Magic Chef MSD2641KEB, 12842123 User Manual

Side-by-Side

Table of Contents

Important Safety Instructions..... 1-2

Installation ...................................... 3-7

Temperature Controls................. 8-10

Fresh Food Features ................. 11-14

Freezer Features.............................. 15

Ice and Water............................. 16-18

Water Filter................................. 19-21

Use & Care Guide

Food Storage Tips..................... 22-24

Care and Cleaning.................... 25-28

Operating Sounds ........................... 29

Troubleshooting......................... 30-33

Warranty & Service ......................... 35

Guide d’utilisation et d’entretien. 36

Guía de uso y cuidado ................... 74

Important Safety Instructions

Installer: Please leave this guide with this appliance. Consumer: Please read and keep this Use and

Care Guide for future reference; it provides the proper use and maintenance information.

Keep sales receipt and/or canceled check as proof of purchase.

Call: 1-800-688-9900 USA

1-800-688-2002 Canada

Have complete model and serial number identification of your refrigerator. This is located on a data plate inside the fresh food compartment, on the upper right side. Record these numbers below for easy access.

Model Number _______________________________ Serial Number ________________________________ Date of Purchase______________________________ In our continuing effort to improve the quality and

performance of our appliances, it may be necessary to make changes to the appliance without revising this guide.

What You Need to Know About Safety Instructions

Warning and Important Safety Instructions appearing in this guide are not meant to cover all possible conditions and situations that may occur. Common sense, caution and care must be exercised when installing, maintaining or operating appliance.

Always contact the manufacturer about problems or conditions you do not understand.

DANGER

To reduce risk of injury or death, follow basic precautions, including the following:

Important: Child entrapment and suffocation are

not problems of the past. Junked or abandoned refrigerators are still dangerous – even if they sit out for “just a few days.” If you are getting rid of your old refrigerator, please follow the instructions below to help prevent accidents.

Before you throw away your old refrigerator or freezer:

• Take off the doors.

• Leave the shelves in place so children may not easily climb inside.

• Cut off power cord plug.

This appliance is equipped with a three-prong grounded plug for your protection against possible electrical shock hazards. It must be plugged into a properly grounded wall receptacle. Where a standard two-prong wall receptacle is encountered, it is the personal responsibility and obligation of the customer to have it replaced with a properly grounded threeprong wall receptacle. Do not, under any

circumstances, cut or remove the third (ground) prong from the power cord. Do not use an adapter

plug.

Power supply cord with

three-prong grounded plug

Recognize Safety Symbols, Words, Labels

DANGER

DANGER – Immediate hazards which WILL result in severe personal injury or death.

WARNING

WARNING – Hazards or unsafe practices which COULD result in severe personal injury or death.

CAUTION

CAUTION – Hazards or unsafe practices which COULD result in minor personal injury or property damage.

Properly

grounded type

wall receptacle

Important Safety Instructions

WARNING

To reduce risk of fire, electric shock, serious injury or death when using your refrigerator, follow basic precautions, including the following:

1. Read all instructions before using the refrigerator.

2. Observe all local codes and ordinances.

3. Be sure to follow grounding instructions.

4. Check with a qualified electrician if you are not sure this appliance is properly grounded.

5. Do not ground to a gas line.

6. Do not ground to a cold-water pipe.

7. Refrigerator is designed to operate on a separate 115 volt, 15 amp., 60 cycle line.

8. Do not modify plug on power cord. If plug does

not fit wall receptacle, have proper receptacle installed by a qualified electrician.

9. Do not use a two-prong adapter, extension cord

or power strip.

10. Do not remove warning tag from power cord.

11. Do not tamper with refrigerator controls.

12. Do not service or replace any part of refrigerator

unless specifically recommended in Use and Care Guide or published user-repair instructions. Do not attempt service if instructions are not understood or if they are beyond personal skill level.

13. Always disconnect refrigerator from electrical supply before attempting any service. Disconnect power cord by grasping the plug, not the cord.

14. Install refrigerator according to Installation Instructions. All connections for water, electrical power and grounding must comply with local codes and be made by licensed personnel when required.

15. Keep your refrigerator in good condition. Bumping or dropping refrigerator can damage refrigerator or cause refrigerator to malfunction or leak. If damage occurs, have refrigerator checked by qualified service technician.

16. Have worn power cords and/or loose plugs replaced by a qualified service technician.

17. Always read and follow manufacturer’s storage and ideal environment instructions for items being stored in refrigerator.

18. Your refrigerator should not be operated in the presence of explosive fumes.

19. Children should not climb, hang or stand on any part of the refrigerator.

20. Clean up spills or water leakage associated with water installation.

SAVE THESE INSTRUCTIONS

Installation

Location

• Do not install refrigerator near oven, radiator or

other heat source. If not possible, shield refrigerator with cabinet material.

• Do not install where temperature falls below 55° F

(13° C) or rises above 110° F (43° C). Malfunction may occur at this temperature.

• Refrigerator is designed for indoor household

application only.

Measuring the Opening

When installing your refrigerator, allow

⁄2” space behind machine compartment cover

and (located in the rear) for proper air circulation. If the refrigerator is placed with the door hinge side against a wall, you may want to allow additional space so the door can be opened wider.

Subflooring or floor coverings (i.e. carpet, tile, wood floors, rugs) may make your opening smaller than anticipated.

Some clearance may be gained by using the leveling procedure under Leveling.

Important: If refrigerator is to be installed into a recess where the top of the refrigerator is completely covered, use dimensions from floor to top of hinge cap to verify proper clearance.

⁄2” space at top

Door and Hinge Removal

Some installations require door removal to get refrigerator to final location.

WARNING

To avoid severe personal injury or death, observe the following:

• Disconnect power to refrigerator before removing doors. Connect power only after replacing doors.

• Green ground wire must be attached to top hinge while performing door removal and replacement.

• Tape decorative panels (select models) securely into place before removing door handles.

CAUTION

To avoid property damage, observe the following:

• Protect vinyl or other flooring with cardboard, rugs or other protective material prior to moving refrigerator.

• Do not adjust refrigerator to be any shorter than

⁄2” tall (minus hinge and cap). Doing so may

68 damage underside components.

1. Unplug power cord from power source.

2. Remove toe grille (see page 4).

• Open both doors 180°, or as wide as possible.

Transporting Your Refrigerator

• NEVER transport refrigerator on its side. If an

upright position is not possible, lay refrigerator on its back. Allow refrigerator to sit upright for approximately 30 minutes before plugging it in to assure oil returns to the compressor. Plugging refrigerator in immediately may cause damage to internal parts.

• Use an appliance dolly when moving refrigerator.

ALWAYS truck refrigerator from its side or back–NEVER from its front.

• Protect outside finish of refrigerator during transport by wrapping cabinet in blankets or inserting padding between the refrigerator and dolly.

• Secure refrigerator to dolly firmly with straps or bungee cords. Thread straps through handles when possible. Do not over-tighten. Over-tightening restraints may dent or damage outside finish.

Note: For refrigerators in operation, shut off water

before removing water line from the door.

To Disconnect the Water Line:

• Push in white collar (A) and hold.

• Pull the door-side tube from the connector (B).

To Reconnect the Water Line:

• Firmly push tube lines on the tube as a guide for full insertion.

• If tube end is damaged, cut off reconnecting.

• If leaking occurs, reconnect the line.

⁄8” into the connector. Use

⁄8” before

Installation

3. Close doors.

4. Remove top hinge covers by removing Phillips screws.

5. Unscrew top hinges.

For water dispensing models only:

• Do not remove screw

connecting green ground wire.

6. For ice and water dispensing models only: Detach main wire connector harness and red wire harness.

• To detach main wire

harness, use a flat blade tool or fingernail to press junction point between two connectors to release.

• To detach red wire harness,

press tab on underside of connector to release.

⁄16” hex head screws from

Leveling

CAUTION

To protect personal property and refrigerator from damage, observe the following:

• Protect vinyl or other flooring with cardboard, rugs, or other protective material.

• Do not use power tools when performing leveling procedure.

To enhance the appearance and maintain performance, the refrigerator should be level.

Notes:

• Complete any required door reversal, panel

installation and/or a water supply connection before leveling.

• Some models only have adjustment screws (A).

Materials Needed:

⁄8” hex head driver

•

• Carpenter’s level

1. Remove toe grille.

7. Remove top hinges along with doors.

8. Remove bottom hinges with a

⁄8” hex head driver.

