Product User Guide
HiTemp140X2 Series
HiTemp140X2 Series
High Temperature Dual Probe Data Logger Series
Find Quality Products Online at: sales@GlobalTestSupply.com
www.GlobalTestSupply.com
Product User Guide
Table of Contents
HiTemp140X2 Data Loggers
Product Overview .......................................... 2
Additional Features ........................................ 3
Installation Guide .......................................... 4
Device Operation .......................................... 4
Device Maintenance ....................................... 5
RMA Instructions ............................................. 5
General Specifications .................................... 6
HiTemp140X2-FP Series
Product Overview ........................................... 7
Specifications ................................................. 8
HiTemp140X2-TD Series
Product Overview ........................................... 9
Specifications ............................................... 10
Troubleshooting Tips ............ Back Cover
Find Quality Products Online at: sales@GlobalTestSupply.com
www.GlobalTestSupply.com
HiTemp140X2 Series
Product Overview
The HiTemp140X2 series of dual probe high temperature data loggers are comprised
of a stainless steel data logger body and feature either two remote temperature probes one
ambient and one remote temperature probe combination. This data logger series oers
extreme flexibility for high temperature monitoring applications.
The dual probes of the HiTemp140X2 series allow for simultaneous temperature monitoring
and are ideal for applications such as oven mapping, surface temperature monitoring,
autoclave validation, food processing, sterilization processes and much more.
The HiTemp140X2-TD data logger models feature a 2 inch rigid, fast response, transitional
diameter probe to measure ambient temperature, combined with a second stainless steel
bendable or flexible RTD probe option.
The HiTemp140X2-FP data logger models feature a 6 inch, 12 inch, 36 inch or 72 inch,
lightweight flexible RTD probe, combined with a second stainless steel bendable probe or a
second flexible RTD probe.
The HiTemp140X2 data logger series is compatible with the latest version of the MadgeTech
Software. This allows for simple starting, stopping and downloading of collected data. Once
the readings have been downloaded to the software, it can be viewed in graphic, tabular,
and summary form for easy analysis, as well as the potential to be exported into Excel for
further calculations.
Rigid Transitional
Diameter Probe (TD)
Stainless Steel Bendable
RTD Probe (PT)
Find Quality Products Online at: sales@GlobalTestSupply.com
www.GlobalTestSupply.com
Flexible RTD Probe (FP)
2
Product User Guide
Additional Features
Submergibility
The HiTemp140X2 series is rated IP68 and is fully submersible. They can be placed in
environments up to 230 ft (70 m) of water.
Bend Radius
- The bendable probe can be bent to a 1/4 inch bend radius. The probe should not be bent
within 1 inch of either weld joint.
- The flexible probe should not be bent within 1 inch where the probe meets the logger or
less than 1 inch from the probe tip.
O-Rings
O-ring maintenance is a key factor when properly caring for the HiTemp140X2 data loggers. The O-rings ensure a tight seal and prevent liquid from entering the inside of the
device. Please refer to the application note “O-Rings 101: Protecting Your Data”, found on
the MadgeTech website, for information on how to prevent O-ring failure.
Trigger Settings
The device can be programmed to only record based o user configured trigger settings.
1. In the Connected devices panel, select the intended device to change the settings.
2. On the Device tab, in the Information group, click Properties. Users can also right-click
on the device and select Properties in the context menu.
3. Click Trigger and configure the Trigger settings. Trigger formats are available in Window
and Two Point (bi-level) mode. Window mode allows for one range of temperature
monitoring and two point mode allows for two ranges.
Note: This product is rated for use up to 140 °C. Please heed the battery warning. The product will explode if
exposed to temperatures above 140 °C.
Temperature Channels
All HiTemp140X2 data loggers feature 2 temperature channels.
The channel number for each probe is identified on the top
of the logger as shown below. The MadgeTech Software will
list the temperature channels in sequence, listing channel 1
first and channel 2 second, under the data logger device ID as
shown to the right.
3
Find Quality Products Online at: sales@GlobalTestSupply.com
www.GlobalTestSupply.com
HiTemp140X2 Series
Installation Guide
Installing the Interface cable
- IFC400 or IFC406
Refer to the “Quick Start Guide” included in the package.
