HiTemp140-FP & HiTemp140-FP-TSK
Product Overview
The HiTemp140-FP is a durable, user friendly high temperature data logger featuring a long,
flexible RTD probe with a narrow diameter, making it ideal for use in steam sterilization and
lyophilization processes.
Commonly used for mapping, validation and monitoring of high temperature surfaces,
this stainless steel data logger is available in two models, the HiTemp140-FP-36 and the
HiTemp140-FP-72, which feature either 36 inch or 72 inch flexible probe lengths, respectively.
The flexible probe is coated with PFA insulation and can withstand temperatures up to 260 °C
with an accuracy of ±0.1 °C
The HiTemp140-FP probe design is narrow and lightweight making it ideal for placement
within small vials, tubing, test tube and other small diameter or delicate applications. Because
of the flexible probe, the risks of breakage (both vial and probe) generally associated with
stainless steel probe loggers are diminished and the location and placement of the probe is
easy to manipulate.
The Trigger Settings feature of the HiTemp140-FP allows users to configure high and low
temperature thresholds that when met or exceeded, will automatically start or stop recording
data to memory. This data logger is capable of storing up to 32,700 date and time stamped
readings and features a nonvolatile solid state memory which retains data even if the battery
becomes discharged.
Submergibility
The HiTemp140-FP is rated IP68 and is fully submersible.
O-Rings
O-ring maintenance is a key factor when properly caring for the HiTemp140-FP. The O-rings
ensure a tight seal and prevent liquid from entering the inside of the device. Please refer to
the application note “O-Rings 101: Protecting Your Data”,
for information on how to prevent O-ring failure.
Trigger Settings
The device can be programmed to only record based o user configured trigger settings.
1. In the Connected devices panel, select the intended device to change the settings.
2. On the Device tab, in the Information group, click Properties. Users can also right-click
on the device and select Properties in the context menu.
3. Click Trigger and configure the Trigger settings. Trigger formats are available in Window
and Two Point (bi-level) mode. Window mode allows for one range of temperature
monitoring and two point mode allows for two ranges.
Note: This product is rated for use up to 140 °C. Please heed the battery warning. The product will explode if
exposed to temperatures above 140 °C (284 ºF).
2
www.GlobalTestSupply.com
Product User Guide
Installation Guide
Installing the Interface cable
- IFC400 or IFC406
Refer to the “Quick Start Guide” included in the package.
Installing the software
The software can be downloaded from the website.
Device Operation
Connecting and Starting the data logger
- Once the software is installed and running, plug the interface cable into the docking
station.
- Connect the USB end of the interface cable into an open USB port on the computer.
- The device will appear in the Connected Devices list, highlight the desired data logger.
- For most applications, select “Custom Start” from the menu bar and choose the desired
start method, reading rate and other parameters appropriate for the data logging
application and click “Start”. ( “Quick Start” applies the most recent custom start options,
“Batch Start” is used for managing multiple loggers at once, “Real Time Start” stores the
dataset as it records while connected to the logger.)
- The status of the device will change to “Running”, “Waiting to Start” or “Waiting to
Manual Start”, depending upon your start method.
- Disconnect the data logger from the interface cable and place it in the environment to
measure. Note: The device will stop recording data when the end of memory is reached or the device is
stopped. At this point the device cannot be restarted until it has been re-armed by the computer.
Note: Please refer to the Disclaimer & Terms of Use section on the back page of this guide for product usage
recommendations.
Downloading data from a data logger
- Place the logger into the docking station.
- Highlight the data logger in the Connected Devices list. Click “Stop” on the menu bar.
- Once the data logger is stopped, with the logger highlighted, click “Download”. You will
be prompted to name your report.
- Downloading will ooad and save all the recorded data to the PC.
3
www.GlobalTestSupply.com
HiTemp140-FP & HiTemp140-FP-TSK
Product Maintenance
Battery Replacement
Materials: ER1425S-HT Battery
1. Unscrew the bottom of the logger and remove the battery.
2. Place the new battery into the logger. Note the polarity of the battery.
3. Screw the cover back onto the logger.
Recalibration
The HiTemp140-FP standard calibrations are two points at 30 °C and 140 °C.
Notice: Steam Sterilization Applications
The pervasive nature of pressurized steam creates a very difficult environment for
electronics. Please refer to the following preventative maintenance procedure when using
this device in steam sterilization applications.
dditionally, this device is not ideal for steam sterilization applications above 121 °C/1.1 bar.
A
Preventive Maintenance
After every 3 hours of steam exposure:
1. Remove the endcap and battery from the device (ref. battery change procedure on
Product User Guide)
2. Place open logger (minus battery) in an oven at 120°C (250°F) for a minimum of
30 minutes
3. Remove logger from oven and allow to cool to room temp
4. Re-assemble the logger with the battery (note polarity) and endcap
www.GlobalTestSupply.com
4
Product User Guide
HiTemp140-FP General Specifications
Temperature Sensor Flexible RTD Probe
Probe Measurement
Temperature Resolution 0.01 °C (0.02 °F)
Calibrated Accuracy ±0.1 °C (0.18 °F)
Data Logger
Response Time
Reading Rate 4 readings per second up to 1 reading every 24 hours
Memory 32,767 readings
Start Modes
Stop Modes Manual or Timed (specific date and time)
Trigger Settings
Readings in Trigger
Settings Mode
Real Time Recording May be used with PC to monitor and record data in real time
Password Protection
Memory Wrap Around Ye s
Battery Type 3.6V high-temperature lithium battery included; user replaceable
Battery Life 1 year typical (1 minute reading rate at 25 °C/ 77 °F)
Calibration Digital calibration through software
Calibration Date Automatically recorded within device
Data Format Date and time stamped °C, °F, °R, K,
Time Accuracy
Computer Interface IFC400 or IFC406 USB docking station required; 125,000 baud
Operating System
Compatibility
MadgeTech Software
Compatibility
Operating Environment -40 °C to +140 °C (-40 °F to +284 °F) 0 %RH to 100 %RH, 0.002 PSIA to 60 PSIA
IP Rating IP68
Dimensions (body) 2.95 in x 0.97 in x 0.97 in (75 mm x 24.6 mm x 24.6 mm)
Dimensions (probe)
Materials
Approvals CE
5
-60 °C to +260 °C (-76 °F to +500 °F)
Range
In AirIn Water
(hours : minutes : seconds : fractions of a second)
- 00:00:30:00
t
60
- 00:01:10:00
t
90
• Software programmable immediate start
• Delay start up to 18 months in advance
High and Low limits may be set. Once data meets or exceed sets limits, the device
will record to memory. Bi-level start and stop triggers can also be programmed.