Replacing the Doors

• To replace the doors, follow the steps in Door and Hinge Removal in reverse order.

Important: If water line tube end is damaged, cut off

⁄8” before reconnecting.

• Grasp firmly and pull outward to unclip.

2. Using hex head driver, turn front adjustment

screws (A) clockwise to raise and counterclockwise to lower the front of the refrigerator.

3. Select models also have rear adjustment screws

(B). Using the hex head driver, turn each of these adjustment screws (B) to raise or lower the rear of the refrigerator.

4. Using the carpenter’s level, make sure front of refrigerator is back of refrigerator and that the refrigerator is level from side to side.

5. If required, correct rocking of refrigerator by turning rear adjustment screw clockwise to raise rocking corner. If doors are uneven, do the following:

⁄4” (6 mm) or 1⁄2 bubble higher than

Cont.

Installation

• Determine which door needs to be raised.

• Turn front roller adjustment screw (A) clockwise to raise front corner of door.

• If one refrigerator door has reached the limit of its adjustment range and doors are still not level, raise or lower the opposite door by turning roller adjustment screw clockwise or counterclockwise.

• Check with level to verify proper door closure.

• If refrigerator is aligned and stable, replace toe grille.

• Align the toe grille mounting clips with the lower cabinet slots.

• Push the toe grille firmly until it snaps into place.

⁄4” tilt to the back for

Connecting the Water Supply

(select models)

WARNING

To reduce the risk of injury or death, follow basic precautions, including the following:

• Read all instructions before installing ice maker.

• Do not attempt installation if instructions are not

understood or if they are beyond personal skill level.

• Observe all local codes and ordinances.

• Do not service ice maker unless specifically

recommended in Use & Care Guide or published user-repair instructions.

• Disconnect power to refrigerator before installing ice maker.

• Water damage due to an improper water connection may cause mold/mildew growth. Clean up spills or leakage immediately!

CAUTION

To avoid property damage or possible injury, follow basic precautions, including the following:

• Consult a plumber to connect

tubing to household plumbing to assure compliance with local codes and ordinances.

• Confirm water pressure to water valve is between 35 and 100 pounds per square inch, 20 pounds per square inch without filter.

• Do not use a self-piercing, or Both reduce water flow and can become clogged over time, and may cause leaks if repair is attempted.

• Tighten nuts by hand to prevent cross threading. Finish tightening nuts with pliers and wrenches. Do not over-tighten.

• Wait two to three hours before placing refrigerator into final position to check and correct any water leaks. Recheck for leaks after 24 hours.

• Verify the copper tubing under the sleeve is smooth and free from defects. Do not reuse an old sleeve.

Materials Needed:

•

⁄4” outer diameter flexible copper tubing

• Shut-off valve (requires a water supply line before valve attachment)

• Adjustable wrench (2)

⁄4” hex nut driver

•

⁄4” O.D. copper

⁄16” saddle valve.

⁄4” hole to be drilled into

Notes:

• Use copper tubing only for installation. Plastic is less durable and can cause damage.

• Add 8’ to tubing length needed to reach water supply for creation of service loop.

1. Create service loop with

copper tubing (minimum 2’ diameter). Avoid kinks in the copper tubing when bending the service loop. Do not use plastic tubing.

2’ diameter

minimum

2. Remove plastic cap from water valve

inlet port.

Installation

3. Place brass nut (A) and sleeve (B)

on copper tube end as illustrated. Reminder: Do not use an old sleeve. The nut and sleeve are provided in the Use and Care packet.

4. Place end of copper tubing into water valve inlet port. Shape tubing slightly. Do not kink – so that tubing feeds straight into inlet port.

5. Slide brass nut over sleeve and screw nut into inlet port.

Place adjustable wrench on nut (1) attached to plastic waterline and maintain position.

Using second adjustable wrench turn the lower nut (2) counterclockwise and fully tighten while holding the upper nut in place.

Plastic Handle with Extensions

Attach Extensions to Handle:

1. Align handle and extension as shown.

B A

1 2

2. Place extension in handle opening.

3. Apply slight pressure to both sides of the extension piece.

4. Slide extension until it stops on inside edge of handle.

To Install:

1. The handles are to be oriented as shown.

2. Align door handle with the door studs.

3. Ensure the large hole in the mounting clip is positioned down on both ends of the handle.

Important: Do not over-tighten. Cross threading may occur.

6. Pull on tubing to confirm connection is secure. Connect tubing to frame with water tubing clamp (C) and turn on water supply. Check for leaks and correct if necessary. Continue to observe the water supply connection for two to three hours prior to moving the refrigerator to its permanent location.

7. Monitor water connection for 24 hours. Correct leaks, if necessary.

Handle Installation

If not installed, the handle is located in the interior of the fresh food section or attached to the back of your refrigerator. Remove and discard handle packaging and tape.

Door

Stud

4. Rotate the handle so that the handle is flat against the door.

5. Grasp the handle firmly and slide down.

Handle design varies from refrigerator to refrigerator. Please reference the appropriate instructions for your model.

Cont.

Installation

To Remove:

1. Grasp the lower part of the handle firmly, slide up, lift and remove from the surface.

Wide-by-Side™ Handles

Materials Needed:

• Gloves to protect hands

• Plastic door handle removal card (or thick plastic card), retain the card

• Flat blade screwdriver

To Install:

1. Align fresh food handle with trim retainer and door clip.

2. Make sure the tabs of the handle clip are below the tabs of the door clip.

3. Rotate the handle so that the handle is flat against the door (see page 6).

4. The tab on the lower part of the handle will align with the hole in the handle cap.

5. Slide handle upward until it clicks.

⁄32”

To Install:

1. Release top door trim by removing Phillips screws from top of fresh food door, retaining screws for later use.

2. Align notches on back of handle with retaining clips on doors. Insert clips into notches and slide handle down until it contacts bottom trim.

3. Replace top door trim and Phillips screws.

4. Repeat instructions 1-3 to install other handle.

Door Clip

WARNING

To avoid possible injury and damage to property, tape decorative panels (select models) securely into place before removing door handles.

To Remove:

1. Release top door trim by removing Phillips screws from top of fresh food door, retaining screws for later use.

2. Grasp handle firmly with both hands. Slide handle upward approximately

⁄4” to release.

6. Snap top of handle into trim retainer clip.

7. Repeat for freezer handle.

To Remove:

1. Protect the area above the handle trim with tape. Insert the tip of a flat blade screwdriver between the handle trim and door panel. Carefully pry the trim away from the door panel.

2. Pull trim free from the trim retainer.

3. Insert door removal card (or between the handle and door panel (approximately

⁄2”).

4. Grasp the handle firmly and pull downward to remove.

5. Repeat for freezer handle.

⁄32” thick plastic card)

Full-Length Aluminum Handles

Materials Needed:

3. Repeat instructions 1-2 to remove other handle.

To Reinstall:

1. Repeat in reverse order.

Metal Handle

Materials Needed:

•

⁄32” Allen wrench

• Gloves to protect hands

Note: Metal handles can scratch doors.

To Remove:

• Loosen set screws in handle using wrench.

• Repeat the procedure on all screws.

To Replace:

• Align handle with the mounting posts.

• Apply upward pressure to the handle and hold.

⁄32” Allen

• Phillips screwdriver

• Fully tighten all set screws to secure handle in place.

Temperature Controls

Dial Temperature Controls

(select models)

The controls are located at the back left of the refrigerator compartment.

Note: The Freezer control turns the cooling system

on. Neither section will cool if freezer control is set to OFF.

Initial Control Settings

After plugging the refrigerator in, set the controls.

• To adjust the controls, turn the control knob to the left or right as desired.

• Set the Freezer control on 4.

• Set the Refrigerator control on 4.

• Let the refrigerator run at least 8 to 12 hours before adding food.

Warm Cabinet Surfaces

At times, the front of the refrigerator cabinet may be warm to the touch. This is a normal occurrence that helps prevent moisture from condensing on the cabinet. This condition will be more noticeable when you first start the refrigerator, during hot weather and after excessive or lengthy door openings.

Adjusting the Controls

• 24 hours after adding food, you may decide that one or both compartments should be colder or warmer. If so, adjust the control(s) as indicated in the Temperature Control Guide table. See page 22 for instructions on checking compartment temperature.

Temperature Control Guide

Refrigerator too warm

Refrigerator too cold

Freezer too warm

Freezer too cold

Turn refrigerator OFF

Turn the Refrigerator control to next higher number.