Installing the software
The Software can be downloaded from the MadgeTech website. Follow the
instructions provided in the Installation Wizard to install the MadgeTech Software.
Device Operation
Connecting and Starting the data logger
- Once the software is installed and running, plug the interface cable into the docking
station.
- Connect the USB end of the interface cable into an open USB port on the computer.
- Place the data logger into the docking station.
- The data logger will automatically appear under Connected Devices within the software.
- For most applications, select Custom Start from the menu bar and choose the desired start
method, reading rate and other parameters appropriate for the data logging application
and click Start. (Quick Start applies the most recent custom start options, Batch Start is used
for managing multiple loggers at once, Real Time Start stores the dataset as it records while
connected to the logger.)
- The status of the device will change to Running, Waiting to Start or Waiting to Manual
Start, depending upon your start method.
- Disconnect the data logger from the docking station and place it in the environment to
measure.
Note: The device will stop recording data when the end of memory is reached or the device is stopped, unless user selectable
memory wrap is enabled. At this point the device cannot be restarted until it has been re-armed by the computer.
Downloading data from a data logger
- Place the logger into the docking station.
- Highlight the data logger in the Connected Devices list. Click Stop on the menu bar.
- Once the data logger is stopped, with the logger highlighted, click Download. You will
be prompted to name your report.
- Downloading will ooad and save all the recorded data to the PC.
4
Find Quality Products Online at: sales@GlobalTestSupply.com
www.GlobalTestSupply.com
Product User Guide
Device Maintenance
Battery Replacement
When replacing the battery, it is important to insert the battery with
positive polarity pointing upward. Failure to do so could result
in product inoperability or potential explosion if exposed to high
temperatures.
Recalibration
The HiTemp140X2 standard calibration points are 30 °C and 140 °C.
Call for custom calibration options to accommodate specific application needs.
Prices and specifications subject to change. See MadgeTech’s terms and conditions. To send
devices to MadgeTech for calibration, service or repair, please use the MadgeTech RMA Process
(next section).
Notice: Steam Sterilization Applications
The pervasive nature of pressurized steam creates a very dicult environment for electronics.
Please refer to the following preventative maintenance procedure when using this device
in steam sterilization applications.
Additionally, this device is not ideal for steam sterilization applications above 121 °C/1.1 bar.
Preventive Maintenance
After every 3 hours of steam exposure:
1. Remove the endcap and battery from the device (ref. battery change procedure on
Product User Guide)
2. Place open logger (minus battery) in an oven at 120°C (250°F) for a minimum of
30 minutes
3. Remove logger from oven and allow to cool to room temp
4. Re-assemble the logger with the battery (note polarity) and endcap
RMA Instructions
To send a device back in to MadgeTech, follow the instructions below to create an RMA
(Return Merchandise Authorization) on the MadgeTech website:
1. Visit the Services tab select RMA Process.
2. When the web page opens, please sign in. If this is the first time, select Click here to
register an account and create one. Once signed in, click on the Make New RMA
button and fill in all the blank fields.
3. Complete the applicable fields on the form including customer Billing and Shipping
information, even if they are the same. Please see the field explanation below for a more
detailed description about questions asked in the Device Information section.
4. When all of the fields are complete, click Generate RMA.
5. Print out the confirmation page that follows containing the RMA number and
MadgeTech’s address for shipping. A Return Merchandise Authorization must be
accompanied by a copy of the RMA paperwork and shipping is prepaid by the
customer. The RMA number should be clearly marked on the outside of the package.
6. Please ship the package via UPS, FedEx, TNT, or DHL to the address listed on the
confirmation page. USPS will not ship MadgeTech data loggers.
