Mackie SA1232 User Manual
SA1232
3-WAY ACTIVE
SPEAKER SYSTEM
USER’S MANUAL
CAUTION AVIS
RISK OF ELECTRIC SHOCK
RISQUE DE CHOC ELECTRIQUE
CAUTION: TO REDUCE THE RISK OF ELECTRIC SHOCK
NO USER-SERVICEABLE PARTS INSIDE
REFER SERVICING TO QUALIFIED PERSONNEL
ATTENTION: POUR EVITER LES RISQUES DE CHOC
ELECTRIQUE, NE PAS ENLEVER LE COUVERCLE. AUCUN
ENTRETIEN DE PIECES INTERIEURES PAR L'USAGER. CONFIER
L'ENTRETIEN AU PERSONNEL QUALIFIE.
AVIS: POUR EVITER LES RISQUES D'INCENDIE OU
D'ELECTROCUTION, N'EXPOSEZ PAS CET ARTICLE
The lightning flash with arrowhead symbol within an equilateral
triangle is intended to alert the user to the presence of uninsulated
"dangerous voltage" within the product's enclosure that may be
of sufficient magnitude to constitute a risk of electric shock to persons.
Le symbole éclair avec point de flèche à l'intérieur d'un triangle
équilatéral est utilisé pour alerter l'utilisateur de la présence à
l'intérieur du coffret de "voltage dangereux" non isolé d'ampleur
suffisante pour constituer un risque d'éléctrocution.
The exclamation point within an equilateral triangle is intended to
alert the user of the presence of important operating and maintenance
(servicing) instructions in the literature accompanying the appliance.
Le point d'exclamation à l'intérieur d'un triangle équilatéral est
employé pour alerter les utilisateurs de la présence d'instructions
importantes pour le fonctionnement et l'entretien (service) dans le
livret d'instruction accompagnant l'appareil.
DO NOT OPEN
NE PAS OUVRIR
DO NOT REMOVE COVER (OR BACK)
A LA PLUIE OU A L'HUMIDITE
SAFETY INSTRUCTIONS
1. Read Instructions — All the safety and operation instructions
should be read before this Mackie product is operated.
2. Retain Instructions — The safety and operating instructions
should be kept for future reference.
3. Heed Warnings — All warnings on this Mackie product and in
these operating instructions should be followed.
4. Follow Instructions — All operating and other instructions
should be followed.
5. Water and Moisture — This Mackie product should not be used
near water – for example, near a bathtub, washbowl, kitchen sink,
laundry tub, in a wet basement, near a swimming pool, swamp, or
salivating St. Bernard dog, etc.
6. Cleaning — Clean only with a dry cloth.
7. Ventilation — This Mackie product should be situated so that its
location or position does not interfere with its proper ventilation. For
example, the Component should not be situated on a bed, sofa,
rug, or similar surface that may block any ventilation openings, or
placed in a built-in installation such as a bookcase or cabinet that
may impede the flow of air through ventilation openings.
8. Heat — This Mackie product should be situated away from heat
sources such as radiators or other devices which produce heat.
WARNING: The heatsink may reach high temperatures during
standard use. To ensure proper operation, allow a minimum of 6
inches of clearance from the heatsink surface and adequate
ventilation.
9. Power Sources — This Mackie product should be connected to a
power supply only of the type described in these operation
instructions or as marked on this Mackie product.
10. Power Cord Protection — Power supply cords should be routed
so that they are not likely to be walked upon or pinched by items
placed upon or against them, paying particular attention to cords at
plugs, convenience receptacles, and the point where they exit this
Mackie product.
11. Object and Liquid Entry — Care should be taken so that
objects do not fall into and liquids are not spilled into this Mackie
product.
12. Damage Requiring Service — This Mackie product should be
serviced only by qualified service personnel when:
A. The power-supply cord or the plug has been
damaged; or
B. Objects have fallen, or liquid has spilled into this
Mackie product; or
C. This Mackie product has been exposed to rain; or
D. This Mackie product does not appear to operate
normally or exhibits a marked change in performance;
or
E. This Mackie product has been dropped, or its chassis
damaged.
