Magic Chef MCWC50DST, MCBC58DST Owner's Manual

STAINLESS STEEL BUILT-IN WINE/BEVERAGE COOLER

INSTRUCTION MANUAL

Model No.: MCWC50DST

MCBC58DST

To ensure proper use of this appliance and your safety, please read the

following instructions completely before operating this appliance.

Product Registration Copy

Thank you for purchasing a Vissani product. The first step in protecting your new product is to complete the product registration form on our website at www.mcappliance.com/register. The benefits of registering your product include the following.

1. Registering your product will allow us to contact you regarding a safety notification or product update.

2. In the event that warranty service is required, registering your product will allow for more efficient warranty service processing.

3. In the event of an insurance loss registering your product could act as your proof of purchase.

Once again thank you for purchasing a Vissani product.

TABLE OF CONTENTS

NAMES OF THE PARTS……………………………………………………… 3 SPECIFICATIONS…………………………………………………………….. 4 IMPORTANT SAFETY INSTRUCTIONS……………………………………. 5 INSTALLATION INSTRUCTIONS

BEFORE USING YOUR APPLIANCE…………………………..…… 5 FREE STANDING INSTALLATION….………………….…………… 5 BUILT-IN INSTALLATION………..…………………………………… 6 ELECTRICAL CONNECTION ……………….………………………. 6

APPLIANCE FEATURE

MCWC50DST: WINE COOLER ……………………………………... 7 MCBC58DST: BEVERAGE COOLER ……………….……………… 7

OPERATING YOUR APPLIANCE

MCWC50DST: WINE COOLER …………….……………………….. 8 MCBC58DST: BEVERAGE COOLER ….…………………….……… 8 CHANGING THE INNER LIGHT …………………………………….. 9

AUTOMATIC DEFROST ……………………………………………… 9 CHANGING THE REVERSIBLE DOOR ……………………………………. 9 CARE AND MAINTENANCE

CLEANING YOUR APPLIANCE……………………………………… 10

VACATION TIME………………………………………………………. 10

MOVING YOUR APPLIANCE………………………………………… 10

ENERGY SAVING TIPS……………………….………..……………. 10 TROUBLESHOOTING GUIDE………………………………………………. 11 APPLIANCE WARRANTY…………………………….……………………… 12

NAMES OF THE PARTS

MODEL NO.: MCWC50DST

MODEL NO.: MCBC58DST

① Electronic thermostat ② Wine rack ③ Door gasket ④ Glass door ⑤ Cabinet

① Electronic thermostat ② Beverage shelf ③ Door gasket ④ Glass door ⑤ Cabinet

SPECIFICATIONS – Model # MCWC50DST

Product Description

Vissani 50 Bottle Stainless Steel

Built-In Wine Cooler

Model No.

MCWC50DST

Unit Dimensions

( inches )

Width

Height

Depth

23.4”

34.4”

24.4”

Net Weight ( lbs)

98 lbs

SPECIFICATIONS – Model # MCBC58DST

Product Description

Vissani 5.8 cu.ft. Stainless Steel

Built-In Beverage Cooler

Model No.

MCBC58DST

Unit Dimensions

( inches )

Width

Height

Depth

23.4”

34.4”

24.4”

Net Weight ( lbs)

99 lbs

IMPORTANT SAFETY INSTRUCTIONS

WARNING

To reduce the risk of fire, electrical shock, or injury when using your appliance, follow these basic precautions:

 Read all instructions before using the wine or beverage cooler.  DANGER or WARNING: Risk of child entrapment.  To avoid the possibility of child entrapment, please take the following precautions

before throwing out the appliance.

- Remove all doors from the unit.

- Leave the shelves in place so that children may not easily climb inside.

 Never allow children to operate, play with, or crawl inside the appliance.  Refrigerants: All refrigeration products contain refrigerants, which under the

guidelines of federal law must be removed before disposal of product. It is the consumer’s responsibility to comply with federal and local regulations when disposing of this product.

 Never clean appliance parts with flammable fluids. The fumes can create a fire

hazard or explosion.

 Do not store or use gasoline or any other flammable vapors and liquids in the vicinity

of this or any other appliance. The fumes can create a fire hazard or an explosion.

-Save these instructions-

INSTALLATION INSTRUCTIONS

Before Using Your Appliance

 Remove the exterior and interior packing.  Before connecting the appliance to the power source, let it stand upright for approximately 4

hours. This will reduce the possibility of a malfunction in the cooling system from improper handling during transportation.