7. A notification email will be automatically sent when MadgeTech has received the RMA.
5
Find Quality Products Online at: sales@GlobalTestSupply.com
www.GlobalTestSupply.com
HiTemp140X2 Series
HiTemp140X2 Series General Specifications
Reading Rate 1 reading every second up to 1 reading every 24 hours
Memory 32,767 readings
Memory Wrap
Around
Start Modes
Stop Modes Manual or Timed (Specific data and time)
Real Time Recording May be used with PC to monitor and record data in real time
Password Protection
Readings in Trigger
Settings Mode
Trigger Settings
Battery Type 3.6V high-temperature lithium battery included user replaceable
Battery Life 1 year typical (1 minute reading rate at 25 °C/77 °F)
Calibration Digital calibration through software
Calibration Date Automatically recorded within device
Data Format Date and time stamped °C, °F, °R, K,
Time Accuracy
Computer Interface IFC400 or IFC406 USB docking station required; 125,000 baud
Operating System
Compatibility
MadgeTech Software
Compatibility
Operating
Environment
IP Rating IP68
Dimensions (body) 1.89 in x 0.97 in x 0.97 in (48 mm x 24.6 mm x 24.6 mm)
Enclosure Material 316 Stainless Steel
Approvals CE
Yes
• Software programmable immediate start
• Delay start up to 18 months in advance
An optional password may be programmed into the device to restrict
access to configuration options. Data may be read out without the
password.
16,383 readings
High and Low limits may be set. Once data meets or exceed sets limits,
the device will record to memory. Bi-level start and stop triggers can
also be programmed. Users can specify the number of readings to take
after the device triggers. (Triggering on channel #1 only)
• 1 minute/month at 25 °C (77 °F)
• Extended Operation: ±20 minutes/month at 140 °C (±450 ppm)
XP SP3/Vista/Windows 7/Windows 8
• MadgeTech Standard Software version 4.2.1.0 or later
• MadgeTech Secure Software version 4.2.0.0 or later
-40 °C to +140 °C (-40 °F to +284 °F)
0 %RH to 100 %RH, 0.002 PSIA to 100 PSIA
Note: any X2 logger with an FP probe is only rated to 60 PSIA.
Battery Warning
WARNING: FIRE, EXPLOSION, AND SEVERE BURN HAZARD. DO NOT SHORT CIRCUIT, CHARGE, FORCE OVER DISCHARGE,
CRUSH, PENETRATE, OR INCINERATE. BATTERY MAY LEAK OR EXPLODE IF HEATED ABOVE 150 ºC (302 ºF).
Speciications subject to change.
See MadgeTech’s terms and conditions
6
Find Quality Products Online at: sales@GlobalTestSupply.com
www.GlobalTestSupply.com
Product User Guide
HiTemp140X2-FP
High Temperature Dual Probe Data Loggers with two Remote
Temperature Probes
*
*Also Available with a 1 Inch Probe Tip
The HiTemp140X2-FP series of dual probe high temperature data loggers are comprised
of a stainless steel data logger body and feature 6 inch, 12 inch, 36 inch or 72 inch flexible
FP probes or are available with one flexible probe and a stainless steel bendable PT probe
combination.
The dual probes of this HiTemp140X2 series allow for simultaneous temperature monitoring
and provide flexibility in applications such as oven mapping, surface temperature
monitoring, autoclave validation and sterilization processes.
The HiTemp140X2-FP model oers lightweight, flexible RTD probes coated with PFA
insulation. The FP probe design allows the probe to be easily maneuvered and is ideal for
temperature monitoring inside test tubes, small vials, and other delicate applications. The
narrow thermistor probe tip is compatible for use with the MicroDisc probe attachment
allowing for precise surface temperature monitoring of shelving and more.
The HiTemp140X2-FP-PT-1 and HiTemp140X2-FP-PT-5 models feature a 6 inch, 12 inch, 36
inch, or 72 inch stainless steel bendable probe with the option of either a 1 inch or 5 inch
probe tip (sheath). The stainless steel probe can be bent, angled, and coiled in any direction
and formed into position as needed. The sharp probe tip allows for easy insertion and has
an extended measurement range of -200 °C to +350 °C.
7
Find Quality Products Online at: sales@GlobalTestSupply.com
www.GlobalTestSupply.com
HiTemp140X2-FP Specifications
• HiTemp140X2-FP:
Temperature Sensor
Flexible RTD Probe
• HiTemp140X2-FP-PT:
Flexible RTD Probe & Bendable RTD Probe
HiTemp140X2 Series
Probe Measurement
Temperature Resolution 0.01 °C (0.02 °F)
Calibrated Accuracy ±0.1 °C (±0.18 °F)
Dimensions (probe)
Materials
Weight
Operating Enviornment
• Flexible Probe: -60 °C to +260 °C (-76 °F to +500 °F)
Range
• Bendable Probe: -200 °C to +350 °C (-328 °F to +662 °F)
• HiTemp140X2-FP
Flexible Probe: 6 in x 0.10 in (152 mm x 2.5 mm)
Flexible Probe: 12 in x 0.10 in (305 mm x 2.5 mm)
Flexible Probe: 36 in x 0.10 in (914 mm x 2.5 mm)
Flexible Probe: 72in x 0.10 in (1829 mm x 2.5 mm)
• HiTemp140X2-FP-PT 1 Inch Bendable Probe:
Probe tip: 1.7 in x 0.125 in dia. (42 mm x 3.2 mm dia.)