13. Servicing — The user should not attempt to service this
Mackie product beyond those means described in this operating
manual. All other servicing should be referred to the Mackie Service
Department.
14. To prevent electric shock, do not use this polarized plug with an
extension cord, receptacle, or other outlet unless the blades can be
fully inserted to prevent blade exposure.
Pour prévenir les chocs électriques ne pas utiliser cette fiche
polariseé avec un prolongateur, un prise de courant ou une autre
sortie de courant, sauf si les lames peuvent être insérées à fond
sans laisser aucune pariie à découvert.
15. Grounding or Polarization — Precautions should be taken so
that the grounding or polarization means of this Mackie product is
not defeated.
16. Power Precaution — Unplug this Mackie product during
lightning storms or when unused for long periods of time. Note that
this Mackie product is not completely disconnected from the AC
mains service when the power switch is in the OFF position.
17. This apparatus does not exceed the Class A/Class B (whichever
is applicable) limits for radio noise emissions from digital apparatus
as set out in the radio interference regulations of the Canadian
Department of Communications.
ATTENTION —
Le présent appareil numérique n’émet pas de
bruits radioélectriques dépassant las limites applicables aux
appareils numériques de class A/de class B (selon le cas) prescrites
dans le règlement sur le brouillage radioélectrique édicté par les
ministere des communications du Canada.
WARNING — To reduce the risk of fire or
electric shock, do not expose this appliance to
rain or moisture.
WARNING
— The cabinet has no rigging
points and is not suitable for flying. Never
attempt to suspend the cabinet by its handles.
The SA 1232 should never be pole-mounted.
2
Lend Me Your Ears
Exposure to extremely
high noise levels may cause
permanent hearing loss. Individuals vary considerably
in susceptibility to noise-
induced hearing loss, but nearly everyone
will lose some hearing if exposed to sufficiently intense noise for a period of time.
The U.S. Government’s Occupational
Safety and Health Administration (OSHA)
has specified the permissible noise level exposures shown in this chart.
Duration Per Day Sound Level dBA, Typical
In Hours Slow Response Example
8 90 Duo in small club
692
4 95 Subway Train
397
2 100 Very loud classical music
1.5 102
1 105 Patrice screaming at Ron about deadlines
0.5 110
0.25 or less 115 Loudest parts at a rock concert
According to OSHA, any exposure in excess of these permissible limits could result
in some hearing loss. To ensure against potentially dangerous exposure to high
sound-pressure levels, it is recommended
that all persons exposed to equipment capable of producing these levels use hearing
protectors while this unit is in operation.
Ear plugs or protectors in the ear canals or
over the ears must be worn when operating
this amplification system in order to prevent a permanent hearing loss if exposure is
in excess of the limits set forth here.
The SA1232
can produce a
maximum SPL of
136 dB @ 1m
Contents
SAFETY INSTRUCTIONS .............................................................................................................2
INTRODUCTION ...........................................................................................................................4
REAR PANEL DESCRIPTION ........................................................................................................5
HOOKUP DIAGRAM .....................................................................................................................5
CONNECTIONS ............................................................................................................................6
PLACEMENT ................................................................................................................................. 6
AC POWER ...................................................................................................................................7
THERMAL CONSIDERATIONS ..................................................................................................... 8
SERVICE INFORMATION .............................................................................................................9
Warranty Service .............................................................................................................9
Troubleshooting ............................................................................................................... 9
Repair ............................................................................................................................10
CARE AND MAINTENANCE .......................................................................................................10
SA1232 SPECIFICATIONS .........................................................................................................11
Architects and Engineers’ Specifications ...................................................................... 12
Graphs ...........................................................................................................................13
SA1232 LIMITED WARRANTY ...................................................................................................15
Don’t forget to visit our website at www.mackie.com
for more information about this and other Mackie products.