Turn the Refrigerator control to next lower number.

Turn the Freezer control to next higher number.

Turn the Freezer control to next lower number.

Turn the Freezer control to

OFF.

Note: Turning Freezer control to OFF stops cooling

in both compartments. It does not shut off power to the refrigerator.

Touch Temperature Controls

(select models, style varies by model)

The controls are located at the top front of the refrigerator compartment.

Control

Initial Control Settings

After plugging the refrigerator in, set the controls.

• Pressing the or pads adjusts the controls to the desired setting.

• Set the Freezer control on 4.

• Set the Refrigerator control on 4.

• Let the refrigerator run at least 8 to 12 hours before adding food.

• Except when starting the refrigerator, do not change

either control more than one number at a time.

• Allow 24 hours for temperatures to stabilize.

• Changing either control will have some effect on the temperature of the other compartment.

Warm Cabinet Surfaces

Adjusting the Controls

• 24 hours after adding food, you may decide that one or both compartments should be colder or warmer. If so, adjust the control(s) as indicated in the Temperature Control Guide, page 9.

Cont.

Temperature Controls

• Except when starting the refrigerator, do not change

either control more than one number at a time.

• Allow 24 hours for temperatures to stabilize.

Temperature Control Guide

Refrigerator too warm

Refrigerator too cold

Freezer too warm

Freezer too cold

Turn refrigerator OFF

Set the Refrigerator control to next higher number by pressing the pad.

Set the Refrigerator control to next lower number by pressing the pad.

Set the Freezer control to next higher number by pressing the

pad.

Set the Freezer control to next lower number by pressing the

pad.

Press the Freezer or Refrigerator pad until a dash “–” appears in the display.

Triple Cool Climate Control

(select models)

The control is located at the top front of the fresh food compartment.

Temperature Control Guide

Refrigerator too cold

Refrigerator too warm

Freezer too cold

Freezer too warm

Turn refrigerator OFF

Speed Ice

When activated, Speed Ice reduces the freezer temperature to the optimum setting for 24 hours in order to produce more ice. Important: When the Speed Ice feature is in operation, the and pads for the Freezer control will not operate.

Set the Refrigerator control to next higher number by pressing the pad.

Set the Refrigerator control to next lower number by pressing the pad.

Set the Freezer control to next higher number by pressing the

pad.

Set the Freezer control to next lower number by pressing the

pad.

Press the Freezer pad until “OFF” appears in the display. Press either the Freezer or Refrigerator pad to turn back on.

Control

Initial Temperature Setting

Temperatures are preset at the factory at 38° F (3° C) in the fresh food compartment and 0° F (-17° C) in the freezer compartment.

Adjusting the Control

24 hours after adding food, you may decide that one or both compartments should be colder or warmer. If so, adjust the control as indicated in the Temperature Control Guide.

• The first touch of the or pads shows the current temperature setting.

• The display will show the new setting for approximately three seconds, and then return to the actual temperature currently within that compartment.

• Do not change either control more than one degree at a time. Allow temperature to stabilize for 24 hours before making a new temperature adjustment.

Reset Filter (select models)

When a water filter has been installed in the refrigerator, the yellow Order light will illuminate when 90 % of the volume of water for which the filter is rated has passed through the filter OR 11 months have elapsed since the filter has been installed.

The red Replace light will illuminate when the rated volume of water has passed through the filter OR 12 months have elapsed since the filter was installed. A new filter should be installed immediately when the Replace light is illuminated.

After replacing the filter, press and hold the Reset Filter pad for three seconds. The Order and Replace lights will go off.

Vacation Mode

The Vacation Mode feature causes the freezer to defrost less frequently, conserving energy. The Vacation Mode indicator light will illuminate when the feature is activated. To deactivate, press the Vacation Mode pad again OR open either door. The indicator light will go off.

Temperature Controls

Notes:

• Door openings will not deactivate Vacation Mode for approximately one hour after activation.

• Enable or disable audible alarms.

• Adjust the light level at which the Dispenser Auto Light will illuminate (when this feature is activated on the ice and water dispenser) (select models).

• If vacationing for more than a few days, see the Preparing for Vacation section, page 28.

Temp Alarm

The Temp Alarm system will alert you if the freezer or fresh food temperatures exceed normal operating temperatures due to a power outage or other event. When activated, the Temp Alarm light will illuminate.

If the freezer or fresh food temperatures have exceeded these limits, the display will alternately show the current compartment temperatures and the highest compartment temperatures reached when the power was out. An audible alarm will sound repeatedly.

Press the Temp Alarm pad once to stop the audible alarm. The Temp Alarm light will continue to flash and the temperatures will alternate until the temperatures have stabilized.

To turn off Temp Alarm, press and hold the Temp Alarm pad for three seconds. The indicator light will go off.

Door Alarm

The Door Alarm will alert you when one of the doors has been left open for five continuous minutes. When this happens, an audible alarm will sound every few seconds until the door is closed OR the Door Alarm pad is pressed to deactivate the feature.

Max Cool

When activated, Max Cool causes the fresh food and freezer temperatures to drop to the minimum settings on the control. This cools down the refrigerator and freezer after extended door openings or when loading the refrigerator or freezer with warm food. Important: When the Max Cool feature is in operation, the

and pads for the refrigerator and freezer

controls will not operate.

• Activate the Sabbath Mode. To access the User Preferences menu, press and hold

the Door Alarm pad for three seconds. When in the User Preferences mode, a short title for the feature will appear in the Freezer temperature display and the feature status will appear in the Refrigerator display.

1. Use the Freezer up and down controls to scroll through the features.

2. When the desired feature is displayed, use the Refrigerator up and down controls to change the status.

3. When changes are complete, press the Door Alarm pad for three seconds OR close the Fresh Food door.

Super Cool (CC) (select models)

When Super Cool is ON, an air-mixing fan in the fresh food compartment is activated to improve air flow and temperature control. To save energy, this feature may be deactivated by pressing OFF.

Temperature Display (F_C)

Change the display to show temperatures in degrees Fahrenheit or degrees Celsius.

Alarm (AL)

When the Alarm mode is OFF, all audible alarms will be disabled until the feature is turned ON.

Auto Light Level Selection (LL) (select models)

This setting adjusts the light level at which the dispenser light will illuminate when the sensor detects that the light levels in the room are low. Setting 1 is the darkest light level setting, setting 9 is the lightest light level setting. Important: The Auto Light (select models) must be activated on the ice and water dispenser control to take advantage of this option.

Sabbath Mode (SAB)

When the Sabbath Mode is ON, all control lights and the night light will be disabled until the feature is turned OFF. This feature does not disable the interior lights. Press any pad to restore the control lights.

To activate, press the Max Cool pad. Max Cool will deactivate automatically after 12 hours, OR press the

Max Cool pad to deactivate the feature.

User Preferences

Access the User Preferences menu to:

• Activate or turn off Super Cool (select models).

• Change the temperature display from °F to °C .

Warm Cabinet Surfaces

At times, the front of the refrigerator cabinet may be warm to the touch. This is a normal occurrence that helps prevent moisture from condensing on the cabinet. This condition will be more noticeable when the refrigerator is first started, during hot weather and after excessive or lengthy door openings.

Fresh Food Features

Shelves

CAUTION

To avoid personal injury or property damage, observe the following:

• Never attempt to adjust a shelf that is loaded with

food, except in the case of the Elevator

• Confirm shelf is secure before placing items on shelf.

• Handle tempered glass shelves carefully. Shelves may break suddenly if nicked, scratched, or exposed to sudden temperature change.

Your refrigerator has either Spill-Catcher™ or nonsealed shelves. Spill-Catcher™ shelves have a spill retainer edge which allows for easier clean up and some are equipped with the Easy-Glide slide out feature. To slide out (select models), grasp the front of the shelf and pull forward. Push in the shelf to return to the original position.

To Remove a Shelf:

• Slightly tilt up the front and lift up the rear of the shelf, then pull the shelf straight out.

To Lock the Shelf Into Another Position:

• Tilt up the front edge of the shelf.

• Insert the hooks into the desired frame openings and let the shelf settle into place.

• Be sure the shelf is securely locked at the rear.

The Crisper Top serves as the lower fresh food shelf.

To Remove the Crisper Top:

• Remove drawers as indicated (see page 13).

• Place hand under the frame to push up the glass. Lift glass out.

To Install:

Shelf.