Bendable portion: 22 in x 0.062 in dia. (559 mm x 1.6 mm dia.
• HiTemp140X2-FP-PT 5 Inch Bendable Probe:
Probe tip: 4.8 in x 0.125 in dia. with 1 in x 0.188 in dia. handle
(121 mm x 3.2 mm dia. with 25 mm x 4.8 mm dia. handle)
Bendable portion: 22 in x 0.062 in dia. (559 mm x 1.6 mm dia.
• Bendable Probe: 316 Stainless Steel
• Flexible Probe: PFA Insulated Cable
• HiTemp140X2-FP: 4.1 oz (115 g)
• HiTemp140X2-FP-PT: 3.9 oz (110 g)
-40 °C to +140 °C (-40 °F to +284 °F)
0 %RH to 100 %RH, 0.002 PSIA to 60 PSIA
Questions?
For troubleshooting tips and information, refer to the built in help section of the MadgeTech 4 software, visit
our Knowledge Base online.
Find Quality Products Online at: sales@GlobalTestSupply.com
www.GlobalTestSupply.com
8
Product User Guide
HiTemp140X2-TD
High Temperature Dual Probe Data Loggers with Ambient & Remote
Temperature Probes
The HiTemp140X2-TD data logger models feature a 2 inch rigid transitional diameter probe
to measure ambient temperature, combined with a second bendable or flexible probe
option. The rigid 2 inch TD probe is made of stainless steel, oers an ultra-fast response time
and is suitable for measuring ambient temperatures in the harshest environments.
The HiTemp140X2-TD-PT-1 and the HiTemp140X2-TD-PT-5 models include a 24 inch
bendable probe made of stainless steel with either a 1 inch or 5 inch probe sheath at the
tip. The stainless steel PT probe options provide the ability to retain shape when bent into
position and the sharp probe tip allows for easy insertion. The stainless steel PT probes also
oer an extended measurement range to accommodate extremely high temperatures.
The HiTemp140X2-TD-FP combines the 2 inch rigid probe with the 6 inch 12 inch, 36 inch,
or 72 inch RTD lightweight flexible RTD probe. The flexible FP probe option is a lightweight, pliable probe coated with PFA insulation making it ideal for use inside small vials
and test tubes. This probe style has a narrow diameter, high accuracy and is ideal for steam
sterilization and lyophilization. The FP probe is also compatible with the MicroDisc probe
attachment, used for the surface temperature monitoring of shelving and more.
.
9
Find Quality Products Online at: sales@GlobalTestSupply.com
www.GlobalTestSupply.com
HiTemp140X2-TD Specifications
• HiTemp140X2-TD-PT:
Temperature Sensor
Rigid RTD Probe with a Bendable RTD Probe
• HiTemp140X2-TD-FP:
Rigid RTD Probe with a Flexible RTD Probe
HiTemp140X2 Series
Probe Measurement
Temperature Resolution 0.01 °C (0.02 °F)
Calibrated Accuracy ±0.1 °C (±0.18 °F)
Dimensions (probe)
Materials
Weight
Operating Enviornment
• Rigid Probe: -200 °C to +260 °C (-328 °F to +500 °F)
• Bendable Probe: -200 °C to +350 °C (-328 °F to +662 °F)
Range
• Flexible Probe: -60 °C to +260 °C (-76 °F to +500 °F)
• HiTemp140X2-TD-PT Rigid Probe:
2.0 in x 0.125 in dia. (0.188 in transitional dia.)
51 mm x 3.2 mm dia. (4.8 mm transitional dia.)
• HiTemp140X2-TD-PT 1 Inch Bendable Probe:
Probe tip: 1.7 in x 0.125 in dia. (42 mm x 3.2 mm dia.)