Part No. 0000431 Rev. B 4/03
© 2003 Mackie Designs Inc. All Rights Reserved.
3
INTRODUCTION
Thank you for choosing Mackie Designs’
active sound reinforcement speaker systems.
The SA1232 is a high-efficiency, extreme
output, active 3-way, wide dispersion,
sound reinforcement speaker system. The
SA1232 benefits from
the integration of 1300
watts of amplifier
power, complete active
control electronics, and
RCF Precision components. These elements
together form a
speaker system with
PARALLEL
MAIN INPUT
LOOP OUT
SA1232
ACTIVE SOUND REINFORCEMENT
THE FOLLOWING ARE TRADEMARKS OR REGISTERED TRADEMARKS OF MACKIE DESIGNS INC.:
SPEAKER SYSTEM
CONCEIVED AND DESIGNED BY MACKIE DESIGNS INC, WOODINVILLE, WA, USA
AND MACKIE EUROPE • MANUFACTURED IN ITALY • COPYRIGHT ©2001 •
"MACKIE", AND THE "RUNNING MAN" FIGURE • PATENT PENDING
103 dB of sensitivity
(@ 1 watt/1 meter).
WARNING:
The result is unprecedented output,
resolution and clarity.
CAUTION
RISK OF ELECTRIC SHOCK
DO NOT OPEN
REPLACE WITH THE SAME TYPE FUSE AND RATING.
DISCONNECT SUPPLY CORD BEFORE CHANGING FUSE
THIS SURFACE MAY REACH HIGH TEMPERATURE DURING
STANDARD USE. TO ENSURE PROPER OPERATION ALLOW A MINIMUM OF 6 INS.
OF CLEARANCE FROM THIS SURFACE AND ADEQUATE VENTILATION. TO REDUCE
THE RISK OF ELECTRIC SHOCK DO NOT REMOVE THIS PANEL OR ANY ATTACHED
COMPONENT. NO OPERATOR SERVICEABLE PARTS INSIDE. REFER SERVICING TO
QUALIFIED PERSONNEL. TO REDUCE THE RISK OF FIRE OR ELECTRIC SHOCK, DO NOT
EXPOSE THIS APPLIANCE TO RAIN OR MOISTURE.
AVIS:
RISQUE DE CHOC ELECTRIQUE — NE PAS OUVRIR
UTILISE UN FUSIBLE DE RECHANGE DE MÊME TYPE.
DEBRANCHER AVANT DE REMPLACER LE FUSIBLE
SERIAL NUMBER
The SA1232 features the same horn
assembly we introduced in the Mackie
Designs SR1530 active
3-way speaker. The horn is a one piece design with 90º x 40º dispersion that
integrates both the mid-range and highfrequency sections. This provides seamless
coupling between the MF and HF sections.
The 6-inch mid-range’s basket assembly is designed as part of the horn assembly and is
also designed to function as an optimized
compression chamber, dramatically simplifying the mid-range assembly. The SA1232
features an “Optimized Wavefront” horn design. Unlike typical mid/high horns where
the mid- and high-frequency horns are
physically pointing to a different location in
front of the box, the SA1232’s high-frequency
section is positioned to fire down into the
six-inch mid-range’s dispersion pattern.
This creates a focused, single wave front
with excellent phase and power response
characteristics. With the resulting 90º x 40º
dispersion pattern, the SA1232 provides
very open, natural sound reproduction at
extreme output levels.
The SA1232 Mid/High Section is designed
to deliver over 136 dB of acoustic output.
In order to achieve this, the SA1232 incorporates several state of the art advancements in
transducer technology, which were developed
over a two year period. The compression
driver is a new 1.75-inch titanium diaphragm
design. It features a 3-slot, low-distortion
geometry phase plug.
4
The motor structure uses a high-grade
neodymium magnet providing extraordinarily high BL (gauss) and performance.
