation expenses to return the unit to our factory prior to receiving a replacement unit or refund. A copy of the dated sales receipt/invoice is required to receive warranty service, replacement or refund.

This warranty covers appliances in use within the continental United States, Alaska, Hawaii and Puerto Rico. This warranty does not cover the following:

• Damages due to shipping damage or improper installation.

• Damages due to misuse or abuse.

• Content losses due to failure of the unit.

• Inside components such as turntable, roller guide, light bulbs, etc.

• Repairs performed by unauthorized service agents.

• Service calls that do not involve defects in material and workmanship such as instructions on proper use of the product or improper installation.

• Replacement or resetting of house fuses or circuit breakers.

• Failure of this product if used for other purposes than its intended purpose.

• Disposal costs for any failed unit not returned to our factory.

• Any delivery/installation costs incurred as the result of a unit that fails to perform as specified.

• Expenses for travel and transportation for product service if your appliance is located in a remote area where service by an authorized service technician is not available.

• The removal and reinstallation of your appliance if it is installed in an inaccessible location or is not installed in accordance with published installation instructions.

• Refunds for non repairable products are limited to the price paid for the unit per the sales receipt.

Limitations of Remedies and Exclusions:

Product repair in accordance with the terms herein, is your sole and exclusive remedy under this limited warranty. Any and all implied warranties including merchantability and fitness for a particular purpose are hereby limited to one year or the shortest

period allowed by law. MC Appliance Corporation is not liable for incidental or consequential damages and no representative or person is authorized to assume for us any other liability in connection with the sale of this product. Under no circumstances is the consumer permitted to return this unit to the factory without the prior written consent of MC Appliance Corporation.

Some states prohibit the exclusion or limitation of incidental or consequential damages, or limitations on implied warranties. This warranty gives you specific legal rights, and you may also have other rights which vary from state to state.

Model Parts & Labor Magnetron (Parts Only) Type of Service

MCM1611ST

For Service or Assistance please call 888-775-0202 or visit us on the web at www.mcappliance.com to request warranty service or order parts.

One Year Eight Years Carry In

www.mcappliance.com Printed in China

1.6 Cu. Ft.

Microondas de encimera

Manual del usuario

Modelo MCM1611ST

LEA ESTE MANUAL ANTES DE UTILIZAR SU MICROONDAS Y

GUÁRDELO PARA FUTURA REFERENCIA.

Registración del producto

Gracias por comprar el producto Magic Chef. El primer paso para proteger su nuevo producto es completar la forma de registración en nuestra pagina web: www.mcappliance/register. Los beneficios de registrar su producto incluyen lo siguiente:

1. Al registrar su producto nos permite contactarle para notificarle de un cambio de seguridad o actualización del producto.

2. Si llegara a necesitar servicio bajo garantía, registrando su producto nos permite ser más eficiente en procesar el servicio.

3. En el evento que usted tenga una perdida que esta cubierto por un seguro, registrando su producto puede servir como prueba de su compra.

Una vez más gracias por comprar un producto marca Magic Chef.

SP-1

PRECAUCIONES QUE DEBEN TENERSE PARA EVITAR QUEDAR EXPUESTO A LA

ENERGIA DIRECTA DE LAS MICROONDAS

(a) No intente operar el horno con la puerta abierta, ya que la operación en tal condición

puede causarle un daño muy grave debido a la exposición directa con la energía de microondas. Es importante no obstruir los orificios de sujeción de los ganchos de seguridad de la puerta.

(b) No coloque ningún objeto entre la puerta y el gabinete, tampoco permita la

acumulación

del horno cierre adecuadamente y que no esté floja, asimismo que las bisagras y los ganchos del seguro de la puerta no estén rotos, retorcidos o flojos. Si así fuese, acuda al centro de servicio autorizado.

(d) El horno deberá repararse únicamente por le personal técnico capacitado.

de grasa e impurezas en los orificios de sujeción de los seguros de la puerta.

SP-2

INSTRUCCIONES IMPORTANTES DE

SP-3

SEGURIDAD

Cuando se usan equipos eléctricos deben seguirse ciertas reglas básicas de seguridad, incluyendo lo

ADVERTENCIA - Para reducir el riesgo de quemaduras, electrocución, incendio, daños a personas o

exposición excesiva a la energía de microondas:

1. Lea todas las Instrucciones antes de usar el equipo.

2. Lea y siga las recomendaciones en:

“PRECAUCIONES QUE DEBEN TENERSE PARA EVITAR QUEDAR EXPUESTO A LA EXCESIVA ENERGIA DE MICROONDAS” señalado en la pág. 1.