To Slide Out Elevator™ Shelf:

• Grasp the front of the shelf and pull forward.

• Push the shelf in to return to original position.

To Adjust the Elevator™ Shelf:

• Pull out the knob on the crank handle.

• Rotate the crank clockwise to raise the shelf, and counterclockwise to lower the height of the shelf.

To Remove Elevator™ Shelf:

• Completely unload the shelf and pull the shelf forward.

• Pull until the shelf stops.

• Press up on the tabs located underneath its outside edges and continue pulling forward until the shelf is clear of the frame.

To Replace Elevator™ Shelf:

• Align the shelf to the frame and push it all the way back. It is not necessary to press up on the tabs for reinstallation.

In ordinary use, the Elevator™ Shelf frame assembly does NOT require removal. Though unlikely, and not recommended, the correct removal procedure is as follows:

To Remove Frame Assembly:

• Unload the shelf completely.

• Slide the shelf forward about 2” and manually move

the two rear latches toward the shelf center.

• While supporting the entire shelf and frame from

underneath, lift slightly and rotate the assembly approximately 30° to allow the rear mechanism to clear the vertical rear side rails.

• The entire assembly can then be moved forward

and clear of the refrigerator compartment.

To Reinstall Frame Assembly:

• Reverse the removal procedure. Be sure the shelf

is in a level position. When the sliding shelf is pushed to the rear, it will reposition the rear latches to their correct operating position.

• Repeat above instructions in reverse order.

Elevator™ Shelf (select models)

The Elevator™ Shelf is equipped with a spill-retaining edge and the Easy-Glide™ slide-out feature. It can be adjusted up or down without unloading.

(style may vary)

Fresh Food Features

Refrigerator Pak Can Organizer (select models)

The Refrigerator Pak Can Organizer conveniently dispenses up to a 12-pack of individual beverage cans. To load beverages into the organizer:

• Open a 12-pack sleeve of beverages.

• Slide can organizer over the cutout portion of beverage sleeve.

• Place container and sleeve in an upright position in a door bucket located in the fresh food door compartment.

The dispenser sits in the door bucket and can be moved to accommodate a variety of storage needs.

Adjustable Deep Tilt-Out Door Buckets

(select models)

The Adjustable Deep Tilt-Out Door Bucket provides easy access to food items stored in the door.

To Remove Bucket:

• Tilt bucket out.

• Pull straight out of the bracket.

To Install Bucket:

• Tilt the front of the bucket down slightly.

• Slide into bracket and tip upright.

To Move Bucket Frame to Another Location:

• Remove bucket.

• Lift bracket up and pull straight out.

• Place the bracket in a new location.

Door Buckets

Dairy Center

The Dairy Center provides convenient door storage for spreadable items such as butter and margarine. On select models, this compartment can be moved to several different locations to accommodate storage needs.

To Remove:

• Slide dairy center up and pull out.

To Install:

• Slide assembly in and down so that the hooks are firmly seated on the door liner.

To Remove Dairy Door:

• Press in sides of dairy door and pull out.

To Install Dairy Door:

• Slide sides of dairy door inside dairy center until hinge points snap into place.

Door Buckets can be moved to meet individual storage needs.

To Remove:

• Lift bucket up and pull straight out.

To Install:

• Place bucket in desired door liner retainer, push down until bucket stops.

Storage Drawers

Humidity-Controlled Crisper Drawers

The Crisper Drawers provide a higher humidity environment for fresh fruit and vegetable storage.

Controls

The crisper controls regulate the amount of humidity in the crisper drawer. Slide control toward the FRUIT setting for produce with outer skins. Slide control toward the VEGETABLES setting for leafy produce.

Cont.

Fresh Food Features

To Remove:

• Pull drawer out to full extension. (On select models, press tabs toward oneself to release drawer from rails.) Tilt up front of drawer and pull straight out.

To Install:

• Insert drawer into frame rails and push back into place.

Note: For best results, keep the crispers tightly

closed.

Automatic Humidity Control

Some crispers are equipped with an Automatic Humidity Control system, eliminating the need for manual humidity slide controls on the drawer. A fabric-like material* covers small air vents in the shelf insert above the crispers.

Temperature-Controlled Drawer (select models)

This drawer can be used for storage of miscellaneous items.

The drawer features a control that regulates the air temperature in the drawer. Set the control to Cheese to provide normal refrigerator temperature. Use the Meats setting for meats.

Can Rack™ (select models)

The Can Rack™ slides out from underneath the Spillsaver™ stationary shelf. The Can Rack™ holds up to twelve 12-ounce beverage cans.

To Remove:

• Empty contents of Can Rack™. Pull forward to full extension and lift front to release from shelf rail assembly. Pull straight out to remove.

To Install:

This material controls the flow of moisture out of the crisper. If a food spill should occur on the air vent or fabric-like material, wipe with a clean, damp cloth.

* The Maytag Automatic Humidity

Control system features a unique, patented material called Shape Memory Polymer (SMP) that when laminated to fabric, becomes DIAPLEX. DIAPLEX is manufactured by Mitsubishi.

To Remove:

• Pull drawer out to full extension. Tilt up front of drawer and pull straight out.

To Install:

• Insert drawer into frame rails and push back into place.

Accessories

Grip Pads (select models)

The Grip Pads prevent objects from sliding in the door buckets. Grip Pads are removable and are top-rack dishwasher safe for easy cleaning.

Covered Storage Bucket

(select models)

The Storage Bucket has a lid and removable egg tray. When tray is removed, bucket will accept items such as a standard egg carton, ice, etc.

Note: For best results, keep the crispers tightly

closed.

Fresh Food Features

Tall Bottle Retainer/Snugger

(select models)

The Tall Bottle Retainer prevents tall bottles from tipping forward. The Retainer can be placed above any removable door bucket.

The Snugger attached to the Tall Bottle Retainer keeps bottles and other containers in place when the door is opened or closed. Adjust the Snugger by sliding from side to side.

Egg Tray With Handle

(style may vary/select models)

The Egg Tray with Handle holds a “dozen-plus” eggs. It can be removed to carry to a work area or to be washed.

Wine Rack (select models)

The Wine Rack provides a place for horizontally storing wine. The rack can also hold an egg carton.

Position the rack to rest on the left hand side of a refrigerator shelf (this rack cannot be positioned on an Elevator Shelf™).

Freezer Features

Shelves and Baskets

Fixed Freezer Shelf

To Remove Clip-Mounted Shelves:

• Lift shelf from wall mounting clips and pull left side of shelf out of wall mounting holes.

To Install Clip-Mounted Shelves:

• Place left side of shelf in mounting holes and press down into wall mounting clips.

Shelves

Shelves can be removed to meet individual storage needs.

To Remove Shelf:

• Snap right side of shelf up from cabinet railing and slide to right.

To Install Shelf:

To Install:

• Slide bin into railing below ice maker until bin locks into place. Drop ice maker arm to activate ice maker.

Important: Ice bin must be locked in place for proper ice dispensing. Turn auger driver behind bin counterclockwise (as shown) to properly align ice bin with auger driver.

Door Storage

Adjustable Door Buckets

Door Buckets can be moved to meet individual storage needs.

To Remove:

• Place shelf in left side cabinet railing snapping shelf into right side cabinet railing.

Baskets and Drawers

Baskets and drawers (style may vary) slide out for easy access to items in back.

To Remove:

• Pull out to its full extension. Lift up front of basket and remove.

To Install:

• Slide basket or drawer into cabinet railing. Lift up front of basket or drawer, and slide to the back of refrigerator.

Ice Storage Bin

The Ice Storage Bin is located below the automatic ice maker.

To Remove:

• Raise ice maker arm to deactivate ice maker. Lift front of bin and pull out to its full extension. Lift up front of bin and remove.

• Lift the door bucket up until it clears the retainers on the door liner, then pull the door bucket straight out.

To Install:

• Slide bucket in above desired door liner retainer and push down until bucket stops.

Fixed Door Bucket (select models)

The Fixed Door Bucket is located in the upper section of the freezer door.

Important: Fixed door bucket is NOT adjustable. If bucket is removed, freezer light will not deactivate when door is closed.

Drop-Down Freezer Door Baskets

(select models)

These baskets provide convenient storage space for frozen food items that tend to shift, such as bagged vegetables.

Ice and Water

Automatic Ice Maker

(non-dispenser models)

Note: Energy rating guides that are posted on the

refrigerator at the time of purchase do not include optional ice maker energy usage.

