Mackie REMOTE48BRO2 User Manual

REMOTE 48 CONTROLLER FOR HDR24/96 & MDR24/96 HARD DISK RECORDERS

POWER SWITCH.

Unique binary
algorithm allows
both off and on
modalities without
additional soft­ware.

POWER CORD SOCKET.

Built-in power
s u p p l y .

SILLY MANDATORY
L E T T E R I N G

opening the
Remote 48 and
sticking your
tongue on the
transformer
mains.

about not

TO HDR or MDR24/96 via

RJ45/Cat5 jacks
and cabling.

FOOT SWITCH JACK for

punch-ins via
gravity-assisted
c h i r o p o d a l
m a n i p u l a t i o n .

A truly professional remote for an equally professional hard disk recorder.

19.32" / 491 mm

12.0" / 305 mm

12.54" / 318 mm

12.54" / 318

3.25"

82.5 mm

©2001 Mackie Designs, All Rights Reserved. Mackie and the Running Man fi gure are registered trademarks of Mackie Designs Inc. All other trademarks are property of their respective companies. Specifi cations are preliminary and are subject to serious change at any moment.

mm

1.49"
38 mm

www.mackie.com

Mackie USA • 800.898.3211
outside the U.S., 425.487.4333
E-mail: [e-mail]

Mackie UK • 44.1268.571212
E-mail: [e-mail]

Mackie Italy • 39.0522.354111
E-mail: [e-mail]

Mackie Germany • 49.2572.96042-0
E-mail: [e-mail]

Mackie France • 03.85.46.91.60
E-mail: [e-mail]

REMOTE 48 CONTROLLER

professional recording tools

FOR HDR24/96 & MDR24/96
HARD DISK RECORDERS

REMOTE 48 CONTROLLER

T

A

o

p

O

T
b
o

a
d

u

R

n
N
L
p

r

o

a
2
b
o

R

C

hands-on creativity

rofessional hard disk recorders

P

require professional remotes. But
we went far beyond just transport
controls and record arm buttons
when we designed our Remote 48.
It fully duplicates the entire front
panel of our HDR24
Editor and MDR24
— including LCD and LED dis­plays, all function buttons and entry
keypad.

n fact, the Remote 48 adds fea­tures including a weighted jog/

I

shuttle wheel, additional Locate
Time display, 10 keypad and more.

se the Remote 48 to control
two HDR24

U

MDR24
connected to an HDR24
Remote 48 controller is fully inter­active with our recorder/editor’s
SVGA graphic user interface.

HDR24/96 RECORDER/EDITOR

/96 Recorder/
/96

Recorder

/96

s or two Mackie

/96

s or one of both. When

/96

ser ving s ugges tion

MDR24/96 RECORDER

REMOTE 48

, the

CUE number display shows the number of the Cue that was last

entered, Stored, or Recalled and also displays the names of
other stored values (Pre Roll, Loop length, Auto Punch, Num­bered locates, or Last Play position) during Recall.

RATES. Status LEDs show Sample Rate (44.1, 48 or 96kHz), Bit

Depth (16 or 24 bits) Sample Clock, and Time Code status
information.

LCD DISPLAY (identical to the ones on the front

panels of the MDR24

TIME UNITS button toggles the Time Units between

SMPTE and BBT on the Remote 48 and MDR/
HDR24

EDIT TIME lets you edit specifi c fi elds within the

Locate Time display. Pressing Edit Time once
selects the Frames/Ticks fi eld, a second time
the Seconds/Beats fi eld, etc.

+

Time fi eld values in Edit Time operations, act
as mat h operators in time code ca lculator oper­ations, and call up the next/previous Cue in
the Cue List in specifi c Recall and Store opera­tions.

PAGE LEFT AND PAGE RIGHT buttons navigate between

different pages in the current LCD display
menu. Menus that contain more than one page

display a ‘←’ or ‘→’ in the upper left or upper

right corner to indicate which direction you can
page to fi nd more choices within that menu.

SELECT buttons are softkeys that select the func-

tion described directly above them in the LCD
display.