3. Este equipo debe tener una conexión de tierra, lea las

"INSTRUCCIONES DE CONEXION A TIERRA", encontradas en la pág. 4.

4. Instale o coloque este aparato de acuerdo únicamente

con las instrucciones de instalación proporcionadas.

5. Algunos productos los huevos tal como enteros y selló

contenedores-Por ejemplo, cerró vidrio los frascos son capaz de estallar y no debe ser calentado en este horno.

6. Utilice este equipo sólo para el propósito por el cual fue

diseñado, especificado en este manual. No use químicos corrosivos en este equipo. Este tipo de horno ha sido diseñado exclusivamente para calentar, cocinar o descongelar alimentos. No esta diseñado para uso industrial o de laboratorio.

7. Como con cualquier aplicación, la supervisión cercana

es necesaria cuando es utilizada por los niños.

8. No use el horno si tiene dañado el cable de

alimentación o clavija, si funciona de manera inapropiada o si ha sufrido alguna caída.

9. Este equipo debe ser revisado solamente por un

personal cualificado de servicio. Contacta un facilidad de servicio el más cercano

para examinar, reparar o ajustar.

10. No cubra o bloquee ninguna salida de ventilación

del equipo.

11. No almacene este aparato fuera. No utilice este producto cerca de agua- Por ejemplo, cerca de un

lavaplatos, en un sótano mojado, o cerca de un estanque, o las ubicaciones semejantes.

12. No sumeria en agua el cable de alimentación o clavija.

13. Mantenga el cable de alimentación alejado de superficies calientes.

14. No deje el cable de alimentación colgado sobre el borde de la mesa o mostrador.

15. Cuando se limpien las superficies que entran en contacto al cerrar la puerta, use jabones o detergentes

suaves aplicados con esponja o paño suave.

16. Para reducir el riesgo de fuego dentro del horno:

a) no recuece alimento. Asista detenidamente

aparato cuando papel, el plástico, u otras materias combustibles se colocan dentro del horno

para facilitar la cocina.

b) Quite las ataduras de alambre de las bolsas de

plástico o papel antes de introducirlas en el horno.

c) Si las materias dentro del horno encienden,

mantengan puerta de horno cerró, apaga horno, y desconecta la cuerda del poder, o apagó el poder en el fufse o entrepaño de cachón de circuito.

d) No utilice el horno para almacenar, no deje

productos de papel, utensilios de cocina o comida en el interior del horno cuando éste se encuentre

sin operar.

17. Los líquidos, tal como agua, el café, o el té son capaces de ser recalentado bevond el punto hirviente sin aparecer para estar heiviéndose debido surgir la tensión del líquido. Burbujear o hervir visibles cuando el contenedor se quita del horno de la microhonda no es siempre el presente. ESTO PODRIA TENER COMO RESULTADO LIQUIDOS MUY CALIENTES REPENTINAMENTE HERVIR SOBRE CUANDO

UNA CUCHARA U OTRO UTIL se METEN EN EL

LIQUIDO. Para reducir el riesgo de inlury a personas: a) No recaliente el líquido. b) Bata el líquido antes de y medio por la

calefacciónlo.

c) No utilice directamente contenedores de lados

con cuellos estrechos.

d) El horno de la microhonda por un tiempo corto

antes de quitar el contenedor.

e) Utilice el cuidado extremo cuando meter una

cuchara u otro útil en el contenedor.

18. No use esta microondas para calentar químicos corrosivos (por ejemplo sulfatos o cloratos.) Los vapores de tales corrosivos pueden reaccionar con los contactos y los muelles del interruptor de seguridad resultado inutilizar.

19. Mantenga limpia la cubierta de la salida de microondas. Limpie el interior del horno con un trapo suave después de usarlo. Si usted deja grasa en cualquier parte de el interior del horno, ésta podría sobrecalentarse, humeando o atrapar fuego cuando

el horno sea utilizado nuevamente.

20. Nunca caliente aceite o grasa para freír en el horno

ya que usted no puede hacerlo y estar controlando

la temperatura, estas pueden sobrecalentarse y provocar fuego.

21. No funcione el horno sin la bandeja de cristal en lugar. Sea seguro que se está sentando correctamente

en la base que rota.