Some models are automatic ice maker ready. The number of the appropriate ice maker kit is IC10S. The kit contains installation instructions and water connection instructions.

Other models have a factory installed ice maker. Connect the ice maker to the water supply as instructed on pages 5-6. Proper water flow and a

level refrigerator are essential for optimal ice maker performance.

Operating Instructions

• Confirm ice bin is in place and ice maker arm is down.

cubes will rattle as they fall into an empty storage pan and the water valve may click or “buzz” occasionally.

• If the ice is not used frequently, the ice cubes will become cloudy, shrink, stick together and taste stale. Empty the ice storage bin periodically and wash it in lukewarm water. Be sure to dry the bin thoroughly before replacing it.

• Beverages and foods should not be placed in the ice storage bin for quick chilling. These items can block the sensor arm, causing the ice maker to malfunction.

• Turn OFF (arm up) the ice maker when the water supply is to be shut off for several hours.

To Remove the Ice Bin:

• Pull it forward, away from the ice maker. To avoid the ice maker dumping ice while the bin is removed, turn the ice maker OFF by raising the sensor arm.

To Install the Ice Bin:

• After freezer section reaches between 0° to 2° F (-18° to -17° C), ice maker fills with water and begins operating. You will have a complete harvest of ice approximately every three hours.

• Allow approximately 3-6 hours after installation to receive first harvest of ice.

• Discard ice created within first 12 hours of operation to verify system is flushed of impurities.

• Stop ice production by raising ice maker arm until click is heard.

• Ice maker will remain in the OFF position until arm is pushed down.

• The first one or two batches will probably contain undersized and irregular cubes because of air in the supply line.

• When the ice cubes are ejected it is normal for several cubes to be joined together at the ends. They can easily be broken apart. The ice maker will continue to make ice until the supply of ice cubes raises the sensor arm, shutting the ice maker off.

• Certain sounds may accompany the various cycles of the ice maker. The motor may have a slight hum, the

• Reverse the above procedure. Turn the ice maker ON

by lowering the sensor arm.

WARNING

To avoid personal injury or property damage, observe the following:

• Do not place fingers or hands on the automatic

ice making mechanism while the refrigerator is plugged in. This will help protect you from possible injury. It will also prevent interference with moving parts of the ejector mechanism and the heating element that releases the cubes.

• Under certain rare circumstances, ice cubes may be discolored, usually appearing with a greenbluish hue. The cause of this unusual discoloration can be a combination of factors such as certain characteristics of local waters, household plumbing and the accumulation of copper salts in an inactive water supply line which feeds the ice maker. Continued consumption of such discolored ice cubes may be injurious to health. If such discoloration is observed, discard the ice cubes and contact your dealer to purchase and install a water line filter.

• Water damage due to improper water connection may cause mold/mildew growth.

• Clean up water and ice spills to avoid personal injury and to prevent mold/mildew growth.

Ice and Water

Dispenser Features

(select models)

Main

Dispenser

Pad

Dispenser Light (select models)

A light activates within the dispenser area at full power when dispensing ice or water with the main dispenser pad.

Dispenser Pad

The Dispenser Pad is located on the back wall of the dispensing area. When the dispenser pad is pressed, the selection chosen on the dispenser control panel will dispense.

Removable

Tray

Note: During initial use of water dispenser, there

will be a one- to two-minute delay while water tank fills before water dispenses. Discard first 10-14 glasses of water after initially connecting refrigerator to household water supply and after extended periods of nonuse.

To Use Dispenser Pad:

• Choose water selection from dispenser control panel.

• Press a sturdy, wide-mouthed container against dispenser pad. When dispensing crushed ice, hold container as close to chute as possible to reduce spraying.

• Release pressure on dispenser pad to stop water dispensing. A small amount of water may continue to dispense and collect in dispenser tray. Large spills should be wiped dry.

Dispenser Control (select models)

(control features vary by model) Ice Dispenser Operation

To Dispense Ice and Water:

Removable Tray

The Removable Tray at the bottom of the dispenser area is designed to collect small spills and may be easily removed for cleaning and emptying purposes.

Important: Removable tray does not drain. Do not allow tray to overflow. If it does, remove tray and wipe up overflow.

Water Dispenser Operation

CAUTION

To avoid personal injury or property damage, observe the following:

• Do not put fingers, hands or any foreign object

into dispenser opening.

• Do not use sharp objects to break ice.

• Do not dispense ice directly into thin glass, fine

china or delicate crystal.

• Select Water, Crush or Cube ice mode by pushing button on dispenser control panel. A green light above button indicates mode selection.

• Press container against dispenser pad. When dispensing crushed ice, hold container as close to chute as possible to reduce spraying.

Notes:

• Mode may not be changed while ice dispenser is in operation.

• If dispenser (select models) is active for more than five minutes, an automatic lock out sensor will shut down power to dispenser area. See Dispenser Lock for unlocking information.

Ice and Water

Dispenser Lock (select models)

The Dispenser Lock prevents ice or water from being dispensed.

To Lock Dispenser:

• Press and hold the Lock button for three seconds. A

green indicator light above button will illuminate when the dispenser is locked.

To Unlock Dispenser:

• Hold the Lock button for three seconds. The green

indicator light above button will go out.

Water Filter Status Indicator Light (select models)

The Water Filter Status Indicator Light serves as a reminder to replace the water filter. A green light indicates that the filter is in good condition. A red light indicates the filter should be changed. Once light turns red, it will remain red until function is reset.

To Reset Indicator:

• Press and hold both the Lock and Water

buttons simultaneously for four seconds. The green filter status indicator light will flash three times when the function has successfully reset.

Auto Light (select models)

The Auto Light function activates the dispenser light at half-power when the Light Sensor detects that the light levels in room are low.

To Activate Auto Light:

• Press Auto Light button. A green indicator light

above button illuminates when the sensor is active.

To Deactivate Auto Light:

Light (select models)

Press the Light pad once to select the Auto Light function which activates the dispenser light at half-power when the light sensor detects that the light levels in room are low. The Auto indicator light will illuminate.

To Activate Light:

• Press the Light pad again to turn the dispenser light

on continuously. The On indicator light will illuminate.

To Deactivate Light:

• Press the Light pad a third time to turn the dispenser

light off.

Sabbath Mode (select models)

When activated, the Sabbath Mode deactivates the control lights while leaving the control operational.

To Activate Sabbath Mode:

• Press and hold the Lock and Auto Light

buttons simultaneously for three to four seconds. After three to four seconds, the dispenser lights will turn off.

To Deactivate Sabbath Mode:

• Press and hold both the Lock and Auto Light

buttons simultaneously for three to four seconds. After three to four seconds, the dispenser lights will activate.

Notes:

• Dispenser light will not activate during dispensing while in this mode.

• If the power fails, the control will remain in Sabbath Mode when power returns.

• Press Auto Light button. The green indicator light

will go out.

Note: The dispenser light will operate when Auto

Light is ON or OFF.

FrontFill™ Button (select models)

The FrontFill™ button works independently of the dispenser controls, providing an up-front alternative to the dispenser pad for dispensing water. This feature is convenient for filling large items that will not fit into the dispenser area (i.e. sport bottles, pitchers, large pans, coffee pots).

This feature allows added convenience of dispensing ice and water simultaneously. To use, choose your preferred ice mode from dispenser control panel. Press container against dispenser pad while pressing the FrontFill™ button.

Water Filter

Water Filter Removal and Installation (select models)

WARNING

To avoid serious illness or death, do not use refrigerator where water is unsafe or of unknown quality without adequate disinfection before or after use of filter.

CAUTION

After installing a new water filter, always dispense water for two minutes before removing the filter for any reason. Air trapped in system may cause water and cartridge to eject. Use caution when removing.

• The bypass cap does not filter water. Be sure to have replacement cartridge available when filter change is required.

• If water filtration system has been allowed to freeze, replace filter cartridge.

• If system has not been used for several months, or water has an unpleasant taste or odor, flush system by dispensing water for two to three minutes. If unpleasant taste or odor persists, change filter cartridge.

Replacing Water Filter

Important: Air trapped in system may cause water and cartridge to eject. Use caution when removing.

1. Turn filter counterclockwise until it releases from filter head.

2. Drain water from filter into sink, and dispose in normal household trash.

3. Wipe up excess water in filter cover and continue with Initial Installation, steps 2 and 4.

The filter should be changed at least every 12 months. Important: Condition of water and amount used

determines life span of water filter cartridge. If water use is high, or if water is of poor quality, replacement may need to take place more often.