Users can specify the number of readings to take after the device triggers.
10,922 readings
An optional password may be programmed into the device to restrict access to
configuration options. Data may be read out without the password.
• 1 minute/month at 25 °C (77 °F)
• Extended Operation: ±20 minutes/month at 140 °C (±450 ppm)
XP SP3/Vista/Windows 7/Windows 8
• MadgeTech Standard Software version 4.2.1.1
• MadgeTech Secure Software version 4.2.0.1 or later
• HiTemp140-FP-36: 36 in x 0.10 in (914 mm x 2.5 mm)
• HiTemp140-FP-72: 72 in x 0.10 in (1829 mm x 2.5 mm)
Weight 85 g (3 oz)
• Body: 316 Stainless Steel
• Probe: PFA Insulated Cable
t
- 00:00:03:50
60
- 00:00:06:50
t
90
www.GlobalTestSupply.com
HiTemp140-FP & HiTemp140-FP-TSK
HiTemp140-FP-TSK Specifications
Thermal Shield
Specifications
Dimensions (enclosure)
Weight
Operating Environment
HiTemp140-FP-TSK (Flush)HiTemp140-FP-TSK (Vented)
2.75 in x 2.0 in dia.
(69.85 mm x 51 mm dia.)
6.7 oz (190 g)
not including data logger
4.3 in x 2.0 in dia.
(109.2 mm x 50.8 mm dia.)
9.5 oz (270 g)
not including data logger
-200 ºC to +250 ºC (-328 ºF to +482 ºF) (Time limited)
0 %RH to 100 %RH
Material Enclosure: PTFE
Maximum Exposure
Time Chart
Temperature
-200 °C (-328 °F)12 minutesN/A14 minutesN/A
-180 °C (-292 °F)13 minutesN/A15 minutesN/A
-160 °C (-256 °F)15 minutesN/A16 minutesN/A
-140 °C (-220 °F)17 minutesN/A18 minutesN/A
-120 °C (-184 °F)19 minutesN/A21 minutesN/A
-100 °C (-148 °F)22 minutesN/A24 minutesN/A
-80 °C (-112 °F)27 minutesN/A30 minutesN/A
-60 °C (-76 °F)37 minutes22 minutes42 minutes25 minutes
-40 °C to +140 °C
(-40 °F to +284 °F)
150 °C (302 °F)59 minutes34 minutes66 minutes40 minutes
160 °C (320 °F)51 minutes29 minutes57 minutes34 minutes
170 °C (338 °F)43 minutes25 minutes48 minutes29 minutes
180 °C (356 °F)37 minutes23 minutes42 minutes26 minutes
190 °C (374 °F)34 minutes20 minutes38 minutes23 minutes
200 °C (392 °F)31 minutes18 minutes34 minutes21 minutes
210 °C (410 °F)29 minutes17 minutes32 minutes19 minutes
220 °C (428 °F)27 minutes16 minutes30 minutes18 minutes
230 °C (446 °F)25 minutes15 minutes27 minutes17 minutes
240 °C (464 °F)23 minutes14 minutes26 minutes16 minutes
250 °C (482 °F)22 minutes13 minutes24 minutes15 minutes
HiTemp140-TS (Flush)HiTemp140-TS (Vented)
Exposure Time
in Air
IndefinitelyIndefinitelyIndefinitelyIndefinitely
Exposure Time
in Liquid
Exposure Time
in Air
Exposure Time
in Liquid
Battery Warning
WARNING: FIRE, EXPLOSION, AND SEVERE BURN HAZARD. DO NOT SHORT CIRCUIT, CHARGE, FORCE OVER DISCHARGE,
CRUSH, PENETRATE, OR INCINERATE. BATTERY
MAY LEAK OR EXPLODE IF HEATED ABOVE 140 ºC (284 ºF).
Specifications subject to change.
www.GlobalTestSupply.com
6
Disclaimer & Terms of Use
Listed specifications can be used to determine maximum allowable exposure times for the
HiTemp140 with Thermal Shield at dierent temperatures beyond the normal operating
range of the logger. Both the data logger and Thermal Shield must be at ambient
temperature (approximately 25 °C) before being placed in the extreme temperature
environment.
Immediately following exposure to high temperature, the data logger should be removed
from the thermal shield (using appropriate precautions, as it could be VERY hot) OR the data
logger and shield should be placed in a water bath (approximately 25 °C) for at least 15
minutes to allow it to cool. Failing to do this may allow heat trapped in the Thermal Shield
to continue to heat the data logger to potentially unsafe levels.
If your application involves a ramp up to a temperature above 140 °C and/or any complex
temperature profile that isn’t simply a constant temperature,
determine whether the HiTemp140 with Thermal Shield is suitable.
,
www.GlobalTestSupply.com
DOC-1296036-00 REV 5 2018.11.02