CONSERVE ESTE MANUAL DE

INSTRUCCIONES

261800317767

DECLARACION SOBRE INTERFERENCIA DE

SP-4

RADIOFRECUENCIAS DE LA COMISION FEDERAL DE COMUNICACIONES

ADVERTENCIA:

Este equipo genera y utiliza energía de frecuencia ISM, por lo que si no es instalado y utilizado apropiadamente, conforme a las instrucciones del fabricante, podría causar interferencia en la recepción de la radio y television. Este producto ha sido clasificado y probado; encontrándose que satisface los términos para un equipo ISM, según la sección 18 del reglamento FCC, que está planteada para ofrecer protección apropiada contra aquella interferencia en instalaciones residenciales. No obstante, no se garantiza que la interferencia no llegue a ocurrir en alguna instalación en particular. Si este equipo ocasiona interferencia en la recepción de radio o televisión, la cual puede suceder al momento de encender o apagar el equipo, entonces será preciso que el usuario intente corregir dicha interferencia mediante alguna de las siguientes indicaciones:

• Reoriente la antena de recepción de radio o televisión.

• Reubique el horno de microondas con respecto al receptor.

• Aleje el horno de microondas del equipo receptor.

• Conecte el horno de microondas en una toma de corriente diferente, de forma que el horno de microondas y el receptor se alimenten de distintos circuitos eléctricos.

EL FABRICANTE no es responsable por cualquier interferencia de radio o TV causada por una MODIFICACION NO AUTORIZADA al horno de microondas. Es responsabilidad del usuario corregir dicha interferencia.

INSTRUCCIONES DE CONEXION A TIERRA

Este equipo debe de estar conectado a tierra; ya que en caso de un corto circuito, el cable a tierra reduce

el riesgo de sufrir una descarga eléctrica al proporcionar una trayectoria de escape a la corriente eléctrica. Por lo tanto este aparato está equipado con una clavija polarizada que contiene una a tierra, la cual debe de conectarse a un contacto que esté propiamente instalado y conectado a tierra.

terminal para la conexión

ADVERTENCIA:

La conexión inapropiada a tierra puede ser un factor de riesgo de sufrir una descarga eléctrica. Consulte a un electricista calificado o al personal de servicio, si las instrucciones de instalación no son completamente entendibles o si existe alguna duda de que el equipo esté conectado adecuadamente a tierra, cuide también:

Si es necesario utilizar una extensión de corriente, entonces use únicamente extensiones de tres

cables, con clavija polarizada con contacto a tierra, y que a su vez el contacto de la extension se ajuste a la clavija del equipo. La capacidad electrica de la extensión debe de ser cuando menos de la misma que la del cable del horno. Así

ADVERTENCIA; No corte ni quite el tercero (ground)prong del cable eléctrico bajo cualquieres

circunstancias.

INSTALACION

SP-5

1. Examine el horno después de abrirlo.

Revise que no esté dañado, no tenga abolladuras, que la puerta esté alineada y que la cavidad no esté rayada o abollada. Si existe algún desperfecto visible, NO INSTALE EL HORNO y notifíquelo inmediatamente a su vendedor.

2. Superficie regular y estable.

Coloque el microondas sobre una superficie plana y estable.

3. Ventilación.

No obstruya las rejillas de ventilación. Si estas son bloqueadas durante la operación, el horno se puede calentar excesivamente y eventualmente tener alguna falla. Para proporcionarle la adecuada ventilación, mantenga como mínimo 4 inches (10.16 cm) de espacio entre cualquier costado del horno y el lugar en donde va a instalarse.

4. Manténgalo alejado de equipos de radio y televisión.

Una mala recepción de televisión e interferencia en la radio pueden presentarse si el horno está colocado cerca de la TV, radio, antena, etc., Mantenga alejado el horno de microondas de estos equipos lo más que se pueda.

5. Manténgalo alejado de equipos generadores de calor y de llaves de agua.

No coloque el equipo en lugares calurosos y húmedos, para prevenir el riesgo de incendio o de sufrir una descarga eléctrica. Asimismo no lo instale cerca de la tarja.

6. Suministro de Energía - Revise el voltaje de su domicilio.

Compruebe su fuente de energía local. Este horno de microondas requiere una corriente aproximada de 1 amperes, a AC 120 Voltios, 60 Hz

con contacto polarizado con conexión a tierra.

1) Este horno tiene suministrado un cable de corriente corto; esto es con la intención de prevenir el riesgo de llegar a enredarse o tropezar con él.

2) Se puede llegar a utilizar juegos de cable más largos o extensiones de corriente, siempre y cuando se tenga el debido cuidado en su uso.