To purchase a replacement water filter cartridge, contact your dealer or call 1-877-232-6771 USA or 1-800-688-8408 Canada.

The dispenser feature may be used without a water filter cartridge. If you choose this option, replace filter with blue bypass cap.

Initial Installation

The water filter is located in the upper right-hand corner of the fresh food compartment.

1. Remove blue bypass cap and retain for later use.

2. Remove sealing label from end of filter and insert into filter head.

3. Rotate gently clockwise until filter stops. Snap filter cover closed.

4. Reduce water spurts by flushing air from system. Run water continuously for two minutes through dispenser until water runs steady. During initial use, allow about a one- to two-minute delay in water dispersal to allow internal water tank to fill.

• Additional flushing may be required in some

households where water is of poor quality.

Water Filter

System Specification and Performance Data Sheet Refrigerator Water Filter Cartridge Model UKF8001AXX

Specifications

Service Flow Rate (Maximum).............................................0.78 GPM (2.9 L/min)

Rated Service Life UKF8001AXX-750 (Maximum)......750 gallons/2838 liters

Maximum Operating Temperature .....................................100° F / 38° C

Minimum Pressure Requirement........................................35 psi / 241 kPA

Minimum Operating Temperature ......................................33° F/ 1° C

Maximum Operating Pressure.............................................100 psi /689 kPA

1000 Apollo Road

Eagan, Minnesota 55121-2240

651.450.4913

EPA EST #35917-MN-1

Performance Data

Standard No. 42: Aesthetic Effects

USEPA

Parameter

Chlorine T&O Particulate**

Parameter

Turbidity Cysts Asbestos Lead at pH 6.5 Lead at pH 8.5 Mercury at pH 6.5 Mercury at pH 8.5 Atrazine Benzene Carbofuran p-Dichlorobenzene Lindane Toxaphene

* Tested using a flow rate of 0.78 gpm; pressure of 60 psig; pH of 7.5 + 0.5; temp. of

68° + 5° F (20° + 3° C)

** Measurement in Particles/ml. Particles used were 0.5 - 1 microns

*** NTU - Nephelometric Turbidity Units

MCL

— — —

USEPA

MCL

1 NTU**

99.5% Reduction 99% Reduction

0.015 mg/L

0.002 mg/L

0.003 mg/L

0.005 mg/L

0.04 mg/L

0.075 mg/L

0.0002 mg/L

0.003 mg/L

Standard No. 53: Health Effects

107108fibers/L; fibers >10 micrometers in length

Influent

Challenge Concentration

2.0 mg/L ± 10% —

at least 10,000 particles/ ml

Influent

Challenge Concentration

11 ± 1 NTU***

Minimum 50,000/L

0.15 mg/L + 10%

0.15 mg/L + 10% .006 mg/L ± 10% .006 mg/L ± 10%

0.009 mg/L + 10%

0.015 mg/L ± 10%

0.08 mg/L ± 10% .225 mg/L ± 10%

0.002 mg/L + 10%

0.015 ± 10%

Influent

Average

1.88 mg/L —

5,700,000 #/ml

Influent

Average

10.7 NTU

166,500 #/L

155 MF/L

0.153 mg/L

0.150 mg/L

0.006 mg/L

0.009 mg/L

0.014 mg/L

0.081 mg/L

0.208 mg/L

0.002 mg/L

0.015 mg/L

100834/B

Effluent % Reduction

Average

<0.05136364 mg /L

—

30,583 # /ml

Average

0.31 NTU <1 #/L

<1 MF/L <.001 mg/L <.001 mg/L

0.0003 mg/L

0.0008 mg/L

<0.002 mg/L

0.0006 mg/L

<0.001 mg/L

<0.0005 mg/L

0.000 mg/L

<0.001 mg/L

Tested and certified by NSF International against ANSI/NSF Standards 42 & 53 in models UKF8001AXX-750 for the reduction of:

Standard No. 42: Aesthetic Effects

Taste and Odor Reduction Chlorine Taste & Odor Mechanical Filtration Unit Particulate Reduction Class 1

Maximum

0.06 mg/L —

69,000 #/ml

Effluent % Reduction

Maximum

.049 NTU

<1 #/L

<1 MF/L <.001 mg/L <.001 mg/L

0.0005 mg/L

0.0015 mg/L

0.002 mg/L

0.0011 mg/L

<0.001 mg/L <0.0005 mg/L <0.0001 mg/L

<0.001 mg/L

Average

>97.26%

—

99.52%

Average

97.09% >99.99% >99.99%

>99.35% >99.33%

95.70%

86.22%

76.99%

95.71%

98.74%

99.76%

98.72%

92.97%

Standard No. 53: Health Effects

Chemical Reduction Unit Lead, Atrazine, Lindane, Benzene, Carbofuran, p-Dichlorobenzene, Mercury & Toxaphene Reduction Mechanical Filtration Unit Cyst, Turbidity and Asbestos Reduction

Minimum

96.84%

98.94%

Minimum

95.20% >99.99% >99.99% >99.29% >99.29%

90.91%

75.93%

75.31%

92.14%

98.46%

99.74%

96.50%

91.67%

—

Min. Required

Reduction

50%

—

85%

Min. Required

Reduction

0.5 NTU

>99.95%

99%

0.10 mg/L

0.002 mg/L

0.003 mg/L

0.005 mg/L

0.04 mg/L

0.075 mg/L

0.0002 mg/L

0.003 mg/L

General Use Conditions

Read this Performance Data Sheet and compare the capabilities of this unit with your actual water treatment needs.

DO NOT use this product where water is microbiologically unsafe or of unknown quality without adequate disinfection before or after the system. System certified for cyst reduction may be used on disinfected water that may contain filterable cysts.

USE ONLY WITH COLD WATER SUPPLY. CHECK FOR COMPLIANCE WITH THE STATE AND LOCAL LAWS AND REGULATIONS.

The PuriClean®II retractable water filtration system uses a UKF8001AXX replacement cartridge. Timely replacement of filter cartridge is essential for performance satisfaction from this filtration system. Please refer to the applicable section of your Use & Care Guide for general operation, maintenance requirements and troubleshooting. Suggested retail price of replacement water filter is $39.99.

This system has been tested according to ANSI/NSF 42 and 53 for reduction of the substance listed above. The concentration of the indicated substances in water entering the system was reduced to a concentration less than or equal to the permissible limit for water leaving the system, as specified in ANSI/NSF 42 and 53.

Water Filter

State of California

Department of Health Services

Water Treatment Device

Certificate Number

03 - 1583

Date Issued: September 16, 2003

Date Revised: April 22, 2004

Trademark /Model Designation Replacement Elements

UKF8001AXX750 UKF8001AXX 469006-750 46 9006 67003523-750 67003523

Manufacturer: PentaPure Inc.

The water treatment device(s) listed on this certificate have met the testing requirements pursuant to Section 116830 of the Health and Safety Code for the following health related contaminants:

Microbiolog

Cysts Asbestos Turbidity Lead

Organic Contaminants

Atrazine Lindane Benzene Carbofuran p-dichlorobenzene Toxaphene

ical Contaminants and Turbidity

Inorganic/Radiological Contaminants

Mercury

Rated Service Capacity: 750 gal. Rated Service Flow: 0.78 gpm

Conditions of Certification:

Do not use where water is microbiologically unsafe or with water of unknown quality, except that systems certified for cyst

reduction may be used on disinfected waters that may contain filterable cysts.

Food Storage Tips

Fresh Food Storage

• The fresh food compartment of a refrigerator should be kept between 34°-40° F (1°-4° C) with an optimum temperature of 37° F (3° C). To check the temperature, place an appliance thermometer in a glass of water and place in the center of the refrigerator. Check after 24 hours. If the temperature is above 40° F (4° C) adjust the controls as explained on pages 8 and 9.

• Avoid overcrowding the refrigerator shelves. This reduces the circulation of air around the food and results in uneven cooling.

Fruits and Vegetables

• Storage in the crisper drawers traps humidity to help preserve the fruit and vegetable quality for longer time periods (see pages 12 and 13).

• Sort fruits and vegetables before storage and use bruised or soft items first. Discard those showing signs of decay.

• Always wrap odorous foods such as onions and cabbage so the odor does not transfer to other foods.