 Clean the interior surface with lukewarm water using a soft cloth. (Cleaning instruction on page 9)

Free-Standing Installation

 This appliance is designed to be installed built-in or free standing.  Locate the appliance away from direct sunlight and sources of heat (stove, heater, radiator, etc.).

Direct sunlight may affect the acrylic coating and heat sources may increase electrical consumption. Ambient temperature below 55°F (12.8°C) or above 77°F (25°C) will hinder the performance of this appliance. This unit is not designed for use in a garage or any other

outside installation.

 Avoid locating the appliance in moist areas.  Plug the appliance into dedicated, properly installed-grounded wall outlet. Do not under any

circumstances cut or remove the third (ground) prong from the power cord. Any questions concerning power and/or grounding should be directed toward a certified electrician or an authorized service center. This unit is not designed to be installed in an RV or used with an

inverter.

 After plugging the appliance into a wall outlet, turn the unit on and allow the unit to cool down for 3

~ 4 hours under before placing wine bottles or beverages in the appliance.

Built-In Installation

The cutout dimension illustrated in figure (A) allows for door swing and access to the pull-out shelves when installed as a built-in appliance. If installing between frameless cabinets,

a ½” wide filler strip or side panel may be needed on hinge side. The filler strip will act as a spacer between the appliance case and adjacent cabinet door swing. The width of the opening must include the filter panels.

Note:

 The door should protrude at least 1” beyond the

surrounding cabinets.

 If door reversal is desired, please follow Reversible door

instructions on page 8 of this manual prior to installation.

Electrical Connection

This appliance should be properly grounded for your safety. The power cord of this appliance is equipped with a three-prong plug which mates with standard three prong wall outlets to minimize the possibility of electrical shock.

Do not, under any circumstances, cut or remove the third ground prong from the power cord supplied. This appliance requires a standard 115 Volt A.C. /60Hz electrical outlet with three-prong ground. This appliance is not designed to be used with an inverter. The cord should be secured behind the appliance and not left exposed or dangling to prevent

accidental injury. Never unplug the appliance by pulling the power cord. Always grip the plug firmly and pull straight out

from the receptacle. Do not use an extension cord with this appliance. If the power cord is too short, have a qualified

electrician or service technician install an outlet near the appliance. Use of an extension cord can negatively affect the performance of the unit.

If any problems with the appliance persist, please contact our Customer Service Dept. to consult with a representative at 888 775-0202 or visit our website to request warranty service at

www.mcappliance.com.

WARNING

Improper use of the grounded plug can result in the risk of electrical shock. If the power cord is damaged, have it replaced by an authorized service center.

The cutout depth must be 24”.

Figure A

APPLIANCE FEATURE

MCWC50DST: Wine Cooler

Engaged Wine Shelves

 There are five wine shelves of full depth in upper part of

cabinet to store wine bottles.

 The second supporting guide (Counted from top, see

illustration “A”) is not designed for wine shelves. It is only for beverage shelf.

 All the top five wine shelve have tabs to engage the

cabinet on both sides.

 Any of the wine shelve can be removed to accommodate

larger bottles.

To Remove a Shelf:

 Remove all bottles from the shelves.  Lift the shelve upwards and then gently pull out the shelves.

To Replace a Shelf:

 Place the sides of the shelves back onto the supporting guides of the cabinet and push back until

the shelf tabs slide into place.

NOTE: Ensure that the tabs are firmly engaged in place before storing any bottles.

Bottle Arrangement

 The top five shelves each hold 8 bottles with the bottle necks

alternating front to back.

 The bottom rack, which consist of two stories, each holds 6

bottles with bottle necks facing the front.

MCBC58DST: Beverage Cooler

Engaged Beverage Shelves

 There are three glass shelves to store beverage cans or

bottles.

 All three glass shelves have tabs to engage the cabinet

on both sides.

 The shelves may be arranged on any supporting guide as

preferred.

 Any of the glass shelves can be removed to

accommodate larger cans or bottles.

To Remove a Shelf:

 Remove all cans or bottles from the shelves.  Lift the shelve upwards and then gently pull out the

shelves.

To Replace a Shelf:

 Place the sides of the shelves back onto the supporting guides of the cabinet and push back until

the shelf tabs slide into place.

NOTE: Ensure that the tabs are firmly engaged in place before storing any beverages.

Warning:

 Do not press/jostle the circulation fan in the cabinet when you place in or remove the beverage

cans or bottles.

 Properly store your beverages so that the cans or bottles do not hinder air circulation inside the

cabinet.