3) Si se utiliza un cable largo o una extensión. Entonces el rango eléctrico del cable (calibre) o de la extensión debe de ser por lo menos del mismo tipo que el usado en el horno. El cable de extensión debe de ser del tipo de 3 conductores. El cable largo debe de acomodarse de forma que no se pueda producir un accidente, debido al tropezar o enredarse con él y a su vez de no quedar al alcance de los niños.

7. El espacio mínimo necesario que debe haber sobre la parte superior del horno es de 4 inches (10.16 cm).

Cuando use clavija de 3 puntas

Contacto para clavija de 3 puntas

Cubierta del contacto

Clavija de 3 puntas

"EL REGLAMENTO ELECTRICO CANADIENSE NO PERMITE EL USO DE ADAPTADORES DE TIERRA"

Cuando utilice un adaptador de clavija, asegúrese de que el contacto esté debidamente conectado a tierra.

Cable de tierra

Adaptador de clavija

Cubierta del contacto

Contacto

ESPECIFICACIONES

SP-6

Fuente de Alimentación

Consumo1 0 W

MICROONDASPotencia de salida de microondas 0 W

Frecuencia de microondas2450 MHz

Dimensiones externas (Ancho x Alto x Fondo) pulgadas)

Volumen de la cavidad u.ft.

Peso netoAproximadamente 3 lbs.

Cronómetro99 min. 99 seg.

Niveles de potencia1 iveles

* Las especificaciones están sujetas a cambio sin notificación previa, por mejoras del equipo.

21.8

120V AC, 60Hz

MONOPHASE AVEC FONDRE

110

553 x 326.1 x 487 mm (21.8 x 12.8 x 19.2

394 x 260 x 433 mm 15.5 x 10.2 x 17.0

1.6 c

1 n

( pulgadas)Dimensiones de la cavidad (Ancho x Alto x Fondo)

19.2

12.

PARTES Y CARACTERÍSTICAS

SP-7

Este manual corresponde a varios modelos diferentes. El modelo que usted adquirió puede presentar sólo algunas de las características que aparecen aquí o todas ellas. El aspecto del modelo que usted adquirió puede ser algo diferente de las ilustraciones que aparecen en el manual.

A B C D E

F G

3. Coloque el plato giratorio en el soporte. Coloque las partes elevadas y curvas en el centro de la base del plato giratorio entre los tres rayos del eje.

CONTROL DE HORNO DE MICROONDAS

A. Traba de seguridad de la puerta B. Malla metálica de protección para la puerta C. Plato giratorio de vidrio D. Tapa de la ranura de ingreso a la cavidad E. Luz del horno F. Visor G. Panel de control

Plato giratorio

A. Plato giratorio B. Eje C. Soporte

El plato giratorio puede rotar en ambas dirección para obtener una cocción más pareja. Para obtener mejores resultados, no ponga en funcionamiento el horno sin el plato giratorio colocado en su lugar. Consulte la sección “Ayuda o Servicio” para realizar el pedido de alguna parte.

Para instalar:

1. Coloque el eje en el orificio que se encuentra en el

centro de la base de la cavidad del horno.

2. Coloque el soporte en la base de la cavidad del horno.

Visor

Cuando el horno se conecte por primera vez a la corriente eléctrica, la leyenda “0:00” aparecerá en el visor. Si en algún otro momento aparece la leyenda “0:00” en el visor, significa que hubo un corte de corriente. Vuelva a programar el reloj si es necesario. Consulte la sección “Reloj”. Cuando el horno está en uso, el visor muestra el tiempo de cocción restante. Cuando el horno no está en uso, en el visor aparece la hora del día (si se ha programado el reloj para mostrar la hora) o el tiempo restante fijado en el temporizador.

START

SP-8

START/+30SEC

STOP/CANCEL

START/+30SEC

COOK

STOP/CANCEL

START/+30SEC

STOP/CANCEL

START/+30SEC.

CLOCK

EXPRESS

STOP/CANCEL

KITCHEN TIMER

SP-9

START/+30SEC.

STOP/CANCEL

SP-10

PORCENTAGE

SP-11

/NOMBRE

NUMERO

USO

PORCENTAGE

SP-12

/NOMBRE

NUMERO

USO

TIME COOK.

Presione

mostrará "PL10". La potencia por defecto es

las teclas numéricas para ajustar el nivel de

potencia.

POWER

100% de potencia. Ahora puede pulsar

una vez, el LED

START/+30SEC.

STOP/CANCEL

Presione

mostrará "PL10". La potencia por defecto

las teclas numéricas para ajustar el nivel de

potencia.