Frozen Food Storage

• The freezer compartment of a refrigerator should be kept at approximately 0° F (-17° C). To check the temperature, place an appliance thermometer between the frozen packages and check after 24 hours. If the temperature is above 0° F (-17° C), adjust the control as described on pages 8 and 9.

• A freezer operates more efficiently when it is at least full.

Packaging Foods for Freezing

• To minimize dehydration and quality deterioration use aluminum foil, freezer wrap, freezer bags or airtight containers. Force as much air out of the packages as possible and be sure they are tightly sealed. Trapped air can cause the food to dry out, change color and develop an off-flavor (freezer burn).

• Overwrap fresh meats and poultry with suitable freezer wrap prior to freezing.

• Do not refreeze meat that has completely thawed.

Loading the Freezer

⁄3

• While vegetables need a certain amount of humidity to remain fresh, too much humidity can shorten storage times (especially leafy vegetables). Drain vegetables well before storing.

• Wait to wash fresh produce until right before use.

Meat and Cheese

• Raw meat and poultry should be wrapped securely so leakage and contamination of other foods or surfaces does not occur.

• Occasionally mold will develop on the surface of hard cheeses (Swiss, Cheddar, Parmesan). Cut off at least an inch around and below the moldy area. Keep your knife or instrument out of the mold itself. Do not try to save individual cheese slices, soft cheese, cottage cheese, cream, sour cream or yogurt when mold appears.

Dairy Food

• Most dairy foods such as milk, yogurt, sour cream and cottage cheese have freshness dates on their cartons for appropriate length of storage. Store these foods in the original carton and refrigerate immediately after purchasing and after each use.

• Avoid adding too much warm food to the freezer at one time. This overloads the freezer, slows the rate of freezing and can raise the temperature of frozen foods.

• Leave space between the packages so cold air can circulate freely, allowing food to freeze as quickly as possible.

• Avoid storing hard-to-freeze foods such as ice cream and orange juice on the freezer door shelves. These foods are best stored in the freezer interior where the temperature varies less with door openings.

Refer to the Food Storage Chart on pages 23 and 24 for approximate storage times.

Food Storage Tips

Food Storage Chart

Storage times are approximate and may vary depending on type of packaging, storage temperature, and the quality of the food when purchased.

FOODS

DAIRY PRODUCTS

Butter Milk and cream

Cream cheese, cheese spread and cheese food

Cottage cheese

Sour cream

Hard cheese (Swiss, Cheddar and Parmesan)

EGGS

Eggs in the shell

REFRIGERATOR

1 month 1 week

1 to 2 weeks

3 to 5 days

10 days

1 to 2 months

3 weeks

FREEZER

6 to 9 months Not recommended

Not recommended

4 to 6 months May become crumbly

Not recommended

STORAGE TIPS

Wrap tightly or cover. Check carton date. Close tightly.

Do not return unused portions to original container. Do not freeze cream unless whipped.

Wrap tightly.

Store in original carton. Check carton date.

Wrap tightly. Cut off any mold.

Refrigerate small ends down.

Leftover yolks or whites

FRUITS

Apples

Bananas

Pears, plums, avocados

Berries, cherries, apricots

Grapes

Citrus fruits

2 to 4 days

1 month

2 to 4 days

3 to 4 days

2 to 3 days

3 to 5 days

1 to 2 weeks

9 to 12 months

8 months (cooked)

6 months (whole/peeled)

Not recommended

6 months

1 month (whole)

Not recommended

For each cup of yolks to be frozen, add 1 tsp. sugar for use in sweet, or 1 tsp. salt for non-sweet dishes.

May also store unripe or hard apples at 60° to 70° F (16° to 21° C).

Ripen at room temperature before refrigerating. Note: Bananas will darken when refrigerated.

Ripen at room temperature before refrigerating. Note: Avocados will darken when refrigerated.

Ripen at room temperature before refrigerating.

May also store at 60° to 70° F (16° to 21° C). If refrigerated, store uncovered.

Pineapples, cut

2 to 3 days

6 to 12 months

Will not ripen after purchase. Use quickly.

Food Storage Tips

FOODS STORAGE TIPS

VEGETABLES

Asparagus

Brussels sprouts, broccoli, cauliflower, green peas, lima beans, onions, peppers

Cabbage, celery

Carrots, parsnips, beets and turnips

Lettuce

POULTRY and FISH

Chicken and turkey, whole Chicken and turkey, pieces Fish

MEATS

REFRIGERATOR

1 to 2 days

3 to 5 days

1 to 2 weeks

7 to 10 days

1 to 2 days 1 to 2 days 1 to 2 days

FREEZER

8 to 10 months

Not recommended

8 to 10 months

Not recommended

12 months 9 months 2 to 6 months

Do not wash before refrigerating. Store in crisper.

Wrap odorous foods. Leave peas in pods.

Wrap odorous foods and refrigerate in crisper.

Remove tops. Wrap odorous foods and refrigerate in the crisper.

Keep in original packaging for refrigeration. Place in the meat and cheese drawer. When freezing longer than two weeks, overwrap with freezer wrap.

Bacon Beef or lamb, ground

Beef or lamb, roast and steak

Ham, fully cooked, whole

half slices

Luncheon meat

Pork, roast Pork, chops Sausage, ground Sausage, smoked Veal

7 days 1 to 2 days

3 to 5 days

7 days 5 days 3 days 3 to 5 days

3 to 5 days 3 to 5 days 1 to 2 days 7 days 3 to 5 days

1 month 3 to 4 months

6 to 9 months

1 to 2 months 1 to 2 months 1 to 2 months 1 to 2 months

4 to 6 months 4 months 1 to 2 months 1 to 2 months 4 to 6 months

Fresh meats can be kept in original packaging for refrigeration.

Place in the meat and cheese drawer. When freezing longer than two weeks, overwrap with freezer wrap.

Unopened, vacuum-packed luncheon meat may be kept up to two weeks in the meat and cheese drawer.

Frankfurters

Sources: United States Department of Agriculture; Food Marketing Institute; Cooperative Extension Service, Iowa State University

7 days

1 month

Processed meats should be tightly wrapped and stored in the meat and cheese drawer.

Care and Cleaning

WARNING

To avoid electrical shock which can cause severe personal injury or death, disconnect power to refrigerator before cleaning. After cleaning, reconnect power.

Refrigerator Cleaning Chart

PART

Smooth or Textured Painted Doors and Exterior (select models)

Damage to finish due to improper use of cleaning products or non-recommended products is not covered under this product’s warranty.

Abrasive or harsh cleaners Ammonia Chlorine bleach Concentrated detergents or solvents Metal or plastic-textured scouring pads

DO NOT USE

CAUTION

To avoid personal injury or property damage, observe the following:

• Read and follow manufacturer’s directions for all cleaning products.

• Do not place buckets, shelves or accessories in dishwasher. Cracking or warping of accessories may result.

Use 4 tablespoons of baking soda dissolved in 1 quart (1 liter) warm, soapy water. Rinse surfaces with clean, warm water and dry immediately to avoid water spots.

Cabinet Interior

Stainless Steel Doors and Exterior (select models) Important:

Damage to stainless steel finish due to improper use of cleaning products or non-recommended products is not covered under this product’s warranty.

Door Gaskets

Condenser Coil

Remove base grille to access.

Condenser Fan Outlet Grille

See back of refrigerator.

Accessories

Shelves, buckets, drawers, etc.

Abrasive or harsh cleaners Ammonia Chlorine bleach Concentrated detergents or solvents Metal or plastic-textured scouring pads Vinegar-based products Citrus-based cleaners

Abrasive or harsh cleaners Metal or plastic-textured scouring pads

Anything other than a vacuum cleaner

A dishwasher

Use warm, soapy water and a soft, clean cloth or sponge. Rinse surfaces with clean, warm water and dry immediately to avoid water spots. To polish and help prevent fingerprints, follow with Stainless Steel Magic Spray (part no. 20000008*).

Use warm, soapy water and a soft, clean cloth or sponge.

Use a vacuum cleaner hose nozzle.

Use a vacuum cleaner hose nozzle with brush attachment.

Follow removal and installation instructions from appropriate feature section.

Allow items to adjust to room temperature.

Dilute mild detergent and use a soft, clean cloth or sponge for cleaning. Use a plastic bristle brush to get into crevices. Rinse surfaces with clean, warm water. Dry glass and clear items immediately to avoid spots.

* To order, call 1-877-232-6771 USA or 1-800-688-8408 Canada.