Bendable portion: 22 in x 0.062 in dia. (559 mm x 1.6 mm dia.)
• HiTemp140X2-TD-PT 5 Inch Bendable Probe:
Probe tip: 4.8 in x 0.125 in dia. with 1 in x 0.188 in dia. handle
(121 mm x 3.2 mm dia. with 25 mm x 4.8 mm dia. handle)
Bendable portion: 22 in x 0.062 in dia. (559 mm x 1.6 mm dia.)
• HiTemp140X2-TD-FP- Flexible Probe:
6 in x 0.10 in (152 mm x 2.5 mm)
12 in x 0.10 in (305 mm x 2.5 mm)
36 in x 0.10 in (914.4 mm x 2.5 mm)
72 in x 0.10 in (1829 mm x 2.5 mm)
• Rigid/Bendable Probe: 316 Stainless Steel
• Flexible Probe: PFA Insulated Cable
• HiTemp140X2-TD-PT: 3.0 oz (85 g)
• HiTemp140X2-TD-FP: 3.5 oz (100 g)
-40 °C to +140 °C (-40 °F to +284 °F)
0 %RH to 100 %RH, 0.002 PSIA to 100 PSIA
Note: any X2 logger with an FP probe is only rated to 60 PSIA.
10
Find Quality Products Online at: sales@GlobalTestSupply.com
www.GlobalTestSupply.com
Troubleshooting Tips
Why is the data logger not appearing in the software?
If a HiTemp140X2 data logger doesn’t appear in the Connected Devices panel, or an error message
is received while using any of the HiTemp140X2 loggers, try the following:
• Check that the IFC400 or IFC406 is properly connected. For more information, see Troubleshooting
Interface Cable problems (below).
• Ensure that the battery is not discharged. For best voltage accuracy, use a voltage meter connected to
the battery of the device. If possible, try switching the battery with a new 3.6V lithium battery.
• Ensure that no other MadgeTech software (such as MadgeTech 2, or MadgeNET) is running in the
background.
• Ensure that MadgeTech 4 is being used. MadgeTech 2 and MadgeNET are not the correct software for
connecting a HiTemp140X2.
• Ensure that the Connected Devices panel is large enough to display devices. This can be verified by
positioning the cursor on the edge of the Connected Devices panel until the resize cursor appears, then
dragging the edge of the panel to resize it. The screen layout may also be reset in the options menu by
selecting File, Options, and scrolling to the bottom.
Troubleshooting Interface Cable problems
Check that the software properly recognizes the connected IFC400 or IFC406.
If the data logger is not appearing in the Connected Devices list, it may be that the IFC400 or IFC406 is
not properly connected.
1. In the software, click the File button, then click Options.
2. In the Options window, click Communications.
3. The Detected Interfaces box will list all of the available communication interfaces. If the IFC400 or
IFC406 is listed here, then the software has correctly recognized and is ready to use it.
Check that Windows recognizes the connected IFC400 or IFC406.
If the software does not recognize the IFC400 or IFC406, there may be a problem with Windows or the
USB drivers.
1. In Windows, click Start, right-click Computer and choose Properties or press Windows+Break as a
keyboard shortcut.
2. Click Device Manager in the left hand column.
3. Double click Universal Serial Bus Controllers.
4. Look for an entry for Data logger Interface.
5. If the entry is present, and there are no warning messages or icons, then windows has correctly
recognized the connected IFC400 or IFC406.
6. If the entry is not present, or has an exclamation point icon next to it, the USB drivers may need to be
installed. These are available on the software flash drive included with the IFC400 or IFC406, and on the
MadgeTech website.
Ensure that the USB end of the IFC400 or IFC406 is securely connected to the computer.
1. Locate the USB-A plug of the IFC400 or IFC406.
2. If the interface cable is connected to the PC, unplug it. Wait ten seconds.
3. Reconnect the cable to the PC.
4. Check to make sure that the blue LED is lit on the IFC400 or the green LED is lit on the IFC406,
indicating a successful connection.
DOC 1297036-00 REV 4 2018.11.02
Find Quality Products Online at: sales@GlobalTestSupply.com
www.GlobalTestSupply.com
Loading...