POWER

100% de potencia. Ahora puede pulsar

una vez, el LED

TIME COOK.

Presione

mostrará "PL10". La potencia por defecto

las teclas numéricas para ajustar el nivel de

potencia.

POWER

100% de potencia. Ahora puede pulsar

una vez, el LED

START/+30SEC.

POWER

STOP/CANCEL

START/+30SEC.

Weight

5-8

WEIGHT DEFROST.

SP-13

START/+30SEC.

STOP/CANCEL

TIME DEFROST

START/+30SEC.

STOP/CANCEL

MEMORY.

START/+30SEC.

SP-14

START/+30SEC.

MEMORY

POPCORN

START/+30SEC.

MEMORY

START/+30SEC.

STOP/CANCEL

POPCORN.

STOP/CANCEL

BEVERAGE

SP-15

POTATO

START/+30SEC.

STOP/CANCEL

PIZZA

START/+30SEC.

STOP/CANCEL

DINNER PLATE

START/+30SEC.

STOP/CANCEL

Vegetales Congelados

SP-16

FROZEN VEGETABLE

START/+30SEC.

STOP/CANCEL

MANTENIMIENTO Y CUIDADO DE

SP-17

SU HORNO

El horno se debe limpiar regularmente y cualquier depsito del alimento quitado. La falta de mantener el horno en condiciones limpias podra conducir a la deterioracin de la superficie que podra afectar al contrario la vida de la aplicacin y dar lugar posiblemente a una situacin peligrosa.

Desconecte el horno antes de limpiarlo.

Mantenga limpio el interior del horno. Cuando los

alimentos salpiquen las paredes o se derramen en el interior, limpie el interior con un paño húmedo. Pude usar un detergente suave si el horno se encuentra demasiado sucio. No es recomendable usar detergentes fuertes o abrasivos.

La parte exterior del horno debe limpiarse con

agua y jabón, y enjuagarse y secarse con un paño suave. Para evitar daños a las partes que operan dentro del horno, no permita que entre agua por la abertura de ventilación.

Si el panel de control se moja, límpielo con un

paño suave. No use detergentes o abrasivos fuertes en el panel de control.

Si se acumula vapor en el interior del horno o

el borde de la puerta, límpielo con un paño suave. Esto suele ocurrir cuando el horno de microondas está siendo operado bajo condiciones de alta humedad, sin embargo, esto no es un indicio de mal funcionamiento.

ARILLO GIRATORIO

El ARILLO y la base de la cavidad, deben

limpiarse regularmente para evitar que hagan demasiado ruido.

El Plato de Cristal siempre debe colocarse

sobre el ARILLO para cocinar.

Ocasionalmente es necesario retirar el plato de

cristal para limpiarlo. Lávelo en agua tibia con jabón o en lavaplatos automático.

El arillo y la base de la cavidad, deben limpiarse

regularmente para evitar que hagan demasiado ruido. Simplemente limpie la superficie con agua y detergente suave o con limpiador de ventanas y seque. El eje puede lavarse con agua tibia.

Plato de Cristal

Arillo Giratorio

PLATO DE CRISTAL

No opere el horno sin el Palto de Cristal.

No use ningún otro plato de cristal en este

horno.

Si el plato de cristal está caliente, permita que

se enfríe antes de limpiarlo o colocarlo en agua.

No cocine directamente sobre el Plato de

Cristal.

ANTES DE LLAMAR AL SER

SP-18

TECNICO

Revisando la siguiente lista, usted podría evitar una llamada innecesaria al servicio técnico.

* El horno no funciona:

1. Revise que el cable de alimentación eléctrica esté bien conectado.

2. Revise que la puerta esté firmemente cerrada.

3. Revise que el tiempo de cocción esté seleccionado.

4. Revise si los fusibles de su casa se encuentran en perfecto estado o si hay algún corto circuito.

* Chispas en el interior:

1. Revise que los utensilios empleados no sean de metal o no tengan algún borde metálico.

Revise que las brochetas metálicas o el papel aluminio no estén rozando en las paredes internas del

horno.

Si persiste el problema llame al centro de servicio más cercano a su domicilio.

La lista de centros de servicio se encuentra en el certificado de garantía que viene en el interior del horno.

CUIDADO Y LIMPIEZA

Aunque su horno se proporciona las características de seguridad, es importante observar el siguiente:

1. Es importante no derrotar o no tratar de forzar con los dispositivos de seguridad.

2. No ponga ningún objeto entre el frontface del horno y la puerta ni permita que el residuo acumule en superficies de lacre. Limpie el área de lacre con frecuencia con un detergente suave, aclaración y seqúese. Nunca utilice los polvos abrasivos o los cojines.