The magnetic structure for both the highfrequency and mid-frequency drivers
incorporate pure, high
grade, neodymium providing a higher gauss
capability, significant
POWER
0dB
SIGNAL
LIMIT
-15
+5
THERMAL
weight reduction, and
higher BL (force) in the
magnetic gap. This results
in better control of the
moving mass, and audio
reproduction with lower
ON
distortion and excellent
linearity.
MANUFACTURING DATE
The amplifiers for the
compression driver and
mid-range driver incorporate a Class AB topology
renowned for its clarity
and warmth, and for its
ability to produce the high-
voltage output required to generate extreme
SPL levels.
By using two 12-inch woofers, we provide a cone surface area larger than a single
18-inch device, yet we are able to move it by
an order of magnitude faster. This results in
an extremely tight, deep bottom end, while
efficiently reaching the mid-frequency
crossover point. The low-frequency amplifier features an innovative Class G hybrid
topology, which features two power supplies for improved efficiency that delivers
1100 watts rms (continuous), and 1400
watts peak at 100 Hz.
The rear mounted amplifier assembly
features separate signal and AC power panels separated by a large aluminum heatsink.
The signal input panel contains:
• an input XLR and loop-through XLR
• a volume level control
• Power On indicator
• Signal Present indicator
• Limit indicator
• Thermal protection indicator
The system accepts a standard line-level
signal via an XLR input connector.
The SA1232 cabinet is constructed using
both multi-layered Baltic birch plywood and
pressure-injected structural resin caps. The
handles on each side are placed at the speaker’s
center of gravity for easy carrying and setup.
The top and bottom sections both have
handles for easy movement and relocation.
REAR PANEL DESCRIPTION
LIMIT Indicator
The SA1232 has a built-in limiter that
MAIN INPUT
This is a female XLR-type connector that
accepts a balanced line-level signal from a
mixing console or other signal source.
prevents the amplifier outputs from clipping or overdriving the transducers. The
LIMIT
indicator lights when the limiter is
activated. It’s okay for the
to blink occasionally, but if it blinks fre-
LOOP OUT
This is a male XLR-type connector that
produces exactly the same signal that is
connected to the
MAIN INPUT
to daisy-chain several SA1232s together off
the same signal source.
jack. Use it
quently or lights continuously, turn down
the level control until the
only blinks occasionally.
THERMAL Indicator
There is also a thermal protection circuit
that monitors the internal temperature of
Level Control
This controls the overall signal level at the
input to the built-in power amplifiers. It
ranges from –15 dB to +5 dB of gain. The
center detent is 0 dB (unity gain).
the amplifiers and heatsink. If the temperature should exceed a safe operating level,
this indicator lights and the signal is muted
to allow the amplifiers to cool. When the
temperature cools to a safe level once again,
the thermal protection circuit deactivates
Power ON Indicator
When the power switch is turned on,
and the linecord is connected to an active
AC power supply, this indicator lights green
to let you know that you’re ready to rock
and roll. The cool blue LED on the front of
the cabinet works in the same way.
and normal operation continues.
Note: Activation of the thermal protection
circuit is an indication that you should take
steps to avoid continued thermal problems.
See “Thermal Considerations” on page 8.
Power Switch
Use this switch to turn the SA1232 on
SIGNAL Present Indicator
This LED illuminates whenever there is
a signal present at the
tor on the rear panel. It senses the signal
just after the Level control, so if the Level
control is turned down, the
indicator turns off.
MAIN INPUT
SIGNAL
connec-
Present
and off. Make sure the level control is
turned down before you turn it on.
AC Receptacle
This is where you connect the AC
linecord to provide AC power to the
SA1232’s built-in power amplifiers. Plug
the linecord into an AC socket properly
HOOKUP DIAGRAM
configured for your particular model.
LIMIT
LIMIT
indicator
indicator
To Next
Speaker
PARALLEL
MAIN INPUT
LOOP OUT
CAUTION
RISK OF ELECTRIC SHOCK
DO NOT OPEN
REPLACE WITH THE SAME TYPE FUSE AND RATING.