Care and Cleaning

Removing Odors From Refrigerator

WARNING

To avoid electrical shock which can cause severe personal injury or death, disconnect power to refrigerator before cleaning. After cleaning, reconnect power.

1. Remove all food and turn the refrigerator OFF.

2. Disconnect power to the refrigerator.

3. Clean the walls, floor, ceiling of cabinet interior, drawers, shelves and gaskets according to the instructions (see page 25).

4. Dilute mild detergent and brush solution into crevices using a plastic bristle brush. Let stand for five minutes. Rinse surfaces with warm water. Dry surfaces with a soft, clean cloth.

5. Wash and dry all bottles, containers and jars. Discard spoiled or expired items.

6. Wrap or store odor-causing foods in tightly sealed containers to prevent reoccurring odors.

7. Reconnect power to refrigerator and return food to refrigerator.

Energy Saving Tips

• Avoid overcrowding refrigerator shelves. This reduces air circulation around food and causes refrigerator to run longer.

• Avoid adding too much warm food to refrigerator at one time. This overloads compartments and slows rate of cooling.

• Do not use aluminum foil, wax paper, or paper toweling as shelf liners. This decreases air flow and causes refrigerator to run less efficiently.

• A freezer that is two-thirds full runs most efficiently.

• Locate refrigerator in coolest part of room. Avoid areas of direct sunlight, or near heating ducts, registers or other heat producing appliances. If this is not possible, isolate exterior by using a section of cabinet or an added layer of insulation.

• Clean door gaskets every three months according to cleaning instructions. This will assure that door seals properly and refrigerator runs efficiently.

• Take time to organize items in refrigerator to reduce time that door is open.

• Be sure your doors are closing securely by leveling refrigerator as instructed in your installation instructions.

8. Allow the refrigerator to cool.

9. After 24 hours, check if odor has been eliminated.

If odor is still present:

1. Remove drawers and place on top shelf of refrigerator.

2. Pack refrigerator and freezer sections – including doors – with crumpled sheets of black and white newspaper.

3. Place charcoal briquettes randomly on crumpled newspaper in both freezer and refrigerator compartments.

4. Close doors and let stand 24 to 48 hours.

• Clean condenser coils as indicated in the cleaning instructions every three months. This will increase energy efficiency and cooling performance.

Care and Cleaning

Replacing Light Bulbs

WARNING

To avoid electrical shock which can cause severe personal injury or death, disconnect power to refrigerator before replacing light bulb. After replacing light bulb, reconnect power.

CAUTION

To avoid personal injury or property damage, observe the following:

• Allow light bulb to cool.

• Wear gloves when replacing light bulb.

Upper Fresh Food Section

The upper fresh food light bulbs are located behind the front panel. Reach behind the panel to remove the bulbs.

Lower Fresh Food Section

1. Push up on bottom tabs on light cover. Rotate cover up and release tabs.

2. Remove light bulb.

3. Replace bulb with appliance bulb

no greater than 40 watts.

4. Insert top tabs of light cover into liner slots and snap bottom tabs into liner slots.

Upper Freezer Section

1. Remove ice bin by lifting front of bin and pulling out.

2. Remove light shield by pressing the upper right side of the shield and rotating downward.

3. Remove light bulb. Replace with appliance bulb no

greater than 40 watts.

4. Rotate the shield upward, press in slightly and snap into place.

5. Replace ice bin by sliding in until bin locks into place.

Lower Freezer Section

1. Pinch both sides of light cover to remove.

2. Remove light bulb. Replace with appliance bulb no

greater than 40 watts.

3. Pinch both sides of the light cover to snap into place.

Ice and Water Dispenser

1. Locate light bulb inside top edge of dispenser frame. Unscrew to remove.

2. Replace light bulb with a

7-watt, 120 volt bulb.

Light Bulb

Location

Care and Cleaning

Preparing for Vacation

CAUTION

If your refrigerator has a dispenser and there is any possibility that the temperature can drop below freezing where the refrigerator is located, the water supply system (including the water tank and the water valve) must be drained by a qualified servicer.

For short vacations or absences (three months or less):

1. Remove all perishables.

2. If no one will be checking in on the refrigerator during your absence, remove all frozen items also.

3. If your refrigerator has an automatic ice maker:

• Shut off the water supply to the ice maker at

least one day ahead of time.

• After the last load of ice drops, raise the wire

shut off arm to the OFF position.

• Empty the ice bin.

4. If the room temperature will drop below 55° F (12° C), follow the instructions for longer absences.

For long vacations, absences (more than three months) OR if the room temperature will drop below 55° F (12° C):

1. Remove food.

2. If your refrigerator has an automatic ice maker:

• Shut off the water supply to the ice maker at

least one day ahead of time.

• After the last load of ice drops, raise the wire

shut off arm to the OFF position.

• Empty the ice bin.

Upon Your Return:

After a Short Vacation or Absence:

For models with automatic ice makers or dispensers:

• Reconnect the water supply and turn on supply valve (see pages 5-6).

• Monitor water connection for 24 hours and correct leaks if necessary.

• Run 10-15 glasses of water from the dispenser to flush out the system.

• Restart the ice maker.

• Discard at least the first three ice harvests.

After a Long Vacation or Absence:

• If your refrigerator has an automatic ice maker, reconnect the water supply and turn on supply valve (see pages 5-6).

• Plug the refrigerator back in and reset controls (see pages 8, 9 and 10).

• Monitor water connection for 24 hours and correct leaks, if necessary.

For dispenser models, run water through the dispenser for at least three minutes with the filter bypass in place, then install water filter (see page 19).

• After installing the water filter, run water through the dispenser continuously for at least two minutes, or until water runs steady. Initially you may notice a one to two minute delay in water dispersal as the internal tanks fills.

• Restart the ice maker.

• Discard ice produced within the first 12 hours (at least the first three harvests).

3. If your refrigerator has a dispenser system with water filter, remove the water filter cartridge and install the filter bypass. Dispose of the used cartridge.

4. Turn the Freezer control to OFF.

5. Unplug the refrigerator.

6. Thoroughly clean the interior of both compartments with a baking soda solution and a clean, soft cloth (four tablespoons of baking soda in one quart of warm water.).

7. Dry thoroughly.

8. Leave the doors open to prevent the formation of mold and mildew.

Preparing to Move

• Follow the instructions for long vacations/absences, through step 7.

• Secure all loose items such as shelves and drawers by taping them securely in place to prevent damage.

• Tape the doors shut.

• Use an appliance dolly when moving the refrigerator. ALWAYS truck the refrigerator from its side or backNEVER from its front.

• Be sure the refrigerator stays in an upright position during moving.

Operating Sounds

Improvements in refrigeration design may produce sounds in your new refrigerator that are different or were not present in an older model. These improvements were made to create a refrigerator that is better at preserving food, is more energy efficient, and is quieter overall. Because new units run quieter, sounds may be detected that were present in older units, but were masked by higher sound levels. Many of these sounds are normal. Please note that the surfaces adjacent to a refrigerator, such as hard walls, floors and cabinetry may make these sounds seem even louder. The following are some of the normal sounds that may be noticed in a new refrigerator.

SOUND

Clicking

Air rushing or whirring

Gurgling or boiling sound

Thumping

Vibrating noise

Buzzing

Humming

POSSIBLE CAUSE

• Freezer control (A) clicks when starting or

stopping compressor.

• Defrost timer or electric damper control (select

models) (B) sounds like an electric clock and snaps in and out of defrost cycle.

• Condenser fan (D) makes this noise while

operating.

• Freezer fan (C) makes this noise while operating.

• Freezer fan (C) slows to a stop as the freezer

door is opened.

• Evaporator (E) and heat exchanger (F)

refrigerant make this noise when flowing.

• Ice cubes from ice maker drop into ice bucket (G).

• Dispenser ice chute (H) closing.

• Compressor (I) makes a pulsating sound while

running.

• Refrigerator is not level.

• Ice maker water valve (J) hookup buzzes when

ice maker fills with water.

• Ice maker (K) is in the ‘on’ position without water

connection.

• Ice auger (L) hums as auger agitates ice during

dispensing.

• Compressor (I) can make a high-pitched hum

while operating.

• Solenoid valve (M) operating ice chute door.

SOLUTION

• Normal operation

• See Leveling, pages 4-5.

• Normal operation

• Stop sound by raising ice maker arm to

OFF position. See Automatic Ice Maker, page 16 for details.

• Normal operation

+ 82 hidden pages