SYSTEM CONTROL BUTTONS a c ces s LCD d is p l ay m e nu s

such as the Track, Project, Backup, Disk Util,
System, Digi I/O, and Sync menus.

LOCATE causes the Transport to jump to the time

displayed in the Locate Time window. The Locate
LED lights whenever the recorder is Stopped at

the Locate Time.

/96

front panels.

NEXT AND -PREV increment/decrement Locate

NUMERIC KEYPAD enters time values or Cue

numbers into the Locate Time or Cue
displays.

CLEAR deletes the last value entered into

the Locate Time or Cue number display
by shifting all of the numbers right by one
character. Pressing Clear after the last character
is deleted Cancels the operation and restores the
previous Locate Time value.

ENTER terminates the entry of a string of num-

bers when entering a time in the Locate Time
display, and completes Time Entr y, new Cue and
Cue Store operations.

STORE copies the value of the Locate Time or Tape

Time displays into Cues, Numbered Locates,
Pre-Roll time, and Loop and Punch lengths.

/96

and HDR24

/96

).

T

r
r

L

v

s

i

P

t
t

L

RECORD RE ADY BUTTONS for tracks 1-48.

CAPTURE copies the instantaneous value of

Tape Time into the Locate Time.

TAPE TIME always shows the current position

/96

of the MDR/HDR
rent Time), and is the same as the Cur­rent Time displays on the recorder front
panels.

“play head” (Cur-

LOCATE TIME displays the time that the

Transport will locate to when the Locate
button is pressed, and acts as a scratchpad
or working display from which you can
view stored time values, manually enter
and Store specifi c times to these values, or
display the result of time code addition/
subtraction operations.

RECORD SAFE disarms all tracks and disables

all recording controls. When enabled,
Record Safe prevents you from arming
tracks and entering record.

AUTO INPUT is used for record ing, and affect s

only armed tracks. When Auto Input is
On, all armed tracks monitor their inputs
except in Play, where tape playback is mon­itored. When Off, armed tracks always
monitor their inputs.

ALL INPUT is most often used for rehearsal

and level setting. When All Input is On,
both armed and unarmed tracks monitor
their inputs, and Auto Input has no effect.
When All Input is Off, output monitor­ing is determined by Auto Input.

JOG gives precise control over Transport

cueing by playing audio both forwards and
back wards at non real-time speeds in pro­portion to how the Wheel is rotated. Jog
play speed varies continuously between 0x
and 1x of normal play speed.

SHUTTLE allows you to play audio both for-

wards and backwards at non real-time
speeds in proportion to how far the Wheel
is rotated. Shuttle play speed is quantized
to 1/32, 1/16, 1/8, 1/4,1/2, 1x, and 2x the normal
play speed.

LOCK OUT disables user input from all soft-

ware and hardware controls while allow­ing the HDR/MDR24
operate normally.

/96

to otherwise

RECALL calls up the time of stored values

into the Locate Time display (Cues,
Numbered Locates, Pre Roll time,
Loop and Punch Lengths, last Play
position).

PREROLL is the amount of time by which the

transport location is offset when jumping
to a Cue or LOC point.

LOOP repeats playback between Loop Start

and the Loop End points (Locates 1 and

2). Punch and Loop, and Auto Take can
be used together to looped auto punch
operations.

TRANSPORT CONTROLS: Rewind,

Fast FWD, Stop, Play, Record.

NUMBERED LOCATE POINTS. sends the

Transports immediately to the
time set for that point.

PUNCH automatically punches into

Record at the punch in point, and
punches out of Record at the punch
out point.

REHEARSE al low s you to p r act i ce pu n c h i ng

without recording anything to disk, and
automatically stores the punch points to
the Auto Punch in and out points.

AUTOPLAY au t om at i c a l ly s t ar ts P l ayb a ck w h en

you’ve jumped to LOC or Cue point.

AUTO TAKE automatically increments the

active Virtual Take of all armed Tracks at
the beginning of each record pass.

JOG/SHUTTLE/DATA WHEEL i s u se d fo r d at a e nt r y

in cer tain Autolocator operations, such as
scrolling through the Cue List or chang­ing time values in edit time operations,
in addition to controlling Jog and Shuttle
motion.