DISCONNECT SUPPLY CORD BEFORE CHANGING FUSE
SA1232
ACTIVE SOUND REINFORCEMENT
SPEAKER SYSTEM
CONCEIVED AND DESIGNED BY MACKIE DESIGNS INC, WOODINVILLE, WA, USA
AND MACKIE EUROPE • MANUFACTURED IN ITALY • COPYRIGHT ©2001 •
THE FOLLOWING ARE TRADEMARKS OR REGISTERED TRADEMARKS OF MACKIE DESIGNS INC.:
"MACKIE", AND THE "RUNNING MAN" FIGURE • PATENT PENDING
WARNING:
THIS SURFACE MAY REACH HIGH TEMPERATURE DURING
STANDARD USE. TO ENSURE PROPER OPERATION ALLOW A MINIMUM OF 6 INS.
OF CLEARANCE FROM THIS SURFACE AND ADEQUATE VENTILATION. TO REDUCE
THE RISK OF ELECTRIC SHOCK DO NOT REMOVE THIS PANEL OR ANY ATTACHED
COMPONENT. NO OPERATOR SERVICEABLE PARTS INSIDE. REFER SERVICING TO
QUALIFIED PERSONNEL. TO REDUCE THE RISK OF FIRE OR ELECTRIC SHOCK, DO NOT
EXPOSE THIS APPLIANCE TO RAIN OR MOISTURE.
AVIS:
RISQUE DE CHOC ELECTRIQUE — NE PAS OUVRIR
UTILISE UN FUSIBLE DE RECHANGE DE MÊME TYPE.
DEBRANCHER AVANT DE REMPLACER LE FUSIBLE
MANUFACTURING DATE
SERIAL NUMBER
PARALLEL
MAIN INPUT
LOOP OUT
CAUTION
RISK OF ELECTRIC SHOCK
DO NOT OPEN
REPLACE WITH THE SAME TYPE FUSE AND RATING.
DISCONNECT SUPPLY CORD BEFORE CHANGING FUSE
SA1232
ACTIVE SOUND REINFORCEMENT
SPEAKER SYSTEM
CONCEIVED AND DESIGNED BY MACKIE DESIGNS INC, WOODINVILLE, WA, USA
AND MACKIE EUROPE • MANUFACTURED IN ITALY • COPYRIGHT ©2001 •
THE FOLLOWING ARE TRADEMARKS OR REGISTERED TRADEMARKS OF MACKIE DESIGNS INC.:
"MACKIE", AND THE "RUNNING MAN" FIGURE • PATENT PENDING
WARNING:
THIS SURFACE MAY REACH HIGH TEMPERATURE DURING
STANDARD USE. TO ENSURE PROPER OPERATION ALLOW A MINIMUM OF 6 INS.
OF CLEARANCE FROM THIS SURFACE AND ADEQUATE VENTILATION. TO REDUCE
THE RISK OF ELECTRIC SHOCK DO NOT REMOVE THIS PANEL OR ANY ATTACHED
COMPONENT. NO OPERATOR SERVICEABLE PARTS INSIDE. REFER SERVICING TO
QUALIFIED PERSONNEL. TO REDUCE THE RISK OF FIRE OR ELECTRIC SHOCK, DO NOT
EXPOSE THIS APPLIANCE TO RAIN OR MOISTURE.
AVIS:
RISQUE DE CHOC ELECTRIQUE — NE PAS OUVRIR
UTILISE UN FUSIBLE DE RECHANGE DE MÊME TYPE.
DEBRANCHER AVANT DE REMPLACER LE FUSIBLE
MANUFACTURING DATE
SERIAL NUMBER
To Next
Speaker
POWER
0dB
SIGNAL
LIMIT
-15 +5
THERMAL
ON
DAISY-CHAINING MULTIPLE SA1232s
POWER
0dB
SIGNAL
LIMIT
-15 +5
THERMAL
ON
PARALLEL
MAIN INPUT
LOOP OUT
CAUTION
RISK OF ELECTRIC SHOCK
DO NOT OPEN
REPLACE WITH THE SAME TYPE FUSE AND RATING.