3. Cuando está abierta, la puerta no se debe sujetar a la tensión, por ejemplo, un niño que colgaba en una puerta abierta o cualquier carga podría hacer el horno caer adelante para causar lesión y también para dañar a la puerta. No funcione el horno si se daña, hasta que ha sido reparado por un técnico competente del servicio. Es particularmente importante que el horno se cierra correctamente y que no hay daños a: i) Door(bent) ii) Bisagras y Hookes(broken o aflojado) iii) Sellos de puerta y superficies de lacre.

4. El horno no se debe ajustar o reparar por cualquier persona excepto un técnico correctamente competente del servicio.

5. El horno se debe limpiar regularmente y cualquier depósito del alimento quitado;

6. La falta de mantener el horno en condiciones limpias podría conducir a la deterioración de la superficie que podría afectar al contrario la vida de la aplicación y dar lugar posiblemente a una situación peligrosa.

PREGUNTAS Y RESPUESTAS

SP-19

*P : ¿Puedo operar el horno sin el plato de cristal

o sin la guía giratoria?

*R : No. Ambos utensilios deben utilizarse en el

horno antes de cocinar algún alimento.

*P : ¿Puedo abrir la puerta cuando el horno está

operando?

*R : Sí. La puerta puede abrirse en cualquier

momento durante la operación. Entonces la energía de la microonda será apagada inmediatamente y el ajuste del tiempo mantendrá hasta que la puerta es cerrada.

*P : ¿Porqué se acumula vapor en el horno de

microondas después de

*R : La acumulación de humedad es normal que

ocurra. Esto sucede, porque la comida produce vapor al cocinarse, y aunque gran parte de este vapor se elimina por el aire que es ventilado, algo de vapor suele permanecer, concentrándose en las superficies frías como lo es la puerta del horno.

*P : El horno de microondas causa interferencia

en mi TV. ¿Es normal esto?

*R : Sí. Algunas interferencias de radio o televisión

pueden ocurrir mientras el horno está en funcionamiento. Esta interferencia es similar a la causada por equipos pequeños como batidoras, aspiradoras, secadoras de pelo, etc. Esto no significa que haya problemas con el horno o su TV.

* P : ¿La energía de las microondas puede

traspasar la ventanilla de la puerta?

*R : No. La pantalla de metal de la ventanilla hace

regresar la energía de las microondas dentro de la cavidad del horno. Los orificios están hechos para permitir el paso de la luz a través de ellos y permitir inspeccionar los alimentos. Pero no dejan pasar la energía.

P: ¿Porqué

después de que se haya terminado la operación que

*R: El tiempo derecho es muy importante.

Con cocinar de microonda, el calor está en el alimento, no en el horno. Muchos alimentos acumulan bastante calor interno para permitir que el proceso que cocina continúe, incluso después el alimento se quite del horno. Hora derecha para los empalmes de la carne, los vehículos y las tortas grandes deben permitir que el interior cocine totalmente, sin quemar el exterior.

esta vez derecha recomendada

cocinaba?

cocinar?

*P: ¿Qué significa el "tiempo que está parado"?

*R: El "tiempo que está parado" significa que el

alimento se debe quitar del horno y cubrir por hora adicional de permitir que acabe el cocinar. libera el horno para otro cocinar.

*P : ¿Porqué

*R: Compruebe a su guía que cocina otra vez, para

*P: ¿Se dañe el horno de microonda si se opera en vacío?

*R: Sí. Nunca funciónela vacía.

*P: ¿Puedo funcionar mi horno de microonda sin

*R: No. Si usted quita o vuelca la placa giratoria,

*P: ¿Es normal para que la placa giratoria dé

*R: Sí. La placa giratoria rota a la derecha o a la

*P: ¿Puedo hacer estallar las palomitas en mi

*R: Sí. El estallido empaquetó las pautas de la

mi horno no cocina siempre como los fastas que la guía el cocinar de microonda dice?

cerciorarse de usted haber seguido direcciones exactamente; y para ver qué pudo causar variaciones en tiempo de cocción. Cocinando tiempos de la guía y calor los ajustes son sugerencias, para ayudar a evitar el quemar... del problema más común de conseguir utilizados a un horno de microonda. Las variaciones en el tamaño, la forma y los pesos y las dimensiones podían requerir tiempo más de largo de cocción. Utilice su propio juicio junto con las sugerencias de la guía que cocinan al cheque si el alimento se ha cocinado correctamente apenas pues usted haría con una cocina convencional.