DISCONNECT SUPPLY CORD BEFORE CHANGING FUSE
SA1232
ACTIVE SOUND REINFORCEMENT
SPEAKER SYSTEM
CONCEIVED AND DESIGNED BY MACKIE DESIGNS INC, WOODINVILLE, WA, USA
AND MACKIE EUROPE • MANUFACTURED IN ITALY • COPYRIGHT ©2001 •
THE FOLLOWING ARE TRADEMARKS OR REGISTERED TRADEMARKS OF MACKIE DESIGNS INC.:
"MACKIE", AND THE "RUNNING MAN" FIGURE • PATENT PENDING
WARNING:
THIS SURFACE MAY REACH HIGH TEMPERATURE DURING
STANDARD USE. TO ENSURE PROPER OPERATION ALLOW A MINIMUM OF 6 INS.
OF CLEARANCE FROM THIS SURFACE AND ADEQUATE VENTILATION. TO REDUCE
THE RISK OF ELECTRIC SHOCK DO NOT REMOVE THIS PANEL OR ANY ATTACHED
COMPONENT. NO OPERATOR SERVICEABLE PARTS INSIDE. REFER SERVICING TO
QUALIFIED PERSONNEL. TO REDUCE THE RISK OF FIRE OR ELECTRIC SHOCK, DO NOT
EXPOSE THIS APPLIANCE TO RAIN OR MOISTURE.
AVIS:
RISQUE DE CHOC ELECTRIQUE — NE PAS OUVRIR
UTILISE UN FUSIBLE DE RECHANGE DE MÊME TYPE.
DEBRANCHER AVANT DE REMPLACER LE FUSIBLE
MANUFACTURING DATE
SERIAL NUMBER
POWER
0dB
SIGNAL
LIMIT
-15 +5
THERMAL
Left
Mixer or
Preamplifier
Line level
1202-VLZPRO
Line level
Output
ON
Right
Output
PARALLEL
MAIN INPUT
LOOP OUT
CAUTION
RISK OF ELECTRIC SHOCK
DO NOT OPEN
REPLACE WITH THE SAME TYPE FUSE AND RATING.
DISCONNECT SUPPLY CORD BEFORE CHANGING FUSE
SA1232
ACTIVE SOUND REINFORCEMENT
SPEAKER SYSTEM
CONCEIVED AND DESIGNED BY MACKIE DESIGNS INC, WOODINVILLE, WA, USA
AND MACKIE EUROPE • MANUFACTURED IN ITALY • COPYRIGHT ©2001 •
THE FOLLOWING ARE TRADEMARKS OR REGISTERED TRADEMARKS OF MACKIE DESIGNS INC.:
"MACKIE", AND THE "RUNNING MAN" FIGURE • PATENT PENDING
WARNING:
THIS SURFACE MAY REACH HIGH TEMPERATURE DURING
STANDARD USE. TO ENSURE PROPER OPERATION ALLOW A MINIMUM OF 6 INS.
OF CLEARANCE FROM THIS SURFACE AND ADEQUATE VENTILATION. TO REDUCE
THE RISK OF ELECTRIC SHOCK DO NOT REMOVE THIS PANEL OR ANY ATTACHED
COMPONENT. NO OPERATOR SERVICEABLE PARTS INSIDE. REFER SERVICING TO
QUALIFIED PERSONNEL. TO REDUCE THE RISK OF FIRE OR ELECTRIC SHOCK, DO NOT
EXPOSE THIS APPLIANCE TO RAIN OR MOISTURE.
AVIS:
RISQUE DE CHOC ELECTRIQUE — NE PAS OUVRIR
UTILISE UN FUSIBLE DE RECHANGE DE MÊME TYPE.
DEBRANCHER AVANT DE REMPLACER LE FUSIBLE
MANUFACTURING DATE
SERIAL NUMBER
POWER
0dB
SIGNAL
LIMIT
-15 +5
THERMAL
ON
5
Loading...