la placa giratoria o dar la vuelta a la placa giratoria para sostener un plato grande?

usted conseguirá a pobres que cocinan resultados. Los platos usados en su horno deben caber en la placa giratoria.

vuelta en cualquier dirección?

izquierda, dependiendo de la rotación del motor cuando el ciclo que cocina comienza.

horno de microonda? ¿Cómo consigo los mejores resultados?

fabricación de siguiente de las palomitas de la microonda. No utilice las bolsas de papel regulares. Utilice la "prueba que escucha" parando el horno tan pronto como el hacer estallar retarde un "estallido" a cada 1 o 2 segundos. No el repop unpopped núcleos. No haga estallar las palomitas en el cookware de cristal.

USAR SU HORNO DE MICROONDAS

SP-20

CON SEGUIRDAD

Uso General

- Es importante no obstruir los orificios o eliminar los ganchos de seguridad de la puerta.

- No coloque ningún objeto entre la parte frontal y la puerta, ni permita que se acumulen residuos o suciedad en las superficies de sellado. Limpie continuamente las superficies de sellado con detergente suave, enjuague y seque. Nunca use polvos o limpiadores abrasivos.

- No permita que la puerta se deforme o sufra algún daño al estar abierta, por ejemplo cuando un niño se cuelgue o se apoye alguna carga. Esto puede causar que el horno se voltee y caiga, dañándose la puerta o el equipo.

- No opere el horno si está dañado y hasta no ser reparado por un técnico calificado. Es importante que la puerta cierre apropiadamente y que no existan daños en los sellos, superficie de sellado, bisagras y seguros. Cuando desempaque su horno, revise que no esté rayado o golpeado y asimismo que la cavidad no esté rayada o golpeada.

Alimentos

- Nunca utilice su horno de microondas para esterilizar comida en casa. El horno no está diseñado para esterilizar adecuadamente. La comida mal esterilizada puede descomponerse y ser peligrosa para su consumo.

- Siempre procure utilizar el menor tiempo de cocción de la receta. Recuerde que es mejor dejar un poco crudo que bien cocido. Si la comida quedó cruda puede regresarse al horno para volverla a cocinar. Si la comida está muy cocida y se ha quemado, entonces ya nada se puede hacer.

- Las pequeñas cantidades de alimento o la comida con bajo contenido de humedad puede llegar a quemarse, secarse o inflamarse si el tiempo de cocción es demasiado largo.

- No cocine huevos con cascarón o con la yema entera, ya que la presión podría hacer que el huevo explote. Revuelva los huevos antes de cocinarlos.

- Papas, manzanas, yemas de huevo, pollo, jitomates y salchichas son ejemplos de comidas con pieles no porosas, las cuales se deben perforar antes de cocinarse para evitar que estallen.

- No intente freír en el horno de microondas.

- No haga funcionar el horno si se encuentra vacío. Esto puede dañar el horno.

- No intente usar el horno para secar ropa, trapos, papel periódico u otros materiales. Estos pueden causar fuego. Tampoco introduzca animales dentro del horno.

- No use productos de papel reciclado, ya que estos pueden contener impurezas, las cuales pueden reflejar las microondas y producir chispas o fuego. Tampoco caliente líquidos, gases volátiles o materiales inflamables.

- No introduzca recipientes sellados, envases herméticos o alimentos enlatados.

- No maltrate ni golpee el panel de control. Esto puede dañar el horno.

- Los líquidos calientes pueden hacer ebullición si no se orean un poco. No caliente líquidos en su horno de microondas sin revolverlos constantemente.

- No descuide el horno mientras se cocinan las palomitas.

- No cocine el maíz palomero en bolsas de papel común y corriente, a menos que se trate de un producto especial para preparar palomitas en microondas. Las semillas de maíz se pueden sobrecalentar e incendiar las bolsas de papel estraza.

- No coloque la bolsa de palomitas directamente sobre el plato. Póngalas en un recipiente especial para microondas. No use aceite al menos que esto se halle especificado por el fabricante.

- No exceda el tiempo de cocción indicado por el fabricante de las palomitas. La cocción prolongada no hará que estalle más el maíz, y sólo ocasionará que se quemen e incendien. Recuerde que después de hacer las palomitas, el plato y la bolsa estarán muy calientes. Tome la bolsa cuidadosamente usando pinzas para cocina y utilice guantes para retirar el plato del horno.

ARCING

Si usted ve la formacin de arcos, toque el cojn de y corrija el problema.

La formacin de arcos es el trmino de la microonda para las chispas en el horno. La formacin de arcos se causa cerca:

* Metal u hoja que toca el lado del horno. * Hoja no moldeada al alimento (acto vuelto hacia arriba

de los bordes como las antenas).

STOP/CANCEL

* El metal, por ejemplo torcer-ata, los pernos de las aves

de corral, o goldrimmed platos, en la microonda.

* Toallas de papel recicladas que contienen los pedazos

pequeos del metal que son utilizados en la microonda.

Garantía limitada

SP-21

MC Appliance Corporation garantiza que todas las Microondas de encimera carecen de defectos en el material y la mano de obra y acuerda solucionar cualquiera de estos defectos o instalar la(s) parte(s) nueva(s) (a elección de la compañía) en caso de

que la unidad haya fallado durante el periodo de garantía. Las partes y gastos de reparación están cubiertos en esta unidad por un periodo de un año a partir de la fecha de compra. Se requiere una copia de la factura o recibo de compra para recibir el servicio de garantía por parte de un agente de servicio autorizado.

Además MC Appliance corporation autoriza el magnetrón (piezas solamente) para estar libre de defectos en material y la ejecución por un período de ocho años. El consumidor es responsable de todo el trabajo y los costos del transporte relacionados con la diagnosis y el reemplazo del magnetrón después de las uno garantías inicial del año expiran. Si en el acontecimiento la unidad requiere el reemplazo o el reembolso bajo términos de esta garantía el consumidor es responsable de todos los costos del transporte volver la unidad a nuestra fábrica antes de recibir una unidad o un reembolso del reemplazo.

Esta garantía cubre los aparatos que se usen dentro de los Estados Unidos continentales, Alaska, Hawái y Puerto Rico. La garantía no cubre lo siguiente:

• Daños debido al daño del envío o a la instalación incorrecta.

• Daños debido al mal uso o abuso.

• Pérdidas de contenido debido a falla de la unidad.

• Componentes internos como platos giratorio, guía de rodillos, bombillas, etc.

• Las reparaciones se realizaron por los agentes desautorizados del servicio.

• Llamadas de servicio que no implican defectos en material y la ejecución tal como instrucción en el uso apropiado del producto o de la instalación incorrecta.

• Reemplazo o reajuste de los fusibles o de los interruptores de la casa.

• Falla de este producto si se usa con fines distintos a los que fue diseñado.

• Costes de la disposición de unidades falladas no vueltas a nuestra fábrica.

• Todos los gastos de entrega/instalación incurridos como resultado de una unidad que no cumple con lo especificado.

• Gastos de viajes y el transporte de los productos principales de servicio si su aparato está situado en una zona remota donde el servicio por un técnico de servicio no está disponible.

• La remoción y reinstalación de su gran aparato, si está instalado en un lugar inaccesible o no está instalado de conformidad con las instrucciones de instalación publicadas.

• Restituciones por productos no reparables se limita al precio pagado por la unidad por el recibo de compra.

Limitaciones de remedios y exclusiones:

La reparación del producto de acuerdo con los términos de este documento, es el único y exclusivo remedio determinado en esta garantía limitada. Todas y cada una de las garantías implicadas, incluyendo la calidad de comerciable y capacidad para un propósito particular, se limitan mediante la presente a un año o el periodo más corto permitido por la ley. MC Appliance Corporation no es responsable por daños incidentales ni resultantes y ningún representante o persona alguna están autorizados para asumir de parte nuestra ninguna otra responsabilidad en relación con la venta de este producto. Bajo ninguna circunstancia se le permite al consumidor regresar esta unidad a la fábrica sin consentimiento previo por escrito de MC Appliance Corporation.

Algunos estados prohíben la exclusión o limitación por daños incidentales o resultantes, o limitaciones en las garantías implícitas. Esta garantía le otorga a usted derechos legales específicos, y usted puede también tener otros derechos que varían según la entidad federa!va donde se encuentre.

Modelo Piezas & Trabajo Magnetrón (Parte solamente) Tipo de servicio

MCM1611ST

Para servicio o asistencia, llame por favor al 888-775-0202. O visítenos en www.mcappliance.com para solicitar el servicio de garantía o repuestos.

Uno año Ocho años Lleve adentro

www.mcappliance.com Impreso en China

Magic Chef MCM1611ST User Manual

Specifications and Main Features

Frequently Asked Questions

User Manual
